Automatic Generation of Interoperability Connectors using Software

Product Lines Engineering

Boubou Thiam Niang

1, 2

, Giacomo Kahn

, Nawel Amokrane

, Yacine Ouzrout

, Hamza Sahli

Mustapha Derras

and Jannik Laval

Univ. Lyon, Univ. Lyon 2, INSA Lyon, Universit

e Claude Bernard Lyon 1, DISP-UR4570, 69676 Bron, France

Berger-Levrault, 1 Pl. Giovanni da Verrazzano, 69009 Lyon, France

hamza.sahli, mustapha.derras}@berger-levrault.com

Keywords:

Code Generation, Information System, Interoperability, Model-driven Engineering, Software Product Line

Engineering.

Abstract:

Information Systems (ISs) of modern companies must be reactive and capable to communicate with third-party

IS. It is, therefore, necessary to establish agile interoperability between information systems. For this purpose,

connectors are used to ensure interactions between IS components. However, components are independently

designed and conform to different technical and domain standards that are continuously evolving. Given that

the connectors are often developed manually and are not reusable in most cases, establishing and maintaining

interoperability becomes a major challenge. In this paper we propose an approach to automatically generate

connectors, using software product line engineering to reuse common features and better manage variability.

A metamodel of the connector is proposed to show that they can be considered as ﬁrst-class entities. An

industrial case study followed by a discussion is proposed to demonstrate the feasibility of our approach.

1 INTRODUCTION

Companies have to interact with many partners,

which are structurally diverse and operate in vari-

ous business sectors. In addition, companies have

to evolve from a technical and organizational point

of view through mergers, acquisition of subsidiaries

or technological migrations. Despite their diversities,

frequent changes, and independent development, the

Information Systems (ISs) of different stakeholders

and their components must remain compatible with

each other in order to work together at all times. Con-

nectors (Mehta et al., 2000) are used for this pur-

pose to enable a successful interaction between com-

ponent.

Some works have been carried out on the effec-

tive implementation of interoperability connectors.

In (Aldrich et al., 2002; Arellanes and Lau, 2017;

Garc

es et al., 2019) the authors focuse on the no-

tion of exogenous connectors i.e., connectors sepa-

rated from business logic components to increase de-

coupling and ﬂexibility. However, this approach do

not address the automation of connectors implemen-

tation.Other proposals such as (Seinturier et al., 2012;

Roth et al., 2018) are interested in automatic recon-

ﬁguration for services orchestration, but the notion of

connectors remains implicit. Then, some approaches

have addressed the automatic synthesis of the connec-

tors as ﬁrst-class entities like (Bencomo et al., 2013;

Bennaceur and Issarny, 2014; Bouloukakis et al.,

2019; Autili et al., 2019). These solutions generally

target a speciﬁc type of connector to be synthesized as

a peer-to-peer exchange, without offering more ﬂexi-

bility to generate other types of connectors.

Having identiﬁed that the cited approaches do not

take into account all the interesting points mentioned

in the cited works, and the shortcomings identiﬁed for

each of the listed works, we raised two research ques-

tions (RQ):

RQ1: To what extent it is possible to decouple the

connector by separating the interaction-speciﬁc code

from the business code? The objective of this RQ is

to clearly identify what falls under interaction codes

and and what falls under business logic in order to

generate the connector.

RQ2: How to facilitate the connectors implemen-

tation despite their variability? The objective of this

RQ is to show that different types of connectors can

be generated regardless of its variability by minimiz-

ing the effort and reusing the connectors features.

Niang, B., Kahn, G., Amokrane, N., Ouzrout, Y., Sahli, H., Derras, M. and Laval, J.

Automatic Generation of Interoperability Connectors using Software Product Lines Engineering.

