HERO: An Artiﬁcial Conversational Assistant to

Support Humans in Industrial Scenarios

Claudia Bonanno

, Francesco Ragusa

1,2

, Rosario Leonardi

, Antonino Furnari

1,2

and Giovanni Maria Farinella

1,2

FPV@IPLAB, DMI - University of Catania, Italy

Next Vision s.r.l. - Spinoff of the University of Catania, Italy

gfarinella@dmi.unict.it

Keywords:

First Person Vision, Object Detection, Chatbot, Conversational Agent, Visual Question Answering.

Abstract:

We present HERO, a Conversational Intelligent Assistant to support workers in industrial domains. The pro-

posed system is able to interact with humans using natural language and observing the surrounding world in

order to avoid the language ambiguity. HERO is composed of four modules: 1) the input module to process

both text and visual signals, 2) the NLP module to predict user intent and extract relevant entities from text,

3) the object detection module to extract entities by analyzing images captured by the user and 4) the output

module which is responsible for choosing the best answer to send to the user. To assess its usefulness in a real

scenario, the proposed system is implemented and evaluated in an industrial laboratory setting. Preliminary

experiments show that HERO achieves good performance in predicting intents and entities exploiting both text

and visual signals.

1 INTRODUCTION

Artiﬁcial Intelligence (AI) allows to build systems

which enable automatic conversation between hu-

mans and machines using natural language. These

conversational agents could be integrated in more

complex systems with the aim to support humans

where they live and work. Generally, conversa-

tional AI systems can be grouped into three categories

(Gao et al., 2018): 1) task-oriented systems, 2) chat-

oriented systems and 3) question answering systems.

The ﬁrst category comprises all systems that aim to

address speciﬁc tasks such as booking a table at a

restaurant or ordering a pizza, while chatbots are de-

signed to handle common queries (e.g., “tell me a

joke”) or to simulate conversation with a virtual friend

(Fedorenko et al., 2017). Given a user’s query, ques-

tion answering bots are able to exploit previously col-

lected knowledge and resources to ﬁnd the most ap-

propriate answer.

Nowadays, well-known hybrid systems, belong-

ing to both chatbot and question answering categories,

are exploited in daily-life applications such as Apple’s

Siri (Apple, 2012) (e.g., to ask her to call someone),

Microsoft’s Cortana (Microsoft, 2014) (e.g., to open

a speciﬁc app in our personal computer) or Amazon’s

Figure 1: Concept of the proposed AI Assistant HERO.

Alexa (Amazon, 2014) (e.g., to receive information

about the weather or to listen to your favourite songs).

Conversational agents are used also in the context of

marketing or customer care, providing several func-

tions such as answering frequently asked questions,

resolving customer queries or recommending new of-

fers in an automatic way. Conversational agents are

used as well in the kitchens domain, where they can

support humans for maintenance of the coffee ma-

chine (Mleczko, 2021).

Bonanno, C., Ragusa, F., Leonardi, R., Furnari, A. and Farinella, G.

HERO: An Artiﬁcial Conversational Assistant to Support Humans in Industrial Scenarios.

DOI: 10.5220/0011318600003289

In Proceedings of the 19th International Conference on Signal Processing and Multimedia Applications (SIGMAP 2022), pages 86-93

ISBN: 978-989-758-591-3; ISSN: 2184-9471

While these solutions are widely employed, they

suffer from natural language ambiguity (or diversity)

due to the fact that they cannot see the surrounding

environment. Recently Amazon’s Alexa has a new

available feature called “Show and Tell” (Amazon,

2019) which allows visually impaired users to exploit

the camera of the smartphone/tablet to recognize the

objects in the hands of the user. Also in the con-

text of kitchens, a conversational agent which can see

through a mobile phone’s camera has been developed

to assist visually impaired people to understand how

long to cook a microwave meal or if it contains an in-

gredient they are allergic to (Brick et al., 2021). De-

spite the progress made in this ﬁeld, there are not so-

lutions able to support workers in the industrial do-

main, e.g., assisting them during the maintenance op-

erations “What is the next step?”) or providing con-

tinuous training (“How can I use this tool?”).

In this paper, we present HERO, an AI Assistant

that, through the interaction with a Conversational

Agent equipped with artiﬁcial vision allows the user

to request information about the environment or the

objects (e.g., How can I use this object?) using natural

language, as well as images acquired from the user’s

point of view using wearable devices (see Figure 1).

