INFORMATION SYSTEM CUSTOMIZATION

Toward Participatory Design and Development of the Interaction Process

Daniela Fogli

Dipartimento di Elettronica per l’Automazione, Università di Brescia, Via Branze 38, Brescia, Italy

Loredana Parasiliti Provenza

Dipartimento di Informatica e Comunicazione, Università di Milano, Via Comelico 38-40, Milano, Italy

Keywords: Customization, Communication gap, Multi-facet specification, Participatory design, Participatory

development.

Abstract: This paper proposes the adoption of human-computer interaction methods to address some of the problems

related to the customization of information systems, and particularly of enterprise resource planning

systems. The paper specifically describes a multi-facet approach to participatory design and development of

information systems to build the dialogue between the information system and its users. It encompasses i) a

specification framework for representing and translating the different perspectives of the members of the

design team, including the end users’ perspective, ii) a methodology for collaborative design of the

interaction process, and iii) a set of guidelines to carry out the development activities.

1 INTRODUCTION

Large scale-software design and implementation

projects, such as those involving information

systems (IS) and, particularly, enterprise resource

planning (ERP) systems, represent a challenge for

many companies all over the world.

These systems are aimed at managing and

integrating business processes within a complex

organization, by adopting existing industry best

practices. However, experience studies document

several project failures, in which cultural misfits

between developers, vendors and consultants, on the

one side, and company managers and employees, on

the other side, are some of the main reasons for

failure (Molla and Loukis, 2005; Soh et al. 2000).

ERP systems are software packages, whose high

complexity is due to their cross-module integration,

data standardization, adoption of underlying

business models and the involvement of several

stakeholders. ERP systems are generally composed

by a core part and a set of modules that can be

customized according to the company’s

characteristics, needs and target market. However,

this customization is often a critical problem because

the philosophy adopted is usually ‘shaping’ the

company and its business processes according to the

predefined ERP model, rather than vice versa.

Consequently, users are forced by the new system to

work and reason in some way different from what

they would naturally do, possibly far from their

usual ways of working and reasoning.

ERP system customization may include either

code modification or ERP parameter configuration,

with the aim of adapting for instance workflows,

reports, queries, data formats. An important aspect

of ERP customization that, in our opinion, is not yet

faced adequately by vendors and consultants is

concerned with designing and developing a proper

dialogue between the ERP system and its users. A

suitable dialogue is however fundamental to make

the interaction effective and efficient. Whenever the

dialogue is not well designed, problems arise: for

example, it often happens that users are not aware of

the presence of some useful functionalities, because

they are not able to find them or even to recognize

them among the available options. These problems

are often due to a presentation and interaction

language alien to users’ experience, which makes

the system not understandable and the interaction

process complicated.

Such a situation leads frequently to failures

manifested by implementation delays, cost

Fogli D. and Parasiliti Provenza L. (2009).

INFORMATION SYSTEM CUSTOMIZATION - Toward Participatory Design and Development of the Interaction Process.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Human-Computer Interaction, pages 72-77

DOI: 10.5220/0001992400720077

 SciTePress

increasing, lack of system use. Such failures are

normally ascribed to users, whose resistance to, or

even rejection of, the software being introduced are

rarely well understood by developers and

consultants (Wagner and Piccoli, 2007).

In this paper, we advocate the adoption of

human-computer interaction (HCI) methods to carry

out the customization of the dialogue between users

and an ERP system. Among HCI approaches and

practices, participatory design appears as the most

promising for reducing the failures described.

Participatory design is a design paradigm that

invokes direct participation of users as active

members of the design team (Schuler and Namioka,

1993) in order to produce interactive systems that

are usable and meet users' needs.

We have been directly involved in participatory

design experiences of interactive systems that

support collaborative work in specific domains – e.g.

medical diagnosis and mechanical engineering

(Costabile et al., 2007). On the basis of those

experiences, we propose here a participatory

approach to designing and developing information

systems. Particularly, the approach can be adopted in

the context of ERP customization to develop, in a

participatory way, the dialogue between users and

the system, by taking into account users’ culture,

language and system of signs. To this end, we

suggest the creation of participatory design teams

constituted by at least three categories of

stakeholders, as owners of different expertises: 1)

software professionals, including developers,

vendors and consultants; 2) domain experts,

including representative users, i.e. employees and

company managers; and, last but not least, 3) HCI

experts, namely professionals in human-computer

interaction who should play the role of mediators

between software professionals and domain experts,

in order to satisfy usability requirements.

