Improving Integration Process Efﬁciency through Pull Request

Prioritization

Agustín Olmedo

1 a

, Gabriela Arévalo

, Ignacio Cassol

1 b

, Christelle Urtado

3 c

and Sylvain Vauttier

3 d

LIDTUA (CIC), Facultad de Ingeniería, Universidad Austral, Buenos Aires, Argentina

DCyT (UNQ), CAETI (UAI), CONICET, Buenos Aires, Argentina

EuroMov Digital Health in Motion, Univ. Montpellier & IMT Mines Ales, Ales, France

Keywords:

Distributed Version Control System, Distributed Software Development, Pull-based Development, Pull

Request, Software Merging, Merge Conﬂicts.

Abstract:

Pull-based Development (PbD) is widely used in software teams to integrate incoming changes into a project

codebase. In this model, contributions are advertised through Pull Request (PR) submissions. Project ad-

ministrators are responsible for reviewing and integrating PRs. Prioritizing PRs is one of the main concerns

of project administrators in their daily work. Indeed, conﬂicts occur when PRs are concurrently opened on

a given target branch and propose different modiﬁcations for a same code part. We propose to consider the

integration process efﬁciency (IPE) as the fact that for a given integration cost (i.e., number of conﬂicts to be

solved) the highest gain is reached (i.e., the largest number of PRs are integrated). The goal of this work is to

optimize the IPE through PR prioritization. We propose a process that provides a sequence of unconﬂicting

PR groups. This sequence minimizes the number of conﬂict resolutions and deﬁnes an optimized integration

order according to the efﬁciency of the integration process. We apply our proposal to seven representative his-

torical integration sequences from an open source project. In all seven cases, the IPE obtained by our proposal

is higher than the historical IPE from 28.73% to 156.52%.

1 INTRODUCTION

Many software development teams rely on a Dis-

tributed Version Control System (DVCS) to man-

age concurrent editing of their projects’ source

code (Brindescu et al., 2014) (Rodríguez-Bustos and

Aponte, 2012). Since their appearance in 2001,

DVCSs –notably Git (Chacon and Straub, 2014)–

have transformed collaborative software develop-

ment. Each developer has a personal local copy of

the entire project history. Changes are ﬁrst applied

locally in the developer copy and are later integrated

into a new shared version. Conﬂicts between paral-

lel changes need to be solved during this integration

process (Mens, 2002).

The pull-based development (PbD) model is

widely used in collaborative software development

(Gousios et al., 2014)(Gousios et al., 2015). In this

model, contributions are advertised through Pull Re-

https://orcid.org/0000-0003-2844-6816

https://orcid.org/0000-0002-6309-7503

https://orcid.org/0000-0002-6711-8455

https://orcid.org/0000-0002-5812-1230

quest (PR) submissions. Members of the project’s

core team (aka project administrators) are responsible

for reviewing and integrating PRs.

In an open-source context, the PbD model encour-

ages contributions since anyone can propose changes

to be integrated into the project, thereby increas-

ing the burden on project administrators who decide

whether to integrate contributions into the main de-

velopment branch or not (Gousios et al., 2015)(Pham

et al., 2013). In large projects, the volume of in-

coming PRs is quite a challenge (Gousios et al.,

2015)(Tsay et al., 2014a). Prioritizing PRs is one of

the main concerns of project administrators in their

daily work (Gousios et al., 2015).

Since contributions can be submitted concur-

rently, more than one PR can propose changes that

modify the same part of the code (i.e., same lines

of the same ﬁle). When two PRs are concurrently

opened on a given target branch, proposing different

modiﬁcations for identical code parts, a pairwise con-

ﬂict exists. In such case, only the ﬁrst one can be

integrated automatically, while the second requires a

conﬂict resolution.

A PRs integration sequence is the chronological

Olmedo, A., Arévalo, G., Cassol, I., Urtado, C. and Vauttier, S.

Improving Integration Process Efﬁciency through Pull Request Prioritization.

DOI: 10.5220/0010992100003176

In Proceedings of the 17th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2022), pages 62-72

ISBN: 978-989-758-568-5; ISSN: 2184-4895

order in which the project administrator integrates

the opened PRs. The integration sequence deﬁnes

the integration process. According to Van Der Veen

(Van der Veen, 2015), there is an integration sequence

in which the number of conﬂict resolutions is reduced.

Although the actual number of conﬂicts is not re-

duced, they can be concentrated in a particular PR in-

tegration action, thus reducing the number of conﬂict

resolutions. The integration process may be there-

fore not as efﬁcient as possible because the number

of conﬂict resolutions could be smaller or because the

integration of less conﬂicting PRs (PRs easier to inte-

grate) are inexplicably delayed.

The advantage of an efﬁcient integration process

is that the codebase is kept as up-to-date as possible.

This is very valuable for the software development

process because efﬁcient continuous integration pro-

cesses limit future integration conﬂicts (Beck, 2000).

In addition, since conﬂict resolutions are carried out at

the end of the integration process, conﬂicts are solved

on an updated codebase, applying the most appropri-

ate resolutions to the latest state of the software.

We propose to consider the integration process ef-

ﬁciency (IPE) as the fact that for a given integration

cost (i.e., number of conﬂicts to be solved) the high-

est possible gain is reached (i.e., the largest number

of PRs are integrated). Therefore, to achieve an opti-

mized IPE, the number of conﬂict resolutions should

be minimized and the least conﬂicting PRs should be

integrated earlier.

We pose the following research questions:

• RQ1. Can the efﬁciency of the integration pro-

cess be improved by prioritizing PRs according to

conﬂicts?

• RQ2. To what extent does our proposal improve

the IPE as compared to the historical IPE mea-

sured from a real project history?

The goal of this work is to evaluate the feasibility of

IPE optimization through PR prioritization. We pro-

pose a process that provides a sequence of unconﬂict-

ing PR groups that minimizes the number of conﬂict

resolutions and deﬁnes an optimized integration order

according to the efﬁciency of the integration process.

In order to answer the research questions, we ap-

ply our proposal to the sets of PRs corresponding to

seven representative historical integration sequences

from an open source project.

The remainder of this paper is structured as fol-

lows. Section 2 includes background knowledge and

deﬁnitions. Section 3 presents our proposed approach

to optimize IPE for a set of PRs. Section 4 explains

how we evaluate our proposal and gives an insight on

the case study that will be used throughout the pa-

per. Section 5 contains results and threats to validity

analyses. Related works are included in Section 6 be-

fore providing our conclusions and perspectives for

this work.

2 BACKGROUND &

DEFINITIONS

In DVCS, versions are created when a developer com-

mits the changes currently staged to the project. Ver-

sions derive from each other and a derivation relation

then links a version to (one of) its predecessor(s). The

graph composed of versions and their derivation re-

lations is called a version history. This history can

be linear, tree-like (several versions can be derived

from the same one, to model software variants for ex-

ample), or, in the most general case, forms a direct

acyclic graph (versions can also be merged). This last

and more generic case is the appropriate framework

for collaborative development. We consider such his-

tories in the remainder of this study.

A branch is the version history up to a speciﬁc

version and deﬁnes an independent line of devel-

opment. To enable collaborative or concurrent de-

velopment, but also to preserve the contents of the

main development branch, developments are typically

performed on new branches, forked from the latest

version currently available on the main development

branch (Bird and Zimmermann, 2012). This branch

is sometimes called a feature branch as its role in the

development process is to bring up a new feature to

the project.

Tasks that have to be dealt with (to correct, main-

tain or improve the software) are stored as issues in an

issue tracking system (IST) such as Jira

. Contribu-

tors choose or are provided a ticket to deal with. To do

so, they create a dedicated feature branch in their local

repository from the latest software version (fetched

from the team repository), check-out this version to

get a work copy and make the necessary changes.

These changes can then be committed on the feature

branch in the local repository so as to enact them.

When the development is achieved, the versions lo-

cally commited on the feature branch are checked-in

(pushed) to the remote team repository. A last step is

to submit a Pull Request (PR) to ask the project ad-

ministrator to include the changes into the project’s

main development branch.

A PR is a request to the project administrator(s)

to pull versions from a branch to another one. So,

a PR contains a source branch from which versions

are pulled from and a target branch to which versions

https://www.atlassian.com/en/software/jira

Improving Integration Process Efﬁciency through Pull Request Prioritization

are pushed. Project administrators must review and

integrate opened PRs in the project. As a result of

the review process, PRs can be closed as accepted

or rejected. PRs can be accepted with or without

changes. In case of being accepted with changes, the

contributor must apply the changes suggested by the

project administrator by committing a new version in

the source branch of the PR, so that the PR is auto-

matically updated.

The accepted PRs are integrated, that is, the

changes of the versions of the source branch since it

was forked from the target branch are incorporated

into the target branch. If versions have been com-

mited on the target branch since the source branch

of the PR was forked, there may be merge conﬂicts

since the head version of the source branch do not

derive anymore from the head version of the target

branch. We consider the changes as text ﬁle modiﬁ-

cations as Git does. A change is the modiﬁcation of

a text chunck in a ﬁle or the addition or deletion of a

ﬁle. Therefore, merge conﬂicts between changes are

due to the fact that the same line(s) of the same ﬁle

are modiﬁed in both branches.

When there are merge conﬂicts between the

changes of the source branch and the changes of the

target branch of a PR, the PR is considered as a con-

ﬂicting PR. Conﬂicting PRs require a conﬂict resolu-

tion to integrate their changes into the target branch

whereas for unconﬂicting PRs, the changes are auto-

matically integrated. In the PbD approach, a pairwise

conﬂict exists between two PRs when the integration

of a PR would entail a future conﬂict when integrat-

ing the other one to their shared target branch (and

reciprocally).

The integration of all opened PRs implies that all

conﬂicts are solved. The ﬁnal cost of the integration

process is therefore the same regardless of the integra-

tion sequence. Even though, the IPE can be improved

since it is possible to propose an integration sequence

that provides greater gain earlier at a lower cost, as

compared with other integration sequences. Particu-

larly, the integration process is more efﬁcient when

all unconﬂicting PRs are integrated ﬁrst because, up

to that point in the integration process, the IPE is op-

timal since these PRs are integrated automatically.

3 OUR APPROACH: IPE

OPTIMIZATION

Our approach takes as its inputs a set of opened PRs

and generates a sequence of PR groups that deﬁnes

an optimized integration process. The proposal takes

as an hypothesis that all the pairwise conﬂict resolu-

Figure 1: IPE optimization steps with their corresponding

artifacts.

tions have the same mean cost (the study of an accu-

rate cost model is a perspective for this work). Thus,

we do not consider the elementary conﬂicts (like con-

ﬂict between ﬁles or line blocks, depending on the

considered detail level) but only pairwise conﬂicts.

PR groups are composed of unconﬂicting PRs.

These can thus be integrated altogether in an auto-

matic manner. In addition, PR groups are ordered so

as to integrate ﬁrst the less conﬂicting PR group, i.e.,

the group with the best trade-off between the number

of PRs in the group and the number of pairwise con-

ﬂicts that need to be solved to integrate the PRs of the

group. Our approach lies on a four stepped process

shown in Figure 1.

Pairwise Conﬂict Representation. It processes the

set of PRs to obtain the existing pairwise conﬂicts.

Conﬂicts between PRs are obtained by performing an

in-memory merge

of the latest version of the source

branch of each PR. A pairwise conﬂict graph is gen-

erated where nodes represent each individual PR and

edges represent the existence of merge conﬂicts be-

tween PRs pairs.

Unconﬂicting PR Clustering. It processes the pair-

wise conﬂict graph to generate a set of groups that

each contains unconﬂicting PRs. Thus, the integra-

tion of each PR group into the target branch is opti-

mized because its PRs can be automatically integrated

as a single composite PR, resulting in a single conﬂict

resolution process. Among the set of possible solu-

tions to this clustering problem, our proposal gives

preference to those ones that have a smaller number

of the biggest possible groups. In this way, we mini-

mize the number of conﬂict resolutions to be actually

handled (one for each group).

Our approach solves this clustering problem as a

graph coloration problem (Kubale, 2004). The graph

coloring algorithm colors nodes that are not adja-

https://git-scm.com/docs/git-merge

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

cent with the same color. In the pairwise conﬂict

graph, two nodes are adjacent when the PRs repre-

sented by those nodes have conﬂicts. Therefore, the

non-adjacent nodes are those that do not conﬂict with

each other and these are the ones that are colored with

the same color. In this way, unconﬂicting PRs are

grouped together. In addition, the coloring algorithm

tries to ﬁnd the solution with the minimum number of

colors, thus the minimum number of unconﬂicting PR

groups.

We model the graph coloration problem as a Con-

straint Satisfaction Problem (CSP) as follows:

• A variable, colors, associated with the deﬁnition

domain [0, #PRs], that models the set of colors

available to color the graph. We use as an upper

bound the number of nodes (the trivial coloring

solution).

• A set of variables v

, associated with the deﬁnition

domain [0, #PRs], that model the color affected to

each node.

• A set of constraints v

< colors, to model that

nodes cannot use more than the available colors.

• A set of constraints v

6= v

, for any couple of

nodes (v

, v

) connected by an edge, to model that

nodes connected by edges cannot have the same

color,

• An objective that is minimize(colors), so the

solver will try to ﬁnd not only a solution but the

best solution and will use the objective to prune

some search branches.

Unconﬂicting PR Groups Representation. It is

quite straightforward from the output of 2

step. It

consists in representing a graph whose k nodes repre-

sent colors (unconﬂicting PR groups) from previous

step and whose edges correspond to integration con-

ﬂicts between PR groups. As any pair of PR groups

is in conﬂict (otherwise they would have the same

colour and have been regrouped), the resulting graph

is complete. The edges of the graph are labelled with

the number of pairwise conﬂicts that exist between

the members of the connected PR groups.

PR Groups Integration Sequence Optimization.

This step provides an ordered set of PR groups which

constitutes our calculated optimized PR group inte-

gration sequence according to the IPE. This order is

calculated by traversing the PR group graph to search

for the best trade-off that maximizes gain (integrate as

much PRs as possible) while minimizing cost (avoid

conﬂict resolutions as much as possible). The travers-

ing algorithm is shown in Algorithm 1. It starts with

the biggest node (line 10). In each step (lines 12-29),

it looks for the best neighbor node, which is the one

with the best trade-off between node size and the cu-

mulative cost of the paths from the node to the nodes

already visited (i.e., the total cost of integrating the

group assuming the already integrated groups).

Input: G is a PR group graph

Output: S is a sequence of nodes

1 S = []

/* select biggest node of G */

2 V = null

3 maxNodeSize = 0

4 for node in G.nodes do

5 if node.size > maxNodeSize then

6 V = node

7 maxNodeSize = node.size

8 end

9 end

10 S.add(V)

/* traverse graph nodes starting with the

biggest node */

11 while length(S) < length(G.nodes) do

12 neighbors = G.adjacentsOf(V) - S

13 bestNeighbor = null

14 bestTradeoffValue = 0

15 for neighbor in neighbors do

16 nodeSize = neighbor.size

17 EdgeAccumWeight = 0

18 for s in S do

19 E = G.edgeBetween(s, neighbor)

20 EdgeAccumWeight =

EdgeAccumWeight + E.weight

21 end

22 tradeoffValue = nodeSize /

EdgeAccumWeight

23 if tradeoffValue > bestTradeoffValue

then

24 bestNeighbor = neighbor

25 bestTradeoffValue = tradeoffValue

26 end

27 end

28 V = bestNeighbor

29 S.add(V)

30 end

31 return S

Algorithm 1: Get PR group integration sequence.

4 EVALUATION ON A CASE

STUDY

In this section we explain how we evaluate our pro-

posal. We set up a case study that consists in extract-

ing integration sequences from the history of a soft-

Improving Integration Process Efﬁciency through Pull Request Prioritization

Table 1: Historical integration sequence from October 16,

2017 to October 30, 2017 of Antlr4 project.

PR ID Integration timestamp

2052 2017-10-21 16:19:55

2058 2017-10-21 16:20:28

2055 2017-10-21 16:20:57

1978 2017-10-21 16:38:02

2062 2017-10-21 19:00:49

2032 2017-10-21 19:26:30

2057 2017-10-21 19:26:35

2063 2017-10-21 19:47:26

2011 2017-10-21 19:53:54

2064 2017-10-21 19:55:32

1996 2017-10-21 19:58:33

1983 2017-10-21 20:00:03

1955 2017-10-21 20:13:49

1974 2017-10-21 20:16:24

1917 2017-10-22 15:52:31

2033 2017-10-23 16:25:40

2070 2017-10-23 21:43:22

2077 2017-10-25 20:16:46

2072 2017-10-27 15:26:04

2073 2017-10-27 15:26:48

2074 2017-10-27 15:27:10

2075 2017-10-27 15:27:47

2076 2017-10-27 15:28:15

2067 2017-10-27 15:28:57

2068 2017-10-27 15:29:27

1951 2017-10-27 17:45:27

1990 2017-10-27 22:54:29

2083 2017-10-29 16:18:09

1930 2017-10-29 22:57:07

ware project and applying our proposal to the set of

PRs for each integration sequence.

4.1 Case Study Deﬁnition

Project Selection. We selected the project Antlr4

since it (i) is publicly available in GitHub, (ii) has

more than ten thousand stars, (iii) has more than two

thousand forks, and (iv) follows a PbD process. In

addition, its history has more than a thousand PRs,

which is an adequate number to evaluate the proposal.

Therefore, the project is suitable because it is popular

and has a good number of contributors and contribu-

tions.

Integration Sequence Extraction. Based on a time

window (t

, t

), we extract the integration sequence

from the project history. The range of the selected

time windows in the case study is 2 weeks based on

the usual sprint length in agile methodologies such as

Scrum (Diebold et al., 2015) or the size of the merge

window used in the Linux kernel project (German

et al., 2016). Opened PRs within the time window

, t

) can be integrated or rejected within or after the

https://github.com/antlr/antlr4

Figure 2: PR types according to their project life cycle for

a time window. Type 5 and 6 are targets of our case study

because those PRs are integrated into the deﬁned time win-

dows (t

, t

time window or remain open indeﬁnitely. Figure 2

shows all these PR types for PRs that are created be-

fore the time window and those that are created within

the time window. Our case study includes all the PRs

integrated within the time window to obtain the inte-

gration sequence. In Figure 2, these PRs correspond

to PR types 5 and 6. Rejected PRs (types 1, 4, 7 and

9) and those that are never closed (types 2 and 10) are

not incuded in the case study because those PR types

are not integrated into the project history. PR types

3 and 8 are not included because they are not inte-

grated within the considered time window. Therefore,

we obtain an integration sequence by extracting inte-

grated PRs within the time window (t

, t

) and sorting

them by their integration timestamp. This sequence

is the historical integration sequence. Table 1 shows

an example of a historical integration sequence of the

Antlr4 project corresponding to a time window from

October 16, 2017 to October 30, 2017.

4.2 Historical IPE

We evaluate the case study by calculating the IPE as a

function of the cumulative cost and gain of each inte-

gration step where the cost is the number of pairwise

conﬂicts to solve and the gain is the number of inte-

grated PRs.

Table 2 shows the cumulative cost and gain val-

ues for each integration step corresponding to the his-

torical integration sequence shown in Table 1. The

pairwise conﬂicts corresponding to this integration

sequence can be seen visually in Figure 4. We start

considering that the ﬁrst 10 PRs of Table 1 do not con-

ﬂict with each other. They are integrated at zero cost

since project admininstrator does not have to solve

any conﬂict to integrate them. Since PR #1996 con-

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

Table 2: Cumulative cost and gain values of each integra-

tion step for the historical integration sequence shown in

Table 1.

Integration

step

PR ID

Cumulative

Cost (x)

Cumulative

Gain (y)

1 2052 0 1

2 2058 0 2

3 2055 0 3

4 1978 0 4

5 2062 0 5

6 2032 0 6

7 2057 0 7

8 2063 0 8

9 2011 0 9

10 2064 0 10

11 1996 7 11

12 1983 7 12

13 1955 7 13

14 1974 8 14

15 1917 8 15

16 2033 8 16

17 2070 8 17

18 2077 8 18

19 2072 8 19

20 2073 8 20

21 2074 8 21

22 2075 8 22

23 2076 8 23

24 2067 8 24

25 2068 8 25

26 1951 8 26

27 1990 20 27

28 2083 20 28

29 1930 22 29

ﬂicts with 7 already integrated PRs (#2052, #2058,

#2055, #2062, #2057, #2063 and #2064), it is re-

quired to solve conﬂicts with those PRs to integrate

it. Therefore the cost of integrating PR #1996 is 7. As

PRs #1955 and #1983 do not conﬂict with any PR al-

ready integrated, then they are integrated at zero cost

and the cumulative cost is still 7. PR #1974 conﬂicts

with PR #2011, so the cumulative cost is 8. The fol-

lowing 12 PRs (#1917, #2033, #2070, #2077, #2072,

#2073, #2074, #2075, #2076, #2067, #2068, #1951)

do not conﬂict with the previously integrated PRs,

thus they are integrated at zero cost and the cumula-

tive cost is still 8. As PR #1990 conﬂicts with 12 pre-

viously integrated PRs (#2052, #2058, #2055, #2062,

#2057, #2063, #2064, #1996, #2070, #2077, #2067,

#2068), the cost is 12 and the cumulative cost is 20.

PR #2083 does not conﬂict with any of the previously

integrated PRs, so it is integrated at zero cost and the

cumulative cost is still 20. Finally, PR #1930 conﬂicts

with PRs #1951 and #2083, thus the integration cost

is 2 and the cumulative cost is 22.

Figure 3 maps the cost/gain to a trajectory where

axis x is the cumulative cost, axis y, the cumulative

gain. Each (x,y) coordinates is an integration step and

Figure 3: Integration trajectory corresponding to the histor-

ical integration sequence shown in Table 1. The area under

the trajectory represents the IPE.

Figure 4: Pairwise conﬂict graph obtained from the set of

PRs of Table 1.

the line between points is the integration step cost.

The trajectory models the integration sequence. The

area under the trajectory represents the IPE because

a larger area means that a higher gain is achieved at

a lower cost. The IPE corresponding to the historical

integration sequence represented on Figure 3 is 449.

In addition, the number of conﬂict resolutions is 4,

corresponding to the integration of PRs #1996, #1974,

#1990 and #1930.

4.3 Optimized IPE

We apply our approach to the set of PRs correspond-

ing to the historical integration sequence shown in Ta-

ble 1. Figure 4 shows the pairwise conﬂicts graph re-

Improving Integration Process Efﬁciency through Pull Request Prioritization

Figure 5: Colored pairwise conﬂict graph resulting from ap-

plying the second step of the proposal to the pairwise con-

ﬂict graph of Figure 4.

Figure 6: PR group graph obtained from the colored pair-

wise conﬂict graph of Figure 5.

sulting from applying the ﬁrst step of the proposal to

the set of PRs of the historical integration sequence.

Figure 5 shows the corresponding colored graph after

applying the second step of the proposal. The chro-

matic number k is 3 meaning that PRs can be grouped

into three groups where PRs do not conﬂict with each

other. Figure 6 shows the PR group graph obtained

after applying the third step of the proposal to the col-

ored pairwise conﬂict graph of Figure 5. Lastly, ap-

plying the fourth step of the proposal to the PR group

graph results in the following PR group integration

sequence: G0 → G1 → G2. So, 25 PRs can be au-

tomatically integrated into the target branch and the

remaining 4 PRs require manual conﬂict resolution.

The three PRs corresponding to G1 do not conﬂict

with each other but 14 pairwise conﬂicts need to be

solved to integrate them into the target branch. Fi-

nally, it is needed to solve 8 pairwise conﬂicts to inte-

grate the PR belonging to G2 to the target branch.

Table 3: Cumulative cost and gain values of each integration

step for the proposed PR group integration sequence.

Integration

step

Group

Cumulative

Cost (x)

Cumulative

Gain (y)

1 G0 0 25

2 G1 14 28

3 G2 22 29

Figure 7: Comparative graph between the historical integra-

tion trajectory and the PR group integration trajectory.

We evaluate the integration sequence optimized

by our proposal by calculating its IPE. Figure 7 shows

both the historical and our optimized integration se-

quences. The IPE corresponding to our optimized

integration sequence is 578 (28.73% higher than the

historical one). In addition, its number of conﬂict res-

olutions is 2, corresponding to the integration of the

G1 and G2 groups.

5 EXPERIMENTAL RESULTS

In this section, we report and discuss the main re-

sults achieved in our work. We extract PR informa-

tion from the GHTorrent dataset

(Gousios and Zaid-

man, 2014). It should be noted that we obtain pair-

wise conﬂicts from the project history considering the

head version of the PRs on the submission date.

We apply our proposal to seven representative

historical integration sequences of the Antlr4 project.

The selection criterion for these sequences is the

number of unconﬂicting PR groups obtained by ap-

plying the coloring algorithm to the pairwise conﬂict

graph corresponding to the integration sequences.

Table 4 shows information about the pairwise conﬂict

graphs corresponding to the selected integration

sequences. The number of PRs (# PRs) and the

number of pairwise conﬂicts (# Pairwise Conﬂcits)

corresponds to the number of nodes and edges of

the pairwise conﬂict graph respectively. The number

of potential conﬂict resolutions (# Potential conﬂict

We download the latest backup dated 2019-06-01 from

https://ghtorrent.org/downloads.html

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

resolutions) corresponds to the worst case of the

number of conﬂict resolutions for the case study.

Finally, the number of unconﬂicting PR groups (#

Unconﬂicting PR Groups) corresponds to the number

of groups (colors) that we obtained by applying the

coloring algorithm explained in Section 3.

RQ1. Can the efﬁciency of the integration process be

improved by prioritizing PRs according to conﬂicts?

Table 5 shows the comparison between the

historical IPE and the optimized IPE obtained by

our proposal for each integration sequence shown in

Table 4. We observe that for all selected integration

sequences our approach improves the historical

IPE, which means that less conﬂicting PRs are inte-

grated earlier in the proposed PR group integration

sequence. In addition, the number of conﬂict resolu-

tions resulting in the proposed PR group integration

sequence is less than or equal to the historical one.

Therefore, we can conclude that prioritizing PR

according to conﬂicts can improve the IPE.

RQ2. To what extent does our proposal improve the

IPE as compared to the historical IPE measured from

a real project history?

Table 5 shows a percentage of improvement of the

IPE between 28.73% and 156.52% as compared to

the historical IPE. We can thus conclude that our pro-

posal can help project administrators signiﬁcantly by

optimizing their integration work when the number of

pairwise conﬂicts is proportionally large with respect

to the number of PRs and the number of potential con-

ﬂict resolutions is close to the optimal.

It should be noted that our solution allows project

administrators to systematically reduce the number of

conﬂict resolutions but not the number of conﬂicts to

be solved.

Threats to Validity. The criteria deﬁned in order to

extract conﬂicts between PRs already integrated into

the project history could be further discussed. An-

other identiﬁed validity threat could be related to the

fact that the proposal was evaluated on a limited num-

ber of historical integration sequences. On the other

hand, we consider they are representative and include

a wide variety of cases. Finally, it would be argued

that the evaluation was not performed on distinct soft-

ware projects. In this way, we prioritized the selection

of the case studies in order to ensure real different sce-

narios more than the inclusion of many projects that

could contain no signiﬁcant differences.

6 RELATED WORK

In recent years, researchers have conducted several

studies to better understand the PbD model usage and

to improve the development process in this model

(Tsay et al., 2014a) (Tsay et al., 2014b) (Gousios

et al., 2014) (Gousios et al., 2015) (Gousios et al.,

2016). We can distinguish two processes within the

PbD model that are closely related: the review and in-

tegration processes. The review process reviews the

code to meet the project’s quality standards and de-

cides to accept or reject a contribution. The integra-

tion process integrates the accepted PRs by solving

merge conﬂicts for conﬂicting PRs.

From the review process viewpoint, works that

study latency factors are (Gousios et al., 2014),

(Zhang et al., 2014), (Yu et al., 2015), (Yu et al.,

2016b) and (Kononenko et al., 2018) that propose dif-

ferent quantitative / qualitative analyzes to identify la-

tency factors in the PR review process. These studies

inspired our proposal to study and improve the latency

of the PR integration process. Other works study

the PR acceptance factors (Tsay et al., 2014a), (Rah-

man and Roy, 2014), (Gousios et al., 2015), (Zam-

petti et al., 2019), (Legay et al., 2018) identifying

and analyzing the social and technical factors behind

PR acceptance or rejection. Gousios et al. (Gousios

et al., 2014) indicates that 27% of rejected PRs are

conﬂicting PRs. Therefore, our work could also im-

prove the acceptance rate by reducing the number of

conﬂicting PRs. Some works recommend the most

suitable project administrator for reviewing a given

PR (Thongtanunam et al., 2014), (Ying et al., 2016),

(Yu et al., 2016a), (Jiang et al., 2017) and (Jiang et al.,

2019).

Among the works that study PR prioritization we

ﬁnd some that prioritize PRs by response and accep-

tance likelihood (Van Der Veen et al., 2015), (Azeem

et al., 2020a) and (Azeem et al., 2020b). The goal of

these prioritization strategies is minimizing the time

required to obtain updates from contributors on the

most useful PRs. Zhao et al. (Zhao et al., 2019) pro-

pose a learning-to-rank approach to prioritize PRs that

can be quickly reviewed by project administrators in

order to review more PRs in a period of time or be

able to review any PR when they have a few minutes.

Recently, Saini and Britto (Saini and Britto, 2021) use

a Bayesian Network to prioritize PRs based on accep-

tance probability, change type (i.e. bug ﬁxing, new

feature, refactoring) and presence or absence of merge

conﬂicts. Their main goal is to decrease the overall

lead time of code review process along with helping

to reduce the workload of project administrators. The

work presented in this paper also prioritizes PRs us-

Improving Integration Process Efﬁciency through Pull Request Prioritization

Table 4: Information about selected historical integration sequences.

Case Study

Time Window

Start Date

Time Window

End Date

# PRs

# Pairwise

Conﬂicts

# Potential

Conﬂict

Resolutions

# Unconﬂicting

PR Groups

1 2017-02-12 2017-02-26 32 23 22 2

2 2017-10-16 2017-10-30 29 22 15 3

3 2018-07-14 2018-07-28 10 7 4 4

4 2018-10-28 2018-11-11 16 29 11 5

5 2017-10-01 2017-10-15 16 47 14 6

6 2017-10-08 2017-10-22 30 74 25 7

7 2018-11-05 2018-11-19 36 63 15 8

Table 5: Comparison between the historical and the optimized IPE obtaining by our proposal for each integration sequence

shown in Table 4.

Case Study

Historical Optimized IPE

improvement (%)# Conﬂict

Resolutions

IPE

# Conﬂict

Resolutions

IPE

1 3 503 1 690 37.17

2 4 449 2 578 28.73

3 3 23 3 59 156.52

4 7 294 4 387 31.63

5 11 480 5 632 31.66

6 17 1138 6 1978 73.81

7 11 1065 7 2014 89.11

ing a strategy very similar to that proposed by Zhao et

al. (Zhao et al., 2019), but with the aim of improving

the integration process instead of the review process.

From the integration process viewpoint, works

that study pairwise conﬂicts (Ma et al., 2017), (Zhang

et al., 2018) propose an analysis of the frequency and

difﬁculty of resolution. The tool proposed by Van

Der Veen et al. (Van Der Veen et al., 2015) offers

an alternative view to Github’s PR interface, which

allows developers to sort opened PRs by their num-

ber of pairwise conﬂicts. This information is use-

ful for project administrators to be aware of the im-

pact of integrating a PR in the integration process.

Other works are focused on the detection of dupli-

cate PRs (Li et al., 2017), (Ren et al., 2019), (Wang

et al., 2019), (Li et al., 2021) by comparing the textual

similarity of title and description or by the similarity

between code changes. Duplicate PRs are not consid-

ered in this paper.

7 CONCLUSIONS

In this paper, we optimize the efﬁciency of the inte-

gration process through PR prioritization. In particu-

lar, our approach is able to automatically calculate a

sequence of unconﬂicting PRs groups that minimizes

the number of conﬂict resolutions and orders the inte-

gration of the groups with the best trade-off between

the number of PRs and the number of conﬂicts still

to be solved. We evaluate the effectiveness of our ap-

proach applying it to seven representative historical

integration sequences of the Antlr4 project. Results

of our study show that the IPE of the integration se-

quence calculated by our approach is higher than the

historical IPE from 28.73% to 156.52%.

It should be noted that applying the approach in a

real environment could have side effects on the work

habits of the people involved in the project.

We plan to conduct an empirical study on a large

number of projects that use PRs intensively. We also

plan to propose a tool integrated into platforms that

support PbD (e.g.,GitHub, Bitbucket, etc.), in order

to (i) further evaluate the usefulness of our proposal,

(ii) study the side effects on the work habits when us-

ing our proposal, and (iii) discover additional factors

that can be used to improve the IPE performed by our

proposal. The study of accurate models for the eval-

uation of the cost and the gain of PR merges is also a

perspective for our work.

REFERENCES

Azeem, M. I., Panichella, S., Di Sorbo, A., Serebrenik, A.,

and Wang, Q. (2020a). Action-based recommenda-

tion in pull-request development. In Proceedings of

the International Conference on Software and System

Processes, pages 115–124.

Azeem, M. I., Peng, Q., and Wang, Q. (2020b). Pull request

prioritization algorithm based on acceptance and re-

sponse probability. In 2020 IEEE 20th International

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

Conference on Software Quality, Reliability and Secu-

rity (QRS), pages 231–242. IEEE.

Beck, K. (2000). Extreme programming explained: em-

brace change. addison-wesley professional.

Bird, C. and Zimmermann, T. (2012). Assessing the value

of branches with what-if analysis. In Proceedings of

the ACM SIGSOFT 20th International Symposium on

the Foundations of Software Engineering, pages 1–11.

Brindescu, C., Codoban, M., Shmarkatiuk, S., and Dig, D.

(2014). How do centralized and distributed version

control systems impact software changes? In Pro-

ceedings of the 36th International Conference on Soft-

ware Engineering, pages 322–333.

Chacon, S. and Straub, B. (2014). Pro git. Springer Nature.

Diebold, P., Ostberg, J.-P., Wagner, S., and Zendler, U.

(2015). What do practitioners vary in using scrum?

In International Conference on Agile Software Devel-

opment, pages 40–51. Springer.

German, D. M., Adams, B., and Hassan, A. E. (2016). Con-

tinuously mining distributed version control systems:

an empirical study of how linux uses git. Empirical

Software Engineering, 21(1):260–299.

Gousios, G., Pinzger, M., and Deursen, A. v. (2014). An

exploratory study of the pull-based software develop-

ment model. In Proceedings of the 36th International

Conference on Software Engineering, pages 345–355.

Gousios, G., Storey, M.-A., and Bacchelli, A. (2016). Work

practices and challenges in pull-based development:

the contributor’s perspective. In 2016 IEEE/ACM

38th International Conference on Software Engineer-

ing (ICSE), pages 285–296. IEEE.

Gousios, G. and Zaidman, A. (2014). A dataset for pull-

based development research. In Proceedings of the

11th Working Conference on Mining Software Repos-

itories, pages 368–371.

Gousios, G., Zaidman, A., Storey, M.-A., and Van Deursen,

A. (2015). Work practices and challenges in pull-

based development: The integrator’s perspective. In

2015 IEEE/ACM 37th IEEE International Conference

on Software Engineering, volume 1, pages 358–368.

IEEE.

Igaki, H., Fukuyasu, N., Saiki, S., Matsumoto, S., and

Kusumoto, S. (2014). Quantitative assessment with

using ticket driven development for teaching scrum

framework. In Companion proceedings of the 36th in-

ternational conference on software engineering, pages

372–381.

Jiang, J., Lo, D., Zheng, J., Xia, X., Yang, Y., and Zhang,

L. (2019). Who should make decision on this pull re-

quest? analyzing time-decaying relationships and ﬁle

similarities for integrator prediction. Journal of Sys-

tems and Software, 154:196–210.

Jiang, J., Yang, Y., He, J., Blanc, X., and Zhang, L. (2017).

Who should comment on this pull request? analyzing

attributes for more accurate commenter recommenda-

tion in pull-based development. Information and Soft-

ware Technology, 84:48–62.

Kononenko, O., Rose, T., Baysal, O., Godfrey, M., Theisen,

D., and De Water, B. (2018). Studying pull request

merges: a case study of shopify’s active merchant. In

Proceedings of the 40th International Conference on

Software Engineering: Software Engineering in Prac-

tice, pages 124–133.

Kubale, M. (2004). Graph colorings, volume 352. Ameri-

can Mathematical Soc.

Legay, D., Decan, A., and Mens, T. (2018). On the impact

of pull request decisions on future contributions. arXiv

preprint arXiv:1812.06269.

Li, Z., Yin, G., Yu, Y., Wang, T., and Wang, H. (2017).

Detecting duplicate pull-requests in github. In Pro-

ceedings of the 9th Asia-Paciﬁc Symposium on Inter-

netware, pages 1–6.

Li, Z.-X., Yu, Y., Wang, T., Yin, G., Mao, X.-J., and Wang,

H.-M. (2021). Detecting duplicate contributions in

pull-based model combining textual and change simi-

larities. Journal of Computer Science and Technology,

36(1):191–206.

Ma, P., Xu, D., Zhang, X., and Xuan, J. (2017). Changes

are similar: Measuring similarity of pull requests that

change the same code in github. In Software Engineer-

ing and Methodology for Emerging Domains, pages

115–128. Springer.

Mens, T. (2002). A state-of-the-art survey on software

merging. IEEE transactions on software engineering,

28(5):449–462.

Pham, R., Singer, L., Liskin, O., Figueira Filho, F., and

Schneider, K. (2013). Creating a shared understand-

ing of testing culture on a social coding site. In 2013

35th International Conference on Software Engineer-

ing (ICSE), pages 112–121. IEEE.

Rahman, M. M. and Roy, C. K. (2014). An insight into

the pull requests of github. In Proceedings of the

11th Working Conference on Mining Software Repos-

itories, pages 364–367.

Ren, L., Zhou, S., Kästner, C., and W ˛asowski, A.

(2019). Identifying redundancies in fork-based devel-

opment. In 2019 IEEE 26th International Conference

on Software Analysis, Evolution and Reengineering

(SANER), pages 230–241. IEEE.

Rodríguez-Bustos, C. and Aponte, J. (2012). How dis-

tributed version control systems impact open source

software projects. In 2012 9th IEEE Working Confer-

ence on Mining Software Repositories (MSR), pages

36–39. IEEE.

Saini, N. and Britto, R. (2021). Using machine intelligence

to prioritise code review requests. In 2021 IEEE/ACM

43rd International Conference on Software Engineer-

ing: Software Engineering in Practice (ICSE-SEIP),

pages 11–20. IEEE.

Thongtanunam, P., Kula, R. G., Cruz, A. E. C., Yoshida,

N., and Iida, H. (2014). Improving code review effec-

tiveness through reviewer recommendations. In Pro-

ceedings of the 7th International Workshop on Coop-

erative and Human Aspects of Software Engineering,

pages 119–122.

Tsay, J., Dabbish, L., and Herbsleb, J. (2014a). Inﬂuence of

social and technical factors for evaluating contribution

in github. In Proceedings of the 36th international

conference on Software engineering, pages 356–366.

Improving Integration Process Efﬁciency through Pull Request Prioritization

Tsay, J., Dabbish, L., and Herbsleb, J. (2014b). Let’s talk

about it: evaluating contributions through discussion

in github. In Proceedings of the 22nd ACM SIGSOFT

international symposium on foundations of software

engineering, pages 144–154.

Van der Veen, E. (2015). Prioritizing pull requests. -.

Van Der Veen, E., Gousios, G., and Zaidman, A. (2015).

Automatically prioritizing pull requests. In 2015

IEEE/ACM 12th Working Conference on Mining Soft-

ware Repositories, pages 357–361. IEEE.

Wang, Q., Xu, B., Xia, X., Wang, T., and Li, S. (2019).

Duplicate pull request detection: When time matters.

In Proceedings of the 11th Asia-Paciﬁc Symposium on

Internetware, pages 1–10.

Ying, H., Chen, L., Liang, T., and Wu, J. (2016).

Earec: leveraging expertise and authority for pull-

request reviewer recommendation in github. In 2016

IEEE/ACM 3rd International Workshop on Crowd-

Sourcing in Software Engineering (CSI-SE), pages

29–35. IEEE.

Yu, Y., Wang, H., Filkov, V., Devanbu, P., and Vasilescu,

B. (2015). Wait for it: Determinants of pull request

evaluation latency on github. In 2015 IEEE/ACM 12th

working conference on mining software repositories,

pages 367–371. IEEE.

Yu, Y., Wang, H., Yin, G., and Wang, T. (2016a). Reviewer

recommendation for pull-requests in github: What can

we learn from code review and bug assignment? In-

formation and Software Technology, 74:204–218.

Yu, Y., Yin, G., Wang, T., Yang, C., and Wang, H. (2016b).

Determinants of pull-based development in the con-

text of continuous integration. Science China Infor-

mation Sciences, 59(8):1–14.

Zampetti, F., Bavota, G., Canfora, G., and Di Penta, M.

(2019). A study on the interplay between pull re-

quest review and continuous integration builds. In

2019 IEEE 26th International Conference on Software

Analysis, Evolution and Reengineering (SANER),

pages 38–48. IEEE.

Zhang, X., Chen, Y., Gu, Y., Zou, W., Xie, X., Jia, X., and

Xuan, J. (2018). How do multiple pull requests change

the same code: A study of competing pull requests

in github. In 2018 IEEE International Conference on

Software Maintenance and Evolution (ICSME), pages

228–239. IEEE.

Zhang, Y., Yin, G., Yu, Y., and Wang, H. (2014).

A exploratory study of@-mention in github’s pull-

requests. In 2014 21st Asia-Paciﬁc Software Engi-

neering Conference, volume 1, pages 343–350. IEEE.

Zhao, G., da Costa, D. A., and Zou, Y. (2019). Improv-

ing the pull requests review process using learning-

to-rank algorithms. Empirical Software Engineering,

24(4):2140–2170.

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering
