PARALLELIZED STRUCTURAL AND VALUE XML FILTERING

ON MULTICORE PROCESSORS

Panagiotis Antonellis, Christos Makris and Georgios Pispirigos

Department of Computer Engineering and Informatics, University of Patras, Rio, Patras, Greece

Keywords: XML, Filtering, Parallel, Multi-core

Abstract: Information filtering systems constitute a critical component in modern information seeking applications.

As the number of users grows and the information available becomes even bigger it is imperative to employ

scalable and efficient representation and filtering techniques. Typically the use of XML representation

entails the profile representation with the use of the XPath query language and the employment of efficient

heuristic techniques for constraining the complexity of the filtering mechanism. However, most of the

existing research work focuses on single-core systems, even though the multi-core processors are already

widely used. In this paper we propose a parallel filtering algorithm based on the well known YFilter, which

dynamically applies a work-load balancing approach to each thread to achieve the best parallelization. In

addition, the proposed filtering algorithm extends YFilter to also support value-based predicates in the user

profiles, thus enabling both structural and content-based XML filtering. Experimental results depict that the

proposed system outperforms the previous parallel approaches to XML filtering problem.

1 INTRODUCTION

Information filtering systems (also known as

publish/subscribe systems) (Aguilera et al., 1999)

are systems that provide two main services:

document selection (i.e., determining which

documents match which users) and document

delivery (i.e., routing matching documents from data

sources to users). In order to implement efficiently

these services, information filtering systems rely

upon representations of user profiles, that are

generated either explicitly by asking the users to

state their interests, or implicitly by mechanisms that

track the user behaviour and use it as a guide to

construct his/her profile. Initial attempts to construct

such profiles typically used “bag of words”

representations and keyword similarity techniques

(closely related to the well known vector space

model representation in the Information Retrieval

area) to represent user profiles and match them

against new data items. These techniques, however,

often suffer from limited ability to express user

interests, being unable to fully capture the semantics

of the user behaviour and user interests. As an

attempt to face this lack of expressibility, there have

appeared lately (Altinel and Franklin, 2000;

Antonellis and Makris, 2008; Canadan et al., 2006;

Diao et al., 2003; Kwon et al., 2005) a number of

systems that use XML representations for both

documents and user profiles and that employ various

filtering techniques to match the XML

representations of user documents with the provided

profiles.

The basic mechanism used to describe user

profiles in XML format is through the XPath query

language (http://www.w3.org/). XPath is a query

language for addressing parts of an XML document,

while also providing basic facilities for manipulation

of strings, numbers and booleans. XPath models an

XML document as a tree of nodes. There are

different types of nodes, including element nodes,

attribute nodes and text nodes and XPath defines a

way to compute a string-value for each type of node.

The process of filtering XML documents is the

reverse of searching XML documents for specific

structural and value information. An XML document

filtering system stores user profiles along with

additional information (e.g. personal information of

the user, email address). A user profile can store

either only structural criteria or both structural and

value criteria. In the first case, the XML filtering is

called structural while in the second case is called

hybrid (structural and value-based). When an XML

Antonellis P., Makris C. and Pispirigos G..

PARALLELIZED STRUCTURAL AND VALUE XML FILTERING ON MULTICORE PROCESSORS.

DOI: 10.5220/0003896600050012

In Proceedings of the 8th International Conference on Web Information Systems and Technologies (WEBIST-2012), pages 5-12

ISBN: 978-989-8565-08-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

document arrives, the system filters it through the

stored profiles to identify with which of them the

document matches. After the filtering process has

finished, the document can be sent to the

corresponding users with matching profiles.

2 BACKGROUND

2.1 Related Work

In recent years, many approaches have been

proposed for providing efficient filtering of XML

data against large sets of user profiles. Depending on

the way the user profiles and XML documents are

represented and handled, the existing filtering

systems can be categorized as follows:

Automata-based Systems. Systems in this category

utilize Finite State Automata (FSA) to quickly match

the incoming XML document with the stored user

profiles. While parsing the XML document, each

node element causes one or more transitions in the

underlying FSA, based on the element's name or tag.

In XFilter (Altinel and Franklin, 2000), user profiles

are represented as queries using the XPath language

and the filtering engine employs a sophisticated

index structure and a modified Finite State Machine

(FSM) approach to quickly locate and examine

relevant profiles. A major drawback of XFilter is its

lack of twig pattern support, as it handles only linear

path expressions. Based on XFilter, a new system

was proposed in (Diao et al., 2003) termed YFilter

that combined all of the path queries into a single

Nondeterministic Finite Automaton (NFA) and

exploited commonality among user profiles by

merging common prefixes of the user profile paths

such that they were processed at most once. Unlike

XFilter, YFilter handles twig patterns by

decomposing them into separate linear paths and

then performing post-processing over the

intermediate matching results. The authors in (Zhang

et al., 2010) propose a parallel implementation of

YFilter for multi-core systems (shared-memory) by

splitting the NFA into smaller parts, with each part

assigned to a single thread. A distributed version of

YFilter which also supports value-based predicates

is presented in (Miliaraki and Koubarakis, 2010). In

this approach the NFA is distributed along the nodes

of a DHT network to speed-up the filtering process

and various pruning techniques are applied based on

the defined value predicates on the stored user

profiles.

Sequence-based Systems. Systems in this category

encode both the user profiles and the XML

documents as string sequences and then transform

the problem of XML filtering into that of

subsequence matching between the document and

profile sequences. FiST (Kwon et al., 2005) employs

a novel holistic matching approach, that instead of

splitting the twig patterns into separate linear paths,

it transforms (through the use of the Prüfer sequence

representation) the matching problem into a

subsequence matching problem. In order to provide

more efficient filtering, user profiles sequences are

indexed using hash structures. XFIS (Antonellis and

Makris, 2008) also employs a holistic matching

approach which eliminates the need of extra post-

processing of branch nodes by transforming the

matching problem into a subsequence matching

problem between the string sequence representation

of user profiles and XML documents.

Stack-based Systems. The representative system of

this category is AFilter (Canadan et al., 2006).

AFilter utilizes a stack structure while filtering the

XML document against user profiles. Its novel

filtering mechanism exploits both prefix and suffix

commonalities across filter statements, avoids

unnecessarily eager result/state enumerations (such

as NFA enumerations of active states) and decouples

memory management task from result enumeration

to ensure correct results even when the memory is

tight. XPush (Gupta and Suciu, 2003) translates the

collection of filter statements into a single

deterministic pushdown automaton using stacks. The

XPush machine uses a SAX parser that simulates a

bottom up computation and hence doesn't require the

main memory representation of the document. XSQ

(Peng and Chawathe, 2005) utilizes a hierarchical

arrangement of pushdown transducers augmented

with buffers.

Although all of the previously described works

have been used successfully for representing a set of

user profiles and identifying XML documents that

structurally match with the user profiles, little work

(Kwon et al., 2008), (Miliaraki and Koubarakis,

2010) has been done to support value matching, that

is evaluation of value-based predicates in the user

profiles. This is a very usual problem in real world

applications where the user profiles except for just

defining some structural predicates, also introduce

value-based predicates. A modern XML filtering

system should be able to handle both types of

predicates and also scale well in case of a large

number of stored user profiles.

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

2.2 Paper Motivation and Contribution

Most of the research work in the area of XML

filtering has been in the context of a single

processing core. However, given the wide spread of

multi-core processors, we believe that a parallel

approach can provide significant benefits for a

number of real world applications. In addition, most

of the existing approaches concentrate only on the

structural characteristics of user profiles, although in

many real-world applications the value predicates

may be more important.

Based on this motivation, we propose a parallel

approach to the problem of structural and value-

based XML filtering for shared-memory systems,

based on the YFilter algorithm. The main

contributions of the proposed parallel algorithm are:

• Parallel execution of the NFA constructed by

the YFilter, by utilizing all the cores of the

processor.

• Dynamic work load balancing based on the

currently active states of the NFA.

• The support of value-predicates in user

profiles, by dynamically pruning the NFA

based on the most “popular” states.

In our knowledge, this is one of the few works in

parallel XML filtering that deal with support of

value-based predicates, mainly inspired by

(Miliaraki and Koubarakis, 2010).

3 YFILTER OVERVIEW

The YFilter algorithm constructs a single NFA for a

large number of queries and utilizes this NFA to

filter a continuous stream of incoming XML

documents (Diao et al., 2003).

In Figure 1 we present an example of such a

nondeterministic finite automaton (NFA)

constructed from four eight user profiles. The user

profiles have been chosen appropriately to represent

the different types of supported structural

relationships. Each intermediate NFA state is

represented with a circle, while each final NFA state

(e.g. a state that leads to accepting a specific user

profile) is represented with a double circle. The user

profiles associated with each final state are shown

with curly braces next to the state. Finally, each edge

transition is triggered when a matching element (tag)

name is encountered during the parsing of the

incoming XML document.

As we can easily observe, YFilter greatly reduces

the number of states by sharing the common prefix

paths of the stored user profiles. YFilter uses an

event-driven method along with a stack of active

states. Each level of the stack represents possible

states of the NFA for the XML part of the XML

document that has currently already been seen. As

shown in Figure 2, once it receives a start-of-

element event, the filtering algorithm follows all

matching transitions from all currently active states.

When checking an available edge transitions, if the

incoming element name matches the transition or the

transition is marked by the * symbol, the

corresponding state will be added to the new active

state set. After all possible transitions have been

checked, the new active state set is complete, and it

is pushed on the stack as a new level. Whenever an

accepting state is reached, it will output the user

profiles list in this state. When an end-of-element

event is received, the active states stack is popped

one level.

It is vital to note that the actual operations

required when a start-of-element event is received

are checking the available transitions for each state

in the top level of the active states stack. For

example, when the start-of-element event for

element <c> is received, the filtering algorithm

checks the available transitions for the states: 2, 4, 5,

7 which result in the states 4, 6, 8, 9, 10, 11 to be

activated and pushed in the top of the stack.

4 PARALLEL STRUCTURAL AND

VALUE FILTERING

In this work we describe our new parallelized XM

filtering algorithm, based on YFilter. The actual

NFA execution is split into the different threads

using a dynamic load balancing technique, which

always ensures that each thread is assigned with the

same work load. The proposed algorithm, in addition

to structural filtering, also supports value filtering

based on the value-predicates defined in the stored

user profiles.

4.1 Parallelized NFA Execution

Our goal was to truly parallelize the YFilter

algorithm in a balanced way in order for each thread

to be assigned with a similar amount of workload

during the filtering process. Existing approaches are

based on statically splitting the constructed NFA

into parts and assigning each specific part at each

thread (Zhang et al., 2010). Similar approaches also

exist for distributed NFA execution on top of DHT

networks (Miliaraki and Koubarakis, 2010).

However, this type of work splitting does not ensure

PARALLELIZEDSTRUCTURALANDVALUEXMLFILTERINGONMULTICOREPROCESSORS

Figure 1: Example NFA constructed from a set of user profiles.

Figure 2: Active states during parsing of an incoming XML document.

that each thread will actually have the same

workload, as the actual state transitions may occur

only in a very small part of the whole NFA. In such

a case some threads may remain idle, while others

are working, thus the NFA execution is not truly

parallelized. For example consider the NFA of

Figure 1, split in four parts: {0, 1, 2}, {3, 4, 5}, {6,

7, 8} and {9, 10, 11, 12}, which each part statically

assigned to a single thread. When the start-of-

element event for element <c> is received, the thread

#1 will check one state (state 1), the thread #2 will

check two states (states 4, 5), the thread #3 will

check only one state (state 7) and the thread #4 will

remain inactive as none of the currently active states

belong to its NFA part. Thus, the actual workload is

not equally split to the four available threads.

Based on this notion, the proposed filtering

algorithm achieves balanced work splitting, by

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

dynamically assigning tasks to each thread during

NFA execution. As mentioned before, whenever a

start-of-element event is received, the algorithm has

to check the transitions of each state included in the

top level of the active states stack. Although each

active state does not have the same number of

candidate transitions with the rest states, we make

the assumption that the number of tasks is equal to

the number of active states at that time. Based on

this assumption, the proposed filtering algorithm

creates a task for each active state and pushes them

into a queue. Whenever a thread is idle, it is

assigned with the next available task (e.g. active

state) from the queue. The only drawback of this

approach is that in cases that a state has a big

number of candidate transitions, the corresponding

thread may be late and thus the achieved

parallelization will be not the best one.

For example, consider a system with three

threads and the NFA of Figure 1, when the start-of-

element event for element <c> is received. The

currently active states are four (states 2, 4, 5, 7) and

thus the thread #1 will be assigned with state 2, the

thread #2 will be assigned with state 4 and the thread

#3 will be assigned with state 5. Each thread will

check the available transitions of its assigned state

with the character <c> and in case of a match, it will

activate the appropriate new state by pushing it on

top of the stack. The first thread that will finish its

job will be also assigned with the remaining state 7.

From the above example, it is clear that the

proposed dynamic parallelization of the NFA

execution achieves best results due to actual work

balancing based on the currently active states, unlike

the existing approaches which are based on statically

assigning NFA subsets to each thread.

A slightly different approach can be utilized if

the fan-out of the NFA (e.g. number of edges per

state) is quite small: in such a case the actual cost of

checking all the transitions of each state is quite

small, so the overhead of creating a separate task for

each active state may overcome the benefits of the

actual parallelization. So, it is better to split the set

of active states into a list of subsets, based on the

number of threads, and assign a subset to each

thread.

For example, consider again a system with two

threads and the NFA of Figure 1, when the start-of-

element event for element <c> is received. Instead of

assigning the state 2 to thread #1, the state 4 to

thread #2 and waiting for them to finish in order to

assign the rest of the states, we can directly assign

the states 2, 4 to thread #1 and the states 5,7 to

thread #2. That way, we reduce the cost of task

initialization for every separate active state, thus

achieving a further improvement on the total

filtering time.

This variation decreases the overhead introduced

of task creation and assignment by creating the least

number of tasks. However, if a specific subset of

states includes much more transitions than the other

subsets, the rest of the threads would have to remain

idle for quite a long time, thus increasing the actual

filtering time. Based on the above notions, the

proposed filtering algorithm only uses this approach

only if the number of transitions is about the same

for every state during NFA construction, based on a

predefined threshold of 15%, which was depicted

after experimental testing.

4.2 Evaluation of Value-Based

Predicates

In the previous section, we described how the

structural matching is parallelized by assigning each

thread with a subset of the active states to check. In

this section, we concentrate on the evaluation of

value-based predicates. Consider for example the

user profile q:

paper[@year=2011]/author[text()=”James”],

which selects the papers of author “James” during

the year 2011. In order to filter an incoming XML

document against the user profile q requires to check

if the document’s structure matches the profile’s

structure and also whether the value predicates of

the user profile q are satisfied by the XML

document.

A naïve approach is to integrate the value

predicates directly on the constructed NFA, by

adding extra transitions for the predicates, thus

considering the value predicates as distinct nodes

(Kwon et al., 2008). However, this approach would

lead to a huge increase in the number of states and

also destroy the sharing of path expressions for

which the NFA was selected to begin with, as the

value predicates usually form a larger set than the

structural constraints of the user profiles. Other

approaches, such as bottom-up and top-down

(Miliaraki and Koubarakis, 2010), have been

proposed to address this problem. The common idea

behind those approaches is the selection of a small

subset of the value predicates for pruning the NFA

execution, based on some predefined selectivity

criterion. However, in real world applications, the

incoming XML documents have been usually

generated by different sources and thus vary both in

structure and content. In such cases, a selected value

PARALLELIZEDSTRUCTURALANDVALUEXMLFILTERINGONMULTICOREPROCESSORS

predicate may be good for pruning the NFA

execution during the filtering of a specific set of

XML documents and bad for another set of XML

documents. Thus, deciding on which value

predicates to utilize during the NFA execution is not

straightforward and has a strong impact on the

efficiency of the filtering algorithm.

Based on this notion, our proposed filtering

algorithm utilizes a novel step-by-step approach for

supporting value-based predicates. This approach

introduces the idea of "popular" NFA states, that is

the NFA states that have been activated a lot during

the filtering of the various incoming XML

documents. More precisely, we keep a counter for

each NFA state that counts the number of activations

for that state and we select the top 10% states as the

most "popular" states. For example, in Figure 3, the

state 4 has been activated two times, while the state

3 has been activated zero times. The value of the

threshold can change to balance the pruning of the

NFA, but it is initialized to 10% which resulted in

better results during the experiments.

The idea of utilizing the most "popular" states

has the benefit that dynamically defines the set of

NFA states that trigger value predicate checking

(and thus may stop the NFA execution), only based

on the set of previously filtered XML documents

and not some user-defined selectivity criterion, like

in (Miliaraki and Koubarakis, 2010). Thus there is

no need for a-priori knowledge of the semantics of

incoming XML documents in order to decide the

those states. This approach is based on the idea that

a state that has been activated a lot during the

filtering of previous XML documents has a greater

possibility to be activated during the filtering of

subsequent XML documents, and thus an unsatisfied

value predicate in that state will stop the NFA

execution (prune this execution path).

During the NFA construction, at each state we

also store a set of the corresponding value-based

predicates along with the query id of each predicate.

This set of predicates will be used during the

filtering in order to decide whether the current

execution path will continue or stop. Whenever an

incoming XML document arrives, we parse it and

create a list of candidate predicates based on the text

data of nodes and attributes. This list of candidate

predicates will be used during candidate checking

during the filtering procedure.

Checking a set of predicates assigned to a state

against the list of candidate predicates contained in

an XML document may be a slow procedure, due to

the big number of candidate predicates. Thus,

instead of checking the predicates at each active

state, the filtering algorithm applies the candidate

checking only on the most "popular" states, as

described before. During this check, we check if at

least one of the state predicates is included in the list

of document’s candidate predicates. In such a case,

the execution path will continue normally on this

state. On the other hand, if none of the state

predicates is part of the candidate predicates, then

there is no need to continue this execution path as

none of the corresponding user profiles are satisfied,

thus the state is not activated.

The only drawback of this approach is that at the

end of filtering process, all the matched user profiles

must be checked against the incoming XML

document based on their value-based predicates, as

the filtering algorithm does not check the value

predicates in all the states. However, usually the

number of matched user profiles is a small portion of

the total number of stored user profiles and thus the

cost is very small compared to the cost of checking

the value predicates at each NFA state.

5 EXPERIMENTS

We tested our filtering system against the most

recent parallel approach to XML filtering (Zhang et

al., 2010). In this approach the authors propose a

method for statically splitting the NFA into subparts

and assign each subpart to a separate thread.

However, this approach does not support value-

based predicates, so for the experiments we only

used structural-only user profiles. Our filtering

system was implemented in Java using the freeware

Eclipse IDE. In order to obtain comparable and

reliable results, we also implemented the other

parallel algorithm in Java as well.

In our experiments we used three different

datasets: DBLP dataset (http://kdl.cs.umass.edu/),

Shakespeare’s plays dataset (http://xml.

coverpages.org/) and synthetic Treebank data

generated by an XML generator provided by IBM

(Diaz and Lovell). We also generated three user

profile sets, one set for each dataset, using the XPath

generator available in the YFilter package. The final

set of user profiles consisted of the three different

user profile sets, each set constructed from the

corresponding XML dataset. We used that approach

in order to emulate a real-world filtering system

where the stored user profiles are usually different

from each other and the same also stands for the

incoming XML documents.

All the experiments were run on a quad-core

hyper threading (thus 8 threads) Linux machine

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

Figure 3: Filtering time as the number of threads increases.

Figure 4: Filtering time as the number of user profiles increases.

running Kubuntu 11.04 with 8 Gb RAM. During the

experiments, we measured the average filtering time

of an XML document with size approximately 5500

nodes through 7000 stored user profiles, by varying

the number of threads between 1 and 8, in order to

calculate the speed-up gained by the proposed

parallelization compared to the parallel algorithm

presented in (Peng and Chawathe, 2005). In

addition, we measured the average filtering time as

the number of stored user profiles increases between

1000 and 10000, for 4 threads.

Figure 3 shows the results of the first

experiment. As it can be easily observed both

approaches achieve a speed-up of the total filtering

process as the number of utilized threads increases.

However, although our approach starts slower (for 1

thread), it turns out that it takes greater advantage of

the increasing number of threads and finally

achieves better filtering times after the 4 threads. In

fact the achieved speed-up in filtering time is 7

(14000ms to 2000ms) for 8 threads, while the other

algorithm actually achieves a speed-up of 2.5

(10000ms to 4000ms) for 8 threads. The results can

be easily explained, as the overhead for creating a

separate task for each active state can slow down the

total filtering process if the number of threads is

small (in the current experiment : 1- 3 threads), but

as the number of threads increases, the proposed

dynamic parallelization works efficiently and the

total filtering time is greatly reduced. On the other

hand, the approach proposed in (Peng and

Chawathe, 2005), which is based on splitting the

NFA into subsets and assigning each subset into a

separate thread, cannot achieve the same speed-ups

as the number of threads increases. This is due to the

fact that it doesn’t apply a balanced workload

2000

4000

6000

8000

10000

12000

14000

16000

12345678

Filteringtime(ms)

Numberofthreads

OurApproach

Otherapproach

1000

2000

3000

4000

5000

6000

1000 2000 5000 8000 10000

Filteringtime(ms)

Numberofuserprofiles

Ourapproach

Otherapproach

PARALLELIZEDSTRUCTURALANDVALUEXMLFILTERINGONMULTICOREPROCESSORS

splitting into the available threads, as each NFA

subset execution may require different work, and

thus some threads may remain idle for quite large

amount of time

Figure 4 shows the results obtained from the

second experiment. It is clear that the filtering time

of both algorithms slightly increases as the number

of stored user profiles increases. This is expected, as

a greater number of user profiles results to a larger

NFA and thus to a bigger number of active states

during NFA execution. Thus, the actual workload

increases and this is depicted in the total filtering

time. However, the filtering time does not increase

analogously to the total number of stored user

profiles, which means that both approaches scale

very well as the number of user profiles increases.

Again, as the number of user profiles increases, our

proposed parallel approach scales better than the

algorithm proposed in (Peng and Chawathe, 2005),

achieving an average of 15% better filtering time for

4 threads.

6 CONCLUSIONS

In this paper we have presented an innovative

parallel XML filtering system that takes advantage

of the multi-core processors that are widely used in

modern computers, in order to speed up the XML

filtering problem. The proposed system, which is

based on the well-known YFilter algorithm,

constructs a NFA from the stored user profiles and

utilizes this NFA to filter a continuous stream of

incoming XML documents. However, instead of

executing the NFA using a single-thread approach, it

splits the workload required at each step of the

filtering process into the available threads, thus

providing a big speed-up to the total filtering time

required. The number of threads depends on the

number of available cores and can vary, but the

proposed filtering algorithm can work with any

number of threads. In addition, the proposed filtering

system extends the YFilter in order to efficiently

support value-based predicates in the user profiles,

enabling both structural and value-based filtering of

the incoming XML documents. The value-based

filtering is applied using a dynamic top-down

approach, where the NFA execution is pruned only

in the most popular states, which results to small

overhead and big speed-up due to early pruning. The

experimental results showed that the proposed

system outperforms the previous parallel XML

filtering algorithms by fully utilizing the available

threads.

ACKNOWLEDGEMENTS

This research has been co-financed by the European

Union (European Social Fund - ESF) and Greek

national funds through the Operational Program

"Education and Lifelong Learning" of the National

Strategic Reference Framework (NSRF) - Research

Funding Program: Τhales. Investing in knowledge

society through the European Social Fund.

REFERENCES

Aguilera, M. K., Strom, R. E., Stunnan, D. C., Ashey, M.

and Chandra, T. D. Matching Events in a Content-

based Subscription System. In Proceedings of the

ACM Symposium on Principles of Distributed

Computing (PODC ’99), 1999, 53-61.

Altinel, M. and Franklin, M.l J. Efficient Filtering of XML

Documents for Selective Dissemination of

Information. In VLDB, 2000, 53-64.

Antonellis, P. and Makris C. XFIS: an XML filtering

system based on string representation and matching. In

International Journal on Web Engineering and

Technology (IJWET), 2008, 4(1), 70-94

Canadan, K., Hsiung, W., Chen, S., Tatemura, J. and

Agrrawal, D. AFilter: Adaptable XML Filtering with

Prefix-Caching and Suffix-Clustering. In VLDB, 2006,

559-570.

Diao, Y., Altinel, M., Franklin, M.l J., Zhang, H. and

Fischer, P. Path sharing and predicate evaluation for

high-performance XML filtering. In TODS, 2003,

28(4), 467-516.

Gupta, A.K and Suciu, D. Stream processing of XPath

queries with predicates. In SIGMOD, 2003, 419-430.

Kwon, J., Rao, P., Moon, B. and Lee, S. FiST: Scalable

XML Document Filtering by Sequencing Twig

Patterns. In VLDB, 2005, 217-228.

Kwon, J., Rao, P., Moon, B. and Lee, S. Value-based

predicate filtering of XML documents. In Data and

Knowledge Engineering (KDE), 67 (1), 2008.

Miliaraki, I. and Koubarakis, M. Distributed structural and

value XML filtering. In DEBS, 2010, 2-13.

Peng, F. and Chawathe, S. XSQ: A streaming XPath

Queries. In TODS, 2005, 577-623.

Zhang, Y., Pan, Y. and Chiu, K. A Parallel XPath Engine

Based on Concurrent NFA Execution. In Proceedings

of the IEEE 16th International Conference on Parallel

and Distributed Systems (ICPADS 2010), 2010, 314-

321.

http://www.w3.org/TR/xpath

http://kdl.cs.umass.edu/data/dblp/dblp-info.html

http://xml.coverpages.org/bosakShakespeare200.html

Diaz, A. L. and Lovell, D. XML Generator. http://

alphaworks.ibm.com/tech/xmlgenerator

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies
