Application Sandboxing for Linux Desktops: A User-friendly Approach

Lukas Brodschelm and Marcus Gelderie

Department of Electrical Engineering and Computer Science, Aalen University of Applied Sciences,

Beethoven Str 1, Aalen, Germany

Keywords:

Sandbox, Linux, Desktop, User-Friendly, Usability, Security.

Abstract:

Sandboxes are a proven tool to isolate processes from the overall system. Although desktop computers face

signiﬁcant risks, there is no widely adopted way to use sandboxes on the Linux desktops, since sandboxing

on desktop PCs is more challenging. We name the speciﬁc challenges for the Linux desktop and derive

requirements that we argue are essential for widespread adoption of any sandbox solution. We then introduce

a concept to isolate Linux desktop software using UIDs and GIDs as well as namespace-based sandboxes.

Furthermore, we provide a PoC implementation including sandbox proﬁles for example applications. Based

on this, we conducted a survey to assess the usability of our sandboxing concept. We report on the results,

analyze the security of our concept, and detail how our sandbox meets the aforementioned requirements.

1 INTRODUCTION

The IT security of individual systems is an important

and active research area. General solutions are difﬁ-

cult, since the needs of a system depend highly on the

way it is being used. The desktop setting is particu-

larly challenging and users make mistakes. As such,

desktop PCs are a common entry point for malware

into corporate networks (Waterson, 2020). On a desk-

top system, many different applications run within the

context of a single user account: A single vulnerable

program might gain access to all data and processes

that belong to the account. This extends an attacker’s

sphere of inﬂuence considerably, once the initial com-

promise has been made.

On Windows, much has been done in the way of

hardening the desktop setting against attacks. Manda-

tory Integrity Control (MIC), Control Flow Guard,

and User Account Control (UAC) – to name only a

few – (Yosifovic et al., 2017). Unlike Windows, the

Linux desktop has to date not seen widespread adop-

tion of a similarly comprehensive desktop hardening

strategy. We hypothesize that, to be adopted a se-

curity feature must meet usability characteristics (cf.

section 3.1).

Our contribution in this paper is a container based

architecture, that separates individual apps users run

on their desktop and respects usability aspects. We

demonstrate the feasibility of this architecture using a

PoC implementation and showcase how it addresses

the issues given in section 3.1. Finally, we evaluate

the usability of our solution with the target user group

in the form of survey. Our approach can serve as the

ﬁrst step in an incremental strengthening of the stan-

dard Linux desktop.

Related Work. In related work, much research

has been devoted to the development of sandboxes,

speciﬁcally those based on containers. We group our

treatment of related work into categories.

Secure Operating Systems: Secure operating sys-

tems that also enforce trust boundaries between appli-

cations, like Cubes, Whonix and SubgraphOS, have

been developed (The Qubes OS Project and others,

2022; ENCRYPTED SUPPORT LP, 2022; Subgraph,

2014). They all use launchers to run applications in

there own isolated environment, enforced either by

virtual machines or container based sandboxes. In

contrast our sandbox provides restricted, but direct ac-

cess to the host ﬁle system and user’s home directory.

The Android platform security model (Mayrhofer

et al., 2021; Android Open Source Project, 2021)

follows a different approach where applications are

aware of the sandbox and need to use speciﬁc APIs

to request access to resources. Android meets our us-

ability requirments but requires cooperation from ap-

plications. Our solution borrows from the Android

model in that we also run applications with dedicated

user IDs. However we do not require cooperation

from the sandboxed applications.

Brodschelm, L. and Gelderie, M.

Application Sandboxing for Linux Desktops: A User-friendly Approach.

DOI: 10.5220/0011145800003283

In Proceedings of the 19th International Conference on Security and Cryptography (SECRYPT 2022), pages 317-324

ISBN: 978-989-758-590-6; ISSN: 2184-7711

317

Containers and Container Based Sandboxes:

Many implementations of sandboxes and containers

exist. Depending on the exact deﬁnition of a sandbox,

any container runtime, like runc (Open Container Ini-

tiative , 2022) or Firecracker (Agache et al., 2020)

can be considered a sandbox. However, typically we

mean designs speciﬁcally targeting security by this

term. Examples for such systems are Bubblewrap and

Firejail (Containers Community, 2016; Firejail Con-

tributers, 2020). They do not cater to any speciﬁc

use-case and instead of enforcing access models the

goal of these sandboxes is to isolate one given appli-

cation. They operate at a lower level than what we

try to achieve with the proposed desktop sandboxing

scheme. Indeed, our design uses Bubblewrap as a

building block. In fact, our sandboxing scheme can

be thought of a way to automatically conﬁgure Bub-

blewrap in a desktop session.

In scientiﬁc research container based sandboxes

have studied extensively (B

elair et al., 2019; Khal-

imov et al., 2019; Anjali et al., 2020; Agache et al.,

2020). The aim of the research is diverse and cov-

ers aspects like kernel interactions, shielding the host

from the workloads and deployment aspects. But in

all these works, the focus is not on desktop systems.

An exception are container based sandboxes for new

application domains, such as malware analysis (Khal-

imov et al., 2019). Here, the focus is on running

suspected-malicious binaries, where near total isola-

tion, erring on the side of caution, is paramount. A

multipurpose concept is TxBox, it relies on monitor-

ing and reverting changes to the kernel state through

system calls from sandboxed applications (Jana et al.,

2011). TxBox requires a modiﬁed kernel, which is

difﬁcult to align with our goal of supporting arbitrary

Linux distributions (section 3.2).

Software distribution and deployment also lever-

ages container sandboxes. Examples are Flatpak and

Snapd (Flatpak Team, 2018; Canonical Ltd., 2022).

Both use container technologies to run the shipped

applications within a dedicated ﬁle system. When

conﬁgured right, they are secure but different to our

approach they ship entrie or partial root-ﬁle-systems

for the applications and they are bound to a package

manager. Furthermore administrative privileges are

required to modify the conﬁguration, which is con-

trary to our goals.

2 PRELIMINARIES

Linux Namespaces (NS) are kernel features provid-

ing isolated abstraction layers for system resources

(Linux Manpage Team, 2021). There are eight types

of NS, but we only mention user namespaces (user

NS) in this paper, which provide isolation of UIDs,

GIDs, and other security-related attributes such as ca-

pabilities. Our treatment of namespaces glosses over

several details, but is sufﬁcient to follow the remain-

der of this paper.

When a process with UID u creates a user NS, that

NS is owned by u. This means that any process with

UID u holds all capabilities inside the NS. Once in-

side the NS, such a process holds CAP SETUID can al-

ter its UID to any one of the UIDs mapped inside the

NS. The UID mapping is a translation of UIDs inside

to UIDs outside (host UIDs). In the simplest case, it

translates UID 0 to UID u and no other UIDs exist

inside the NS. This is called a trivial map. For a non-

trivial map to be deﬁned, a privileged process outside

must deﬁne the map. The setuid binary newuidmap

can be used to do this as an unprivileged user while

restricting the user to a permitted range of host UIDs.

On the Linux desktop, applications are typically

launched via a menu item or a launcher tool (such

as rofi, dmenu or the like). All these tools support

using desktop entries to launch applications. Desk-

top entries are conﬁguration ﬁles that provide infor-

mation on how to start applications (CLI arguments,

environment variables etc). Most desktop environ-

ments support desktop entries (Brown et al., 2020)

and provide them for most graphical user interface

software. It is possible to shadow system-wide desk-

top entries by providing a ﬁle of the same name in-

side a location in the user’s home directory (usually

˜/.local/share/applications).

Access control systems enforce trust boundaries

and deﬁnes rules for data ﬂow between them. There

are many different ways of approaching access con-

trol models known from standard literature (Ander-

son, 2020). Two that have traditionally been very

popular are the hierarchical model, which dates back

to (Bell, 1975; Biba, 1975) and is the basis of Mi-

crosoft’s “Mandatory Integrity Control”. Another

is the type enforcement (TE) model (Badger et al.,

1996), which is successfully deployed on many sys-

tems in the form of SELinux.

In the hierarchical access control model resources

and applications are assigned levels from “untrusted”

to “trusted” and only processes in levels that are at

least as high as the one of a resources may access

them. In the type enforcement mode, one instead as-

signs types to resources and domains to processes. A

policy then speciﬁes, which types may be accessed by

a domain, and how one domain may transition into

another domain (such as by executing another pro-

gram).