HERO is based on the Egocentric Vision paradigm,

which offers a convenient setting to collect visual in-

formation about the user’s activities and the interac-

tions with objects and can be useful to remove the

ambiguity present in the human’s questions. Speciﬁ-

cally, we assume that the user interacting with HERO

is equipped with a wearable camera able to collect vi-

sual information from their point of view. By means

of its direct access to the egocentric camera, HERO

can exploit both language and vision to interact with

the user. HERO is composed of four main modules:

1) the input module which takes both text/audio and

visual signals, 2) the NLP module which analyzes the

text/audio signal to understand the user’s questions, 3)

the object detection module which processes the in-

put images acquired from the user’s point of view and

recognizes all the objects present in the surrounding

environment and 4) the output module which com-

bines the obtained information to generate the most

reasonable answer to the human’s question. The pro-

posed system has been tested in a real industrial lab-

oratory (Leonardi et al., 2021) where workers per-

formed different maintenance operations with 2 elec-

trical boards and 21 industrial tools. To implement

HERO in this domain, we considered 26 different

worker’s intents such as “Which objects are there?”

or “Turn off the oscilloscope”, which HERO should

exploit to generate the correct answer and give the

needed support. Preliminary experiments show that

the proposed system achieves good performance in

the tasks of object detection and natural language un-

derstanding in the considered industrial domain. The

remainder of the paper is organized as follows. Sec-

tion 2 reports the related work. Section 3 presents the

collected datasets in the industrial laboratory. The ar-

chitecture of HERO and its services are discussed in

Section 4, while the experimental results are reported

in Section 5. Section 6 concludes the paper.

2 RELATED WORK

Natural Language Understanding (NLU). Several

works investigated how to perform text classiﬁcation

(Joachims, 1998; Fan et al., 2008; Zhang et al., 2015).

In particular, different word embedding approaches

have been proposed in literature for classiﬁcation pur-

poses. The authors of (Mikolov et al., 2013) sug-

gested Word2Vec, a vectorial representation of words

for learning high-quality text representations consid-

ering huge datasets. The authors of (Joulin et al.,

2017) proposed a simple and efﬁcient baseline called

fastText able to classify millions of sentences repre-

sented as bags of n-grams. GloVe (Global Vectors)

has been proposed in (Pennington et al., 2014) with

the aim to produce a vector space which is generic

with respect to the variations in phrasing.

Text classiﬁcation is a key task to build a Dia-

log Management Control system which is able to un-

derstand the human’s natural language (Young et al.,

2013). Most task-oriented systems are able to per-

form end-to-end learning to build natural conversa-

tions in speciﬁc domains (Wen et al., 2015; Bordes

et al., 2017). To overcome this limitation, the au-

thors of (Williams et al., 2017) proposed a end-to-end

learning RNN which reduced the amount of training

data required to adapt the dialog control system in

speciﬁc domains. Also the authors of (Williams and

Liden, 2017) proposed an interactive “teaching” sys-

tems which allows a developer to teach the network

by interacting with the system and providing on-the-

spot corrections. Recently, the authors of (Bunk et al.,

2020) proposed the Dual Intent and Entity Trans-

former (DIET), which is a multi-task architecture for

intent classiﬁcation and entity recognition. DIET has

the ability to generalize to different domains by in-

corporating pre-trained word embeddings from lan-

guage models and combining these with sparse word-

and character-level n-gram features. To allow HERO

to understand the human’s language and to answer

the human’s questions, we designed a NLU module

which contains a DIET module, considering a ﬁxed

set of possible requests which the user can ask.

HERO: An Artiﬁcial Conversational Assistant to Support Humans in Industrial Scenarios

Figure 2: Sample images of the industrial laboratory with

bounding box annotations for the objects present in the

scene.

NLU Software Libraries. There are differ-

ent software libraries publicly available to build high-

quality conversational agents. PyDeal (Ultes et al.,

2017) is an open source end-to-end statistical spo-

ken dialogue system toolkit which offers easy conﬁg-

urations and domain-independent implementations of

several dialogue system modules. To avoid the need

of specialist software developers, several frameworks

have been released with the aim to build conversa-

tional agents in a easy way such as OpenDial (Li-

son and Kennington, 2016), RavenClaw (Bohus and

Rudnicky, 2009), AT&T (Williams et al., 2010), In-

proTKs (Kennington et al., 2014) and IrisTK(Skantze

and Moubayed, 2012). In particular, RASA NLU and

RASA Core have been proposed in (Bocklisch et al.,

2017) and are open source Python libraries for build-

ing conversational software. The main difference with

respect to the other works is the architecture which

has been implemented as common APIs, which can

be easily integrated in other systems. We considered

the RASA framework to develop our NLP module.

Object Detection and Recognition. Given an

image, the aim of an object detector is to detect and

recognize all the objects present in the input image. In

the literature, there are two main groups of object de-

tectors: 1) Two-stages detectors and 2) One-stage de-

tectors. Two-stage methods predict a set of candidate

bounding boxes in the ﬁrst step, while, in a second

step, they extract visual features from each box and

use them to classify boxes into one of the considered

object classes and regress accurate bounding box co-

ordinates. These detectors (Girshick et al., 2014; Gir-

shick, 2015; Ren et al., 2015) favor the accuracy of

the predictions at the expenses of computation speed.

Differently, one-stage methods perform object local-

ization and classiﬁcation in a single step, allowing for

a faster computation, but often with a reduced accu-

racy (Liu et al., 2016; Redmon and Farhadi, 2018;

Bochkovskiy et al., 2020). Due to its more accurate

results, we choose the two-stage detector Faster R-

Figure 3: Samples of the structured data used to train the

NLU module. For each intent (blue) we designed different

examples including different entities (red, green and pur-

ple).

CNN (Ren et al., 2015) to build our Object Detection

module.

3 INDUSTRIAL LABORATORY

We considered the realistic industrial context pro-

posed in (Leonardi et al., 2021), where an industrial

laboratory has been set up. The authors acquired 8

real egocentric videos using a Microsoft Hololens 2

device in which subjects interact with 23 objects fol-

lowing different sequences of operations related to

test and repair procedures on two electrical boards

(e.g., turning on the power supply or pushing the red

button on the electrical panel). Figure 2 shows sam-

ple images of the industrial laboratory where HERO

is able to support workers performing several opera-

tions.

3.1 Dataset for the NLP Module

We built a dataset to train our NLP module consid-

ering the industrial laboratory. We structured infor-

mation about the user messages following the intent-

entity concepts. The intent is what the user plans

to do or accomplish (e.g., greeting, turn on objects,

etc.), while the entities are the key pieces of infor-

mation that can be extracted from the message (e.g.,

phone number, location, objects, etc.). Considering

the videos and the operations performed by the users,

we deﬁned 26 different intents and 4 entities. The 4

entities are the following:

• object: is related to the object’s class of the indus-

trial laboratory;

• electronic board: it can be high or low voltage

electronic board;

• component: several objects are composed of dif-

ferent components (e.g., the high voltage elec-

SIGMAP 2022 - 19th International Conference on Signal Processing and Multimedia Applications

Figure 4: Some images with bounding box annotations for

the objects present in the scene.

tronic board has a display);

• procedure: indicates a procedure that the subject

can perform. There are two kinds of procedures:

testing and repair.

For each intent, we deﬁned several examples which

represent different questions that the user can make

referring to the same intent. For example, the sen-

tences How can I use the oscilloscope? and I can’t use

the power supply are different examples belonging

to the same intent (i.e., object’s instructions). Since

HERO is able to see what the user is looking at, the

user does not need to ask questions explicitly includ-

ing the name of the objects, for example when he does

not know its name (e.g., How can I use this object?).

At the end, we obtained 136 examples related to the

26 intents. Figure 3 reports some intents with the re-

lated examples.

3.2 Dataset for the Object Detection

Module

We used the dataset proposed in (Leonardi et al.,

2021), which includes 8 videos acquired using a Mi-

crosoft Hololens 2 wearable device at a resolution of

2272 × 1278 pixels and with a framerate of 30 f ps.

For each of these videos, the authors selected the ﬁrst

frame where the hand touches an object and the frame

after the hand releases it. For each extracted frame,

the objects visible in the image have been annotated

with (x, y, w, h, c) tuples, where c indicates the object

class among the 19 object categories and (x, y, w, h)

are the bounding box coordinates. Following this pro-

cedure, we extended the set of annotations from 19

to 23 object classes, manually annotating all the ob-

ject instances belonging to the following 4 object cat-

egories: power supply cables, ground clip, battery

charger connector and panel A. With this procedure,

we obtained 20000 labeled objects belonging to 23

objects categories. Figure 4 shows some examples of

the annotated frames.

Figure 5: The architecture of the HERO system.

4 PROPOSED SYSTEM

Figure 5 illustrates the architecture of the HERO sys-

tem. It is composed of four main components: 1) in-

put module, 2) NLP module, 3) object detection mod-

ule and 4) output module. We describe the modules

of HERO in the following sections.

4.1 Input Module

The input module is responsible for taking different

inputs from the user and sending them to the corre-

sponding modules. In particular, this module takes

in input the text which will be processed by the NLP

module and the images acquired by a camera from

the ﬁrst point of view which will be sent to the object

detection module.

4.2 NLP Module

This module is based on the RASA framework (Bock-

lisch et al., 2017) and it is responsible for managing

conversations between humans and the AI assistant.

In the considered scenario, the user follows a pro-

cedure (i.e., testing or repairing) composed of sev-

eral sequential operations. At any point of the pro-

cedure the AI assistant must be able to change con-

text and answer other questions related to the dif-

ferent intents (e.g., object’s instructions). In RASA,

a general conversation can be represented by stories

or rules, a type of data, which are used to train the

assistant’s dialogue management module. Since in

real cases, such as in the considered industrial con-

text, a complex conversation between a worker and

the AI agent can be composed of different question-

answer couples, it would be too expensive to add a

story for each different question-answer instance. For

HERO: An Artiﬁcial Conversational Assistant to Support Humans in Industrial Scenarios

Figure 6: A sample conversation with our HERO system

through a Telegram bot.

this reason, we represented the data as rules which

describe short pieces of conversations that should al-

ways follow the same path. The output of the NLP

module is made of the predicted intent and the en-

tities. The entities can sometimes be absent (e.g.,

if the user does not know the name of an object,

the NLP module will not able to extract this infor-

mation from the text). The intent represents the

main intention of the user when they ask a ques-

tion. The intent information will be combined with

the extracted entities in order to choose the correct

response. In this industrial scenario, 4 of the 26 con-

sidered intents (i.e., present objects, can use objects,

powered objects, where PPE) do not need any en-

tities nor any context in order to generate the an-

swer. These 4 intents have been grouped into a

macro-intent called FAQ. Using this scheme, the DI-

ETClassiﬁer (Bunk et al., 2020) predicts whether

each intent is a regular intent or a FAQ. In the lat-

ter case, the ResponseSelector further classiﬁes the

FAQ macro-intent into one of the four related intents

(present objects, can use objects, powered objects,

where PPE).

4.2.1 NLU Pipeline

Our NLU Pipeline is composed of several compo-

nents which are described in the following:

• SpacyNLP: This component is needed in order to

initialize Spacy structures

;

• SpacyTokenizer: This component segments each

message into words, punctuation and so on using

speciﬁc rules related to the used language model,

thus obtaining tokens;

• CountVectorsFeaturizer (CVF): This component

creates bag-of-words representation of user mes-

sages, intents, and responses. Two instances of

CVF are used. The former analyzes messages at

word-level, whereas the latter analyzes messages

at character-level. We consider n-grams of lengths

ranging from 1 to 4.

• SpacyFeaturizer: This component creates a vector

representation of user messages and responses.

• DIETClassiﬁer (Dual Intent Entity Transformer)

(Bunk et al., 2020): This component is a multi-

task architecture for intent classiﬁcation and en-

tity recognition. The architecture is based on a

transformer which is shared for both tasks;

• EntitySynonymMapper: This component is re-

sponsible of the synonymous entities. If the train-

ing data contains deﬁned synonyms, this compo-

nent will make sure that detected entity values will

be mapped to the same value;

• ResponseSelector: This component chooses the

response from a set of possible responses for those

intents that were grouped in a macro-intent;

4.3 Object Detection Module

Our Object Detection module relies on the two-stage

object detector Faster-RCNN (Ren et al., 2015) to ad-

dress object detection and recognition. Given an im-

age from the Input module, the object detector pre-

dicts a (x, y, w, h, c) tuple for each detected object,

where c indicates the class belonging to the 23 object

categories and (x, y, w, h) are the bounding box coor-

dinates. Since humans usually focus their attention on

the center of the image when they are interacting with

an object, we ﬁlter the predictions choosing only the

object closest to the center of the image. The class of

the predicted object represents an entity and it will be

used by the output module.

4.4 Output Module

This module chooses the ﬁnal answer to send to the

user considering the intent and the entities predicted

by the NLP module and the entity detected by the ob-

ject detection module.

The RASA framework is based on the Spacy library:

https://spacy.io/

SIGMAP 2022 - 19th International Conference on Signal Processing and Multimedia Applications

Table 1: Results obtained by the NLP module consider-

ing the intent and entity classiﬁcation of the DIETClassiﬁer

(ﬁrst and second row) and the response selection performed

by the ResponseSelector (last row).

Precision Accuracy F

-score

Entity classiﬁcation 0.944 0.959 0.866

Intent classiﬁcation 0.729 0.735 0.700

Response Selection 0.800 0.867 0.822

5 PRELIMINARY EXPERIMENTS

AND RESULTS

To evaluate HERO, we assess the performance the

NLP and object detection modules. In particular, we

consider two tasks: 1) intent-entity recognition and 2)

object detection and recognition. For a preliminary

evaluation we designed channel connectors where the

user can send and receive messages. In particular, we

integrated a channel connector through the use of a

Telegram bot where the input signals are the text writ-

ten in a chat by the user and the images is acquired by

the camera phone (see Figure 6).

5.1 NLP Module

We split the dataset into training and test sets with

an 80 : 20 ratio. Considering the small dimension of

the dataset, we ﬁnd the optimal model’s parameters

performing a 5-fold cross-valuation on the training

set. We trained the ﬁnal model on the whole training

set considering the mean of the parameters of each

split. The model has been trained on an Intel Core

i5 CPU for 100 epochs with learning rate of 0.001

and a variable batch size which linearly increases for

each epoch from 64 to 256. We evaluate our model

on the test set using precision, accuracy and F

-score

measures. Table 1 reports the results obtained on the

entity classiﬁcation (ﬁrst row) and intent classiﬁca-

tion (second row) using the DIETClassiﬁer module,

as well as the response selection performed by the

ResponseSelector module (last row). The DIETClas-

siﬁer recognizes very well the entities considering all

the evaluation measures with a precision of 0.944, an

accuracy of 0.959 and an F

-score of 0.866. The per-

formances of the intent classiﬁcation are lower, with

a precision of 0.729, an accuracy of 0.735 and a F

score of 0.700. The ResponseSelector module ob-

tains good performance considering the classiﬁcation

of the 4 micro-intents contained in the FAQ group,

achieving a precision of 0.800, an accuracy of 0.867

and an F

-score of 0.822.

Figure 7: Qualitative results of the object detector.

Table 2: Splits of the dataset reporting the number of

videos, images and objects for each split.

Train Validation Test

Videos 4 2 2

Images 1,367 832 857

Objects instances 7,981 6,009 6,010

5.2 Object Detection Module

We split the object detection dataset into training, val-

idation and test sets being careful to include all the

frames extracted from a video in a single split. Ta-

ble 2 reports statistics about these splits considering

the number of videos, images and objects included in

each split.

As object detector we used Faster R-CNN (Ren

et al., 2015) with a ResNet-101 backbone (He et al.,

2016). We used the implementation provided in the

Detectron2 (Wu et al., 2019) framework. The exper-

iments were conducted on a Nvidia V100 GPU. We

trained the model for 30,000 iterations with a batch

size of 2, a learning rate of 0.001 and 1000 warmup

iterations. We decreased the learning rate by a factor

of 10 after 15,000 and 20,000 iterations. We evaluated

the model using the COCO mean Average Precision

metric (mAP)

with an Intersection over Union (IoU)

of 0.5 (mAP@50). The mAP measures the ability of

the model to both localize and classify the objects in

the image. We tested the model on the Test set ob-

taining a mAP of 73.41%, which indicates that the

module is able to correctly localize and recognize the

objects present in the images. Table 3 reports the indi-

vidual APs for each object class. The results suggest

that the network recognizes well large objects such

as the oscilloscope (90.12%) or the welder station

(89.87%), whereas it has some difﬁculty in recogniz-

ing small objects such as the battery charger connec-

tor, obtaining an AP of 15.91%. Figure 7 shows some

qualitative results of our object detector.

https://github.com/cocodataset/cocoapi

HERO: An Artiﬁcial Conversational Assistant to Support Humans in Industrial Scenarios

Table 3: Average Precision AP per class.

Category AP Category AP

power supply 80.18 working area 90.18

oscilloscope 90.12 welder base 88.82

welder station 89.87 socket 90.27

electric screwdriver 81.45 left red button 100

screwdriver 58.73 left green button 100

pliers 79.18 right red button 81.82

welder probe tip 50.63 right green button 90.91

oscilloscope probe tip 51.72 power supply cables 41.34

low voltage board 88.53 ground clip 44.84

high voltage board 61.44 battery charger connector 15.91

electric screwdriver battery 51.72

6 CONCLUSION

We presented HERO, a Conversational Intelligent As-

sistant able to support workers using the natural lan-

guage and observing the surrounding environment to

avoid natural language ambiguity. Experiments high-

light the good performance on the considered indus-

trial laboratory used to evaluate HERO’s ability of

intent-entity prediction considering both text and vi-

sual inputs. Future works will consider the integration

of wearable devices such as Microsoft Hololens2 and

a speech-to-text module to leave the human hands-

free during their work.

ACKNOWLEDGEMENTS

This research is supported by Next Vision

s.r.l. and

by the project MEGABIT - PIAno di inCEntivi per la

RIcerca di Ateneo 2020/2022 (PIACERI) – linea di

intervento 2, DMI - University of Catania.

REFERENCES

Amazon (2014). Amazon’s alexa. https://developer.

amazon.com/alexa.

Amazon (2019). Amazon’s show and tell. https://www.

amazon.com/b?ie=UTF8&node=21213731011.

Apple (2012). Apple’s siri. https://www.apple.com/siri/.

Bochkovskiy, A., Wang, C., and Liao, H. M. (2020).

Yolov4: Optimal speed and accuracy of object detec-

tion. CoRR, abs/2004.10934.

Bocklisch, T., Faulkner, J., Pawlowski, N., and Nichol, A.

(2017). Rasa: Open source language understanding

and dialogue management. CoRR, abs/1712.05181.

Bohus, D. and Rudnicky, A. I. (2009). The ravenclaw di-

alog management framework: Architecture and sys-

tems. Comput. Speech Lang., 23.

Next Vision: https://www.nextvisionlab.it/

Bordes, A., Boureau, Y.-L., and Weston, J. (2017). Learning

end-to-end goal-oriented dialog. In 5th International

Conference on Learning Representations (ICLR).

Brick, E., Alonso, V., O’Brien, C., Tong, S., Tavernier, E.,

Parekh, A., Addlesee, J.-A., and Lemon, O. (2021).

Am i allergic to this? assisting sight impaired people

in the kitchen. ICMI ’21: Proceedings of the 2021

International Conference on Multimodal Interaction.

Bunk, T., Varshneya, D., Vlasov, V., and Nichol, A. (2020).

DIET: lightweight language understanding for dia-

logue systems. CoRR, abs/2004.09936.

Fan, R.-E., Chang, K.-W., Hsieh, C.-J., Wang, X.-R., and

Lin, C.-J. (2008). Liblinear: A library for large linear

classiﬁcation. J. Mach. Learn. Res., 9.

Fedorenko, D. G., Smetanin, N., and Rodichev, A. (2017).

Avoiding echo-responses in a retrieval-based conver-

sation system. ArXiv, abs/1712.05626.

Gao, J., Galley, M., and Li, L. (2018). Neural approaches

to conversational AI. In Proceedings of the 56th An-

nual Meeting of the Association for Computational

Linguistics: Tutorial Abstracts.

Girshick, R. (2015). Fast r-cnn. In Proceedings of the IEEE

international conference on computer vision.

Girshick, R., Donahue, J., Darrell, T., and Malik, J. (2014).

Rich feature hierarchies for accurate object detec-

tion and semantic segmentation. In Proceedings of

the IEEE conference on computer vision and pattern

recognition.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In Conference on

Computer Vision and Pattern Recognition.

Joachims, T. (1998). Text categorization with support vec-

tor machines: learning with many relevant features. In

edellec, C. and Rouveirol, C., editors, Proceedings

of ECML-98, 10th European Conference on Machine

Learning, number 1398.

Joulin, A., Grave, E., Bojanowski, P., and Mikolov, T.

(2017). Bag of tricks for efﬁcient text classiﬁcation.

In EACL.

Kennington, C. R., Kousidis, S., and Schlangen, D. (2014).

Inprotks: A toolkit for incremental situated process-

ing. In SIGDIAL Conference.

Leonardi, R., Ragusa, F., Furnari, A., and Farinella, G. M.

(2021). Egocentric human-object interaction detection

exploiting synthetic data. In International Conference

on Image Analysis and Processing.

Lison, P. and Kennington, C. (2016). OpenDial: A toolkit

for developing spoken dialogue systems with prob-

abilistic rules. In Proceedings of ACL-2016 System

Demonstrations.

Liu, W., Anguelov, D., Erhan, D., Szegedy, C., Reed, S.,

Fu, C.-Y., and Berg, A. C. (2016). Ssd: Single shot

multibox detector. In Computer Vision – ECCV 2016.

Microsoft (2014). Microsoft’s cortana.

https://support.microsoft.com/en-us/topic/what-

is-cortana-953e648d-5668-e017-1341-7f26f7d0f825.

Mikolov, T., Chen, K., Corrado, G. S., and Dean, J. (2013).

Efﬁcient estimation of word representations in vector

space.

SIGMAP 2022 - 19th International Conference on Signal Processing and Multimedia Applications

Mleczko, K. (2021). Chatbot as a tool for knowledge shar-

ing in the maintenance and repair processes. Multidis-

ciplinary Aspects of Production Engineering, 4.

Pennington, J., Socher, R., and Manning, C. D. (2014).

Glove: Global vectors for word representation. In

EMNLP.

Redmon, J. and Farhadi, A. (2018). Yolov3: An incremental

improvement. CoRR, abs/1804.02767.

Ren, S., He, K., Girshick, R., and Sun, J. (2015). Faster R-

CNN: Towards real-time object detection with region

proposal networks. In Advances in neural information

processing systems.

Skantze, G. and Moubayed, S. A. (2012). Iristk: a

statechart-based toolkit for multi-party face-to-face

interaction. In ICMI ’12.

Ultes, S., Rojas-Barahona, L. M., Su, P.-H., Vandyke, D.,

Kim, D., Casanueva, I., Budzianowski, P., Mrk

c, N.,

Wen, T.-H., Ga

c, M., and Young, S. (2017). PyDial:

A multi-domain statistical dialogue system toolkit. In

Proceedings of ACL 2017, System Demonstrations.

Wen, T.-H., Ga

c, M., Mrk

c, N., Su, P.-H., Vandyke,

D., and Young, S. (2015). Semantically conditioned

LSTM-based natural language generation for spoken

dialogue systems. In Proceedings of the 2015 Con-

ference on Empirical Methods in Natural Language

Processing.

Williams, J., Asadi, K., and Zweig, G. (2017). Hybrid

code networks: practical and efﬁcient end-to-end dia-

log control with supervised and reinforcement learn-

ing. In ACL.

Williams, J. D., Arizmendi, I., and Conkie, A. (2010).

Demonstration of at amp;t “let’s go”: A production-

grade statistical spoken dialog system. In 2010 IEEE

Spoken Language Technology Workshop.

Williams, J. D. and Liden, L. (2017). Demonstration of in-

teractive teaching for end-to-end dialog control with

hybrid code networks. In Proceedings of the 18th An-

nual SIGdial Meeting on Discourse and Dialogue.

Wu, Y., Kirillov, A., Massa, F., Lo, W.-Y., and Gir-

shick, R. (2019). Detectron2. https://github.com/

facebookresearch/detectron2.

Young, S., Ga

c, M., Thomson, B., and Williams, J. D.

(2013). Pomdp-based statistical spoken dialog sys-

tems: A review. Proceedings of the IEEE, 101(5).

Zhang, X., Zhao, J., and LeCun, Y. (2015). Character-

level convolutional networks for text classiﬁcation. In

Proceedings of the 28th International Conference on

Neural Information Processing Systems - Volume 1,

NIPS’15.

HERO: An Artiﬁcial Conversational Assistant to Support Humans in Industrial Scenarios
