Exploring User-centered Requirements Validation and Veriﬁcation

Techniques in a Social Inclusion Context

Emille Catarine Rodrigues Canc¸ado

, Ian Nery Bandeira

, Pedro Henrique Teixeira Costa

Jos

e Fortes Neto, Daniel Carvalho Moreira, Lu

ıs Amaral

and Edna Dias Canedo

Department of Computer Science, University of Bras

ılia (UnB), P.O. Box 4466, Bras

ılia, DF, Zip-cod 70910-900, Brazil

ednacanedo@unb.br

Keywords:

Former Inmates, Social Inclusion, Requirements Veriﬁcation and Validation, Privacy, Prototyping.

Abstract:

The activities that comprise a requirements engineering process involve elicitation, modeling, validation, and

veriﬁcation of requirements, and these activities tend to be more communication and interaction-intensive than

others during the software development process. This paper presents an experience report on requirements

validation and veriﬁcation techniques applied to a mobile application project developed for the Brazilian prison

system’s former inmates, aiming to support them in their resocialization process. Besides, it presents the

decisions we made in agreement with the project stakeholders to guarantee the end-users data privacy. Our

results show that even with the Covid-19 pandemic and social isolation restrictions, it was possible to apply

the requirements validation techniques. Furthermore, the mobile application’s acceptance tests with both

stakeholders and the end-users demonstrate that the developers duly followed the privacy guidelines. Finally,

all privacy requirements comply with the stakeholders and the application’s end-users needs and are under the

Brazilian General Data Protection Law (LGPD).

1 INTRODUCTION

A software’s set of requirements must be validated

to ensure that the stakeholders’ needs are being ad-

dressed and that the deﬁned quality criteria are being

fulﬁlled (Lampa et al., 2017). Therefore, it is nec-

essary to validate and verify the requirements to de-

tect any errors or inconsistencies in the team’s elicited

and documented requirements for this activity (Bjar-

nason et al., 2014). Software requirements valida-

tion encompasses validation and veriﬁcation activities

(Nascimento et al., 2021). Veriﬁcation is perceived

as sufﬁcing the precepts of correction and complete-

ness of requirements, while validation is understood

as meeting users’ expectations (Fiorini et al., 1998;

do Prado Leite and Freeman, 1991).

Validation and veriﬁcation of elicited require-

ments are related to the quality of the software. Thus,

as software systems become more complex, concerns

https://orcid.org/0000-0002-1283-8391

https://orcid.org/0000-0002-8083-7278

https://orcid.org/0000-0002-8385-8314

https://orcid.org/0000-0003-1236-3119

https://orcid.org/0000-0002-2159-339X

about validating and verifying requirements increase

since it is necessary to ensure that each error has

been identiﬁed and corrected (McMillan et al., 2019).

Therefore, the non-alignment of requirements engi-

neering with veriﬁcation and validation can lead to

software deployment problems regarding the dead-

line, quality, and scope (Bjarnason et al., 2014).

The legal requirements of software also need to be

veriﬁed and validated (Santos et al., 2017), especially

in the current context. There is speciﬁc legislation to

guarantee users’ data privacy. In Brazil, the General

Data Protection Law (LGPD) came into force in 2020,

which establishes the rules for collecting, storage,

treatment, and sharing personal data, imposing more

protection and penalties for non-compliance with the

principles of the law by organizations (Macedo, 2018;

BRASIL, 2020). The LGPD covers all personal data

collected, stored, and processed by public and pri-

vate organizations with an international reach (Bax

and Barbosa, 2020; Ferr

ao et al., 2021; Canedo et al.,

2021; Canedo et al., 2020).

This paper presents a case study of requirements

validation and veriﬁcation techniques applied in soft-

ware development to support the Brazilian prison sys-

tem’s former inmates. As it is a more vulnerable

Cançado, E., Bandeira, I., Costa, P., Neto, J., Moreira, D., Amaral, L. and Canedo, E.

Exploring User-centered Requirements Validation and Veriﬁcation Techniques in a Social Inclusion Context.

DOI: 10.5220/0010959900003179

In Proceedings of the 24th International Conference on Enterprise Information Systems (ICEIS 2022) - Volume 1, pages 85-92

ISBN: 978-989-758-569-2; ISSN: 2184-4992

group, our choices related to data privacy were re-

shaped so as not to be intimidating to the end-users,

for instance, not saving end-users personal informa-

tion and creating the possibility for former inmates to

use all the application services, even if one chooses

not to permit any of their device’s native tools in the

app, such as its location service. We also analyzed the

impact of using these techniques on an actual software

project amidst the period of social isolation caused by

the Covid-19 pandemic.

2 VALIDATION AND

VERIFICATION TECHNIQUES

The requirements validation and veriﬁcation process

consist of reviewing, analyzing, and testing the re-

quirements to ensure that the designed system is com-

patible with the users’ needs (Laplante, 2017). Sev-

eral techniques in the literature address the validation

and veriﬁcation of requirements (Bertini et al., 2006;

Kalinowski et al., 2007; Maalem and Zarour, 2016;

Bhatti et al., 2015; Pohl, 2016):

1. Review by a Specialist – This technique is based

on using a specialist’s knowledge to check the

quality of the requirements. The specialist re-

views all requirements and looks for problems

such as inconsistency or ambiguity. When the re-

viewer ﬁnds a problem, he/she comments on the

documentation for errors and possible solutions to

ﬁx them.

2. Inspection of Requirements – This technique

consists of a team with different responsibilities

(Pohl, 2016): Organizer: Plans and controls the

inspection process; Moderator: Lead the ses-

sions, always maintaining the inspection follow-

up as agreed in the initial stages; Author: Re-

sponsible for explaining the requirements to in-

spectors in the early stages of the project. The

author is also responsible for correcting the errors

identiﬁed in the process’s steps; Reader: Member

of the team that will guide inspectors in the face

of the various requirements to be inspected. The

reader’s job is to take the inspector’s responsibil-

ity away from interpreting what the author meant,

and they can focus on the requirement itself; In-

spectors: Responsible for detecting faults and

reporting them to other members of the project

team; Secretary: Responsible for taking the re-

sults of the session and compiling them, in addi-

tion to preparing the minutes of the session. In-

spection within the context of requirements val-

idation can be divided into the stages of plan-

ning, overview, fault detection, and fault collec-

tion: (Pohl, 2016):

(a) Planning: In this step, one deﬁnes the objec-

tive of the inspection, the planning of the pro-

cess, and the functions of each participant;

(b) Overview: In this phase, the author details all

the requirements for his/her team so that every-

one is aware of the system in question and can

clarify any doubts;

amine the requirements and document the pos-

sible faults for the next step. Fault ﬁnding can

be done either as a team or individually. The

group search has the advantage of communica-

tion and consequent synergy between inspec-

tors whilst the individual search makes every-

one focused on the work;

(d) Fault Collection: In this last step, all faults

presented in the detection stage are reevaluated

to avoid duplication or to remove faults classi-

ﬁed incorrectly.

3. Walkthrough – It is a technique similar to in-

spection, but it is a more straightforward and less

rigid version (Pohl, 2016). The division of the

team is simpliﬁed, in which the same person can

perform several functions. In this technique, the

functions of at least one reviewer, author, secre-

tary, and moderator are used. This technique aims

to identify ﬂaws in the requirements and share

the project’s understanding among the people in-

volved in the inspection.

4. Veriﬁcation in Different Perspectives – This

technique validates the requirements through an

interpretation of the system, taking into account

different perspectives. The perspectives usually

vary from system to system, but it is possible to

elicit at least some types that usually occur in ev-

ery project, and that can be adapted:

(a) Perspectives of Stakeholders –

User perspective: The user checks the re-

quirements from his/her perspective and

checks whether it matches the reality and

expected quality; Developer perspective: The

developer veriﬁes that the requirements contain

all the information and properties necessary for

the project to be completed; Test perspective:

The tester veriﬁes whether it is possible to

make test cases that satisfy the entire project

based on the elicited requirements.

(b) Perspectives of System Quality –

Documentation perspective: From this per-

spective, it is ensured that the documentation

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

involving the requirements meets all the criteria

that have been deﬁned;

Content perspective: Perspective that deals

with the content of the requirements itself and

focuses on the quality of that content;

Perspective of agreement: In this perspective,

the focus is on ensuring that everyone involved

in the project is following the elicited require-

ments and that there is no conﬂict to be re-

solved.

5. Prototyping Validation – Prototype is a prelimi-

nary model of a complete system. Thus, what this

technique does is to use this model in favor of re-

quirements validation. Based on the project pro-

totype, requirements can be tested and validated

practically by the stakeholders, checking if they

meet the expectations. Prototypes can be divided

depending on their destination in disposable pro-

totypes or evolutionary prototypes (Pohl, 2016).

The disposables are only for the current test. They

will not be put into production again since the

evolutionary is a constantly evolving prototype as

the project develops and requires more work to

be done. For a prototype to be made, it is neces-

sary to select the requirements that it will contem-

plate. This set does not typically cover all docu-

mented requirements as it would bring very high

costs and complexities. Therefore, it is necessary

to make a selection criterion among the require-

ments and determine the most suitable to be used

in the prototype. Along with the prototype itself,

three more documents are needed to validate the

requirements (Pohl, 2016): a manual containing

all the usage and application information; a doc-

ument containing several scenarios for validating

requirements; and a checklist for each of the re-

quirements that will be validated. Scenarios that

are not included in the documents can and should

be tested after the entire process to verify the sys-

tem in different situations and circumstances that

were not planned initially. After the validation

is completed, the results are compiled and dis-

cussed. Changing, removing, or adding require-

ments are consequences during this step. If the

changes are very large or impactful, it is advisable

to remodel the prototype to cover these changes,

and it is possible to carry out a new validation

(Pohl, 2016).

6. Checklist Validation – The checklist technique is

used in complex projects and when the system has

several issues that need to be taken into account.

Checklists can be used in conjunction with many

other techniques and are made up of questions or

statements to identify errors in the requirements.

The source for assembling the checklist can come

from both stakeholders and requirements quality

criteria. The list can constantly be updated as

the project progresses. New features and require-

ments emerge, so removing ambiguous questions,

editing, and adding information are always wel-

come as the project develops. The success of the

technique will depend on the length and complex-

ity of the checklist. A very long and complete list

of details can make the process slower and unfea-

sible for the inspector. The same thing can happen

if the list is very subjective, making the validation

process slow and susceptible to failures.

3 SOFTWARE REQUIREMENTS

The Virtual Social Ofﬁce (ESVirtual) purpose is to fa-

cilitate access to services and support the former in-

mates and their families (de Mendonc¸a et al., 2020)

The mobile application provides access to informa-

tion on services and policies for assisting people from

the Brazilian prison system by giving opportunities

to take online courses, providing job advice, infor-

mation about Health Care, proof of compliance with

sentence conditionalities for people on semi-open and

open prison regimes, among other features.

Among the requirements validation and veriﬁca-

tion techniques presented in Section 2, we used veri-

ﬁcation from different perspectives and validation by

prototyping in software development in this research.

In an effort to ensure that every possible necessity

of both the public and the creators of the Virtual So-

cial Ofﬁce would be met, we opted to use veriﬁcation

from different perspectives. Along with the develop-

ment, testing, and design leads, we analyzed the per-

spective of three different entities:

1. The Brazilian National Council of Justice (CNJ)

administrative staff, who have overall knowledge

of the resocialization process and which, despite

not working directly with the app’s target audi-

ence, have facilitating expertise in devising tools

for the ﬁnal product’s deployment and dissemina-

tion;

2. Employees of the physical social ofﬁce, who di-

rectly serve the app’s target audience, since the

physical social ofﬁces already provide assistance

to former inmates in their resocialization process;

3. Potential end-users, who have experiential knowl-

edge of their particular processes and might pos-

sess insight into critical issues and features not ad-

dressed by the other two parties.

Exploring User-centered Requirements Validation and Veriﬁcation Techniques in a Social Inclusion Context

Validation by prototyping was employed in an at-

tempt to ensure ease of communication between the

different project stakeholders since suggestions could

be better understood and debated when embodied and

evaluated in a prototype. In addition, prototyping

might facilitate the communication process between

the project’s design and development teams to pre-

vent the idealization of any functionality that is not

feasible for development.

3.1 Veriﬁcation in Different

Perspectives

In the ESVirtual development, we carried out the

validation and veriﬁcation of requirements from the

stakeholders’ perspectives and the system’s quality.

