Bypassing Current Limitations for Implementing a Credential

Delegation for the Industry 4.0

Santiago de Diego

, Óscar Lage

, Cristina Regueiro

, Sergio Anguita

and Gabriel Maciá-Fernández

Trustech Department, TECNALIA, Basque Research and Technology Alliance (BRTA), Derio, Spain

Department of Signal Theory, Telematics and Communications, University of Granada, Granada, Spain

Keywords: IIoT, Identity Management, SSI, Verifiable Credentials.

Abstract: Industry 4.0 is set to modernize industrial processes as we know them today. This modernization goes hand

in hand with the digitalization of industry and the need to digitally identify the different devices involved in

the manufacturing process. Verifiable credentials and Decentralized Identifiers, which are part of the self-

sovereign identity (SSI) concept, allow decentralized identification and characterization of the devices

(commonly IIoT devices) that make up Industry 4.0. However, some use cases in the Industry 4.0 cannot be

modelled with standard SSI schemes. Despite the fact that delegated credentials have been defined in the

W3C standard for verifiable credentials, current technologies present some important limitations that make

them non-implementable. This paper analyses these limitations in the context of the problem of building

delegated credentials for the Industry 4.0, and proposes an alternative based on an Hyperledger Aries RFC,

bypassing these limitations. Finally, some implementation tests have been conducted in order to demonstrate

that the Aries RFC does not add extra complexity in terms of performance to the normal SSI flow.

1 INTRODUCTION

The Fourth Industrial Revolution, also commonly

known as Industry 4.0, implies a drastic change in

current processes. From the manufacturing side,

digitalization plays a crucial role, enabling the so-

called intelligent industry (Preuveneers & Ilie-Zudor,

2017) because a high level of automation is required

to reduce costs to the levels offered by the mass-

production paradigm.

Solutions based on the self-sovereign Identity

(SSI) framework, where verifiable credentials (VCs)

(W3C, 2021) and decentralized identifiers (DIDs)

(Reed et al., 2021) are utilized in combination with

blockchain and are potentially adequate for

empowering the Industry 4.0.

The characteristics of a certain manufacturing

process, such as the compliance with a standard, are

received by different elements manufactured by one

https://orcid.org/0000-0002-8823-7509

https://orcid.org/0000-0003-1168-1932

https://orcid.org/0000-0002-6031-9449

https://orcid.org/0000-0001-5517-7645

https://orcid.org/0000-0001-9256-453X

or several factories. In this way, the manufactured

element also complies with the standard that the

manufacturing process complies with. In other words,

the property that the process complied with was

received by the elements manufactured in it. It would

be much more complex to model this example

without using the concept of delegation.

Delegated credentials refer to credentials which

allow the user to delegate some of his attributes to

another user and is a term recognised by numerous

authors (as shown in the State of the Art section), as

well as the W3C standard for VCs (W3C, 2021). At

the same time, this delegated credential scheme

presents challenges in terms of issuing, verifying, and

revoking credentials in a chain.

Although the VCs model proposed by the W3C

standard defines certain high-level guidelines that can

be used for creating delegated credentials, it does not

go deep into: i) Providing implementation guidelines

de Diego, S., Lage, Ó., Regueiro, C., Anguita, S. and Maciá-Fernández, G.

Bypassing Current Limitations for Implementing a Credential Delegation for the Industry 4.0.

DOI: 10.5220/0011136600003283

In Proceedings of the 19th International Conference on Security and Cryptography (SECRYPT 2022), pages 485-490

ISBN: 978-989-758-590-6; ISSN: 2184-7711

485

for the issuance of delegated credentials. As it will be

analysed in Section 4, most of technologies do not

currently support this approach; ii) Detail how to deal

with effective verification of delegated credentials.

This paper improves the current body of

knowledge by three contributions. First, it compares

and analyses two different approaches for the

implementation of delegated credentials; second, it

identifies possible incompatibilities when

implementing delegated credentials with current SSI

technologies; finally, it provides some

implementation guidelines to implement the

complete flow of a delegated credential.

2 STATE OF THE ART

The SSI paradigm has been broadly studied in the

context of Internet of Things (IoT) environments.

