Estimating the Optimal Number of Clusters from Subsets of Ensembles

Afees Adegoke Odebode, Allan Tucker, Mahir Arzoky and Stephen Swift

Brunel University, London, U.K.

Keywords:

Ensemble Clustering, Subset Selection, Cluster Analysis, Number of Clusters.

Abstract:

This research estimates the optimal number of clusters in a dataset using a novel ensemble technique - a

preferred alternative to relying on the output of a single clustering. Combining clusterings from different

algorithms can lead to a more stable and robust solution, often unattainable by any single clustering solution.

Technically, we created subsets of ensembles as possible estimates; and evaluated them using a quality metric

to obtain the best subset. We tested our method on publicly available datasets of varying types, sources and

clustering difﬁculty to establish the accuracy and performance of our approach against eight standard methods.

Our method outperforms all the techniques in the number of clusters estimated correctly. Due to the exhaustive

nature of the initial algorithm, it is slow as the number of ensembles or the solution space increases; hence, we

have provided an updated version based on the single-digit difference of Gray code that runs in linear time in

terms of the subset size.

1 INTRODUCTION

Finding the number of clusters in a dataset remains

a largely unsolved problem in cluster analysis since

there is often no clear deﬁnition of what constitutes a

“cluster”. Clustering is assigning similar data points

to the same cluster and dissimilar points to different

clusters without any prior knowledge of the members’

labels (Jain et al., 1999). It can also be described

as an application that determines partitions based on

distance and correlation metrics (Swift et al., 2007).

The clustering process often involves determining the

number of clusters by learning from similarity or dis-

similarity between objects or points in the dataset.

Learning or estimating clusters in datasets is a sub-

tle way of unravelling the pattern or the underlying

structure in the dataset from where other analyses can

commence.

This paper employed a novel ensemble method to

estimate the number of clusters in datasets. Ensem-

ble clustering, ﬁrst introduced by (Strehl and Ghosh,

2002), is a technique that improves clustering perfor-

mance by generating multiple partitions of a dataset

and combining them to create a summary clustering

solution. Ensemble methods have various applica-

tions in classiﬁcation techniques (Giacinto and Roli,

2001), (West et al., 2005), and due to its success-

ful application, attempts have been made to apply

the same model in unsupervised learning. Two main

questions that often arise in a clustering ensemble are:

(i) What is the best way of generating the cluster-

ings and combining them into representative so-

lutions while maintaining diversity and promot-

ing accuracy?

(ii) What is the optimal way of identifying the best

solution from the pool of representative solu-

tions(subsets)?

We attempt to answer both questions by creating

all possible subsets of ensembles and generating an

agreement matrix between outputs from the differ-

ent clustering algorithms. The agreement matrix con-

tains cluster similarity from the clusterings for each

value of the number of clusters (k). The subset with

the maximum agreement as determined by our quality

function is the best subset, and the best subset’s index

is the number of clusters in the dataset. An exhaus-

tive search for the best subset can be computationally

intensive as the clusterings increase. Therefore, we

used a technique that maps outputs from the agree-

ment matrix to Gray codes

successive members to

create subsets. We provided a run-time of both im-

plementations (quality and update quality). The re-

sults show that our approach is accurate for different

datasets, distributions, and datasets with outliers com-

pared with similar methods. Some methods described

Gray code is the weighted code where only one-bit

changes for every two consecutive members.

Odebode, A., Tucker, A., Arzoky, M. and Swift, S.

Estimating the Optimal Number of Clusters from Subsets of Ensembles.

DOI: 10.5220/0011275000003269

In Proceedings of the 11th International Conference on Data Science, Technology and Applications (DATA 2022), pages 383-391

ISBN: 978-989-758-583-8; ISSN: 2184-285X

383

below depend on speciﬁc data distribution, for exam-

ple, Gaussian distribution and may suffer from over-

ﬁtting. Our approach does not because the estimated

clusters rely on the agreement matrix generated from

multiple clusterings.

Cluster analysis is essential in exploratory data

analysis and data cleaning with many practical ap-

plications, which includes: character recognition (Ar-

ica and Yarman-Vural, 2001), tissue segmentation and

tumour identiﬁcation (Vishnuvarthanan et al., 2016),

also in applications involving astronomical data clas-

siﬁcation (Zhang and Zhao, 2004), and more recently

in bioinformatics and related applications (Higham

et al., 2007). Our primary motivation for this work

is two-fold: accuracy and effort. Accuracy is mea-

sured as the correctly estimated number of clusters

compared with similar metrics, and effort is how fast

the prediction takes or the runtime. It has been shown

(Ayed et al., 2018) that the average Weighted Kappa

)

between pair of inputs highly correlates to the

average Weighted Kappa (W

) of each input compared

to the expected number of clusters (gold standard).