DOI: 10.5220/0011278000003266

In Proceedings of the 17th International Conference on Software Technologies (ICSOFT 2022), pages 449-456

ISBN: 978-989-758-588-3; ISSN: 2184-2833

449

This paper consider connectors as ﬁrst class-entity

and the set of connectors is considered as a Software

Product Line (SPL) (Clements and Northrop, 2002) in

order to exploit the commonalities of the connectors

and easily manage their variability. The main contri-

butions of this article are the following:

• Analysis of connectors commonalities and vari-

ability to consider them as a software product line,

• Design of a feature model (FM) that represents

commonalities and variability of connectors,

• Proposal of a connector metamodel with reusable

artifacts,

• Proposal of a software product line approach for

generating interoperability connectors.

Based on an industrial case study where two connec-

tors have to be implemented between different ap-

plications in various domains, we discussed the ap-

proach and gave feedback on the lessons learned. The

metamodels, the feature models and the implementa-

tion example of the study discussed in the article are

available on a public git repository.

The paper is organized as follows: in Section 2,

we discuss the state of the art. The proposed soft-

ware product lines approach for connector generation

is presented in Section 3. Section 4 presents a case

study that illustrates a concrete problem to be solved.

Finally, in Section 5 we discuss the approach and

present feedback on the lessons learned.

2 STATE OF THE ART

Different approaches have been developed to facil-

itate implementation of connectors, seen in several

aspects: exogenous connectors, dynamic orchestra-

tions, and automatic synthesis.

The ﬁrst aspect focuses on the separation of con-

nectors and business logic components to increase de-

coupling and ﬂexibility. Approaches such as (Aldrich

et al., 2002; Arellanes and Lau, 2017; Garc

es et al.,

2019) go in this direction by considering connectors

as ﬁrst-class entities that aim to guarantee the tech-

nical, geographical, and life cycle management inde-

pendence of the connectors.

The second aspect concerns the dynamic imple-

mentation of connectors via reconﬁguration for com-

ponent orchestration. Thus, studies such as (Sein-

turier et al., 2012) and (Roth et al., 2018) propose

a way of composing connectors by simplifying the

development of connectors. These approaches are

https://cvs.disp-lab.fr/demo-approach-spl-dop-

connector

design-time or at runtime with the possibility of re-

conﬁguration of the interactions between the entities.

The third aspect deals with the generation of con-

nectors. Inverardi, Tivoli and Autili (Inverardi and

Tivoli, 2013; Autili et al., 2018) propose a method for

automatic synthesis of modular connectors, a compo-

sition of independent primitive sub-connectors called

mediators, which realize a mediation pattern. Propo-

sition like Bencomo et al. (Bencomo et al., 2013)

or Bennaceur and Issarny (Bennaceur and Issarny,

2014) go further by focusing on functionality dis-

covery and automatic generation of connectors on-

the-ﬂy. To this end, both combine machine learning

techniques and ontological reasoning. Bouloukakis et

al. (Bouloukakis et al., 2019) introduce a solution

for the automated synthesis of mediators that ensure

the interoperability of heterogeneous things, Data eX-

change (DeX) connector model. This solution aims

to devise a generic connector that comprehensively

abstracts and represents the semantics of the various

middleware protocols. Autili et al. (Autili et al., 2019)

deﬁne a model-based framework for mediators and an

automated approach to mediator synthesis. the model

takes as input an interaction process, a choreogra-

phy speciﬁcation and its ontology to produce what is

called coordination delegate.

The state of the art show some limitations that may

constraint open and evolving interoperability. Stud-

ies that address the notion of exogenous connectors

do not explain how to implement them. Solutions

that allow the dynamic reconﬁguration of services are

highly focused on orchestration where the connector

is centralized. The notion of exogenous connector is

not put forward for these types of approaches. It is

therefore difﬁcult to change a single connector with-

out impacting other connector’s combination. Ap-

proaches that deal with automatic connector synthesis

for creating connectors are mainly focused on chore-

ography and does not address the orchestration. Our

approach aims to overcome some of the limitations

mentioned in the state of the art.

