Semantic-based Data Integration and Mapping Maintenance:

Application to Drugs Domain

Mouncef Naji

, Maroua Masmoudi

, Hajer Baazaoui Zghal

, Chirine Ghedira Guegan

Vlado Stankovski

and Dan Vodislav

ETIS Labs, CY Cergy Paris University, ENSEA / CNRS, France

CY Tech, Pau, CY Cergy Paris University, France

Univ. Lyon, Universit

e Jean-Moulin Lyon 3, LIRIS UMR5205, iaelyon School of Management, France

Faculty of Civil and Geodetic Engineering, University of Ljubljana, Ljubljana, Slovenia

Keywords:

Big Data, Mapping Maintenance, Data Integration, Ontology, Deep Learning, Classiﬁcation.

Abstract:

In recent years, the number of data sources and the amount of generated data are increasing continuously. This

voluminous data leads to several issues of storage capacities, data inconsistency, and difﬁculty of analysis.

In the midst of all these difﬁculties, data integration techniques try to offer solutions to optimally face these

problems. In addition, adding semantics to data integration solutions has proven its utility for tackling these

difﬁculties, since it ensures semantic interoperability. In our work, which is placed in this context, we propose

a semantic-based data integration and mapping maintenance approach with application to drugs domain. The

contributions of our proposal deal with 1) a virtual semantic data integration and 2) an automated mapping

maintenance based on deep learning techniques. The goal is to support the continuous and occasional data

sources changes, which would highly affect the data integration. To this end, we focused mainly on managing

metadata change within an integrated structure, refereed to as mapping maintenance. Our deep learning models

encapsulate both convolutional, and Long short-term memory networks. A prototype has been developed and

performed on two use cases. The process is fully automated and the experiments show signiﬁcant results

compared to the state of the art.

1 INTRODUCTION

Big data has become a great phenomenon in the mod-

ern industry, especially with the availability of enor-

mous amounts of data. The beneﬁts of such data

sparkled the curiosity of multiple companies and re-

searchers.

Nevertheless, although it offers such beneﬁts,

managing the different data sources remains a chal-

lenging problem. Indeed, data size, heterogeneity, va-

riety, etc, make it hard to manage and interlink data

sources. Accordingly, to overcome this problem, it

has been suggested to add semantics to data. Ontolo-

gies, as a knowledge representation formalism, con-

tinue to be a promising solution for the semantic in-

teroperability between this data. Indeed, they allow

representing data following a semantic model, which

permit a better understanding of data. In this regard,

in terms of heterogeneity, variety and volume, drugs

data are one of the targeted ﬁelds by big data tech-

niques. In effect, big biomedical data has grown expo-

nentially during the last decades and a similar growth

rate is expected in the next years, resulting into differ-

ent interoperability conﬂicts among data collections

with entities being dispersed across different datasets.

Each data source can likely get a change of structure

and metadata, which compromises the whole integra-

tion (Maria-Esther and al., 2019). As aforesaid, the

data sources being numerous and varied, this issue

impacts consistency in virtual data integration and its

maintenance. This latter, namely, mapping mainte-

nance is deﬁned as the task aiming to keep existing

mappings in an updated and valid state, reﬂecting the

changes affecting a source’s entities at evolution time

(Cesar and al., 2015).

Therefore, this work aims to integrate data sources

based on ontologies with an application to drugs’ do-

main. Our proposal takes into account both the data

sources integration changes and associated metadata.

To do so, the study focuses on automatically manip-

ulating mappings generated from virtual data integra-

tion, in order to adapt them to the observed changes.

Thus, the study responds to two main research ques-

tions: (i) which data integration is suitable for the

Naji, M., Masmoudi, M., Zghal, H., Guegan, C., Stankovski, V. and Vodislav, D.

Semantic-based Data Integration and Mapping Maintenance: Application to Drugs Domain.

DOI: 10.5220/0011279900003266

In Proceedings of the 17th International Conference on Software Technologies (ICSOFT 2022), pages 469-477

ISBN: 978-989-758-588-3; ISSN: 2184-2833

469

mentioned problem, and (ii) how to adapt and update

mappings to handle data sources’ changes. The orig-

inality of our work is the novel automated mapping

maintenance that we propose, based on deep learning

techniques. This article is organized as follows: Sec-

tion 2 presents related works. Our proposal is detailed

in section 3. Section 4 presents the implementation

and discusses the evaluation of our proposal. Lastly,

we conclude and deliver the future works in section 5.