We can thus infer that selecting the best subset (sub-

set with the highest average Weighted Kappa) should

strongly correlate to the gold standard without know-

ing it beforehand. Therefore, it can be used as a proxy

for the gold standard. The following are some of our

contributions:

• We design a selection scheme that searches for the

subset/solution from the ensemble of input clus-

tering techniques.

• We formulate an objective function that deter-

mines the quality of a subset and ﬁnds the subset

that optimises the objective function(quality).

• We establish a mathematical framework for the

quality metrics. The metrics allow larger subsets

to be scored in parity with smaller subsets using

the threshold.

The rest of this paper is organised as follows: Sec-

tion 2 contains a review of the literature and an intro-

duction to some standard methods used in estimating

the number of clusters in datasets. Section 3 lays out

the framework of our ensemble technique, whilst Sec-

tion 4 describes the datasets used for the experiments.

The experimental detail is in section 5 and the results

of the experiments and their comparison with exist-

ing methods are in Section 6. The conclusions and

recommendations are in section 7.

Weighted Kappa is a metric that compares expected

accuracy with observed accuracy based on the agreement

between the two, and it is equivalent to the Adjusted Rand.

2 ESTIMATING THE NUMBER

OF CLUSTERS

There are several methods for determining the num-

ber of clusters in datasets; most are dated. We selected

a range of standard methods and indices to compare

with our method. The ﬁrst category of methods we

used are those that cluster datasets and then report the

number of clusters; essentially, they are clustering al-

gorithms. We consider three methods in this category.

First, X-means (Pelleg et al., 2000) for example, pro-

vides a framework for estimating the number of clus-

ters in datasets using k with the best Bayesian Infor-

mation Criterion (Kass and Wasserman, 1995) score.

However, X-means assumes that the width of the co-

variances is identical and spherical, thus limiting the

method to speciﬁc data distribution. X-means is one

of the methods we used in generating the initial clus-

terings. (Hamerly and Elkan, 2003) proposed the G-

means algorithm. The algorithm grows the value of

k starting with a small number of centres and tests if

the data is from a Gaussian distribution using a statis-

tical test. Those not from Gaussian distribution are

split into two repeatedly until all assume Gaussian

distribution. Although G-means works well, if the

data is well separated, it can encounter difﬁculty with

overlapping data. In this category, we also consid-

ered the Expectation-Maximisation (EM) algorithm.

Unlike distance-based and hard clustering algorithms

such as k-means, EM constructs statistical models of

the data and accommodates categorical and continu-

ous data ﬁelds with varying degrees of data member-

ship in multiple clusters.

The second category of methods we reviewed

against our ensemble techniques are the nineteen clas-

sical methods from the R’s nbclust

package (Char-

rad et al., 2014); we will explain a few of the meth-

ods here and report on the top ﬁve based on the

outputs. One of the methods is Gap statistics. It

compares the total intra-cluster variation for differ-

ent values of clusters with their expected values un-

der speciﬁc distribution, for example, the null ref-

erence distribution. Although it is good at identify-

ing well-separated clusters, it can sometimes overes-

timate the number of clusters for exponential distri-

butions (Sugar and James, 2003). We also compared

our method with the Silhouettes (Rousseeuw, 1987)

technique. The Silhouettes technique depends on par-

titions from the clustering and the collection of prox-

nbclust provides 30 indices for determining the num-

ber of clusters and proposes to the user the best clustering

scheme from the different results obtained by varying all

combinations of number of clusters, distance measures, and

clustering methods.

DATA 2022 - 11th International Conference on Data Science, Technology and Applications

384

imities between the objects to construct the Silhou-

ette plot. Lastly, we included the Calinski Harabasz

(Calinski and Harabasz, 1974) (CH) index, Ball (Ball

and Hall, 1965), Ratkwosky (Ratkowsky and Lance,

1978), Krzanowski Lai (Krzanowski and Lai, 1988),

and Milligan (Milligan, 1981) as implemented in R’s

nbclust package (Charrad et al., 2014) . The Calinski

index, like all the other indices, maximises the CH in-

dex and is computed as shown in equation 1. Where

k is the number of clusters, n is the number of data

points, B

is the between clusters sum of squares, and

is the within-cluster sum of squares. The rest of

the methods in this category seek to maximise a value

or an index. We selected the best ﬁve of the methods,

and the results are as presented in section 7.

CH(k) =

/(k −1)

/(n −k)

(1)

In summary, the common theme of the above

methods is that they are all based on a single input

method, such as k-means or hierarchical clustering,

for generating the clusterings. The current method ex-

plores multiple clusterings to increase diversity, thus

encouraging inputs from both strong and weak clus-

terings for the optimal estimate. However, both ap-

proaches seek to maximise a metric deﬁned as a func-

tion of the number of clusters. The index that corre-

sponds to the maximum value of the metric as shown

in Figure 1 is the estimated number of clusters in the

dataset. None of the approaches are guaranteed to

perform well in all situations; they tend to over-ﬁt,

under-ﬁt, or are too computationally costly, but we

are optimistic that our method has effectively reduced

the over-ﬁtting problem. Section 3 describes the en-

semble framework shown in Figure 2.

3 THE ENSEMBLES

FRAMEWORK

The framework we presented is general to most en-

semble clustering (Hubert and Arabie, 1985), (Swift

et al., 2004); however, we focus our attention on

the two crucial processes in the ensemble framework:

the pre-processing and optimisation stages. The pre-

processing stage uses clusterings from the input meth-

ods to construct the agreement matrix. The optimi-

sation determines the optimal clustering arrangement

using an objective function applied to the subsets.

More theoretical foundations for clustering ensemble

can be found in the following references (Strehl and

Ghosh, 2002), (Fern and Brodley, 2004), (Li et al.,

2007). The current design of the ensemble consists

Figure 1: Estimating Number of Clusters.

Figure 2: Ensemble Framework.

of four key stages: the generation of the base clus-

terings, the construction of an agreement matrix from

the input clusterings, the creation of subsets from the

agreement matrix and determining the subset that op-

timises the objective function. The main motivation

for creating subsets in this model is twofold. The ﬁrst

is getting potential solution space and then searching

for the best subset from the pool of possible solutions.

The current implementation performs an exhaustive

search of all subsets. Figure 2 summarises the differ-

ent stages in the current implementation. To reduce

the complexity associated with an exhaustive search

of the solution space, especially as the input clustering

increases and for huge datasets, we provided a math-

ematical framework and an improved version of the

search process in the update quality, as shown in Sec-

tion 5.2. We showed that the update quality function

runs in linear time in terms of the subset size.

4 DATA DESCRIPTION

The datasets presented are available on: UCI machine

learning repository (Dua and Graff, 2017), the univer-

sity of Finland’s clustering basic benchmark (Fr

anti

and Sieranoja, 2018) and Outlier Detection Datasets

(Rayana, 2016) among others in various formats. The

datasets serve as the benchmark for several cluster-

ing algorithms, and the collection contains thirteen

real-world and ﬁfteen artiﬁcial datasets. In addition,

there are both 2D and 3D continuous-valued datasets.

We started with two-hundred and ninety-two (292)

Estimating the Optimal Number of Clusters from Subsets of Ensembles

385

Table 1: Dataset FEATURES.

SN Datasets #Clusters Attributes #Instances

1 Aml28 5 2 804

2 Atom 2 3 800

3 BezdekIris 3 4 150

4 Blobs 3 2 300

5 Cassini 3 2 1000

6 Compound 6 2 399

7 Curves1 2 2 1000

8 Gaussian-500 5 2 3000

9 Glass 6 9 214

10 Hepta 7 3 212

11 Longsquare 6 2 900

12 Lsun 3 2 400

13 Pearl 3 2 266

14 Pmf 5 3 649

15 Shapes 4 2 1000

16 Size1 4 2 1000

17 Size2 4 2 1000

18 Spherical-52 5 2 250

19 Square2 4 2 1000

20 Synthetic-Control 6 60 600

21 Tetra 4 3 400

22 Tetragonular-bee 9 15 236

23 ThreeMC 3 2 400

24 Traingle1 4 2 1000

25 Twosp2glob 4 2 2000

26 Vehicle 4 18 846

27 Veronica 7 8 206

28 Zelnik3 3 2 266

datasets. Some of which were eliminated because of

one or a combination of the followings:

• Dataset failed to cluster - no match at all to the

published number of clusters (gold standard).

• The data size is less than 100 instances - too small.

• There are a large missing values- many clustering

methods cannot cope with missing values.

We used datasets from various sources, including bio-

medical, ecological, statistical, and time-series. The

attributes of the datasets range from 3 to 100, and the

instances are up to 3000. The datasets contain the

actual number of clustering arrangements as reported

in table 1.

4.1 Subsets Generation

Different approaches exist in the literature for produc-

ing the initial partitions, including generating clus-

terings for different values from a single clustering

method or using multiple clustering methods to gener-

ate clusterings. The current approach combines both.

In generating the subsets, we have a set of input clus-

tering arrangements ranging from k= 2 to k =

√

is the commonly suggested maximum number of clus-

ters when the number is unknown (Kent et al., 2006),

where n is the number of observations. To select the m

clusterings for input, we ranked forty variants of dif-

ferent clustering algorithms and selected the top ten.

We selected the top ten based on the algorithms’ per-

formance against the gold standard (expected num-

ber of clusters). Algorithms that performed poorly for

the two hundred and ninety-two datasets initially se-

lected for the experiment, for example, cases where

the Weighted Kappa is below 0.1 (Ayed et al., 2018),

were removed from the methods used for clustering

generation. The ten methods are listed below:

• Three versions of k-means: Macqueen, Hartigan-

Wong and Lloyd.

• Two Hierarchical agglomerative methods: Com-

plete and Average.

• Partition Around Medoids(PAM) : A more robust

version of k-means.

• CLARA : An extension of k-medoids.

• X-means : Partitions data into two disjoint sets.

• DBSCAN : (Density-Based Clustering of Appli-

cations with Noise (DBSCAN) and Related Algo-

rithms)

• ccfkms : k-means based on conjugate convex

functions.

First, we needed to decide the possible maximum

number of clusters k in each dataset since it is un-

known. The commonly suggested estimate that we

found in the literature when the number of clusters

is unknown was

√

n (Kent et al., 2006) where n is

the number of instances in the dataset. We combined

corresponding clustering values of k from the input

clusterings and rated the adjacent values using the

Weighted Kappa metric described above to create the

agreement matrix.

The agreement matrix for each k is used to create

the subsets. To create all possible subsets, we gener-

ated all binary codes of size 2

where m = 10 with at

least two members. We then map the binary combina-

tions to corresponding columns in the agreement ma-

trix to create subsets. For example, a string with bi-

nary values 1000110110 will form a subset compris-

ing columns/rows 1,5,6,8,9 selected from the agree-

ment matrix. The rest of the estimation is now re-

duced to ﬁnding the best subset. Equation 3 explains

the process of ﬁnding the best subset along with the

derivation of the quality metric, and the optimal clus-

ter is depicted in Figure 1.

4.2 Why Gray Codes?

The Gray code invented by Frank Gray (Doran, 2007)

is a single-distance code in which adjacent code-

words only differ by single-digit position, and it is

cyclic. These two properties of Gray code provides

a natural template for generating all possible combi-

nations of subsets from the agreement matrix, with

DATA 2022 - 11th International Conference on Data Science, Technology and Applications

386

Table 2: The weighted kappa guideline.

Weighted-kappa Agreement Strength

0.0 ≤ K ≤ 0.2 Poor

0.2 < K ≤ 0.4 Fair

0.4 < K ≤ 0.6 Moderate

0.6 < K ≤ 0.8 Good

0.8 < K ≤ 1.0 Very good

each column of the subset from the agreement ma-

trix changing from the next slightly (single-digit dif-

ference). To improve our initial quality’s speed, we

explored the single-column difference between two

successive subsets to calculate subsequent quality val-

ues from the previous quality by adding or subtracting

the difference described in detail in the update quality

function. With ten input algorithms, the total number

of Gray codes generated with at least two members

(subsets) is one thousand and thirteen (1013). Sam-

ples are shown in the matrix below, and the result for

both implementations: binary(quality) and gray code

(update quality), are the same.

Sample Gray Codes.







0 0 0 0 0 0 0 0 1 1

0 0 0 0 0 0 0 1 1 0

0 0 0 0 0 0 0 1 1 1

0 0 0 0 0 0 0 1 0 1

0 0 0 0 0 0 1 1 0 0







4.3 The Weighted Kappa Metric

The Kappa measure (k) is a metric used to compare an

expected accuracy with an observed accuracy based

on the agreement between the two. It is generally a

more robust measure than a simple per cent agreement

because it accounts for the possibility of the agree-

ment occurring by chance. It is usually expressed, as

shown in the equation below:

−p

1 −p

= 1 −

1 −p

, (2)

Where p

is the relative observed agreement among

raters (identical to accuracy), and p

is the probabil-

ity of chance agreement. If the raters are in com-

plete agreement then W

= 1. If there is no agreement

among the raters, then W

= 0. If Kappa is negative, it

implies no effective agreement between the two raters

or is worse than random.

The Weighted kappa derives from the Kappa met-

ric; it allows weight to be assigned to disagreement

between two raters. It has an agreement strength be-

tween poor to very good, and it is also equivalent to

the Adjusted Rand Index. The full guideline is shown

in Table 2 reproduced from (Swift et al., 2004)

Algorithm 1: BestSubset: Determine the best Subset.

Require: m ×m agreement matrix from clustering algorithms

Ensure: Subset with the best Quality

1: for i = 0 to 2

m−1

2: g=binary(i)

3: if nbits(g) > 1 then

4: s = subset(g)

5: count = 0

6: for a = 0 to |s|−1 do

7: for b = (a + 1) to |s| do

8: Q = wk(a,b)−T

9: count = count +1

10: end for

11: end for

12: Q = Q/count

13: if (Q > bestQ) then

14: bestSS = s

15: bestQ = Q

16: end if

17: end if

18: end for

4.4 Determining the Best Subset

In this section, we describe brieﬂy the process of de-

termining the best subset outlined in Algorithm 1.

The algorithm describes critical functions in the pro-

cess. For example, the binary in the algorithm is the

regular 2

combinations or the Gray code sequence

depending on which implementation: quality or the

update quality, respectively. The threshold value

measures the quality of the intervention introduced

through the values: 0.4, 0.6, average, and median on

the Weighted Kappa values of adjacent columns in the

subset, represented as T

. The best quality and best

subset are deﬁned as bestQ and bestSS.

5 QUALITY FUNCTIONS

DESCRIPTION

This section describes the mathematical framework

for quality and the update quality functions used to

determine the best subset.

5.1 The Quality Function

The quality function (Q) measures the accuracy of the

subset (s) to correctly estimate the number of clus-

ters in a dataset using the sum of agreements from

the Weighted Kappa of adjacent inputs taken from a

threshold value (T

). A summary of the quality of a

subset is as described in equations (3) and (4). The av-

erage Weighted Kappa value (A

) is only a part of the

selection process; if used alone to determine quality,

it would select a two-variable subset of the best W

Estimating the Optimal Number of Clusters from Subsets of Ensembles

387

Table 3: Errors: Methods and the Average Ensemble.

Datasets EM CH Gap Silhouette PtBiserial Ratkwosky Ball KL Ensemble

Aml28 0.800 0.400 0.400 0.200 0.200 0.400 0.400 0.400 0.400

Atom 3.500 3.000 0.500 3.000 3.000 1.500 0.500 0.000 3.000

BezdekIris 0.333 0.000 1.000 0.333 0.333 0.333 0.000 0.333 0.000

Blobs 0.000 0.000 0.000 0.000 0.000 0.000 0.000 1.333 0.000

Cassini 1.333 0.667 0.333 0.333 0.333 0.667 0.000 0.667 0.000

Compound 0.800 0.600 0.400 0.600 0.600 0.400 0.400 0.200 0.400

Curves1 2.000 1.667 2.333 0.333 0.333 0.333 0.000 0.333 0.000

Gaussian-500 0.000 0.000 0.000 0.000 0.400 0.200 0.400 0.200 0.000

Glass 0.429 0.143 0.429 0.714 0.714 0.571 0.571 0.714 0.429

Hepta 0.000 0.000 0.000 0.000 0.000 0.429 0.571 0.000 0.571

Longsquare 0.167 0.333 0.000 0.667 0.667 0.667 0.500 0.667 0.000

Lsun 0.667 1.000 1.000 0.667 0.333 0.000 0.000 1.000 1.000

Pearl 1.000 1.667 1.333 1.667 1.000 0.000 0.000 0.333 0.667

PMF 0.000 0.000 0.600 0.200 0.200 0.600 0.400 0.000 0.200

Shapes 1.250 0.500 0.500 0.000 0.000 0.250 0.250 0.500 0.000

Size1 0.000 0.000 0.000 0.000 0.000 0.250 0.250 0.000 0.000

Size2 0.000 0.000 0.000 0.000 0.000 0.250 0.250 0.000 0.000

Spherical˙5˙2 0.000 0.000 0.000 0.000 0.200 0.400 0.400 0.600 0.000

Square2 0.000 0.000 0.000 0.000 0.000 0.000 0.250 0.000 0.000

Synthetic˙control 0.667 0.000 0.000 0.167 0.667 0.167 0.500 0.667 0.000

Tetra 0.000 0.000 0.000 0.000 0.000 0.000 0.250 0.000 0.250

Tetragonular˙bee 0.111 0.111 0.111 0.111 0.111 0.667 0.667 0.667 0.333

ThreeMC 1.000 1.667 0.667 0.667 0.000 0.000 0.000 0.667 0.333

Triangle1 0.000 0.500 0.250 0.000 0.000 0.250 0.250 0.250 0.000

Twosp2glob 1.000 0.250 0.250 0.250 0.250 0.500 0.250 0.250 0.000

Vehicle 0.500 0.500 1.000 0.500 0.500 0.500 0.250 0.500 0.000

Veronica 0.143 0.000 0.429 0.000 0.000 1.143 0.571 0.000 0.000

Zelnik3 1.000 1.667 1.333 1.667 1.000 0.000 0.000 0.333 0.000

Average Errors 0.596 0.524 0.460 0.431 0.387 0.374 0.281 0.379 0.271

Correct Estimates 10 12 10 11 10 7 8 8 17

pair from the subset. Instead, we used A

as shown

in Figure 1 to indicate the optimal number of clusters,

but the quality determines the best subset as described

in equation 3.

Q =

∑

|s|−1

a=1

∑

|s|

b=a+1

[wk(s(a),s(b))−T

] (3)

∑

|s|−1

a=1

∑

|s|

b=a+1

[wk(s(a),s(b))]

|s|(|s|−1)

(4)

where

ˆs =

|s|(|s|−1)

;

Q = ˆsA

− ˆsT

Q = ˆs(A

−T

);

ˆs

+ T

= A

5.2 The Update Quality (

The quality function described in equation 3 takes

longer as the input clusterings increase- the runtime

is quadratic because it calculates the values of each

quality at each iteration. We developed an update ver-

sion of the quality function that uses single-digit dif-

ferences between consecutive Gray codes. The next

quality is calculated from the previous quality value

depending on the bit difference between Gray code;

If the difference from the previous is a 0, then the col-

umn’s difference in the agreement matrix is added;

otherwise, it is subtracted (This is shown as ± in

equation 7). The Gray code version of the quality

function dramatically speeds up the search process

and avoids recomputing the quality values of subsets

on every iteration. A mathematical derivation of the

updated quality function is described in equations (5),

(6), and (7).

Q =

∑

|s|

i=1

∑

|s|

j=1

[wk(s

)) −T

] (5)

Q =

∑

|s|−1

i=1

∑

|s|−1

j=1

[wk(s

) −T

]

∑

|s|−1

j=1

wk(s

,x) −T

(6)

Q = Q ±2

∑

|s|−1

i=1

wk(s

,x) −T

(7)

Lastly, we used the Weighted Kappa guideline (Swift

et al., 2004) to select two of the threshold around

the mid-point (0.4 ≡ f air, 0.6 ≡ good); we wanted

to have a mix of the good subsets (high threshold)

and the fair subsets in the cluster estimates. Also,

we examined the choice of different threshold val-

ues and how it affects the estimated number of clus-

ters, thus allowing the algorithm to explore all possi-

ble solutions for the best subset. We equally included

two standard statistical measures- average and median

Weighted Kappa. Intuitively the average Weighted

Kappa was the best option in the results as shown in

table 4. The rest of the paper describes the results,

conclusions and provide recommendations for future

research.

DATA 2022 - 11th International Conference on Data Science, Technology and Applications

388

Figure 3: Normalised Average Errors on the Twenty-Eight datasets.

(a) Update Quality. (b) Update Quality Vs Exhaustive.

Figure 4: Runtime for the Quality Metrics.

Table 4: Error Values: Fair, Moderate, Median, Average.

Datasets Fair (0.4) Moderate (0.6) Median Average

aml28 0.400 0.600 0.000 0.400

Atom 2.000 2.500 3.000 3.000

BezdekIris 0.000 0.000 0.000 0.000

Blobs 0.000 0.000 0.000 0.000

Cassini 0.333 0.333 0.333 0.000

Compound 0.200 0.600 0.400 0.400

Curves1 1.000 1.333 0.000 0.000

Gaussian500 1.000 0.600 0.400 0.000

Glass 0.571 0.143 0.429 0.429

Hepta 0.143 0.000 0.571 0.571

Longsquare 0.167 0.333 0.667 0.000

Lsun 0.000 0.000 1.000 1.000

Pearl 1.333 1.333 0.667 0.667

Pmf 0.600 0.000 0.200 0.200

Shapes 0.000 0.000 0.000 0.000

Size1 0.000 0.000 0.000 0.000

Size2 0.000 0.000 0.000 0.000

Spherical˙5˙2 0.000 0.200 0.000 0.000

Square2 0.000 0.000 0.000 0.000

Synthetic control 0.000 0.000 0.167 0.000

Tetra 0.000 0.000 0.250 0.250

Tetragonular Bee 0.333 0.333 0.333 0.333

ThreeMC 0.000 0.000 0.333 0.333

Triangle1 0.000 0.000 0.000 0.000

Twosp2glob 0.500 0.000 0.000 0.000

Vehicle 0.000 0.000 0.000 0.000

Veronica 0.000 0.143 0.000 0.000

Zelnik3 1.667 0.000 0.000 0.000

0.366 0.302 0.313 0.271

Correct Estimates 10 16 10 17

6 RESULTS AND DISCUSSIONS

This paper offered methods for estimating the num-

ber of clusters in datasets using subsets from input se-

lected from binary and the Gray code. We present the

result of four groups of experiments conducted using

different thresholds of Weighted Kappa values - aver-

age, fair, moderate and median. To ascertain which

of the four values best predict the average number of

clusters in the datasets, we recorded cases where the

predictions were off and how far off the predicted re-

sults were from the number of clusters reported as er-

rors. The cumulative errors of the datasets are shown

for each case in Table 3. We equally measure the

speed difference between the Quality and the update

Quality implementations, and the results are reported

below.

6.1 Estimated Errors

We calculated the cumulative error for the datasets as

shown in equation 8 using the absolute average dif-

ference between the predicted values for each method

taken from the actual number of clusters. We used

the absolute value of the difference to normalise the

Estimating the Optimal Number of Clusters from Subsets of Ensembles

389

errors. We compared the best threshold from the en-

sembles to the earlier-mentioned methods. The error

values in table 3 show that overall the average thresh-

old predicted seventeen of the datasets correctly, fol-

lowed by sixteen for moderate, and both fair and me-

dian had ten (10) each. Similarly, the average error of

0.271 was the best for the average threshold. There-

fore, we compare the results of the other methods with

the average threshold.

Error =

|Estimate −#Clusters|

#Clusters

(8)

Table 3 shows the errors for the eight methods com-

pared with the ensemble(average). Our ensemble pre-

dicted seventeen of the twenty-eight dataset correct

against twelve predicted by the Calinski Index (CH),

the best among methods considered. Similarly, the

best error estimate among the methods considered

was Ball=0.281. Although relatively close to the en-

semble, the number of clusters predicted correctly

was just eight (8).

We examine cases where the error from the en-

semble was higher than any of the other methods.

Five datasets are mentioned here: Atom, Compound,

Glass, Lsun and Tetragonular bee, where Ball, KL,

CH, Ptbiserial, and Expectation maximisation per-

formed much better than the ensemble, and we dis-

cuss in detail two of the dataset. First, the Atom

dataset consists of two clusters in three dimensions

with a completely overlapping convex hull, by deﬁni-

tion (Ultsch, 2004), the Atom dataset is linearly non-

separable because the ﬁrst cluster entirely encloses

the second. The four ensembles performed poorly in

the number of clusters predicted correctly with an er-

ror of 3.00 compared with KL, which correctly pre-

dicted the number of clusters in Atom. However, on

average, the correctly predicted number of clusters for

KL is eight against seventeen from the average en-

semble. We intend to examine the agreement matrix

produced from the initial clustering in-depth to ascer-

tain if the shape or the unique characteristics of the

dataset contributed to the error margin. Second, the

Lsun dataset initially published in (Thrun and Ultsch,

2021) was based on the two-dimensional version of

the dataset, and the challenge is the unique character-

istics of non-overlapping convex hulls, varying geo-

metric shapes, and pockets of outliers. At the time

of this writing, we are yet to explore factors such as

differences in the shapes of the clusters, variance be-

tween the inner clusters, and cluster separations to

see how they may have contributed to the error es-

timate observed in the ensemble. In conclusion, the

four ensemble technique’s error is less on average

for all datasets. Second, the number of datasets cor-

rectly estimated compared with the actual clusters in

the datasets also conﬁrms that the clustering ensem-

ble is a preferred alternative to all the other methods

considered.

6.2 Quality vs Update Quality

The update quality uses the previous subset qual-

ity value to calculate the next quality. It compares

the pairs of the subset (the unique pairs) for differ-

ence, and depending on the difference in combina-

tion; the next subset quality is calculated as an update

Q by adding or subtracting based on the difference,

as shown in equation 7. Using previous values of the

quality in calculating the next quality improves the

calculation of the subsequent subset’s quality and re-

duces the number of iterations. We measure the per-

formance of the quality and update quality on sim-

ulated data. The data consists of a symmetric ma-

trix using the R program’s random uniform distribu-

tion from intervals 0.1 and 0.97 (intervals could be

from any range) — the symmetric matrix range from

5...20, which corresponds to the number of input clus-

terings. The result, as expected, shows that the update

quality implementation performs better than the orig-

inal quality function, as shown in Figure 4. The result

conﬁrms the earlier theoretical framework in runtime

improvement.

7 CONCLUSION AND FUTURE

WORK

This paper introduces a novel ensemble technique that

uses subsets of ensembles to estimate the number of

clusters in the dataset. Compared to similar methods,

the method’s performance shows that our approach is

promising, both in the number of clusters correctly

predicted and the error in the prediction, as demon-

strated in the outputs above. We envisage that speed

will be a problem as the number of datasets and in-

put methods increases. The Gray code version re-

duces the runtime from quadratic to linear time. How-

ever, the approach may no longer be feasible as the

input size grows. It would be interesting to explore

whether a heuristic search approach could speed up

the method in future implementations.

REFERENCES

Arica, N. and Yarman-Vural, F. T. (2001). An overview

of character recognition focused on off-line handwrit-

ing. IEEE Transactions on Systems, Man, and Cyber-

DATA 2022 - 11th International Conference on Data Science, Technology and Applications

390

netics, Part C (Applications and Reviews), 31(2):216–

233.

Ayed, S., Arzoky, M., Swift, S., Counsell, S., and Tucker, A.

(2018). An exploratory study of the inputs for ensem-

ble clustering technique as a subset selection problem.

In Proceedings of SAI Intelligent Systems Conference,

pages 1041–1055. Springer.

Ball, G. H. and Hall, D. J. (1965). Isodata, a novel method

of data analysis and pattern classiﬁcation. Technical

report, Stanford research inst Menlo Park CA.

Calinski, R. and Harabasz, G. (1974). A dendrite method

for cluster analysis. Communications in Statistics,

pages 1–27.

Charrad, M., Ghazzali, N., Boiteau, V., and Niknafs, A.

(2014). Determining the number of clusters using

nbclust package. MSDM, 2014:1.

Doran, R. W. (2007). The gray code. J. Univers. Comput.

Sci., 13(11):1573–1597.

Dua, D. and Graff, C. (2017). Uci machine learning reposi-

tory.

Fern, X. Z. and Brodley, C. E. (2004). Solving cluster en-

semble problems by bipartite graph partitioning. In

Proceedings of the twenty-ﬁrst international confer-

ence on Machine learning, page 36. ACM.

anti, P. and Sieranoja, S. (2018). K-means properties on

six clustering benchmark datasets.

Giacinto, G. and Roli, F. (2001). Design of effective neural

network ensembles for image classiﬁcation purposes.

Image and Vision Computing, 19(9-10):699–707.

Hamerly, G. and Elkan, C. (2003). Learning the k in k-

means. Advances in neural information processing

systems, 16.

Higham, D. J., Kalna, G., and Kibble, M. (2007). Spectral

clustering and its use in bioinformatics. Journal of

computational and applied mathematics, 204(1):25–

37.

Hubert, L. and Arabie, P. (1985). Comparing partitions.

Journal of classiﬁcation, 2(1):193–218.

Jain, A. K., Murty, M. N., and Flynn, P. J. (1999). Data

clustering: a review. ACM computing surveys (CSUR),

31(3):264–323.

Kass, R. E. and Wasserman, L. (1995). A reference

bayesian test for nested hypotheses and its relation-

ship to the schwarz criterion. Journal of the american

statistical association, 90(431):928–934.

Kent, J., Bibby, J., and Mardia, K. (2006). Multivariate

analysis (probability and mathematical statistics).

Krzanowski, W. J. and Lai, Y. (1988). A criterion for deter-

mining the number of groups in a data set using sum-

of-squares clustering. Biometrics, pages 23–34.

Li, T., Ding, C., and Jordan, M. I. (2007). Solving con-

sensus and semi-supervised clustering problems using

nonnegative matrix factorization. In Seventh IEEE

International Conference on Data Mining (ICDM

2007), pages 577–582. IEEE.

Milligan, G. W. (1981). A monte carlo study of thirty inter-

nal criterion measures for cluster analysis. Psychome-

trika, 46(2):187–199.

Pelleg, D., Moore, A. W., et al. (2000). X-means: Extend-

ing k-means with efﬁcient estimation of the number of

clusters. In Icml, volume 1, pages 727–734.

Ratkowsky, D. and Lance, G. (1978). Criterion for deter-

mining the number of groups in a classiﬁcation. Aus-

tralian Computer Journal.

Rayana, S. (2016). ODDS library.

Rousseeuw, P. J. (1987). Silhouettes: a graphical aid to

the interpretation and validation of cluster analysis.

Journal of computational and applied mathematics,

20:53–65.

Strehl, A. and Ghosh, J. (2002). Cluster ensembles—

a knowledge reuse framework for combining multi-

ple partitions. Journal of machine learning research,

3(Dec):583–617.

Sugar, C. A. and James, G. M. (2003). Finding the num-

ber of clusters in a dataset: An information-theoretic

approach. Journal of the American Statistical Associ-

ation, 98(463):750–763.

Swift, S., Tucker, A., Crampton, J., and Garway-Heath, D.

(2007). An improved restricted growth function ge-

netic algorithm for the consensus clustering of reti-

nal nerve ﬁbre data. In Proceedings of the 9th annual

conference on Genetic and evolutionary computation,

pages 2174–2181. ACM.

Swift, S., Tucker, A., Vinciotti, V., Martin, N., Orengo, C.,

Liu, X., and Kellam, P. (2004). Consensus clustering

and functional interpretation of gene-expression data.

Genome biology, 5(11):1–16.

Thrun, M. C. and Ultsch, A. (2021). Swarm intelligence

for self-organized clustering. Artiﬁcial Intelligence,

290:103237.

Ultsch, A. (2004). Strategies for an artiﬁcial life system to

cluster high dimensional data. Abstracting and Syn-

thesizing the Principles of Living Systems, GWAL-6,

pages 128–137.

Vishnuvarthanan, G., Rajasekaran, M. P., Subbaraj, P., and

Vishnuvarthanan, A. (2016). An unsupervised learn-

ing method with a clustering approach for tumor iden-

tiﬁcation and tissue segmentation in magnetic reso-

nance brain images. Applied Soft Computing, 38:190–

212.

West, D., Dellana, S., and Qian, J. (2005). Neu-

ral network ensemble strategies for ﬁnancial deci-

sion applications. Computers & operations research,

32(10):2543–2559.

Zhang, Y. and Zhao, Y. (2004). Automated clustering algo-

rithms for classiﬁcation of astronomical objects. As-

tronomy & Astrophysics, 422(3):1113–1121.

Estimating the Optimal Number of Clusters from Subsets of Ensembles

391
