PE-AONT: Partial Encryption All or Nothing Transform

Katarzyna Kapusta

1,2 a

and Gerard Memmi

2 b

Thales SIX GTS France, ThereSIS, Palaiseau, France

LTCI, T

ecom Paris, Institut Polytechnique de Paris, Palaiseau, France

Keywords:

Data Fragmentation, Data Dispersal, Distributed Storage, Multi-storage, Cloud Storage Security, Key

Exposure, Secret Sharing, All-or-Nothing, AONT, SAKE-secure.

Abstract:

We introduce PE-AONT: a novel algorithm for very fast computational secret sharing scheme. The core idea

of this scheme is to encrypt the data only partially before applying an all-or-nothing transform that will blend

the encrypted and non-encrypted data. By doing this, we achieve much better performance than relevant

techniques including straightforward encryption. To this regard, a performance benchmark is provided. In-

terestingly, when the ratio between the number of encrypted and non-encrypted fragments is wisely chosen,

data inside fragments are protected against exposure of the encryption key unless all fragments are gathered

by an attacker. Therefore, by choosing the right parameters, we can achieve key exposure protection, faster

processing, and a better overall protection.

1 INTRODUCTION

Fragmenting and dispersing data over multiple inde-

pendent storage sites reinforces its levels of conﬁden-

tiality, integrity, and availability (Bessani et al., 2013).

During the past decades, multiple fragmentation

methods were deﬁned and used in various settings

(Buchanan et al., 2015; Memmi et al., 2015). These

methods include but are not limited to information-

theoretic secret sharing schemes (Shamir, 1979; Blak-

ley, 1979), information dispersal algorithms (Rabin,

1989), as well as schemes combining symmetric en-

cryption with data fragmentation (Krawczyk, 1994;

Resch and Plank, 2011).

In distributed systems, it is not uncommon to en-

crypt then fragment data in large chunks in a straight-

forward manner and then disperse them over differ-

ent independent servers or storage sites. To support

key management, encryption keys will be fragmented

using a secret sharing scheme and appended to data

fragments. To ensure resilience, data replication or

error-correction codes (Reed and Solomon, 1960)

may be applied. This sturdy way of proceeding does

not protect against attackers able to recover encryp-

tion keys. Such attackers may obtain a portion of

information just by decrypting fragments they suc-

ceeded to access to.

https://orcid.org/0000-0003-0963-4782

https://orcid.org/0000-0002-3380-8394

Protection against key exposure requires addi-

tional post-processing that will create dependencies

between ciphertext blocks contained inside the frag-

ments (Karame et al., 2018) or that will shred ci-

phertext blocks over fragments (Kapusta and Memmi,

2018a). Encrypted data are then protected against key

exposure unless all fragments are gathered. Such ad-

ditional protection comes at a performance cost, as it

increases the required number of operations.

On another hand, partial encryption is usually

used in lightweight cipher. In this paper, we intro-

duce Partial Encryption with All Or Nothing Trans-

form (PE-AONT) : a new fragmentation algorithm

that is not only faster than most common fragmen-

tation techniques, but also (when carefully applied)

protects encrypted data inside fragments against a sit-

uation of key exposure. To this end, PE-AONT frag-

ments initial data into k fragments and encrypts only

e of them. In a next step, it applies an AONT over

the totality of the fragments that exclusive-ors cipher-

text with plaintext blocks. PE-AONT is then combin-

ing AONT technique with partial encryption achiev-

ing both speed and a good level of security. A secure

dispersal of fragments ensures that data from a single

fragment cannot be recovered unless all fragments are

being gathered. Limiting data encryption to e frag-

ments allows speeding up performance in proportion

of (k − e)/k, while the AONT combined with frag-

mentation ensures good level of data protection. Last

but not least, tuning the values of k and e provides

636

Kapusta, K. and Memmi, G.

PE-AONT: Partial Encryption All or Nothing Transform.

DOI: 10.5220/0011300600003283

In Proceedings of the 19th International Conference on Security and Cryptography (SECRYPT 2022), pages 636-641

ISBN: 978-989-758-590-6; ISSN: 2184-7711

the user with a seldom means to easily change the ra-

tio between performance and data protection level in

order to meet the desired requirements of his applica-

tion.

Outline. In Section 2, we present a selection of rele-

vant techniques for fast data fragmentation. We also

recall two threat models to analyze protection under

key exposure. In Section 3, we describe in details

the proposed PE-AONT algorithm. In Section 4, we

compare PE-AONT with relevant works, analyzing

its complexity and level of data protection. A per-

formance benchmark is provided in Section 5. We

conclude with an insight into future works.

2 RELEVANT WORKS

In this section, we brieﬂy describe selected relevant

fragmentation techniques that will later be used for

theoretical ans performance comparisons. The inter-

ested reader can go to (Memmi et al., 2015; Qiu et al.,

2019) for more extensive surveys.

2.1 Notations

By convention, we keep upper cases variables for se-

quences of bits (D for the initial data, F for a frag-

ment, C for a block). Lower cases variables are for pa-

rameters: initial data D are divided into k fragments.

A fragment is seen as sequence of f blocks and D of

l = f × k blocks.

For resilience purposes, a threshold (i.e. the mini-

mal number of fragments necessary to reconstruct D,

moreover, less fragments must not provide any infor-

mation about the D) can be introduced, In such a case,

D is divided into n fragments with a threshold of k.

2.2 Encryption and Straightforward

Fragmentation

A computationally secure scheme for fragmentation

of a large amount of data was ﬁrst introduced by

Krawczyk in his seminal work Secret Sharing Made

Short (SSMS) (Krawczyk, 1994). SSMS is a general

methodology combining data encryption and frag-

mentation together with secret sharing of the encryp-

tion key. In the original proposal, data is encrypted

using a symmetric cipher (usually, AES), and then

fragmented using an information dispersal algorithm

(e.g. see (Rabin, 1989)) into n fragments. A thresh-

old of k of them are needed for data reconstruction.

Encryption key is split using a perfect secret sharing

scheme (typically Shamir’s secret sharing (Shamir,

1979)) and embedded within data fragments. In con-

trast to perfect secret sharing schemes (such as one-

time pad or Shamir’s scheme), the storage overhead

of SSMS does not depend on data size, but is equal

to the key size per data fragment which is practically

negligible for sizeable data.

Performance of SSMS depends on implementa-

tion details of encryption and dispersal techniques. In

modern implementations, systematic error-correction

codes are used as the dispersal technique (Bessani

et al., 2013; Reed and Solomon, 1960). This improves

the performance, but allows a partial decryption of

compromised fragments in a situation of key expo-

sure, as the set of fragments contains fragments that

are formed from large encrypted data chunks.

Alike SSMS, the AONT-RS method (Chen et al.,

2017; Resch and Plank, 2011) combines symmetric

encryption with data dispersal. The difference be-

tween those two methodologies lies in the key man-

agement. In AONT-RS, the key is exclusive-ored with

the encrypted data hash. See (Qiu et al., 2019) for a

survey on different AONT variations such as (Boyko,

1999). A recent extension to AONT can be found in

(Esfahani et al., 2021).

2.3 CAKE Threat Model and the

Bastion Scheme

The Ciphertext Access under Key Exposure (CAKE)

threat model (Karame et al., 2018) aims at addressing

the problem of data protection against key exposure

in cloud environments. A scheme is denoted to be

(l − λ) CAKE-secure when it resists an attacker able

to access any (l − λ) blocks of the dispersed ciphertext

as well as the encryption key. Bastion protects trans-

formed ciphertext against key exposure as long as two

blocks are not being exposed ((l-2) CAKE-secure).

Authors of the CAKE model introduce an efﬁ-

cient encryption scheme, Bastion, that provides c − 2

CAKE security (decryption computationally infeasi-

ble unless all but two ciphertext blocks are being gath-

ered). In more details, the sequence of l input cipher-

text blocks X = X

,..., X

is is transformed into a se-

quence of l transformed blocks: X

= X

,..., X

multiplying X by a square matrix A, such that: (i) all

diagonal elements are set to 0, and (ii) the remaining

off-diagonal elements are set to 1. The multiplication

= A · X (where ’and’ and ’xor’ stand for ’multi-

ply’ and ’add’ respectively) ensures that each output

block X

will depend on all input blocks X

excluding

. k fragments are then formed from the transformed

ciphertext, for instance, by cutting it into blocks of

The Bastion scheme achieves much better per-

formance than other AONTs as it requires only 2l

PE-AONT: Partial Encryption All or Nothing Transform

637

exclusive-or operations in addition to data encryption.

2.4 SAKE Threat Model

The Shares Access under Key Exposure (SAKE)

threat model introduced in (Kapusta et al., 2020),

is a variation of CAKE that results from the obser-

vation that once an attacker compromises a storage

site, she will be most probably able to acquire all the

blocks of the share S

stored at this site. A scheme

is denoted (k − λ) SAKE-secure when it resists an at-

tacker able to access any (k − λ) fragments of the dis-

persed ciphertext as well as the encryption key. The

SAKE model comes with SSAKE and ROSSAKE

schemes that outperforms the Bastion scheme (thanks

to changing the threat model, it is possible to re-

duce (SSAKE) or even remove (ROSSAKE) the post-

processing of the ciphertext) (see (Kapusta et al.,

2020) for details).

2.5 Mix and Slice

Mix&Slice (Bacis et al., 2016) is an approach to

enforce access revocation on data stored at external

Cloud providers. Before being uploaded to the cloud,

data is transformed in an AONT manner making the

data decryption infeasible as long as the ciphertext is

incomplete. Consequently, re-encrypting even a small

portion of the outsourced data with a fresh key re-

vokes the access to a user who does not possess the

new key. Mix&Slice uses a symmetric block cipher

to create dependencies inside the data. Indeed, a sym-

metric block function transforms a plaintext block

into a ciphertext block, correct decryption of which

is infeasible when even a single bit of data is missing.

Thus, it is possible to use it as a way of creating strong

dependencies between bits of data.

2.6 Secure Fragmentation and

Dispersal (SFD)

Secure fragmentation and dispersal (Kapusta and

Memmi, 2018a) divides a ciphertext encrypted us-

ing a block cipher with a mode of operation that cre-

ates chaining between consecutive ciphertext blocks

(like Cipher Block Chaining) into fragments resisting

to key exposure. The complete scheme is composed

of three steps. The ﬁrst step separates consecutive

blocks of the ciphertext. The second step separates

bits of blocks over ﬁnal fragments. At last, fragments

are dispersed and stored over independent storage lo-

cations e.g. multiple cloud providers (like in (Bessani

et al., 2013)). In consequence, an attacker present at

a single storage location is unable to decrypt a single

block of the ciphertext even if she possesses the right

encryption key.

3 ALGORITHM DESCRIPTION

PE-AONT is composed of three steps detailed in the

subsequent subsections. In a ﬁrst step, initial data D

together with an Initial Vector (IV) is composed of l

plaintext blocks. They are structured into k fragments

of which only e of them are encrypted. In a second

step, the k fragments are transformed using an AONT

that blends ciphertext contained inside the e encrypted

fragments with the k − e plaintext fragments in a one-

time pad fashion. It is this step that is ensuring the

protection of the k − e plaintext fragments with a level

of protection depending on the values of k and e. The

last step simply consists of dispersing the fragments.

3.1 Step1: Data Fragmentation and

Partial Encryption

The pseudo-code of the ﬁrst step of the algorithm -

FRAGMENTANDENCRYPT- is presented in Figure 1

and illustrated by the example in Figure 2.

1: function FRAGMENTANDENCRYPT(D,e,k)

2: Fragment data D into k initial fragments

,..., F

k−1

and of

3: //each fragment has f blocks

4: //Encrypt e of the k fragments:

5: for each fragment F

, i = 0, .. .,e − 1 do

6: Encrypt fragment F

7: // l blocks C

,...,C

l−1

are now straightfor-

wardly deﬁned from the e encrypted fragments

and the k − e plaintext fragments.

Figure 1: Pseudo-code of Step 1 fragmenting data into k

fragments, encrypting e of them, creating l blocks.

Figure 2: Step 1 example with k = 4, e = 3, and l = 8. The

ﬁrst step of the algorithm fragments D into k fragments of

f = 2 blocks, the last fragment contains plaintext blocks. D

has 7 blocks: D = P

,...P

. The block P

= IV is added

to D; it corresponds to the ciphertext block containing the

Initial Vector used by the cipher.

During this step, a block P

containing the Initial

Vector (IV) is added to D = P

,...P

the initial data

to form l plaintext blocks which are structured into k

fragments. Only e < k of the fragments are being en-

SECRYPT 2022 - 19th International Conference on Security and Cryptography

638

crypted using a block cipher (usually, AES). There-

fore, at the end of the processing l blocks denoted

with the letter C are created. Each fragment contains

f =

blocks, e fragments contain ciphertext blocks,

k − e of them contain plaintext blocks.

The fragments can be put together side by side to

form a matrix of f rows and k columns as in Figure 2

where each block is an element of the matrix, each

column a fragment. This way of organizing blocks

will be used to more easily describe the second step

of our algorithm.

3.2 Step 2: All-or-Nothing Transform of

the Fragments

The pseudo-code of the second step of the algorithm -

AONTTRANSFORM - is presented in Figure 3 and il-

lustrated by a continuation of the example of Figure 2

shown in Figure 4. Blocks are processed in a row by

row fashion by sets of k blocks, each block coming

from a different fragment. The AONT presented in

(Karame et al., 2018; Stinson, 2001) is applied over

the set of k blocks, e of which are ciphertext blocks

and the k − e remaining ones are plaintext blocks.

1: function AONTRANSFORM(D)

2: for i = 0, .. ., f − 1 do

3: sum =

j=k−1

f × j+i

4: for j = 0,. ..,k − 1 do

5: C

f × j+i

= sum ⊕C

f × j+i

Figure 3: Pseudo-code of Step 2. An AONT is applied over

the k fragments exclusive-oring their plaintext and cipher-

text blocks. f denotes the number of blocks inside a frag-

ment. Blocks are processed by ’rows’ of k blocks (each

block of a given row coming from a different fragment). For

each ’row’ of k blocks a sum value containing the exclusive-

or of the k blocks is ﬁrst computed. sum is then exclusive-

ored with each original block in the row in order to remove

it and getting a different new block in each fragment.

It must be pointed out that for k = 2 this process-

ing does not change anything about the values of the

blocks save for the 2 fragments numbering. For k = 3

the knowledge of 2 fragments allows deducing the

third one. It is therefore, necessary to consider k > 3.

3.3 Step 3: Dispersing Fragments

In a ﬁnal step, fragments are dispersed over indepen-

dent storage sites. The dispersal technique depends

on values of e and k and of course, on the number of

available machines.

• For e = k − 1: no more than k − 2 fragments can

be stored at a single storage site. This comes from

the property of the linear AONT protecting trans-

Figure 4: Step2, example for k = 4 and e = 3. Fragments

are transformed using an AONT that exclusive-ors cipher-

text and plaintext blocks. The transform is applied ’row’

by ’row’ over k blocks (each block comes from a different

fragment) protecting the k− e fragments which were not en-

crypted.

formed blocks unless more than k − 2 blocks are

exposed (Karame et al., 2018).

• For e < k − 1: all fragments have to be dispersed

over independent storage sites. As the number

of plaintext fragments increases, it is possible that

same combinations of ciphertext blocks will be

used to protect different plaintext blocks.

3.4 Further Considerations

As -AONTransform- uses the Bastion transform over

k blocks at a time, k has to be even in order to al-

low the Bastion’s reconstruction matrix to be invert-

ible (Karame et al., 2018) ). Under this condition, the

defragmentation process is an inverse of the fragmen-

tation and is straightforward.

Indeed, data protection level is lower as e de-

creases and fragments are only secure when the as-

sumed attacker is not able to compromise more than

one storage site. It is the price that has to be paid for

speeding up the algorithm processing.

4 THEORETICAL ASPECTS

4.1 Choosing PE-AONT Parameters

To achieve the protection against key exposure, each

plaintext block should be exclusive-ored with at least

two different ciphertext blocks. This goes from the

deﬁnition of a SAKE-secure scheme, which is pre-

sented in details in (Kapusta et al., 2020). An intuitive

explanation is that an adversary possessing a linear

combination of plaintext blocks xored with a single

ciphertext block is able to win the ind-CPA game. In

contrary, if the plaintext blocks are xored with more

that one ciphertext blocks, the adversary has a negli-

gible chance to win the game, even if it possess the

right encryption key.

Thus, the minimum value of e is 3, which enables

combinations of at least two ciphertext blocks hiding

a plaintext. The minimum value of k is 4, as the num-

ber of input block has to be even in order to allow

PE-AONT: Partial Encryption All or Nothing Transform

639

the Bastion’s reconstruction matrix to be invertible

(Karame et al., 2018) and k ≥ e. Intuitively, the larger

the value of e, the higher will be the provided level

of data protection. When e = k − 1, data cannot be

decrypted unless all k fragments are gathered. Frag-

ments are thus protected against key exposure (are

SAKE-secured). It’s the most interesting PE-AONT

conﬁguration from a security point of view, as it is not

only faster than encryption and straightforward frag-

mentation (enc.+ SF) but also protects data against

key exposure.

When 3 ≤ e ≤ k − 2 the protection is lower and en-

sured only if the attacker is not able to access to more

than a single storage site. Indeed, when the attacker

compromised more than one site, she can obtain re-

lationships between fragments by exclusive-oring the

fragments in her possession (a similar problem occurs

when a one-time pad is reused).

4.2 Comparison with Relevant Schemes

We compared PE-AONT with relevant works in terms

of amount of computations and ability to protect

against key exposure. Results are shown in Figure 5.

As a baseline, we use encryption that requires l − 1

block cipher operations and l − 1 exclusive-or op-

erations (when applied on a plaintext composed of

m = l − 1 blocks).

Figure 5: Comparison in terms of number of block cipher

operations (block op.), number of exclusive-ors, and ability

to provide a key exposure protection (K.E.P), assuming a

plaintext of l − 1 blocks. (*): PE-AONT provides key expo-

sure protection when e ≥ 3. When e < k − 1 fragments are

protected against key exposure, but data is protected only

against an attacker at a single storage site.

Bastion scheme applies only a linear transform

over the encrypted data without increasing the num-

ber of block cipher operations. Bastion’s trans-

form uses 2l exclusive-or operations. Counting with

the encryption step, Bastion scheme requires 3l − 1

exclusive-ors.

SFD does not require additional operations in ad-

dition to data encryption, as it just disperses data

chunks over fragments (depending on the program-

ming technique this also leads to a slight performance

overhead of up to 11%).

PE-AONT requires only e × f block cipher op-

erations, as it does not encrypt the totality of the

Figure 6: Performance benchmark. PE-AONT was mea-

sured in different conﬁgurations of (k, e). In all of them it

is faster than encryption and straightforward fragmentation

(enc.+ SF). It is also faster than two fragmentation schemes

protecting against data exposure: secure fragmentation and

dispersal (SFD) and the Bastion scheme.

data contained inside the fragments. It performs

2l + f × (e − 1) exclusive-or operations: e × f during

the encryption and 2l − f during the AONT.

5 PERFORMANCE

COMPARISON

Implementation Details. Relevant algorithms were

implemented using the same programing style in

JAVA with JDK 1.8 on DELL Latitude E6540, X64-

based PC running on Intel

Core

i7-4800MQ CPU

@ 2.70 GHz with 8 GB RAM, under Windows 7.

Standard javax.crypto library was used. A random

data sample was used for each measurement and each

presented result is an average of 30 measurements.

AES-NI with 128 bits key was used for encryption.

Performance comparison between relevant algo-

rithms is presented in Figure 6. The performance of

PE-AONT is shown in 4 conﬁgurations: two con-

ﬁgurations were e = k − 1 (and where the protec-

tion level is high) and for two conﬁgurations when

e ≤ k − 2 (data protection is traded for better perfor-

mance). In all conﬁgurations, PE-AONT outperforms

encryption and straightforward fragmentation. More-

over, it is much faster than two relevant fragmentation

techniques protecting fragmented data against key ex-

posure: SFD and Bastion’s scheme.

6 FUTURE WORKS

Our software integrates AES-NI cipher and PE-

AONT in a coarse-grained fashion. In the future, we

would like to integrate the algorithm within the code

of the encryption process in a ﬁne-grain fashion to al-

low an even better fragmentation performance. We

improved the Bastion AONT algorithm by decreas-

ing the number of Xor operations needed to protect

SECRYPT 2022 - 19th International Conference on Security and Cryptography

640

data against key exposure in (Kapusta and Memmi,

2018b) or in (Kapusta and Memmi, 2018c). It be-

comes important to keep analyzing and comparing

these various scheme and determine in which situa-

tion one method is preferable over another one. We

believe PE-AONT is very likely best ﬁtted as a tun-

able lightweight cipher since it is faster than the other

AONT algorithms.

Moreover, we would like to integrate PE-AONT

inside a complete distributed system protecting data

using an adaptable combination of fragmentation, en-

cryption, and dispersal (Kapusta et al., 2020).

7 CONCLUSION

PE-AONT: a fast fragmentation method combining

Partial Encryption with an AONT was introduced in

order to speed up the overall scheme performance

in a tun-able fashion. The desired ratio between

performance and protection levels can easily be ad-

justed by users with just two parameters to increase

performance and decrease protection or the other

way around. An experimental evaluation shows that

the algorithm achieves better performance than rele-

vant techniques including the most common way of

data fragmentation. As such, it can be chosen as a

lightweight cipher. Moreover, by carefully choosing

parameters values, it protects fragmented data against

key exposure (SAKE-secure) as long as an attacker

does not access to the entire set of fragments.

We now believe that PE-AONT is ready for seri-

ous consideration as a component and successfully be

integrated within modern distributed or transmission

systems where rapid protection is required.

REFERENCES

Bacis, E., De Capitani di Vimercati, S., Foresti, S.,

Paraboschi, S., Rosa, M., and Samarati, P. (2016).

Mix&slice: Efﬁcient access revocation in the cloud.

In Proc. of the 2016 ACM SIGSAC Conf. on Computer

and Communications Security, CCS’16, pages 217—

-228, New York, NY, USA. ACM.

Bessani, A., Correia, M., Quaresma, B., Andr

e, F., and

Sousa, P. (2013). Depsky: Dependable and se-

cure storage in a cloud-of-clouds. Trans. Storage,

9(4):12:1–12:33.

Blakley, G. (1979). Safeguarding cryptographic keys. In

Proc. of the National Computer Conf. v48, pp313-317.

Boyko, V. (1999). On the security properties of OAEP as an

all-or-nothing transform. In Wiener, M. J., editor, Ad-

vances in Cryptology - CRYPTO’99, 19

Annual Int.

Cryptology Conf., Santa Barbara, CA, USA, August,

1999, Proc., LNCS 1666, P503-518. Springer.

Buchanan, W., Lanc, D., Ukwandu, E., Fan, L., and Rus-

sell, G. (2015). The future internet: A world of secret

shares. Future Internet, 7(4):445.

Chen, L., Laing, T. M., and Martin, K. M. (2017). Revisiting

and Extending the AONT-RS Scheme: A Robust Com-

putationally Secure Secret Sharing Scheme, pages 40–

57. Springer Int. Pub., Cham.

Esfahani, N. N., Cheriton, D. R., and Stinson, D. R.

(2021). Asymetric all-or-nothing transforms.

arXiv:2105.14988v1.

Kapusta, K. and Memmi, G. (2018a). Enhancing data

protection in a distributed storage environment us-

ing structure-wise fragmentation and dispersal of en-

crypted data. In 2018 17

IEEE Int. Conf. On Trust,

Security And Privacy In Computing And Communica-

tions (TrustCom/BigDataSE), pages 385–390.

Kapusta, K. and Memmi, G. (2018b). Poster: Circular aon:

A very fast scheme to protect encrypted data against

key exposure. In ACM CCS’18, Toronto, Canada.

Kapusta, K. and Memmi, G. (2018c). Selective all-or-

nothing transform: Protecting outsourced data against

key exposure. In Proc. of 10th Int. Symp, CSS, LNCS

11161, pages 181–193, Amalﬁ, Italy. Springer.

Kapusta, K., Rambaud, M., and Memmi, G. (2020). Revis-

iting shared data protection against key exposure. In

Sun, H., Shieh, S., Gu, G., and Ateniese, G., editors,

ASIA CCS ’20: The 15

ACM Asia Conference on

Computer and Communications Security, Taipei, Tai-

wan, October 5-9, 2020, pages 165–177. ACM.

Karame, G. O., Soriente, C., Lichota, K., and Capkun, S.

(2018). Securing cloud data under key exposure. IEEE

Trans. on Cloud Computing, pages 1–1.

Krawczyk, H. (1994). Secret sharing made short. In Proc. of

the 13

Annual International Cryptology Conference

on Advances in Cryptology, CRYPTO ’93, pages 136–

146, London, UK. Springer-Verlag.

Memmi, G., Kapusta, K., and Qiu, H. (2015). Data protec-

tion: Combining fragmentation, encryption, and dis-

persion. In 2015 International Conference on Cyber

Security of Smart Cities, Industrial Control System

and Communications (SSIC), pages 1–9.

Qiu, H., Kapusta, K., Lu, Z., Qiu, M., and Memmi, G.

(2019). All-or-nothing data protection for ubiquitous

communication: Challenges and perspectives. Inf.

Sci., 502:434–445.

Rabin, M. O. (1989). Efﬁcient dispersal of information for

security, load balancing, and fault tolerance. J. ACM,

36(2):335–348.

Reed, I. S. and Solomon, G. (1960). Polynomial Codes

Over Certain Finite Fields. Journal of the Society for

Industrial and Applied Mathematics, 8(2):300–304.

Resch, J. K. and Plank, J. S. (2011). Aont-rs: Blending se-

curity and performance in dispersed storage systems.

In 9

USENIX Conf. on File and Storage Technolo-

gies, FAST’11, pages 14–14, Berkeley, CA, USA.

Shamir, A. (1979). How to share a secret. Commun. ACM,

22(11):612–613.

Stinson, D. R. (2001). Something about all or nothing

(transforms). Des. Codes Crypto., 22(2):133–138.

PE-AONT: Partial Encryption All or Nothing Transform

641
