A Framework for Seamless Ofﬂoading in IoT Applications using Edge

and Cloud Computing

Himesh Welgama, Kevin Lee and Jonathan Kua

School of Information Technology, Deakin University, VIC 3220, Geelong, Australia

Keywords:

Edge, Cloud, Docker, IoT, Ofﬂoading.

Abstract:

Typical Internet of Things (IoT) deployments are resource-constrained, with limited computation and storage,

high network latency, and low bandwidth. The introduction of Edge and Cloud computing provides a method

of mitigating these shortfalls. This paper proposes a framework for structuring IoT applications to allow for

seamless ofﬂoading (based on CPU load) of work from IoT nodes to Edge and Cloud computing resources.

The proposed ﬂexible framework utilises software to orchestrate multiple containerised IoT applications

for optimal performance within available computational resources. Edge and Cloud servers co-operate

autonomously to determine the appropriate resource allocation based on the requirements of running IoT

applications in real-time. The result is a framework that is suited to perform with heterogeneous IoT hardware

while improving overall computational performance, latency and bandwidth relative to IoT architectures that

do not auto-scale. This framework is evaluated using an experimental setup with multiple IoT nodes, Edge

nodes and Cloud computing resources. It demonstrates the approach is viable and results in a ﬂexible and

scalable IoT solution.

1 INTRODUCTION

The beneﬁts for Internet of Things (IoT) applications

of integrating sensing nodes, Edge and Cloud will

lead to improved latency and bandwidth for IoT

devices and also provide additional resources for

resource constrained devices (El-Sayed et al., 2017).

Edge and Cloud computing paradigm that is a

bridge between IoT, Edge and Cloud computing,

data is stored and pre-processed at Edge servers,

only a small amount of data is then pushed towards

Cloud servers if increased computation is needed.

This process of transmitting data between different

levels reduces the latency, assists in increase overall

computational power along with boosting scalability.

There are particular challenges in the convergence

of IoT, Edge and Cloud computing for various

applications (Biswas and Giaffreda, 2014; Kua et al.,

2017),

A 3-tier Edge and Cloud infrastructure can

address the limitations of Edge computing but these

are difﬁcult to build due to the coordination required.

Data needs to be seamlessly transferred between

the IoT node, Edge resources and Cloud resources

without introducing unnecessary delay. These

challenges can be mitigated through well designed

frameworks and architectures that allow applications

to be built that utilise IoT, Edge and Cloud computing

resources. A three-tier architecture builds a hierarchy

with inter-layer computation ofﬂoading to address

this problem (Hwang et al., 2021). To this end, much

research has also been done to realize the “Edge-

Cloud Continuum” (Milojicic, 2020; Taivalsaari

et al., 2021; Aloi et al., 2020).

The aim of the research presented in this paper

is to improve the scalability and performance of

IoT applications that use a 3-tier architecture. The

contributions of this paper are: (i) the development of

a framework that allows IoT applications to be built

that can utilise Edge and Cloud resources seamlessly

through the use of container-based virtualisation, (ii)

mechanisms to support the automatic scaling (based

on CPU load) of container-based IoT applications

across edge and cloud resources, (iii) support for

the dynamic addition and removal of IoT, edge

and cloud resources in IoT applications, and (iv)

an evaluation comparing the approach to one that

doesn’t automatically scale. The proposed approach

allows for improved resource utilisation and improved

capability for all nodes in IoT applications.

The remainder of this paper is as follows.

Section 2 provides a background of the state-of-the-

Welgama, H., Lee, K. and Kua, J.

A Framework for Seamless Ofﬂoading in IoT Applications using Edge and Cloud Computing.

DOI: 10.5220/0011107500003194

In Proceedings of the 7th International Conference on Internet of Things, Big Data and Security (IoTBDS 2022), pages 289-296

ISBN: 978-989-758-564-7; ISSN: 2184-4976

289

art in the area. Section 3 proposes a new framework

for scalable IoT Applications using ofﬂoading.

Section 4 presents an experimental evaluation of the

proposed framework. Finally, Section 5 presents

some conclusions and future work.

2 AUTO-SCALING AND

OFFLOADING FOR EDGE

COMPUTING

Auto-scaling and ofﬂoading allow for IoT and edge

applications to be able to meet processing demand.

Fundamentally, auto-scaling is about increasing the

amount of resources available to the task. In

edge computing, auto-scaling represents a variety of

challenges and can be implemented in a range of

different ways (Taherizadeh and Stankovski, 2017).

The work in (Dinh et al., 2017) proposes an approach

to auto-scaling in mobile edge computing by scaling

the CPU frequency on devices that support it. This

is an example of utilising resources to the maximum,

whilst potentially incurring costs, such as increased

energy use or device life span. Auto-scaling is

a core property of cloud computing, through the

automatic additional and removal of cloned virtual

machines (Lorido-Botran et al., 2014). This approach

can be used in IoT, for example, increase the number

of supported IoT or sensor nodes (Lee et al., 2010).

Ofﬂoading is a form of auto-scaling which utilises

additional devices to increase the computational

resources available for the task. In edge computing,

there are a variety of approaches to supporting

ofﬂoading of work (Mach and Becvar, 2017).

(Zhang, 2018) takes a pricing based approach

to choosing between different edge servers to

ofﬂoad data for processing. (Liu and Zhang,

2018) focuses on ensuring achieving low-latency

communications through the use of ofﬂoading. There

is also promising work to improve the battery

life of mobile devices by ofﬂoading to nearby

edge computing resources (Sardellitti et al., 2015).

Recent work in container based approaches for

IoT allows automatic failure-recovery for IoT edge

applications (Olorunnife et al., 2021).

As increasingly IoT applications are being de-

ployed using containers, and more processing is being

performed in IoT applications (e.g. video processing),

there will be a need for auto-scaling and ofﬂoading in

these applications. Support for auto-scaling and of-

ﬂoading in container-based deployments is currently

extremely limited, with none of the approaches dis-

cussed here targeting container-based deployments

through the whole of the IoT architecture. As an

example, (Wu et al., 2017) proposes the use of of-

ﬂoading in a container-based deployment for mobile

computation, but only creates cloud-based contain-

ers to ofﬂoad work directly to, and does not take a

hierarchical scalable approach suitable for IoT. (Ab-

dul Majeed et al., 2019) provide an analysis of the

performance beneﬁt in ofﬂoading critical tasks from

edge to cloud, in a container-based environment, but

this is focused on normally ﬁxed services than IoT

applications, and doesn’t take into account the end

node. Most container-based auto-scaling approaches,

focus on a single layer, such as the edge or fog layer.

For example, (Zheng and Yen, 2019) propose an

approach to auto-scale Kubernetes containers to bal-

ance application performance and resource usage.

This paper aims to demonstrate that auto-scaling for

IoT applications through the use of ofﬂoading is a

viable technique in container-based deployments.

3 PROPOSED FRAMEWORK

This paper proposes a framework for building

scalable IoT applications with a focus on using Edge

and Cloud computing resources. Existing methods

(involving the use of container-based virtualization,

Edge, Cloud and Fog computing as described in

Section 2) often execute computational tasks in a

siloed fashion, and often lack seamless cooperation

between the various IoT/Edge/Cloud nodes.

The novelty of the framework proposed in

this paper is in the real-time cooperation between

IoT, Edge and Cloud nodes using a container-

based ofﬂoading mechanism to satisfy performance

requirements.

3.1 Design

Figure 1 illustrates the architecture of the proposed

framework that aims to balance and satisfy the

requirements. It adopts the popular 3-tier architecture

of IoT, Edge and Cloud computing resources. The

architecture aims to be scalable through the use

of decentralized management, which allows for the

introduction of new Edge or Cloud devices at any

point in time. An application container can be

run as a whole or as sub-tasks, depending on the

tasks requirements. Host devices are connected to

a private Docker registry and a Message Queuing

Telemetry Transport (MQTT) broker. For evaluation

purposes the program offers clients the ability to

create Docker registries or MQTT brokers upon its

ﬁrst initialisation. MQTT is used as the primary

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

290

method of communication between the nodes. All

nodes must be connected to the same MQTT broker.

Figure 1: Overview of proposed architecture.

In the architecture, the IoT node/device is

responsible for data collection and processing within

the initial phase. Applications of low latency and

minimum computational demands will run on the

IoT device until the thresholds are met. Sub-

tasks can be partitioned from larger applications

and containerised, Each sub-task will have different

application and computational requirements. When

the sub-tasks increase their demands, they may

exceed the processing capability of the IoT device.

Under such circumstances, a request will be made

to a local Edge server to share hardware resources.

Containerised sub-tasks will be transitioned through a

Docker registry for processing within the Edge server.

An Edge node is situated within the networks

Edge. It aims to provide local optimisation through

increased computational resources and improved la-

tency for IoT devices. Edge nodes may undertake

any task requested from IoT devices requiring ad-

ditional resources. Furthermore, the availability of

Edge nodes can be increased to meet scalability re-

quirements of an application. Situations where a

particular Edge node is unable to satisfy computa-

tional needs of a sub-task can request resources from

the Cloud nodes. If a global optimisation approach

is required, the applications can also be processed

entirely across the Cloud nodes.

The Cloud Node can operate with a similar method

to Edge nodes, providing global optimisation and in-

creased computational resources. Sub-tasks that re-

quire access from a secure remote location will be

controlled through the Cloud tier. As computational

resources increase, the availability of Cloud resources

provide more utility than constructing new Edge

servers. Cloud nodes can communicate with each

other to distribute their computational loads effec-

tively, e.g., using load-balancer and auto-scaler (Pan

and McElhannon, 2017).

Applications can be separated into sub-tasks and

distributed across Cloud or Edge nodes. However,

they require a method of orchestration to allow for

the whole system to perform correctly. Once an

instance of this infrastructure scales, decentralized

communication can be deployed to avoid any vendor

lock-in or possibilities of information loss. MQTT

is a lightweight protocol that offers a ﬂexible

Publish/Subscribe model. This architecture allows

for any additional Edge or Cloud node to subscribe

to open application requests, without requiring

databases or centralized management systems. As

long as a system is connected to the same MQTT

broker, it can scale to ‘n’ size.

Figure 2: Initialisation of nodes within the framework.

To ensure safe orchestration of applications within

the system, a conﬁguration program will run inside

the operating system of each node. The program

will track the statistics of each IoT service within

the pool and relay MQTT messages and Docker API

calls when necessary. To improve computational

performance of this system, new nodes can be added

and initialised.

Node.js is used in the proposed framework. Each

node within the system is initialised at the start of

each experiment.

• All nodes must have Docker Engine installed

• Required thresholds for application limits need to

be decided prior to conﬁguring nodes

• MQTT Broker and Docker Registry are set-up

• Docker application must be saved as .tar ﬁle

within IoT node prior to execution

A series of system checks are performed prior to

setting up each node on the IoT framework. Figure 2

details the required responses upon initialisation.

A Framework for Seamless Ofﬂoading in IoT Applications using Edge and Cloud Computing

291

Figure 3 shows an example of the conﬁguration ﬁle

created following the initialisation of a node within

the framework. This ﬁgure describes the necessary

information that’s required in order to establish a

connection between the Docker registry, Docker

image, MQTT broker and other nodes within the

framework.

{

registryLocation: ‘192.168.0.0:5000’,

nodeType: ‘iot’,

imageLocation: ‘/image-name.tar’,

imageName: ‘Hello-World’,

mqttLocation: ‘192.168.0.1’

}

Figure 3: Node conﬁguration JSON ﬁle.

4 EVALUATION

This section presents the experimental setup and

evaluation results of the proposed framework. The

ﬁrst two evaluation scenarios focus on the validation

of the proposed system while the third evaluation

scenario compares the real-world performance of a

traditional non-auto-scaling IoT architecture and the

proposed framework.

4.1 Experimental Setup and Network

Conﬁguration

The experimental test-bed setup consists of the

following:

• Raspberry Pi 3B+ with Wiﬁ connection (IoT

node)

• x86 Intel i5-3570s @ 3.10GHz, 4GB RAM,

300GB HDD (Edge node)

• 4 Core Intel x86 CPU, 16Gb RAM, 25GB SSD

system (Cloud)

• 1 Core Intel x86 CPU, 1GB RAM, 25GB SSD

system (Cloud for Evaluation 1)

The network conﬁguration for the experiments is

illustrated in Figure 4 and described as follows.

• IoT nodes connected to gateway through Wi-Fi.

• An edge node that uses a Gigabit wired Ethernet

connection to the gateway. This has a maximum

achievable download speed of 1000Mbits/s

• The network gateway from the selected Internet

Service Provider (ISP) is capped at 250Mbits/s

download and 20Mbits/s upload.

• A Cloud server is located in close geographical

proximity (Sydney Australia)

4.2 Scenario 1: Migration of

IoT-Edge-Cloud Nodes

This scenario analyses the impact of node movement

based on the available resources by visualising the

time between the transfer of a Docker container to a

higher level node in the framework. A Linux-based

software library stress-ng (King, 2017) is used to

create artiﬁcial load for performance bench-marking

and testing. In these experiments, the software stress

tests each CPU to 25% on each thread. The command

was encapsulated within a Docker image that was

containerised and used for each node.

A counter is used to track the CPU percentage

from when the Docker image is ran to the moment it

has reached its maximum threshold. On the Edge and

Cloud nodes, the counter will gather CPU percentage

as soon as the MQTT message is received. This is

used to calculate the downtime between the transfer of

images between nodes. Each node along the system

has speciﬁc maximum thresholds placed based on

their requirements. This is less relevant in this

experiment as the primary focus is on observing the

transfer of Docker images between nodes.

Figure 4: Network conﬁguration for the evaluation.

Figure 5 presents the evaluation results. It is

observed that the transfer of Docker image from IoT

to the Edge node has negligible downtime. This is due

to the location of the Docker registry location being

within the Edge node itself, therefore drastically

reducing the amount of information that has to be

downloaded. The Cloud node has signiﬁcantly more

difﬁculty in downloading and running the Docker

image from the registry, which resulted in an almost

20-second delay in data loss between the moment

the Edge node stopped to when the Cloud node

started. This delay is heavily dependent on the

networking conﬁguration of Edge Server and Cloud

Server. This scenario demonstrated the efﬁciency of

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

292

data transmission from the IoT node to the Edge node.

As the system requirements become more complex,

a more logical approach would be the use of task

splitting with the proposed architecture.

100

120

140

160

180

200

1 11 21 31 41 51 61 71 81

CPU Utilization (%)

Elapsed Time (s)

IoT Edge Cloud

Figure 5: Scenario 1: Application movement when

thresholds are met.

4.3 Scenario 2: Aggregation of

Sub-tasks

Scenario 2 evaluates the separating of an application

into multiple containerised sub-tasks with the goal

of mitigating downtime and improving the utilisation

of each node. Based on thresholds, sub-tasks are

automatically set to migrate to a higher-level node

if a threshold is met. This evaluation hypothesises

a greater reduction in downtime between tasks, and

efﬁcient resource allocation within nodes. The main

application is split between three separate tasks,

ranging from 25%, 50% and 75% CPU load utilised

in each task respectively. Tasks are initially deployed

on the IoT node as one application and are moved

to a separate node if the threshold is met. In this

experiment, the threshold values are not signiﬁcant,

however the movement and CPU% utilisation of each

sub-task is important as this value will indicate the

successful migration/movement and optimal usage of

compute resources.

100

120

140

160

180

1 11 21 31 41 51 61 71 81

CPU Utilization (%)

Elapsed Time (s)

Figure 6: Scenario 2: Sub-task 1, Avg 25% load per thread.

Figures 6, 7, 8 present the CPU utilisation for each

sub-tasks at 25%, 50% and 75% CPU load on each

thread. Figure 9 overlays all three graph plots and

100

150

200

250

300

350

400

450

0 19 40 60 82 102 122 142 162

CPU Utilization (%)

Elapsed Time (s)

IoT Edge

Figure 7: Scenario 2: Sub-task 2, Avg 50% load per thread.

100

150

200

250

300

350

0 17 38 59 81 101 121 141 162

CPU Utilization (%)

Elapsed Time (s)

Series1 Edge Cloud

Figure 8: Scenario 2: Sub-task 3, Avg 75% load per thread.

compares the performance across the three sub-tasks.

In this evaluation, all sub-tasks successfully run

on the most optimal node. The approach uses a 1

minute time window to examine the average CPU

usage compared against a set threshold. During each

1-minute interval, each sub-task will re-evaluate its

computational requirements and move the application

to a higher level node if necessary. The variability

of CPU utilisation percentages between each sub-

task are inﬂuenced by many different factors. This

evaluation focuses on the node movement and average

CPU load utilisation. The two key takeaways from

this evaluation are:

1. The application does not stop running during

periods of downtime between transitioning from

nodes. This can be observed from Figure 8,

as the migration of sub-task from Edge node to

Cloud node has caused a 20-second delay. During

this period, sub-tasks 1 and 2 are still running at

optimal performance as seen in Figure 9.

2. Performance of sub-tasks on each node will be

below ideal when the host is executing more

than one task running at similar or higher CPU

percentage. This can be observed in Figures 7

and 8 where each sub-task is running at a higher

CPU percentage. This result indicates that more

computational resources are being allocated as the

operating system increases the priority level for

the particular task, and CPU throttling. Figure 7

demonstrates the increase of CPU percentage

following the Cloud migration of sub-task 3.

A Framework for Seamless Ofﬂoading in IoT Applications using Edge and Cloud Computing

293

100

150

200

250

300

350

400

450

0 17 38 59 81 101 121 141 162

CPU Utilization (%)

Elapsed Time (s)

Sub Task 1

Sub Task 2

Sub Task 3

Figure 9: Application view: Aggregation of all sub-tasks.

Scenario 2 validates the framework for multi-task

programs and evaluates the effectiveness of utilising

IoT/Edge/Cloud nodes for optimal performance.

4.4 Scenario 3: IoT Node Optimised for

Image Detection

An IoT framework that autonomously optimises each

node to perform at its peak has been validated in

Scenarios 1 and 2. Scenario 3 represents a use-case

scenario in the real world. This use case involves

real-time image detection with Machine Learning

on IoT/Edge/Cloud nodes. The application of IoT

technologies for image detection is rapidly growing,

e.g., the need for robust face/mask detection and

social distancing during the COVID-19 pandemic.

This scenario evaluates the performance of each

different node to process face detection, and compares

the performance to a traditional Cloud approach.

The deployed application gathers an image of an

artiﬁcially generated face database and perform

image detection algorithms. This process is repeated

many times and the response times between the

generation of image to detection are recorded along

with the total number of faces processed within

the elapsed time frame. Using this metric, the

performance of the proposed architecture and its

usability in real-world applications can be further

investigated. The ability of the proposed architecture

to handle multiple IoT nodes, and the performance

impact of larger applications can also be evaluated.

An experiment is conducted to evaluate a tradi-

tional multi-device IoT architecture against the pro-

posed three tier architecture. This scenario utilises

two Raspberry Pi 3B+ IoT devices that work con-

currently to perform the same task. Both IoT de-

vices (IoT A and IoT B) vary the amount of threads

that are used to perform the application. IoT A uses

four threads whereas IoT B uses two threads. This

is purposely done in order to maximise the CPU us-

age where available resulting in the highest possible

output for either architecture and showcase variability

in the IoT devices used. Detailed speciﬁcations for

the experimental setup can be observed in Sub Sec-

tion 4.1. A second experiment is conducted with the

same setup, also using the same three-tier architec-

ture. The containerised application runs on two Rasp-

berry Pi 3B+ boards separately. This evaluation ini-

tially runs on a traditional IoT architecture, where the

device uses HTTP GET to retrieve the image and ex-

ecutes the ML algorithm. Next, the application runs

within the proposed architecture.

1 11 21 31 41 51 61 71 81 91 101 111 121

Processnig Time (s)

Number of images processed

Figure 10: IoT A (four threads): Traditional approach.

1 11 21 31 41 51

Processing Time (s)

Number of images processed

Figure 11: IoT B (two threads): Traditional approach.

The test was performed for 180 seconds, with

results presented in Figs. 10 and 11). IoT A had

faster processing time given the higher number of

threads. The extra two threads resulted in roughly

129% increase in the number of faces processed. The

traditional approach gathered 177 processed faces

within the time frame.

100

150

200

250

300

350

400

450

0 20 41 61 81 102 122 142

CPU Utilization (%)

Time Elapsed (s)

Two Threads

Four Threads

Figure 12: Results with proposed architectural framework:

IoT A (four threads) and IoT B (two threads).

The same containerised application was then

launched from both IoT devices within the proposed

architecture. As illustrated in Figure 12, the appli-

cation was successful in transitioning the application

accordingly based on the CPU usage threshold. It can

be noted that the initial erratic CPU ﬂuctuations are

due to the lower computational power of the Rasp-

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

294

berry Pi, this same pattern is seen on Figure 6. The

periods of which either application migrates from

one host to another can be observed in sections of the

graph where the CPU % dips to 0. During the applica-

tion, IoT A (two threads) was above the set threshold

therefore requiring a migration to the Cloud server.

However, this migration was unsuccessful due to ma-

jor delays in the Cloud host to download the requested

Docker container. Furthermore, the ’Four Threads’

application remained on the Edge node, most likely

due to the increased computational resources avail-

able while the ’Two Threads’ application remained

ofﬂine in its attempt to migrate to the cloud node.

A conclusion is drawn from this initial testing: The

proposed architecture is not designed to be suited for

large applications with sizes ranging above 1GB as

this induces further strain on the networking capabil-

ities of the involved nodes. The architectural design

of the proposed framework will need to be adapted to

suit larger applications.

Figure 13: Workﬂow of ‘pre-loaded’ approach.

A ‘pre-loaded’ approach can be taken to ensure

that the application is loaded within the Cloud

server prior to the initialisation of the IoT node.

Figure 13 demonstrates that a possible solution is

a Publish/Subscribe protocol to indicate completion

of pre-loaded images in the Cloud server. Complex

applications may cause high storage and network load

when ’pre-loading’ multiple applications.

100

150

200

250

300

350

400

450

0 12 24 35 47 59 71 83 96 108 120 133 145 157 169 181

CPU Utilization (%)

Time Elapsed (s)

Two Thread

Four Thread

Figure 14: Proposed framework with pre-loading.

The effects of pre-loading images onto the Cloud

server is illustrated in Figure 14. The CPU utilisation

shows that both applications had made use of

all available computational resources as transitions

between nodes can be observed through CPU%

dipping to 0% as seen in Figure 9 and 8. Successful

migration of the containerised applications to the

cloud node was made possible through the use

of pre-loading the application in the Cloud server,

thereby, allowing the two IoT applications to preform

optimally with higher computational resources. With

comparison to the ﬁrst evaluation made on the

proposed architecture, this evaluation resulted in

around 2-second delay between the Edge node and

Cloud node. The performance of the application

to successfully process faces (images) from the

proposed architecture can be compared against the

traditional approach of running IoT A and IoT B

individually (See Figure 10 and 11).

0 5 10 15

Traditional

Framework

Average Processing Time Required (s)

Figure 15: Comparison: Processing time.

100

200

300

400

500

600

700

Traditional Framework

Total number of

images processed

Figure 16: Comparison: Overall performance.

A comparison can be made between the two

approaches, by comparing the total amount of images

processed and the total processing time. The

proposed architecture is able to outperform the

traditional IoT system in both processing time and

overall performance. This indicates the movement

of nodes between IoT to Edge and Cloud servers are

successful in providing the most optimal environment

for each application to thrive. Figure 15 shows a 10-

second gap between processing averages of the two

systems. Figure 16 presents a 237% increase in total

faces processed through out the three-minute elapsed

time. Further evaluations can be performed to assess

a many-to-many situation where multiple IoT nodes

are sending data to multiple Edge and Cloud servers.

This will provide extra validation for the scalability

for such architectures in real-world applications.

A Framework for Seamless Ofﬂoading in IoT Applications using Edge and Cloud Computing

295

5 CONCLUSIONS

In this paper, a framework for seamless ofﬂoading for

IoT applications using Edge and Cloud computing for

container-based applications was proposed. It aims

to overcome the issues of traditional IoT systems

by utilising a sub-task methodology in deploying

IoT applications for optimal performance under the

proposed architecture. It evaluated in a variety

of scenarios to demonstrate ofﬂoading to Edge

and Cloud resources under load. The evaluation

demonstrated that in real world applications, it

outperforms traditional IoT applications. However,

it is noted that the work presented in this paper is

a proof-of-concept demonstration and further work

is needed. Our work has not yet taken into

account real-world applications that have stringent

real-time latency requirements. Future work will

seek to address these issues and investigate the

seamless integration of the proposed framework, in

particular its ofﬂoading capability with common IoT

development frameworks

REFERENCES

Abdul Majeed, A., Kilpatrick, P., Spence, I., and Varghese,

B. (2019). Performance estimation of container-based

cloud-to-fog ofﬂoading. In Proceedings of the 12th

IEEE/ACM International Conference on Utility and

Cloud Computing Companion, pages 151–156.

Aloi, G., Fortino, G., Gravina, R., Pace, P., and Savaglio,

C. (2020). Simulation-driven platform for edge-based

aal systems. IEEE Journal on Selected Areas in

Communications, 39(2):446–462.

Biswas, A. R. and Giaffreda, R. (2014). IoT and cloud

convergence: Opportunities and challenges. In 2014

IEEE World Forum on Internet of Things (WF-IoT),

pages 375–376. IEEE.

Dinh, T. Q., Tang, J., La, Q. D., and Quek, T. Q.

(2017). Ofﬂoading in mobile edge computing: Task

allocation and computational frequency scaling. IEEE

Transactions on Communications, 65(8):3571–3584.

El-Sayed, H., Sankar, S., Prasad, M., Puthal, D., Gupta, A.,

Mohanty, M., and Lin, C.-T. (2017). Edge of things:

The big picture on the integration of edge, iot and the

cloud in a distributed computing environment. IEEE

Access, 6:1706–1717.

Hwang, R.-H., Lai, Y.-C., and Lin, Y.-D. (2021). Ofﬂoading

optimization with delay distribution in the 3-tier

federated cloud, edge, and fog systems. arXiv preprint

arXiv:2107.05015.

King, C. I. (2017). Stress-ng. URL: http://kernel. ubuntu.

com/git/cking/stressng. git/(visited on 28/03/2018).

Kua, J., Armitage, G., and Branch, P. (2017). A survey

of rate adaptation techniques for dynamic adaptive

streaming over http. IEEE Communications Surveys

Tutorials, 19(3):1842–1866.

Lee, K., Murray, D., Hughes, D., and Joosen, W. (2010).

Extending sensor networks into the cloud using

amazon web services. In 2010 IEEE International

Conference on Networked Embedded Systems for

Enterprise Applications, pages 1–7. IEEE.

Liu, J. and Zhang, Q. (2018). Ofﬂoading schemes in

mobile edge computing for ultra-reliable low latency

communications. IEEE Access, 6:12825–12837.

Lorido-Botran, T., Miguel-Alonso, J., and Lozano, J. A.

(2014). A review of auto-scaling techniques for elastic

applications in cloud environments. Journal of grid

computing, 12(4):559–592.

Mach, P. and Becvar, Z. (2017). Mobile edge comput-

ing: A survey on architecture and computation of-

ﬂoading. IEEE Communications Surveys & Tutorials,

19(3):1628–1656.

Milojicic, D. (2020). The edge-to-cloud continuum.

Computer, 53(11):16–25.

Olorunnife, K., Lee, K., and Kua, J. (2021). Automatic fail-

ure recovery for container-based iot edge applications.

Electronics, 10(23):3047.

Pan, J. and McElhannon, J. (2017). Future edge cloud and

edge computing for internet of things applications.

IEEE Internet of Things Journal, 5(1):439–449.

Sardellitti, S., Scutari, G., and Barbarossa, S. (2015). Joint

optimization of radio and computational resources for

multicell mobile-edge computing. IEEE Transactions

on Signal and Information Processing over Networks,

1(2):89–103.

Taherizadeh, S. and Stankovski, V. (2017). Auto-scaling

applications in edge computing: Taxonomy and

challenges. In Proceedings of the International

Conference on Big Data and Internet of Thing,

BDIOT2017, page 158–163, New York, NY, USA.

Association for Computing Machinery.

Taivalsaari, A., Mikkonen, T., and Pautasso, C. (2021).

Towards seamless iot device-edge-cloud continuum.

In International Conference on Web Engineering,

pages 82–98. Springer.

Wu, S., Niu, C., Rao, J., Jin, H., and Dai, X. (2017).

Container-based cloud platform for mobile computa-

tion ofﬂoading. In 2017 IEEE International Paral-

lel and Distributed Processing Symposium (IPDPS),

pages 123–132.

Zhang, T. (2018). Data ofﬂoading in mobile edge

computing: A coalition and pricing based approach.

IEEE Access, 6:2760–2767.

Zheng, W.-S. and Yen, L.-H. (2019). Auto-scaling in

kubernetes-based fog computing platform. In Chang,

C.-Y., Lin, C.-C., and Lin, H.-H., editors, New Trends

in Computer Technologies and Applications, pages

338–345, Singapore. Springer Singapore.

IoTBDS 2022 - 7th International Conference on Internet of Things, Big Data and Security

296