2 STATE OF THE ART

Our study of recent works has focused on schema

matching and mapping maintenance as a solution for

change in the metadata of data sources.

Schema matching makes use of name, descrip-

tion, type of data, constraint, and schema struc-

ture in order to identify the match between two at-

tributes of data source’s schema. (Do, 2007) de-

scribes the architecture, functionality, and evaluation

of the schema matching system COMA++ (Combin-

ing Matchers). COMA++ represents a generic and

customised system for semi-automatic schema match-

ing, which combines different match algorithms in a

ﬂexible way. But even though the work shows good

results, it stays limited due to the unavailability of

metadata and schema of all data-sources. Further-

more, the use of metadata is not always appropriate to

schema matching process. This issue has been related

in many works. That being said, work on schema

matching has shifted towards Instance based match-

ing. This approach employs the available instances

as a source to identify the correspondences between

schema attributes. (Munir and al, 2014) focuses

on ﬁnding similarities/matchings between databases

based on the instance approach. It uses the databases’

primary keys. The proposed approach consists of two

main phases : Row Similarity and Attribute Similar-

ity. This work shows signiﬁcant results in terms of

matching accuracy. However, it remains limited by

its applicability to only databases.

While working on databases, (Sahay and al, 2019)

and (Mehdi and al, 2015) use a hybrid approach, using

schemas and data provided to manage matchings, by

using machine learning. They try to work on one-

to-one matchings, and introduce a dictionary for one-

to-many matchings. The results seem sufﬁcient for

simple use cases, but show mediocre performance in

a complex mappings while supporting only databases.

Concerning other formats, (Mohamed-Amine and

al, 2017) work on Json datasets. They focus solely

on schema inference, but they show great potential

for schema matching. They deal with the problem

of inferring a schema from massive JSON datasets,

by identifying a JSON type language which is simple

and expressive enough to capture irregularities and

to give complete structural information about input

data. (Ahmad Abdullah Alqarni, 2017) introduces

two approaches to improve XML Schema matching

efﬁciency: internal ﬁltering and node inclusion. In

the former, it detects dissimilar elements at all schema

levels at early stages of the matching process. And In

the latter, it detects dissimilarity between elements on

leaf nodes only using their ancestor degree of simi-

larity and then exclude them from the next phase of

matching process.

In another context, several researches focused on

mappings maintenance to ﬁx data availability. This

means manipulating and updating mappings to handle

data sources’ and ontologies’ change.

In that matter, (Cesar and al, 2015) and

(N. Popitsch, 2018) take into account the deﬁnition

of established mappings, the evolution of Knowl-

edge Organization Systems (KOS) and the possible

changes that can be applied to the mappings. they de-

ﬁne complete frameworks based on formal heuristics

that drives the adaptation of KOS mappings. These

studies show great results in terms of mappings main-

tenance, but they require a lot of human interven-

tion, with a repeated the integration process, which

re-value the need for a mapping maintenance solution.

(Khattaka and al., 2015) proposes an other ap-

proach towards mappings evolution regeneration. It

focuses on ﬁnding alignments between ontologies.

The paper proposes a mapping reconciliation ap-

proach between the updated ontologies that have been

found to take less time to process compared to the

time of existing systems when only the changed re-

sources are considered and also eliminates the stale-

ness of the existing mappings. Even though this work

presents intresting work concerning mappings main-

tenance, it focuses only on ontology descriptions,

without taking into consideration the data change.

2.0.1 Synthesis

The literature revue on schema matching and map-

ping maintenance shows that the existing works fo-

cused either on manipulating ontologies or by chang-

ing data sets. But since our focus is on mapping ﬁles,

no study has tried to manipulate the ﬁles directly. That

being said, our aim is to focus on how to manipulate

and update mapping ﬁles, following a change in data

sources’ metadata.

ICSOFT 2022 - 17th International Conference on Software Technologies

470

3 SEMANTIC-BASED DATA

INTEGRATION AND MAPPING

MAINTENANCE APPROACH

In this section, we describe our proposed approach

for drug integration. The aim is to provide a virtual

semantic data integration of heterogeneous multiple

data sources in drugs domain. As aforementioned, the

proposed approach focuses on two main functionali-

ties: Federated data integration and mappings update.

Figure 1 presents the global architecture of the

proposed approach. The layered architecture is com-

posed of 6 components:

Figure 1: The proposed data integration architecture.

• Selection Data Component: It encompasses the

selection of different data sources with different

contents and data types (XML, CSV, TXT, etc).

• Access Component: It contains all the necessary

implementations allowing the access to multi-

source data.

• Integration Component: The purpose of the in-

tegration component is to combine data coming

from multiple data sources to provide a uniﬁed,

single view of data. The integration process is

based on a drug ontology (concepts). The out-

put of the integration is a ﬁle of mappings. This

component takes as input, the data sources and the

domain ontology. As output, it returns the map-

pings ﬁle for the virtual integration. We point out

that a virtual integration approach means that data

remains in local sources and is accessed through

an intermediate infrastructure called a mediator

(Masmoudi and al, 2021).

• Processing Component: The aim of this compo-

nent is to maintain an integration system up-to-

date. It checks changes in data sources, and up-

dates accordingly the mapping ﬁle, as presented

in ﬁgure 2.

We perform this processing by following three ba-

sic functionalities:

Figure 2: Processing component.

– Metadata Changes Detection: an algorithm

is proposed to detect changes occurred in the

sources’ metadata. The changes are taken into

account by the algorithm, to classify them into

the corresponding metadata: matching between

and new data sources/metadata.

– Mappings Update: for this functionality, we

develop an algorithm to update the previous

mapping ﬁle to match the new changes. It takes

as input the list of changes resulted from the

ﬁrst algorithm, and outputs the updated map-

ping ﬁle.

According to the list of changed attributes, we

use a classiﬁcation algorithm to match data

with the corresponding attribute (ﬁgure 3).

Figure 3: Classiﬁcation.

– Integration Update: After generating the up-

dated mapping ﬁle, this latter gets transferred

to the integration component once more, in or-

der to maintain the integration process with the

new changes.

• Semantic Component: This component contains

the domain ontology allowing the semantic inte-

gration.

• User’s Interface Component: It represents the

front-end interface allowing to dialog with the

proposed system. Through this interface, users

are able to query the integrated data.

3.1 Data and Algorithms’ Description

This section describes the algorithms developed for

our approach, as well as a presentation of the drugs

dataset used for the prototype.

Semantic-based Data Integration and Mapping Maintenance: Application to Drugs Domain

471

3.1.1 Drug Dataset Overview

As aforementioned we applied our approach to the

drugs domain, thus we used the DrugBank dataset

It is a comprehensive online database containing in-

formation on drugs and drug targets. DrugBank com-

bines detailed drug (i.e. chemical, pharmacological

and pharmaceutical) data with comprehensive drug

target (i.e. sequence, structure, and pathway) infor-

mation. The database contains 9591 drug entries in-

cluding 2037 FDA-approved small molecule drugs,

241 FDA-approved biotech (protein/peptide) drugs,

96 nutraceuticals and over 6000 experimental drugs.

It contains 55 attributes, each attribute describing a

characteristic of the drugs. We enumerate some of

them : the drug identiﬁer (Drugbank-id), the drug’s

name, the drug’s Chemical Abstracts Service number

(CAS number).

3.1.2 Data Integration

The proposed approach starts with semantically inte-

grating data and generating the corresponding map-

ping ﬁles. Indeed, it matches the attributes of the data

source (metadata) with the ontology concepts. To do

so, we used Onto-Kit (Masmoudi and al, 2021), an

automatic ontology-based data integration tool. By

importing the drug ontology and the dataset to the

tool, we generate an RML mapping document 1. We

point out that RML is a mapping language that de-

scribes mapping rules between any form of data to

RDF (A triple based graph model language) (Mas-

moudi and al, 2021).

@prefix r r : <h t t p : / / www. w3 . o rg / n s / r 2 r m l #>.

@prefix r m l : <h t t p : / / semweb . mmlab . be / n s / rml#> .

@prefix x s d : <h t t p : / / www. w3 . o r g / 2 0 0 1 / XMLSchema#>.

@prefix r r x : <h t t p : / / www. w3 . o r g / n s / r 2 r m l −e x t #>.

@prefix r r x f : <h t t p : / / www. w3 . o r g / n s / r 2 r m l −e x t / f u n c t i o n s

/ d e f / > .

@prefix d rug b a n k v o c ab : <h t t p : / / b i o 2 r d f . o r g / d r u g b a n k

v o c a b u l a r y : >.

@base <h t t p : / / exa m p le . com / b a s e> .

<#DrugBankMapping> a r r : T ri p l e s M a p ;

rml : l o g i c a l S o u r c e [

rml : s o u r c e ”C: \ U s e r s \marmo\ One D riv e \ B u r eau

\TEST\ d r u g b a n k . c s v ” ;

rml : r e f e r e n c e F o r m u l a t i o n q l : CSV ;

] ;

r r : s u b j e c t M ap [

r r : t e m p l a t e ” h t t p : / / e x ampl e . com / { dr u g bank −i d } ” ;

r r : c l a s s d r u gba n k v o c a b : d r u gban k −i d ;

] ;

r r : p r e d i c a t e O b j e c t M a p [

r r : p r e d i c a t e d r u g b a n k voc a b : name ;

r r : o b j e c t M a p [

rml : r e f e r e n c e ”name ” ; ] ;

] ;

r r : p r e d i c a t e O b j e c t M a p [

r r : p r e d i c a t e d r u g b a n k voc a b : d e s c r i p t i o n ;

r r : o b j e c t M a p [

rml : r e f e r e n c e ” d e s c r i p t i o n ” ; ] ;

] ;

Listing 1: Mapping ﬁle.

Drugbank dataset, https://go.drugbank.com

This ﬁle deﬁnes links as a triple map format, be-

tween a concept of the ontology and an attribute of

the data source.

Onto-kit maps each class of the ontology to the

corresponding attribute of the dataset. Then, run-

ning through all the attributes, Onto-kit generates the

predicate-object mapping ﬁle, in which the number of

maps corresponds to the number of attributes of the

data source.

3.1.3 Metadata Change Detection

While ensuring the data integration, the work of the

processing component comes in play, when a change

is detected in the data source. We try periodically to

check change in the metadata following the algorithm

1. This detection is based on the old metadata previ-

ously registered of the data source and the new one.

Algorithm 1: Metadata change detection.

1: Old. f ile ← read −CSV (old. f ile)

2: New. f ile ← read −CSV (new. f ile)  Read the data

3: List.changes ← []

4: Old.attributes ← metadata − o f (Old. f ile)

5: New.attributes ← metadata.o f (New. f ile)  Get the metadata /

attributes

6: for attribute.1 in Old.attributes do

7: for attribute.2 in New.attributes do

8: while attribute.1 and attribute.2 have the same index do

9: if attribut e.1 is not similar to attribute.2 then  Check for

changes

10: Add attribut e.2 to List.changes

11: end if

12: end while

13: end for

14: end for

return List.changes

The algorithm 1 compares the old and the new

data source’s metadata, and returns a list of the

changed attributes. The next step is to determine the

corresponding attributes of these changes in the new

data source.

3.1.4 Metadata Matching

With the algorithm 1, we got to detect the attributes

that have been changed in the new data source. But

the problem is that we don’t know to which attributes

correspond these changes.

For example, we know that the metadata

drugbank − id and description have been changed,

but how can we match the new changes to them?

a bad scenario would be to correspond the data ”

DB00105 ” to the attribute description, and the data

” Lepirudin is used to break up clots and to reduce

thrombocytopenia. It binds to thrombin ... ” to

ICSOFT 2022 - 17th International Conference on Software Technologies

472

drugbank − id.

Such a bad matching would have bad impact on

the mapping ﬁle, and thus, it would result a wrong

data integration.

Thus, the problem we are facing now, is a classi-

ﬁcation one. This means that we want to classify the

data to a corresponding attribute. In other words, we

consider each attribute of the dataset as a class, and

based on the data, we predict the corresponding class.