However, in such a multidisciplinary team,

communication gaps may arise (Folmer et al., 2005),

due to the different skills, cultures and languages of

team members, and this may seriously compromise

the collaboration. Another problem emerges when

the participatory approach remains at the high level

of system design, without explicitly addressing the

problem of system development (Wagner and

Piccoli, 2007).

To overcome these problems, our participatory

approach is characterized as follows: 1) it is multi-

facet, in that it recognizes the existence of the

different stakeholders’ perspectives and permits their

expression according to the stakeholders’ culture

and language; 2) it supports an effective

communication among stakeholders, by permitting

the translation of each stakeholder’s perspective into

a language comprehensible to the others and by

sustaining the iterative design of the interaction

process; 3) it advocates a true engagement of users

in carrying out the IS customization, by giving them

the possibility to participate in creating the

interaction experience they would like to live with

the system.

The paper is organized as follows: Section 2

presents the motivation underlying this work and

discusses related literature; Section 3 describes the

proposed participatory approach; Section 4

concludes the paper by delineating a promising

research line.

2 MOTIVATION AND RELATED

WORK

Daneva (2003) describes various degrees of success

and failure in ERP requirements engineering. With

reference to a well-known commercial product, she

analyses the main causes of success and failure.

Some of the reasons for failures are interesting to be

mentioned here, such as insufficient validation

efforts, clashes between process stakeholders, ad-

hoc ways of working, underestimation of the

importance of certain practices. As one can notice,

they are in some way due to inadequate

comprehension of user requirements and, generally,

to insufficient user involvement.

Soh et al. (2000) wonder, from an Asian

perspective, if an ERP can be considered a universal

solution. Through a study performed in seven public

hospitals in Singapore they arrive at identifying

different types of misfits – data misfits, functional

misfits, output misfits –, namely gaps between what

is offered by the ERP package and organizational

requirements. Then, the authors observe that most

solutions to these problems “require the users to

work around with the alternatives offered by the

package” (Soh et al., 2000, p. 50). Other solutions

consist in working without validation checks, thus

compromising control, or in going back and forth

through different screens to look for necessary

information, thus compromising productivity. Soh

and colleagues argue that the strategy to be followed

to cope with these misfits is asking users for

assimilating the package functionality in some

depth. They say that users “must now consciously

‘get into the ERP software’ to evaluate the

appropriateness of the new configured system or the

alternatives adopted” (Soh et al., 2000, p. 51). This

conclusion assumes that users should become expert

INFORMATION SYSTEM CUSTOMIZATION - Toward Participatory Design and Development of the Interaction

Process

also in information technologies and in the specific

package characteristics, besides being expert in their

own application domain. Actually, this is a usual

attitude of software developers and vendors, who

consider users as some people to be ‘educated’. A

similar ‘recipe’ is suggested in (Simosko, 2008),

who presents tips “on how to prepare and enable

your users”, by considering user education as a key

business process. While, in principle, we can agree

on most of these tips, what we question here is the

undervaluation of users’ competencies, experience

and knowledge.

As Rittel (1984) highlights in his “symmetry of

ignorance” principle, each person has different

knowledge and experience, but none is more

important than the others. Therefore, all stakeholders

must recognize that each one complements the

ignorance of the others, and that it is necessary to

reach a mutual understanding by means of a peer

collaboration. Thus, Rittel suggests that the

knowledge owned by every stakeholder be shared

and integrated with other stakeholders’ knowledge.

This perspective is in line with the ideas

presented in (Molla and Loukis, 2005), where an

ERP system is not considered as a mere technical

product, but as a socio-technical system including

several stakeholders, each one holding a certain

cultural assumption towards implementing and using

the ERP system. The analysis they performed on real

cases suggests that the congruency between the

system culture – the views of ERP developers,

vendors and consultants – and the host culture – the

views of the organization’s project team, managers

and employees – may contribute to the ERP success.

As advocated in HCI by participatory design

scholars, methods, techniques, and possibly software

tools should be defined and developed to bring

together different and controversial perspectives,

with the aim of avoiding misunderstandings and

communication barriers that may compromise the

collaboration among the different stakeholders. In

(Bodker and Iverson, 2002), the authors discuss how

to concretely involve users in participatory design by

means of scenarios and prototypes. Scenarios

represent an informal way of investigating current

practice and triggering ideas for future system

usages. Prototypes, besides permitting evaluation of

hypotheses, also encourage exploration of design

alternatives.

However, even if the adoption of participatory

design promises to offer solutions to users’

resistance (or even rejection) and system’s

requirements change, in practice this is far from an

automatic occurrence. In the study described in

(Wagner and Piccoli, 2007), it was observed that

“users tend not to fully engage until the system’s

impact on their working life is apparent – generally

when the system ‘goes live’” (p. 52). According to

the authors, to make participation more powerful,

users should be involved on topics really salient for

them. This suggests to consider participatory design

and participatory development as two interrelated

activities (Pekkola et al., 2006). Pekkola and

colleagues propose a multi-methodological approach

that bridges the gap between participatory design

and information systems development (ISD)

methodologies, where methods and techniques for

system design and system development are used in

an interleaved way. Even though this represents an

interesting proposal, a lot remains to be done for

developing “a formalized end-user-oriented ISD

method that is useful not only for the system

designers but also for every party involved in the

ISD process in each of its phases” (p. 28). The

present paper proposes an approach that goes in this

direction.

3 THE PROPOSED

PARTICIPATORY APPROACH

We present here the multi-facet participatory

approach to system design and development. The

approach derives from our direct experiences in

participatory design of domain-specific interactive

systems (Costabile et al., 2007; Costabile et al.,

2008). It aims at giving value to the stakeholders’

different perspectives and, at the same time, at

supporting their convergence toward a shared

understanding of the interaction with an information

system. Through proper procedures, guidelines and

techniques, the approach has the goal of fostering

true engagement of team members and supporting

communication among them during all system

lifecycle phases.

In the context of IS customization, the

participatory design activity has the purpose of

allowing different stakeholders to achieve a common

specification of user-system dialogue in terms of the

functionalities to be made available to users, the

interaction metaphor on which the system should be

based, and the interaction style it should support.

Whilst, the participatory development activity aims

at building such a dialogue in order to obtain an

information system that is understandable, usable,

reliable and accepted by its users. A key issue in

both system design and development is to permit

each stakeholder to describe the interaction process

between user and system from her/his point of view

and to support an efficient and effective

communication among the different stakeholders.

ICEIS 2009 - International Conference on Enterprise Information Systems

Therefore, the approach foresees (Figure 1):

• A specification framework, which provides

languages to support the expression of one’s own

view of the interaction experience with the

system and the communication among the team

members in all the stages of the design and

development processes;

• A design methodology, which establishes how

the different stakeholders in the multidisciplinary

team should work together and collaborate in

designing the interaction process between user

and system, by specifying it according to their

own perspectives;

• Development guidelines, i.e. a set of

recommended practices to be followed when

developing, in a participatory way, the designed

interaction process.

Specification

framework

Design

methodology

Development

guidelines

Specification

framework

Design

methodology

Development

guidelines

Figure 1: Our participatory approach.

For sake of simplicity, but without loosing

generality, in the following we restrict our reasoning

to the description of the collaboration among three

categories of stakeholders: software professionals,

domain experts, and HCI experts. It is worth

noticing that, especially in the case of ISs, one can

identify different stakeholders among software

professionals, as well as among domain experts. The

approach is scalable to situations where the various

stakeholders are identified more precisely. Another

important consideration about the team composition

is the presence of HCI experts, who play the role of

mediators between domain experts and software

professionals. In our participatory design

experiences, as HCI experts, we empirically adopted

a framework of languages and translation procedures

in order to bridge the communication gap between

domain experts and software engineers. We actually

operated translations from the domain experts’ view

to the software engineering experts’ view and vice

versa. The approach presented in the following aims

at formalizing and generalizing these experiences,

which can be effectively applied to the case of IS

customization.

3.1 Specification Framework

In our participatory design experiences (Costabile et

al., 2007; Costabile et al., 2008), we have observed

that each stakeholder looks at and describes the

interaction experience with a software system from

her/his own perspective and according to her/his

goals. Based on these observations, we have

formalized a specification framework constituted by

different interaction languages – one for each

different stakeholder – whose sentences provide an

explicit description of the interaction process

between the user and the system according to the

different perspectives (Fogli et al., 2007). By

restricting to the case of three kinds of stakeholders

– domain experts, HCI experts, and software

professionals –, we have introduced three interaction

languages to describe the different perspectives. The

first language, the interaction trace language (ITL)

describes the interaction experience from users’

point of view. It is expressed as finite sequences of

images on the screen coupled with the names of

operations users perform on them. The second

language, the direct manipulation language (DML),

describes the interaction experience from the HCI

point of view, by adding state-based descriptions to

the elements of the previous language. Finally, the

third language, the finite state machine-interaction

language (FSM-IL), describes the interaction

experience from the software professionals’ point of

view, by enriching the previous language with

computational-oriented information. ITL, DML and

FSM-IL share some core elements, which can be

used to define translation procedures for mapping

each language into the others. They are called

animated pictorial elements (APEs): the pictorial

parts of the system each stakeholder can see on the

screen and reasons about during interaction, together

with the names of operations that can be performed

on the system. Figure 2 gives an overview of the

specification framework.