Regarding the stakeholders’ perspectives, those re-

sponsible for the project are Brazilian National Justice

Council administrative staff, who regard this applica-

tion as a tool to support the re-socialization process

of former inmates. These executives have selected

some physical Social Ofﬁce members to validate the

requirements along with three potential end-users.

The stakeholders’ and users’ validation was per-

formed through online meetings. The project lead de-

signer presented to the meeting participants the pro-

totypes proposed for the application’s functionalities.

The validation and veriﬁcation meetings were held

one week after eliciting requirements for the respec-

tive functionality. In case an error was detected in

the understanding of the requirement, we recorded the

observations. In the following week, we presented the

proposed prototype’s updates to the stakeholders un-

til there were a consensus and the validation of the re-

quirement. Thus, the requirement was only forwarded

to the software development team after its validation

by the stakeholders.

From the test and developers’ perspectives, we

tested the functionalities using integrated technolo-

gies through programs that simulate the application’s

use from a user’s perspective. We created auto-

matic actions on the screen using command lines,

and through the answers presented, it was possible to

carry out a general analysis. Thus, we expected re-

sponsive activities on the screen according to the se-

quence of pre-established actions.

We could analyze the application’s response time,

the availability of features, and errors that may arise

without prior knowledge from the automated tests.

Also, these tests could reveal bugs in the features re-

sulting in a different procedure than expected, thus

predicting future errors that could come to the end-

user of the application. We tested all possible ac-

tions related to the application’s functionality to ex-

pose, predict and correct possible errors that could

occur through malfunction behavior. Error prevention

allows preventing failures from remaining in the ap-

plication and ﬁnd possible improvements for the user

experience. We use some tools to perform this type of

tests, namely: Cucumber (Li et al., 2016; Fazzolino

et al., 2018), tool developed in the Java language, used

to describe all the scenarios and steps that were simu-

lated in the application.

The Appium (Alotaibi and Qureshi, 2017), tech-

nology responsible for integrating other tools into the

application and executing the steps deﬁned in Cucum-

ber, promoting the communication and execution of

the commands to be executed on the screen automat-

ically. For the most part, the operation of Cucumber

occurs through references that are pre-labeled in the

front-end project through identifying each feature that

has an assigned reference name. It allows localization

on screen and the necessary action of the feature to

obtain the application’s expected response. In addi-

tion to the identiﬁcation property, others such as po-

sitions of elements using height and width references

on the screen and the response time were considered

in the execution of the test sessions.

We used Cucumber to describe the steps that, the-

oretically, would be performed by an actual user of the

application, an emulator, or a physical device. The

Cucumber was responsible for running the applica-

tion, and the Appium tool was responsible for making

the communication between Cucumber and the appli-

cation on the device. Figure 1 shows one of the tests

performed to verify the functioning of the functional-

ity required for health facilities. This requirement is

responsible for providing information on basic health

units, emergency services, psychosocial care centers,

and hospitals to former inmates from the prison sys-

tem. We performed all the steps described in Cucum-

ber in an actual use scenario. Besides, we corrected

the found errors before the implementation phase, and

the speciﬁcations of the Virtual Social Ofﬁce require-

ments were updated.

Figure 1: Veriﬁcation of Health Facilities requirements.

The perspective of the system’s quality was real-

ized through the content, in which three researchers of

the project initially validated the screens of the proto-

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

type, developed from the elicited requirements. Sub-

sequently, we validated the prototypes again with the

project stakeholders to guarantee that all requirements

were in line with expectations and that there was no

conﬂict between the decisions adopted.

Figure 2 (a) presents the proposed prototype for

the speciﬁed requirement of the Health Facilities

functionality, also validated through the testing per-

spective (Figure 1). All inconsistencies/errors de-

tected in the veriﬁcation from different perspectives

were corrected, and we implemented suggestions for

improvements in the prototypes before the next phase

of the software development process.

4 PROTOTYPING VALIDATION

The prototyping of the requirements can be used as a

validation technique, identifying the problems in the

speciﬁcation of requirements from a visual perspec-

tive of the software under development (Bilal et al.,

2016). Aceituna et al. (Aceituna et al., 2011) stated

that prototyping could prevent more errors than re-

quirements validated in natural language. Prototyp-

ing allows us to include non-technical stakeholders in

the inspection process and validate, with less time and

cost, the hardware and software requirements of a sys-

tem (Aceituna et al., 2011).

We prototyped all the ESVirtual features to val-

idate with the stakeholders before going to the im-

plementation phase. First, the elicitation of require-

ments occurred in face-to-face meetings at the Na-

tional Council of Justice headquarters. Subsequently,

due to the Covid-19 pandemic, virtual meetings were

held using the Microsoft Teams tool

. We choose

this tool because both institutions involved in the de-

velopment of the project (National Council of Justice

(CNJ) and University of Bras

ılia (UnB)) adopted it.

Requirements elicitation meetings were held

weekly with various project stakeholders and re-

searchers and lasted an average of 02 hours. During

the meetings, the functionalities were discussed, and

the stakeholders passed on the necessary information.

Then the researcher Designer of the project later per-

formed the prototyping of the ESVirtual’s function-

alities. We prototyped all the functionalities of the

application using the tool Figma (Figma, 2021).

We carefully reviewed all functionalities with the

stakeholders in the prototyping phase, aiming to pro-

vide a solution according to the former inmates’ needs

and with a friendly interface because it is an applica-

tion that serves a fragile audience. After the proto-

https://teams.microsoft.com/

typing of the functionalities, we presented the newly

proposed solution to the stakeholders. During the

presentation, the meeting participants discuss doubts,

and in some situations, there were suggestions for im-

provements and reformulation of the proposed solu-

tion. These reviews allow the ESVirtual to be an ally

to the end-user searching for important information

for their re-socialization process.

As an example, it is worth mentioning the pro-

posed solution for the requirement “ Food ”. The pur-

pose of this functionality in the ESVirtual application

is to indicate to the user (former inmates) food facil-

ities to ﬁnd meals at a popular price. If the user per-

mits the application to access their location, they will

have access to a list of places that offer food, ordered

by proximity, as shown in Figure 2 (b). Ordering by

proximity helps them to take the shortest route/path to

reach a community restaurant.

Figure 2: (a) Validation of the prototype of the health facil-

ities requirements and (b) “Food” functionality with access

to the user’s location.

However, sharing the location can be sensitive in-

formation for many users. Even if the application

does not save the location information, some may

choose not to provide this data. In this way, if the

users choose the application not to access their loca-

tion, they can indicate the state and city to consult

and access the complete list of community restaurants

in alphabetical order. Figure 3 presents the proposed

prototype for the requirement speciﬁed for this func-

tionality. Although the user does not know the dis-

tance of these restaurants concerning his current loca-

tion, he is not deprived of accessing the application’s

information.

All errors found in the validation activity in the re-

quirements elicitation phase were corrected, and we

implemented some suggestions for improvements in

the functionalities. Thus, we can conclude that us-

ing the techniques of validation and veriﬁcation of

requirements was positive since all users could vali-

date the requirements elicited through different per-

spectives and the prototypes proposed for each func-

Exploring User-centered Requirements Validation and Veriﬁcation Techniques in a Social Inclusion Context

Figure 3: “Food” functionality without access to the user’s

location.

tionality of the application.

In addition to using the techniques to perform the

validation and veriﬁcation of requirements in the ini-

tial phases of the project, we also carried out a valida-

tion with the project stakeholders after implementing

all software requirements. The stakeholders and users

performed the validation by downloading the appli-

cation from Play Store stores (for Android platform

users) and Apple Store stores (for iOS users). Par-

ticipants in the validation activity performed all the

features provided and made available in the ESVir-

tual. We did not ﬁnd impacting errors that could harm

the evolution of the ESVirtual. Thus, we can con-

clude that the veriﬁcations and validations before the

implementation phase were essential for the delivered

project’s quality.

5 DATA PRIVACY

We developed the ESVirtual for a vulnerable popula-

tion that seeks to re-socialize in society. Thus, we

elicited the software requirements to keep the end-

users’ information conﬁdential to avoid embarrass-

ment on the former inmate or situations considered

difﬁcult and/or embarrassing by them. Therefore, the

requirements elicitation ensure that users’ data were

not requested and maintained when using the appli-

cation’s functionalities. For this reason, according to

the ESVirtual speciﬁcation, the system developed will

only attend queries to public data provided by differ-

ent government agencies. There is no need to keep a

the consultations anonymously to public data. As the

system does not store user information, no actions

were necessary to guarantee the user’s data privacy.

The functionality called “Legal Situation” allows the

former inmates to monitor their processes’ execution

through a private consultation using a personal access

key.

The project development team opted to use the

POST request method, from the HTTP (Tanenbaum

and Wetherall, 2011) protocol, to pass the query key

to the processes so that this data was not part of the

query URL. Besides, the HTTPS protocol was used,

which implements the HTTP protocol with an ad-

ditional layer of security over Secure Socket Layer

(SSL), so that all requests are encrypted, thus guaran-

teeing the security of the execution of the functional-

ity. The prototype of the “Legal Situation” function-

ality is shown in Figure 4.

Figure 4: “Legal Situation” functionality.

6 DISCUSSIONS

The Virtual Social Ofﬁce application’s proposed re-

quirements stemmed from discussions and interviews

held with the National Council of Justice (CNJ) stake-

holders, prison system former inmates, and Social Of-

ﬁce of Esp

ırito Santo employees. These requirements

guided the layout and usability solutions proposed by

the project designer, and the prototyping of the solu-

tions on the Figma Design Tool (Figma, 2021) facil-

itated the process of monitoring and validation of the

entire team and stakeholders, and through the visual

concept rendered by the prototype, stimulated further

discussions involving the gathering of new require-

ments and the validation of requirements already pro-

posed.

Using the validation technique involving multi-

ple perspectives enabled all parties involved in the

project to validate the requirements, whether from

the stakeholders’, end-users’, developers’, or project

researchers’ perspectives. The physical Social Of-

ﬁce employees and the former inmates who partici-

pated in our meetings fulﬁlled essential development

roles. Their inputs and insights, which are from peo-

ple closely intertwined with the re-socialization pro-

cess, aligned the development and design teams for

features that effectively reach the application’s target

audience. Such interaction among the contributors al-

lowed for interesting exchanges related to user expe-

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

rience, solution usability, and possible technologies

which might be employed to support the application’s

acceptance by the end-users.

The validation by prototyping proved to be highly

adequate and enabled the project’s design team’s in-

volvement in the software release schedule and the

requirements prioritization. The prototypes were sub-

mitted to the Scrum master and the project devel-

opment team right after the stakeholder validation

to ensure that any concerns and features were ex-

plained to the team. Each solution proposed by the

design team is discussed with the project’s lead en-

gineer to ensure the proposed approach’s feasibility.

Errors found during the validation and requirements

veriﬁcation phase and after the application was pub-

lished online were negligible and could be addressed

quickly. Furthermore, the use of prototypes proved

to be extremely important for the idealization of the

application’s functionalities by the entire team during

the Covid-19 pandemic, in which only non-presential

meetings were held. This graphic resource allowed

easier comprehension of all the proposed ideas, ﬁl-

tered and represented by the design team, and then

discussed, reviewed, and validated by the entire team.

This process, along with the interaction between

the project members, reduced the risks of errors,

usability failures, or wrongly implemented require-

ments by the development team. Besides, the ﬁn-

ished prototypes were of high graphic quality, facil-

itating the appraisal from every member involved and

accurately representing every detail of what was ex-

pected as an outcome from the development team. As

a result, this eased the entire process of implementing

new features. Also due to the social isolation period

resulting from the Covid-19 pandemic, meetings be-

tween the research team and the stakeholders became

more limited. This limitation resulted in the research

team having to make critical decisions to develop the

app without the stakeholders’ direct involvement. The

prototyping and requirements validation enabled all

such decisions to be easily identiﬁed, understood, and

validated before the app’s release in the stores.

Furthermore, the usability tests with end-users

were also impaired due to social isolation, especially

among sensitive groups with low education levels or

little to no familiarity with mobile devices. However,

the app’s alpha version allowed virtual usability tests

with three former inmates, which were able to con-

solidate the proposed solutions and point out not only

constructive criticism towards what had already been

implemented but also requirements that they deemed

relevant and that had not been addressed in the app so

far.

7 CONCLUSIONS

In this paper, we provide an experience report on the

use of software requirements validation and veriﬁca-

tion techniques applied to real-world software devel-

opment. We conducted these processes using veriﬁ-

cation from different perspectives and validation by

prototyping. These results have shown how the tech-

niques have mitigated the likelihood of errors during

the requirements engineering process. Furthermore,

performing the validation made it possible to pinpoint

possible errors in advance of the beta testing period,

as all members involved could assess the proposed so-

lutions in both functioning prototypes and the appli-

cation’s alpha version.

The requirements validation also allowed the

stakeholders and end-users to ensure that the privacy

of the user’s data was being guaranteed in the devel-

opment process, as per the requirements elicitation

performed, and whether it complied with the LGPD

standards. For future projects, we intend to work to-

wards the requirements elicitation for new applica-

tion functionalities based on interviews and discus-

sions with the CNJ stakeholders, former inmates of

the prison system, and employees of physical Social

Ofﬁces across the country. New tests will also be con-

ducted with stakeholders and former inmates, hope-

fully with more participants with varying age, edu-

cation, and gender proﬁles. Also, we will perform a

usability evaluation on the ESVirtual application em-

ploying the set of usability heuristics for quality as-

sessment of mobile applications on smartphones, pro-

posed by Ruyther et al. (da Costa et al., 2019). Simul-

taneously, we will investigate the application’s impact

on the re-socialization process of Brazilian prison sys-

tem former inmates.

ACKNOWLEDGMENTS

We want to thank the National Council of Justice for

supporting this research. This work has been partially

supported by FAP-DF (the Brazilian Federal District

Research Foundation).

REFERENCES

Aceituna, D., Do, H., and Lee, S. (2011). Interactive

requirements validation for reactive systems through

virtual requirements prototype. In First Model-Driven

Requirements Engineering Workshop, MoDRE 2011,

Trento, Italy, August 29, 2011, pages 1–10. IEEE

Computer Society.

Exploring User-centered Requirements Validation and Veriﬁcation Techniques in a Social Inclusion Context

Alotaibi, A. A. and Qureshi, R. J. (2017). Novel framework

for automation testing of mobile applications using

appium. International Journal of Modern Education

& Computer Science, 9(2).

Bax, M. P. and Barbosa, J. L. S. (2020). Proposta de mecan-

ismo de consentimento na lei geral de protec¸

ao a da-

dos - LGPD (consent mechanism proposal in LGPD).

In ONTOBRAS, volume 2728 of CEUR Workshop

Proceedings, pages 316–321, http://ceur-ws.org/Vol-

2728/doctorate4.pdf. CEUR-WS.org.

Bertini, L. A., Kirner, T. G., Montebelo, M. I., and Lara,

I. A. R. (2006). T

ecnicas de inspec¸

ao de documentos

de requisitos de software: um estudo comparativo. In

Alencar, F. M. R., S

anchez, J., and Werneck, V., edi-

tors, Workshop on Requirements Engineering (WER),

Rio de Janeiro, RJ, Brasil, Julho 13-14, 2006, pages

67–74.

Bhatti, S. N., Usman, M., and Jadi, A. A. (2015). Validation

to the requirement elicitation framework via metrics.

ACM SIGSOFT Software Engineering Notes, 40(5):1–

Bilal, H. A., Ilyas, M., Tariq, Q., and Hummayun, M.

(2016). Requirements validation techniques: An em-

pirical study. International Journal of Computer Ap-

plications, 148(14).

Bjarnason, E., Runeson, P., Borg, M., Unterkalmsteiner, M.,

Engstr

om, E., Regnell, B., Sabaliauskaite, G., Locon-

sole, A., Gorschek, T., and Feldt, R. (2014). Chal-

lenges and practices in aligning requirements with

veriﬁcation and validation: a case study of six com-

panies. Empir. Softw. Eng., 19(6):1809–1855.

BRASIL (2020). Guia de boas pr

aticas – lei geral

de protec¸

ao de dados (lgpd). Comit

e Central de

Governanc¸a de Dados. Secretaria de Governo Digi-

tal, 1–65.

Canedo, E. D., Calazans, A. T. S., Masson, E. T. S., Costa,

P. H. T., and Lima, F. (2020). Perceptions of ICT

practitioners regarding software privacy. Entropy,

22(4):429.

Canedo, E. D., Cerqueira, A. J., Gravina, R. M., Ribeiro,

V. C., Cam

oes, R., dos Reis, V. E., de Mendonc¸a, F.

L. L., and de Sousa Jr., R. T. (2021). Proposal of an

implementation process for the brazilian general data

protection law (LGPD). In ICEIS (1), pages 19–30.