Therefor, the purpose of the algorithm 2 is to

match the old changed attributes with the new ones.

This is done by training learning models to predict

which class an attribute’s data corresponds to. The

algorithm returns the attribute of the new data which

enables the resulting matching.

Algorithm 2: Metadata matching.

1: Data.Frame ← read −CSV(old. f ile)

 transform the dataframe to a two column data frame of attributes and

values

2: Data.Frame ← Re − map(Data.Frame)

 Delete NULL values

3: Data.Frame ← Drop.Null.Values

4: Dictionary ←[]

5: i ← 0

6: for attribute in data f rame.attributes do

7: add [attribute : i] to Dictionary

8: i ← i + 1

9: end for

 We replace the attributes by numerical values

10: Data.Frame[attributes] ← Data.Frame[Dictionary]

11: Labels ← Data.Frame[at tributes]

12: Vocab ← words in Data.Frame[values]

13: Vocab.int ← to − int (Vocab)

 We create a matrix of data in numerical values

14: Feature ← matr ix(Vocab.int(Data.Frame[values]))

 We split the data to training set and test set

15: train

,test

,train

,test

← train

est

plit( f eatures, labels)

16: train

,test

← one.hot.encoding(train

,test

)

17: model ← model.train(train

,train

)

18: Precision ← model. precision

19: New.Data ← Data.change from List.changes

20: Prediction ← model. predict(New.Data)

return Prediction

In terms of data processing, we transform all data

to strings. In the neural network, we use an embed-

ding layer, which purpose is compressing the feature

space of the input into a smaller one.

We use afterwards layers of LSTM (long short-

term memory) to conceptualize semantics in data, and

CNN (Convolutional neural network) layers to well

extract features of data.

For optimisation purposes (time execution and

precision), we decided to train the model on the at-

tributes (classes) changed. The predictions made will

be therefore applied to update the mappings.

3.1.5 Mapping File Update

In the integration process, the generated output is a

ﬁle of mappings connecting the metadata of the data

source with the ontology concepts. Our aim is to

change this ﬁle according to the predictions made by

the previous algorithm.

We perform this by replacing the changed at-

tributes in the mapping ﬁle, with the new ones pre-

dicted by the metadata matching algorithm.

4 IMPLEMENTATION AND

RESULTS

We present in this section the execution of our solu-

tion, as well as it’s application on different use cases.

4.1 Tools of Development

To manage the implementation of our approach, we

used the following tools :

• Google Colab

: We used Google colab as a

python platform to develop the proposed algo-

rithms and to build the prediction models of the

system.

• Keras

: We used the keras library to create, train

and test the prediction models of our system.

• Prot

: An open source ontology editor and

a knowledge management system. We used it to

explore the ontology of drugbank available online.

4.2 Evaluation Metrics

To evaluate the classiﬁcation models, we used the

confusion matrix. This latter is a table used to de-

scribe the performances of a classiﬁcation model on a

set of data. It differentiates between the true and false

positives and negatives. It allows us to compute the

metrics of Precision, Recall, F-mesure and Accuracy.

TP / TN: True Positive / True Negative.

FP / FN: False Positive / False Negative.

• Accuracy : It’s the ratio between the total correct

predictions and the total predictions. Accuracy =

T P+T N

T P+T N+FP+FN)

Google Colab, https://colab.research.google.com

Keras, https://keras.io

Prot

e, https://protege.stanford.edu

Semantic-based Data Integration and Mapping Maintenance: Application to Drugs Domain

473

• Precision: Proportion of well classed elements in

a particular class.

Precision =

T P

T P+FP

• Recall: Proportion of well classed elements over

the number of elements of a given class. Recall =

T P

T P+FN

• F1-score: Mesures the compromise between the

precision and the recall.

F1 −score =

2∗(Recall∗Precision)

(Recall+Precision)

Regarding the model’s calculated loss, we use the

Mean Square Error, to determine how much is the dif-

ference between the actual values and the predicted

values: y (Actual values), y

(Predicted values).

Loss = MSE =

∗

∑

i=1

+ y

)

4.3 Classiﬁcation Model

As for the classiﬁcation model, we use two architec-

tures and compare the results. Te ﬁrst architecture

depends on LSTM layers and the second depends on

CNN layers. The ﬁgure 4 presents these architectures.

We explore 2 use cases: 4 classes (4 attribute

changes) and 6 classes (6 attribute changes). We run

our approach in these cases, and capture the results.

4.4 Study Cases

The approach, and speciﬁcally the processing compo-

nent starts by detecting changes in ﬁles metadata. It

works by comparing lists of strings corresponding to

the metadata. The result is the list of changes with

attributes of the old ﬁle.

For the drugbank data we’re working with, we

have 55 attributes in the metadata. To illustrate the

result of the algorithm, we display changes over 10

attributes shown in table 1.

Table 1: Metadata change.

Old metadata drugbank-id name description cas-number unii

state groups general-references synthesis-reference indication

New metadata drug name speciﬁcation cas-number unii

state groups general-references source indication

As we can see, some attributes have been changed

(colored attributes), others did not. The algorithm

returns the list of attributes that have been changed

[drugbank-id, description, synthesis-reference]. We

train therefore the models, and we present the results

as study cases.

4.4.1 Case of 4 Classes

We plot the training-validation accuracy and loss

throughout the whole training of the model. These

(a) LSTM based model

(b) CNN based model

Figure 4: Classiﬁcation models.

plots (ﬁgure 6 a/b) describe the training phase of both

models. This phase has a training sub-phase in blue,

and a validation sub-phase in orange. We can see that

the LSTM model has a steady training accuracy, but

in contrast, it has a growing loss regarding the valida-

tion.

As for the CNN model, even though it lacks con-

sistency, it shows better results over the loss and ac-

curacy in training.

But these results do not fully represent the models

capacity, that’s why we test (test phase) them on a test

dataset, to compute the actual accuracy and recall.

Using the corresponding confusion matrices, we

compute the precision, recall, f1-score and accuracy

in table 2.

The test results show that, although the fact that

the LSTM model struggled and had poor results in

training, it has performed well. This is annotated by

ICSOFT 2022 - 17th International Conference on Software Technologies

474

Table 2: Metrics of the models for 4 classes.

Model Accuracy Precision Recall F1-score

LSTM Model 0.93 0.859 0.855 0.86

CNN model 0.90 0.80 0.80 0.81

the accuracy reaching 93%.

But overall, both models got good results by

reaching an accuracy of 90%

4.4.2 Case of 6 Classes

We plot again the training-validation accuracy and

loss throughout the whole training of the model (ﬁg-

ure 6 c/d).

The plots show that both models do train well, but

have trouble to well predict the classes in the valida-

tion. As validation loss, once again, the CNN model

show better results, but it lacks consistency.

We execute therefore the models on a test dataset

and compute evaluation metrics as shown in table 3.

As test results, LSTM model gives better perfor-

mance, even though it lacked a bit in the training

phase. These good results are due to it’s consistency

in the training, which is not the case for the CNN

model, who, the more it loses consistency, the more

poorly it performs.

Table 3: Metrics of the models for 6 classes.

Model Accuracy Precision Recall F1-score

LSTM Model 0.93 0.891 0.894 0.89

CNN model 0.85 0.74 0.72 0.70

But in general, the performance of both models is

good, by attending 85% for the CNN model and 93%

for the LSTM model.

4.4.3 Optimization

For both models, we have observed that they suffer

from an over-ﬁtting problem. This problem means

that the model has a bad generalisation (Brownlee,

2018). It has learned too much that it performed well

on the training but poorly on a new data (test data).

So, to overcome this issue, we have applied some

regularisation techniques throughout our process to

get better results. Speciﬁcally, we used dropout and

early stopping.

By using both techniques, we managed to raise the

accuracy of both models to nearly 80%.

4.5 Mappings Update

As previously said, the classiﬁcation algorithm takes

as input the data corresponding to the changes dis-

covered, and it outputs the attribute (class) of each set

of data. To update the mappings ﬁle, we take list of

changes and update the ﬁle correspondingly.

The ﬁnal updated ﬁle (shown in ﬁgure 5) will en-

sure that the data integration approach works without

any issues, regardless of the metadata change of data

sources.

(a) Old mappings

(b) Updated mappings

Figure 5: Results of the mappings update.

Semantic-based Data Integration and Mapping Maintenance: Application to Drugs Domain

475

(a) LSTM based model

(4 classes)

(b) CNN based model (4

classes)

(6 classes)

(d) CNN based model (6

classes)

Figure 6: Test cases’ models training.

5 CONCLUSION AND

LIMITATIONS

In this paper, we give a response to the problem of

how to ensure the maintenance of the virtual data in-

tegration and metadata changes. Indeed, we present a

semantic-based data integration and mapping mainte-

nance approach with an application to drugs domain.

The proposed approach contains two main compo-

nents: a virtual semantic data integration component,

and a mapping update component. Both of them en-

sure the fully automated mapping maintenance of the

data integration. The proposal includes deep learning

techniques for the mapping maintenance. We have

performed our solution on two use cases, 4 and 6

changes in the data sources’ metadata. In each case,

we detect changes, and train a deep learning model to

classify the corresponding attribute based on its’ data.

We used also two types of models, an LSTM-based

model and a CNN-based model.

In terms of results, the models showed interest-

ing performances, as the accuracy reached 90%. Al-

though, the models did suffer from an over-ﬁtting

problem, which is due to the similarity between the

different classes (attributes) in the dataset. Overall,

our solution is fully automated, which represents huge

beneﬁts compared to the existing solutions that re-

quire human intervention. In matters of time execu-

tion, training models do not surpass the limit of 10

minutes for the worst-case scenario. This time exe-

cution is indeed long for an automated system, but

compared to the state of the art (human intervention),

it shows signiﬁcant optimal result. We are currently

working on the number of classes that the model

needs to deal with. Indeed, as we handle data sources

changes, the data within these sources doesn’t contain

high rate of change. So, basically, the models work

on the same data that they were trained on, which will

enable high performance results. We intend also, to

manage not only one-to-one changes (one class corre-

sponding to only one class), but one to many changes,

which will improve the mapping maintenance. We

also plan, to improve our proposal to support differ-

ent multimodal data.

ACKNOWLEDGMENT

This work was funded by CY Initiative of Excellence

(grant ”Investissements d’Avenir” ANR- 16-IDEX-

0008), MuseMed Emergence project.

REFERENCES

Ahmad Abdullah Alqarni, E. P. (2017). Xml schema match-

ing using early dissimilarity detection approaches. In

La Trobe University Melbourne, Australia.

Brownlee, J. (2018). Better deep learning, train faster, re-

duce overﬁtting, and make better predictions.

Cesar, J. and al (2015). Dykosmap a framework for map-

ping adaptation between biomedical knowledge orga-

nization systems. In Journal of Biomedical Informat-

ics (EDBT).

Cesar, J. and al. (2015). State-of-the-art on mapping main-

tenance and challenges towards a fully automatic ap-

proach.

Do, H. (2007). Schema matching and mapping-based data

integration: architecture, approaches, and evaluation.

Khattaka, A. and al. (2015). Mapping evolution of dynamic

web ontologies. In Information Sciences.

Maria-Esther, V. and al. (2019). Semantic data integration

of big biomedical data for supporting personalised

medicine.

ICSOFT 2022 - 17th International Conference on Software Technologies

476

Masmoudi, M. and al (2021). Knowledge hypergraph-based

approach for data integration and querying: Applica-

tion to earth observation.

Mehdi, O. and al (2015). An approach for instance based

schema matching with google similarity and regular

expression. In University Putra Malaysia, Malaysia.

Mohamed-Amine, B. and al (2017). Schema inference for

massive json datasets. In The International Confer-

ence on Extending Database Technology (EDBT).

Munir, S. and al (2014). An instance-based schema match-

ing between opaque database schemas. In Proceed-

ings of the 4th International Conference on Engineer-

ing Technology and Technopreneuship (ICE2T).

N. Popitsch, B. H. (2018). Dsnotify – a solution for event

detection and link maintenance in dynamic datasets.

In Journal of web semantics.

Sahay, T. and al (2019). A schema matching using machine

learning. In 7th International Conference on Signal

Processing and Integrated Networks.

Semantic-based Data Integration and Mapping Maintenance: Application to Drugs Domain

477