Some authors (Fedrecheski et al., 2020 ; Mahalle et

al., 2020) have deepen on it, presenting own

proposals for decentralized identifiers (DIDs) and

VCs for the IoT. Most of these works prove that SSI

is a better method for identifying IoT devices than

other traditional schemes, such as using X.509

certificates. Some authors (Bartolomeu et al., 2019)

provide an overview of some SSI concepts and

present use cases for the IIoT. Other authors (Niya et

al., 2020) have proposed an identification system

based on SSI that uses unique information from each

IoT device to identify it. In addition, others

(Kortesniemi et al., 2019) go further by proposing the

use of DIDs as decentralized identifiers for IoT

devices and studying the requirements that these

devices must meet in order to run an identity

management system based on SSI. If these devices

are extremely constrained, a proxy-based approach

gives support to the solution.

One of the common current issues when

implementing SSI solutions is the lack of maturity of

SSI technologies (Fedrecheski et al., 2020); the W3C

guidelines are clear, but each technology follows its

own development roadmap, which may

overcomplicate the implementation of SSI-based

solutions.

Regarding implementations of SSI, only few SSI-

enabling technologies are currently outstanding,

including Hyperledger Indy (Windley, 2018) and

Hyperledger Aries (Hyperledger Aries, 2020),

Veramo (2021)), Veres One (2022), Jolocom (2019),

which have different levels of maturity. Indy and

Aries have a strong development team supporting

them and they are the most mature implementations,

followed by Veramo, although they have some

unfinished aspects, as it will be seen later in this

paper.

Finally, focusing on the credential delegation

concept, some works refer to it. The one in Belenkiy

et al. (2009) is likely to be the first work introducing

delegated credentials, resulting in a non-feasible

implementation mainly due to its complexity,

similarly as happened with Chase et al. (2013), as

both depend on Groth-Sahai proofs. Camenisch et al.

(2017) presented a delegated credentials scheme

where the VC is directly passed to a new user that

receives delegated permissions to issue new

credentials. Then, this issuer can generate copies of

this credential, but then signed by himself. Thus, for

every credential, he has two instances: the original

and the copy. This approach is also suggested by the

W3C standard in section C.5. This standard will be

discussed in Section 5. Other posterior works

(Blömer & Bobolz, 2018; Crites & Lysyanskaya,

2019) study different schemes for delegating

credentials, but they are not exempt from limitations;

the first scheme does not allow to read the whole

delegation history of a credential, while the second is

not compatible with adding more attributes to the

original credential, which automatically invalidate

them for implementing the whole credential

delegation framework. Finally, Hyperledger Aries

has proposed an RFC with his own method for

delegated credentials, termed chained credentials

(Hardman & Harchandani, 2021). This method will

be also analysed in the next section and we will refer

to it as Aries RFC.

3 DELEGATED CREDENTIALS

Initially, let us consider that there is a certification

entity that issues a credential to another actor, a

manufacturer. Here, following the SSI approach, the

certification entity is acting as an issuer, and the

manufacturer, as a holder. The certification entity

would certify that a manufacturer's product complies

with a certain standard (for example, ISO9001), so it

sends to the manufacturer a VC that provides

evidence that the manufacturer does indeed comply

with this standard. The manufacturer desires to

certify some of his devices, claiming that they comply

with the standard. However, the manufacturer only

wants to certify the devices that belong to a certified

product line, specified by the certification entity. In

other words, not all devices are eligible for receiving

the credential. In this case, the certification entity

must delegate the certification to the manufacturer,

who will issue a VC to his devices. The manufacturer

SECRYPT 2022 - 19th International Conference on Security and Cryptography

486

is in this case acting as a delegator, and the device as

a delegate. It is also desirable that the certification

entity can express the scope in which this delegation

is made. In this context, this credential is termed as

delegated credential.

In what follows we analyse W3C standard (W3C,

2021) and the Aries RFC (Hardman & Harchandani,

2021) approaches for building and working with

delegated credentials. The W3C standard specifies

how delegation must be implemented, while the Aries

RFC provides a proposal for delegated credentials,

compliant with the W3C.

W3C Standard.

The W3C standard proposes

expressing the relationship between the delegator and

the delegate using a relationship credential (RC).

