Threat Modelling with the GDPR towards a Security and Privacy

Metrics Framework for IoT Smart-farm Application

Steph Rudd and Hamish Cunningham

Department of Computer Science, University of Shefﬁeld, Shefﬁeld, U.K.

Keywords:

IoT, Smart-farms, GDPR, Privacy, DPIA, Energy Consumption, Risk Mitigation, Threat Modelling.

Abstract:

This paper considers a balance between privacy and security provisions for IoT devices constrained by pro-

cessing ability, energy consumption, and storage. Risk-driven testing is invoked in conjunction with the seven

GDPR principles towards a metrics framework suitable for such an energy-conscious network within the do-

main of IoT-oriented smart-farms. The resulting metrics framework demonstrates how the inﬂuence of privacy

can minimise processing requirements, whilst threat modeling assures security. The research concludes that

several redundant security provisions can be replaced with privacy alternatives that improve energy efﬁciency.

1 INTRODUCTION

With IoT the aim is always to reduce power - often

constrained devices rely on the limited power sup-

ply of batteries. Within the remit of IoT agriculture,

this aim extends to enable crop growth automatically,

without internet dependence, and supported by green

energy towards sustainably powering constrained de-

vices. Unfortunately, security implementation is a

threat to device lifespan. It is heavy in both power and

processing - a threat to the longevity of the environ-

ment, yet necessary to protect it from malicious and

accidental downfall. This research proposes a solu-

tion to the security and threat balance - how to reduce

the burden of security whilst protecting against down-

time using privacy functions pertinent to the Gen-

eral Data Protection Regulation (GDPR), and Soft

Systems Modelling (SSM), for a perspective beyond

cryptography metrics.

The outcome is a framework with agnostic appli-

cation to IoT environments exempliﬁed in the ﬁeld of

aquaponic smart-farming, with the following contri-

butions:

1. Content-driven: Vulnerabilities assessed on value

and impact enabled selectivity in protection.

2. Energy reduction: The framework prioritised

green-farming towards sustainability.

3. Worldview: SSM and GDPR provided valuable

insight into atypical threat factors.

4. Substitution: Privacy functions ranked by energy

use demonstrated GDPR application.

5. Additional attributes: Modelling using a world-

view enabled domain-speciﬁc data attributes.

The study begins with explaining the issues pertaining

to de facto standard Transport Layer Security (TLS),

and vulnerabilities of IoT. Next, related work consid-

ers modelling methods suitable for the environment,

risk-driven metrics and privacy substitution. Assess-

ment and scoring is then deﬁned before the frame-

work is invoked for testing. The results demonstrate

great beneﬁt of such a framework for modelling secu-

rity and privacy at the design stage by employing the

principles of TLS, SSM, GDPR and threat modeling,

but in a way to beneﬁt and sustain IoT operations very

different to traditional security application.

2 PROBLEM BACKGROUND

The problem is separated into an overlap between se-

curity and privacy, nature and vulnerabilities of IoT,

and the paradox of TLS, as the de facto security

standard for both traditional and constrained environ-

ments.

2.1 Security and Privacy

The misconceptions pertaining to the domain of pri-

vacy are likely due to the long-standing deﬁnitions of

Conﬁdentiality, Integrity, and Availability (CIA), be-

longing to security (Aminzade, 2018). Whereas secu-

rity deﬁnitions CIA relate to encryption, attestation of

Rudd, S. and Cunningham, H.

Threat Modelling with the GDPR towards a Security and Privacy Metrics Framework for IoT Smart-farm Application.

DOI: 10.5220/0010920800003194

In Proceedings of the 7th International Conference on Internet of Things, Big Data and Security (IoTBDS 2022), pages 91-102

ISBN: 978-989-758-564-7; ISSN: 2184-4976

non-tampering, and proof of origin respectively, pri-

vacy deﬁnitions refer to the rights of a living subject

through anonymity, pseudonymisation, and tokenisa-

tion (Varanda et al., 2021). Anonymisation means the

inability to identify a living person amongst a data set

- a series of values exempliﬁed by health data of a

group, for example, where many subjects will belong

to a group of age or gender, but none shall stand out as

an individual. Anonymisation is often used in statis-

tics for geography, health, demographics, and risk

factors like insurance. Pseudonymisation, compared

to anonymisation, does not alleviate data of all iden-

tiﬁable information - but reduces the link of a dataset

with the original identity of an individual.

Pseudonymisation and anonymisation as privacy

functions overlap with security, as they could mean

an encryption scheme, or a nickname with meaning to

operatives but not outsiders. They could also mean a

reference code, an artiﬁcial identiﬁer indexed against

the real data in a central server. Tokenisation is also

similar to encryption, but often operates on a simple

substitution to disguise data such as credit card num-

bers. Tokenisation can therefore be ‘unlocked’ with-

out a key, particularly with well known credit card to-

kenisation algorithms used as part of the Cardholder

Data Environment (CDE) (El Alloussi et al., 2014), of

PCI DSS (Razikin and Widodo, 2021).

The approval of PCI DSS for use of cryptographic

alternatives such as pseudonymisation for sensitive

data, indicates that negation of heavily mathematical

functions is entirely safe, practical, and even encour-

aged under the governing bodies of ﬁnancial regula-

tion. This work investigates where it is safe to substi-

tute security functions for privacy.

2.2 Nature and Vulnerabilities of IoT

IoT networks by nature are chaotic, constrained, and

heterogeneous - opposite of the capabilities and re-

sources of typical computers such as desktop ma-

chines and smartphones. However, particularly in

the case of microcontrollers (as opposed to micro-

computers), their constraint and simplicity provides

natural protection. In the way that a calculator

cannot be exploited through lacking architecture, a

microcontroller is naturally without Operating Sys-

tem (OS) or the problems that go with it. De-

velopments of microcontroller-oriented developments

such as Serial Peripheral Interface Flash File System

(SPIFFS) (Espressif, 2021a), Mongoose OS (Espres-

sif, 2021b), and the Arduino webclient (Microcon-

trollerslab, 2019), increase the threat landscape by

removing this natural robustness of IoT simplicity.

Attempting to transform machines comparable with

those of the 1990’s towards modern expectations,

weighs heavily on the storage and energy restrictions.

TLS is a reﬂection of such unreasonable expectations;

it is centralised, rigid, and contradicts notions of het-

erogeneous freedom and spontaneity. However, TLS

is strong, widespread, and available for most, if not

all, communications protocols.

2.3 Rigidity of TLS

As the long-standing de facto standard in online secu-

rity, TLS has carried ubiquity onto IoT, with libraries

for both software and embedded devices, and dedi-

cated hardware acceleration in some microcontrollers

such as the ESP32 (ESP32, 2021). However, the ben-

eﬁts of TLS end at the convenience of ubiquity. De-

signing an agnostic security application to satisfy the

same standards as TLS would be quite a challenge,

particularly since the CIA functions are readily avail-

able. Therefore the challenge is not to reinvent TLS

security, but disrupt everything about it apart from

the ubiquitous functions - as a challenge centric to

carbon-neutrality and device longevity, this is moti-

vation enough to accept.

Now, TLS relies on invoking a channel to agree

on the authenticity of the server which a client wishes

to connect with. The client interrogates the server, to

ascertain it is who it claims to be, before agreeing to

send over any sensitive information such as username

and password credentials. Subsequently the server’s

identity is conﬁrmed through the medium of an X.509

certiﬁcate, or more speciﬁcally, the Digital Signature

Algorithm (DSA) on that certiﬁcate, and then the se-

cure session begins. This is the way online transac-

tions have taken place for decades.

Now, if the network entities do not intend to use

web browsers, Certiﬁcate Authorities (CA), an OS,

SPIFFS, or any other complications pertaining to their

detriment, they do not need the certiﬁcate either. The

reason for this is, without a browser, the certiﬁcate

need not be kept, since it is for browser display behind

the TLS handshake. Without the browser, devices can

authenticate perfectly well using regular TLS func-

tions and without all the unnecessary infrastructure.

This deals with the centralised aspect that would oth-

erwise stiﬂe equality and distribution throughout the

network.

To address energy consumption this is where risk

assessment becomes so valuable. Since the TLS chan-

nel must no longer be invoked due to removing the

centralised infrastructure, security functions can be

employed with disregard to the rules of that channel.

This allows freedom to employ CIA or privacy func-

tions on a very ﬂexible basis. It is important to em-

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

brace the standards and reasoning behind TLS, and so

related works on risk-driven assessment for address-

ing the energy-security-privacy balance shall now be

investigated.

3 RELATED WORK

Related work considers how a requirements analysis

of the smart-farm domain would be fulﬁlled, threat

modelling strategies, relevance of privacy under the

GDPR, and security under the CIA.

3.1 Domain Requirements

From a business perspective, production input com-

pared with output justiﬁes domain viability. In the

context of a smart-farm, this balance is delicately

subject to the power vs processing tradeoff (Pavlovi

et al., 2021); a paradigm in which microcontrollers

provide system monitoring and control ideally un-

der the jurisdiction of green energy. If that green

energy can supply all the energy required to fulﬁll

the paradigm of carbon-neutral or negative crop pro-

duction, the application is feasible, and if it can’t, it

isn’t. Since security application threatens resources

of constrained networks with such energy burdens,

Soft Systems Modelling (SSM) (Sarrala, 2021), is a

good place to scope basic requirements and eliminate

frivolous procedures.

The ‘seven stages’ is an activity model based

on domain context, achievable changes and action-

able points, whereas ‘two stream’ model refers to

logic-based analysis with cultural and political in-

ﬂuence, similar to the ‘four main activities’ model.

The CATWOE model identiﬁes people, processes and

environments which contribute to a situation, and

is the most appropriate approach given that security

should be tailored to an environment and its vul-

nerabilities. On this basis of environmental inﬂu-

ences, other notable business models include SWOT

and TOWS; Strengths Weaknesses Opportunities and

Threats from internal and external direction.

3.2 Threat Modelling Strategies

There are several risk-driven methodologies for se-

curity at the systems design phase. STRIDE is the

most mature (Mauri and Damiani, 2021), and pro-

vides threat-speciﬁc variants to arrange property vi-

olations identiﬁable in Data Flow Diagrams (DFDs)

of the system design. An immediate problem with

STRIDE in the smart-farm domain is the presump-

tion of speciﬁc vulnerabilities according to the top

ten, which in a heterogeneous environment, may not

be applicable.

PASTA (Shin et al., 2021), describes a seven-stage

model of activities to combine business objectives and

technical requirements. It is attacker-centric, con-

siders governance, architecture and operations, and

may reﬂect the concerns of the domain better than

STRIDE.

LINDDUN (Robles-Gonzalez et al., 2020),

largely concerns privacy, with a systematic approach

inﬂuenced by DFD-illustrated entities, data stores,

processes and data ﬂows. With reference to the

aforementioned overlap between privacy and security,

LINDDUN will be a valuable approach.

CVSS (Walkowski et al., 2021), provides a nu-

merical score of a vulnerability based on its charac-

teristics. The CVSS consists of three metrics groups

(base, temporal and environmental), and is often used

in conjunction with other threat-modelling methods.

CVSS is not useful for the smart-farm security appli-

cation design, but as part of a penetration test follow-

ing implementation, towards remediation. It will not

be used.

Persona non Grata (PnG) (Mantha et al., 2021),

considers the motivations and skills of human attack-

ers by characterising attackers as archetypes for sys-

tem misuse towards speciﬁc goals. Use case scenarios

are generally helpful in system design, and so this will

be a beneﬁcial security application of such scenarios.

TRIKE, was created as a security audit framework

from a defensive perspective, understanding actors,

assets, intended actions and rules based on a DFD,

and then dividing each one into one of two categories

- elevation of privilege or denial of service. Since this

framework assumes that users are very active in the

system, it is irrelevant - the aquaponics system aims

for autonomy. The same disregard applies for the

VAST threat model.

3.3 GDPR and the CIA

Privacy by Design (PbD) has been proposed as a

Quantitative Threat Modeling Methodology (QTMM)

(Luna et al., 2012), by risk assessment based on

privacy-related attacks. The difference between

privacy-oriented assessment is that other forms of

threat modelling are largely agnostic of involved data

subjects (Sion et al., 2019). The GDPR sets 99 ar-

ticles and 173 recitals towards protecting the privacy

of personal and sensitive data for subjects - and pro-

cesses to attain that protection, with and without se-

curity functions.

Although the aquaponics system is largely de-

void of personal and sensitive data belong to human

Threat Modelling with the GDPR towards a Security and Privacy Metrics Framework for IoT Smart-farm Application

subjects (we shall assume the ﬁsh don’t mind), then

the usefulness of the GDPR pertains to assessing a

‘data-oriented’ or ‘content-based’ attack risk, and ide-

ally will result in substitution of security functionality

with the less mathematical privacy functionality. Fol-

lowing the GDPR principle of ‘necessary processing

of data and nothing more than absolutely necessary’,

the challenge is to reduce protected content, and pro-

cessing wherever possible.

GDPR privacy functions can be realised in several

ways:

• Data masking (Larrucea et al., 2021): refers to

disclosure of data with modiﬁed values. This

could be character shufﬂing, tokenization, en-

cryption, or character substitution - one of the

oldest forms of cryptography. Substitution is

where a value is exchanged for another value, to

make identiﬁcation or reverse engineering difﬁ-

cult. This character set will be the same through-

out the policy, but may turn into a centralised pro-

cess.

• Pseudonymisation (Kangwa et al., 2021): data

de-identiﬁcation that substitutes private identi-

ﬁers with false identiﬁers or pseudonyms. “John

Smith” could be changed to “Mark McConnell”,

but this would require some form of centralised

database.

• Generalisation or minimisation (Goldsteen et al.,

2021): the removal of data to prevent identiﬁca-

tion, such as a house number of an address, so

accuracy of data remains whilst not being too spe-

ciﬁc.

• Perturbation (Broen et al., 2021): the use of

round-numbering and adding random noise to

modify a dataset. The set of values must be pro-

portionate to noise to avoid disturbance, making

this method quite complex.

• Synthetic data (Slokom and Larson, 2021): is

algorithmically-generated information with no re-

lation to the real case. These datasets represent

patterns from real data by invoking standard devi-

ation, linear regression, medians and other statis-

tical methods. It is of no use to our comparatively

simple model.

• Permutation (Barati et al., 2021): data swap-

ping or shufﬂing rearranges dataset attributes so

that they do not ﬁt original information, often by

switching columns in databases.

4 ASSESSMENT METHODS

This section considers the purpose of the security ap-

plication with appropriate risk-based methodologies,

how objective scoring can be calculated given the

application parameters, and the inﬂuence of GDPR

compliance.

4.1 Addressing Purpose

The purpose of the security application does not re-

quire typical considerations (Ankele et al., 2019), and

the outcome will not be maximum security, granular-

ity of roles or rules enforcement. IoT demands an un-

usual assessment method; to reduce security as much

as safely possible for the longevity and autonomy of

the domain.

Privacy Impact Assessment (PIA), and Privacy

Threat Analysis (PTA), have been derived from se-

curity assessment models but do not consider privacy

systematically, and so LINDDUN was invoked to sat-

isfy this concern towards attributes Identiﬁcation and

Authentication (IA) (Robles-Gonzalez et al., 2020).

Since IA are ubiquitous security procedures, the PIA

and PTA approaches exemplify objective measure-

ment, and how two entities can operate as a unit to-

wards data reduction.

Although LINDDUN describes the use of DFDs

to deﬁne a problem space, the smart-farm domain

should be considered by content in preference to pro-

cess ﬂow. The reasons behind invoking metrics for

content are the same as GDPR but with the focus on

reduction of means rather than addition.

Data Protection Impact Assessments (DPIA),

form metrics based on business impact which will

then provide a risk score often requiring additional

protection to mitigate that risk. Generally this is

a positive approach - data can freely move around

email, desktop folders, and portal hierarchies tiered

by roles. The challenge with typical application is

therefore to compose an exhaustive overview of hu-

man activity and put in place as many preventative

measures as needed. In a smart-farm domain largely

operating by autonomy of sensors and without an OS

for human-oriented navigation, data cannot as easily

be accessed, manipulated, lost or duplicated. As a re-

sult, it would be more fruitful to list the content by

style of data dictionary and align privacy and security

laws to each attribute, than it would to compile addi-

tional processes.

Data dictionaries are useful to exhaust all the pos-

sible system attributes proposed for security applica-

tions, without limiting the potential for data ﬂow later

on, this is because even as systems expand by network

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

entities or sensors, ideally the security principles will

not change. There is no need to deﬁne a number of

maximum sensors as long as we know what type of

topology is appropriate, and we do not limit attributes

by a ﬁnite set. Security must be designed on the basis

of inﬁnite network expansion, and this way of design-

ing is useful to ensure that scalability threats such as

the data cumulation of blockchain will never occur.

4.2 Objective Scoring

The Open Web Application Security Project

(OWASP), provides a risk rating template (OWASP,

2021), to objectively evaluate risk severity by multi-

plying likelihood of attacks from threat agents and

vulnerabilities, by impact on technical systems and

business continuity. Factor scores are ranked 1-9,

based on a ‘worst case scenario’, and are fulﬁlled by

the following criteria:

Estimating Likelihood: Threat Agent Factors.

• Skill level: How technically skilled the threat

agents are.

• Motive: How motivated the group is likely to be,

on desirability of reward.

• Opportunity: Resources and opportunities re-

quired.

• Size: The origin and position of threat agents

against the system.

Estimating Likelihood: Vulnerability Factors.

• Ease of discovery: How easy it was to discover

the vulnerability.

• Ease of exploit: How easy it is to perform the ex-

ploit.

• Awareness: The assumed knowledge of the ex-

ploit to the threat agents.

• Intrusion detection: How likely it is that the ex-

ploit will be detected.

Estimating Impact: Technical Factors.

• Loss of conﬁdentiality: How much data could be

disclosed and how sensitive it is.

• Loss of integrity: How much the data could be-

come corrupted and how damaged it would be.

• Loss of availability: How much of the service

could be lost, and the vitality of that service.

• Loss of accountability: The traceability of the

threat to their origin.

Estimating Impact: Business Factors.

• Financial damage: Resulting ﬁnancial loss from

an exploit.

• Reputation damage: The extent to which reputa-

tion damage would cause the business.

• Non-compliance: How much exposure non-

compliance would introduce.

• Privacy violation: The amount of resulting per-

sonal and sensitive information disclosure.

Resulting scores in low risk severity are not a con-

cern, and medium scores are considered tolerable

with monitoring, but high and critical results require

immediate attention. To expand this template for IoT

smart-farm application, additional factors and PbD

solutions should be considered based on the results

of the SSM testing; CATWOE, BATWOVE, SWOT

and TOWS.

4.3 GDPR Compliance

The GDPR (Chikukwa, 2021), is a set of requirements

composed of 173 recitals within 99 articles, to address

seven principles. Big data systems have addressed

GDPR requirements by mapping them to IT design

for compliance of collection, storage, and analytics

(Rhahla et al., 2021). The seven principles are out-

lined below with implications of smart-farm compli-

ance.

Lawfulness, Fairness and Transparency. When-

ever processing personal data, there must be a good

reason for doing so, and the user must have given con-

sent, be necessary to fulﬁl a legal obligation, for the

protection of vital interests of a natural person or a

public task for the interest of the public, and ﬁnally,

with proof of legitimate interest. Reasons for process-

ing must be transparent and reasonable.

Purpose Limitation. There must be a speciﬁc, ex-

plicit and legitimate reason for collecting this data.

This reason must be justiﬁed in a sense that there is

no alternative, and that data must be collected for this

purpose.

Data Minimisation. Only collect the smallest

amount of data possible for the purpose, additional

data is not permitted. For example, email subscrip-

tions should be limited to email addresses and not

names, phone numbers or addresses.

Accuracy. Accuracy should be ensured on collec-

tion and storage, which is the responsibility of the

collector.

Threat Modelling with the GDPR towards a Security and Privacy Metrics Framework for IoT Smart-farm Application

Storage Limitation. The length of time data is

stored must be justiﬁed. In the UK, the standard

for data retention is seven years. Integrity and conﬁ-

dentiality Although integrity is always necessary and

consistent by deﬁnition between privacy and security,

conﬁdentiality in a privacy sense does not necessarily

mean encryption of data, but to preserve the privacy of

an identiﬁable subject, whilst keeping it secure from

internal and external threat.

Accountability. This is the proof that an organisa-

tion is complying with the GDPR and actually doing

it - appropriate measures must be in place which su-

pervising authorities can request at any time. This can

be achieved by privacy by design and default.

5 METRICS AND RESULTS

Results of SSM are presented to outline the require-

ments of the application. From the CATWOVE and

TOWS, additional attributes were deduced, and the

data attributes listed by sensitivity. Security and pri-

vacy functionality was then ordered by energy con-

sumption, and ﬁnally the full metrics framework

demonstrated beneﬁts of privacy and SSM design.

5.1 CATWOVE

CATWOE (Moumivand et al., 2021), and BATWOVE

(Ireland et al., 2012), were combined to produce Cus-

tomers, Actors, Transformation, World-view, Owner,

Victims and Environment (CATWOVE), as a frame-

work for deﬁning business stakeholder perspectives.

From the resulting concerns of this analysis, attributes

can be considered for threat modelling and subse-

quently aligned with quantitative risk severity scores

and solutions.

Customers: Consumers, green interests, investors,

farmers, food retailers.

Actors: Researchers, engineers, plant and computer

scientists, green energy interests.

Transformation: Security energy consumption to

extend smart-farm battery life.

Worldview: Reducing security strength wherever

safely possible, based on data content.

Owner: The model ignores TLS recommendations

and instead uses ‘threshold’ security.

Victims: Each type of content must be considered,

and the TLS channel will not be used.

Environment: All content must be considered, and

TLS recommendations are ignored.

The security application intends to reduce energy

waste towards environmentalism for the beneﬁt of

any system operating constrained devices. However,

there is a threshold approach to the security levels of

this solution, and that threshold is considerably lower

than TLS recommendations stipulate. The metrics

framework is designed to quantify the risks of such

threshold-based practice to justify safety.

5.2 TOWS

Strengths, Weaknesses, Opportunities and Threats

(SWOT), is a classic business strategy tool and TOWS

is a variant of the same acronym to extend SWOT

from an internal environment to an external one

(Javaid, 2021). The aim of this model is to draw

domain-speciﬁc attributes such as communication

ranges and architectural details, which will impact the

attributes of the metrics framework later on.

Internal Strengths: No browser, restricted internet

access, hardware-accelerated crypto functions.

External Strengths: Range of communications pro-

tocols, one-to-one device relationships in BLE.

Internal Weaknesses: Battery life, overheads of

cryptography, frequency of data transmission.

External Weaknesses: Lack of solar and wind in the

Northern hemisphere and at night.

Internal Opportunities: Selective use of cryptogra-

phy, data volume, privacy functions, protocols.

External Opportunities: Green energy - solar, wind,

piezoelectric etc for charging device batteries.

Internal Threats: Sabotage by authorised access,

downtime. External threats: Physical tampering, ma-

licious attempts at network downtime by protocols.

SO: Strengths to Maximize Opportunities. Pro-

tocols belonging to IoT such as BLE, MQTT and Lo-

RaWAN, are considerably lighter than the internet,

and drain battery life at a much slower rate. As a re-

sult, a combination of reducing computation by selec-

tive cryptography, utilising green energy can sustain

the network without mains electricity. In conjunction

with the carbon dioxide absorbed by crop production,

this can become a carbon-negative environment.

ST: Strengths to Minimise Threats. The use of

short-range communications protocols reduces the

threat landscape to that limited range. Use of the in-

ternet opens the network to threats of a global scale,

whereas the use of BLE for example, restricts the

threat to anyone outside of a 100m range at most.

WO: Minimise Weaknesses by Taking Advantage

of Opportunities. With the exclusive one-to-one

device relationships supported by BLE, the threat

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

landscape becomes even smaller. Each device owns

its own public-private key pair and long-term relation-

ships promote the notion of infrequent authentication,

as relationships are static until the system fails. As a

result, the relationships stay the same, recognise each

other, and use little power in re-authenticating.

WT: Minimize Weaknesses and Avoid Threats.

This is about defensive strategies to minimise loss

rather than promote success. The notion of ‘adequate’

or ‘threshold’ security is emphasised here to main-

tain a good balance between power and computation,

where security is lowered as much as safely possible,

whilst battery life beneﬁts as much as possible by suf-

fering from the least feasible computation.

5.3 Additional Attributes

IoT-speciﬁc attributes derived from the SSM study

were: Time to exploit: The longevity of the data in

the system. Physical range: The distance between

two devices of each protocol. Key length by time:

Key strength of relevant authentication keys.

5.4 Data Attributes

The ‘data dictionary’ was ordered by rank of sensitiv-

ity, where 1 was most sensitive, 10 the least:

1. Private keys: Private keys of the Public-Private

key pair of device authentication should be a long-

standing, impenetrable set for delivering data with

guaranteed conﬁdentiality.

2. AES keys: These keys are not as long-standing

but should be capable of full conﬁdentiality.

HMAC-SHA keys: This key ensures integrity and

authentication of each message.

3. Initialisation Vector (IV): This key is for harden-

ing session ciphers.

4. Instruction code: This does not require conﬁden-

tiality for the most part, but small amounts do.

5. Readings: These require integrity and authentica-

tion, but not conﬁdentiality.

6. MAC address: This can be spoofed and should be

connected with other security.

7. IP address: This can be spoofed and should be

connected with other security.

8. Digital signatures: Proof of sender origin, and can

be transferred without any CIA.

9. Public keys: Intended to be public identiﬁers of

each device to decrypt transmissions.

5.5 Functionality Reduction

Functions of TLS can be applied individually and at

the discretion of an application that does not require

abiding by heavyweight regulations to function. This

is because a TLS channel will not be employed, but

the TLS library will. The challenge is ﬁrst to deter-

mine the least energy-consumptive TLS application,

and then if privacy functions can be used for substi-

tution. Due to the vast number of TLS functions, ap-

plications, protocols and attack scenarios, it is most

straightforward to rank functions by strength and en-

ergy consumption, where the strongest is highest con-

sumption, but least risk severity. Using this method, a

similar outcome to the OWASP DPIA was produced:

Threat agent factors have been removed as it is good

practice to assume agents are motivated and skilled.

5.5.1 Security Application

This set considers what kind of basic protection the

data attributes require compared with what they are

worth as a reward from an exploit. It is a good way

of comparing typical TLS and internet applications

against IoT by applying TLS-standards to deduce a

result and comparing it against the IoT environment

to determine which properties could be lightened or

removed given the ﬂexibility.

Table 1 describes protection requirements where

the difference between privacy and conﬁdentiality

represent GDPR and encryption techniques respec-

tively. From an IoT perspective, readings need not

be fully protected, because it makes no difference if

threat agents can see them or not. It does however

matter that they are integrity-assured and with proof

of origin. Digital signatures can be delivered in plain-

text with zero protection, as they represent proof of

origin. In these examples, the two most common data

transmissions require no encryption - a huge energy

saving to the IoT system that is not available when

employing TLS.

Table 1: Protection: How much protection is required for

this attribute.

Severity

score

Attribute

1 Plaintext, no CIA or GDPR required.

2 Integrity and availability required.

3 Integrity, availability, and some privacy

required.

4 Integrity, availability, and guaranteed

conﬁdentiality required.

Table 2 represents the value of the exploit reward

and correlates with how much security it should have

Threat Modelling with the GDPR towards a Security and Privacy Metrics Framework for IoT Smart-farm Application

by that value. Low value material need not employ

heavyweight protection, and ideally all data that can

be transparent should be to reduce costs. This table

differs from the ﬁrst in a sense of motivation - whereas

any network implementer will be inclined to protect

data rigorously, if there is no motive to steal it, they

should be discouraged from doing so.

Table 2: Value: Value of exploited data on success.

Severity

score

Attribute

1 No value at all.

2 Value in conjunction with other data

exploits.

3 Reputation and business disruption.

4 Full downtime, ﬁnancial reward or ku-

dos.

Table 3 is unique to IoT and was deduced from the

SSM earlier. Since most of the communications will

take place within a small and restricted environment,

the threat landscape is not representative of global ap-

plications, and this further reduces the need for heavy

security.

Table 3: Physical range: Accessibility of communications

protocol.

Severity

score

Attribute

1 1:1 relationships, up to 100m range.

2 1:1 relationships, up to 10km range.

3 M:N relationships, up to 1000 nodes.

4 M:N relationships, global range and

unlimited nodes.

5.5.2 Energy Consumption

This set considers how long data attributes are in use

compared against the security applied to them. It is

useful to compare TLS default features in energy con-

sumption against ideal IoT consumption. As a rule of

thumb, the more ephemeral the data, the less heavy

the protection need be - but TLS contradicts this by

applying top security for all transactions.

Table 4 describes the frequency of reprocessing

the security application of data.

Table 5 describes the symmetric, asymmetric, and

Elliptic Curve Cryptography (ECC), security tiers.

80-bit security is very easy to break and is not in-

cluded. 112-bit security has been deprecated by TLS,

but could be used for short-lived attributes such as

session key exchange prior to key derivation, or One-

Time Pads (OTP).

Table 4: Frequency: Of security processing of data.

Severity

score

Attribute

1 Weeks and months.

2 Days and weeks.

3 Hours and days.

4 Seconds and hours.

Table 5: Security strength: The level of security according

to TLS.

Severity

score

Attribute

1 None.

2 AES-112, RSA-2048, ECC-224, less

strong and less costly.

3 AES-128, RSA-3072, ECC-256, quite

strong and less costly.

4 AES-256, RSA-15,360, ECC-521, very

strong but very costly.

Table 6 describes the sensitivity of data against

business impact, and should be assessed on the as-

sumption that data has been attained for malicious in-

tent.

Table 6: Sensitivity: The intended exposure to the public.

Severity

score

Attribute

1 Designed to be public.

2 Not designed to be public but of no

consequence.

3 Designed to be private and could be

critical with other data.

4 Designed to be secret and will be criti-

cal.

5.5.3 Privacy Substitution

This set is intended to provide potential differences in

energy consumption by changing TLS settings. Low

outcomes demonstrate little difference in energy use,

but attention should be paid to medium, high and crit-

ical results, where a large amount of energy can be

saved.

Table 7 represents energy savings based on reduc-

ing encryption key strengths. At the time of writing,

an AES-112 key is safe for around 15 years, and AES-

128 is quantum-proof for considerably longer (Barker

and Roginsky, 2018). Coupled with the fact that a net-

work operating on such small range communications

such as BLE or LoRaWAN, smaller keys are safe for

application. In an environment where security is so

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

strong and energy so critical, all efforts towards re-

duction can safely be made.

Table 7: Encryption: The amount of reduction available by

TLS standard.

Severity

score

Attribute

1 No reduction in encryption strength.

2 Reduce to bit-strength AES-192, RSA-

7680 or ECC-384.

3 Reduce to bit-strength AES-128, RSA-

3072 or ECC-256.

4 Reduce to bit-strength AES-112, RSA-

2048 or ECC-224.

Table 8 represents changes applied to data using

privacy functions, ranked by lowest energy (1), to

highest energy use (4).

Table 8: Privacy: Function substitution graded by strength.

Severity

score

Attribute

1 Pseudonymisation or tokenisation.

2 Data masking, substitution, or permu-

tation.

3 Plain text without privacy.

4 Data anonymised by removing at-

tributes.

Table 9 represents changes in data frequency,

where attributes such as device authentication can be

extended given the permanent nature of device rela-

tionships. This is a different scoring system to protec-

tion of data, where rather than short-lived data being

safer and cheaper, the reduction is placed on using it

for longer periods of time in order to process it less.

Table 9: Computation time: Frequency of security or pri-

vacy to data.

Severity

score

Attribute

1 Seconds and hours.

2 Hours and days.

3 Days and weeks.

4 Weeks and months.

5.6 Comparison Results

Generally, results of low are ideal, medium is accept-

able, high requires attention and critical equates to

running the system towards downtime given poor en-

ergy management.

Table 10 shows energy consumption using TLS:

Table 10: TLS results.

Data at-

tribute

Ref Security

appli-

cation

Energy

con-

sump-

tion

Privacy

substi-

tution

Private

keys

1 4 4 4

AES

keys

2 4 4 4

HMAC-

SHA

keys

3 4 4 4

IV 4 3.33 3.50 3.50

Instruction

code

5 3.33 3.50 3.50

Readings 6 3 3.25 3.25

MAC

address

7 3 2.5 2.5

IP ad-

dress

8 3 2.5 2.5

Digital

signa-

tures

9 4 3.25 3.25

Public

keys

10 4 3.25 3.25

Average

Score

- 3.567 3.375 3.375

Severity - Critical High High

5.6.1 Security Application

With TLS, security application is what it is, and there

is no ﬂexibility - the data is either sent using TLS and

is under full protection, or no security is applied at

all. As a result, every result is under full protection.

The values vary, as some data ranges from public to

secret, and the range of technologies can change such

as MAC used for BLE. Range does not make a dif-

ference when using TLS, because the assumption is a

global scale network of unlimited nodes. All scores

return as high or critical.

5.6.2 Energy Consumption

Critical scoring has been saved by the nature of the

data, and not the actions of TLS. Readings and MAC

addresses owning public status lower the score of en-

ergy consumption, but it is still a high score, and that

means a short lifespan for battery or green-powered

networks.

Threat Modelling with the GDPR towards a Security and Privacy Metrics Framework for IoT Smart-farm Application

5.6.3 Privacy Substitution

The keys could all be reduced to recomputing every

few months to reﬂect the strength of AES. Reducing

the cipher to 112-bit would be beneﬁcial; despite the

warnings from TLS that 112-bit is inadequate, it is

still safe for several years, and the threat landscape

is so small without a browser or global access, and

atypical communications protocols such as BLE.

In summary, TLS is very high in security and en-

ergy consumption, but also very high in mitigation op-

tions given the ability to make them.

Table 11 shows energy consumption using a de-

sign framework to model an IoT security application:

Table 11: Privacy by design results.

Data at-

tribute

Ref Security

applica-

tion

Energy

con-

sump-

tion

Privacy

substi-

tution

Private

keys

1 3 2.75 2.75

AES

keys

2 3 2.75 2.75

HMAC-

SHA

keys

3 2.33 2.25 2.25

IV 4 2.33 2.25 2.25

Instruction

code

5 2 2 2

Readings 6 1.33 1.25 1.25

MAC

address

7 1 1 1

IP ad-

dress

8 1 1 1

Digital

signa-

tures

9 1 1 1

Public

keys

10 1 1 1

Average

Score

- 1.8 1.725 1.725

Severity - Low Low Low

5.6.4 Security Application

The beauty of energy consumption, security and pri-

vacy by design is that the consumption can be as-

sessed before implementation. Here security appli-

cation is the highest consumption of energy because

the keys require full CIA, and without it there would

be full downtime. However, the nature of other data

has changed from full protection to optional privacy

(instructional code), and no conﬁdentiality or privacy

(readings). The range of device communications has

also changed from a presumption of global threat to

a small network less than 100m between pairs of de-

vices.

5.6.5 Energy Consumption

Severity scores requiring encryption are higher than

others because encryption is computationally expen-

sive. The score is still an overall low, and leaves little

room for improvement.

5.6.6 Privacy Substitution

The keys could all be substituted with forms of

pseudonymisation or tokenisation, and with an ex-

tended lifespan given the strength of AES. Reduction

was not available for any attribute since the design in-

dicated a value and sensitivity assessment pointing to

the many attributes not requiring full protection. This

consistency is a good indication that security and pri-

vacy by threat-base modelling offers beneﬁts to the

IoT environment.

In summary, the scores were low throughout, and

there was little energy reduction ability given the ben-

eﬁts offered by the framework earlier on, whereas

TLS returned critical and high, the IoT network re-

turned low.

6 CONCLUSION AND FURTHER

WORK

The metrics framework has provided an effective way

to identify areas of security available for energy re-

duction using privacy functions. The following con-

tributions were made:

6.1 Content-driven

Vulnerabilities were based on assessing the content

of data attributes and transmissions. Selective secu-

rity was applied to the majority of data, saving large

amounts of energy where TLS would automatically

apply high-level security. A lot of data was discov-

ered to be of little value in plaintext, and so making it

transparent but retaining integrity assurance and mes-

sage authentication meant there is less attack motiva-

tion.

6.2 Energy Reduction

Whereas risk-driven methodologies aim towards de-

fense, this framework offers the novelty of security

reduction towards energy conservation. The biggest

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

100

threat to an IoT environment is the constraint of power

and processing which reduce device lifespan. As long

as security is ‘adequate’ then extending the longevity

of the network is a priority. The metrics framework

demonstrated how energy reduction can be identiﬁed

by using risk modelling so that non-threatening secu-

rity is possible.

6.3 Worldview

The use of SSM allowed a wider analysis not typically

employed in security assessments. This was useful

to establish the beneﬁts and concerns of an IoT do-

main away from protection needs, which in turn was

very useful for providing adequate protection without

superﬂuous energy use. Since the communications

protocols were so short in range compared to internet

use, and many of the transmissions were deemed low

value, the majority of computing could be alleviated.

6.4 Substitution

The use of GDPR allowed a list of available functions

not typically employed in security design. Since most

of the data could be generalised or pseudonymised

in whole or part, selectivity of standard TLS func-

tions was applied. Substituting security functions for

privacy functions reduced the energy consumption of

the domain enormously, and the metrics framework

demonstrated the areas in which substitution could

make high and critical differences to energy use.

6.5 Additional Attributes

Modelling using a worldview enabled domain-

speciﬁc data attributes. Attributes not normally con-

sidered in risk assessment for security applications

made a big difference in energy use. By consider-

ing the domain from a business perspective, attributes

such as range and the value of content during data

transmissions gave insight into how security functions

could either be reduced to privacy or removed com-

pletely. Although TLS does not provide the ﬂexibility

to do this, the functions belonging to TLS can be ap-

plied to retain strength and ubiquity of security whilst

avoiding the high costs.

The framework was designed to have agnostic

application - future work could include health care,

blockchain and industry towards sustainability in re-

duced energy use.

REFERENCES

Aminzade, M. (2018). Conﬁdentiality, integrity and avail-

ability – ﬁnding a balanced IT framework. Netw. se-

cur., 2018(5):9–11.

Ankele, R., Marksteiner, S., Nahrgang, K., and Val-

lant, H. (2019). Requirements and recommendations

for IoT/IIoT models to automate security assurance

through threat modelling, security analysis and pen-

etration testing. In Proceedings of the 14th Interna-

tional Conference on Availability, Reliability and Se-

curity, number Article 102 in ARES ’19, pages 1–8,

New York, NY, USA. Association for Computing Ma-

chinery.

Barati, M., Aujla, G. S., Llanos, J. T., Duodu, K. A., Rana,

O. F., Carr, M., and Rajan, R. (2021). Privacy-Aware

cloud auditing for GDPR compliance veriﬁcation in

online healthcare. IEEE Trans. Ind. Inf., pages 1–1.

Barker, E. and Roginsky, A. (2018). Transitioning the use of

cryptographic algorithms and key lengths. Technical

report, National Institute of Standards and Technol-

ogy.

Broen, K., Trangucci, R., and Zelner, J. (2021). Measuring

the impact of spatial perturbations on the relationship

between data privacy and validity of descriptive statis-

tics. Int. J. Health Geogr., 20(1):3.

Chikukwa, G. (2021). A Consent Framework for the Inter-

net of Things in the GDPR Era. PhD thesis, Dakota

State University.

El Alloussi, H., Fetjah, L., and Chaichaa, A. (2014).

Securing the payment card data on cloud environ-

ment: Issues & perspectives. International Journal

of Computer Science and Network Security (IJCSNS),

14(11):14.

ESP32 (2021). https://www.esp32.net. Accessed: 2021.

Espressif (2021a). https://www.espressif.com. Accessed:

2021.

Espressif (2021b). https://www.espressif.com. Accessed:

2021.

Goldsteen, A., Ezov, G., Shmelkin, R., Mofﬁe, M., and

Farkash, A. (2021). Data minimization for GDPR

compliance in machine learning models.

Ireland, V., Cavallo, A., Omarova, A., Ooi-Sanches, Y., and

Rapaport, B. (2012). Approaches in addressing sys-

tem of systems. In 2012 7th International Conference

on System of Systems Engineering (SoSE), pages 380–

385.

Javaid, N. (2021). Integration of context awareness in inter-

net of agricultural things. ICT Express.

Kangwa, M., Lubobya, C. S., and Phiri, J. (2021). Pre-

vention of personally identiﬁable information leak-

age in e-commerce via ofﬂine data minimisation and

pseudonymisation. Int. J. Innov. Sci. Res. Technol,

6(1):209–212.

Larrucea, X., Mofﬁe, M., Mor, D., and Others (2021). En-

hancing GDPR compliance through data sensitivity

and data hiding tools. JUCS-Journal of Universal

Computer Science.

Luna, J., Suri, N., and Krontiris, I. (2012). Privacy-by-

design based on quantitative threat modeling. In 2012

Threat Modelling with the GDPR towards a Security and Privacy Metrics Framework for IoT Smart-farm Application

101

7th International Conference on Risks and Security of

Internet and Systems (CRiSIS), pages 1–8.

Mantha, B., Garc

ıa de Soto, B., and Karri, R. (2021). Cyber

security threat modeling in the AEC industry: An ex-

ample for the commissioning of the built environment.

Sustainable Cities and Society, 66:102682.

Mauri, L. and Damiani, E. (2021). Stride-ai: An approach

to identifying vulnerabilities of machine learning as-

sets. In 2021 IEEE International Conference on Cyber

Security and Resilience (CSR), pages 147–154.

Microcontrollerslab (2019). Esp32 web server in arduino

ide: Control leds.

Moumivand, A., Azar, A., and Toloie Eshlaghy, A. (2021).

Combined soft system methodology and agent-based

simulation for multi-methodological modelling. Syst.

Res. Behav. Sci., (sres.2802).

OWASP (2021). https://www.owasp.org. Accessed: 2021.

Pavlovi

c, N.,

Sarac, M., Adamovi

c, S., Sara

cevi

c, M., Ah-

mad, K., Ma

cek, N., and Sharma, D. K. (2021). An

approach to adding simple interface as security gate-

way architecture for IoT device. Multimed. Tools

Appl.

Razikin, K. and Widodo, A. (2021). General cybersecurity

maturity assessment model: Best practice to achieve

payment card Industry-Data security standard (PCI-

DSS) compliance. CommIT (Communication and In-

formation Technology) Journal, 15(2):91–104.

Rhahla, M., Allegue, S., and Abdellatif, T. (2021). Guide-

lines for GDPR compliance in big data systems.

Journal of Information Security and Applications,

61:102896.

Robles-Gonzalez, A., Parra-Arnau, J., and Forne, J. (2020).

A linddun-based framework for privacy threat analysis

on identiﬁcation and authentication processes. Com-

put. Secur., 94:101755.

Sarrala, T. (2021). Uncovering privacy threats with Soft

Systems Methodology: Development of a privacy

threat modelling method for today’s needs. PhD the-

sis.

Shin, Y.-J., Cho, E., and Bae, D.-H. (2021). PASTA:

An efﬁcient proactive adaptation approach based on

statistical model checking for Self-Adaptive systems.

Fundamental Approaches to Software Engineering,

12649:292.

Sion, L., Van Landuyt, D., Wuyts, K., and Joosen, W.

(2019). Privacy risk assessment for data Subject-

Aware threat modeling. In 2019 IEEE Security and

Privacy Workshops (SPW), pages 64–71.

Slokom, M. and Larson, M. (2021). Doing data right:

How lessons learned working with conventional data

should inform the future of synthetic data for recom-

mender systems.

Varanda, A., Santos, L., Costa, R. L. d. C., Oliveira, A.,

and Rabad

ao, C. (2021). Log pseudonymization: Pri-

vacy maintenance in practice. Journal of Information

Security and Applications, 63:103021.

Walkowski, M., Oko, J., and Sujecki, S. (2021). Vulnerabil-

ity management models using a common vulnerability

scoring system. NATO Adv. Sci. Inst. Ser. E Appl. Sci.,

11(18):8735.

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

102
