Testing React Single Page Web Application using Automated Testing

Tools

Md Mehedee Hasan

, Mohammad Ashikur Rahman

, Md Salman Chowdhury

Md Habibur Rahman

, Kaal Harir Abdulle

, Farzana Sadia

and Mahady Hasan

Department of Computer Science and Engineering, Independent University, Bangladesh, Dhaka, Bangladesh

Department of Software Engineering, Daffodil International University, Dhaka, Bangladesh

Keywords:

Software Testing, Testing Tools, GUI Testing, Automated Testing Tools, Single Page Web Application

Testing, React Application Testing.

Abstract:

In modern software development practices, single page application development is becoming popular. Among

the available frameworks, React is a popular platform to develop web applications front-end. For most of the

software, almost half of the application code is for the front-end. Therefore testing the front-end or GUI is

also almost equally important. In modern application development, React is by far the most popular front-end

framework/library. In modern development practice, like agile development or CI/CD development, testing

performance and the easiness of implementing testing tools are very crucial factor. In this paper, three different

testing tools, Jest, Enzyme and Cypress speciﬁcally designed for React based single page application, were

analysed. The main objective is to check the execution time performance for the same testing functionality

on different tools, and developer friendliness of these tools. While each tool having their own features and

limitations, for modern development practices like Agile or CI/CD, Enzyme is tested as a better tool which is

both easy to integrate while providing efﬁciency.

1 INTRODUCTION

In modern web development, testing has become a

very important part in software development. Ensur-

ing the quality of the product is also becoming im-

portant. While testing the business logic at the appli-

cation level ensures the reliability of the applications

functionality, it is also important to test the Graphical

User Interface (GUI) to provide users a more seamless

experience. In modern software applications, around

50% of the application code is for GUI implementa-

tion. (Broer Bahaweres et al., 2020). The modern de-

velopment can be divided into two segments, namely,

a) frontend development, b) backend development.

Front-end web development is the development of the

graphical user interface of a website, through the use

of HTML, CSS, and JavaScript, so that users can view

and interact with that website.(b15, 2021). React is

one of the most popular and widely used libraries

on modern websites. This library can be used for

either single page application (SPA) or even mobile

applications (React Native). Testing the applications

based on React can be slightly different during de-

velopment. Generic testing techniques might not be

effective for such library based GUI (Xiao-Fang Qi,

2017)

When testing GUI, we can have two approaches,

a) Manual Testing where one or more person is man-

ually testing the application and b) Automated testing

where the tests are done based on a written test code

automatically. Manual testing has some advantages,

however, it requires a dedicated QA team (Chen et al.,

2020), manual testing is often costly (Broer Bahaw-

eres et al., 2020) (Garousi and Yildirim, 2018), and

manual testing can be error prone due to human in-

teraction (Silistre et al., 2020). In case of automated

testing, it does require programming knowledge, but

it provides a lot of beneﬁts over manual testing. In

industrial level touch based machines automated test-

ing provides several advantages(Klammer and Ram-

ler, 2017a), it is also beneﬁcial for modern develop-

ment practice like Continuous Integration and Con-

tinuous Deployment (CI/CD) (Al

egroth et al., 2018).

While recent studies mostly focuses on particular

tools for testing, there is a little study on how differ-

ent tools performs and how easy to work with them

with Single Page applications, like applications built

on React. To ﬁnd out how different tools can affect

Hasan, M., Rahman, M., Chowdhury, M., Rahman, M., Abdulle, K., Sadia, F. and Hasan, M.

Testing React Single Page Web Application using Automated Testing Tools.

DOI: 10.5220/0011077900003176

In Proceedings of the 17th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2022), pages 469-476

ISBN: 978-989-758-568-5; ISSN: 2184-4895

469

the single page applications we developed three main

research objects, a) Easiness of integration of differ-

ent tools, b) How different tool performs for similar

tests and C) Developer friendliness to write test codes

using different tools. In this paper, we will try to study

three different testing tools named, Jest, Enzyme and

Cypress and explore their various attributes like per-

formance, user friendliness, memory cost on React

based websites. Along with our study, we will fur-

ther ﬁnd the beneﬁts and drawbacks of these tools to

propose a suitable tool for different levels of software

development which in return, can provide better soft-

ware quality with interactive GUI.

2 LITERATURE REVIEW

Modern applications are separated into frontend and

backend development. Backend development is re-

sponsible for the functionality of the business cases

and processing data. One of the beneﬁts of sep-

arating two parts is, the frontend or the backend

can be changed without changing or with very little

changes on the other end. This often provides the

developers to change the backend language without

changing the User experience in the frontend. The

frontend is responsible for handling the user inter-

face through Graphical User Interface (GUI) (b15,

2021). The frontend is often developed as a single

page application (SPA) to provide users a more im-

mersive and interactive experience. Unlike the tra-

ditional web application development where each in-

teraction is achieved through different pages using

HTML and CSS, such interactive pages often take

beneﬁts of javascript, taking the beneﬁts of provid-

ing users the similar experience without refreshing the

pages. The concept of (Asynchronous JavaScript and

XML) AJAX is hugely implemented here. There are

various libraries and frameworks used to develop in-

teractive web interfaces. In recent years, React is by

far the most popular front-end framework/library (and

continues to grow faster) (2021, ). One of the fea-

tures that makes React stand out from traditional web

development is its Virtual DOM functionality. The

virtual dom provides beneﬁts where the codebase is

large. In regular DOM (Data Object Model), these are

in simple words the html and stylesheets, however,

if the project is too large, there can be thousands of

lines of codes which makes it inconvenient and hard

to manage. In React, these large codebases are di-

vided into small components, which can be returned

on user request or based on the data from the server

side.

When testing the frontend or GUI both manual

testing and automated testing is used. Manual testing

provides some beneﬁts but it is often costly and time

consuming (Broer Bahaweres et al., 2020). Previ-

ous research by Filippo Cacciotto, Tommaso Fulcini,

Riccardo Coppola, and Luca Ardito ﬁnds that man-

ual testing can be boring, costly and repetitive tasks

which are handled manually (Klammer and Ramler,

2017b). The author proposed gamiﬁcation in manual

testing which might convince the developers in man-

ual testing. Another drawback of manual testing is

that the test team needs to manually update the test

scripts as the project becomes large (Aho et al., 2021).

Automated testing is becoming more popular day by

day due to the nature of modern software develop-

ment practices. One of the most popular development

practices, Agile development often follows Testing

focused processes such as Test Driven Development

(TDD), Behavior Driven Development (BDD). These

practices are considered to play a very important role

in the success of the project (Broer Bahaweres et al.,

2020). Automated testing is also essential in Continu-

ous Integration and Continuous Deployment (CI/CD)

to make it work efﬁciently.(Al

egroth et al., 2018).

Automated testing tools like Selenium usually re-

quires less maintenance but it requires some program-

ming knowledge (Dobslaw et al., 2019). Muneyoshi

Iyama even proposed a method to generate the auto-

mated test scripts, automatically based on static anal-

ysis and dynamic analysis on the application (Iyama

et al., 2018). Automated testing tools also has the ca-

pability of taking beneﬁt of modern technologies like

Computer vision and Machine learning (Macchi et al.,

2021) (White et al., 2019)

Most of the research focused on only improv-

ing the automated testing methodology or techniques

means how efﬁciently the test cases can be executed

with the different methodologies such as using ma-

chine learning or AI rather than focused on the test-

ing tools and their efﬁciency. However, automated

testing tools nowadays outweigh manual tools due to

their many bright aspects. There exists a quite large

number of GUI-testing tools all over the software in-

dustry and have been tremendously used as well. The

goal is the same as with any testing technique - to

identify a manageability small set of test cases that is

sufﬁciently rigorous and diverse to expose any faults.

However, concentrating on chieﬂy testing tools, espe-

cially automated testing tools in terms of their perfor-

mance, for example, execution time, error detection

rate, user friendly and so on are the key parameters or

attributes in case of selecting testing tools. Many test

engineers have challenges in the proper and success-

ful implementation of test automation, especially in

the case of VGT (Visual GUI Testing). Though some

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

470

existing studies compare VGT tools, however, test-

ing especially React components automatically that

are based on java scripts are not much available in

the industry for the testers. This paper aims to make a

better understanding of the capabilities of these three

tools and to assist the testers to evaluate the pros and

cons associated with them.

VGT [Visual GUI Testing] tools require a speciﬁc

expected output image to assert if what is being ren-

dered is correct according to an expected result. The

main implication of the ﬁndings provided is that VGT

can be utilized in industrial practice for a long time

(Al

egroth and Feldt, 2017). However, many practic-

ing test engineers have challenges in proper and suc-

cessful implementation of test automation, especially

in the case of VGT. when VGT and GUI test automa-

tion are not planned, designed, or implemented prop-

erly by test engineers, the efforts have led to disap-

pointments and various negative outcomes (Garousi

et al., 2017). Additionally, a new pattern-based GUI

testing (PBGT) technique is introduced that formal-

izes the concept of UI Test Patterns, which are gen-

eral test strategies for evaluating UI patterns across

the many implementations and the ﬁndings show that

PBGT is more effective than a manual model-based

test case generation approach (Moreira et al., 2017).

The widespread use of iterative and incremental

processes and continuous integration practices in soft-

ware development has shortened the development cy-

cles, drastically limiting the time for testing and qual-

ity assurance of each release. Instead of months or

weeks, the longest period for testing a release is over

a weekend or a night. The results of an automated

smoke test set are expected almost instantly or in a

few minutes. In practice, a high level of test automa-

tion is a requirement for a successful continuous inte-

gration process (Aho and Vos, 2018). However, eval-

uate the effectiveness of the characteristics on test-

ing cost and fault detection is effectiveness and the

test designer should take a diversity of states in which

an event executes and the event coverage of the suite

to get proper fault detection with effectiveness (Xie

and Memon, 2006). Moreover, On-device test gener-

ation gives faster result for simple application which

needs less computation and On-device test genera-

tion is 3.2 times faster than computer device testing

(Borges et al., 2020).

React framework, unlike regular website, is a sin-

gle page application. In regular websites, there are

usually multiple pages containing different contents.

React on the other hand, is a single page application,

meaning all the contents will render on single page.

React achieves this interactivity by rendering only the

part requested by the user. Such parts are deﬁned as

Component in React. Single page applications are

mostly Ajax based application which is heavily de-

pendent on JavaScript language. It also uses special

templating engine called JSX to render the html con-

tents. Another special feature of single page applica-

tion is Virtual DOM, where the HTML elements are

dynamically updated or rendered. These uniqueness

makes React applications different from regular web-

sites, which also requires the testing tool to be precise

in testing these components or virtually rendered dom

elements or attributes.

In SPAs, all the required components are down-

loaded in the ﬁrst page load. The twitter’s timeline

and the gmail’s inbox are examples of SPA’s. How-

ever, some contents and components are loaded dy-

namically as the user interacts with it. For example, in

the same web page a user may change tabs open a dia-

log to post new content and execute pagination opera-

tions without changing the URL path in the browser’s

address bar. In a case where a web page generates UI

components dynamically, for example a list of items

appears as a consequence of a page change, or new

items are loaded as the user scrolls, problems in the

user experience (UX) may be perceived. These tools

would not be able to identify it as something to be

carefully analyzed by the developers because the sce-

nario that causes the issue does not happen in the

ﬁrst page load. It depends on how the user interacts

with the system and when the content is dynamically

loaded (Quental et al., 2019). With the growing vari-

ety of screen sizes and resolutions of mobile devices,

the need to validate GUI layout correctness in differ-

ent screen sizes as well (Hasselknippe and Li, 2017).

React applications needs to be compiled before

using, which can be time consuming based on the

complexity and size of the application. However, in

modern web development, time is one critical met-

ric, on which the success of project highly depends.

Therefore, the objective is to reduce the overall time

taken to implement a feature and publish it with

proper quality. And to ensure the quality, testing must

be done before it is deployed.

Software development practices like Agile devel-

opment or deployment scenarios like CI/CD are a

continuous process where the features and functional-

ities are implemented over time in phases. In each it-

eration, the application also needs to pass through the

testing phase as well. Study shows that, in automated

testing, each attempt at a test case execution can take

a long time, eliminating the possibility of rapidly at-

tempting large numbers of alternatives (Walkinshaw,

2020). Our goal in this paper is to ﬁnd a suitable tool

which can be easily used to test the application GUI

properly while it takes less time which improves over-

Testing React Single Page Web Application using Automated Testing Tools

471

all application delivery time.

While the papers related to our ﬁeld of study

mostly focus on choosing manual or automated test-

ing on GUI testing, there is little exploration on how

different testing tools interact with such SPAs. Our

goal in this project is to explore some of the modern

automated testing tools for testing React based single

page applications and observe different metrics which

can provide insightful information.

2.1 Cypress

Cypress is a javascript library used for end-to-end

testing. It can be used to test anything that runs on

a browser. It is often compared with Selenium, but it

has a totally different architecture. It facilitates dif-

ferent testings like End-to-end tests, Integration tests,

Unit tests etc. Cypress is an open source software. It

has a dashboard service which can record our test runs

and produce logs. Setting up cypress is very easy. No

servers, drivers or dependencies to install or conﬁg-

ure. As an application is developed, the tests can be

seen running in real time.

2.2 Enzyme

Enzyme is a JavaScript Testing utility for React that

makes it easier to test your React Components’ out-

put. In this framework testers can manipulate and

traverse the component. Learning curve is slightly

Tough.

2.3 Jest

Jest is another popular testing tool for javascript. Jest

is developed and maintained by Facebook Inc and

widely popular among javascript developers. Jest can

be used to test different types of projects both in back-

end and frontend. It focuses on simplicity to pro-

vide developers with faster testing. Jest is well doc-

umented and often recommended for React projects,

however, it is not suitable for a beginner level devel-

oper.

3 METHODOLOGY

A lot of testing tools exist that are based on different

architectural designs and implementations. As a con-

sequence, it is not possible for researchers, and practi-

tioners alike, to make an informed decision on which

tool to use and on the strengths and weaknesses of the

tools. Because of the nature of modern software de-

velopment techniques, automated testing is becoming

increasingly prevalent. In our research, we addressed

this issue by comparing three automated testing tools

that work for React projects. React has become a very

popular and extensively used tool among front-end

developers. The tools are Jest, Cypress and Enzyme.

They are open source testing tools which are archi-

tecturally very different from each other. This pa-

per compares the execution time, error detection rate,

CPU usage and the ease of effort to set up or develop

the tools.

To select our test projects, we performed a search

on Github to choose an interactive React application

on which we would implement the test scripts. We

selected a popular React based app named TakeNote

which has over 5100 stars and forked over 740 times.

This is a simple note taking application which has the

ability to create, edit, delete and update notes and can

create categories. TakeNote, an interactive app, will

be ideal for putting the three tools to the test. The

data from the tools will be stored and compared for a

full review of the tools. The testers are divided into

three groups and each group assigned to each of the

three tools. A list of test cases are prepared and the

groups implement all the test cases with their respec-

tive tools. After running the test cases, the data is

collected and compared. The running time, time to

set up, ease of integration, error detection rates would

give us enough data to analyse and provide insights

for software business ranging from startups to enter-

prises.

Figure 1: GUI of TakeNote Application.

Writing test cases can be error-prone and a tester’s

ability or skill level to write a test script may produce

a bias for different tools. And also, the very different

way cypress behaves from the other two testing tools

may provide a challenge in reaching a solid conclu-

sion. In order to minimize these issues, the test scripts

are shared between the testers to prevent the scripts

from being too different in terms of code complexity.

Another limitation of our experiment that the number

of tests are relatively small and the project is compar-

atively simpler. The real world application may have

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

472

other dependencies which might force the developer

team to go with speciﬁc tool regardless the beneﬁt or

limitation of any tool.

4 RESULT ANALYSIS

We targeted to respond to the following main research

questions (RQs) in our study: How do these three

tools compare when they are used to test React com-

ponents from a single web page running the same test

scripts? To evaluate the RQs methodically and for

various features, we separated them into three sub-

research questions:

• RQ1: How do the three tools compare in terms of

integration?

• RQ2: How do the three tools compare in terms of

“execution time” for the same test case?

• RQ3: How do the three tools compare in terms of

user friendliness?

Before the tests were actually ran, we needed to inte-

grate these tools with the project. We forked the main

application from GitHub and created three different

branch for each tools. And then we implemented our

tools with conﬁguration and packages. During our

implementations, we came across some of the differ-

ences among these tools. In modern React applica-

tions, the Jest is provided as default testing tools with

the default project skeleton. Both Enzyme and Cy-

press needs to be added separately. Jest while itself

can not interact with the GUI directly, it depends on

JEST-DOM and testing-packages to interact with the

GUI elements. Enzyme operates similarly. However

the main beneﬁt of Jest is that it can be used to test the

internal functionalities of React Components. Docu-

mentation from Jest shows that it can be used to test

in business logic & functionalities as well. Enzyme

performs similarly, however, it has the beneﬁt to test

a component without the need to render other compo-

nents within that component. Cypress, on the other

hand focuses on GUI. It has a native GUI where the

tests can be simulated and monitored. However, if

a developer is working on Linux system, cypress re-

quires few operating system dependencies to be re-

solved before it can be operated. Once we have con-

ﬁgured each tool with the project, we found the Jest to

be easiest solution to start since it’s already integrated,

being Cypress the hardest one to conﬁgure since it has

operating system library dependencies.

To observe how easy or hard to use each of these

tool we explored different functionalities and facili-

ties provided by each tools. Different GUI actions

like Clicking, Typing, double click or navigating is

Table 1: Test Cases.

S/L Test Scenario

1 User can click on the + button on Category

menu and new category input ﬁeld should

appear, upon typing the name, when clicked

outside, a new category should be created

2 Category list should be hidden when user

clicks Category menu, if there are categories

3 When user clicks Sync button, a current time

should be displayed as synced time.

5 When user visits the website, the application

should be properly rendered

6 User can change to dark mode by clicking the

‘Theme‘ button at bottom right

7 User can start a new note by pressing

‘CTRL+ALT+N‘

8 When a user clicks on a New note, it should

take the user with a empty note

9 Settings modal should open when a user

clicks on the settings icon

10 When user clicks the Scratchpad menu, it

should take to the Scratchpad view

11 When user clicks on New note menu, it

should open a new note

12 On the menu list a search box should be ren-

dered which can be used to search notes

13 When the main view is loaded, Add new cat-

egory menu should be rendered and ready for

action

14 When user clicks on Preference tab in Set-

tings modal, it should render the preference

options

15 When user clicks on Data management tab

in Settings modal, it should render the data

management options

16 When user is on the data management tab,

user should see an Export Button to export

the notes

17 When user is on the data management tab,

user should see an Import Button to import

notes from other sources

18 When user is on the data management tab,

user should see an Download all button to

download

19 When user is on the About tab, user should

see an View source Button to see the details

about the app

20 User should see logout button when they are

in Settings modal

not directly possible with Jest and Enzyme, rather re-

lies on ﬁreEvent, render or screen functionalities pro-

vided by testing-library/React package. These tools

provides jest to trigger different events on GUI. En-

Testing React Single Page Web Application using Automated Testing Tools

473

zyme, in our observation performs similarly, since it

depends on Jest by default, however this can be con-

ﬁgured with other tool as well. Cypress on their other

hand, provides a handful of features to interact with

the different GUI elements. We found cypress very

easy for writing the test codes, while both Jest and

Enzyme has some learning curve.

To study the behavior of our selected tools, a num-

ber of tests were generated to test different elements.

Then these tests were written using three tools, The

dependencies, limitations and beneﬁts of integrating

and writing the test codes were closely logged during

developing the test codes. Table 1 contains the test

cases deﬁned for our study

After test codes were written and prepared using

three different tools, the execution time is observed

on two different computers with different conﬁgura-

tion for 20 times. The ﬁrst for each tool is recorded

separately as the ﬁrst run of each tools take longer

time. The ﬁrst run of the test codes usually indicates

a fresh set of test codes. If there are no changes in

the test codes, the later test runs take less time to run

the codes. If there is any change that is implemented

later the test run time increases as the tests run run

from scratches. We have ran 20 more tests with each

tool and ﬁnd the average time needed for each tool to

complete the test. To avoid any other impacts we ran

all the test in single test ﬁle.

For hardware we chose one desktop conﬁguration

running Linux operating system and one laptop con-

ﬁguration running MacOS system. It would help us

to identify if the operating system can cause differ-

ent performance result. Also, during the development

phase, software developers either uses desktop or lap-

top, so it was also our objective if different hardware

conﬁguration can bias the testing performance. Ta-

ble 2 contains the detail of our two test machines.

Table 2: Hardware Conﬁguration.

Item Conﬁguration 1 Conﬁguration 2

CPU 4 Core 8 Thread 2 Core 4 Thread

Frequency 4Ghz 2.7Ghz

RAM 16 GB 16 GB

OS Linux Mac OS

First we ran the test on our desktop conﬁguration.

Tests were run for 21 times for each tool. From the

records of Table 3 we can see on the ﬁrst run Jest

took the least time of 3.85 seconds and followed by

Enzyme and Cypress with score of 5.62 seconds and

6.36 seconds. Then we ran the tests for another 20

times to ﬁnd the average time for each tool.

In ﬁrst conﬁguration the Enzyme took least time to

complete each 9 tests with an average of 3.73 seconds

Table 3: Test Scores on Conﬁguration 1.

Test Jest Enzyme Cypress

Initial 7.723 10.896 9.61

Average 5.25 3.73 8.12

followed by Jest with 5.25 seconds. Cypress achieved

3rd position with comparatively longer time of 8.12

seconds.

Figure 2: Test Run Time on Conﬁguration 1.

Figure 2 shows that throughout the tests, the per-

formance of Jest remains almost consistent including

the initial test run. Enzyme behaves similarly, how-

ever the initial run time for Enzyme is almost 3 sec-

onds longer than Jest. Cypress on the other hand is not

as consistent as other two tools and provides different

time in each tests.

Then we ran the same tests on our 2nd conﬁgura-

tion and observed the performance of each tool. Since

this conﬁguration is comparatively weak, tools took

comparatively longer time than 1st conﬁguration. In

such conﬁguration, for the ﬁrst run, Enzyme scored

the lowest with 19.55 seconds, followed by Cypress

and Jest with 18.81 and 16.016 seconds respectively.

In consecutive tests, Enzyme scored ﬁrst with average

of 7.24 seconds, followed by Jest with 10.21 seconds

and Cypress scored last with 14.70 seconds.

Table 4: Test Scores on Conﬁguration 2.

Test Jest Enzyme Cypress

Initial 16.016 19.55 18.81

Average of 20 10.21 7.24 14.70

In our conﬁguration 2, Enzyme again scored the

lowest score with 7.24 seconds, Jest ﬁnished the tests

with an average of 10.21 seconds and Cypress scored

last with 14.70 seconds.

Figure 3 indicates that both Jest and Enzyme per-

forms similarly across the whole test runs. The output

from 1st conﬁguration and conﬁguration 2 are iden-

tical, In 2nd conﬁguration the time for each time is

increased proportionally due to lower CPU conﬁgu-

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

474

Figure 3: Test Run Time on Conﬁguration 2.

ration. However comparing the Figure 2 & Figure 3

we can see the performance of each tool remains sim-

ilar.

4.1 Observations

While implementing and analyzing each tool for test-

ing, we observed and studied different scenarios for

each tools. Functionalities like, tool scope, inte-

gration with project, developer friendliness etc were

monitored.

• Enzyme is faster than other two tools in executing

tests. Which is very helpful for performing testing

with lots of tests, where testing takes less time al-

lowing developers to deploy the application faster.

• Cypress is very easy to write and test. It also has

native GUI to simulate the test activities. It is very

easy for developers to begin with GUI testing.

However, integrating Cypress is little bit complex,

it also has OS library dependency in certain OS

which increases the project setup complexity.

• Jest while is not as fast as Enzyme, in React ap-

plications, it comes built in, therefore there is no

need for extra setup. Another big beneﬁt of Jest is

that it can be used for both back-end and front-end

testing, making it very convenient for Full Stack

developers.

From the analysis we found from our experiment, we

generated a score for each tool, based on likert chart,

where 1 is the lowest score and 5 being the highest.

For Navtive GUI option we either gave 0 or 1 based

on its availability.

From the Table 5 we can see Jest scores high-

est with 17 points, while Enzyme is very close with

16 points but Cypress is lagging behind with only 12

points.

Table 5: Findings based on analysis.

Research Topic Jest Enzyme Cypress

Time 4 5 2

Integration 5 3 2

Ease of Use 3 3 5

Consistency 5 5 2

Native GUI 0 0 1

Total Score 17 16 12

5 CONCLUSIONS

As modern development is becoming advanced and

more complex, more focus should be given to test-

ing. For Front-End, as single page application devel-

opment is getting popular day be day, Modern devel-

opment practices such CI/CI is highly dependent on

automatic processes, therefore an automated testing

tool can contribute in reducing development and de-

ployment time. We evaluated three different but pop-

ular testing tools and provided an empirical review.

This study was not empirically evaluated due to

some unavoidable circumstances, such as covid situ-

ation was major. Besides, research questions (RQs)

and analysis are solely based on literature reviews as

well as work experience. However, analysis after do-

ing survey or getting gap amongst the tools could have

enriched the result more perfectly wherein some sug-

gestions or guideline could be recommended for the

testers to do automated testing more effectively and

efﬁciently. This study compared the tools focusing

on primarily execution time to perform the test cases.

However, adding other factors to our study like re-

source usage could also improve our research with

cost optimization. In future we plan to do a survey

among different companies about their GUI testing

tool usage for React based applications to ﬁnd more

industry relevant beneﬁts and limitations and explore

other parameters which might have contribution to

testing performance.

REFERENCES

(2021). Front-end web development. Page Version ID:

1053051857.

2021. Front-end frameworks popularity (React, Vue, Angu-

lar and Svelte).

Aho, P., Buijs, G., Akin, A., Senturk, S., Ricos, F. P.,

de Gouw, S., and Vos, T. (2021). Applying Script-

less Test Automation on Web Applications from the

Financial Sector. In JISBD2021. SISTEDES.

Aho, P. and Vos, T. (2018). Challenges in automated testing

through graphical user interface. In 2018 IEEE Inter-

Testing React Single Page Web Application using Automated Testing Tools

475

national Conference on Software Testing, Veriﬁcation

and Validation Workshops (ICSTW), pages 118–121.

egroth, E. and Feldt, R. (2017). On the long-term use of

visual gui testing in industrial practice: a case study.

Empirical Software Engineering, 22(6):2937–2971.

egroth, E., Karlsson, A., and Radway, A. (2018). Contin-

uous integration and visual gui testing: Beneﬁts and

drawbacks in industrial practice. In 2018 IEEE 11th

International Conference on Software Testing, Veriﬁ-

cation and Validation (ICST), pages 172–181.

Borges, N. P., Rau, J., and Zeller, A. (2020). Speeding up

gui testing by on-device test generation. In 2020 35th

IEEE/ACM International Conference on Automated

Software Engineering (ASE), pages 1340–1343.

Broer Bahaweres, R., Oktaviani, E., Kesuma Wardhani,

L., Hermadi, I., Suroso, A., Permana Solihin, I., and

Arkeman, Y. (2020). Behavior-driven development

(bdd) cucumber katalon for automation gui testing

case cura and swag labs. In 2020 International Con-

ference on Informatics, Multimedia, Cyber and Infor-

mation System (ICIMCIS), pages 87–92.

Chen, Y., Pandey, M., Song, J. Y., Lasecki, W. S., and Oney,

S. (2020). Improving crowd-supported gui testing

with structural guidance. In Proceedings of the 2020

CHI Conference on Human Factors in Computing Sys-

tems, CHI ’20, page 1–13, New York, NY, USA. As-

sociation for Computing Machinery.

Dobslaw, F., Feldt, R., Michaelsson, D., Haar, P.,

de Oliveira Neto, F., and Torkar, R. (2019). Estimating

return on investment for gui test automation frame-

works. pages 271–282.

Garousi, V., Afzal, W., C¸ a

glar, A., Is¸ık, u. B., Baydan, B.,

C¸ aylak, S., Boyraz, A. Z., Yolac¸an, B., and Herk-

ilo

glu, K. (2017). Comparing automated visual gui

testing tools: An industrial case study. In Proceed-

ings of the 8th ACM SIGSOFT International Work-

shop on Automated Software Testing, A-TEST 2017,

page 21–28, New York, NY, USA. Association for

Computing Machinery.

Garousi, V. and Yildirim, E. (2018). Introducing automated

gui testing and observing its beneﬁts: An industrial

case study in the context of law-practice management

software. In 2018 IEEE International Conference on

Software Testing, Veriﬁcation and Validation Work-

shops (ICSTW), pages 138–145.

Hasselknippe, K. F. and Li, J. (2017). A novel tool for

automatic gui layout testing. In 2017 24th Asia-

Paciﬁc Software Engineering Conference (APSEC),

pages 695–700.

Iyama, M., Kirinuki, H., Tanno, H., and Kurabayashi, T.

(2018). Automatically generating test scripts for gui

testing. In 2018 IEEE International Conference on

Software Testing, Veriﬁcation and Validation Work-

shops (ICSTW), pages 146–150.

Klammer, C. and Ramler, R. (2017a). A journey from man-

ual testing to automated test generation in an industry

project. In 2017 IEEE International Conference on

Software Quality, Reliability and Security Companion

(QRS-C), pages 591–592.

Klammer, C. and Ramler, R. (2017b). A journey from man-

ual testing to automated test generation in an industry

project. In 2017 IEEE International Conference on

Software Quality, Reliability and Security Companion

(QRS-C), pages 591–592.

Macchi, F., Rosin, P., Mervi, J. M., and Turchet, L. (2021).

Image-based approaches for automating gui testing of

interactive web-based applications. In 2021 28th Con-

ference of Open Innovations Association (FRUCT),

pages 278–285.

Moreira, R., Paiva, A., Nabuco, M., and Memon, A. (2017).

Pattern-based GUI testing: Bridging the gap between

design and quality assurance. Software Testing, Veri-

ﬁcation and Reliability, 27.

Quental, N. C., de Albuquerque Siebra, C., Quintino, J. P.,

Florentin, F., da Silva, F. Q. B., and de Medeiros San-

tos, A. L. (2019). Automating gui response time

measurements in mobile and web applications. In

Proceedings of the 14th International Workshop on

Automation of Software Test, AST ’19, page 35–41.

IEEE Press.

Silistre, A., Kilincceker, O., Belli, F., Challenger, M., and

Kardas, G. (2020). Models in graphical user interface

testing: Study design. In 2020 Turkish National Soft-

ware Engineering Symposium (UYMS), pages 1–6.

Walkinshaw, N. (2020). Improving automated gui testing by

learning to avoid infeasible tests. In 2020 IEEE Inter-

national Conference On Artiﬁcial Intelligence Testing

(AITest), pages 107–114.

White, T. D., Fraser, G., and Brown, G. J. (2019). Im-

proving random gui testing with image-based wid-

get detection. In Proceedings of the 28th ACM SIG-

SOFT International Symposium on Software Testing

and Analysis, ISSTA 2019, page 307–317, New York,

NY, USA. Association for Computing Machinery.

Xiao-Fang Qi, Zi-Yuan Wang, J.-Q. M. P. W. (2017). Auto-

mated testing of web applications using combinatorial

strategies. Journal of Computer Science and Technol-

ogy, 32(1):199.

Xie, Q. and Memon, A. (2006). Studying the characteristics

of a good gui test suite. pages 159 – 168.

ENASE 2022 - 17th International Conference on Evaluation of Novel Approaches to Software Engineering

476