APEs

DML

FSM-IL

ITL

End user’s

point of view

HCI expert’s

point of view

Sw professional’s

point of view

APEs

DML

FSM-IL

ITL

End user’s

point of view

HCI expert’s

point of view

Sw professional’s

point of view

Figure 2: The specification framework.

3.2 Design Methodology

The design methodology is a procedure that

establishes how the members of a multidisciplinary

team work together to design the interaction with the

information system, by providing different but

INFORMATION SYSTEM CUSTOMIZATION - Toward Participatory Design and Development of the Interaction

Process

related specifications. The methodology is multi-

facet since it aims at building, through the

framework, three different descriptions of the

interaction process. The procedure consists of the

following steps to be performed several times in an

order dictated by the results of each step:

1. Domain and HCI experts work together by

discussing scenarios that describe current work

practices and possible future system usages with the

purpose of providing a description of the interaction

process from users’ point of view. Specifically, they

firstly identify the alphabet of APEs, on which the

interaction process will be based, according to users

notation and system of signs. Then, they collaborate

each other in defining the ITL.

2. HCI experts analyse the ITL obtained in the

previous step from the usability point of view, by

taking into account intention formulation, action

planning and user perception and interpretation of

system feedback; then, they translate the user’s view

– ITL – into a state-based specification of the system

– DML – to be submitted to software professionals.

3. Software professionals analyse such state-

based specification and produce a computational-

oriented specification of the system – FSM-IL. In

this phase, software professionals could notice

problems in the state-based specification that may

ask for a revision; this requires a new collaboration

phase with HCI experts, and thus to go back to step

2. Whenever this revision affects the user’s

description of the interaction process, HCI experts

need to collaborate again with domain experts to

decide the necessary modifications, thus going back

to step 1.

4. The computational-oriented specification is

then used to generate a prototype, which is given to

domain experts in order to be tested.

5. Domain experts can thus analyse the prototype

physical appearance and behaviour, possibly

noticing interaction problems due to

misunderstandings, incompleteness, lacking in

consistency, etc.

6. To solve the above problems, domain experts

should ask for collaborating with HCI experts to

revise together the ITL. This situation will also occur

at use time whenever users, as well as their work

environments, organization procedures and adopted

technologies, evolve. In both cases, it is necessary to

go back to step 1.

Note that, as suggested by step 6, the design

process is active throughout the IS lifecycle.

3.3 Development Guidelines

During participatory design activities, it may happen

that the specific users’ needs are not clearly

understood and that attention is not paid to users’

ideas. Very often, users are not even able to express

their point of view because design problems are

presented them by using terms alien to their

experience and culture. Consequently, users are not

able to understand soon the impact of the new

system in their life and work, and tend to perceive

participatory design just as an overhead to their

work activities (Wagner and Piccoli, 2007).

To support an effective user engagement during

IS customization, our participatory approach

includes also the following development guidelines:

• each member of the team should be able to

analyse the interaction experience according to

her/his own reasoning strategies using her/his own

notations and system of signs;

• each team member should be able to develop

the interaction experience from her/his own

perspective;

• all team members should be able to

communicate about and collaborate in designing and

developing the interaction experience with the

system.

These guidelines suggest that each member of

the team should be provided with a development

environment permitting the description of one’s own

perspective on the interaction with the system under

customization. Such environment should facilitate

its users in defining the corresponding interaction

language formalized in the framework. The different

perspectives should be exchanged among the

stakeholders and properly interpreted by the

development environment used by each stakeholder.

In the past, we have proposed the software

shaping workshop (SSW) methodology to support

participatory design and development of domain-

specific interactive systems. Particularly, the

methodology has been applied in the mechanical

engineering and medical diagnosis domains

(Costabile et al., 2007). SSWs are software

environments conceived according to the

development guidelines delineated in this paper:

they are customized to stakeholder’s culture and

knowledge, they provide all and only the tools to be

used to perform the stakeholder’s activities, and are

organized in a network to support communication

among stakeholders. We argue that similar tools

might be developed to make concrete our

participatory approach to IS customization.

ICEIS 2009 - International Conference on Enterprise Information Systems

4 CONCLUSIONS

This paper asks for a greater awareness by IS

developers and consultants of the Rittel’s symmetry

of ignorance principle. They should regard users as

the ‘owners’ of the problem, thus recognizing that

users’ domain knowledge complements their

ignorance (and not only vice versa, as software

professionals are used to think).

The multi-facet approach here proposed

recognizes this symmetry by allowing a

multidisciplinary team to take into account all the

different perspectives in designing and developing

the dialogue between an information system and its

users. More specifically, the approach provides a

methodology for participatory design and a set of

development guidelines, which recognize and give

value to the different expertises of the team

members while fostering their collaboration. The

approach also provides a specification framework

that supports team members in both design and

development by allowing them to represent and

translate their different perspectives.

The languages in the framework are formal tools

that may facilitate system prototyping, since they

can be used for creating proper software

environments that support system specification and

prototype generation from the specification. The

generated prototypes can then be directly tested by

the users, who can thus ask immediately for system

refinement.

As a future work, we plan to apply the approach

to a real ERP context, in order to evaluate its

effectiveness in the case of information system

customization. In general, our objective is to

persuade IS vendors and developers of the

importance of providing their clients and consultants

with software environments for participatory design

and development of the dialogue between an

information system and its users.

ACKNOWLEDGEMENTS

The authors wish to thank Piero Mussio for his

contribution to the approach presented in this paper.

This work capitalizes on participatory design

experiences carried out in collaboration also with

Maria Francesca Costabile and Antonio Piccinno,

who are herewith acknowledged. The authors are

also grateful to Sonia Di Labio for the interesting

discussions about the content of the paper.

REFERENCES

Bødker, S., Iversen, O. S., Staging a Professional

Participatory Design Practice – Moving PD beyond

the Initial Fascination of User Involvement, Proc.

NordCHI 2002, October 2002, Arhus, Denmark, 11-

18.

Costabile, M. F., Fogli, D, Lanzilotti, R., Mussio, P.,

Parasiliti Provenza, L., Piccinno, A. Advancing End

User Development Through Meta-Design, in S. Clarke

(Ed.), End User Computing Challenges and

Technologies: Emerging Tools and Applications,

Hershey, PA, IGI Global, 2008, 143-167.

Costabile, M. F., Fogli, D., Mussio, P., Piccinno, A.,

Visual Interactive Systems for End-User

Development: a Model-based Design Methodology,

IEEE Trans. on Systems Man and Cybernetics 37(6),

2007, 1029–1046.

Daneva, M., Six Degrees of Success or Failure in ERP

Requirements Engineering: Experiences with the

ASAP Process. Int. Workshop on COTS and Product

Software: Why Requirements are so Important (11th

IEEE Int. Conf. Requirements), Monterey Bay, 2003.

Fogli, D., Marcante, A., Mussio, P., Parasiliti Provenza,

L., Piccinno, A., Multi-facet Design of Interactive

Systems through Visual Languages. In F. Ferri (Ed.),

Visual Languages for Interactive Computing:

Definitions and Formalizations, Hershey, PA, IGI

Global, 2007, 174-204.

Folmer, E., van Welie, M., Bosch, J. Bridging patterns: An

approach to bridge gaps between SE and HCI, Journal

of Information and Software Technology, 48(2), 2005,

69–89.

Molla, A., Loukis, I., Success and Failure of ERP

Technology Transfer: A Framework for Analysing

Congruence of Host and System Cultures, Working

Paper Series, University of Manchester, 2005.

Pekkola, S., Kaarilahti, N., Pohjola, P., Towards

Formalised End-User Participation in Information

Systems Development Process: Bridging the Gap

between Participatory Design and ISD Methodologies,

Proc. PDC 2006, 2006, Trento, Italy, 21-30.

Rittel, H., Second-Generation Design Methods. In Cross,

N. (Ed.), Developments in Design Methodology, John

Wiley and Sons, New York, NY, 1984, pp. 317-327.

Schuler, D., Namioka, A. (eds.), Participatory Design -

Principles and Practices, Hillsday, N.J: Lawrence

Erlbaum Associates, 1993.

Simosko, N., The IT Transformation Process – 5 Tips on

How to Prepare and Enable Your Users, SAP Insider,

Apr-May-Jun 2008, www.SAPInsederonline.com.

Soh, C., Kien, S. S., Tay-Yap, J., Cultural Fits and Misfits:

Is ERP A Universal Solution?, CACM 43(4), 2000, 47-

51.

Wagner, E. L., Piccoli, G., Moving Beyond User

Participation to Achieve Successful IS Design, CACM

50(12), 2007, 51-55.

INFORMATION SYSTEM CUSTOMIZATION - Toward Participatory Design and Development of the Interaction

Process
