Schema-guided Testing of Message-oriented Systems

André Santos

1,2 a

, Alcino Cunha

2 b

and Nuno Macedo

3 c

VORTEX CoLab, Vila Nova de Gaia, Portugal

High-Assurance Software Laboratory, INESC TEC and University of Minho, Braga, Portugal

High-Assurance Software Laboratory, INESC TEC and University of Porto, Porto, Portugal

Keywords:

Software Testing, Formal Speciﬁcations, Speciﬁcation-based Testing, Property-based Testing.

Abstract:

Effective testing of message-oriented software requires describing the expected behaviour of the system and

the causality relations between messages. This is often achieved with formal speciﬁcations based on temporal

logics that require both ﬁrst-order and metric temporal constructs – to specify constraints over data and real time.

This paper proposes a technique to automatically generate tests for metric ﬁrst-order temporal speciﬁcations

that match well-understood speciﬁcation patterns. Our approach takes in properties in a high-level speciﬁcation

language and identiﬁes test schemas (strategies) that are likely to falsify the property. Schemas correspond to

abstract classes of execution traces, that can be reﬁned by introducing assumptions about the system. At the

low level, concrete traces are successively produced for each schema using property-based testing principles.

We instantiate this approach for a popular robotic middleware, ROS, and evaluate it on two systems, showing

that schema-based test generation is effective for message-oriented software.

1 INTRODUCTION

As the complexity of software systems increases, so

does the necessity to properly verify that safe be-

haviour will be observed. Testing is an essential, and

often the only, strategy deployed for that purpose, but

the complexity of modern systems renders the manual

encoding of test cases impractical. As a consequence,

several automated approaches to test generation have

emerged, such as model-based (MBT), property-based

(PBT), and speciﬁcation-based testing (SBT).

These challenges are exacerbated when targeting

distributed systems where components communicate

asynchronously through message-passing, such as

those complying to the OMG’s DDS standard (OMG,

2015). These systems are typically heterogeneous and

built from third-party components, so system-level

testing should act at the message-passing level, treat-

ing components as black-boxes. In this context, the

behaviour to be analysed is of a dynamic nature, and

testing procedures must take into consideration full

traces of messages as inputs and outputs. This limits

the feasibility of using unit tests beyond speciﬁc cor-

https://orcid.org/0000-0002-1985-8264

https://orcid.org/0000-0002-2714-8027

https://orcid.org/0000-0002-4817-948X

ner cases. PBT approaches are also ill-suited since

they either focus on execution safety properties (such

as null references or buffer overﬂows) or require the

expected behaviour to be speciﬁed operationally. MBT

approaches require modelling the system behaviour,

which is often infeasible in systems of this nature.

SBT approaches can be used to tackle these issues.

Here, the user is only expected to provide a single

artefact, a high-level declarative speciﬁcation of the

expected behaviour of the system. In a dynamic con-

text, these take the shape of temporal speciﬁcations,

allowing the encoding of functional safety properties.

Relevant trace inputs are automatically generated by

inspecting the speciﬁcations, while validity is auto-

matically tested by evaluating the speciﬁcation against

the output traces. However, previously proposed tech-

niques of this nature are still affected by some issues.

First, they are often based on logics with abstract time,

such as linear temporal logic (LTL) (Tan et al., 2004;

Michlmayr et al., 2006; Arcaini et al., 2013; Bloem

et al., 2019; Narizzano et al., 2020), but most sys-

tems are expected to be tested for some timing con-

straints. Moreover, they often fail to provide a proper

high-level interface that spares the developer from hav-

ing to understand the underlying formalisms. Lastly,

due to the extent of the search-space for timed trace

test cases, such techniques must provide some kind

Santos, A., Cunha, A. and Macedo, N.

Schema-guided Testing of Message-oriented Systems.

DOI: 10.5220/0010976100003176

In Proceedings of the 17th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2022), pages 26-37

ISBN: 978-989-758-568-5; ISSN: 2184-4895

Figure 1: Overview of the proposed approach.

of mechanisms to guide the input generation. Some

techniques have been proposed in PBT, such as target-

oriented (Löscher and Sagonas, 2017) and coverage-

guided (Padhye et al., 2019) approaches, but they are

ill-suited for heterogeneous and distributed systems.

In this paper we propose a novel SBT approach, de-

picted in Figure 1, based on trace schemas for message-

oriented systems whose expected behaviour is speci-

ﬁed in a high-level speciﬁcation language. The users

are only required to specify the architecture and the

expected behaviour of the system under test (SUT),

from which the input generator and the property moni-

tors are derived. The language is based on well-known

speciﬁcation patterns (Dwyer et al., 1999), so that

knowledge about the underlying formalisms or the im-

plementation details of the SUT is not required. A

trace schema is a sequence of message-passing con-

ditions that are expanded by the trace generators into

concrete message traces, which are automatically de-

rived from the speciﬁed properties based on the used

pattern. To restrict the search-space of the trace gen-

erator, the developer can specify additional properties

over the communication channels using the same spec-

iﬁcation language, which the testing procedure uses to

reﬁne the schemas derived from the speciﬁcation.

We evaluated our technique by implementing it

over the most popular robotic middleware, the Robot

Operating System (ROS) (Quigley et al., 2009). ROS

provides a communication layer that allows robotic

systems to be built from components communicating

through a publisher-subscriber paradigm. This instan-

tiation comprised the implementation of the speciﬁca-

tion language for ROS messages, a test generator for

trace schemas, and the deployment of runtime mon-

itors. It was integrated into HAROS (Santos et al.,

2016; Santos et al., 2021), a framework for the devel-

opment of high-assurance ROS software, which auto-

mates several tasks required for analysis and reporting.

Evaluation shows that schemas automatically derived

from speciﬁcations are effective in ﬁnding bugs related

to message interleaving, and that providing additional

assumptions further improves the results.

The rest of this paper is organized as follows. Sec-

tion 2 presents an overview of the proposed approach.

Section 3 presents the proposed property speciﬁca-

Figure 2: ROS system with open subscribers.

tion language, followed by the formalization of trace

schemas, their derivation and associated trace genera-

tor in Section 4. Section 5 and Section 6 present the

instantiation of the approach for ROS and the evalua-

tion results. Section 7 presents and discusses related

work. Lastly, Section 8 concludes the paper.

2 SCHEMA-GUIDED TESTING

To provide an overview of the proposed framework,

consider its instantiation for ROS (Section 5), used for

evaluation in Section 6. ROS is a collection of libraries,

tools and components for the development of robotic

applications. In ROS, software is organised in pack-

ages, the basic build and release units. A large number

of packages is open source and over 4 000 are indexed

in ofﬁcial collections, called distributions. At runtime,

a ROS system is typically distributed, with various

independent nodes consuming, processing and pro-

ducing data. Nodes often communicate via structured

messages sent through topics – typed message-passing

channels implementing a publisher-subscriber model.

Consider the system in Figure 2 as an example.

It contains two nodes:

/planner

, which subscribes

/position

messages and publishes

/plan

messages,

and

/control

, which given

/plan

and

/laser

, pub-

lishes velocity messages at

/vel

with some degree of

safety. Let us say that we want to check whether a

simple safety property holds in this system: that when

the laser detects an obstacle closer than 40cm, a zero

velocity message will be published within a certain

threshold (say, 500ms), so that the robot avoids hit-

ting the obstacle. Using the proposed speciﬁcation

language (Section 3), this could be easily speciﬁed as

1 globally : / laser { dist < 40} causes

2 / vel { l i n e a r .x = 0} within 5 00 ms

How can such a property be tested? Since nodes

are considered to be black boxes, one must act at the

message-passing level, publishing and listening to mes-

sages being passed by the middleware. However, not

all available channels should be exercised by the test-

ing procedure: we must identify the channels that

represent the inputs of the system under test. An open

subscribed channel is any channel that the system sub-

Schema-guided Testing of Message-oriented Systems

scribes but for which there are no publishers. They

are the intended interfaces to integrate the system with

the environment, since there is no other purpose for

subscribers that lack their respective publishers. In

the example,

/position

and

/laser

are open subscrip-

tions. Even though closed channels are technically

usable by external components, we treat them as inter-

nal communication channels and do not tamper with

them by publishing additional messages, because the

system is likely not designed to expect the additional

publishers. To test speciﬁc portions of the system, our

approach also allows the testing of a projection of the

architecture. For instance, in the example the user

could wish to focus on testing the

/control

node, in

which case

/plan

would become an open subscribed

channel and /position rendered irrelevant.

Once the input channels are selected, the testing

procedure must decide the channels, order and delay

between the messages that will be published. Our

approach is based on PBT and SBT principles. We use

the former to automatically explore the input space and

test the SUT with a variety of valid inputs. We use the

latter to convert formal properties into specialized test

strategies, in order to nudge the input generators in a

direction that is more likely to reveal counterexamples.

We call these test strategies input trace schemas,

an abstraction for a certain category of input traces.

They describe a general sequence of events using ab-

stract messages and durations, annotated with their

respective constraints. For instance, for the property

just presented, only input traces that publish

/laser

messages with values below 40cm are relevant, other-

wise the property will never be falsiﬁed. This could be

speciﬁed with the following simple trace schema.

1 forbid / l a s e r { d i st < 40}

2 +0..: publish / l a s e r { dist < 4 0}

Our system derives automatically an input trace

schema for each property (Section 4.2). The nota-

tion is simple: a schema is interpreted line by line,

each statement representing general constraints over

channels (

forbid

) or mandatory events of interest

(

publish

). The syntax follows the one used in our

speciﬁcation language, i.e., it expects a channel name,

followed by predicates over the message’s ﬁelds. The

forbid

statement imposes restrictions over the (zero

or more) random messages an input trace is allowed

to instantiate within a segment of the trace, applied

from the instant immediately following the previous

mandatory event (or the start of the trace) until (but not

including) the next mandatory event (or until the end

of the trace). In the example, the ﬁrst line states that

there should be no

/laser

detecting obstacles until it

is forced to be published later in the trace. There is no

restriction on

/position

, so any number of

/position

messages – regardless of their content – and

/laser

messages with value

≥ 40

may be published in this

interval. A

publish

statement is composed of an in-

terval and of constraints over a channel. It denotes a

single mandatory message whose timestamp must be

contained in the speciﬁed interval, relative to the pre-

vious event. In the example the derived schema does

not impose any time interval, so the interval is left

unbounded (0 or more milliseconds after the initial in-

stant). After forced publication no further constraints

are imposed, so any arbitrary

/position

and

/laser

messages may be published until the end of the trace.

An input trace is a ﬁnite sequence of messages

with concrete values in data ﬁelds, annotated with

timestamps generated from the schemas, that the test

driver should replay on open subscribed channels to

stimulate the SUT. Input traces are, thus, instances of

a schema. Note that this is distinct from the observed

trace, the actual sequence of events that makes a par-

ticular run of the SUT, including messages published

by the nodes under test. For instance, the following

input trace is an instance of the previous schema.

1 @40ms / laser { dist : 50.0}

2 @50ms / p o s ition { x: 0.0 , y: 0.0}

3 @60ms / laser { dist : 30.0}

4 @70ms / p o s ition { x: 2.5 , y: 0.5}

5 @80ms / laser { dist : -20.0}

6 @90ms / p o s ition { x: 3.0 , y: 1.0}

We can see how this trace is an instance of the

previous schema: a

/laser

message with value

< 40

is published after 60 milliseconds and there is no such

message before it. Besides the restrictions imposed by

the schema statements, the trace generator will gener-

ate arbitrary messages to build a complete input trace.

However, we should also notice that it is allowing mes-

sages that are invalid in a real environment: sensors do

not publish negative /laser messages.

To address this, the user can introduce additional

assumptions following the same speciﬁcation lan-

guage. For the example, this could speciﬁed as:

1 globally: no / l a s e r { d i st < 0}

Properties that only refer to open subscriptions,

called axioms, are considered global constraints over

the input trace schemas and are used to reﬁne them.

They are used to ignore tests whose actual input traces

are nonconforming. Our example schema, now reﬁned,

would be:

1 forbid / l a s e r { d i st < 40}

2 +0..: publish / l a s e r {0 <= dist < 40}

3 forbid / l a s e r { d i st < 0}

The previously shown (invalid) input trace would

no longer be generated from this schema.

Bugs often occur from speciﬁc message combina-

tions, so the tighter the allowed message values, the

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

higher the probability relevant input traces are gen-

erated. For instance, bugs may be triggered by the

rapid publication of

/laser

messages near the 40cm

boundary value. By being able to generate any positive

ﬂoat it would still be very unlikely to generate such a

trace. Guided by speciﬁc knowledge of the SUT, the

developer may introduce additional, ﬁner axioms to

force the trace generator to focus on particular classes

of input traces. In our example, the developer could

have imposed a very speciﬁc of range of

/laser

values,

knowing that – in principle – the system would not

behave differently for other values:

1 globally: no / l a s e r { d i st < 0 or

dist > 100}

Such axioms should be used with care: they rule

out test cases that are theoretically valid, even though

they might be unexpected for a particular application.

3 SPECIFICATION LANGUAGE

The property speciﬁcation language we propose is

based solely on the messages that components ex-

change with one another in a message-oriented system.

The SUT is treated as a black box, as is custom in SBT.

The language is built on top of the well-known

property speciﬁcation patterns proposed by (Dwyer

et al., 1999). We focus on the Absence (a certain type

of message, a behaviour, must not be observed), Exis-

tence (a certain type of message, a behaviour, must be

observed at least once), Precedence (observing a cer-

tain type of message, a behaviour, implies that another

type of message, a stimulus, must have been observed

prior) and Response (observing a certain type of mes-

sage, a stimulus, implies that another type of message,

a behaviour, must be observed in the future) patterns.

We also add a new Prevention pattern (a certain type

of message, a stimulus, implies that another type of

message, a behaviour, must not be observed in the

future). In addition, properties specify a scope, delim-

iting the times during which the pattern must hold. A

scope may be Global (the pattern should always hold),

After (the pattern should hold indeﬁnitely, after a cer-

tain message, the activator, is observed for the ﬁrst

time), Until (the pattern should hold up to the point

when a certain message, the terminator, is observed

for the ﬁrst time), or After-until (the pattern should

hold after a certain message, the activator, is observed,

up to the point when another message, the terminator,

is observed), the last being possibly re-entrant.

3.1 Syntax

The following grammar deﬁnes the language’s syntax.

hpropertyi ::= hscopei ‘:’ hpatterni

hscopei ::= ‘globally’ | hafter-untili | huntili

hafter-untili ::= ‘after’ heventi [huntili]

huntili ::= ‘until’ heventi

hpatterni ::= ‘no’ heventi [htime-boundi]

| ‘some’ heventi [htime-boundi]

| heventi ‘requires’ heventi [htime-boundi]

| heventi ‘causes’ heventi [htime-boundi]

| heventi ‘forbids’ heventi [htime-boundi]

htime-boundi ::= ‘within’ htimei

htimei ::= hnatural-zeroi ‘ms’

heventi ::= hros-namei [haliasi] [hpredicatei]

haliasi ::= ‘as’ hidi

hpredicatei ::= ‘{’ hconditioni ‘}’

hconditioni ::= hvaluei hbinary-rel-operatori hvaluei

| ‘(’ hconditioni ‘)’

| ‘not’ hconditioni

| ‘forall’ hidi ‘in’ hmsg-ﬁeldi ‘:’ hconditioni

| hconditioni hbinary-connectivei hconditioni

hbinary-rel-operatori ::= ‘=’ | ‘<’

hbinary-connectivei ::= ‘or’ | ‘and’

hvaluei ::= hbooleani | hnumeric-expri | hstringi

hvariablei ::= ‘$’ hidi

hmsg-ﬁeldi ::= hﬁeld-namei {‘.’ hﬁeld-namei}

| halias-ref i ‘.’ hﬁeld-namei {‘.’ hﬁeld-namei}

halias-ref i ::= ‘@’ (hnatural-zeroi | hidi)

hﬁeld-namei ::= hidi [hindexi]

hindexi ::= ‘[’ (hnatural-zeroi | hvariablei) ‘]’

We present only a small set of logical connectives

and relational operators, but we can assume common

syntactic sugar such as the relational operator ‘>’.

The

forall

quantiﬁer provides a basic means

of iterating over all valid indices of array ﬁelds.

The syntax ‘

forall i in array

’ is roughly equiv-

alent to the Python ‘

for i in range(len(array))

’.

The grammar also captures references to quantiﬁed

variables (

‘$var’

) and to message ﬁelds. Message

ﬁelds can be: (i) simple identiﬁers (

‘field’

) to re-

fer to a ﬁeld of the message; (ii) multiple identi-

ﬁers separated by dots (

‘parent.child’

) to refer to

nested ﬁelds of composed messages; or (iii) indexed

(‘parent.array[1]’) to access array positions.

Every message in a property has an implicit as-

sociated index, to enable cross-references with

‘@’

Messages are numbered, starting at 1 with the acti-

vator event, if any, and then following up with the

pattern events. Since numeric references can become

confusing, we introduce event aliases to allow human-

readable names instead. For instance, a predicate

Schema-guided Testing of Message-oriented Systems

can refer to ﬁelds of an activator ‘

/bumper as Bumper

’

‘@Bumper.field’

rather than

‘@1.field’

. Cross-

references are only possible if the referenced message

(unambiguously) happens before the current message;

e.g., pattern events can refer to the scope activator.

3.2 Semantics

The original speciﬁcation patterns (Dwyer et al., 1999)

are intended for propositional temporal logics, such

as LTL, but our speciﬁcation language adds ﬁrst-order

predicates over data and real-time constraints. Thus,

we use Metric First-Order Temporal Logic (Chomicki,

1995) (MFOTL), whose syntax and semantics are sim-

ilar to other commonplace logics, such as LTL, except

that temporal operators in MFOTL can be annotated

with metric time intervals. A temporal formula is only

satisﬁed if it is satisﬁed within the bounds given by the

time interval of the temporal operator, which is always

relative to a timestamp.

Let

∆

be the set of non-empty intervals over

such that an interval

δ ∈ ∆

is written

[δ

, δ

)

with

∈

∈ N∪{∞}

, and

< δ

. A signature

is a tuple

(C, P, a)

, where

is a ﬁnite set of constant symbols,

is a ﬁnite set of predicates disjoint from

, and the

function

a : P 7→ N

provides the arity of each predicate.

Also, let

denote a countably inﬁnite set of variables,

where we assume that V ∩ (C ∪ P) =

Deﬁnition 1. The formulae over

are inductively

deﬁned: (i) For

x, y ∈ V ∪C

x = y

is a formula. (ii) For

p ∈ P

n = a(p)

and

, . . . , x

∈ V ∪ C

p(x

, . . . , x

)

is a formula. (iii) For

x ∈ V

, if

and

are formulae,

then

(¬ϕ)

(ϕ ∧ ψ)

and

(∃x : ϕ)

are formulae. (iv) For

δ ∈ ∆

, if

and

are formulae, then

(

ϕ)

(

ϕ)

(ϕS

ψ), and (ϕU

ψ) are formulae.

Here

is read previous,

next,

since and

until. Other common operators can be deﬁned in terms

of the core set, namely



(historically),



(globally),



(once),

♦

(ﬁnally),

(weak-until),

(back-to) and

Z (weak-previous).

A ﬁrst-order structure

over

consists of a

domain

|D| 6=

and interpretations

∈ |D|

and

⊆ |D|

a(p)

, for each

c ∈ C

and

p ∈ P

. A tempo-

ral ﬁrst-order structure over

is a pair

(D, τ)

, where

D = (D

, D

, . . .)

is a sequence of structures over

and

τ = (τ

, τ

, . . .)

is a sequence of natural numbers

(timestamps), where

is monotonically increasing

(

∀i ≥ 0 : τ

≤ τ

i+1

) and makes progress (

∃ j > i : τ

);

has constant domains (

∀i ≥ 0 : |D

| = |D

i+1

);

and each constant symbol

c ∈ C

has a rigid interpreta-

tion (

∀i ≥ 0 : c

= c

i+1

). A valuation is a mapping

v : V 7→ |D|

. We abuse notation by applying valuations

also to constant symbols

c ∈ C

, with

v(c) = c

. Ad-

ditionally, we denote

v[x 7→ d]

as the valuation where

(D, τ, v, i)  x = y iff v(x) = v(y)

(D, τ, v, i)  x < y iff v(x) < v(y)

(D, τ, v, i)  p(x

, . . . , x

a(p)

)

iff (v(x

), . . . , v(x

a(p)

)) ∈ p

(D, τ, v, i)  (¬ϕ) iff (D, τ, v, i) 2 ϕ

(D, τ, v, i)  (ϕ ∧ ψ) iff (D, τ, v, i)  ϕ

and (D, τ, v, i)  ψ

(D, τ, v, i)  (∃x : ϕ) iff (D, τ, v[x 7→ d], i)  ϕ,

for some d ∈ |D|

(D, τ, v, i)  (

ϕ) iff i > 0, τ

− τ

i−1

∈ δ

and (D, τ, v, i − 1)  ϕ

(D, τ, v, i)  (

ϕ) iff τ

i+1

− τ

∈ δ

and (D, τ, v, i + 1)  ϕ

(D, τ, v, i)  (ϕ S

ψ) iff (D, τ, v, j)  ψ

and (D, τ, v, k)  ϕ

for some j ≤ i, τ

− τ

∈ δ and all k ∈ [ j + 1, i]

(D, τ, v, i)  (ϕ U

ψ) iff (D, τ, v, j)  ψ

and (D, τ, v, k)  ϕ

for some j ≥ i, τ

− τ

∈ δ and all k ∈ [i, j)

Figure 3: Metric First-Order Temporal Logic semantics.

every mapping is unaltered, when compared to

, save

for x ∈ V, which should map to d ∈ |D|.

