Testing Conformance of EJB 3 Enterprise Application Servers

Sander de Putter, Serguei Roubtsov and Alexander Serebrenik

Department of Mathematics and Computer Science, Eindhoven University of Technology,

P.O. Box 513, 5600 MB Eindhoven, The Netherlands

Keywords:

Enterprise JavaBeans, Speciﬁcation Conformance, EJB Application Server.

Abstract:

Enterprise JavaBeans (EJB) is a component technology used for enterprise application development. EJB

is currently being implemented by such application servers as GlassFish, OpenEJB, JBoss, WebLogic and

Apache Geronimo. Through the entire history EJB claimed its adherence to the “write once, run anywhere”

philosophy of Java suggesting that an application developed for and deployed on one application server should

be easily portable to a different application server. Therefore, one could have expected different application

servers to adhere to the EJB speciﬁcation. Adherence to this and related Java EE speciﬁcations is subject of the

“Java EE 6 Full Proﬁle” compatibility testing carried by Oracle. However, anecdotal evidence of discrepancies

between the speciﬁcation and certiﬁed implementations such as GlassFish, has been reported in the literature.

In this paper we present an approach allowing one to go beyond the level of anecdotal knowledge and test

requirements for EJB application servers with focus on portability. We apply the approach developed to test

how well two popular “Java EE 6 Full Proﬁle”-compatible EJB application servers, GlassFish and JBoss,

conform to the requirements in the EJB speciﬁcation. The results are alarming: both application servers failed

on a number of tests, violating the speciﬁcation. Moreover, in GlassFish conformance to a requirement varies

depending on whether a local or a remote application is used. Lack of conformance to the EJB speciﬁcation

compromises the portability of the EJB applications, deviates from the portability philosophy of Java, leads to

unexpected behaviour, and hinders the learning process of novice EJB developers.

1 INTRODUCTION

Enterprise JavaBeans™(EJB) is a component tech-

nology used for enterprise application development.

While the ﬁrst version of the speciﬁcation was re-

leased in 1998 (Matena and Harper, 1998), its most

recent version has been released in 2009 (EJB 3.1

Expert Group, 2009) and it is currently being im-

plemented by such application servers as GlassFish,

OpenEJB, JBoss AS and WebLogic.

Through the entire history EJB claimed (Matena

and Harper, 1998; EJB 3.1 Expert Group, 2009) its

adherence to the “write once, run anywhere” philos-

ophy of Java (Hamilton, 1996) suggesting that an ap-

plication developed for and deployed on one appli-

cation server should be easily portable to a different

application server. Application portability is essen-

tial for reuse of Enterprise Beans across application

servers (Dorda et al., 1999), helps EJB developers

and users to avoid vendor lock-in and fosters integra-

tion with additional technologies chosen by the cus-

tomer (Krastev and Galletly, 2003). Therefore, one

could have expected different application servers to

adhere to the EJB speciﬁcation. Adherence to this and

related Java EE speciﬁcations is subject of the “Java

EE 6 Full Proﬁle” compatibility testing carried by Or-

acle.

However, anecdotal evidence of discrepancies

between the speciﬁcation and certiﬁed implementa-

tions such as GlassFish, has been reported in the liter-

ature (Serebrenik et al., 2009).

Conformance of application servers to the EJB

speciﬁcation is important for understanding EJB ap-

plications. Deviation of the application servers from

the EJB speciﬁcation is not documented and difﬁcult

to discover. Moreover, these discrepancies can put

in jeopardy speciﬁcation-based tools and techniques

intended to facilitate the developers’ comprehension.

Thus, testing conformance of an application server to

the EJB speciﬁcation helps to indicate deviating be-

haviour, and contributes to improving the developers’

understanding of EJB applications.

To address the problem of discrepancies between

the EJB speciﬁcation and its implementations we

have formulated the following research questions.

http://goo.gl/qjqa3.

272

de Putter S., Roubtsov S. and Serebrenik A..