3 THE CONNECTORS PRODUCT

LINE

3.1 Proposed Software Product Line

Engineering Approach

In accordance of the software product line engineer-

ing, the proposed approach follow two sub-process:

Domain Engineering (DE) and Application Engineer-

ing (AE). Each of the sub-processes can be divided

ICSOFT 2022 - 17th International Conference on Software Technologies

450

into two parts, the problem space and the solution

space as illustrated in Fig. 1.

In both sub-processes, we rely on model-driven

engineering (MDE) (Schmidt, 2006). For the DE sub-

process, the architecture of the software product line

is represented by the connector metamodel. In AE

sub-process, the expected connector model is used

for code generation, instead of directly generating

the connector source code. This allows for a higher

level of abstraction and ﬂexibility. Indeed, without

MDE, the SPL would have to directly implement a

main class, in a target programming language, rep-

resenting the connectors commonalities and variabil-

ity. Thus, operations such as adding, deleting or re-

moving can be made to this main class to vary it,

and then generate the connector directly in the pre-

targeted language. This kind of implementation can

be achieved through delta-oriented programming with

tools like DeltaJ (Koscielny et al., 2014). However,

this would be a major constraint in terms of open-

ness and scalability, as some technical choices such

as the target language have to be made upstream. To

avoid this, MDE provides platform independence and

allows source code to be generated a posteriori using

model-to-code transformation techniques to generate

source code in a desired language.

3.2 Description of the Approach

3.2.1 Analysis of Commonalities and Variability

of Connectors

The ﬁrst step of the DE sub-process corresponds to

the top leftmost box in Fig. 1. This step consists of

identifying the commonalities and variability of the

connectors. To this end, software product line engi-

neering offers three approaches (Bakar et al., 2015):

proactive, reactive, and extractive.

This work is produced with an industrial partner

Berger-Levrault (BL)

, which already operates vari-

ous interoperability connectors: REST API call, En-

terprise Service Bus, event-driven connectors, etc.

Since we are not starting from scratch and are given

the existing connectors, we opted for the extractive

approach. We combine the extractive approach with

the iterative approach for a variability analysis that

goes beyond the existing connectors, and for future

scalability of the connectors product line. The extrac-

tive approach itself can be carried out according to

several extraction strategies according to Assunc¸

ao et

al. (Assunc¸

ao et al., 2017). This paper relies on Static

Berger-Levrault is a software provider specialized in

the ﬁelds of education, health, sanitary, social and territorial

management.

Analysis and Expert-Driven strategy extraction strate-

gies.

Static analysis consists of analyzing the structural

information of static artifacts such as source code,

or textual technical and functional speciﬁcation doc-

uments. To do this, we considered a repository of

twenty connector projects from our industrial part-

ner BL implementing different communication mech-

anisms. For most existing connectors, there is a strong

coupling between the communication and the busi-

ness logic source code. It was therefore necessary

to ﬁrst carry out a manual separation of concerns

by isolating the connectors codes as much as possi-

ble. This separation of concerns addresses one of our

research questions on separating interaction-speciﬁc

source code from business logic (RQ1). Once this

separation is made, we analyzed connectors speciﬁ-

cation documents, even for connectors that are not

yet in use or have not been effectively implemented

by the company. Finally, we collect additional char-

acteristics from the literature such as the EIPs (Hohpe

and Woolf, 2004) book. These three sources allowed

us to deﬁne the required features for the connec-

tors. Thus, we have identiﬁed that the connector as

a ﬁrst-class entity is mainly decomposed into three

sub-components: source, sink, and processor which

are common to all connectors. The source is the en-

try point of the connector which receives the message

from an externe component, the sink is the output of

the connector, it sends the message to a component,

the processor is a sub-component which can trans-

form the information that passes through the connec-

tor such as ﬁltering or aggregation. Each of these sub-

components can vary depending on the need for inter-

operability. For example, you may have a rabbitMQ

or an http source, a kafka or ftp sink and an aggre-

gator or message sequencer processor. These com-

monalities and variability make it easier to choose the

SPL for connectors and therefore the positioning of

our paper.