Deﬁnition 2. Let

(D, τ)

be a temporal structure over

, with

D = (D

, D

, . . .)

and

τ = (τ

, τ

, . . .)

and

formulae over

a valuation, and

i ∈ N

. The tempo-

ral structure satisﬁes a formula

, written

(D, τ)  ϕ

if and only if (D, τ, v, 0)  ϕ, as shown in Figure 3.

In the interpretation of the proposed language, the

ﬁrst-order structures

over

consist of a domain

|D|

containing all numbers, Boolean values, strings, and

messages (consisting of a unique identiﬁer). Also, for

all message channels

/ch

there is a predicate

ch ∈ P

such that

ch(m)

is true if and only if a message

can be observed on

/ch

. The relation of messages

to data ﬁelds is given by predicates

ﬁeld(m, x) ∈ P

such that

ﬁeld(m, x)

holds if and only if a message

carries the value (or message)

in a ﬁeld named

field

. To simplify quantiﬁcation over the indices of

an array, we redeﬁne

ﬁeld(m, k)

to hold for all indices

of the array rather than values. That is, for

k ∈ N

ﬁeld(m, k)

holds if

is an index of an array named

field

. In addition, we deﬁne a predicate

ﬁeld

(m, x)

that holds if the ﬁeld

field[k]

carries the value

i.e., if

ﬁeld(m, k)

holds and the array contains

index

. We address composed messages,

f.g

, with

the composition of predicates f and g, such that

g ◦ f (m, x) ≡ (∃m

: f (m, m

) ∧ g(m

, x))

Deﬁnition 3. Let

(D, τ)

be a temporal structure over

, with

D = (D

, D

, . . .)

and

τ = (τ

, τ

, . . .)

. Let

be a valuation,

i ∈ N

and

a property over

. We

deﬁne

JΦK

, the interpretation of

, as a function that

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

Scopes

Jglobally: ΨK , JΨK

⊥

Juntil q: ΨK , JΨK

Jafter p: ΨK , (∀x : (JpK

∧ Z ((@y : JpK

))) → JΨK

⊥

)

Jafter p until q: ΨK , (∀x : (JpK

∧ (@y : JqK

) ∧ Z((@y : JpK

) B (∃y : JqK

))) → JΨK

)

Patterns

Jno b within t msK

, (@y : JbK

x,y

) W

[0,t)

(∃y : JqK

)

Jsome b within t msK

, (@y : JqK

) U

[0,t)

((∃y : JbK

x,y

) ∧ (@y : JqK

))

Ja causes b within t msK

, (∀y : JaK

x,y

→ Jsome b within t msK

x,y

) W (∃y : JqK

)

Ja forbids b within t msK

, (∀y : JaK

x,y

→ Jno b within t msK

x,y

) W (∃y : JqK

)

Jb requires a within t msK

, ∀y : (¬JbK

x,y

W (∃z : JaK

x,y,z

∨ JqK

))

∧((JbK

x,y

→ 

[0,t)

(∃z : JaK

x,y,z

)) W (∃z : JqK

))

Events

J/ch K

, J/ch {>} K

J/ch {ϕ} K

,...,x

, ch(x

) ∧ JϕK

,...,x

Predicates

J>K

, >

J⊥K

, ⊥

J(ϕ)K

, (JϕK

)

Jnot ϕK

, ¬JϕK

Jϕ and ψK

, JϕK

∧ JψK

Jϕ or ψK

, JϕK

∨ JψK

Ja ∼ bK

, ∃y, z :

JaK

∧

JbK

∧ y ∼ z

for ∼∈ {=, <, ≤, >, ≥}

Jforall var in f : ϕK

, ∀y :

J f K

→ JϕK

γ[var7→y]

Jforall var in @k. f : ϕK

, ∀y :

J@k. f K

→ JϕK

γ[var7→y]

Values and Expressions

Jc K

, y = c for c constant

J$varK

, y = γ(var)

J f K

,...,x

, J f K

, y)

J@k. f K

,...,x

, J f K

, y) if 1 ≤ k ≤ n

J(a)K

, (

JaK

)

Ja ⊕ bK

, ∃z, w :

JaK

∧

JbK

∧ y = (z ⊕ w)

for ⊕ ∈ {+, −, ×, ÷}

Field Predicates

JfieldK

, ﬁeld

Jfield[k]K

, ﬁeld

Jfield[$var]K

, ﬁeld

γ(var)

J f

. f

, J f

◦ J f

Figure 4: Speciﬁcation language semantics.

translates

to its equivalent MFOTL formula. Thus,

we deﬁne

(D, τ, v, i)  Φ

(D, τ, v, i)  JΦK

, and

JΦK

is deﬁned as shown in Figure 4.

To shorten some formulae and improve readability,

we assume that all interpreted properties

are type-

checked prior to their semantic interpretation JΦK.

Scopes.

globally

and

until

start, by deﬁnition,

at the initial instant of the trace and, thus, require the

inner formula to hold at that instant. On the other hand,

after

and

after-until

start when an activator is

been observed – hence the

(activator → Ψ)

type of

formula. The translation of a pattern

is denoted by

JΨK

and is passed a vector of quantiﬁed messages

x = x

, . . . , x

– initially the activator, if any – and the

terminator event q, if any.

Patterns. We present only the timed variants of each

pattern, since untimed variants are particular cases

where

δ = ∞

. Unary patterns,

and

some

, are already

close to a MFOTL formula, requiring the translation of

event predicates, denoted by

JaK

for an event

given

quantiﬁed messages

. The binary patterns

causes

and

forbids

are translated via composition with the

unary ones. The most complex pattern,

requires

, is

deﬁned with two conjuncts: behaviour

should not

happen before its stimulus

or the scope terminator

;

and if

happens before

, then

must have happened

within the previous δ time instants.

Predicates. The translation of a predicate

is mostly

direct to logic values or connectives, and is denoted

JϕK

for quantiﬁed messages

and a mapping

for syntactic replacements arising from quantiﬁcations

(given a variable name as written in the property, its

occurrences are replaced with a quantiﬁed variable in

|D|

). When translating an expression

JaK

denotes

a predicate that tests whether the value of the variable

y is one of the values for the expression a.

Schema-guided Testing of Message-oriented Systems

Values and Expressions. Message ﬁelds translate

to their homonymous predicates, and ﬁeld composi-

tion to predicate composition, as previously explained.

References to other messages, e.g.,

@k. f

, convert the

human-readable aliases to the message index, referring

to the

-th message of the superscript vector,

, rather

than the current message,

. Lastly, arithmetic expres-

sions bind quantiﬁed variables to domain values.

4 TRACE SCHEMAS

This section formalizes the core notion of the proposed

approach, that of input trace schemas. Then it shows

how they integrate the approach by presenting how

schemas are derived from patterns, and then concrete

input traces generated from schemas.

4.1 Formalization

A trace schema is a sequence of restrictions on a se-

quence of messages, forcing messages with certain

properties to be published and forbidding certain other

kinds of messages between such publications.

Deﬁnition 4. An input trace schema

is a set of for-

mulae over a signature

, written as a sequence of

statements according to the following grammar.

hschemai ::= hstatementi*

hstatementi ::= ‘forbid’ heventi

| hboundsi ‘:’ ‘publish’ heventi

hboundsi ::= ‘+’ hnatural-zeroi ‘..’ [hnatural-zeroi]

To convert schemas into MFOTL formulae, let us

start by deﬁning an atomic variable

for the initial

instant of the trace and atomic variables

for each of

the

k publish

events in a schema. Each atomic vari-

able

is true only at the instant when the

publish

event happens. Given statements of the form

..n

: publish /ch {ϕ

}

for all

i ∈ N

, we have that:

(e

→

(¬e

))

, i.e.,

once

happens, it will not happen again; and also

(e

→ (∃x : ch(x) ∧ ϕ

))

, i.e., at the instant

hap-

pens, there is a message on

/ch

such that

. Then,

we must schedule all mandatory events. For all

i ≤ k

we must observe

(e

i−1

→ ♦

)

. Then, the con-

straints given by

forbid

statements must be consid-

ered. Given a statement

forbid /ch {ϕ}

placed be-

tween events

and

i+1

, it follows that:

(e

→

((¬∃x : ch(x) ∧ ϕ) W e

i+1

))

. The

and

oper-

ators ensure that the constraints do not apply at the

logical instants

and

i+1

. If the schema ends with

forbid

statement, the

operator will impose the

constraints indeﬁnitely, as e

k+1

≡ ⊥.

hglobally: Ψi , hΨi

huntil q: Ψi , hΨi

hafter p: Ψi

hafter p until q: Ψi

forbid p

+0..: publish p

hΨi

hno b within t msi , ε

hsome b within t msi , ε

hb requires a within t msi , ε

ha causes b within t msi

ha forbids b within t msi

forbid a

+0..: publish a

Figure 5: Translation from speciﬁcations to schemas.

4.2 Generating Input Traces

From Patterns to Schemas. For each pattern of the

property language we specify how a base schema is

derived. These schemas represent a set of traces with

minimal constraints such that every counterexample

to the property is necessarily in them (i.e., they are

complete). These schemas essentially take into con-

sideration the activators and stimuli of the properties,

without which no counterexample can be found.

This translation between properties and base

schemas is shown in Figure 5, and is mostly self-

explanatory, denoted by

hΦi

for a property

. For

example, consider the base schema for

a causes b

a stimulus is forced to be published, otherwise the

property cannot be falsiﬁed.

Reﬁning Schemas. Axioms play an important role

in establishing valid data and valid trace structure.

In some cases, they can be embedded into the base

schemas, so that generated traces are mostly correct

by construction. The reﬁnement of a schema

by an

axiom

is denoted by

bΓc

. We support reﬁnements

for two types of properties, speciﬁcally:

1 globally: no /c {ϕ}

2 globally: / c forbids / c within t ms

If an axiom

is of the ﬁrst shape, constraints are

added to the data a message can carry. For /c 6= /d:





δ: publish /d {ψ}





forbid /c { ϕ}

δ: publish /d {ψ}

forbid /c { ϕ}

Publish statements on the same channel

also

have their predicates restricted:

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering





δ: publish /c {ψ}





forbid /c { ϕ}

δ: publish /c

{ ψ and not φ}

forbid /c { ϕ}

Axioms

of the second shape impose additional

temporal constraints. For two consecutive

publish

statements on channel

, we shift the lower-bound of

the second interval, if t < n:





δ: publish /c {ψ}

m..n:

publish /c {ψ

}





δ: publish /c {ψ}

t..n:

publish /c {ψ

}

If t ≥ n, the speciﬁcation is a contradiction.

From Schemas to Traces. The last step is to generate

traces that conform to the schemas.

Deﬁnition 5. Let

be a signature,

a valuation and

an input trace schema over

. A temporal ﬁrst-order

structure

(D, τ)

over

is said to be an instance of

and only if, for all

ϕ ∈ Γ

, it is true that

(D, τ, v, 0)  ϕ

This deﬁnition determines whether a temporal ﬁrst-

order structure (an inﬁnite trace) is an instance of a

schema, but we can only generate ﬁnite input traces.

Thus, we need to validate ﬁnite traces against schemas.

Deﬁnition 6. An input trace of length

is a

-preﬁx of

a temporal structure over S, for some k ∈ N

Deﬁnition 7. Let

be a signature,

be a valuation

and

be an input trace schema over

. Let

k ∈ N

and

[0,k)

, τ

[0,k)

)

be a

-preﬁx of a temporal structure over

. The

-preﬁx

[0,k)

, τ

[0,k)

)

is said to be an instance

if and only if, for all

, τ

)

temporal structures

over

[0,k)

, τ

[0,k)

)

is a

-preﬁx of

, τ

)

, and it is

true that (D

, τ

, v, 0)  ϕ, for all ϕ ∈ Γ.

The previous deﬁnition, in essence, states that, for

a ﬁnite trace to be an instance of a schema, any of its

possible (inﬁnite) extensions must also be instances of

the same schema, as is standard in bounded temporal

semantics. With this, we are now equipped to produce

traces that comply with a set of constraints.

The algorithm for trace generation is simple. An

initial pass allocates all timestamps and messages as-

sociated with

publish

events. A second pass iterates

over all intervals before and after the mandatory events,

and, evaluating the applicable

forbid

statements for

each interval, builds a set of all usable channels. From

this set, it then produces a random number of mes-

sages, and intersperses the messages randomly along

the interval. The result is a sorted list of (timestamp,

channel, message) tuples; a ﬁnite trace.

5 TOOL SUPPORT FOR ROS

Given a system speciﬁcation, composed of behavioural

properties following the syntax shown in Section 3

and a description of the inputs and outputs of the

SUT, the proposed schema-based testing approach au-

tomatically generates property-based tests that try to

falsify the speciﬁcation. Our implementation is com-

positional, tackling one problem at a time, namely:

property parsing

, runtime monitor generation

and

data generation for trace schemas

. To obtain the nec-

essary architecture model of the SUT, we implemented

the test generator as a plug-in for the HAROS frame-

work, which is already capable of extracting models

from source code (Santos et al., 2019). This eases

workﬂow automation, from model extraction to test

generation, execution and reporting.

From a high-level perspective, the tool starts by

ﬁltering the provided properties. Each property is as-

signed one category of axiom, testable or non-testable.

Although in theory all properties can be tested, our

current implementation for ROS only considers a prop-

erty testable if we have complete control of its scope

and stimulus events. That is, its scope activator, scope

terminator and stimulus event (if applicable) must be

open subscribed topics (inputs), while its behaviour

event must be a published topic (output). Further-

more, predicates over input messages must not contain

arithmetic or quantiﬁed expressions. These limitations

help ensure that tests are feasible and reproducible.

Predicates over input messages are embedded into the

message generators on a best-effort basis, which still

requires a subsequent runtime validation step. Quanti-

ﬁers and arithmetic expressions make constraints over

data signiﬁcantly more complex, meaning that more

input candidates have to generated until one is valid.

Limiting outputs only to behaviour events grants the

test driver control over the pace of the test; the input

trace schema dictates when scopes should start and

when behaviours should be triggered.

For each testable property, the tool identiﬁes the

property’s pattern and produces the corresponding base

schemas, as presented in Section 4. Axioms are consid-

ered next, if applicable, to reﬁne all starting schemas.

Reﬁnement is a best-effort attempt at generating cor-

rect data by construction. Again, it does not capture

all given constraints and must be validated at runtime.

https://github.com/git-afsantos/hpl-specs

https://github.com/git-afsantos/hpl-rv-gen

https://github.com/git-afsantos/haros-plugin-pbt-gen

Schema-guided Testing of Message-oriented Systems

Following the schema generation and reﬁnement

steps, the tool applies meta-programming Jinja

tem-

plates for all properties, to produce source code blocks

for the runtime monitors, trace generators and the over-

all test case structure. Each property pattern has its

corresponding code template, meaning that we can

produce optimized monitors and data generators for

our limited catalogue of options. The trace genera-

tors are implemented as data generators for Hypoth-

esis (MacIver et al., 2019), a well-established PBT

library. At the end, all pieces are weaved into a single

test script, which is responsible for successively pro-

ducing traces using Hypothesis, according to a given

schema, launching the SUT using tools of the ROS

infrastructure, deploying runtime monitors, replaying

the input trace and then observing the results. The test

script is itself a ROS node, allowing runtime monitors

to subscribe directly to all topics in the system, and,

thus, observe messages as they are published.

6 EVALUATION

The ROS-based implementation of the proposed

schema-based approach for PBT has been applied to

two concrete robotics applications. Note that the SUT

are treated as black boxes with a publisher-subscriber

interface, which makes the actual number of ROS

nodes in the network irrelevant. Thus, for both case

studies, we tested both individual nodes and fully inte-

grated systems. We present now our case studies, the

methodology behind our evaluation of the approach

and, lastly, the observed results.

6.1 Case Studies

The iClebo Kobuki

is our ﬁrst test subject and one

of the most iconic ROS robots. It is a low-cost, per-

sonal robot kit with open-source software whose main

purpose is to provide an entry-level platform for roboti-

cists to build applications with. Kobuki provides for an

interesting case study, since its source code has been

relatively well maintained and there is online docu-

mentation easily available – which makes it easier to

understand the expected behaviour of the system.

AgRob V16

is a modular robotic platform for

hillside agriculture, adapted to steep slope vineyards.

There are a few appealing factors in AgRob V16 as a

case study, namely that it is an industrial robot, more

complex than Kobuki, and that a large part of its soft-

ware comes from integrated third-party packages.

https://palletsprojects.com/p/jinja/

http://kobuki.yujinrobot.com/about2/

http://agrob.inesctec.pt/

For this evaluation, and for both robots, we con-

sider a conﬁguration with three components: a Trajec-

tory Controller node, that provides velocity commands

to the robot; a Safety Controller node, responsible for

reacting to dangerous sensor readings; and a Supervi-

sor node, that selects which commands to pass down

to the hardware, based on the current safety state and

the priority of the command source.

6.2 Methodology

One of the characteristics of PBT is that it can only

ﬁnd discrepancies between implementation and speci-

ﬁcation (Hughes, 2016). Whether such discrepancies

are an error in the system or in the speciﬁcation is left

to the user to decide. We have spent months studying

the implementations of our target systems. Judging

from the available documentation, we assume that they

are relatively stable, with correct functional behaviour

for the most part. This is a crucial assumption, as we

write speciﬁcations mostly based on the actual (and

expected) behaviour of the implementation. Given that

PBT focuses on discrepancies, our evaluation process

involves two types of testing:

Positive Testing

is the act of testing properties that

we know to be true. The goal is to conﬁrm that the

tool does not introduce false positives – i.e., that it

does not report an error if there is none to report.

Negative Testing

is the act of testing properties that

we know to be false. The tool should be able to

ﬁnd at least one counterexample, athough this may

require tuning how many examples are tested.

We follow a systematic method to write speciﬁcations

that include both true and false properties. We start

by writing a catalogue of true properties and axioms

for each system. Then, we apply speciﬁcation mu-

tation (Budd and Gopal, 1985; Ammann and Black,

1999; Black et al., 2000; Trab et al., 2012) to construct

mutants (i.e., variants) of the initial set. Mutations are

often small changes, such as changing a single opera-

tor or a variable. If the initial properties are as precise

as we can write them, any small mutation should end

up generating a false property. In practice, a validation

step is still required to discard duplicates, trivial prop-

erties and equivalent mutants (mutants that are still

true properties). Mutant validation is done manually,

since it is an undecidable problem (Trab et al., 2012).

The existing literature provides many operators to

mutate speciﬁcations. We adapt and reuse those that

are applicable to our speciﬁcation language, such as:

replacing an operand in an expression with another

valid operand of the same type (e.g., 1 with 0); negat-

ing an expression; replacing a logical operator (e.g.,

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

and

with

); replacing a relational operator (e.g.,

with

); removing a predicate from an event (e.g.,

/p {ϕ}

becomes

); widening or shortening time con-

straints; replacing a message channel with another of

the same type; widening the scope (e.g.,

after /p

{ϕ}

becomes

globally

); and replacing the property’s

pattern (e.g., causes with forbids).

After building the ﬁnal catalogue of property mu-

tants, we run the PBT tool on each mutated property

multiple times, with different parameters. With this,

we aim to answer the following research questions:

RQ1, how effective are the base schemas we intro-

duce in Section 4, when compared to a pure random

approach; RQ2, how effective is a speciﬁcation with

stronger axioms; and RQ3, what efﬁciency gains can

we make from base schemas and stronger axioms.

To answer these questions, we ran the tool with

empty schemas (effectively turning tests into a naïve

PBT approach with random exploration); with the auto-

matically derived base schemas; and with both empty

and base schemas reﬁned through stronger axioms.

To evaluate RQ1 and RQ2, we compare the resulting

speciﬁcation coverage (Ammann and Black, 1999), a

metric that is, in essence, a mutation score, i.e., the

ratio of mutants that the testing suite kills. For RQ3,

for each property mutant we measured the number of

examples until a test fails for the ﬁrst time; the number

of examples until the ﬁnal test result (includes the PBT

shrinking phase); and the required time to run each

example (in full, including data generation, launching

the SUT, and replaying the example trace).

6.3 Results

The evaluation results we present here are an aggre-

gated overview of all SUTs and test runs (6 individual

nodes and 2 full systems). In total, our speciﬁcation is

comprised of 153 axioms, 33 true properties and 318

mutants. Some axioms from testing single nodes are

replicated to the integrated system, making the total

number of unique axioms 82.

Effectiveness. Regarding the positive testing step,

no false positives have been observed in any of the

SUTs, resulting in a precision of 1. As for the negative

testing step, for the total of 318 mutants, and an initial

limit of 200 examples per property, our schema-based

approach achieved a mutant score (or recall) of 0.909

(29 surviving mutants), while the naïve approach only

achieved a score of 0.808 (62 survivors). All mutants

that survived the base schema also survived the empty

schema. Increasing the limit to 500 examples per prop-

erty did not make a difference for the empty schemas,

but dropped the survivors to 27 with the base schemas.

These surviving mutants are all very similar, belong-

ing to 5 properties of AgRob V16 (one of them being

the root of 13 false negatives). The expected coun-

terexamples for these mutants require sequences of 3

or more messages, with both timing and content con-

straints. Answering RQ1, the base schemas represent

an increase in recall of 13.24% (from 0.808 to 0.915).

Next, we reverted the testing limit to 200 examples

and strengthened 16 axioms affecting the surviving

mutants. The mutant score increased to 0.934 (21

surviving mutants) with our base schemas – a better

improvement than simply running more examples. The

empty schema also achieved an increased mutant score,

of 0.858 (45 survivors). Again, raising the testing

limit to 500 examples was not enough for the naïve

approach, leaving 35 survivors (score of 0.89). For

our base schemas, however, the increased limit was

sufﬁcient to kill all mutants. Answering RQ2, stronger

axioms represented a boost in recall as high as 12.35%.

Efﬁciency. On average, each example takes about

8 seconds to set up and execute, including generat-

ing the trace, and starting and shutting down the SUT.

However, this number tends to decrease the less ex-

amples we run, as the PBT library requires less effort

to ﬁnd new inputs. All properties and mutants com-

bined required a total of 43 029 examples until our

base schemas killed all mutants, which makes for a

total runtime of about 98 hours and 18 minutes. Con-

sidering only the cases for which the tool found a coun-

terexample within 200 examples, it took, on average, 6

examples (52 seconds) to ﬁnd an initial counterexam-

ple and 27 examples to report the ﬁnal counterexample

(226 seconds). This difference is due to the example

shrinking phase of PBT, which spanned nearly half of

the negative testing runtime (17 959 examples out of

36 429). While the average time per example is similar

for an empty schema, the total number of examples

tried for the whole test suite jumps up to 92 800, for

a total runtime of about 211 hours and 59 minutes. A

pure random approach takes longer not only to ﬁnd

an initial counterexample (12 examples), but also to

shrink it and report the ﬁnal counterexample (58 ex-

amples). Overall, and answering RQ3, we observe

that the schema-based approach is between 3 times

(median) and 7 times (average) faster than the random

approach in all measures, if there is a counterexample

to be found. In addition, for a limit of 500 examples,

stronger axioms killed an additional 27 mutants with

our approach, which amounts to sparing 5 697 exam-

ples, or about 12 hours and 40 minutes of runtime.

Schema-guided Testing of Message-oriented Systems

7 RELATED WORK

Speciﬁcation-based Testing. Most of the existing

literature on SBT shares a few common traits. First,

regarding the tested speciﬁcations, there is a general

lack of high-level (possibly pattern-based) speciﬁca-

tion languages. Properties are encoded directly in for-

mal logics, often in LTL, which makes our approach

more easily usable by non-experts. Second, the fo-

cus on LTL means that speciﬁcations cannot impose

constraints related to real-time performance, as we

can with MFOTL semantics. Third, few approaches

target publisher-subscriber architectures over (possi-

bly) distributed systems. A notable exception is the

work of Michlmayr et al., which does target publisher-

subscriber systems, although these are non-distributed

Java applications (Michlmayr et al., 2006).

Different strategies and techniques are used to ex-

plore relevant test cases from LTL speciﬁcations. In

the case of Michlmayr et al., it is unclear whether there

is a concrete strategy behind input generation. Tan et

al. convert the original formula into a ﬁnite set of

formulae characterizing non-trivial tests (Tan et al.,

2004); these are then fed to a model checker, whose

counterexamples are turned into concrete inputs. Ar-

caini et al., and later Narizzano et al., build online

monitors based on Büchi automata from LTL speciﬁ-

cations over sequences of function calls (Arcaini et al.,

2013; Narizzano et al., 2020). The monitors serve both

as a test oracle and as an automaton whose states are

used to generate test cases, according to various cover-

age criteria. The former focuses on safety properties

only, while Narizzano et al. consider also bounded

liveness (co-safety) properties. Bloem et al. follow

a similar approach, but deem requirements to be too

abstract to fully predict the behaviour of a black-box

system (Bloem et al., 2019). Their online testing ap-

proach asks the user for a system speciﬁcation and

a fault model deﬁning coverage goals (rather than a

behaviour model), both speciﬁed in LTL. Test cases

are synthesized from an automata of the fault model.

Property-based Testing. Work on PBT often acts

at a much lower level of abstraction than we propose

in this paper. The notion of system speciﬁcation is

lacking; properties are encoded programmatically and

tend to focus on simpler assertions, rather than tempo-

ral logic formulae. A partial exception to this pattern

is FlinkCheck (Espinosa et al., 2019), a PBT tool for

Apache Flink, a stream processing framework. Prop-

erties over streams are deﬁned programmatically, but

formalized in

LTL

, a three-valued variant of LTL

with timeouts on operators.

One of the major problems tackled in PBT research

is input space exploration – how data is generated.

Pure random generation is generally considered inef-

ﬁcient, which led to novel techniques to guide input

generators. ConFuzz (Padhiyar and Sivaramakrish-

nan, 2021) is a PBT technique for event-driven pro-

grams that uses a state-of-the-art grey-box fuzzer to

target concurrency bugs. It focuses on event callback

scheduling, not on the notion of traces of events. Tar-

geted PBT is an enhanced form of PBT where input

generation is guided by a search strategy and a util-

ity function (Löscher and Sagonas, 2017). The latter

attributes a score to each input-output pair that de-

termines how close an input was to falsify the prop-

erty, which should be maximized. Coverage-guided

PBT (Padhye et al., 2019) is another mechanism to

guide test generation, here using coverage information

provided by the execution of the previous tests. In our

case, it is the structure of the high-level speciﬁcation

that enables us to guide input generation and discard a

large portion of irrelevant message traces.

Lastly, various authors have been researching the

potential of PBT and fuzzing in the context of ROS

systems (Santos et al., 2018; Woodlief et al., 2021;

Delgado et al., 2021). These works conﬁrm the bug

detection effectiveness of these techniques in complex

robotic systems, but they lack high-level property spec-

iﬁcations. They provide mostly message generators,

with limited degrees of input generation guidance.

8 CONCLUSION

Testing distributed message-passing systems is a com-

plex task, for there are many possible causes of failure,

such as message interleaving, message contents or

timing. In this paper we presented a novel schema-

guided testing approach for such systems that com-

bines principles from both Speciﬁcation-based Testing

and Property-based Testing. With the former, we are

able to identify classes of relevant inputs for a given

temporal property, here called schemas. With the lat-

ter, we have an automated mechanism to instantiate

schemas into actual traces of messages to replay to

the system under test. Speciﬁcations are composed of

both assumptions and properties to be tested, formal-

ized with Metric First-Order Temporal Logic to sup-

port real-time constraints and constraints over complex

data structures. Contrary to most existing approaches,

however, speciﬁcations are written using a high-level,

pattern-based speciﬁcation language, also presented in

this paper, to ease the learning curve.

We have applied the proposed approach to robotic

systems implemented with the popular Robot Operat-

ing System middleware. Our results show that schema-

guided testing is both more effective and more efﬁcient

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

than a pure PBT approach, even when using minimal

schemas. Our ﬁrst goal for future research is to ex-

plore whether we could further boost performance by

partitioning minimal schemas into several specialized

schemas that, as a whole, are equivalent to the current

schemas. Second, our approach to automatic schema

reﬁnement via user-provided assumptions can be im-

proved. Many assumptions are only validated at run-

time in the current version, which wastes time in data

generation. Third, we will open up the implementation

to accept arbitrary, user-provided schemas, in addition

to properties. Finally, we also envision improvements

to the speciﬁcation language, so as to support other

property patterns or full-blown state machines.

ACKNOWLEDGEMENTS

The research leading to these results has received fund-

ing support from the projects: ERDF - European Re-

gional Development Fund through the Operational Pro-

gramme for Competitiveness and Internationalisation

- COMPETE 2020 Programme; project PTDC/CCI-

INF/29583/2017 (POCI-01-0145-FEDER-029583) ﬁ-

nanced by National Funds through the Portuguese

funding agency, FCT - Fundação para a Ciência e

a Tecnologia; “STEROID - Veriﬁcation and Valida-

tion of ADAS Components for Intelligent Vehicles

of the Future” from the European Union Financial

Support (FEDER) under grant agreement No. 69989;

and “NORTE-06-3559-FSE-000046 - Emprego alta-

mente qualiﬁcado nas empresas – Contratação de Re-

cursos Humanos Altamente Qualiﬁcados (PME ou Co-

LAB)” ﬁnanced by the Norte’s Regional Operational

Programme (NORTE 2020) through the European So-

cial Fund (ESF).

REFERENCES

Ammann, P. and Black, P. E. (1999). A speciﬁcation-based

coverage metric to evaluate test sets. In HASE, pages

239–248. IEEE CS.

Arcaini, P., Gargantini, A., and Riccobene, E. (2013). On-

line testing of LTL properties for java code. In Haifa

Veriﬁcation Conference, volume 8244 of LNCS, pages

95–111. Springer.

Black, P. E., Okun, V., and Yesha, Y. (2000). Mutation op-

erators for speciﬁcations. In ASE, pages 81–88. IEEE

CS.

Bloem, R., Fey, G., Greif, F., Könighofer, R., Pill, I., Riener,

H., and Röck, F. (2019). Synthesizing adaptive test

strategies from temporal logic speciﬁcations. Formal

Methods Syst. Des., 55(2):103–135.

Budd, T. A. and Gopal, A. S. (1985). Program test-

ing by speciﬁcation mutation. Computer Languages,

10(1):63–73.

Chomicki, J. (1995). Efﬁcient checking of temporal integrity

constraints using bounded history encoding. ACM

Trans. Database Syst., 20(2):149–186.

Delgado, R., Campusano, M., and Bergel, A. (2021). Fuzz

testing in behavior-based robotics. In ICRA, pages

9375–9381. IEEE.

Dwyer, M. B., Avrunin, G. S., and Corbett, J. C. (1999).

Patterns in property speciﬁcations for ﬁnite-state veri-

ﬁcation. In ICSE, pages 411–420. ACM.

Espinosa, C. V., Martin-Martin, E., Riesco, A., and

Rodríguez-Hortalá, J. (2019). FlinkCheck: Property-

based testing for Apache Flink. IEEE Access,

7:150369–150382.

Hughes, J. (2016). Experiences with QuickCheck: Testing

the hard stuff and staying sane. In A List of Successes

That Can Change the World, volume 9600 of LNCS,

pages 169–186. Springer.

Löscher, A. and Sagonas, K. (2017). Targeted property-

based testing. In ISSTA, pages 46–56. ACM.

MacIver, D., Hatﬁeld-Dodds, Z., and Contributors, M.

(2019). Hypothesis: A new approach to property-based

testing. Journal of Open Source Software, 4(43):1891.

Michlmayr, A., Fenkam, P., and Dustdar, S. (2006).

Speciﬁcation-based unit testing of publish/subscribe

applications. In ICDCS Workshops, page 34. IEEE CS.

Narizzano, M., Pulina, L., Tacchella, A., and Vuotto, S.

(2020). Automated requirements-based testing of

black-box reactive systems. In NFM, volume 12229 of

LNCS, pages 153–169. Springer.

OMG (2015). Data Distribution Service (DDS), Version 1.4.

Object Management Group (OMG).

Padhiyar, S. and Sivaramakrishnan, K. C. (2021). ConFuzz:

Coverage-guided property fuzzing for event-driven pro-

grams. In PADL, volume 12548 of LNCS, pages 127–

144. Springer.

Padhye, R., Lemieux, C., and Sen, K. (2019). JQF: coverage-

guided property-based testing in java. In ISSTA, pages

398–401. ACM.

Quigley, M., Conley, K., Gerkey, B. P., Faust, J., Foote, T.,

Leibs, J., Wheeler, R., and Ng, A. Y. (2009). ROS:

An open-source Robot Operating System. In ICRA

Workshop on Open Source Software.

Santos, A., Cunha, A., and Macedo, N. (2018). Property-

based testing for the robot operating system. In A-

TEST@ESEC/SIGSOFT FSE, pages 56–62. ACM.

Santos, A., Cunha, A., and Macedo, N. (2019). Static-time

extraction and analysis of the ROS computation graph.

In IRC, pages 62–69. IEEE.

Santos, A., Cunha, A., and Macedo, N. (2021). The high-

assurance ROS framework. In RoSE@ICSE, pages

37–40. IEEE.

Santos, A., Cunha, A., Macedo, N., and Lourenço, C. (2016).

A framework for quality assessment of ROS reposito-

ries. In IROS, pages 4491–4496. IEEE.

Tan, L., Sokolsky, O., and Lee, I. (2004). Speciﬁcation-

based testing with linear temporal logic. In IRI, pages

493–498. IEEE SMCS.

Trab, M. S. A., Counsell, S., and Hierons, R. M. (2012).

Speciﬁcation mutation analysis for validating timed

testing approaches based on timed automata. In COMP-

SAC, pages 660–669. IEEE CS.

Woodlief, T., Elbaum, S., and Sullivan, K. (2021). Fuzzing

mobile robot environments for fast automated crash

detection. In ICRA, pages 5417–5423. IEEE.

Schema-guided Testing of Message-oriented Systems