SCITEPRESS.

da Costa, R. P., Canedo, E. D., de Sousa J

unior, R. T.,

de Oliveira Albuquerque, R., and Garc

ıa-Villalba,

L. J. (2019). Set of usability heuristics for quality

assessment of mobile applications on smartphones.

IEEE Access, 7:116145–116161.

de Mendonc¸a, W. L. M., Costa, P. H. T., Canc¸ado, E. C. R.,

Lima, F., Canedo, E. D., Bonif

acio, R., and Amaral, L.

H. V. (2020). From dusk till dawn: Reﬂections on the

impact of COVID-19 on the development practices of

a r&d project. In SBES, pages 596–605. ACM.

do Prado Leite, J. C. S. and Freeman, P. (1991). Require-

ments validation through viewpoint resolution. IEEE

Trans. Software Eng., 17(12):1253–1269.

Fazzolino, R., de Faria, H. M., Amaral, L. H. V., Canedo,

E. D., Rodrigues, G. N., and Bonif

acio, R. (2018). As-

sessing agile testing practices for enterprise systems:

A survey approach. In SAST, pages 29–38. ACM.

Ferr

ao, S.

E. R., Carvalho, A. P., Canedo, E. D., Mota, A.

P. B., Costa, P. H. T., and Cerqueira, A. J. (2021). Di-

agnostic of data processing by brazilian organizations

- A low compliance issue. Inf., 12(4):168.

Figma (2021). The collaborative interface design tool.

Figma, accessed on march 5, 2021.

Fiorini, S. T., do Prado Leite, J. C. S., and de Lucena, C.

J. P. (1998). Organizando processos de requisitos. In

Workshop on Requirements Engineering(WER), pages

1–8.

Kalinowski, M., Sp

ınola, R. O., Dias-Neto, A., Bott, A.,

and Travassos, G. H. (2007). Inspec¸

oes de requisitos

de software em desenvolvimento incremental: Uma

experi

encia pr

atica. VI Simp

osio Brasileiro de Quali-

dade Software (SBQS), Porto de Galinhas, Brazil.

Lampa, I. L., de Godoi Contessoto, A., Amorim, A. R.,

Zafalon, G. F. D., Val

encio, C. R., and de Souza, R.

C. G. (2017). Project scope management: A strategy

oriented to the requirements engineering. In Proceed-

ings of the 19th International Conference on Enter-

prise Information Systems - Volume 2: ICEIS,, pages

370–378. INSTICC, SciTePress.

Laplante, P. A. (2017). Requirements engineering for soft-

ware and systems. CRC Press.

Li, N., Escalona, A., and Kamal, T. (2016). Skyﬁre: Model-

based testing with cucumber. In ICST, pages 393–400.

IEEE Computer Society.

Maalem, S. and Zarour, N. (2016). Challenge of validation

in requirements engineering. J. Innov. Digit. Ecosyst.,

3(1):15–21.

Macedo, P. N. (2018). Brazilian general data protection law

(lgpd). Brazilian National, accessed on January 18,

2021, 1(1):1–16.

McMillan, C., Crapo, A., Durling, M., Li, M., Moitra,

A., Manolios, P., Stephens, M., and Russell, D.

(2019). Increasing development assurance for system

and software development with validation and veri-

ﬁcation using assert™. Technical Report 2019-01-

1370, SAE Technical Paper.

Nascimento, R., Souza, L., Targino, P., Siz

ılio, G., Kulesza,

U., and Lucena, M. (2021). Investigating information

about software requirements in projects that use con-

tinuous integration or not: An exploratory study. In

Proceedings of the 23rd International Conference on

Enterprise Information Systems - Volume 2: ICEIS,,

pages 303–312. INSTICC, SciTePress.

Pohl, K. (2016). Requirements engineering fundamentals:

a study guide for the certiﬁed professional for require-

ments engineering exam-foundation level-IREB com-

pliant. Rocky Nook, Inc.

Santos, I., Miranda, E., and Lucena, M. (2017). Rastrea-

mento e gerenciamento de requisitos em busca da con-

formidade legal. In Workshop on Requirements Engi-

neering(WER).

Tanenbaum, A. S. and Wetherall, D. (2011). Computer Net-

works. Prentice hall, 5 edition.

ICEIS 2022 - 24th International Conference on Enterprise Information Systems