A type may contain many resources but a resource

SECRYPT 2022 - 19th International Conference on Security and Cryptography

318

is associated with exactly one type. A domain may

access many types – a one to many association. The

communication between applications, and which ap-

plication is allowed to launch other applications, is

deﬁned by a domain to domain relation.

3 SANDBOXING ON DESKTOP

SYSTEMS

Sandboxes can be used in many different scenarios

and as such will serve different needs in different de-

ployment scenarios. We focus on desktop use cases,

where one or many users interact with a personal

computer or laptop via a graphical user interface. In

these situations, it is difﬁcult to predict the software

that is installed or the precise conﬁguration in which

the system is used. While true on desktop systems

in general, this observation is particularly relevant to

the GNU/Linux ecosystem with its variety of distri-

butions and desktop environments.

3.1 Observations

We highlight the main aspects of the Linux desktop

(or desktop systems in general) that are, in our view,

relevant to designing a user-friendly, yet reasonably

secure sandboxing solution for the desktop:

Choice of Software. Linux users expect to be able

to install software of their choice and work with that

software. This is true for the Linux distribution it self,

but also for installed software.

Unknown Workﬂow. Users are unlikely to accept

security mechanisms that require them to change their

workﬂow, but users work in different ways. This man-

ifests in different folder layouts, different interactions

between tools, and so forth.

Out of the Box Functionality. Most users expect,

that software on their system works out of the box in

most cases. They usually do not want to make manual

conﬁgurations to obtain basic functionality. This is

true, in particular, for security measures.

Multi-User Systems. Desktop systems are occasion-

ally used by multiple users (such as in an ofﬁce setting

or at home). A sandboxing solution must support this

use-case and uphold the separation between accounts.

Rootless. Sometimes, users do not have administra-

tive rights on their machine (e.g. when computers are

part of a laboratory setup or when they are centrally

managed by an organization’s IT department).

3.2 Requirements

From these observations, we derive the following us-

ability requirements that a sandbox must meet in or-

der to be accepted by the user. The sandbox must be:

R1 Able to support any application in principle.

R2 Able to Co-exist and even interact with unsand-

boxed applications.

R3 Amendable to support new applications and self-

developed software in particular.

R4 Provided as an additional application, that can be

installed using the package manager of any stan-

dard Linux distributions.

R5 Customizable to accommodate user’s preferred

workﬂow.

R6 Conﬁgurable. This must be easy and not require

administrative privileges.

R7 Provided with predeﬁned proﬁles for most com-

mon applications.

R8 Able to support multi-user environments.

R9 Transparent as possible to users and once conﬁg-

ured not require their attention.

In addition to the requirements above, the soft-

ware must be secure in the following threat model:

Threat Model. We assume that an adversary has full

control of a process P on the desktop system. This

means that the adversary can execute arbitrary code

within the context of that process, read all of that pro-

cess’s memory and access any system resource that

process can access.

Note that in the traditional Linux security model,

if an adversary has full control over a process run-

ning as some user, the adversary has full control over

the entire desktop session of that user: All ﬁles are

accessible, and all processes can be signaled. Permis-

sion to trace processes is typically restricted by the

Yama LSM, but this need not be the case and usually

permits tracing of descendent processes. We aim to

strengthen security in that the adversary is restricted

to only those parts of the session that the benign code

within that process would have legitimately had ac-

cess to.

4 SANDBOXING CONCEPT

In this section we outline the access control model

we use for our proposed sandboxing solution and de-

scribe how we implement that model for any recent

Linux kernel (i.e. one that supports required functions

for unprivileged user NS).

Application Sandboxing for Linux Desktops: A User-friendly Approach

319

Note that these models are usually seen in the con-

text of mandatory access control, but we are not build-

ing a MAC system in the traditional sense. Instead,

we devise a policy that is built on these models and

which can be enforced using discretionary access con-

trol in conjunction with standard Linux sandboxing

software.

An issue with poorly protected, application-

speciﬁc resources (e.g. conﬁg-ﬁles), which exists for

the hierarchical access control model, can be solved in

the TE model by introducing an application-speciﬁc

type for every application and granting only the cor-

responding domain access to it. Futher, the TE model

promises to be more suitable for our purposes and we

choose to base our sandbox policy on it.

The TE model knows domains and types, as-

sociated with processes and resources, respectively.

Those model concepts must be represented in prac-

tice by using the features provided by an unpatched

Linux kernel. In the following, we outline how TE

can be realized using namespaces to assign UIDs to

domains and GIDs to types. We also detail how a

container based sandbox can enforce a policy deﬁned

in this way. The resulting model is visualized in ﬁg. 1.

On common Linux desktops all processes of an

account run with the same privileges. But to imple-

ment TE, it is necessary to enforce trust boundaries

between them. Therefore we execute every applica-

tion with its own unique UID and thereby think of

UIDs as domains.

The concept of a type labels resources (ﬁles, in

particular) is characterised by a many to many rela-

tion to domains and by a many to one relation to re-

sources. Since on Unix, famously, everything is a ﬁle,

we may think of resources as ﬁles (so ﬁle does not

mean “regular ﬁle” in this paper, but may be a block

device, socket etc.). As a consequence GIDs are a

suitable representation of types. A ﬁle has exactly one

GID but many ﬁles can have the same GID, and a pro-

cesses can be a member of several GIDs. Membership

of a process in a group can be thought of as a domain

having access to a type.

On Linux the association between UID and GIDs

is usually part of the account. However, creating an

account for every required UID is not appropriate in

our case, since creating or modifying accounts re-

quires elevated privileges (cf. requirement R6). In-

stead of using accounts we deﬁne the relations be-

tween UID and GIDs in a user-editable conﬁguration

ﬁle. Besides the UID to GIDs relation, the mapping of

executables to UIDs, as well as the relation between

GIDs and paths is deﬁned in this ﬁle.

Deﬁning path permissions in a conﬁguration ﬁle

rather than on the directory or ﬁle itself is clearer.

Unfortunately, it is not possible to apply those per-

missions to common Linux ﬁle systems in real-time

without intercepting ﬁle system access or conﬂicting

with the classic Linux ﬁle system and its access con-

trol. Therefore a software is required, which corrects

the ﬁle system permissions on demand. In the PoC

such a script is provided, it traverses the directories

recursive and corrects ﬁles UID / GID and permis-

sions. Further it it applies the SETGID bit, and an

access control list rule to directories, to change the

default ﬁle owner and mode declarations. This is not

a security but a usability feature.

Until this point not required is the ﬁle owner, this

is used to ensure that unsandboxed processes continue

to have access to user ﬁles in the usual way. The ﬁle

owner property is set to the UID of the user account.

In a sense, processes running with this UID are more

privileged than the other UIDs in the system. This is

done to support requirement R2.

On Linux, processes require CAP SETUID/

CAP SETGID to change UID and GIDs. Assigning

these capabilities to any process in the user’s session

would mean that we weaken security compared to

the classical Linux desktop setup. Instead, we use

bubblewrap to run applications in user NS and create

UID/GID mappings, using the setuid application

newuidmap, to implement a container based sand-

box that does not require elevated privileges to be

executed. Note that the user account’s UID owns the

new user NS and has full capabilities inside. As a

result, it can assume any UID/GID inside, as long as

it is mapped. This gives another reason to think of

the user account’s UID as privileged. A side effect

of using bubblewrap and user NS is that we need

to deﬁne bind mounts, since a mount NS is always

unshared. Our PoC does not use the mount NS for

isolation and simply provides the entire root ﬁle

system to the sandbox.

Besides implementing enforcement of domain-

type relations, we also must specify domain-domain

relations, which dictate which other domains a given

domain might start. On Linux there is no suitable re-

lation between UIDs that governs this kind of access:

Setuid binaries allow transitioning to other domains,

but they are set globally and affect every account and

they will also not launch a new user NS.

We chose to enforce this relation using a user-

space service, which runs with the permissions of the

user’s primary UID. We assume the administrator de-

ﬁned a UID range for this user in /etc/subuid (and

likewise for GIDs) when creating the account. Then

our service can deﬁne UID mappings via newuidmap

and run applications in their correct domains. A pro-

cess that wants to start another process then launches

SECRYPT 2022 - 19th International Conference on Security and Cryptography

320

Namespace

Application 1

Unsandboxed

Applications

Launcher

File

UID: 1000

UID: 100001

GID: 100111

GID: 100222

GID: 100111 UID: 1000

GID: 100222 UID: 1000

UID: 100002

GID: 100222

File

Application 2

launch

UID: 100002

GID: 100222

Launch Request

IPC: Application 2

launch

accesses

Client

Configuration:

- Application 2:

- UID: 100002

- Groups: [Download]

- Download:

- GID: 100222

Documents

Downloads

Figure 1: Sandbox Design.

a client binary, which communicates with the service

via an D-Bus IPC interface and requests the launch.

To enable this the D-Bus session bus is available to

all sandboxed applications. Upon receiving a launch

request, the service will look up the permissions of

the requesting UID in a conﬁguration ﬁle and decide

whether or not to launch the requested application

with its conﬁgured privileges. It is important that no

other UID than the user’s primary one is capable of

changing the conﬁguration.

In order to launch an application after validation,

the service runs a helper script in the namespaces us-

ing bubblewrap. After the namespaces are unshared

the execution is blocked by bubblewrap, and conﬁg-

ures the service uses newuidmap to setup UID and

GID mappings. Once the mappings are setup the

helper script in the sandbox change its UID and GIDs

to the conﬁgured ones and executes the target appli-

cation.

When using UIDs and GIDs to identify types and

domains, the UID/GID range assigned to a user’s ac-

count must be carefully chosen. For distinct users,

these ranges must be disjoint. Moreover, no two ap-

plications must share the same host UID. To ensure

this the presented PoC assigns a global UID to every

domain d, and a global GID to every type t. The ac-

tual ID u is computed by combining the global ID,

called the offset, with a user speciﬁc base UID to

avoid ID collisions: u = base + oﬀset(d)

A similar equation holds for the GIDs g corre-

sponding to types. This method has the advantage

that data can be transferred between systems as long

as the user base is identical. A typical value for the

user base would be 100000, which means that the

UID/GID range [100000, 100999] might be a good

UID/GID range for this user.

In order to add an application to the sandbox sys-

tem an user might add an entry containing its per-

missions and an unused offset by hand or install an

application proﬁle. The proﬁle may be provided by

a package maintainer and consists of the applications

permissions (using ﬁle paths and global offsets). Whit

the installer, that is part of our PoC it can be merged

with the current conﬁg, but on conﬂict no user conﬁg-

uration is over written.

5 EVALUATION

To evaluate the requirements from section 3.2, we

conducted a usability survey on the prototype and pro-

vide an analysis of the access control model and our

prototype.

5.1 Theoretical Analysis

All requirements except requirement R9 and parts of

requirement R6 may be veriﬁed by analysing the ac-

cess control model and the PoC implementation.

Requirement R1: Support Any Application. Our

sandbox does not expect applications’ cooperation,

but can interfere with the way it expects to access

ﬁles, IPC, or other processes. If an application re-

quires access to a resource, that access can be granted

by adjusting group membership appropriately. This is

obvious for ﬁles but for IPC the situation is more com-

plex. For example during development, some work

was required to enable sound of sandboxed applica-

tions via PulseAudio. We allow D-Bus communica-

tion, but other IPC can be challenging, we believe that

it affects very few applications.

There is a large group of tools that are challenging

Application Sandboxing for Linux Desktops: A User-friendly Approach

321

to sandbox in our model: Command line tools and

terminal emulators. For command-line tools it is dif-

ﬁcult to wrap them because they are not launched via

desktop ﬁles. For terminal emulators, it is possible

to provide a proﬁle, but it is very difﬁcult to restrict

access in a meaningful way.

Requirement R2: Co-exist with Unsandboxed

Applications. Our sandbox does not conﬂict with

unsandboxed applications, since the sandbox access

model maintains ﬁle ownership of the primary UID

of the user and only group ownership is changed for

access control. Unsandboxed applications have full

access to all of user-session’s resources, just as they

do on traditional Linux desktop environments.

Requirement R3: Support New Applications.

Given our analysis of requirement R1 it only remains

to discuss that adding new software will not pose lo-

gistical issues arising from collisions in the UIDs as-

signed to individual applications.

We ﬁrst note that our sandbox assigns global

unique UIDs but running out of UIDs seems unlikely.

If users install software outside the package manager,

there is a risk that the UID u manually chosen for such

an app will collide with a packaged app that is later in-

stalled: u = UserBase + Oﬀset(Firefox), resulting in

a security breach. This can be avoided, by specifying

a range of private offsets (much like private IPv4 net-

work ranges) that is forbidden to be used by packaged

software.

Requirement R4: Installable as Additional Pack-

age. The prototype can be packaged like any other

application and installed on standard Linux distribu-

tions. Our PoC comes with a Debian package that can

be used to install it on systems using dpkg. However,

it does not depend on any distribution-speciﬁc con-

tent – only Python 3, Bubblewrap, subuidmap, and

D-Bus. Additionally, the way we use Bubblwrap in

conjunction with NS requires support for unprivileged

user NS. However, unprivileged unsharing of user NS

is enabled on recent kernels in popular distributions

today (e.g. Debian, Ubuntu, Arch Linux).

Requirement R5: Customizable. Our sandbox is

customizable via its conﬁguration ﬁles. The labeling

of ﬁles and directories can be changed according to

the user’s preference. Files and directories can then

be relabeled automatically using the provided tools.

Customization includes both the ability to change a

ﬁle or directory’s type, as well as the types of any ap-

plication. Moreover, those changes are not undone on

update. There is some overhead if the package main-

tainer alters the applications initial conﬁguration ﬁle

and those changes are ported to the user’s local copy.

Requirements R6 and R8: Multi-user and Easy

Customization. The conﬁguration of the sandbox

is deﬁned for every user on a system in a user-speciﬁc,

human readable conﬁguration ﬁle that is owned by

the primary UID of the user’s account. Users may

edit this conﬁguration ﬁle without root privileges to

make smaller modiﬁcations or change the entire ac-

cess model. As mentioned, the question whether con-

ﬁguration is “easy” is best answered using an survey

and this is done further below.

The precondition for the way we launch applica-

tions with UIDs different from the user’s own primary

UID is that the user may set up UID mappings in the

new user NS. Since we use the newuidmap family of

tools for this purpose, a valid range for the user needs

to be written to /etc/subuid. This is the only con-

ﬁguration step that requires administrative privileges,

but can be done when the user’s account is created. If

those ranges are set up without overlap, the sandbox

may be used for multiple users without risk of weak-

ening the isolation between those accounts.

Requirement R7: Sandbox Must Provide Proﬁles

for Standard Applications. While our PoC cannot

provide proﬁles for every “common” application for

obvious reasons, we demonstrated that providing such

a proﬁle is a simple task for any user with at least

moderate knowledge: A new permission ﬁle need

only describe the application offset (cf. section 4) and

required group memberships. The PoC already in-

cludes a number of groups for common tasks, e.g. of-

ﬁce applications. Those ﬁles can be merged using the

installer provided with the PoC.

5.2 Survey

We conducted a survey to investigate whether require-

ments R6 and R9 are fulﬁlled: if the sandbox, once

conﬁgured, is transparent to the user and whether it

is easy to customize. The test environment was pro-

vided in the form of a virtual machine conﬁgured with

the PoC. Participants are required to perform certain

tasks on the system, and answer questions about their

interaction with the sandboxed applications. The sur-

vey was conducted with students in computer science

or electrical engineering at a college of higher educa-

tion in Germany. The questionnaire and manual were

provided in German.

The questionnaire consists of pairs of a task to

be performed, followed by questions about the task.

SECRYPT 2022 - 19th International Conference on Security and Cryptography

322

With every task description, a short sandbox manual

is provided. Furthermore the questionnaire contains

free text ﬁelds, so that subjects can provide additional

comments. The tasks the subjects had to perform are:

1. Starting the Firefox web browser and visiting an

arbitrary website.

2. Downloading a PDF ﬁle with Firefox, opening it

with the Okular PDF viewer and saving it in folder

“Documents”.

3. Creating a text ﬁle in “Documents” with the text

editor Geany and reopening it with VSCode.

4. Adding a new folder to the users home directory

and grant access to it to both Geany and VSCode.

Results. 22 students took part in the survey, but not

every question was answered by every student.

During the ﬁrst task, we expect subjects not to no-

tice the sandbox. 95% of the test users respond that

they would use the sandbox for this scenario. All sub-

jects did not notice the sandbox.

For the second task, 60% of the users had to inter-

act with the sandbox, which was expected due to Fire-

fox internals. 42.66% of the users that had to interact

with the sandbox reported difﬁculties but 76.19% of

all users would use the sandbox for this scenario.

The third task was not expected to lead to any is-

sues. Although 40% of the users experienced unex-

pected errors at this point 68.42 % of the subjects re-

sponded they would use the software for this scenario.

We can trace it back to permission issues of VSCode

with access to tmpfs and a bug in our PoC.

With the fourth task, we checked if subjects are

able to customize the policies. 68.4% percent of

the subjects claimed to succeed. Since 57.9% of the

subjects had problems with the documentation, more

comprehensive documentation is desirable.

Evaluation of the free-text comments showed that

several subjects were confused about the purpose of

the survey and did not necessarily evaluate the usabil-

ity, but rather tried to understand the security bene-

ﬁts of the sandbox. Those subjects reported that they

were not ready to use the sandbox in the future, be-

cause they were not convinced of its beneﬁts. This is

an interesting criticism, but since we did not attempt

to explain those beneﬁts to subjects, it is also not very

surprising. Future evaluations should be constructed

to avoid this misunderstanding by communicating the

intent of the survey more clearly.

5.3 Security Evaluation

We begin by noting that, since the UID ranges as-

signed to distinct users do not overlap, our sandbox

will not be less secure than the traditional Linux desk-

top with respect to ﬁle permissions. If access control

checks based on UIDs in IPC frameworks are deac-

tivated, this may weaken the security compared with

the classical desktop setting. However, if access to the

IPC interface can otherwise be restricted (e.g. through

ﬁle permissions on AF UNIX sockets), this problem is

mitigated. A generic solution based on a proxy is pos-

sible, but has not been implemented in our PoC. Nev-

ertheless, the security of a system running our sand-

box can be considered at least as high as that of a stan-

dard Linux desktop.

If an attacker A controls a process P, our sandbox

ensures that A cannot access any ﬁle that P could not

already have accessed. Recall that ﬁle access includes

IPC access where the IPC interface is represented as

a ﬁle (e.g. an AF UNIX socket). This is also true for

child-processes launched by P. It is possible for A to

launch applications in other sandboxes through their

desktop ﬁle by invoking the launcher via its D-Bus in-

terface. Again, this does not enable A to do anything

that was not explicitly permitted for P. There are still

two primary sources for security breaches in this sce-

nario: First, A has access to a resource, such as IPC,

that can be used to inﬂuence other processes. Second,

A may exploit programming errors (e.g. command in-

jection) in other applications. As dangerous as this

situation is, we consider it out of scope, because there

is nothing the sandbox can do to mitigate it.

Xorg is a well-known display server used to dis-

play the UIs of applications. Applications use it via

a socket that is widely accessible. Xorg does not

support the concept of trust boundaries or window

ownership on a single Xorg desktop, which means

that applications can access other X applications. To

deal with this either the Xorg successor Wayland or

a multi-instance desktop implementation like Xpra

might be used (Antoine Martin and others, 2021). We

designed a concept, where every sandboxed applica-

tion starts its own Xpra instance and a client under

the user’s primary UID connects to it. This is not cur-

rently part of the PoC due to time constraints.

Finally, D-Bus access is a potential issue. If

clients may access arbitrary D-Bus Interfaces, this

may allow them to access sensitive material. It is pos-

sible to add D-Bus conﬁguration templates as part of

an application’s proﬁle, which can be used to restrict

that applications access to the session bus. Again, this

is not implemented within our PoC due to time con-

straints.

Application Sandboxing for Linux Desktops: A User-friendly Approach

323

6 CONCLUSION AND FUTURE

WORK

In this paper we introduced a method, how to use

UIDs, GIDs, and user NS to create a sandbox for

Linux desktops. The proposed sandbox is designed to

meet requirements that we consider to be important

for wide spread adoption. We implemented a proto-

type and performed a usability survey. The results

indicate that an easy to use, transparent sandbox will

likely be adopted, provided users understand the ben-

eﬁts of using the software. Furthermore provided an

analysis of how the sandbox addresses each of the re-

quirements mentioned above, and analyzed its secu-

rity impact on the overall system.

Our research indicates several areas that future re-

search should address. First of all a long term evalu-

ation should be conducted to obtain results about the

applications stability. As mentioned above, the cur-

rent prototype does not support access control for the

D-Bus session bus. A solution to restrict this access,

is a necessary in our opinion. Another challenge for

future work is that Xorg does not separate the graph-

ical user interfaces of the applications. Therefore,

either a multi instance display server like Xpra or a

Wayland-based solution should be added. Third, cur-

rently network access is unrestricted. Isolating net-

work access through network namespaces should be

considered. The challenge here is to strike a balance

between full and no access – many applications use

localhost communication extensively.

REFERENCES

Agache, A., Brooker, M., Iordache, A., Liguori, A., Neuge-

bauer, R., Piwonka, P., and Popa, D.-M. (2020). Fire-

cracker: Lightweight virtualization for serverless ap-

plications. In 17th USENIX Symposium on Networked

Systems Design and Implementation (NSDI 20), pages

419–434, Santa Clara, CA. USENIX Association.

Anderson, R. (2020). Security engineering: a guide to

building dependable distributed systems. John Wiley

& Sons.

Android Open Source Project (2021). Android compatibil-

ity deﬁnition document. https://source.android.com/

compatibility/cdd.

Anjali, Caraza-Harter, T., and Swift, M. M. (2020). Blend-

ing containers and virtual machines: A study of

ﬁrecracker and gvisor. In Proceedings of the 16th

ACM SIGPLAN/SIGOPS International Conference

on Virtual Execution Environments, VEE ’20, page

101–113, New York, NY, USA. Association for Com-

puting Machinery.

Antoine Martin and others (2021). Xpra readme.

https://github.com/Xpra-org/xpra/blob/master/

README.md.

Badger, L., Sterne, D. F., Sherman, D. L., Walker, K. M.,

and Haghighat, S. A. (1996). A domain and type

enforcement unix prototype. Computing Systems,

9(1):47–83.

elair, M., Laniepce, S., and Menaud, J.-M. (2019). Lever-

aging kernel security mechanisms to improve con-

tainer security: A survey. In Proc. of the 14th Int.

Conf. on Availability, Reliability and Security. ACM.

Bell, D. E. (1975). Secure computer systems: Mathematical

foundations and model. Mitre Corp. Report, pages

74–244.

Biba, K. (1975). Integrity considerations for secure com-

puting systems. Mitre Report MTR-3153, Mitre Cor-

poration, Bedford, MA.

Brown, P., Blandford, J., Taylor, O., Untz, V., Bastian,

W., Lortie, A., Faure, D., and Thompson, W. (2020).

Desktop Entry Speciﬁcation.

Canonical Ltd. (2022). Snap documentation — snapcraft

documentation. https://snapcraft.io/docs.

Containers Community (2016). Bubblewrap source code.

https://github.com/containers/bubblewrap.

ENCRYPTED SUPPORT LP (2022). Whonix. https:

//www.whonix.org/.

Firejail Contributers (2020). Firejail source code. https:

//github.com/netblue30/ﬁrejail.

Flatpak Team (2018). Flatpak’s documentation. https:

//docs.ﬂatpak.org/en/latest/#.

Jana, S., Porter, D. E., and Shmatikov, V. (2011). TxBox:

Building secure, efﬁcient sandboxes with system

transactions. In 2011 IEEE Symposium on Security

and Privacy. IEEE.

Khalimov, A., Benahmed, S., Hussain, R., Kazmi, S. A.,

Oracevic, A., Hussain, F., Ahmad, F., and Kerrache,

C. A. (2019). Container-based sandboxes for malware

analysis: A compromise worth considering. In Pro-

ceedings of the 12th IEEE/ACM International Confer-

ence on Utility and Cloud Computing, UCC’19, page

219–227, New York, NY, USA. Association for Com-

puting Machinery.

Linux Manpage Team (2021). Linux manual page.

Mayrhofer, R., Stoep, J. V., Brubaker, C., and Kralevich, N.

(2021). The android platform security model. ACM

Transactions on Privacy and Security, 24(3):1–35.

Open Container Initiative (2022). Runc source code. https:

//github.com/opencontainers/runc.

Subgraph (2014). Subgraph os. https://subgraph.com/.

The Qubes OS Project and others (2022). Architecture —

qubes os. https://www.qubes-os.org/doc/architecture/.

Waterson, D. (2020). Managing endpoints, the weakest link

in the security chain. Network Security, 2020(8):9–13.

Yosifovic, P., Ionescu, A., Russinovich, M. E., and

Solomon, D. A. (2017). Windows Internals Sev-

enth Edition Part 1: System architecture, processes,

threads, memory management, and more, Seventh

Edition. O’Reilly.

SECRYPT 2022 - 19th International Conference on Security and Cryptography

324
