Machine Learning in Software Development Life Cycle:

A Comprehensive Review

Maryam Navaei and Nasseh Tabrizi

Department of Computer Science, East Carolina University, East 5

Street, Greenville, NC, U.S.A.

Keywords: Software Engineering, Software Development Life Cycle, Artificial Intelligence, Machine Learning, Machine

Learning Algorithms.

Abstract: This research concludes an overall summary of the publications so far on the applied Machine Learning (ML)

techniques in different phases of Software Development Life Cycle (SDLC) that includes Requirement

Analysis, Design, Implementation, Testing, and Maintenance. We have performed a systematic review of the

research studies published from 2015-2021 and revealed that Software Requirements Analysis phase has the

least number of papers published; in contrast, Software Testing is the phase with the greatest number of papers

published.

1 INTRODUCTION

As Software Engineering has become an essential

industrial domain and software systems have become

increasingly complex due to the performance

requirements of their operating environment, the

ability to design, develop, maintain, and adapt these

systems has surpassed human comprehension alone

(Elhabbash et al., 2019). Therefore, software systems

need to autonomously adapt to changing

environments to guarantee expected quality of service

(Wan et al, 2019).

Artificial Intelligence (AI) has a long tradition in

computer science. Since 1950 in its first three

decades, the academy and industry worked

diligently to reach to human level machine

intelligence. In retrospect that was an overly

optimistic expectation (Holzinger et al., 2018).

Nevertheless, the need for more automation and

intelligence have led to further advances in ML and

AI. Researchers are increasingly applying ML and AI

to remediate failures and inadequacies in the software

systems and the SDLC (Khomh et al., 2018). ML is a

branch of AI that uses data or former development

experience to enhance the performance standards of

software systems (Zhang et al., 2017, Zhu et al.,

2018).

Traditionally, software systems are built

deductively, by implementing the rules that

administer the system performances as program code.

However, with ML techniques, these rules are

collected from training data. Conventionally, ML

methods can learn a model’s parameters

automatically using training data and thus it can

create models with respectable performance that can

satisfy the software system requirements. ML has

achieved great success in challenging real-world AI

and data mining scenarios, such as object detection,

natural image processing, autonomous car driving,

urban scene understanding, automatic machine

translation of human speech, and web

search/information retrieval, among others (Gong et

al., 2019, Chen et al. 2015, Peng et al., 2017).

ML enables computer systems to use data,

examples, and experience without human

involvement but to replicate some form of human

intelligence. ML algorithms are utilized to help

computer systems learn rules from data (England,

2018). These technologies will be optimized to be the

core components in a variety of software-intensive

systems. Recent advances in ML have fostered

extensive interest in the Information Technology

industry to integrate AI capabilities into software and

services. Systems employing ML technologies, have

distinctive characteristics moderately distinctive from

those of the other software systems. Functionalities of

ML based systems heavily depend on the quality of

training datasets used to create the predictive models.

Changing the training dataset has significant impact

on learning results and thus on functional behavior of

programs (Bird et al., 2017, Nakajima, 2018).

344

Navaei, M. and Tabrizi, N.

Machine Learning in Software Development Life Cycle: A Comprehensive Review.

DOI: 10.5220/0011040600003176

In Proceedings of the 17th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2022), pages 344-354

ISBN: 978-989-758-568-5; ISSN: 2184-4895

ML is used to continuously improve system

performance and efficiency on a particular task by

helping computer systems to learn from experience

how to perform the job autonomously. ML plays a

significant role in SDLC and has been used in variety

of domains (Alloghani et al., 2020, Shafiq et al., 2021,

Abubakar et al., 2020). For example, these domains

include defect prediction, requirements elicitation

etc. Therefore, ML is becoming one of the most

important technologies used in SDLC. It is being

applied to poorly understood problem domains where

little domain knowledge currently exists for the

humans to develop effective methodologies. These

scenarios include data mining large databases

containing valuable but undiscovered implicit

regularities, and domains where software systems

must adapt to changing conditions (Khomh et al.,

2018). ML has become the preferred technique for

developing practical Software Systems in Computer

Vision, Speech Recognition, Natural Language

Processing, Robot Control, Health Systems, Banking,

Defence, E-Commerce and many more environments

(Panichella and Ruiz, 2020, Bhatore et al., 2021).

Conventionally, developing software systems

necessitates on specifying the requirements in

advance to define how the system should behave.

ML techniques are being used to accelerate SDLC

and has been used in many areas including behavior

extraction, testing, and bug fixing (Meinke and

Bennaceur, 2018, DE-Arteaga et al., 2018). This has

led to a new paradigm in technology invention.

During the SDLC, the development team must spend

significant time discussing how the system must

operate to decide which features should be prioritized

and which ones need to be eliminated. This

Requirement Analysis needs to be followed by

Design, Implementation, Testing and Integration, and

Maintenance phases (Cetiner and Sahingoz, 2018).

By utilizing ML algorithms, software developers

can accelerate the decision-making process based on

the previous projects to create data-driven business

decisions to ultimately help decrease the development

risks and costs. This is invaluable for software

companies. Since projects can go over costs and

deadlines, coming up with a precise budget and

schedule to develop software systems can be an

overwhelming task. Therefore, accurate estimation of

efforts is highly crucial for Software Project

Planning. With the help of ML techniques, the

development team can analyze data from past projects

to provide a more precise budget estimate and

delivery time frame (Yurdakurbann and Erdogan,

2018).

ML also has a great impact in decreasing the time

spent on prototyping as well as the number of expert

engineers required to develop the software. In

Software Testing, with the help of ML algorithms,

testers can come up with more accurate results to

reduce the errors in the system. ML techniques also

help accelerate the process of finding defects. Since

clean code is crucial for effective software

maintenance, large scale code refactoring is

unavoidable.

Utilizing ML techniques, developers can review

the code and maintain it automatically. Since

maintenance is one of the most critical yet expensive

phases of SDLC, this results in developing high

quality Software Systems. Traditional SDLC can

benefit from ML models for rapid prototyping,

intelligent programming assistants, automatic

analytics and error handling, automatic code

refactoring, and precise estimates and strategic

decision-making. Given the significant role that ML

techniques and AI-based systems can play in the

development of Software systems, it is very important

for both the Software Engineering and ML

communities to research and develop innovative

approaches to address the advantages and

disadvantages (Khomh et al., 2018, Abubakar et al.,

2020). Although ML datasets for SDLC analysis are

often poorly documented and maintained and do not

have clear creation processes (Hutchinson et al.,

2021) there are many advantages in utilizing ML

techniques.

Because of the significant role of ML techniques

in SDLC and their advantages, we have prepared an

overall review to see the impact of data analytics and

ML algorithms on each phase of the SDLC. We were

interested to identify phases in which ML models are

widely being utilized. Our goal was to see why

researchers focused more on certain phases than

others when it comes to utilizing ML methodologies.

We also wanted to see if ML techniques can be

applied to less popular phases as well.

To prepare our review, we collected and compiled

a database of almost 150 journal articles and

conference papers retrieved from ACM, IEEE and

Springer digital libraries within the past five years.

We created figures to demonstrate visually and

summarize current research trends. Our research

uncovers significant differences in the use of ML

methodologies in various aspects of Software

Engineering and the SLDC (e.g., Requirements

Analysis, Design, Implementation, Testing and

Maintenance). After a discussion of related work and

our methodology, we discuss our findings for each

Machine Learning in Software Development Life Cycle: A Comprehensive Review

345

phase of SDLC. We then conclude with a summary

of our work and suggestions for further research.

2 RELATED WORK

In this paper we review current research on

applications of ML to different phases of SDLC and

SE generally. Because of the popularity of

incorporating ML techniques into SDLC, several

prior researchers have conducted empirical studies of

SE for data science. One study focused on differences

between the development of ML systems and non-

ML systems in various aspects of SE. That study used

interviews to identify pain points from a general

tooling standpoint to discover the challenges and

obstacles of implementing visual analytic tools as

none of the SE phases have a developed set of tools

and methods (Kim et al., 2018, Giray, 2021). Another

study focused on characterizing professional roles

and practices regarding data science (Wan et al,

2019).

ML Software systems are challenging to test and

verify. Sometimes the ML model may be incorrect

even if the learning algorithm is executed properly

due to inaccurate training data. Traditional testing

techniques are insufficient for such systems.

Therefore, it is crucial for Software Engineers to

research and develop advanced ways to report these

challenges (Khomh et al., 2018). Software Engineers

focused on the challenge of verifying accuracy of

systems built using ML and AI models and testing

those systems.

Multiple previous literature reviews have been

written on applying ML algorithms to each phase of

SDLC (Talele and Phalnikar, 2021, Lima et al.,2020,

Sobhy et al., 2021, Syaeful et al.,2017). We came

across a publication that provides a broader context

that discusses the relationship of ML techniques and

its tools within SDLC stages which is related to our

work to some extend however their review was

performed for the period of 1991 to 2021(Shafiq et

al., 2021). Nonetheless, our paper utilizes a

systematic review methodology to study the impact

of ML across the entire SDLC in the most recent

publications (2015-2021) as opposed to focusing on a

single phase as seen in most publications. Our

research also makes an additional contribution by

identifying the four most popular ML algorithms in

overall SDLC. We studied those four techniques in

each phase independently to observe their overall

popularity based on each phase of life cycle.

3 METHODOLOGY

Initially, we intended to focus on publications for the

past decade (2010-2020). Due to overwhelming

number of publications, we finally decided to focus

our review on the journal articles and conference

papers published in the past five years. We realized

the application of ML in SDLC considerably

increased in the past ten years where it had a slow

start from 2010 to 2015 and then significantly boosted

from 2015 onward based on the number of

publications, because recent advances in ML greatly

impacted SDLS as ML techniques can change and

update software systems.

We used different keywords and queries to

retrieve our results from ACM, IEEE and Springer

databases. Some queries gave us our desired results in

IEEE and Springer whereas we had to modify our

keywords and queries to retrieve relevant

publications from ACM. Additionally, we found out

that ACM would return significant number of

irrelevant publications when using verbatim queries

utilized in the other two libraries. Therefore, we had

to apply more constraints when searching in ACM

database. For instance, we had to include ‘Artificial

Intelligence’ as a keyword to ensure our query

retrieved relevant results.

There were situations where our queries returned

similar or enhanced work in more than one

publication, we treated each of those as a separate

publication since each focused on a unique topic.

Also, there were situations where one ML technique

was utilized in multiple phases, we counted those

separately for each phase. The latter scenario led us

to study the four trendiest ML techniques in each

phase furthermore to have a more focused

observation.

4 CURRENT APPLICATIONS OF

MACHINE LEARNING TO

SDLC

ML plays a significant role throughout the SDLC. In

this section we discuss the impact of applying ML in

each phase of the SDLC:

• Software Requirements Analysis

• Software Architecture Design

• Software Implementation

• Software Testing

• Software Maintenance

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

346

We provide an overview of each phase of the SDLC

and discuss current research trends in ML for each

phase.

4.1 Software Requirements Analysis

and Machine Learning

Software Requirements Analysis (also called

Requirements Engineering) clarifies the

specifications needed for a software system to satisfy

the business requirements. High quality software

development strongly depends on clearly defined

Software Requirements (SR) that explains the needs

and expectation of the software in a very detailed

form (Navarro-Almanza et al., 2017). These

requirements must be documented, measurable,

testable, traceable, and related to the business needs.

Requirements Engineering (RE) plays an

important role in the overall process of Software

Development and consists of two main phases:

Requirements Identification and Prioritization (Talele

and Phalnikar, 2021). Requirements Analysis is

critical to the success or failure of a Software system.

Software Engineers must also perform Requirements

Classification during the Analysis phase.

Requirements Classification is cumbersome, time

consuming, and difficult when performed as a manual

process. RE consists of four parts: Requirements

Elicitation and Discovery, Requirements

Specification and Analysis, Requirements Validation

and Requirements Management (Iqbal et al., 2018).

However, after utilizing ML techniques, Software

Engineers were able to automate the process of

grouping the requirements into Functional

Requirement (FRs) and Non-Functional

Requirements (NFR) (Quba et al., 2021). RE is also

one of the key factors in Software Quality (Panichella

and Ruiz, 2020).

In SDLC, requirement analysis is the process of

correct requirement gathering, the efficient

examination of collected requirements, and clear

requirement documentation. As software systems

increase in complexity and scale, Requirement

Engineering becomes a challenging issue that leads to

increased development costs. This has led to

engineers showing additional interest in automatic

requirement analysis techniques which can lead to

more accurate and rapid analysis of SR and reduction

in development costs. ML methodologies are being

used for Requirement Prioritization where engineers

need to decide which set of requirements to be

considered first and in requirement specification. ML

algorithms are likely to classify and prioritize the

requirements efficiently and how they can be

evaluated (Talele and Phalnikar, 2021).

Researchers have shown a lot of interest in

applying Supervised ML algorithms including

Support Vector Machine, Naïve Bayes, Decision

Tree, K-Nearest Neighbor and Random Forest when

their focus is on one of the following broad categories

(Gramajo et al., 2020):

• Detection of linguistic problems in

requirements documents and artifacts

written in natural language

• Classification of document content

• Requirement traceability

• Effort estimation

• Requirements analysis

• Failures Prediction

• Quality of and detection of business rules.

Techniques used in Software Requirements

Specification (SRS) approach are Natural Language

Processing (NLP) and Information Retrieval (IR)

(Navarro-Almanza et al., 2017). ML provides

approaches that use big data to enable a ML algorithm

to learn from producing outputs, which would be

difficult to obtain otherwise (Horkoff, 2019). RE

plays a key role in the success of a project. Based on

previous research that was conducted on 350

companies to understand project failure rates, 16.2%

projects were completed successfully, 52.7% faced

challenges and were partially completed. About 31%

of the projects were never completed due to poor RE

(Haleem et al., 2021).

One main limitation with public ML datasets is

that there are a limited number of such datasets

available for Requirements Analysis. One of the most

used RE databases is the PROMISE repository, which

is unbalanced and has only 625 classified

requirements written in natural language (Iqbal et al.,

2018). Despite limitations of current ML algorithms

in recognizing and prioritizing requirements,

including scalability, dependency, and complexity

(Talele and Phalnikar, 2021), what prompts

researchers to show continued interest in utilizing ML

algorithms in SR classification is the significant role

that these techniques play in helping developers

document their software with more precision and

validation. This makes the software system easier to

understand and use (Quba et al., 2021).

Machine Learning in Software Development Life Cycle: A Comprehensive Review

347

4.2 Software Architecture Design and

Machine Learning

The Architecture Design phase (also called the

preliminary or general design stage) deals with

converting the defined requirements from the

Analysis phase into an implementable form. Software

design has a major impact on software quality.

Examples of bad design include anti-patterns, high

dependency design, and massive source code files.

These make SE tasks more difficult by exacerbating

the challenges and expense of fixing software defects

(Zhang et al., 2017, McIntosh and Kamei 2017).

This phase can be divided into three categories:

Interface Design, Architectural Design and Detailed

Design. Interface Design specifies interaction

between a system and its users. In the Architectural

Design, the specification of major system

components, their responsibilities, relationships, and

their interactions are defined. During Detailed Design

the specification of internal elements of all major

system components along with their properties,

relationships and data structures are determined.

Evaluation of system architecture is a turning point in

the decision-making process. It aims at justifying the

extent to which decisions made during Architecture

Design satisfy a system’s quality requirements.

Specifically, when there are functional uncertainties

and changing requirements. Architecture Evaluation

facilitates the process of identifying and minimizing

the design risks that save integration, testing and

evolution costs in software systems (Sobhy et al.,

2021).

Software Design should be clear and

understandable to meet all system requirements.

Since subsequent phases of SDLC significantly rely

on the Architecture Design phase, many companies

and researchers show interest in understanding the

relationship between Software Design and

Maintenance. Researchers have been working on

introducing various ML techniques for efficient

prediction of Software Design’s impact on

maintainability of a system (Elmidaoui et al., 2020).

Several ML techniques are being used in this

phase on criteria such as predicting the design for a

mobile application’s user interface (UI), predicting

the architecture for safety critical systems, web

service anti-pattern detection, etc. For instance,

design patterns can add complexity. This leads to an

increase in maintenance and evolution efforts. Using

ML for design pattern detection decreases the system

complexity and results in increased understandability

of the software’s architecture and design (Mhawish

and Gupta, 2019, Dwivedi et al., 2016, Dwivedi et al.,

2016).

Code Smells, Call Dependencies and Lines of

Code can be indicators of poor architecture and

design (McIntosh and Kamei, 2021). Code Smells are

not the errors in implementation; rather they are

weaknesses in the design of part of the software

system that can either impede the development

process or increase the chance of system failure and

errors in the future. Detecting Code Smells could

lessen the work of developers, resources, and cost of

development (Kaur et al., 2017).

Since detecting Code Anomalies requires

refactoring approach, Support Vector Machine is the

most effective ML algorithm used for this matter

(Gramajo et al., 2020). Design patterns are a known

reverse engineering technique to solve numerous

problems in the design phase; they can be mined from

source code of similar category software. Data

mining from design patterns, which is based on

supervised learning and software metrics, is another

most popular research area in Design phase. ML

techniques are being used to enhance pattern mining

by excluding as many false matches as possible. ML

algorithms such as Layer Recurrent Neural Network,

Random Forest, Support Vector Machine and Boost

are mostly used in this process (Navarro-Almanza et

al., 2017, Giray, 2021).

4.3 Software Implementation and

Machine Learning

The Implementation phase involves construction of

the actual software system. Coding the system takes

place in this phase and when it is complete, the result

will be evaluated against the elicited requirements

from the Analysis phase. Software defects are

prevalent in software development and might cause

several problems for users and developers alike. As a

result, research has examined distinct techniques to

diminish the impacts of these defects in the source

code. One of the most prominent algorithms focuses

on defect prediction using ML methods. This helps

developers in managing these defects before they are

commenced in the production (Esteves et al., 2020).

Code refactoring is one of the popular research

areas for this phase. Refactoring changes the system

in such a way that does not alter the external behavior

of the code but will improve its internal structure.

Software containing code smells indicates a violation

of design and coding practices in SDLC. This issue

can turn into a larger problem as the effort to remove

the errors will increase exponentially if code smells

are left unremedied (Gupta et al., 2019).

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

348

ML algorithms can precisely model the

refactoring recommendations. Process and ownership

metrics both play a significant role in the creation of

highly effective models. In addition, models trained

with data from heterogeneous projects generalize

better and achieve great performance (Aniche et al.,

2020). God Classes, Long Methods, Functional

Decomposition and Spaghetti Code are the most

frequently identified code smells (Paiva et al., 2017).

Supervised Machine Learning algorithms are

known to be the most effective approach in predicting

code refactoring, as these will help developers to

make faster and more-educated decisions considering

what to refactor. These ML techniques evaluated

included Support Vector Machines, Naïve Bayes,

Decision Trees, Random Forest, Logistic Regression

and Neural Networks. Random Forest has emerged as

the most accurate approach in predicting software

refactoring using Apache, F-Droid and GitHub

datasets (Sagar et al., 2021).

4.4 Software Testing and Machine

Learning

In order to verify and validate Software Systems,

engineers need to find a system’s faults and defects.

Software Testing is thus one of the most important

phases in SDLC. The objective of Software Testing is

to reveal existing faults, particularly during

automated testing (Nasrabadi and Parsa, 2021). Due

to constant changes to the codebase of a system,

errors, failures and defects can happen in system

behavior, there should be automated tests to identify

these errors before a system is deployed.

Improvements in system infrastructure by finding its

faults could save up to third of its costs (Lima et al.,

2020).

Testing helps developers ensure the behavior of a

system is working as specified. Testing efforts must

be predicted in advance to guarantee time efficiency,

effort, and cost usage (Syaeful et al., 2017). In

general, Software Testing is an inductive inference in

which the tester determines the general properties of

a software system by carefully studying the behavior

of the system on a finite number of test cases (Zhu et

al., 2018).

As software systems increase in complexity, it

becomes more difficult to detect faults (Li et al.,

2020). We can collect numerous kinds of data during

software testing process, including execution traces,

coverage information for test cases, failure data etc.

ML techniques applied during Software Testing

identifies the patterns in data that often feature about

data generation process and will be used for decision-

making. Experts need to provide inputs to transform

raw test data into abstract test cases (Bhavsar et al.,

2019).

Test cases are generated to provide test output

data. Decision trees or induction rules are widely used

in Software Testing especially in fault prediction.

Models produced by these techniques are simpler to

interpret compared to techniques that are more

sophisticated such as neural networks or support

vector machines. Support Vector Machine and

Random Forest provide best prediction models for

these datasets (the most widely used Testing dataset

is from NASA) in fault prediction (Bhavsar et al.,

2019, Zhu, 2020).

When testing software, there are considerable

advantages to be gained from techniques which

propose unusual interactions within a system.

Techniques such as Random Testing, Fuzzing and

Exploratory Testing have a disadvantage, however, in

that the outputs of the tests need to be manually

checked for correctness which adds additional effort

for Software Engineers (Roper, 2019). Currently

testing techniques and software reengineering are

critical and most crucial in determining software

usability (Banga et al., 2019, Herzig and Nagappan,

2015).

Due to the quantifiable nature of Software

Testing, there are many datasets available. Likewise,

the number of publications is also significantly higher

compared to other phases.

4.5 Software Maintenance and

Machine Learning

The process of maintaining a software system after it

has been delivered, modifying, and updating it to

correct defects is called Software Maintenance. This

is the final phase of SDLC. Software Maintenance has

become an important area in SE related to software

quality. Consequently, predicting this characteristic

in an accurate and timely manner is a crucial

requirement for efficient management during the final

phase of SDLC (Gupta and Chug, 2021).

Software Maintenance incorporates repair,

preservation, and continuing optimization of a

system. This phase has four different categories:

Preventive Maintenance, Corrective Maintenance,

Adaptive Maintenance and Perfective Maintenance

(Sulaiman, 2005). As change is inevitable, engineers

must develop techniques for evaluating, controlling,

and making modification. Software Engineers need

to be capable of predicting software maintainability

in time, ensuring a constrained and optimum use of

the available resources. A large number of ML

Machine Learning in Software Development Life Cycle: A Comprehensive Review

349

techniques, including hybrid techniques, ensemble

techniques, and meta-heuristic techniques have been

explored for Software Maintainability Prediction

(SMP) (Alsolai, 2018, Gupta and Chug, 2021, Baskar

and Chandrasekar, 2018). Yet researchers continue to

seek improvement in this area.

A significant amount of time sometimes about 60-

70% in SDLC total cost is dedicated to maintenance

purposes (Gupta and Chug, 2021). As software

systems are getting more complex and increasing in

size, maintenance has become increasingly difficult.

Therefore, software maintainability has turned into a

serious challenge that companies are dealing with.

Software maintainability is directly connected with

the financial implementation and project success (Jha

et al., 2019).

Software Maintenance is classified based on three

viewpoints: intention-based classification, activity-

based classification, and evidence- based

classification. Software Maintenance involves bug

fixing, upgrading, and enhancing the software

program.

Many ML and AI techniques have been used in

Software Maintenance. Yet, there are not sufficient

datasets available as input data. Among available

datasets, their size is not large enough to give accurate

results. More work is needed in this area. Fuzzy logic

is the mostly frequently used ML technique in

Software Maintenance predictive models (Haleem et

al.,2021). Other techniques include ML algorithms

such as Soft Computing, Fuzzy Networks,

Evolutionary Algorithm, Deep Learning and ID3

(Xin et al., 2018).

5 RESULTS

We include publications from 2015 to 2021 in this

review.

The figure below summarizes how many journal

articles and conference papers are published in ACM,

IEEE and Springer for the period of 2015 to 2021 that

focus on ML techniques applied in each phase of

SDLC.

Table 1 lists the keywords we used to retrieve

these publications and ultimately generate the figures

to show the overall results. For some of the phases,

we had to modify our search queries as it was a quite

challenge to find more related and accurate results.

Whereas some phases like Testing, had a very large

number of publications.

Table 1: Searched Keywords for Paper Retrieval.

Keywords (Searched Queries)

Software engineering AND Machine learning

Software Development Life Cycle AND Machine

Learning

Machine Learning AND Software System

Requirements Analysis

Machine Learning AND Software Design

Machine Learning AND Software Implementation

Machine Learning AND Software Testing

Machine Learning AND Software Maintenance

Impact of Machine Learning in Software

Maintenance

Impact of Machine Learning in Software

Architecture

Impact of Machine Learning in Software

Requirements

Software Requirements Analysis AND Random

Forest Algorithm

Software Requirements Analysis AND Support

Vector Machine

Software Requirements Analysis AND Naïve

Bayes

Software Requirements Analysis AND Decision

Trees

Software Design Phase AND Random Forest

Algorithm

Software Design Phase AND Support Vector

Machine

Software Design Phase Analysis AND Naïve

Bayes

Software Implementation AND Random Forest

Algorithm

Software Implementation AND Support Vector

Machine

Software Implementation AND Naïve Bayes

Software Testing AND Random Forest Algorithm

Software Testing AND Support Vector Machine

Software Testing Analysis AND Naïve Bayes

Software Maintenance AND Random Forest

Algorithm

Software Maintenance AND Support Vector

Machine

Software Maintenance Analysis AND Naïve

Bayes

Software Maintenance AND Decision Trees

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

350

As shown in Figure 1, Software Requirements

Analysis has the least number of papers published in

this topic; in contrast, Software Testing has the largest

number of publications. The reason is partially

because there are many datasets available for

Software Testing due to its quantifiable nature as well

as the ease of obtaining data for this phase.

Figure 1: ML Applied in SDLC – Papers published from

2015 to 2021.

Hence it is much easier to utilize ML techniques

in Software Testing than in Requirements Analysis.

In Figure 2, we narrowed our findings by selecting

the four most used ML algorithms in all phases of

SDLC (Random Forest, Support Vector Machine,

Naïve Bayes and Decision Trees). Ultimately, we

analyzed all the relevant publications done in ACM,

IEEE and Springer in the same timeframe to see

which ML methodologies are the most popular in

particular phases.

Figure 2: SDLC Software Requirements Analysis - ML

Applied in SDLC – Papers published from 2015 to 2021.

Based on the results shown in Figure 2, Decision

Trees are most popular algorithms among these four

elected techniques. One reason is because Decision

Trees are quick to create and help with eliminating

dead ends. This decreases the probability of errors

made in this phase that can affect subsequent phases

as well. This technique can greatly simplify the SR

gathering process and saves engineers significant

time and budget resources.

In the process of SR, due to their exclusive

characteristics, the appropriate data sets are extremely

dimensional, sparse, and are mostly the outcome of

ambiguous expressions and, consequently, show

problematic challenges for data processing

techniques (Borges et al., 2021). there are many

repositories with duplicate code, which constitutes

data inconsistency (Allamanis, 2018). Hence, more

work needs to be done on creating more diverse and

appropriate datasets for this phase.

Figure 3: SDLC Software Architecture Design - ML

Applied in SDLC – Papers published from 2015 to 2021.

Support Vector Machine (SVM) is one of the most

popular ML techniques used in SDLC. It is a

supervised learning algorithm used for both

classification and regression problems. This

technique is very accurate and robust in detecting

design anomalies such as code smells also known as

Bad Smells, Design Flaws, Anti Patterns and Code

Anomaly (Zhang et al., 2006).

ML demands massive datasets to train on and

these should be unbiased and have great quality

which sometimes requires new data to be generated.

We suggest applying ML algorithms more in

Software architecture design as little work has been

done and needs to be explored more (Borges et al.,

2021).

1117

1116

1112

1106

1104

303

1722

810

1960

421

686

1604

1407

1946

614

500

1000

1500

2000

SDLC

PHASE 1

& ML

SDLC

PHASE 2

& ML

SDLC

PHASE 3

& ML

SDLC

PHASE 4

& ML

SDLC

PHASE 5

& ML

ACM IEEE SPRINGER

665

295

945

104

339

179

200

400

600

800

1000

Random

Forest

Support

Vector

Machine

Naïve Bayes Decision

Tree

ACM IEEE Springer

428

970

275

141

980

1245

295

883

200

400

600

800

1000

1200

1400

Random

Forest

Support

Vector

Machine

Naïve Bayes Decision

Trees

ACM IEEE Springer

Machine Learning in Software Development Life Cycle: A Comprehensive Review

351

Figure 4: SDLC Phase Implementation - ML Applied in

SDLC – Papers published from 2015 to 2021.

Again, Support Vector Machine is most frequent

algorithm used in the third phase of Software

Development Life Cycle known as Software

Implementation. This technique is very popular in

Design and Development of software applications.

Figure 5: SDLC Phase Testing- ML Applied in SDLC –

Papers published from 2015 to 2021.

As shown in Figure 5, both Random Forest and

Support Vector Machine are popular techniques in

Software Testing phase. However, SVM has slightly

more publications. One reason for this is SVM is the

better classifier to eliminate infeasible test cases

saving time and costs in projects which is a huge

achievement as testers spend more time and their

resources on testing mobile and hybrid applications.

ML helps testers to better understand user’s needs and

respond faster to the everchanging expectations by

improving automation testing, reduced UI based

testing, assisting in API testing, and improving

accuracy.

Figure 6: SDLC Maintenance - ML Applied in SDLC –

Papers published from 2015 to 2021.

Data Scientists and Software Engineers have

shown the most interest in applying Support Vector

Machine in last phase of SDLC than other techniques.

However, Decision Trees have high usage as well.

Classification and refactoring approaches play a

significant role when maintaining software systems.

Available datasets are not sufficient to give

conclusive results which provide information

regarding the input data of the system (Jha et al.,

2019) and more work need to be done to create new

datasets to determine the accuracy of the precision

and decreasing the complexity.

6 CONCLUSIONS

Machine Learning is becoming one of the most

important technologies used in Software

Development Life Cycle. ML approaches are being

used for inadequately implied problem domains

where little knowledge exists for humans to develop

effective algorithms. ML has different types:

Supervised Learning, Semi-Supervised Learning,

Unsupervised Learning and Reinforcement Learning.

Our study shows Support Vector Machine (SVM) is

one of the most popular supervised ML algorithms in

current SE research. It is being applied on all the

phases of SDLC as it can be used for both

classification and regression problems. While SVM is

not considered the best performing algorithm in all

cases, it remains among the most highly used ML

methods. Reinforcement Learning is among the least

mentioned ML algorithms in SDLC. Although it has

been used in Software requirements analysis for

understanding the relationships between

requirements at different levels of abstractions a few

times, it is an interesting topic that we can study on

150

441

220

163

101

295

100

150

200

250

300

350

400

450

500

Random

Forest

Support

Vector

Machine

Naïve Bayes Decision

Tree

147

324

119

287

206

592

130

263

845

443

158

499

200

400

600

800

Random

Forest

Support

Vector

Machine

Naïve Bayes Decision

Tree

ACM IEEE Springer

4,3

327

118

292

120

373

110

100

150

200

250

300

350

400

Random

Forest

Support

Vector

Machine

Naïve

Bayes

Decision

Trees

ACM IEEE Springer

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

352

more in terms of simplifying SE. Software Testing is

utilizing ML techniques more than any other SDLC

phase since there are a lot of datasets available to

researchers.

Our future work aims at addressing the challenges

outlined in Software Requirements Analysis,

Architecture Patterns, Software Maintenance and

ultimately creation of datasets for those phases. Also,

future works could look at data mining, predictive

design and modeling for different software

applications including mobile applications.

REFERENCES

Abubakar, H., Obaidat, M. S., Gupta, A., Bhattacharya, P.,

Tanwar, S. (2020) - Interplay of Machine Learning and

Software Engineering for Quality Estimations – IEEE

Allamanis, M. (2018) - The adverse effects of code

duplication in machine learning models of code –

Research Gate.

Alloghani, M., Al-Jumeily, D., Baker, T., Hussain, A.,

Mustafina, J., Ahmed J. Aljaaf (2020) - An Intelligent

Journey to Machine Learning Applications in

Component-Based Software Engineering - Springer.

Software Maintainability Metrics Prediction – IEEE.

Aniche, M., Maziero, E., Durelli, R., Durelli, V. H. S.

(2020) - The Effectiveness of Supervised Machine

Learning Algorithms in Predicting Software

Refactoring – IEEE.

Alsolai, H. (2018) - Predicting Software Maintainability in

Object-Oriented Systems Using Ensemble Techniques –

IEEE.

Banga, M., Bansal, A., Singh, A. (2019) - Implementation

of Machine Learning Techniques in Software

Reliability: A framework – IEEE.

Baskar, N. and Chandrasekar, C. (2018) - An Evolving

Neuro-PSO-based Software Maintainability Prediction

– IEEE.

Bhatore, S., Reddy, Y., R., Sanagavarapu, L. M, Chandra,

S. S. (2021) - Software Patterns to Identify Credit Risk

Patterns – IEEE.

Bhavsar, K., Gopalan, S., Shah, V. (2019) - Machine

Learning: A Software Process Reengineering in

Software Development Organization – Research Gate.

Bird, C., DeLine, R., Gall, H., Kamar, E., Nagappan, N.,

Nushi B., Zimmermann, T. (2017) - Software

Engineering for Machine-Learning: A Case Study –

IEEE.

Borges, O. T., Couto, J. C., Ruiz, D., Priklladnicki, R.

(2021) – Challeneges in using Machine Learning to

Support Software Engineering – Research Gate.

Cetiner, M., Sahingoz, O. K. (2020) - A Comparative

Analysis for Machine Learning based Software Defect

Prediction Systems – IEEE.

Chen, C., Seff, A., Kornhauser, A., and Xiao, J. (2015) -

DeepDriving: Learning affordance for direct

perception in autonomous driving - IEEE.

Dwivedi, A. K., Tirkey, A. , Rath, S. K. (2016) - Applying

software metrics for the mining of design pattern –

IEEE.

Dwivedi, A. K., Tirkey, A., Ray, R. B., Rath, S. K. (2016)

- Software design pattern recognition using machine

learning techniques – IEEE.

DE-Arteaga, M., Herlands, W., Neill, D. B., Dubrawski, A.

(2018) - Machine Learning for the Developing World –

ACM.

Elhabbash, A., Salama, M., Bahsoon, R., Tino, P. (2019) -

Self-awareness in Software Engineering: A Systematic

Literature Review – ACM

Elmidaoui, S., Cheikhi, L., Idri, A., Abran, A. (2020) -

Machine Learning Techniques for Software

Maintainability Prediction: Accuracy Analysis –

Springer.

England, M. (2018) - Machine Learning for Mathematical

Software – Springer.

Esteves, G., Figueiredo, E., Veloso, A., Viggiato, M., Nivio

(2020) - Understanding Machine Learning Software

Defect Predictions – Springer.

Giray, G (2021) - A software engineering perspective on

engineering machine learning systems: State of the art

and challenges - Science Direct.

Gramajo, M., Ballejos, L., Ale, M. (2020) - Seizing

Requirements Engineering Issues through Supervised

Learning Techniques – IEEE.

Gong, Z., Zhong, P., Hu, P. (2019) - Diversity in Machine

Learning – IEEE.

Gupta, S., Chug, A. (2021) - An Optimized Extreme

Learning Machine Algorithm for Improving Software

Maintainability Prediction – IEEE.

Gupta, H., Kumar, L., Neti, L. B. M. (2019) - An Empirical

Framework for Code Smell Prediction using Extreme

Learning Machine – IEEE.

Haleem, M., Farooqui, M. F., Faisal, M. (2021) - Cognitive

impact validation of requirement uncertainty in

software project development – Science Direct.

Herzig, K. and Nagappan, N. (2015) - empirically detecting

false test alarms using association rules – IEEE.

Holzinger, A., Kieseberg, P., Weippl, D., Tjoa, A. (2018) -

Current Advances, Trends and Challenges of Machine

Learning and Knowledge Extraction: From Machine

Learning to Explainable AI – Springer.

Horkoff, J. (2019) - Non-Functional Requirements for

Machine Learning: Challenges and New Directions –

IEEE.

Hutchinson, B., Smart, A., Hanna, A., Denton, E. (2021) -

Towards Accountability for Machine Learning

Datasets: Practices from Software Engineering and

Infrastructure – ACM.

Iqbal, T., Elahidoost, P., Lúcio, L. (2018) - A Bird's Eye

View on Requirements Engineering and Machine

Learning – IEEE.

Jha, S., Kumar, R., Son, L. H., Abdel-Basset, M.,

Priyadarshini, I., Sharma, R., Long, H. V. (2019) - Deep

Learning Approach for Software Maintainability

Metrics Prediction

Karim, M. S., Warnars, H. L. H. S., Gaol, F. L.,

Abdurachman, E., Soewito, B. (2017) - Software

Machine Learning in Software Development Life Cycle: A Comprehensive Review

353

metrics for fault prediction using machine learning

approaches: A literature review with PROMISE

repository dataset – IEEE.

Kaur, A., Jain, S., Goel, S. (2017) - A Support Vector

Machine Based Approach for Code Smell Detection –

IEEE.

Khomh, F., Adams, B., Cheng, J. , Fokaefs, M., Antoniol,

G. (2018) - Software Engineering for Machine-

Learning Applications: The Road Ahead – IEEE.

Kim, M., Zimmermann, T., DeLine, R. and Begel, A.

(2018) - Data scientists in software teams: State of the

art and challenges – IEEE.

Li, J. J., Ulrich, A., Bai, X., Bertolino, A. (2020) - Advances

in test automation for software with special focus on

artificial intelligence and machine learning – Springer.

Lima, R. , Da Cruz, A. M. R., Ribeiro, J. (2020) - Artificial

Intelligence Applied to Software Testing: A Literature

Review – IEEE

Meinke, K., Bennaceur, A. (2018) - Machine Learning for

Software Engineering: Models, Methods, and

Applications – IEEE.

McIntosh, S., Kamei, Y. (2017) - Are fix-inducing changes

a moving target? a longitudinal case study of just-in-

time defect prediction – IEEE.

Mhawish, M. Y., Gupta, M. (2019) - Software Metrics and

tree-based machine learning algorithms for

distinguishing and detecting similar structure design

patterns – Springer.

Nakajima, S. (2018) - Quality Assurance of Machine

Learning Software – IEEE.

Nasrabadi, M. Z., Parsa, S. (2021) – Learning to Predict

Software Testability - IEEE.

Navarro-Almanza, R., Juarez-Ramirez, R., Licea, G. (2017)

- Towards Supporting Software Engineering Using

Deep Learning: A Case of Software Requirements

Classification – IEEE.

Quba, G., Qaisi, H. A., Althunibat, A., AlZu’bi, S. (2021) -

Software Requirements Classification using Machine

Learning algorithm’s – IEEE.

Paiva, T., Damasceno, A., Figueiredo, E., Sant’Anna, C.

(2017) - On the evaluation of code smells and detection

tools – Springer.

Panichella, S., Ruiz, M. (2020) - Requirements-Collector:

Automating Requirements Specification from

Elicitation Sessions and User Feedback – IEEE.

Peng, H., Li, B., Ling, H., Hu, W., Xiong, W. and Maybank,

S. J. (2017) - Salient object detection via structured

matrix decomposition - IEEE.

Roper, M. (2019) - Using Machine Learning to Classify

Test Outcomes – IEEE.

Sagar, P. S., AlOmar, E. A., Mkaouer, M. W., Ouni, A.,

Christian Newman (2021) - Comparing Commit

Messages and Source Code Metrics for the Prediction

Refactoring Activities – Research Gate.

Shafiq, S., Mashkoor, A., Mayr-Dorn, C., Egyed, A. (2021)

- A Literature Review of Using Machine Learning in

Software Development Life Cycle Stages – IEEE.

Sobhy, D., Bahsoon, R., Minku, L., Kazman, R. (2021) -

Evaluation of Software Architectures under

Uncertainty: A Systematic Literature Review – ACM.

Sulaiman, S. (2005) - Viewing Software Artifacts for

Different Software Maintenance Categories Using

Graph Representations – Research Gate.

Talele, P., Phalnikar, R. (2021) - Classification and

Prioritisation of Software Requirements using Machine

Learning – A Systematic Review – IEEE.

Wan, Z., Xia, X., Lo, D., Murphy, G. C. (2019) - How does

Machine Learning Change Software Development

Practices? – IEEE.

Xin, Y., Kong, L., Liu, Z., Chen, Y., Li, Y., Zhu, H., Gao,

H., Hou, H., Wang, C. (2018) - Machine Learning and

Deep Learning Methods for Cybersecurity – IEEE.

Yurdakurbann, V., Erdogan, N. (2018) - Comparison of

machine learning methods for software project effort

estimation – IEEE.

Zhu, H. (2018) - Software Testing as a Problem of Machine

Learning: Towards a Foundation on Computational

Learning Theory – IEEE.

Zhang, L., Tan, J., et al, D. H.. (2017) - From machine

learning to deep learning: progress in machine

intelligence for rational drug discovery – IEEE.

Zhang, X., Gu, C., Lin, J (2006) - Support Vector Machines

for Anomaly Detection – Research Gate.

Zhang, X., Zhou, T., Zhu, C. (2017) - An Empirical Study

of the Impact of Bad Designs on Defect Proneness –

IEEE.

Zhu, Y, Chen, L, Zhou, H, Feng, W., Zhu, Q. (2018) -

Design and Implementation of WeChat Robot Based on

Machine Learning – IEEE.

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

354