The Expert-Driven strategy relies on the expertise

of specialists e.g. software engineers, architects, de-

velopers, and stakeholders, etc. Experts knowledge

allows us to complete, adjust and validate the ex-

tracted features.

3.2.2 Modeling Connector Variability

The second step of the DE sub-process corresponds to

the second box from the left at the top in Fig. 1. This

step allows to represent the previously analyzed con-

nectors features by highlighting commonalities and

variability. For this purpose, we use a feature model

(FM) (Kang et al., 1990), which present all possible

features to create a connector. For reasons of space

Automatic Generation of Interoperability Connectors using Software Product Lines Engineering

451

Figure 1: Overview of the software product line approach to generate connectors. The process presents the domain engineering

(top) and the application engineering sub-process (bottom). For each sub-process the problem space (left) and the solution

space (right) are identiﬁed.

and readability, only part of the FM is presented in

Fig. 2. This later remains expandable for future evo-

lution. A more complete FM is available on a public

git repository URL indicated in the introduction.

Figure 2: The domain feature model of the connectors that

represents all possible features to create a connector.

3.2.3 The Connectors Software Product Line

Architecture

This is the last step of the DE sub-process, the last

box on top from the left. It is broken down into two

phases.

• The ﬁrst phase concerns the implementation of the

connector software product line architecture, the

connector metamodel shown in Fig. 3, which is

one of the contributions of this paper. The pro-

posal of a metamodel allows us to assert that con-

nectors are ﬁrst-class entities rather than an im-

plicit mechanism for interaction between compo-

nents. The connector metamodel is designed ac-

cording to the domain FM. The transition from the

domain FM to the connector metamodel is done

manually.

Indeed, the features present in the feature model

become the entities of the metamodel, and differ-

ent constraints and relationships must be main-

tained. The common features, which have a

mandatory constraint, are transformed into an en-

tity whose life cycle depends on that of the con-

nector. This results in a composition relation-

ship between the connector and these common

entities, with the minimum cardinality equal to

one. As far as the optional features are concerned,

they are transformed into non-mandatory entities,

which results in a composition relation with no

minimal cardinality. The other constraints are

represented by simple associations between en-

tities. Features that can take a simple value be-

comes attributes, for example message format can

be JSON or Avro. Due to space limitations and to

stay readable, a portion of the metamodel is pre-

sented in Fig. 3. The complete connector meta-

model is provided via public access on the pro-

vided git repository, and remains expandable to

ensures evolving of the connector product line by

adding new functionalities to the connector fea-

ture model and the corresponding entities in the

metamodel. This extension is done manually.

• The second phase focuses on the creation of

reusable operations that specify the modiﬁcations

that could be applied to the connector architec-

ture, it metamodel in this case. Indeed, these

operations is due to our implementation choice

which is based on Delta-Oriented Programming

(DOP) (Schulze et al., 2013). The connectors

product lines is represented by a core model, and

a set of delta modules. The core model pro-

vides an implementation of a valid base connec-

tor. It is here about the connector metamodel.

ICSOFT 2022 - 17th International Conference on Software Technologies

452

Figure 3: The metamodel of the connector representing the connectors software product line architecture. The entities with a

bold border correspond to the expected connector model.

Delta modules specify the changes to be applied

to the core module to create an expected connec-

tor by adding, modifying and deleting entities or

their attributes. This phase consists in creating a

number of delta modules, each of them is created

for a valid conﬁguration of the connector feature

model. Then, for each delta module, the differ-

ence with the metamodel is evaluated that consti-

tute so-called delta actions for later use. It should

be noted that delta actions can be calculated be-

tween two delta modules, i.e., one delta module

is considered as a core model to create another

delta module. In this case, constraints on the or-

der of application of the module deltas are cre-

ated. The industrial case study proposed in Sec. 4

will illustrate the application and use of delta ac-

tions through a concrete case. To create delta

modules and delta actions, we use SiPL (Pietsch

et al., 2015), a model-driven delta-oriented tool

offered on top of the Eclipse modeling framework

(EMF) (Steinberg et al., 2008).

3.2.4 Application Engineering

The AE sub-process leverages the domain engineer-

ing one to create a connector. It consists in four steps.

The ﬁrst step, the leftmost box at the bottom in Fig. 1

is to specify the desired connector. In the second step,

a stakeholder conﬁgures the domain feature model by

selecting the required feature for the connector spec-

iﬁcation. The third step, second to last box from the

left, is the synthesis of the expected connector model.

This is done on the basis of the connector product line

architecture, delta modules and constraints created in

the problem space of the DE sub-process, and the

desired connector conﬁguration based on the domain

feature model. Delta actions are created with different

constraints in the DE sub-process. Each delta action

is created for a given conﬁguration. Thus, in the cur-

rent step, all delta actions corresponding to the con-

ﬁguration of the feature model are automatically pro-

posed, while respecting constraints such as the order

of application. The application of these delta actions

allows to automatically obtain the expected connector

model. The connector model is then instantiated to

generate the source code of the connector in the de-

sired language. The last step, last box from the left at

the bottom in Fig. 1 is a sub-process that involves the

use of certain Eclipse-based tools. To transform the

model into code, the Eclipse GenModel tool is used

to generate the model code which then instantiates the

expected connector with property values provided by

a end user.

An example of an application showing concretely

how each step of the entire process works is presented

in the section. 4.

4 INDUSTRIAL CASE STUDY

4.1 Scenario Presentation

To illustrate our approach, we consider a concrete

case study from our industrial partner BL as shown

in Fig. 4. It concerns a part of an information sys-

tem where some internal components have to inter-

act: SaaS-Console, Legibase, and Helios Analyzer

and Helios Scraper. For this purpose, two variable

connectors are needed to answer the research ques-

tion (RQ2).

1. The SaaS-Console is an administration console

that allows the clients to autonomously manage

their accounts and access rights related to the

Software as a Service (SaaS) they use.

2. Legibase is an application that manages practical

fact sheets, articles on the latest legislation and

Automatic Generation of Interoperability Connectors using Software Product Lines Engineering

453

case law developments in several areas. Legibase

is used by professionals who need access to the

latest versions of often evolving legislation.

3. The Helios analyzer gathers data from different

information sources such as social network, sci-

entiﬁc and political report and integrate these in-

formation in the Helios scrapper database. Helios

Analyzer allows to make a weather forecast of the

latest news.

Fig. 4 shows two connectors that allow the de-

scribed application to interact: an event-driven con-

nector based on publish-subscribe (Tarkoma, 2012)

communication pattern, and an hybrid connector that

combine one event-driven consumer and one syn-

chronous http endpoint.

The objectives of the ﬁrst connector are to syn-

chronize user access between the SaaS-Console, the

Helios scraper, and the Helios analyzer applications,

and to synchronize data between the Helios scraper

database and the Helios analyzer database. This con-

nector accomplish event-driven communication us-

ing the publish-subscribe pattern. We identify in-

teractions performed by the same connector: SaaS-

Console ↔ Helios scrapper, SaaS-Console ↔ Helios

analyzer, and Helios scrapper database → Helios an-

alyzer database. The directions of the arrows indicate

in which direction the exchanges are made.

From SaaS-Console to Helios Scraper and Helios

Analyzer and conversely, when the status of a user

account changes in the UserAccessTopic in which

the SaaS-Console has beforehand pushed. An event

is then sent to Helios Scraper and Helios Analyzer

through the connector. Events are then delivered to

consumers subscribed to the topic, in this case He-

lios scraper and Helios analyzer. In this study case,

connectors source consume the event from SaaS-

Console. Upon receiving the event, components sub-

scribed to the topic can consume the message from

the sink of the connector. This is partly the same

as for the ﬂow SaaS-Console to Legibase. The dif-

ference is that for the communication from the con-

nector to Legibase, the connector sink calls the API

exposed by Legibase, upon receiving the event. The

ﬂow from Helios scraper and Helios analyzer operates

in the same way, with the difference that the commu-

nication is between databases and not between busi-

ness applications.

A ﬁrst effort has been made by our industrial part-

ner BL with the creation of BL-MOM, a messaging-

based API (Application Platform Interface) that aims

to support implementing a new connector according

to the publish-subscribe communication pattern and

based on the RabbitMQ broker. However, to date,

BL-MOM only supports the development of asyn-

chronous connectors. Another problem with BL-

MOM is that backwards compatibility is not obvious.

Indeed, our industry partner BL has found that adapt-

ing the BL-MOM API to create connectors based on

a Kafka broker, for example, instead of a RabbitMQ

broker requires an important development cost. In

this speciﬁc case, our approach overcomes these lim-

itations in terms of backwards compatibility, connec-

tor type and development time.

The present exchange ﬂow case study is about a

new need to connect the SaaS-Console to Legibase

for access contract management, connect the SaaS-

Console to Helios Scrapper and Helios analyzer for

user access creation and update purpose, and connect-

ing Helios Scrapper and Helios analyzer database for

synchronization.

4.2 Implementation of the Use Case

we consider one of the connectors presented in Fig. 4

to prove the feasibility of our approach, the connec-

tor that enable communication between SaaS-Console

and Legibase components.

1. We need ﬁrst the speciﬁcation of the connectors.

For this, we consider the connector that enable

interoperability between SaaS-Console and Leg-

ibase. The objective is to generate a connector

that receives an event concerning user access to

which it is subscribed via a topic and to make a

HTTP call to the Legibase component. It is pos-

sible for the connector to ﬁlter some information

thanks to the ﬁlter processor as shown in Fig. 4

2. Once the connector speciﬁed, the domain feature

model must be conﬁgured by selecting the re-

quired features. The conﬁguration is realized us-

ing SiPL tool as explained in Section 3 and Fig. 1.

3. As reminder, in the DE sub-process shown in

Sec. 1, several delta modules have been cre-

ated for different conﬁgurations. For each delta

module the difference with the connector meta-

model is calculated to obtain the delta actions, that

must be applied to obtain the model of the ex-

pected connector. The resulting connector model

is shown in Fig. 3, when only the entities with

the bold border are considered. In other words,

the model of the expected connector corresponds

to the metamodel of the connector presented in

Fig. 3, from which several entities have been re-

moved such as: ftp sources, rabbit sink, and all

processors except ﬁlter.

4. The last step focuses on the sub-process of trans-

forming the resulting model of the expected con-

nector into code. These codes are generated us-

ICSOFT 2022 - 17th International Conference on Software Technologies

454

Figure 4: Overview of the industrial use case showing several components that must interact through two variable connectors

based on interoperability requirements.

ing Eclipse GenModel tool. The generated code

represent an API that we can use to manipulate

the model. Next, we create an Eclipse fragment

project to instantiate the model with the required

values for the connector, using the API generated

from the expected connector model , and based

on EarlyBinding techniques. As a result, we get

an instance of connector in the XMI format. To

move on to the automatic generation of the con-

nector code itself, we created a code generator

module with our industrial partner BL. This mod-

ule requires a JSON ﬁle as input and generate a

connector code in java. Simply convert the XMI

ﬁle to JSON and run the automatic code genera-

tion add-on.

An example of an automatic end-to-end connector

generation project based on the proposed approach

is available on the indicated gitlab repository. The

project contains four sub-projects: feature model-

ing, ecore modeling, delta modeling with SiPL, and

eclipse fragment project.