Hence, the verifier should accept a VP if it includes a

delegated credential and the corresponding

relationship between the delegate and the delegator.

Often, the delegated credential is transferred to the

new subject so he can present it together with a copy

of this credential, where the issuer is the

manufacturer and the subject is the device; and/or a

relationship credential, which expresses this

relationship. The general flow for the W3C proposal

has been summed up in Figure 1, where the

manufacturer is delegating a VC to the device. Hence,

the verifier can ask for a proof directly to the device.

Finally, it is worth to mention that W3C proposes

the use of their own credentials, known as W3C

credentials, which intend to be a standard for VCs.

This fact will be important when discussing the

implementation issues in Section 4.

Figure 1: General flow in the W3C standard for delegated

credentials.

Aries RFC. Aries proposes, in a Request For

Comments (RFC), the creation of a field in the VC

containing the VP of the delegated credential, DC. In

other words, it proposes including a VP into a VC.

Consequently, it proposes creating a chain of trust

where the different VPs of the different delegated

credentials are attached in a field of the VC, called

provenanceProofs. The verifier then can verify the

VPs included in the VC and therefore accept or reject

them if all these proofs are either valid or not. The

complete flow of the Aries RFC adapted to the

proposed industrial use case is shown in Figure 2.

Comparative Analysis. Regarding privacy, both the

W3C and the Aries RFC have their privacy

drawbacks. There is a risk of privacy loss when a

holder stores another-subject credential, as the W3C

proposes. This has also been noted from the research

community. For example, some authors (Lim et al.,

2021) recognized the possibility of a loss of control

when the subject delegates a credential to another

holder; therefore, an authentication mechanism based

on public key cryptography is proposed for VCs.

However, the verification process becomes

complicated because VCs need to be ciphered, and the

authors also recognize some drawbacks with this

design, e.g., this design is not fully compatible with

selective disclosure in VCs. There is also a privacy loss

in the Aries RFC because the VP is included in the

credential, so the verifier has access to all the fields

through the VP. However, we consider that it is a better

alternative in terms of privacy because the credential is

still under the control of his original holder.

The W3C approach might also lead to certain

security risks when implemented. In this approach, the

verifier infers that a group of credentials are related

when they are presented together. Therefore, devices

could steal other credentials from the manufacturer

and present them with the same relationship

credential, which would ultimately make the verifier

accept this credential as valid. In other words, without

verifying the original credential against the

manufacturer, the sole existence of a relationship

credential does not guarantee full security. Aries RFC

does not have this risk because the holder only presents

one credential containing all the information.

However, this design comes with its own drawbacks.

By including VPs into VCs, their size is increased,

leading into extremely big credentials.

Figure 2: Complete flow for the Aries RFC proposal.

Bypassing Current Limitations for Implementing a Credential Delegation for the Industry 4.0

487

4 ANALYSIS OF CURRENT

IMPLEMENTATIONS

From the state of the art, it is conveyed that both

Veramo and Hyperledger Indy/Aries are the most

advanced technologies for implementing SSI

solutions. The implementation of delegated

credentials following the W3C standard should be

straightforward because all technologies should have

support for this type of credentials. However, this is

not always true, as some technologies have their own

way to implement the standard and some operations,

although they are standard-compliant, might not be

supported by specific technologies. To validate this

assertion, we have carried out some implementation

analysis using some technologies, and the

conclusions are as follows.

Hyperledger Indy and Hyperledger Aries. A first

consideration is related to the Indy wallet. Indy agents

do not support storing VCs in the wallet if the subject

is different from the holder of the credential. This is

a technical limitation of Indy-based credentials,

which assume that the holder and the subject are

always the same person. Indy-based credentials do

not have a subject field, because they are linked to

their holder, who is also the subject. Consequently, it

is not possible for a delegated holder to generate

verifiable presentations (VP) based on these

credentials and, thus, we can deduce that Indy is not

compatible with the W3C standard. Regarding Aries

wallet, specifically when Indy credentials are used, it

simply inherits all the indicated limitations from Indy.

However, Aries has recently added support for W3C

credentials, which allows to create delegated

credentials following the W3C standard.

A second consideration is related to the verification

process when the W3C approach is used in Aries.

First, it is necessary to implement an additional

verification logic to tell the verifier that he needs to

iterate over the original credentials and check the

existence of another credential, which represent the

relationship between the holder and the subject,

before discarding a VP containing a VC whose

subject is different from his holder. It clearly adds

extra complexity when it comes to implementing this

protocol. Consequently, it is necessary to make

considerable changes within the Indy/Aries code to

support this functionality.

Regarding the Aries RFC, Indy currently supports

this approach because there is no need to store

credentials whose holder is different from the subject.

Thus, it is compatible with Indy-based credentials.

However, Hyperledger Aries must be adapted to

support the Aries RFC because his verification

method uses sequence numbers to link the proof

request with the rest of the verification process, which

does not allow to send the VP, store it and verify it

later. This can be indeed useful in order to prevent

from replay attacks. By linking the proof request with

the rest of the verification process we avoid that a

malicious user can reuse the same proof request to

obtain the verifiable presentation once and again.

This mechanism should be implemented by other

technologies to prevent this kind of scenarios.

Veramo. Veramo does not present some of the issues

that Indy and Aries have. In particular, in Veramo, it

is possible that devices store any VC as there are no

limitations when it comes to storing credentials

whose subject is different from the holder. This is

because Veramo natively works with W3C

credentials. This adds more flexibility to Veramo

against Indy and Aries. However, regarding the

verification process, it is also necessary to implement

the same logic in Veramo to properly implement the

delegation flow, so some changes need to be made in

the source code to do that. Furthermore, Veramo is

still in an early stage of development.

Regarding the Aries RFC, it is currently

implementable in Veramo, as well as in Hyperledger

Indy. Furthermore, Veramo does not implement any

sequence numbers between verification steps as Aries

does. This can lead to replay attacks as discussed

before

Other Technologies. Other technologies, such as

those described in the state-of-the-art section, have

the same issues. Veres One is still in an early stage of

development and the documentation regarding

implementation guidelines for VCs is very limited.

Jolocom presents a higher maturity level than Veres

One, but it still needs to adapt the verification method

to support the W3C standard. Regarding the Aries

RFC, it is implementable by Jolocom.

Table 1: Mapping between SSI technologies and the W3C

(W) and Aries RFC (R).

Support

other-subject

VCs

Support

verification

method

Overall

maturity

Indy R R High

Aries W R High

Veramo W R R Medium

Veres one Low

Jolocom W R R Medium

SECRYPT 2022 - 19th International Conference on Security and Cryptography

488

Table 1 maps the current technologies with the

W3C standard and the Aries RFC approach regarding

delegated credentials. As shown, Aries RFC is

supported by most technologies. The overall maturity

was determined based on the documentation available

for these technologies.

5 PERFORMANCE EVALUATION

Here some results from a performance evaluation of

an implementation of delegated credentials based on

Hyperledger Indy with the Aries RFC approach are

presented. Indy has been chosen instead of Aries so

that the described problem of sequence numbers in

Aries (see Section 4) is circumvented. Furthermore,

Indy is currently more mature than Veramo or

Jolocom.

An Indy client that implements the delegation has

been implemented in python. A private testing Indy

network with four nodes running in a single VM has

been deployed as VDR to test the client. The

implementation includes these steps: 1) A

certification entity creates and stores a Credential

Schema and an associated Credential Definition; 2)

The certification entity issues a delegated credential

to a manufacturer with the Credential Definition; 3)

A verifier verifies the delegated credential from the

manufacturer; 4) The manufacturer creates and

stores a Credential Schema and a Credential

Definition for a new VC; 5) The manufacturer creates

a VP based on his delegated credential and sends the

new VC to the device, which embeds the VP in an

attribute; 6) The verifier verifies this new VC; 7) The

verifier verifies the VP embedded in the VC.

The proposed implementation uses a set of three

attributes for the new VC, which are: i)

provenanceProofs: it stores the VP of the delegated

credential; ii) provenanceSchemas: it stores the

credential schema of the delegated credential; iii)

ProvenanceDefinitions: it stores the credential

definition of the delegated credential.

The provenanceProofs attribute solves the

problem of storing a VC with a different subject in the

wallet and avoid generating a VP based on this VC,

which is not possible as discussed in Section 4. The

provenanceSchemas and ProvenanceDefinitions

attributes eliminate the necessity of querying the

VDR and make the VP self-contained. Additionally,

another attribute could be added to control the usage

of the delegated credential.

For this purpose, a nonTransferable attribute with

a Boolean true/false value is used to indicate that this

credential cannot be delegated. The nonTransferable

property is proposed by the W3C and indicates that a

VC must only be encapsulated into a verifiable

presentation whose proof was issued by the credential

subject. This model can be extended by adding as

many attributes as required for more complex

scenarios. The labels proposed by Aries RFC are

considered to act as separators between different

elements and help to retrieve them when required.

Thus, we use [proof], [schema] and [definition]

labels to separate them.

Regarding the performance evaluation, the main

interest was to analyse if the proposed delegation

mechanisms impact in the performance when

compared with a scenario without delegation. The

latter scenario does not include an embedded VP into

the VC and changing the step 7 by a standard

verification against the manufacturer.

A Dell Latitude 5580 equipped with an Intel®

Core™ i7-7600U and 8GM of RAM memory has

been used to conduct the tests. For simplicity, all

actors are running in the same machine, so network

latency does not apply. The experiment has been

conducted 400 times and it measures the time spent

with and without delegation. The results are shown in

Table II. The Proof of Concept (PoC) with delegation

corresponds to the seven steps described above, while

the PoC without delegation corresponds to the normal

Indy flow, which can be found in the Indy

documentation.

As seen in Table II, there are not significant

differences in terms of performance, so any system

supporting the normal Indy flow should support

delegation as well with nearly insignificant impact in

the performance.

Table 2: Experimental results.

Test Measure Value

PoC with delegation Avera

e 32,73 seconds

sdv 8,63 seconds

PoC without

delegation

Avera

e 32,49 seconds

sdv 7,53 seconds

6 CONCLUSIONS

This paper has presented the concept of verifiable

credential delegation for the Industry 4.0 and has also

compared the W3C standard and the Aries RFC

proposal for delegated credentials. As it has been

analysed, the technologies that allow implementing

SSI solutions are not always fully compatible with the

W3C standard, which may require minor and, in some

of them, major adaptations. The present work has

revealed this reality, and some implementation-

Bypassing Current Limitations for Implementing a Credential Delegation for the Industry 4.0

489

related drawbacks have been presented. Finally, a

Proof of Concept about delegated credentials has

been implemented following the Aries RFC proposal,

which avoids some implementation issues for most

technologies and presents better characteristics in

terms of privacy.

ACKNOWLEDGEMENTS

This work has been supported by Izertis through the

SSI4.0 project, which is a collaborative project co-

funded by the Department of Economic

Development, Sustainability and Environment of the

Vice-Ministry of Technology, Innovation and

Competitiveness of the Basque Government within

the HAZITEK program. (File: ZE-2020/00020).

This work has also been partially supported by

Spanish Government-Ministry of Science and

Innovation through project SICRAC (PID2020-

114495RB-I00).

REFERENCES

Preuveneers, D., & Ilie-Zudor, E. (2017, April). The

intelligent industry of the future: A survey on emerging

trends, research challenges and opportunities in

Industry 4.0. Journal of Ambient Intelligence and Smart

Environments, 9(3), 287-298.

W3C. (2021, November). Verifiable Credentials Data

Model 1.1: Expressing Verifiable Information on the

Web. https://www.w3.org/TR/vc-data-model/.

Accessed on: Feb 21, 2022.

Reed, D., Sporny, M., Longley, D., Allen, C., Grant, R.,

Sabadello, M., & Holt, J. (2021, August). Decentralized

identifiers (DIDs) v1. 0. Draft Community Group

Report. [Online]. Available: https://www.w3.org/TR/

did-core/. Accessed on: Feb 21, 2022.

Fedrecheski, G., Rabaey, J. M., Costa, L. C., Ccori, P. C.

C., Pereira, W. T., & Zuffo, M. K. (2020, June). Self-

sovereign identity for IoT environments: a perspective.

In 2020 Global Internet of Things Summit (GIoTS) (pp.

1-6). IEEE.

Mahalle, P. N., Shinde, G., & Shafi, P. M. (2020, February).

Rethinking decentralised identifiers and verifiable

credentials for the Internet of Things. In Internet of

Things, Smart Computing and Technology: A

Roadmap Ahead (pp. 361-374). Springer, Cham.

Bartolomeu, P. C., Vieira, E., Hosseini, S. M., & Ferreira,

J. (2019, September). Self-sovereign identity: Use-

cases, technologies, and challenges for industrial IoT.

In 2019 24th IEEE International Conference on

Emerging Technologies and Factory Automation

(ETFA) (pp. 1173-1180). IEEE.

Niya, S. R., Jeffrey, B., & Stiller, B. (2020, November).

KYoT: Self-sovereign IoT Identification with a

Physically Unclonable Function. In 2020 IEEE 45th

Conference on Local Computer Networks (LCN) (pp.

485-490). IEEE.

Kortesniemi, Y., Lagutin, D., Elo, T., & Fotiou, N. (2019,

March). Improving the privacy of IoT with

decentralised identifiers (DIDs). Journal of Computer

Networks and Communications, 2019.

Windley, P., & Reed, D. (2018, January). Sovrin: A

protocol and token for self-sovereign identity and

decentralized trust. Whitepaper, The Sovrin

Foundation.

Hyperledger Aries. (2020). [Online]. Available:

https://github.com/hyperledger/aries. Accessed on: Feb

21, 2022.

Veramo – Performant and modular APIs for Verifiable Data

and SSI. 2021. [Online]. Available: https://veramo.io/.

Accessed on: Feb 21, 2022

Veres One - A Globally Interoperable Blockchain for

Identity. 2022. [Online]. Available: https://veres.one/.

Accessed on: Feb 21, 2022.

Jolocom - A Decentralized, Open Source Solution for

Digital Identity and Access Management. [Online].

2019. Available: https://jolocom.io/wp-content/

uploads/2019/12/Jolocom-Whitepaper-v2.1-A-

Decentralized-Open-Source-Solution-for-Digital-

Identity-and-Access-Management.pdf. Accessed on:

Feb 21, 2022

Belenkiy, M., Camenisch, J., Chase, M., Kohlweiss, M.,

Lysyanskaya, A., & Shacham, H. (2009, August).

Randomizable proofs and delegatable anonymous

credentials. In Annual International Cryptology

Conference (pp. 108-125). Springer, Berlin,

Heidelberg.

Chase, M., Kohlweiss, M., Lysyanskaya, A., & Meiklejohn,

S. (2013, March). Malleable Signatures: Complex

Unary Transformations and Delegatable Anonymous

Credentials. IACR Cryptol. ePrint Arch., 2013, 179.

Camenisch, J., Drijvers, M., & Dubovitskaya, M. (2017,

October). Practical UC-secure delegatable credentials

with attributes and their application to blockchain. In

Proceedings of the 2017 ACM SIGSAC Conference on

Computer and Communications Security (pp. 683-699).

Blömer, J., & Bobolz, J. (2018, July). Delegatable attribute-

based anonymous credentials from dynamically

malleable signatures. In International Conference on

Applied Cryptography and Network Security (pp. 221-

239). Springer, Cham.

Crites, E. C., & Lysyanskaya, A. (2019, March).

Delegatable anonymous credentials from mercurial

signatures. In Cryptographers’ Track at the RSA

Conference (pp. 535-555). Springer, Cham.

Hardman D., Harchandani, L. Aries RFC 0104: Chained

Credentials. (2021). [Online]. Available: https://github.

com/hyperledger/aries-rfcs/tree/main/concepts/0104-

chained-credentials. Accessed on: Feb 21, 2022

Lim, S., Rhie, M. H., Hwang, D., & Kim, K. H. (2021,

January). A Subject-Centric Credential Management

Method based on the Verifiable Credentials. In 2021

International Conference on Information Networking

(ICOIN) (pp. 508-510). IEEE.

SECRYPT 2022 - 19th International Conference on Security and Cryptography

490
