A Longitudinal Study of Cryptographic API: A Decade of Android

Malware

Adam Janovsky

, Davide Maiorca

, Dominik Macko

, Vashek Matyas

and Giorgio Giacinto

Masaryk University, Czech Republic

University of Cagliari, Italy

Keywords:

Cryptographic API, Malware, Android, Malware Detection.

Abstract:

Cryptography has been extensively used in Android applications to guarantee secure communications, conceal

critical data from reverse engineering, or ensure mobile users’ privacy. Various system-based and third-party

libraries for Android provide cryptographic functionalities, and previous works mainly explored the misuse of

cryptographic API in benign applications. However, the role of cryptographic API has not yet been explored

in Android malware. This paper performs a comprehensive, longitudinal analysis of cryptographic API in

Android malware. In particular, we analyzed

603937

Android applications (half of them malicious, half benign)

released between

2012

and

2020

, gathering more than 1 million cryptographic API expressions. Our results

reveal intriguing trends and insights on how and why cryptography is employed in Android malware. For

instance, we point out the widespread use of weak hash functions and the late transition from insecure DES to

AES. Additionally, we show that cryptography-related characteristics can help to improve the performance of

learning-based systems in detecting malicious applications.

1 INTRODUCTION

The Android operating system has spread worldwide

during the last decade, reaching almost

billion users

2021

(BusinessOfApps, 2022). At the same time,

security threats against Android have multiplied, as

recent reports showed (McAfee Labs, 2019).

Most Android applications employ cryptographic

primitives to conceal critical information and securely

carry out communication with internal components,

applications, and web services. At the same time, it

is natural to imagine that malware authors may lever-

age cryptography in a plethora of artful ways to serve

their malevolent objectives. For instance, cryptogra-

phy equips attackers with the ability to ﬁngerprint the

parameters of an infected device, encrypt users’ media

ﬁles, establish a secure connection with a command-

and-control server, or manage ransom payments car-

ried out by victims infected by, e.g., ransomware.

Previous research conveyed a signiﬁcant effort in

analyzing cryptography in benign applications. The fo-

cus was mainly related to the misuse of cryptographic

application programming interface (API) in benign An-

droid applications, i.e., on ﬁnding and eliminating vul-

nerabilities in the employed crypto-routines that may

allow attackers to obtain sensitive information (Egele

et al., 2013; Muslukhov et al., 2018; Chatzikonstanti-

nou et al., 2016; Shuai et al., 2014).

To the best of our knowledge, however, no study

explored how cryptography is currently employed in

malicious applications. In this paper, we answer two

important research questions related to cryptography

and Android malware:

RQ.1: Are there signiﬁcant differences in how

cryptography is employed in benign and malicious

applications?

RQ.2: Can information about cryptography im-

prove Android malware detection?

We believe that answering these questions will

shed more light on the mechanisms of Android mal-

ware, providing new insights for its analysis, charac-

terization, and detection. In this paper, we propose

two main contributions. First, we deliver a compre-

hensive comparison of how cryptography is employed

603937

malicious and benign applications released

in the last decade. Such a comparison is carried out

with an open-source

, scalable approach that inspects

(among others) the usage of hash functions, symmetric

The code is acessible from github.com/adamjanovsky/

AndroidMalwareCrypto.

Janovsky, A., Maiorca, D., Macko, D., Matyas, V. and Giacinto, G.

A Longitudinal Study of Cryptographic API: A Decade of Android Malware.

DOI: 10.5220/0011265300003283

In Proceedings of the 19th Inter national Conference on Security and Cryptography (SECRYPT 2022), pages 121-133

ISBN: 978-989-758-590-6; ISSN: 2184-7711

121

and public-key encryption, PRNGs, etc. In total, we

inspect over 10

of cryptographic API expressions.

Second, we show that cryptographic features can

be used to augment the performances of state-of-the-

art malware detectors, demonstrating their discrim-

inant power in distinguishing malicious and benign

applications. We also employ techniques inherited

from the interpretation of learning models to point out

possible connections between cryptographic API and

malicious actions.

The attained results show many intriguing and sur-

prising trends. For example, in contrast to benign

applications, malware authors do not typically resort

to strong cryptography to perform their actions. We

show that malware often favors the use of cryptograph-

ically defeated primitives, e.g., weak hash functions

MD5 (Wang and Yu, 2005) or SHA-1 (Stevens et al.,

2017), or symmetric encryption scheme DES (Biham

and Shamir, 1991). These insights can also be es-

pecially useful to learning-based models, which can

leverage these cryptographic trends to improve the de-

tection rate of malware. We believe that the results

presented in this work can constitute a seminal step to

foster additional research on the relationship between

cryptography and Android malware.

The paper is organized as follows: In Section 2,

we describe the methodology of our analysis. In Sec-

tion 3, we answer the ﬁrst research question. Section 4

discusses cryptographic API in relation to malware

detection. The limitations of our study are discussed

in Section 5. Section 6 describes the related work and

Section 7 closes the paper with the conclusions.

We also deliver an extended technical report for

this paper on arXiv

2 METHODOLOGY

This section describes the methodology we employed

to extract and analyze the cryptographic API embed-

ded in Android applications. We start by formalizing

the problem, properly deﬁning its domain and vari-

ous constraints. We then show how we implemented

this formalism in practice by discussing our developed

analysis framework. Our ﬁndings are based on the

static analysis of the Java source code obtained by the

decompilation of the Android executables.

2.1 Problem Formalization

We organize the problem formalization in two parts:

part one treats the deﬁnition of the crypto-routines of

https://arxiv.org/abs/2205.05573.

interest for our analysis, part two describes the process

of locating those routines in the application source

code.

I. Deﬁnition of Crypto-routines. Given a set of An-

droid applications, we denote the set of all possible

functions F contained in their source code as:

F = U ∪ S ∪ T = C ∪ C

Where

represents the set of functions deﬁned by the

user,

is the set of system-related functions contained

in the Android SDK, and

is the set of functions be-

longing to third-party libraries. Given a set of known

crypto-related functions

, our goal is to study the in-

tersection of

and

, denoted as

. In other words,

is the set of cryptography-related functions that are

deﬁned in the system package (in Android represented

by JCA functions). Notably, in this analysis, we dis-

card custom cryptographic functions that users or third

parties may implement. Automatic detection of such

functions would be a complex task in the context of

a large-scale analysis, which may lead to false posi-

tives (or negatives) without further manual inspection.

In our study, we solely aim to answer what functions

from F

the malware authors favor.

From the cryptographical perspective, the func-

tions contained in

can be divided into the fol-

lowing categories: (i) Hash functions. Cryptographic

hash functions such as MD5, SHA-1, or SHA-2; (ii)

Symmetric encryption. Symmetric cipher primitives

such as AES, DES, or RC4; (iii) Public-key encryp-

tion. Asymmetric primitives, in Android represented

by the RSA cryptosystem; (iv) Digital signature al-

gorithms. Primitives that empower digital signatures,

e.g., ECDSA; (v) MAC algorithms. Primitives that

construct Message Authentication Codes, also called

MACs; (vi) PRNG. Functions to run pseudo-random

number generators (PRNG); (vii) Key agreement proto-

cols. Algorithms for key exchange, in JCA represented

by Difﬁe-Hellman protocol; (viii) Others. Functions

that do not fall into any of the previous categories.

II. Locating Cryptographic API. All functions in

are available through two Java packages in An-

droid API:

javax.crypto

and

java.security

. Our

research aims to reveal which cryptographic functions

have been chosen and directly employed by the au-

thors. Notably, Android applications typically contain

third-party packages that invoke crypto functions. We

aim to exclude those packages from our analysis as the

application authors did not contribute to them.

Thus, for each Android sample, we are interested

in extracting the cryptographic API

⊆ F

that is

invoked from user-deﬁned functions

. To obtain the

functions belonging to

, we perform two steps: (i)

We automatically detect the classes that belong to third-

SECRYPT 2022 - 19th International Conference on Security and Cryptography

122

party or system libraries, and we exclude them from

the set of classes that should be explored. By doing so,

we establish the list of user-implemented functions

;

(ii) We extract all references to crypto-related functions

that are invoked directly from U.

The ﬁrst step is motivated by the discovery (Wang

et al., 2015) that more than 60% of Android APK

code (on average) originates from third-party packages.

To study user-authored code, it is therefore critical to

differentiate, with reasonable certainty, whether a class

belongs to a third-party library or not. This task can

be extremely challenging and was extensively studied,

e.g., by (Wang et al., 2015; Ma et al., 2016b; Backes

et al., 2016). It does not sufﬁce to merely search for the

import

clauses in the decompiled source code since

the non-system packages could be renamed. This sce-

nario is especially frequent in malicious applications,

as the authors aim to defend against any forensics. In-

spired by the systematic review of third-party package

detectors (Zhan et al., 2020), we opted to tackle this

with

LibRadar

, a popular third-party libraries detec-

tion tool that utilizes clustering and complex signatures

to recognize such libraries (Ma et al., 2016b). In this

review,

LibRadar

achieves the highest precision and

second-highest recall while it takes approx. 5 seconds

to evaluate an APK on average. The runner-up requires

over 80 seconds per APK, which would be unsuitable

for large-scale analysis.

LibRadar

was trained on a

large dataset of Android applications and can reliably

ﬁngerprint more than

29000

third-party libraries, not

relying on package names. Consequently,

LibRadar

can identify obfuscated packages. Using

LibRadar

we ﬁlter the identiﬁed third-party packages of an APK

from subsequent cryptographic API analysis.

2.2 Crypto API Extraction Pipeline

Our system generates a comprehensive report of the

embedded cryptographic API, given an application

dataset. As an input, conﬁguration ﬁles for the to-be-

conducted experiment are taken. Apart from other

choices, the ﬁles contain a list of APKs that can be

loaded from a disk or downloaded from the Internet.

The APKs are then processed in parallel, and each

sample traverses the following pipeline:

Pre-processor. This module decompiles the APKs

Android Application Package, an archive that encapsu-

lates the whole Android application.

Since

LibRadar

requires large Redis database to

run (preventing parallelization), we actually leveraged its

lightweight version

LiteRadar

. Prior to doing so, we com-

pared the output of both tools on a small subset to ﬁnd out

that this decision has a negligible effect on the number of

detected libraries.

to obtain their Java source code. Then, the third-

party packages of the APKs are identiﬁed, and the

whole Java source code of the APKs is extracted.

Crypto-extractor. This module extracts and an-

alyzes the cryptographic function call sites in the

application source code. Their ﬁltering is achieved

by matching pre-deﬁned regular expressions. Ad-

ditionally, the crypto-extractor also detects both

Java and native third-party cryptographic libraries.

Evaluator. This module stores, organizes, and ag-

gregates the information retrieved by the analyzed

APKs to a JSON record.

The evaluator outputs a report of the cryptographic

usage for each APK. We designed the system in a

modular fashion so that one can alter its inner workings

to extract further valuable insights from the APKs.

2.3 Dataset

To gain an all-around view of the cryptographic API

landscape in Android applications, we leverage the

Androzoo dataset (Allix et al., 2016). Currently, An-

drozoo is the largest available dataset of Android ap-

plications, containing more than 15 million of APKs.

We sampled

302039

benign applications and

301898

malicious applications from Androzoo released in the

years 2012-2020. We strived for uniform distribution

of samples in the studied timeline. Yet, for years 2018,

2020 we could only collect a limited number of ma-

licious samples –

19305

and

10039

, respectively. To

speed up the computation, we only gathered APKs

smaller than

20MB

(approximately 89% of malicious

APKs in the Androzoo fulﬁll this criterion).

To accurately discriminate malicious ﬁles, we con-

sider an APK as malicious if it was ﬂagged malicious

by at least ﬁve antivirus scanners from the VirusTo-

tal service

, which should reliably eliminate benign

ﬁles deemed malicious, as reported by Salem (Salem,

2020). Our samples are predominantly originating

from 3 distinct sources: Google Play (

60%

), Anzhi

(

19%

), and Appchina (

13%

). Note that the samples

were deduplicated on a per-market basis (Allix et al.,

2016) to avoid over-counting.

2.4 Cryptography and Machine

Learning

Statistics about cryptographic usage are undoubtedly

helpful in pointing out differences between benign and

malicious applications. Another intriguing question to

virustotal.com. The number of VirusTotal positive ﬂags

is already contained in the Androzoo dataset.

A Longitudinal Study of Cryptographic API: A Decade of Android Malware

123

explore is whether such statistics can be useful to rec-

ognize malicious samples from benign ones effectively.

To answer this question, we propose three methods

that employ machine learning techniques, described in

the following.

2.4.1 Cryptographic Learning Model

The ﬁrst technique consists of deﬁning a learning-

based system whose structure is inspired by other pop-

ular detection systems (Daniel et al., 2014; Chen et al.,

2016; Maiorca et al., 2017). In particular, the pro-

posed system performs the following steps: (i) it takes

as an input an Android application and extracts its

cryptographic API usage with the pipeline described

in Section 2.2; (ii) it encodes this statistics into a vector

of features; (iii) it trains a machine-learning classiﬁer

to predict a benign/malicious label.

The feature vector includes features that can be

categorized into three sets:

•

Set A: ﬂags indicating the use of third-party cryp-

tographic libraries (both Java and native).

•

Set B: frequencies of speciﬁc cryptographic API

constructors and imports of crypto-related classes,

e.g., number of DES constructors in a sample.

•

Set C: aggregated statistics of call sites and

imports related to categories of cryptographic

primitives: hash functions, symmetric encryption

schemes, and so forth. For example: how many

distinct hash functions a sample uses.

By joining these sets, we obtain 300 potentially

informative features. These features are further ﬁl-

tered with a feature selection algorithm. The dataset

with candidate features is split in a 9:1 ratio into train-

ing/test sets. Then, we apply two feature selection

methods to drop uninformative features. First, we ex-

amine all possible pairs of features. If a pair exhibits

Pearson’s correlation coefﬁcient higher than 0.95, we

drop a random feature of such a pair. Second, we re-

move the features that are deemed uninformative by

Boruta (Kursa et al., 2010). Boruta is a supervised

algorithm that iteratively replicates features, randomly

permutates their values, trains a random forest, and

removes redundant features based on the z-score. The

feature selection process yields 189 features that are

used for learning.

To choose the best family of models for discrimi-

nating between malicious and benign samples on our

dataset, we experimented with naive Bayes, logistic

regression, support vector machines with linear kernel,

random forest, gradient boosted decision trees, and

multilayer perceptron. We tuned the classiﬁers’ hy-

perparameters using 10-fold cross-validation on the

training dataset, optimizing for the F1 score. Subse-

quent evaluation yielded a random forest (which works

as a majority-voting ensemble of decision trees trained

on different subsets of the data) as the best-performing

classiﬁer (w.r.t. F1 score). We do not report the entire

analysis here for brevity, and we stick to the random

forest in the rest of the paper.

2.4.2 Explaining the Learning Model

To further advance the understanding of cryptographic

API in Android detection, we explain the predictions

of the just described cryptographic classiﬁer. To do

so, we follow the techniques of explainable machine

learning, a ﬁeld that attempts to understand why a clas-

siﬁer makes certain decisions. We study both global

and local importances of the features extracted by the

classiﬁer, in a similar fashion to what has been pro-

posed in previous work (Melis et al., 2018; Melis et al.,

2022). A global analysis evaluates the impact of the

features averaged over the whole dataset, while local

analysis evaluates the impact of the features on speciﬁc

samples.

To interpret the classiﬁer’s predictions, we used

Shapley additive explanations (SHAP) (Lundberg and

Lee, 2017) that are successfully used outside of com-

puter science. SHAP can consistently explain both

local predictions and global feature importance by

measuring each feature’s contribution to the predic-

tion. This method uses Shapley values (Shapley, 1953)

from coalitional game theory. Each player is a feature

or a coalition of features, and the game (payout) is

the prediction. Shapley values are considered opti-

mal because they satisfy the properties of efﬁciency,

symmetry, dummy, and additivity.

2.4.3 Classiﬁer Enhancing

The third approach consists of taking a well-

established malware classiﬁer for Android as a base-

line and measuring its performance when enhanced

with features related exclusively to cryptographic API.

To this end, we chose

R-PackDroid

(Maiorca et al.,

2017), an available learning-based classiﬁer (trained

on random forests) based on static features, and we

expand its feature set by adding the cryptographic fea-

tures described above. There are multiple reasons for

which this system was chosen as a baseline: (i) It was

initially designed to detect ransomware; (ii) It harvests

a relatively small number of features; (iii) It features a

high detection rate (the original paper documents over

97% F1 score).

Considering the characteristics described above, it

would normally be challenging to improve the already

strong performance of the system by adding more fea-

SECRYPT 2022 - 19th International Conference on Security and Cryptography

124

tures. To keep some space for improvement when

enhancing the classiﬁer with cryptographic features,

we decreased the number of

R-PackDroid

features

from 211 to 10 in a controlled manner, leading to an

F1 score of

76%

. To measure the effect of crypto-

graphic API features on the model, we replicated the

following procedure

1000

times: (i) We sample 10

random features from

R-PackDroid

; (ii) We build

a random forest classiﬁer and measure its F1 score;

(iii) We enhance the 10

R-PackDroid

features with

all 189 cryptographic API features chosen by feature

selection; (iv) We use the expanded feature set to build

another random forest classiﬁer and measure its per-

formance gain over the baseline classiﬁer.

With the three strategies described above, we un-

veil the role of cryptographic API for malware detec-

tion, as will be shown in Section 4.

3 TRENDS IN CRYPTOGRAPHY

In this section, we answer RQ.1: Are there signiﬁcant

differences in how cryptography is employed in be-

nign and malicious applications? We report the most

signiﬁcant statistics we obtained with the API extrac-

tion methodology presented in Section 2.2. First, we

discuss the general prevalence of cryptographic API

that can be extracted with static analysis by discussing

the effects of obfuscation, the incidence of third-party

packages, and the overall differences between benign

and malicious applications. Then, we provide a more

detailed focus on the distribution of cryptographic API

in malicious applications.

3.1 General API Distribution

3.1.1 Application Obfuscation

The ﬁrst interesting trend of this study is a decreasing

ratio of malicious applications for which we detect

usage of cryptographic API, as depicted in Figure 1.

However, such a ratio is not visible for benign applica-

tions. We conjecture that this drop does not represent

a genuine decrease in usage of cryptographic function-

ality in time but rather a consequence of increasing

ratio of obfuscated malicious applications. To conﬁrm

this hypothesis, we randomly sampled 4444 malicious

applications from 2018-2020 that allegedly contain

no cryptographic API or third-party libraries. We dis-

sected them using commercial dynamic analysis tool

apklab

and searched for clues of obfuscation. We

The tuples were sampled in advance to avoid repetition.

Kindly provided by Avast, available at http://apklab.io.

identiﬁed that 98% applications use some form of An-

droid packer, with

jiagu

being most popular. Each

packed application also uses reﬂection API and dy-

namic library loading, tools that prevent static analysis

from registering cryptographic API call sites. We also

report that 83% of applications use some form of en-

cryption API (AES being the most prevalent, followed

by RSA), often to decrypt application resources. Such

reduced prevalence of crypto API constitutes a limita-

tion of our study, further discussed in Section 5.

3.1.2

Third-party Packages and Crypto Libraries

Another closely related trend is the dropping ratio of

third-party packages captured by

LiteRadar

in ma-

licious applications. Before 2018, we documented a

high ratio of malware employing third-party packages

(

86%

). Starting with 2018, this ratio quickly drops

as depicted in Figure 1. Similar to obfuscation, this

drop is not evident in benign applications. Overall,

LiteRadar

was able to identify at least one third-party

package in

94.6

% of analyzed goodware with little

variance between years (see Figure 1). On average,

packages were identiﬁed in benign APKs. This un-

derpins the importance of robust third-party package

detection. In contrast to prior work that did not con-

sider third-party package ﬁltering, we discarded over

million third-party packages with at least

thousand

unique package names from the analysis.

Apart from Android API, cryptographic functions

can also be delivered by third-party libraries, typically

adopted to integrate functionality missing in system-

based libraries. With expert knowledge, we identi-

ﬁed 13 Java and 10 native third-party cryptographic

libraries for which we searched in the samples (see

paper artifacts for the full list). We identiﬁed only

796 benign and 198 malicious applications that im-

port third-party cryptographic libraries. Of the studied

libraries,

sqlcipher

was most popular in goodware

(found in

622

samples), and

keyczar

was most pop-

ular in malware (found in

124

samples). The ratio

of these applications has been stable throughout the

studied timeline. As for the native libraries, not a sin-

gle call to a native cryptographic library was detected

in the malicious dataset, and merely 91 imports of

OpenSSL occurred in the benign dataset.

From these results, it is possible to observe that

third-party cryptographic libraries are not widely used

in Android applications. This aspect demonstrates that

attackers often resort to standard crypto functionali-

ties provided by system libraries (that can use various

backends, e.g., BouncyCastle).

A Longitudinal Study of Cryptographic API: A Decade of Android Malware

125

2012 2020

10%

30%

50%

70%

(a) cryptographic API

% of APKs in dataset

malicious

benign

2012 2020

25%

50%

75%

100%

(b) third-party package

malicious

benign

2012 2020

10%

15%

20%

AES

DES

2012

2015

2020

10%

15%

(d) Malicious AES/DES

AES

DES

Figure 1: Time evolution of important dataset characteristics. The y-axis show the percentage of APKs exhibiting given

feature, whereas the x-axis represents the time in years. In subplot (a) we see the ratio of APKs in which we detected any

cryptographic API. Subplot (b) shows APKs for which we detect any third-party package. These are the main artifacts of

increasing obfuscation. Subplots (c), (d) document the usage of AES vs. DES in benign, and malicious samples respectively.

AES has been the most prevailing cipher suite in benign applications since 2012. On the contrary, DES was more popular in

malware in previous years, only in 2015 being outran by AES.

3.1.3 Crypto API in Goodware and Malware

We now describe the general prevalence of crypto-

graphic API in the dataset presented in Section 2.3 by

showing the differences between malicious and benign

applications and comparing our results with two stud-

ies conducted on benign datasets. For this comparison,

we employed: (i) A dataset collected in 2012 as a part

of the study CryptoLint (Egele et al., 2013) that we

refer to as CryptoLint-B12; (ii) A dataset collected

in 2016 as a part of Binsight study (Muslukhov et al.,

2018) that we refer to as Binsight-B16. To avoid tem-

poral data drift, we cast four subsets of our dataset:

Androzoo-B12, Androzoo-M12, Androzoo-B16, and

Androzoo-M16, limited to malicious (M), and benign

(B) samples from years 2012 (12), and 2016 (16). As

explained in Section 2, our goal is to analyze only cryp-

tographic APIs contained in user-deﬁned code. From

this respect, both (Egele et al., 2013; Muslukhov et al.,

2018) employ weaker methodologies to ﬁlter third-

party libraries, relying on whitelisting and package

names. Conversely, our approach of

LiteRadar

ﬁlter-

ing captures the code written by the application authors

more reliably. The numbers drawn from the Androzoo

datasets serve as conservative estimates, with the real

number of cryptographic API call sites even higher.

The overall comparison with benign datasets is de-

picted in Table 1. It can be seen that the malicious

datasets have a dramatically higher density of crypto-

graphic API call sites than their benign counterparts.

CryptoLint-Anndrozoo Comparison. The

CryptoLint-B12 dataset resulted from scanning

145095

samples for the presence of cryptographic

API (and its misuse). The study concluded that

15134

(

10.4

%) of APKs contain some cryptographic

call sites. However, the subsequent BinSight study

attributed

79.5

% of these call sites to the ignored

third-party packages, showing that the original

CryptoLint study suffered from overcounting.

In contrast, we report that

27.4%

of Androzoo-B12

contains cryptographic API call sites and nearly twice

as much malware from Androzoo-M12 (

53.1

%), too.

This highlights the extensive use of cryptographic API

in malicious applications compared to the benign land-

scape. A closer examination of symmetric ciphers in

Table 2 also reveals considerable differences between

malicious and benign datasets. AES dominates benign

datasets with

58.9

% in CryptoLint-B12 and

52.4%

Andozoo-B12. The situation is strikingly different in

the malicious dataset. In Androzoo-M12, the most

popular primitive is DES with

% of call sites, fol-

lowed by AES (12.1%) and 3DES (0.9%).

BinSight-Androzoo Comparison. The BinSight pa-

per aimed to answer what proportion of cryptographic

API misuse can be attributed to third-party packages.

The authors identiﬁed

638

distinct third-party pack-

ages in

115683

unique samples in BinSight-B16, re-

lying on the package name as an identiﬁer. The au-

thors attributed at least

90.7

% of the call sites to third-

party packages, underlying the need for their robust

detection. Even after we discarded

9870

third-party

packages from Androzoo-M16, the malicious dataset

still contains much more cryptographic API in the

user-authored codebase. Again, the relations between

Androzoo-M16 and BinSight-B16 are depicted in Ta-

ble 1. Interestingly, in 2016, AES was dominant in

Androzoo-M16 as well with

45.1%

of call sites, fol-

lowed by DES (

22.8%

). We depict the time evolution

of AES vs. DES in Androzoo dataset in Figure 1,

showing that it was only in 2015 when AES outran

DES in malicious applications.

3.2 Crypto API Categories in Malware

Apart from the comparison to benign applications, we

also report a broad view of the distribution of cryp-

tographic API in malicious applications, concentrat-

ing on the years 2012-2018, for which we dispose of

SECRYPT 2022 - 19th International Conference on Security and Cryptography

126

Table 1: Comparison of cryptographic API spread in benign vs. malicious datasets. The last column normalizes by the size of

the datasets, allowing for direct comparison.

Dataset #APKs #User-def. call sites #User-def. call sites/10k samples

CryptoLint-B12 145095 20967 1445

BinSight-B16 115683 78163 7006

Androzoo-B12 39838 81698 20507

Androzoo-B16 37493 124705 33260

Androzoo-M12 39767 125225 31489

Androzoo-M16 39325 208625 53051

Table 2: Distribution of symmetric ciphers in benign and malicious datasets with AES dominating all but Androzoo-M12.

Dataset AES DES 3DES RC4 Blowﬁsh Unknown

CryptoLint-B12 58.9% 19.0% 8.8% 0.4% 1.9% 10.9%

BinSight-B16 64.4% 14.3% 1.1% 2.1% 0.9% 17.2%

Androzoo-B12 52.4% 16.9% 3.8% 0% 0.0% 26.8%

Androzoo-B16 59.0% 12.2% 2.0% 0.1% 0.0% 26.8%

Androzoo-M12 12.1% 56.0% 0.9% 0.0% 0.0% 31.0%

Androzoo-M16 45.1% 22.8% 2.1% 0.0% 0.0% 30.0%

representative samples not clouded with high ratio of

obfuscated applications.

Table 3 illustrates that the majority of call sites

from this period can be attributed to hash functions

(

%) and symmetric encryption (

%), which leaves

the rest of the categories rarely used. Nevertheless,

we comment on our ﬁndings in all categories, observ-

ing the time evolution trends and showing the most

prevailing primitives. We could not attribute

21%

the identiﬁed constructors to the exact cryptographic

primitive (partial obfuscation) during our experiments.

We still manage to pinpoint their presence and even

their category, as the system-based API calls are chal-

lenging to obfuscate entirely.

Hash Functions. The hash functions are by far the

most popular category of cryptographic API in mali-

cious applications, as they are present in 40% of all

studied APKs and responsible for

424858

call sites in

our dataset. Interestingly, the majority of the call sites

resort to primitives MD5 or SHA-1 that were already

shown to be broken (Wang and Yu, 2005; Stevens et al.,

2017). Speciﬁcally, MD5 can be attributed to more

than

% of these call sites and does not lose any of

its popularity in time. This may suggest that MD5 is

either not meant to provide secure integrity protection

for the authors or that the developers are unaware of its

weakness. The time evolution of SHA-1 and SHA-256

points to the former case. Indeed, the overall dominant

SHA-1 (almost

% of call sites) is gradually decreas-

ing over time in favor of the more secure SHA-256 (

overall). In 2018, SHA-256 was present in more APKs

(708) than SHA-1 (528). This phenomenon can mean

that, when secure integrity protection is needed, more

secure SHA-256 is nowadays being selected instead

of SHA-1. Still, MD5 is preferred by the malware

creators for other use cases. Apart from the hash func-

tions mentioned above, only SHA-512 and SHA-384

are represented in the dataset, but these are responsible

for less than 1000 call sites in total.

Symmetric Encryption. A large portion of the sym-

metric encryption API landscape was already de-

scribed in Section 3.1.3, but some important aspects

were yet omitted. Overall, our dataset contains

165994

symmetric encryption call sites distributed in approx-

imately

% of APKs. A large portion of the call

sites (

%) is obfuscated. Besides AES and DES, only

3DES is used in more than 1000 APKs. We also re-

port that the concept of password-based encryption is

applied merely in 837 APKs. A closer look at the en-

cryption modes offers an interesting perspective. Our

observations conﬁrm that the authors favor the default

constructors (

"AES"

and

"DES"

) compared to construc-

tors that specify encryption mode and padding (e.g.,

"AES/CBC/PKCS5PADDING"

). The default constructors

fall back into the ECB mode with PKCS#7 padding,

which is (under most circumstances) considered inse-

cure (Menezes et al., 1996).

Public-key Encryption. The only asymmetric encryp-

tion scheme appearing in the Android API is RSA. The

RSA encryption occurs in approximately

1.55

% of all

APKs in our dataset. Until 2013, RSA appeared very

rarely, but then it peaked within two years to almost

1800 APKs in 2015.

Digital Signature Algorithms. Surprisingly, digital

signature algorithms occupy

4.5

% of the malicious

APKs and are present in

17505

call sites. Considering

possible applications of digital signature primitives in

malware, this constitutes a rather large number. De-

A Longitudinal Study of Cryptographic API: A Decade of Android Malware

127

Table 3: Popularity distribution of cryptographic API cat-

egories. The ratio of APKs for symmetric encryption and

RSA is approximate, since one cannot differentiate the ob-

fuscated constructors of these two categories. Note that ap-

proximately 1% of APKs contain cryptographic API outside

of these categories.

Category #call sites %obfusc. %APK

Hash functions 424858 16.8% 39.7%

Symmetric enc. 165994 25.9% 19.4%

Public-key enc. 13 262 25.9% 1.5%

Digital sig. alg. 17 505 81.4% 4.5%

MAC 11661 46.4% 3.0%

PRNGs 10381 6.6% 2.9%

Key agreement 87 29.9% 0%

Sum 646018 21.5% 44.6%

spite the highest obfuscation rate among categories

(

81.43

%), the

SHA1withRSA

primitive is responsible

for almost

80%

of the unobfuscated call sites. As in

the case of the hash functions,

SHA256withRSA

is on

the rise in time, ﬁrst appearing in 2015 and steadily in-

creasing the fraction of APKs it appears in ever since.

Still, in 2018 it is less than four times probable to

appear compared to SHA1withRSA.

While multiple schemes supporting elliptic curves

over RSA or DSA are offered in the API, these are

explicitly speciﬁed only in 19 APKs in total, with the

ﬁrst use appearing in 2014.

MAC Algorithms. The situation with MAC algo-

rithms is similar to that of digital signatures algorithms.

The MAC systems are responsible for

11661

call sites

and are present in

of APKs. Still, a large portion

(

46.4

%) of the call sites are obfuscated. Nevertheless,

only two functions are called in more than 1% of the

call sites –

HMACSHA1

and

HMACSHA256

. The former

is heavily dominant throughout the studied timeline,

being responsible for 70% of the MAC call sites.

PRNGs. The functionality of PRNGs is utilized in

nearly 3% of the APKs, being responsible for

10381

call sites. A relatively small fraction of the call sites

(

6.6

%) are obfuscated, and virtually all unobfuscated

call sites (over 90%) can be attributed to SHA1PRNG.

Key Agreement Protocols. The key agreement API’s

functionality consists purely of the Difﬁe-Hellman

protocol (DH) for key exchange. Concerning the DH

protocol parameters, we can only differentiate between

the use of DH over ﬁnite ﬁelds or elliptic curves. The

key agreement API appears only in 53 APKs over

the nine years, occupying 87 call sites in total. 36 of

the APKs use elliptic curves, whereas 20 APKs use

obfuscated calls. Interestingly, only a single APK was

detected to be explicitly using DH over ﬁnite ﬁelds.

The dominant use of elliptic curves over ﬁnite ﬁelds

is in contrast with the situation in digital signature

algorithms.

Worth noting, we did not thoroughly explore how

cryptographic primitives were employed in the context

of the applications (e.g., to send SMS, encrypt data, et

cetera). This analysis is extremely complex due to the

variety of application contexts, and it is hardly feasible

with static analysis. However, to give readers possible

directions about the motivations for using cryptogra-

phy in malware, we manually inspected a small subset

of samples during our study. For the categories deﬁned

in Section 2.1 we documented the following use-cases:

(i) Hash functions are generally used to ﬁngerprint the

attributes of a device (IMEI, Android version, etc.), to

hash whole ﬁle or string, or to construct home-brew

MACs or signature primitives; (ii) Public-key encryp-

tion was witnessed to provide hybrid encryption, or

to construct digital signature algorithms from its basic

blocks; (iii) Symmetric encryption is used to encrypt

ﬁles, as well as strings, and to obfuscate expressions

directly in the source code. We also witnessed the use

of PRNG to generate random keys (often with static

seeds) or to provide nonces for more complex sce-

narios; (iv) Both key agreement protocols and digital

signature algorithms were found to empower more

complex network protocols, e.g., SASL (Simple Au-

thentication and Security Layer (Isode Limited and

OpenLDAP Foundation, 2006)); (v) We report no sur-

prising use-cases for MAC primitives that serve their

original purpose of data authentication.

4 MACHINE LEARNING AND

CRYPTOGRAPHIC API

In this section, we answer RQ.2: Can information

about cryptography improve Android malware detec-

tion? To do so, we analyze the outcome of the experi-

ments outlined in Section 2.4.

4.0.1 Cryptography-based Learning Model

We trained a random forest model based only on

cryptography-related features described in Section 2.4

and compared its performance to

R-PackDroid

. To

obtain a valid comparison, we replicated the ex-

perimental setup of the original

R-PackDroid

pa-

per (Maiorca et al., 2017), taking 10 thousand appli-

cations divided 50:50 into benign/malicious, and split

50:50 into training/test set. Our classiﬁer achieved

62.4%

F1 score on the malicious samples (see also

Table 4), showing that cryptographic information is

discriminant enough to separate malicious from benign

samples. Even though that

R-PackDroid

performs sig-

SECRYPT 2022 - 19th International Conference on Security and Cryptography

128

0 0.01 0.02 0.03 0.04

Number of MD5 constructors

Number of hash function imports

Number of PRNG imports

Number of classes that import hash functions

Number of cryptographic key imports

Sqrt. of total number of unique crypto. imports

Sqrt. of total number of crypto. imports

Number of DES cipher constructor imports

Number of PRNG constructors

Number of digital signature imports

0.038

0.015

0.013

0.01

0.008

0.007

|SHAP value| (effect on model output)

Figure 2: A representation of 10 most inﬂuential features (their

SHAP

values are high, averaged over all samples). These

represent the spots in cryptographic API with the largest difference in usage between malicious and benign samples. The x-axis

shows the average effect on the model output in either direction. The model outputs values from 0 (benign) to 1 (malicious).

niﬁcantly better than our system

, our classiﬁer was

able to correctly identify 88/180 malicious samples

that were misclassiﬁed as benign by

R-PackDroid

(with all 211 features). This shows that cryptographic

API can assist the classiﬁcation of samples that would

otherwise ﬂy under the radar of existing classiﬁers.

4.0.2 Explanations of Decisions

In Figure 2, we present the 10 most inﬂuential fea-

tures of the cryptographic-API classiﬁer, based on the

SHAP values calculated for the whole dataset (global

explanation) according to the methodology from Sec-

tion 2.4. Note that the model outputs values from 0

(benign) to 1 (malicious), and the expected value of the

model on a balanced dataset is hence

0.5

. The SHAP

value of a feature thus represents a deviation from this

expected value after inspecting a particular feature.

It is rather interesting to see that the usage of cer-

tain hashing functions is discriminative w.r.t. mali-

ciousness of the samples. More speciﬁcally, weak hash

functions (MD5) are especially used in malicious sam-

ples (as also reported by the analysis in Section 3.1),

and they constitute an important indicator of mali-

ciousness. Additionally, the classiﬁer observes the

general number of imported cryptographic functions.

An increasing number of imported functions lead to

an increasing suspicion of maliciousness.

Concerning the local explanation, we present an

example related to the malware with MD5 hash

Remember that our goal was not to build a better clas-

siﬁer but to show that it is possible to distinguish between

malicious and benign Android applications only by their

cryptographic API usage.

Table 4: Comparison of performance of malware classiﬁers

without and with cryptographic API features. The perfor-

mance metrics measure the result of the malicious samples.

Enhancing the limited RPackDroid with cryptographic fea-

tures causes

4.18%

increase of precision and

5.61%

increase

of recall on the Androzoo dataset, projecting into

4.86

% F1

score increase.

Classiﬁer # features F1 score

Cryptographic API 189 62.40%

RPackDroid (full) 211 92.71%

RPackDroid (limited) 10 76.47%

RPackDroid + cryptoAPI 10 + 189 81.33%

e1001da40929df64443f6d4037aa3a9f

. VirusTotal

classiﬁes this sample as a riskware of type SMSpay.

By extracting the local SHAP values (Figure 3), it is

possible to see signiﬁcant importance of a DES en-

cryption that steers the classiﬁers’ decision towards

maliciousness. Driven by this explanation, we manu-

ally disassembled the sample and looked for the usage

of DES-related cryptographic API. We found that, in

this case, DES is used to encrypt sensitive information,

such as the phone device id, which is then subsequently

exﬁltrated to a remote server. This detail is especially

useful to attract the attention of the analyst towards

malicious operations carried out by the sample. Also,

note that this sample employs name obfuscation, and

the required effort to carry out similar analysis without

such guidance would be higher.

4.0.3 Enhancing Existing Classiﬁer with

Cryptographic API Features

In the original work,

R-PackDroid

achieved 97%

F1 score distinguishing between three classes (ran-

A Longitudinal Study of Cryptographic API: A Decade of Android Malware

129

0.5 0.6 0.7 0.8 0.9 1.0

Model output

180 less important features

Number of secretkeyfactory class imports

Number of PRNG imports

Number of generateSecret() call sites

Number of DES generated keys

Number of Cipher class imports

Number of DES cipher constructors

Number of DES key constructor imports

Number of secureRandom(generateSecret()) call sites

Number of DES/CBC/PKCS5Padding constructors

180 less important features

Number of secretkeyfactory class imports

Number of PRNG imports

Number of generateSecret() call sites

Number of DES generated keys

Number of Cipher class imports

Number of DES cipher constructors

Number of DES key constructor imports

Number of secureRandom(generateSecret()) call sites

Number of DES/CBC/PKCS5Padding constructors

+0.09

+0.06

+0.05

+0.03

+0.02

+0.1

Figure 3: Local impact of 10 most inﬂuential features w.r.t the models’ prediction on a particular sample. The shown APK is a

malware of SMSpay type. It exﬁltrated DES-encrypted data through SMS. Apart from the features, the ﬁgure also depicts how

the value of each feature shifts the models’ output from a neutral score

0.5

to the ﬁnal output

that labels the APK as malware.

somware in addition to malware/benign). Leverag-

ing the source code of authors, we achieved

92.71%

F1 score with

R-PackDroid

on the Androzoo dataset.

Thus, enhancing this classiﬁer would not bring a big

performance gain. Hence, we decreased the number

of features employed by the classiﬁer to 10, reducing

F1 score to

74.47%

when averaged over different 10-

tuples of features. We then added the cryptographic

features following the methodology from Section 2.4.

We document an increase of classiﬁers’ perfor-

mance when enhanced with crypto features. Our re-

sults demonstrate that, while the margin for improve-

ment is not huge, adding cryptographic features signif-

icantly improved both recall (

+5.61%

), and precision

(

+4.18%

) of the classiﬁer, which in turn increases the

F1 score by +4.86%. See the summary in Table 4.

5 DISCUSSION AND

LIMITATIONS

Our main goal was to provide a comprehensive

overview of the role of cryptography in the analy-

sis of Android applications and malware detection.

As explained in Section 3.1, we found a signiﬁcant

amount of obfuscation in recent malicious applications,

which prevented us from providing detailed informa-

tion about their usage of cryptography. We recognize

that this is an inherent limitation of static analysis.

While other static techniques such as program slic-

ing may provide additional insights, we believe that

dynamic analysis is the only reliable way to defeat dy-

namic code loading and other types of packing. How-

ever, it is infeasible to analyze more than half million

of APKs with dynamic analysis. Hence, we believe

that our proposed approach constitutes the right bal-

ance between effectiveness, precision, and analysis

time.

We also point out that possible biases can be

present in the data we analyzed. In particular, we

did not have control over the contents of the Androzoo

dataset. According to the indications provided by the

Androzoo authors (Allix et al., 2016), we can safely

rule out the presence of possible duplicates for appli-

cations coming from the same sources (e.g., the same

stores). We point out that the risk of ﬁnding dupli-

cates across stores is signiﬁcantly lower for malicious

applications than benign ones. Nevertheless, even if

such duplicates were found, their number should not

inﬂuence a large-scale analysis.

6 RELATED WORK

Most of the research on cryptographic API in Android

is mainly focused on benign applications where the

ultimate goal is to mitigate its misuse. Several steps

are needed to achieve this, and the respective works

usually treat one or two steps at a time. We can sum-

marize these steps as follows: (i) Inferring the rules of

cryptographic API misuse; (ii) Evaluation of crypto-

graphic API misuse; (ii) Attribution of cryptographic

API misuse; (iv) Automatic cryptographic API repairs.

The following paragraphs discuss the related research

SECRYPT 2022 - 19th International Conference on Security and Cryptography

130

for all these steps mentioned above.

Inferring Rules of Cryptographic API Misuse. In

the area of inferring the rules of cryptographic API

misuse, the goal is to create a list of speciﬁcations for

developers and researchers that imply the insecure use

of cryptography. Such rules can be crafted manually as

done in (Egele et al., 2013; Chatzikonstantinou et al.,

2016; Shuai et al., 2014). However, this approach

does not scale well, leading to the works (Paletov

et al., 2018; Gao et al., 2019) that attempt to infer

these rules from git commits, conjecturing that newly

introduced commits typically eliminate security vul-

nerabilities from the code. Surprisingly, Paletov et

al. (Paletov et al., 2018) reported success with this

approach, whereas chronologically later work (Gao

et al., 2019) commends against the initial assumption.

Evaluation of Cryptographic API Misuse. After

having a set of rules that suggest security violations

at hand, it is vital to explore these violations in the

Android applications market. While more powerful

dynamic analysis is employed in (Chatzikonstantinou

et al., 2016; Shuai et al., 2014) to show that more than

half of the examined applications violate the static set

of rules, the application dataset is relatively small (size

< 100

). On the contrary, the static analysis approach

used by Egele et al. in (Egele et al., 2013) allowed

examining a large dataset of

145

thousand benign ap-

plications to reveal that

10.4

% of them uses some form

of cryptography.

88%

of such applications were found

to violate some rule of secure cryptography usage.

These results were conﬁrmed by a later study (Mus-

lukhov et al., 2018) that gathered a new dataset of

109

thousand APKs that contain at least one cryptographic

API call and showed the analogical proportion of in-

secure applications. Static rules were substituted by

a more sophisticated deﬁnition language in (Kr

uger

et al., 2018) where 10 000 Android applications were

analyzed and misuses detected in over 95% of cases.

Some of the solutions above are impractical to run

against large projects due to many false positives. This

is treated by

CryptoGuard

(Rahaman et al., 2019)

that prunes the alerts to achieve

98%

precision and

is successfully run against real-world projects. As of

early 2022, an open-source

CRYLOGGER

(Piccolboni

et al., 2021) can well complement

CryptoGuard

, as

it is based on dynamic analysis and was tested on a

sufﬁciently large dataset (approx. 1800 applications).

In 2021, the ﬁrst systematic evaluation study (Ami

et al., 2021) was published that allows to measure the

quality of such detectors and reveals many ﬂaws in

their design or implementation.

Concentrating on the TLS protocol, the work (Fahl

et al., 2012) from 2012 analyzed

thousand Android

applications to reveal inadequate TLS usage in 8% of

cases. The authors also managed to launch

MiTM

attacks against selected applications. Iterating on this

effort, an article (Oltrogge et al., 2021) studied Net-

work Security Conﬁguration ﬁles

in Android. The

authors revealed that

88%

of applications employing

custom settings downgrade the security compared to

the default conﬁguration. Also, the authors penetrated

Google Play safeguards that are supposed to protect

from publishing applications vulnerable to MiTM.

Attribution of Cryptographic API Misuse. Reliable

third-party package detection is central for attribution

of misuse. This problem has been addressed, e.g.,

in (Wang et al., 2015; Ma et al., 2016b; Backes et al.,

2016; Backes et al., 2016) where matching algorithms

were proposed to reliably detect third-party libraries.

As already discussed, a systematic review (Zhan et al.,

2020) then compared these detectors from various per-

spectives conﬁrming that

LibRadar

is superior to oth-

ers when used for large-scale analysis due to result

quality comparable with the most precise tools, yet

running much faster.

Automatic Cryptographic API Repairs. More dis-

tant to our research are papers that concentrated on

automatic cryptographic API misuse repairs. From

this area of research, we refer the reader to (Ma et al.,

2016a; Zhang et al., 2017).

Study of Cryptography in Android Malware. We

point out that all the aforementioned research on the

Android platform did not concentrate on cryptographic

API in malicious applications or its comparison to the

benign landscape. Our work in this paper aims to ﬁll

this gap in knowledge.

7 CONCLUSIONS AND FUTURE

WORK

In this paper, we provide a longitudinal analysis of how

cryptographic API was typically employed in Android

malware in the years 2012-2020. We analyzed

603937

applications and extracted over 1 million call sites that

have been extensively analyzed by extracting various

statistics. The attained results showed the following:

Use of weak hash functions. Most malicious appli-

cations featuring cryptographic routines resorted

to weak MD5 hash functions.

Late transition from DES to AES. It is worth point-

ing out one aspect of comparison with benign sam-

ples. In the symmetric cipher category, malware

authors adopted weak DES to modern AES only

developer.android.com/training/articles/

security-conﬁg

A Longitudinal Study of Cryptographic API: A Decade of Android Malware

131

in 2015, while AES was the most popular cipher

in benign samples already in 2012.

Very limited use of third-party cryptographic li-

braries. Our analysis showed that Android appli-

cation authors favor using system-based libraries

to deliver cryptographic functionality.

Contrast between malicious and benign usage of

cryptography. Our study shows that cryptographic

API is generally more frequent in malware than in

benign samples (in relative measures).

Building a cryptography-based machine learning

model, we showed a signiﬁcant difference in cryptogra-

phy deployment between benign and malware samples.

We demonstrated that a learning-based model based on

cryptography alone could separate between benign and

malicious samples with good performance. Moreover,

we showed that explaining the decision of the classiﬁer

can expose intriguing links between cryptography and

malicious actions that are typically carried out by mal-

ware. In particular, these techniques constitute a valid

resource to guide the analysts towards discovering crit-

ical characteristics of the examined malicious samples.

Moreover, cryptographic features until now neglected

can be employed to further improve state-of-the-art

malware detectors.

Our results open door to various follow-up work.

For instance, it would be interesting to cluster malware

samples into families based on its usage of cryptog-

raphy. Likewise, future work can more closely focus

on understanding for what purpose speciﬁc crypto-

routines are employed in Android malware, thus better

understanding and proﬁling the characteristics of mal-

ware authors. This could, for instance, conﬁrm or

dismiss our conjecture that weak hash functions are

not used for integrity-critical operations in malware.

Last but not least, one could employ more powerful

dynamic analysis to check if our ﬁndings hold also for

packed and obfuscated applications.

ACKNOWLEDGEMENTS

This work was partially supported by the project PON

AIM Research and Innovation 2014–2020 - Attraction

and International Mobility, funded by the Italian Min-

istry of Education, University and Research; and by

the European cybersecurity pilot CyberSec4Europe.

Vashek Matyas was supported by Czech Science Foun-

dation project GA20-03426S. Adam Janovsky was

supported by Invasys company. We are grateful to

Jonas Konecny who ran the initial machine learning

experiments. We also thank Avast for providing the

dynamic-analysis tool apklab.io.

REFERENCES

Allix, K., Bissyand

e, T. F., Klein, J., and Le Traon, Y. (2016).

AndroZoo: Collecting millions of Android apps for the

research community. In Proc. of MSR ’16, pages 468–

471. ACM.

Ami, A. S., Cooper, N., Kaﬂe, K., Moran, K., Poshyvanyk,

D., and Nadkarni, A. (2021). Why Crypto-detectors

Fail: A Systematic Evaluation of Cryptographic Mis-

use Detection Techniques. arXiv:2107.07065 [cs].

Backes, M., Bugiel, S., and Derr, E. (2016). Reliable third-

party library detection in android and its security appli-

cations. In Proc. of CCS ’16, pages 356–367. ACM.

Biham, E. and Shamir, A. (1991). Differential cryptanalysis

of DES-like cryptosystems. Journal of CRYPTOLOGY,

4(1):3–72.

BusinessOfApps (2022). Android statistics. http://

businessofapps.com/data/android-statistics.

Chatzikonstantinou, A., Ntantogian, C., Karopoulos, G.,

and Xenakis, C. (2016). Evaluation of Cryptography

Usage in Android Applications. In Proc. of EAI BCT

’16, pages 83–90. ACM.

Chen, S., Xue, M., Tang, Z., Xu, L., and Zhu, H. (2016).

Stormdroid: A streaminglized machine learning-based

system for detecting android malware. In Proceedings

of the 11th ACM on Asia Conference on Computer

and Communications Security, ASIA CCS ’16, pages

377–388, New York, NY, USA. ACM.

Daniel, A., Michael, S., Malte, H., Hugo, G., and Rieck, K.

(2014). Drebin: Efﬁcient and explainable detection of

android malware in your pocket. In Proceedings 2014

Network and Distributed System Security Symposium,

pages 23–26, San Diego, CA. The Internet Society.

Egele, M., Brumley, D., Fratantonio, Y., and Kruegel, C.

(2013). An empirical study of cryptographic misuse in

android applications. In Proc. of CCS’13, pages 73–84.

ACM.

Fahl, S., Harbach, M., Muders, T., Smith, M., Baumg

artner,

L., and Freisleben, B. (2012). Why eve and mallory

love android: An analysis of android SSL (in)security.

In Proc. of CCS ’12, pages 50–61. ACM.

Gao, J., Kong, P., Li, L., Bissyande, T. F., and Klein, J.

(2019). Negative Results on Mining Crypto-API Usage

Rules in Android Apps. In Proc. of MSR ’19, pages

388–398. IEEE.

Isode Limited and OpenLDAP Foundation (2006). RFC

4422 - simple authentication and security layer (sasl).

http://tools.ietf.org/html/rfc4422. March 2, 2022.

uger, S., Sp

ath, J., Ali, K., Bodden, E., and Mezini, M.

(2018). CrySL: An Extensible Approach to Validating

the Correct Usage of Cryptographic APIs. In Proc. of

ECOOP ’18, LIPIcs vol. 109, pages 10:1–10:27. LZI.

Kursa, M. B., Rudnicki, W. R., et al. (2010). Feature selec-

tion with the boruta package. J Stat Softw, 36(11):1–13.

Lundberg, S. M. and Lee, S.-I. (2017). A uniﬁed approach

to interpreting model predictions. In Proc. of NIPS ’17,

pages 4765–4774. Curran Associates, Inc.

Ma, S., Lo, D., Li, T., and Deng, R. H. (2016a). CDRep:

Automatic Repair of Cryptographic Misuses in An-

SECRYPT 2022 - 19th International Conference on Security and Cryptography

132

droid Applications. In Proc. of ASIACCS ’16, pages

711–722, Xi’an, China. ACM.

Ma, Z., Wang, H., Guo, Y., and Chen, X. (2016b). LibRadar:

Fast and accurate detection of third-party libraries in

Android apps. In Proc. of ICSE ’16, pages 653–656,

Austin, Texas. ACM.

Maiorca, D., Mercaldo, F., Giacinto, G., Visaggio, C. A.,

and Martinelli, F. (2017). R-PackDroid: API package-

based characterization and detection of mobile ran-

somware. In Proc. of SAC ’17, pages 1718–1723.

ACM.

McAfee Labs (2019). McAfee labs threats report,

august 2019. http://mcafee.com/enterprise/en-us/

threat-center/mcafee-labs/reports.html. March 7, 2022.

Melis, M., Maiorca, D., Biggio, B., Giacinto, G., and Roli, F.

(2018). Explaining black-box android malware detec-

tion. In 26th European Signal Processing Conference,

EUSIPCO 2018, pages 524–528, Rome, Italy. IEEE.

Melis, M., Scalas, M., Demontis, A., Maiorca, D., Biggio, B.,

Giacinto, G., and Roli, F. (2022). Do gradient-based

explanations tell anything about adversarial robustness

to android malware? Int. J. Mach. Learn. Cybern.,

13(1):217–232.

Menezes, A. J., Katz, J., Van Oorschot, P. C., and Vanstone,

S. A. (1996). Handbook of Applied cryptography. CRC

press.

Muslukhov, I., Boshmaf, Y., and Beznosov, K. (2018).

Source Attribution of Cryptographic API Misuse in

Android Applications. In Proc. of ASIACCS ’18, pages

133–146. ACM.

Oltrogge, M., Huaman, N., Amft, S., Acar, Y., Backes, M.,

and Fahl, S. (2021). Why eve and mallory still love

android: Revisiting TLS (In)Security in android appli-

cations. In Proc. of USENIX ’21, pages 4347–4364.

USENIX.

Paletov, R., Tsankov, P., Raychev, V., and Vechev, M. (2018).

Inferring crypto API rules from code changes. In Proc.

of PLDI ’18, pages 450–464. ACM.

Piccolboni, L., Guglielmo, G. D., Carloni, L. P., and

Sethumadhavan, S. (2021). CRYLOGGER: Detect-

ing Crypto Misuses Dynamically. In Proc. of IEEE SP

’21, pages 1972–1989. IEEE.

Rahaman, S., Xiao, Y., Afrose, S., Shaon, F., Tian, K., Frantz,

M., Kantarcioglu, M., and Yao, D. D. (2019). Cryp-

toGuard: High Precision Detection of Cryptographic

Vulnerabilities in Massive-sized Java Projects. In Proc.

of CCS ’19, pages 2455–2472. ACM.

Salem, A. (2020). Towards accurate labeling of Android

apps for reliable malware detection. arXiv preprint

arXiv:2007.00464.

Shapley, L. (1953). A value for n-person games. contribu-

tions to the theory of games. Annals of mathematics

studies (2).

Shuai, S., Guowei, D., Tao, G., Tianchang, Y., and Chenjie,

S. (2014). Modelling Analysis and Auto-detection of

Cryptographic Misuse in Android Applications. In

Proc. of DASC ’14, pages 75–80. IEEE.

Stevens, M., Bursztein, E., Karpman, P., Albertini, A., and

Markov, Y. (2017). The ﬁrst collision for full SHA-1.

In Proc. of CRYPTO ’17, pages 570–596. Springer.

Wang, H., Guo, Y., Ma, Z., and Chen, X. (2015). WuKong: A

scalable and accurate two-phase approach to Android

app clone detection. In Proc. of ISSTA ’15, pages

71–82. ACM.

Wang, X. and Yu, H. (2005). How to break MD5 and other

hash functions. In Proc. of EUROCRYPT ’05, pages

19–35. Springer.

Zhan, X., Fan, L., Liu, T., Chen, S., Li, L., Wang, H., Xu,

Y., Luo, X., and Liu, Y. (2020). Automated third-party

library detection for Android applications: are we there

yet? In Proc. of ASE ’20, pages 919–930. ACM.

Zhang, X., Zhang, Y., Li, J., Hu, Y., Li, H., and Gu, D.

(2017). Embroidery: Patching Vulnerable Binary Code

of Fragmentized Android Devices. In Proc. of ICSME

’17, pages 47–57. IEEE.

A Longitudinal Study of Cryptographic API: A Decade of Android Malware

133
