Cardiovascular Disease Risk Prediction with Supervised Machine

Learning Techniques

Elias Dritsas, Sotiris Alexiou and Konstantinos Moustakas

Department of Electrical and Computer Engineering, University of Patras, 26504 Rion, Greece

Keywords:

CVDs, Machine Learning, Risk Prediction.

Abstract:

Cardiovascular diseases (CVDs) are the leading cause of death worldwide and a major public health concern,

with heart diseases being the most prevalent ones, thus the early prediction is being considered as one of the

most effective measures for CVDs control. The risk evaluation for CVD occurrence on participants (men

and women) especially aged older than 50 years with the aid of Machine Learning (ML) models is the main

purpose of this research paper. The performance of supervised ML models is compared in terms of accuracy,

sensitivity (or recall) in identifying those participants that actually suffer from a CVD and Area Under Curve

(AUC) score. The experimental analysis demonstrated that the Logistic Regression classiﬁer is the most

appropriate against Naive Bayes, Support Vector Machine (SVM) and Random Forest with 72.1% accuracy,

recall and 78.4% AUC.

1 INTRODUCTION

The term ”cardiovascular disease” contains a wide

range of disorders, including all pathological changes

involving the heart and/or blood vessels. These dis-

eases include hypertension, coronary heart disease,

heart failure, angina, myocardial infarction and stroke

(Kumar and Ramana, 2021). Cardiovascular diseases

have been the leading cause of death in developing

countries for the past 15 years, and by 2030 deaths

will exceed 20 million per year. A taxonomy of CVDs

is presented in Table 1.

Heart diseases and stroke constitute one of the

biggest causes of morbidity and mortality among

the population worldwide (Roth et al., 2017), with

the most important behavioral risk factors being un-

healthy diet, sedentary lifestyle, smoking and exces-

sive use of alcohol. The effects of behavioral risk

factors may show up as raised blood pressure, raised

blood glucose, raised blood lipids, and overweight

and obesity. In detail, the main risk factors for the oc-

currence of cardiovascular diseases include (Wilkins

et al., 2017), (Abdalrada et al., 2022):

• Obesity/High BMI: obesity alone is a high-risk

factor for CVDs

• Physical activity: sedentary lifestyle increases the

risk of CVDs

• Alcohol consumption: excessive alcohol use can

Table 1: Taxonomy of CVDs.

Heart Disease Description

Coronary disease of the blood vessels supplying the

heart muscle

Cerebrovascular disease of the blood vessels supplying the

brain

Peripheral arterial disease of blood vessels supplying the arms

and legs

Rheumatic damage to the heart muscle and heart valves

from rheumatic fever

caused by streptococcal bacteria

Congenital malformations of heart structure existing at

birth

Deep vein thrombosis blood clots in the leg veins, which can dis-

lodge and move to the heart and lungs

Pulmonary embolism

Heart attacks, strokes acute events mainly caused by a blockage

that prevents blood from ﬂowing to the heart

or brain

raise blood pressure levels and increase levels of

triglycerides, thus increasing the risk for cardio-

vascular diseases

• Smoking and secondhand smoke: nicotine raises

blood pressure

• Hyperlipidemia: also known as High cholesterol

or hypercholesterolemia

• Dyslipidemia: abnormal level of fat or cholesterol

in human’s blood vessels

• Family history, Psychosocial stress, the coexis-

tence of other chronic conditions: Type 2 dia-

betes, Arterial hypertension

The ”2013 ACC/AHA Guideline on the Assessment

Dritsas, E., Alexiou, S. and Moustakas, K.

Cardiovascular Disease Risk Prediction with Supervised Machine Learning Techniques.

DOI: 10.5220/0011088300003188

In Proceedings of the 8th International Conference on Information and Communication Technologies for Ageing Well and e-Health (ICT4AWE 2022), pages 315-321

ISBN: 978-989-758-566-1; ISSN: 2184-4984

315

of Cardiovascular Risk” (Yancy et al., 2013) provides

detailed recommendations for estimating cardiovas-

cular disease risk in the clinical practice, considering

several factors including age, gender, race, cholesterol

and blood pressure levels, diabetes and smoking sta-

tus, and the use of blood pressure-lowering medica-

tions. In Europe, the 10-year risk factor of fatal CVD

is estimated based on different charts established by

the European Society of Cardiology for high-risk and

low-risk populations across Europe, which may be

further adapted to national or regional speciﬁc charts

based on published mortality data.

In the literature, the CVDs risk prediction is ad-

dressed with either appropriate risk tools or the aid of

machine learning. In (Gale et al., 2014), the Fram-

ingham cardiovascular disease risk score and inci-

dent frailty studied on English cohort data for age-

ing participants. Moreover, the systematic coronary

risk evaluation (SCORE) has been suggested to pre-

dict the 10-year risk of cardiovascular death in Eu-

rope or the QRISK to predict the composite outcome

of coronary heart disease and ischaemic stroke. Oth-

ers employ machine learning techniques, also aiming

at predicting potential risk of CVDs (Mohan et al.,

2019), (Yang et al., 2020).

ML is a branch of artiﬁcial intelligence (AI) and a

powerful tool in the medical ﬁeld, as it can help pre-

dict various diseases. In (Dinesh et al., 2018), var-

ious data-driven approaches are presented to predict

diabetes and cardiovascular disease with ML models.

Here, we will solely focus on its application to cardio-

vascular medicine (Haq et al., 2018). Our purpose is

to identify predictive data patterns and high-risk CVD

groups among the elderly. Moreover, we aim to create

personalized risk models that will be part of the pre-

dictive AI tools integrated into the SmartWork (Koc-

sis et al., 2019) and GATEKEEPER systems. The

presented method for the risk prediction of CVDs oc-

currence was developed and validated independently

with a publicly available dataset and, in parallel, as

part of the projects with pilot data. The incorporation

of the ML models into the Long-term Risk Prediction

tools of the SmartWork system aims to design a smart

age-friendly healthy living and working environment

for ofﬁce workers. The GATEKEEPER system pur-

sues to sustain, as healthy as possible, the life of older

people living at home, preventing the occurrence of

CVD, type 2 diabetes mellitus (T2DM)(Fazakis et al.,

2021), high cholesterol, hypertension (Dritsas et al.,

2021), chronic obstructive pulmonary disease-COPD

(Hussain et al., 2021) (chronic conditions related to

Metabolic Syndrome-MetS).

Given that MetS combines risk factors that pro-

mote the development of cardiovascular disease

(CVD) and type 2 diabetes (T2DM)(Hoyas and Leon-

Sanz, 2019), as a ﬁrst approach, our paper aims to

present a methodology for correctly identifying those

at risk of diagnosed with a CVD in long-term. For

this purpose, the classiﬁcation performance of various

ML models is estimated on each test instance from a

CVD dataset. The ML models that achieve the high-

est recall (namely, high sensitivity) and Area Under

Curve (AUC) show that the CVD class can be pre-

dicted correctly. The main contribution of this work

is a comparative evaluation of different ML models

on a balanced dataset and the proposal of a Logistic

Regression model for the long-term CVD risk predic-

tion. In the upcoming sections, the main steps of the

employed process are demonstrated.

The rest of this paper is organized as follows. Sec-

tion 2 presents the main parts of the methods for the

long-term risk prediction of CVD. Section 3 makes

an analysis of the dataset features and Section 4 de-

scribes the pre-processing steps for the design of the

training and testing dataset and feature ranking. Sec-

tion 5 presents the experimental set up and the clas-

siﬁcation performance of ML techniques. Ultimately,

Section 6 concludes the paper and notes future direc-

tions of the current outcomes.

2 MACHINE LEARNING

METHODS

Data science and especially machine learning has

been widely used in the ﬁeld of medicine for the risk

analysis of several chronic conditions. The most com-

mon application of these models aims to determine

the most suitable factors for the long-term risk pre-

diction to avoid serious health complications (due to

certain symptoms) and support health care manage-

ment.

In this study, the forecasting performance of four

different machine learning models is presented. In

particular, the Naive Bayes, SVM, Logistic Regres-

sion and Random Forest are utilized to estimate the

long-term risk of an older person being diagnosed

with cardiovascular disease.

The dataset is separated into a training set of size

M, a test set of size N. A categorical variable c which

captures the class label of an instance i in the dataset.

In the context of this work, the investigating problem

has two possible classes, e.g., c = ”CVD” or ”Yes”

or c= ”Non-CVD” or ”No”. The features vector of

an instance i is captured by f



, f

, . . . , f



(with M  n).

Our aim is to achieve high recall or sensitivity

and Area Under Curve (AUC) through supervised ma-

ICT4AWE 2022 - 8th International Conference on Information and Communication Technologies for Ageing Well and e-Health

316

chine learning, meaning that the CVD class can be

predicted correctly. Our methodology for CVD pre-

diction includes the following models which are ex-

plained below.

2.1 Naive Bayes

Naive Bayes (Dinesh et al., 2018) is a simple classiﬁer

founded on the Bayes theorem that supposes highly

independent attributes known as predictors to achieve

probability maximization. The main interest is to ﬁnd

the posterior probabilities

P(c

, . . . , f

) =

P( f

, . . . , f

|c)P(c)

P( f

, . . . , f

)

(1)

where P( f

, . . . , f

|c) =

∏

j=1

P( f

i j

|c) is the proba-

bility of predictors given class, P ( f

, . . . , f

) is the

prior probability of predictors and P(c) is the prior

probability of class. The testing data is classiﬁed

based on the probability of association:

ˆc = argmaxP(c)

∏

j=1

P( f

i j

|c)

for c ∈ {CV D, Non −CV D},

2.2 Support Vector Machine

The SVM is a machine learning algorithm that has

been used in medicine due to its high classiﬁcation

performance. It can be used to solve a binary classi-

ﬁcation problem (as the one investigated here), either

linear or non-linear using a Kernel function to map the

nonlinear data to high dimensional feature space. In

the linear case, the instances are separated with a hy-

perplane, called support vector, of the form w

f + b,

where w is n dimensional coefﬁcient vectors normal

to the hyperplane of the surface and b is offset value

from the origin. The value of w and b are calculated,

and the linear discriminant function can be written as

g(w) = sign(w

f + b).

2.3 Logistic Regression

Logistic Regression predicts the class label of the in-

put features based on their values using a binary lo-

gistic regression model. Assuming p = P(c = ‘CVD),

log

(

1−p

) = β

∑

j=1

i j

, with (β

, β

, . . . , β

) be

the regression weights attached to features row vector

, i = 1, 2, . . . , M . Isolating p, if it is greater than the

threshold, it is set to CVDs class (Yes); otherwise, it

is set to Non-CVDs class (No). The β coefﬁcients val-

ues of the logistic regression algorithm are estimated

from training data using maximum-likelihood estima-

tion.

2.4 Random Forest

The Random forest method (Yang et al., 2020) is a su-

pervised learning algorithm that can be employed for

the classiﬁcation of instances as either CVD or Non-

CVD. A Random forest algorithm is an ensemble of

decision trees that are created on data samples. The

more decision trees are considered, the more robust

is the constructed forest. It combines the prediction

from each tree separately to ﬁnally select the best out-

come by means of majority voting.

3 DATASET DESCRIPTION

The training and test dataset for the cardiovascu-

lar diseases risk prediction model was constructed

based on the CVDs dataset (an open-source dataset

derived from Kaggle), which consists of 70000 par-

ticipants. It is a balanced dataset of approximately

equal healthy and diagnosed with CVD participants,

which contains 11 features (4 demographic, 4 ex-

amination, and 3 social history) which include age

(years), gender, weight (Kg) and height (m

) from

which BMI =

weight

(height)

was derived, cholesterol and

glucose levels characterized as normal, above normal

or well above normal, physical activity, drinking and

smoking habits with values yes or no, systolic and di-

astolic blood pressure (mmHg), physical activity. No-

tice that the blood pressure measurements have been

recorded at the moment of medical examination. To

identify linear correlations between the features and

the target class we employed Pearson’s correlation co-

efﬁcient (CC) (Mukaka, 2012) deﬁned as

C =

∑

i=1

− ¯x)(y

− ¯y)

∑

i=1

− ¯x)

∑

− ¯y)

, (2)

where x

and y

are the values of features x and y for

the i-th individual.

The results presented in Table 2 were derived set-

ting an alpha value equal to 0.01 to compute a 99%

conﬁdence interval. From Table 2, we verify high

linear dependence among BMI and weight features

as the corresponding coefﬁcient is equal to 0.7620.

Also, a moderate correlation value of 0.4520 was ob-

served between glucose and cholesterol. A low corre-

lation value of 0.3400 was noted between smoke and

alcohol. Focusing on the CVD class and the features

that capture age and cholesterol, low correlation val-

ues are recorded (since 0.2 ≤ C ≤ 0.39 )from the cur-

rent dataset.

Furthermore, in Tables 4-8, the distributions of se-

lected participants considering different combinations

Cardiovascular Disease Risk Prediction with Supervised Machine Learning Techniques

317

Table 2: Pearson Correlation Coefﬁcients Matrix between the features and target CVD class.

Age Gender Height Weight BMI SBP DBP Chol Glucose Smoke Alcohol

Physical

Activity

CVD

Age 1.0000 -0.0230 -0.0810 0.0540 0.0850 0.0210 0.0180 0.1540 0.0990 -0.0480 -0.0300 -0.0100 0.2380

Gender -0.0230 1.0000 0.4990 0.1550 -0.0970 0.0060 0.0150 -0.0360 -0.0200 0.3380 0.1710 0.0060 0.0080

Height -0.0810 0.4990 1.0000 0.2910 -0.2910 0.0050 0.0060 -0.0500 -0.0190 0.1880 0.0940 -0.0070 -0.0110

Weight 0.0540 0.1550 0.2910 1.0000 0.7620 0.0310 0.0440 0.1420 0.1070 0.0680 0.0670 -0.0170 0.1820

BMI 0.0850 -0.0970 -0.2910 0.7620 1.0000 0.0250 0.0350 0.1460 0.1010 -0.0270 0.0140 -0.0140 0.1660

SBP 0.0210 0.0060 0.0050 0.0310 0.0250 1.0000 0.0160 0.0240 0.0120 -0.0010 0.0010 0 0.0540

DBP 0.0180 0.0150 0.0060 0.0440 0.0350 0.0160 1.0000 0.0240 0.0110 0.0050 0.0110 0.0050 0.0660

Chol 0.1540 -0.0360 -0.0500 0.1420 0.1460 0.0240 0.0240 1.0000 0.4520 0.0100 0.0360 0.0100 0.2210

Glucose 0.0990 -0.0200 -0.0190 0.1070 0.1010 0.0120 0.0110 0.4520 1.0000 -0.0050 0.0110 -0.0070 0.0890

Smoke -0.0480 0.3380 0.1880 0.0680 -0.0270 -0.0010 0.0050 0.0100 -0.0050 1.0000 0.3400 0.0260 -0.0150

Alcohol -0.0300 0.1710 0.0940 0.0670 0.0140 0.0010 0.0110 0.0360 0.0110 0.3400 1.0000 0.0250 -0.0070

Physical

Activity

-0.0100 0.0060 -0.0070 -0.0170 -0.0140 0 0.0050 0.0100 -0.0070 0.0260 0.0250 1.0000 -0.0360

CVD 0.2380 0.0080 -0.0110 0.1820 0.1660 0.0540 0.0660 0.2210 0.0890 -0.0150 -0.0070 -0.0360 1.0000

Table 3: Distribution per gender group of healthy and diag-

nosed with CVD in the dataset.

CVD

Gender No Yes Total

Female 32,73% 32,31% 65,04%

Male 17,30% 17,66% 34,96%

50,03% 49,97% 100,00%

Table 4: Distribution per age group of healthy and diag-

nosed with heart disease in the dataset.

CVD

Age Group No Yes Total

30-34 0,01% 0,00% 0,01%

35-39 0,45% 0,13% 0,58%

40-44 9,62% 4,12% 13,74%

45-49 7,04% 5,41% 12,46%

50-54 14,95% 12,64% 27,59%

55-59 10,23% 12,68% 22,91%

60-64 7,56% 14,65% 22,21%

65-69 0,16% 0,35% 0,50%

50,03% 49,97% 100,00%

of the features and the target classes (yes or no) are

presented. In Table 3, the 32.31% of participants that

suffer from CVD are women which are almost twice

greater than men with CVD.

Moving on to Table 4, it is shown that approxi-

mately 70% of the total participants are elderly (age

≥ 50) which is the target group of people that concern

the current study. From older participants, about 40%

belongs to the CVD class.

Table 5 presents a classiﬁcation of participants ac-

cording to the values of systolic and diastolic blood

pressure. The current data has shown that about 45%

of the participants have been diagnosed with a CVD

and are categorized as hypertensive (I or II).

Table 6 shows the distribution of participants in

Table 5: Distribution per blood pressure category of healthy

and diagnosed with heart disease in the dataset.

CVD

Blood Pressure No Yes Total

Elevated 3,02% 1,45% 4,46%

Hypertension I 31,44% 25,60% 57,05%

Hypertension II 4,89% 19,87% 24,76%

Normal 10,68% 3,05% 13,73%

Total 50,03% 49,97% 100,00%

Table 6: Distribution of healthy and diagnosed with CVD

in relation to smoke and alcohol features in the dataset.

CVD

Smoke No Yes Total

No 45,40% 45,79% 91,19%

No 44,10% 44,36% 88,46%

Alcohol

Yes 1,30% 1,43% 2,73%

Yes 4,63% 4,18% 8,81%

No 3,16% 3,01% 6,16%

Alcohol

Yes 1,47% 1,18% 2,65%

50,03% 49,97% 100,00%

Table 7: Distribution of healthy and diagnosed with CVD

in relation to glucose level feature in the dataset.

CVD

Glucose level No Yes Total

Normal 41,90% 32,94% 74,84%

Above Normal 5,43% 8,21% 13,64%

Well Above

Normal

2,70% 8,82% 11,52%

50,03% 49,97% 100,00%

Non-CVD and CVD classes according to smoke and

alcohol features. Here, it should be noted that a small

percentage of participants (1.18%) diagnosed with

CVD are simultaneous smokers and consume alcohol.

Tables 7, 8 show the distribution of participants

in Non-CVD and CVD classes according to glucose

ICT4AWE 2022 - 8th International Conference on Information and Communication Technologies for Ageing Well and e-Health

318

Table 8: Distribution of healthy and diagnosed with CVD

in relation to cholesterol level feature in the dataset.

CVD

Cholesterol level No Yes Total

Normal 41,90% 32,94% 74,84%

Above Normal 5,43% 8,21% 13,64%

Well Above Normal 2,70% 8,82% 11,52%

50,03% 49,97% 100,00%

and cholesterol features. Here, it should be noted that

a small percentage of participants (1.18%) diagnosed

with CVD are simultaneous smokers and consume al-

cohol. Moreover, there is no knowledge of the amount

of consumption to understand to what extent the par-

ticipants’ habits are harmful to their health.

Table 9 records the distribution of participants in

Non-CVD and CVD classes according to physical ac-

tivity and BMI classes. It is observed that 11,55%

of participants although they belong to healthy BMI

class and are physically active, they have been di-

agnosed with CVD. Also, in obese and overweight

classes, the number of participants diagnosed with

CVD is approximately similar. Both in this case,

there is no knowledge of exercise-related character-

istics (intensity, duration, frequency, type) to under-

stand to what extent physical activity can be beneﬁcial

for CVD patients health.

Finally, it should be highlighted that the small per-

centage of participants with CVD who smokes, con-

sumes alcohol and is physical activity in Table 3 is re-

ﬂected as negatively low correlation with CVD class.

4 DATA PREPROCESSING

The data preprocessing was evaluated using Stata

V.14 tool kit. Stata is a general-purpose statisti-

cal software package developed by StataCorp for

data manipulation, visualization, statistics, and auto-

mated reporting. The constructed training and testing

dataset, which is based on the CVDs dataset, was cre-

ated by studying all attributes that are correlated and

potentially relevant for the identiﬁcation of Cardio-

vascular Diseases. In order to establish a uniﬁed set

of attributes for each participant, we derived harmo-

nized variables for each attribute, by transforming all

numeric values to nominal values, according to prede-

ﬁned attribute rules. Moreover, the class was created

based on CVD’s dataset cardiovascular diseases fea-

ture. The class distribution is balanced containing in

total 70,000 observations.

In order to examine all attributes’ correlation with

the class, we used a feature selection method that

ranks all attributes with respect to the relevance to

the speciﬁc class. More speciﬁc, we utilized a fea-

Table 9: Distribution of healthy and diagnosed with CVD

in relation to Physical Activity level and BMI class in the

dataset.

CVD

Physical Activity No Yes Total

No 9,11% 10,52% 19,63%

BMI Class Underweight 0,10% 0,05% 0,15%

Overweight 3,22% 3,71% 6,93%

Obese III 0,16% 0,45% 0,61%

Obese II 0,41% 0,90% 1,31%

Obese I 1,22% 2,27% 3,49%

Healthy 4,01% 3,14% 7,15%

Yes 40,92% 39,45% 80,37%

BMI Class Underweight 0,56% 0,21% 0,77%

Overweight 14,41% 14,63% 29,04%

Obese III 0,68% 1,41% 2,09%

Obese II 1,61% 3,36% 4,97%

Obese I 5,71% 8,29% 14,00%

Healthy 17,95% 11,55% 29,51%

50,03% 49,97% 100,00%

ture selection method based on a variation of Ran-

dom Forests (Genuer et al., 2010) and according to

this method, the attributes are ranked using the Gini

importance score of the model’s trees. The Gini in-

dex (Sundhari, 2011) is estimated as follows

Gini = 1 −

∑

i=1

, (3)

where c is the number of classes and p

is the relative

frequency of class i in the dataset. In our case param-

eter c = 2 captures the CVDs and non-CVDs classes.

5 EXPERIMENTS AND

EVALUATION

5.1 Experiments Setup

The experiments were evaluated using WEKA.

WEKA is a JAVA-based data mining toolkit created

and free software tool distributed under the GNU

General Public License that provides a large library of

methods and models for classiﬁcation, clustering, pre-

diction, feature selection. For the purposes of this ex-

periment, we split the dataset into two parts, 30% test-

ing and 70% training. To do that, we ﬁrst randomized

the dataset, in order to create a random permutation.

Then, we applied the RemovePercentage method with

30% and saved the resulting dataset as training. We

also applied the same ﬁlter choosing invertSelection

in order to pick the rest of the data (30%) which is the

testing dataset.

Cardiovascular Disease Risk Prediction with Supervised Machine Learning Techniques

319

Table 10: Performance of ML models for CVDs risk pre-

diction.

Algorithm Accuracy Recall AUC

Naive Bayes 59.59% 59.60% 69.4%

SVM 70.61% 70.60% 70.6%

Random Forest 70.86% 70.90% 76.6%

Logistic Regression 72.06% 72.10% 78.4%

5.2 Experiments Results

For the speciﬁc experiment, accuracy, recall and AUC

were considered as performance metrics. Also, the

10-fold cross-validation procedure was used to eval-

uate four different classiﬁers: Na

ıve Bayes, SVMs,

Logistic Regression and Random Forests. The mod-

els’ evaluation is executed based on the confusion ma-

trix, namely TP (True Positive), TN (True Negative),

FP (False Positive) and FN (False Negative). More

speciﬁcally, the measures used for the calculation of

the accuracy and recall are deﬁned as

Accuracy =

(T N + T P)

(T N + T P + FN + FP)

(4)

Recall =

T P

T P + FN

(5)

The performance results of the ML algorithms, in

terms of the employed metrics, are shown in Table

10. The predictive ability of the Logistic Regression

model in cardiovascular diseases is promising and su-

perior in terms of accuracy, recall and AUC against

the rest of the ML models. The higher the AUC, the

better the performance of the model at distinguishing

between CVD and Non-CVD classes. In particular,

AUC shows that there is a 78.4% chance that the Lo-

gistic Regression model will be able to distinguish be-

tween CVD and Non-CVD classes.

6 CONCLUSIONS

In the context of this research study, a supervised ma-

chine learning methodology was employed and prop-

erly designed to assess the long-term risk of occur-

ring CVD. The outcomes of the study may provide

useful information in the clinic viewpoint and assist

clinicians in how to interpreting data and implement-

ing optimal algorithms for the dataset (Al’Aref et al.,

2019).

It is ongoing research in which, as a ﬁrst step, sev-

eral traditional models were developed to investigate

data quality and determine that model with the best

predictive performance. The current outcomes will be

used to design the next steps of our research and iden-

tify the optimal models to improve the performance

metrics. The evaluation results presented similar ac-

curacy and recall, a fact that is justiﬁed by the bal-

anced distribution of participants into two classes. A

promising direction for enhancing the achieved out-

comes (accuracy, recall, AUC) is the utilization of

deep learning models and techniques (Swathy and

Saruladha, 2021), as they can provide complex de-

cision boundaries and thus better ﬁt the training data.

Finally, our aim is to focus our analysis on i) anomaly

detection techniques to identify instances with in-

correct values and ii) dimensionality reduction tech-

niques to optimize the performance of ML models.

ACKNOWLEDGEMENTS

This work has been partially supported by the

European Union’s H2020 research and innovation

programme SmartWork under grant agreement No

826343, SC1-DTH-03-2018 - Adaptive smart work-

ing and living environments supporting active and

healthy ageing and GATEKEEPER under grant

agreement No 857223, SC1-FA-DTS-2018-2020 -

Smart living homes-whole interventions demonstra-

tor for people at health and social risks.

REFERENCES

Abdalrada, A. S., Abawajy, J., Al-Quraishi, T., and Islam,

S. M. S. (2022). Machine learning models for predic-

tion of co-occurrence of diabetes and cardiovascular

diseases: a retrospective cohort study. Journal of Di-

abetes & Metabolic Disorders, pages 1–11.

Al’Aref, S. J., Anchouche, K., Singh, G., Slomka, P. J.,

Kolli, K. K., Kumar, A., Pandey, M., Maliakal, G.,

Van Rosendael, A. R., Beecy, A. N., et al. (2019).

Clinical applications of machine learning in cardio-

vascular disease and its relevance to cardiac imaging.

European heart journal, 40(24):1975–1986.

Dinesh, K. G., Arumugaraj, K., Santhosh, K. D., and

Mareeswari, V. (2018). Prediction of cardiovascu-

lar disease using machine learning algorithms. In

2018 International Conference on Current Trends to-

wards Converging Technologies (ICCTCT), pages 1–

7. IEEE.

Dritsas, E., Fazakis, N., Kocsis, O., Fakotakis, N., and

Moustakas, K. (2021). Long-term hypertension risk

prediction with ml techniques in elsa database. In

International Conference on Learning and Intelligent

Optimization, pages 113–120. Springer.

Fazakis, N., Kocsis, O., Dritsas, E., Alexiou, S., Fakotakis,

N., and Moustakas, K. (2021). Machine learning tools

for long-term type 2 diabetes risk prediction. IEEE

Access, 9:103737–103757.

Gale, C. R., Cooper, C., and Sayer, A. A. (2014). Fram-

ingham cardiovascular disease risk scores and incident

ICT4AWE 2022 - 8th International Conference on Information and Communication Technologies for Ageing Well and e-Health

320

frailty: the english longitudinal study of ageing. Age,

36(4):1–9.

Genuer, R., Poggi, J.-M., and Tuleau-Malot, C. (2010).

Variable selection using random forests. Pattern

recognition letters, 31(14):2225–2236.

Haq, A. U., Li, J. P., Memon, M. H., Nazir, S., and Sun,

R. (2018). A hybrid intelligent system framework for

the prediction of heart disease using machine learning

algorithms. Mobile Information Systems, 2018.

Hoyas, I. and Leon-Sanz, M. (2019). Nutritional challenges

in metabolic syndrome. Journal of clinical medicine,

8(9):1301.

Hussain, A., Ugli, I. K. K., Kim, B. S., Kim, M., Ryu, H.,

Aich, S., and Kim, H.-C. (2021). Detection of dif-

ferent stages of copd patients using machine learning

techniques. In 2021 23rd International Conference

on Advanced Communication Technology (ICACT),

pages 368–372. IEEE.

Kocsis, O., Moustakas, K., Fakotakis, N., Vassiliou, C.,

Toska, A., Vanderheiden, G. C., Stergiou, A., Amaxi-

latis, D., Pardal, A., Quintas, J., et al. (2019). Smart-

work: designing a smart age-friendly living and work-

ing environment for ofﬁce workers. In Proceedings

of the 12th ACM International Conference on PErva-

sive Technologies Related to Assistive Environments,

pages 435–441.

Kumar, M. D. and Ramana, K. (2021). Cardiovascular

disease prognosis and severity analysis using hybrid

heuristic methods. Multimedia Tools and Applica-

tions, 80(5):7939–7965.

Mohan, S., Thirumalai, C., and Srivastava, G. (2019). Ef-

fective heart disease prediction using hybrid machine

learning techniques. IEEE access, 7:81542–81554.

Mukaka, M. M. (2012). A guide to appropriate use of corre-

lation coefﬁcient in medical research. Malawi medical

journal, 24(3):69–71.

Roth, G. A., Johnson, C., Abajobir, A., Abd-Allah, F.,

Abera, S. F., Abyu, G., Ahmed, M., Aksut, B., Alam,

T., Alam, K., et al. (2017). Global, regional, and na-

tional burden of cardiovascular diseases for 10 causes,

1990 to 2015. Journal of the American College of Car-

diology, 70(1):1–25.

Sundhari, S. S. (2011). A knowledge discovery using de-

cision tree by gini coefﬁcient. In 2011 International

Conference on Business, Engineering and Industrial

Applications, pages 232–235. IEEE.

Swathy, M. and Saruladha, K. (2021). A comparative study

of classiﬁcation and prediction of cardio-vascular dis-

eases (cvd) using machine learning and deep learning

techniques. ICT Express.

Wilkins, E., Wilson, L., Wickramasinghe, K., Bhatnagar,

P., Leal, J., Luengo-Fernandez, R., Burns, R., Rayner,

M., and Townsend, N. (2017). European cardiovascu-

lar disease statistics 2017.

Yancy, C. W., Jessup, M., Bozkurt, B., Butler, J., Casey,

D. E., Drazner, M. H., Fonarow, G. C., Geraci, S. A.,

Horwich, T., Januzzi, J. L., et al. (2013). 2013

accf/aha guideline for the management of heart fail-

ure: a report of the american college of cardiology

foundation/american heart association task force on

practice guidelines. Journal of the American College

of Cardiology, 62(16):e147–e239.

Yang, L., Wu, H., Jin, X., Zheng, P., Hu, S., Xu, X., Yu, W.,

and Yan, J. (2020). Study of cardiovascular disease

prediction model based on random forest in eastern

china. Scientiﬁc reports, 10(1):1–8.

Cardiovascular Disease Risk Prediction with Supervised Machine Learning Techniques

321