5 DISCUSSION AND LESSONS

LEARNED

The proposed approach helps to reduce the effort re-

quired for the development of connectors by reusing

their commonalities.

We made sure that the analysis of variability was

as complete as possible. For this purpose, we con-

sidered concrete connectors used in the industry, or

open source tools such as Spring Cloud Data Flow

(SCDF)

, and Kafka Connect

. We also retrieved

https://spring.io/projects/spring-cloud-dataﬂow

https://docs.conﬂuent.io/platform/current/connect/ind

ex.html

features found in the literature, such as from the EIPs.

This rigorous analysis of commonalities and variabil-

ity has provided us a feature model that cover a wide

range of connector types. The paper also explains the

transition from a feature model to a software prod-

uct line architecture manually and following rules we

described. We have also shown how to use the fea-

ture model and the product line architecture to easily

create a desired connector. For this purpose, delta-

oriented programming was exploited using the SiPL

tool and other Eclipse tools such as GenModel.

The DE sub-process being set up only once with

punctual evolution, by considering the steps of AE

only, we noted with the presented example that the

generation of source code process based on our ap-

proach take less than one hour. This is very encour-

aging in terms of time saving, as according to feed-

back from BL developers and experts, it takes about a

week for a novice to develop a connector for a single

exchange ﬂow. Although feedback from our indus-

trial partner, BL conﬁrms that an experienced devel-

oper takes less time, about three hours, it is always

advantageous to start with an existing base project,

this reduces, for example, the number of copy/paste

operations that need to be performed without forget-

ting anything. Moreover, the fact of having a common

core codes makes it possible to reduce the number of

tests to be carried out, in fact the base of the product

is tested only once.

6 CONCLUSION

We have adopted model-driven engineering to be plat-

form independent, and have gone as far as possible

with the code generated in Java. In the future we need

to prove the code generation in other languages. We

will also need to be able to manage the life cycle of

Automatic Generation of Interoperability Connectors using Software Product Lines Engineering

455

connectors. Indeed, once the connector is generated,

we must be able to make it evolve without having to

regenerate all its source code. Considering life cycle

management, the proposed approach can also be used

for low-coding purposes in component-based connec-

tors such as the SCDF connectors. In this case, we

have a catalog of components sources, sinks, and pro-

cessors to create connectors. The approach could thus

be used to generate conﬁgurations allowing the cre-

ation of complex connectors through the composition

of various sub-components.

REFERENCES

Aldrich, J., Chambers, C., and Notkin, D. (2002). Archjava:

Connecting software architecture to implementation.

In Proceedings of the 24th International Conference

on Software Engineering. ICSE 2002, pages 187–197.

IEEE.

Arellanes, D. and Lau, K.-K. (2017). Exogenous connec-

tors for hierarchical service composition. 2017 IEEE

10th Conference on Service-Oriented Computing and

Applications (SOCA), pages 125–132.

Assunc¸

ao, W. K., Lopez-Herrejon, R. E., Linsbauer, L.,

Vergilio, S. R., and Egyed, A. (2017). Reengineer-

ing legacy applications into software product lines: a

systematic mapping. Empirical Software Engineering,

22(6):2972–3016.

Autili, M., Inverardi, P., Spalazzese, R., Tivoli, M.,

and Mignosi, F. (2019). Automated synthesis

of application-layer connectors from automata-based

speciﬁcations. Journal of Computer and System Sci-

ences, 104:17–40.

Autili, M., Inverardi, P., and Tivoli, M. (2018). Choreog-

raphy realizability enforcement through the automatic

synthesis of distributed coordination delegates. Sci-

ence of Computer Programming, 160:3–29.

Bakar, N. H., Kasirun, Z. M., and Salleh, N. (2015). Feature

extraction approaches from natural language require-

ments for reuse in software product lines: A system-

atic literature review. Journal of Systems and Soft-

ware, 106:132–149.

Bencomo, N., Bennaceur, A., Grace, P., Blair, G., and Is-

sarny, V. (2013). The role of models@ run. time

in supporting on-the-ﬂy interoperability. Computing,

95(3):167–190.

Bennaceur, A. and Issarny, V. (2014). Automated syn-

thesis of mediators to support component interoper-

ability. IEEE Transactions on Software Engineering,

41(3):221–240.

Bouloukakis, G., Georgantas, N., Ntumba, P., and Is-

sarny, V. (2019). Automated synthesis of mediators

for middleware-layer protocol interoperability in the

iot. Future Generation Computer Systems, 101:1271–

1294.

Clements, P. C. and Northrop, L. M. (2002). Salion, inc.:

A software product line case study. Technical report,

Carnegie-Mellon Univ Pittsburgh Pa Software Engi-

neering Inst.

Garc

es, L., Oquendo, F., and Nakagawa, E. Y. (2019). Soft-

ware mediators as ﬁrst-class entities of systems-of-

systems software architectures. Journal of the Brazil-

ian Computer Society, 25(1):1–23.

Hohpe, G. and Woolf, B. (2004). Enterprise integration pat-

terns: Designing, building, and deploying messaging

solutions. Addison-Wesley Professional.

Inverardi, P. and Tivoli, M. (2013). Automatic synthesis of

modular connectors via composition of protocol medi-

ation patterns. In 2013 35th International Conference

on Software Engineering (ICSE), pages 3–12. IEEE.

Kang, K. C., Cohen, S. G., Hess, J. A., Novak, W. E.,

and Peterson, A. S. (1990). Feature-oriented domain

analysis (foda) feasibility study. Technical report,

Carnegie-Mellon Univ Pittsburgh Pa Software Engi-

neering Inst.

Koscielny, J., Holthusen, S., Schaefer, I., Schulze, S., Bet-

tini, L., and Damiani, F. (2014). Deltaj 1.5: delta-

oriented programming for java 1.5. In Proceedings of

the 2014 International Conference on Principles and

Practices of Programming on the Java platform: Vir-

tual machines, Languages, and Tools, pages 63–74.

Mehta, N. R., Medvidovic, N., and Phadke, S. (2000). To-

wards a taxonomy of software connectors. In Pro-

ceedings of the 22nd international conference on Soft-

ware engineering, pages 178–187.

Pietsch, C., Kehrer, T., Kelter, U., Reuling, D., and Ohrn-

dorf, M. (2015). Sipl–a delta-based modeling frame-

work for software product line engineering. In 2015

30th IEEE/ACM International Conference on Auto-

mated Software Engineering (ASE), pages 852–857.

IEEE.

Roth, F. M., Becker, C., Vega, G., and Lalanda, P. (2018).

Xware—a customizable interoperability framework

for pervasive computing systems. Pervasive and mo-

bile computing, 47:13–30.

Schmidt, D. C. (2006). Model-driven engineering.

Computer-IEEE Computer Society-, 39(2):25.

Schulze, S., Richers, O., and Schaefer, I. (2013). Refactor-

ing delta-oriented software product lines. In Proceed-

ings of the 12th annual international conference on

Aspect-oriented software development, pages 73–84.

Seinturier, L., Merle, P., Rouvoy, R., Romero, D., Schi-

avoni, V., and Stefani, J.-B. (2012). A component-

based middleware platform for reconﬁgurable service-

oriented architectures. Software: Practice and Expe-

rience, 42(5):559–583.

Steinberg, D., Budinsky, F., Merks, E., and Paternostro, M.

(2008). EMF: eclipse modeling framework. Pearson

Education.

Tarkoma, S. (2012). Publish/subscribe systems: design and

principles. John Wiley & Sons.

ICSOFT 2022 - 17th International Conference on Software Technologies

456