Testing Conformance of EJB 3 Enterprise Application Servers.

DOI: 10.5220/0004864402720279

In Proceedings of the 16th International Conference on Enterprise Information Systems (ICEIS-2014), pages 272-279

ISBN: 978-989-758-029-1

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

RQ1. How should one test requirements for EJB

application servers with focus on portability?

Rationale. An application server can be seen as a

meta-program, i.e., as opposed to traditional software

testing an application server requires designing an in-

put program. Moreover, due to the nature of an ap-

plication server, the input program should be built,

deployed and run as part of the testing process, i.e.,

a novel approach to extracting information from the

running application server is required. Compatibil-

ity testing also implies that input programs should be

application-server independent.

Results. This paper applies the traditional testing

methodology to the client-server architecture of EJB.

To support multiplicity of requirements and applica-

tion servers to be tested we specify application servers

and test cases independently of each other, and pro-

vide a conﬁguration ﬁle indicating how an application

server should deploy and run a test case.

RQ2. How well do “Java EE 6 Full Proﬁle”-

compatible EJB application servers conform to

the requirements in the EJB speciﬁcation?

Rationale. Discrepancy between the speciﬁcation and

its implementations puts portability in jeopardy, leads

to unexpected behaviour and can be confusing for

novice developers accustomed to a different applica-

tion server. Furthermore, as EJB technology is being

taught and certiﬁed worldwide, clear relation between

the speciﬁcation and the implementation used during

the training is a prerequisite for further successful em-

ployment of the trainees.

Results. We apply our approach to test the EJB

speciﬁcation conformance of two “Java EE 6 Full

Proﬁle”-compatible EJB application servers: Glass-

Fish version 3.1.2

, EJB reference implementation by

Oracle, and JBoss AS version 7.1.1

. GlassFish is the

reference implementation of an application server,

i.e., when novice developers learn EJB they are likely

to encounter GlassFish ﬁrst. JBoss AS, JavaBeans

Open Source Software Application Server, recently

renamed to WildFly is a popular (Kounev et al.,

2004; Xian et al., 2006) open source application

server. Of 21 tests GlassFish fails 8 and JBoss AS

fails 2. Moreover, in GlassFish conformance to a

requirement varies depending on whether a local

or a remote application is used. In JBoss AS no

local/remote discrepancies have been found.

https://glassﬁsh.java.net/.

http://www.jboss.org/jbossas.

RQ3. What are the implications of the (lack of)

conformance observed?

Rationale. The extent to which a given application

server conforms to the speciﬁcation may have impact

on the portability of applications developed for that

application server. Furthermore, the (lack of) confor-

mance may lead to confusion for developers who are

only familiar with application servers that behave dif-

ferently for certain requirements.

Results. Our results suggest that EJB applica-

tions that do not conform to the EJB speciﬁcation may

not be portable between different application servers.

Hence, the lack of conformance results in a deviation

from the portability philosophy of Java. Furthermore,

anecdotal evidence indicates that lack of conformance

results in confusion amongst EJB developers, and af-

fects validity of the analysis tools.

The remainder of the paper is organized as fol-

lows. After introducing EJB 3 in Section 2, we dis-

cuss RQ1 and present our approach in Section 3. In

Section 4 we present a motivating example. The ap-

proach is evaluated and RQ2 and RQ3 are addressed

in Section 5. Finally, related work is reviewed in

Section 6, while conclusions and directions for future

work are sketched in Section 7.

2 OVERVIEW OF EJB 3

This section presents a brief overview of Enterprise

JavaBeans and the client view interfaces of the EJB

3.1 session bean (EJB 3.1 Expert Group, 2009).

2.1 EJB 3 Alternatives

In addition to EJB 3 additional architectural ap-

proaches have been proposed for the development of

(business) Web applications. Similarly to EJB 3, Win-

dows Communication Foundation (.NET) and Jini/-

JavaSpaces attempt to decouple interface and imple-

mentation, and support service lookup and discov-

ery, as well as transaction management. However,

Windows Communication Foundation does not dis-

tinguish between local and remote applications, while

Jini/JavaSpaces has been reported to have failed to at-

tract a signiﬁcant market.

Tomcat is sometimes men-

tioned as an alternative to EJB as it used to offer a

lightweight version of JavaEE. However, since 2011

next to the lightweight version a JavaEE certiﬁed ver-

sion of Tomcat is offered as well, deeming the Tomcat

http://goo.gl/gwZVd0.

TestingConformanceofEJB3EnterpriseApplicationServers

273

vs. JavaEE discussion “tired and old”.

2.2 Enterprise JavaBeans

Enterprise JavaBeans (EJB) is a server-side compo-

nent architecture for development and deployment of

business applications. The business logic of the ap-

plication is implemented in Java classes. Optionally,

a set of EJBs is packaged into larger deployable ap-

plication. Finally, the EJBs are deployed into an EJB

container provided by an application server.

The EJB container is a run-time environment for

EJBs within the application server (Figure 1). The

container can contain one or more EJB modules

which each can contain one or more EJBs. It man-

ages the life cycles of bean objects, provides remote

access, and coordinates distributed transactions.

Client view

Enterprise JavaBean

EJB module

EJB container

invokes

accesses

Client

Figure 1: Overview of an EJB container.

The EJB architecture deﬁnes three types of EJBs:

the session bean, the message-driven bean, and the

deprecated entity bean. We focus on the ﬁrst type,

the session bean, because it has more interesting re-

quirements: the speciﬁcation (EJB 3.1 Expert Group,

2009) lists only a few requirements for the message-

driven bean and entity bean is deprecated.

The session bean implements business methods of

a module. The business methods are exposed through

the client view interfaces of an EJB module. Client

access to an instance of the session bean’s class is me-

diated by the container via the session bean’s client

view. A client view is provided by the session bean

and made available when deployed in the EJB con-

tainer, the container itself is transparent to the client.

2.3 Client Views

Client views provide access to the business methods

of a session bean. There are a total of six client views:

Local, Remote, No-Interface, Web Service, 2.x Local

Home and 2.x Remote Home.

The Local client view is location dependent. The

EJB 3.1 speciﬁcation only requires the support of Lo-

cal clients that are packaged within the same module

as the session bean that provides the Local client view.

However, EJB application servers may also support

http://goo.gl/3N5jpt.

access to the Local client view of session beans that

are located in a different module.

The Remote client view is location independent.

The Remote client may be located in the same Java

Virtual Machine (JVM) or in a different JVM. Argu-

ments and return values of methods of the Remote

client interface are passed by value. Communica-

tion occurs through Java Remote Method Invocation

(RMI) over the Internet Inter-Orb Protocol (IIOP).

The No-Interface client view is a variation of the

Local client view. All public methods of the session

bean’s class are exposed to clients.

The Web Service client view provides web ser-

vices access to the exposing session bean. This client

view is speciﬁed in a WSDL document describing the

client view interface as a set of endpoints operating on

messages. Communication to this client view occurs

through SOAP or plain XML over HTTP or HTTPS.

Finally, the 2.x Local Home and 2.x Remote Home

client views are used to provide Local and Remote

client views in EJB 2.1 and earlier releases. These

client views ensure backwards-compatibility for ap-

plications written for EJB 2.1 or earlier.

3 APPROACH

Discrepancies between the EJB speciﬁcation and

EJB implementations have been observed in the past

(Dorda et al., 1999; Serebrenik et al., 2009). Such dis-

crepancies may put portability at risk or lead to unex-

pected behaviour. It is therefore important that imple-

mentations adhere to the speciﬁcation. Furthermore,

testing requirements for multiple application servers

is essential to the EJB component market.

To address RQ1 we present an application of

the traditional software testing methodology (Interna-

tional Software Testing Qualiﬁcations Board, 2011)

to the client-server architecture of EJB. As opposed to

traditional software testing, the testing requirements

on an application server requires designing an input

program and a client of the input program. A test

case consists of the server-side application (the input

program), a client application, and a speciﬁcation of

the expected behaviour. The input program adheres

to a given requirement iff it exhibits the expected be-

haviour. To indicate an application server’s lack of

conformance to the EJB speciﬁcation it is sufﬁcient

to present input programs that fail to adhere to the

speciﬁcation’s requirements.

Our approach consists of the following steps.

First, a server-side test application is built. When a

requirement demands a certain behaviour to be sup-

ported, the server-side test application implementing

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

274

Table 1: Requirements from Section 4.9.7 (EJB 3.1 Expert Group, 2009) and conformance results for GlassFish 3.1.2. and

JBoss AS 7.1.1

Requirement GlassFish JBoss Remarks

1 The interface must not extend the

javax.ejb.EJBObject

javax.ejb.EJBLocalObject

interface.

Local fail fail The presence of

EJBLocalObject

is ignored.

Remote success fail In GlassFish the application fails to deployed. In JBoss the presence of

EJBObject

is ignored.

2 If the business interface is a remote business interface, the argument and return values must be of valid types for RMI/IIOP. The remote business interface

is not required or expected to be a

java.rmi.Remote

interface. The throws clause should not include the

java.rmi.RemoteException

. The methods of the

business interface may only throw the

java.rmi.RemoteException

if the interface extends

java.rmi.Remote

Local N/A N/A The requirement is only applicable to remote applications.

Remote success success An exception is thrown after invocation of the test method in both servers.

3 The interface is allowed to have superinterfaces.

Local success success

Remote success success

4 If the interface is a remote business interface, its methods must not expose local interface types, timers or timer handles, or the managed collection classes

that are used for EJB 2.1 entity beans with container-managed persistence as arguments or results.

Local N/A N/A The requirement is only applicable to remote applications.

Remote success success After invocation of the test method an error is raised both client-side and

server-side.

5 The bean class must implement the interface or the interface must be designated as a local or remote business interface of the bean by means of the Local or

Remote annotation or in the deployment descriptor. The following rules apply:

5a If the bean does not expose any other business interfaces (Local, Remote) or No-Interface view, and the bean class implements a single interface, that

interface is assumed to be the business interface of the bean. This business interface will be a local interface unless the interface is designated as a remote

business interface by use of the

Remote

annotation on the bean class or interface or by means of the deployment descriptor.

Local success success

Remote N/A N/A The requirement is only applicable to local applications.

5b A bean class is permitted to have more than one interface. If a bean class has more than one interface — excluding the interfaces listed below — any

business interface of the bean class must be explicitly designated as a business interface of the bean by means of the

Local

Remote

annotation on the bean

class or interface or in the deployment descriptor.

Local fail success In GlassFish all interfaces are exposed. JBoss does not deploy the bean.

Remote fail success In GlassFish all interfaces are exposed. JBoss does not deploy the bean.

5c The following interfaces are excluded when determining whether the bean class has more than one interface:

java.io.Serializable

;

java.io.Externalizable

;any of the interfaces deﬁned by the

javax.ejb

package.

Local success success

Remote success success

5d The same business interface cannot be both a local and a remote business interface of the bean. It is also an error if the

Local

and/or

Remote

annotations

are speciﬁed both on the bean class and on the referenced interface and the values differ.

Local

@Local

and

@Remote

on the BC fail success GlassFish ignores these inconsistent annotations.

@Local

on the BC,

@Remote

on the BI fail success GlassFish ignores these inconsistent annotations.

@Local

on the BI,

@Remote

on BC fail success GlassFish ignores these inconsistent annotations.

@Local

and

@Remote

on the BI fail success GlassFish ignores these inconsistent annotations.

Remote

@Local

and

@Remote

on the BC success success

@Local

on the BC,

@Remote

on the BI success success

@Local

on the BI,

@Remote

on BC fail success GlassFish ignores these inconsistent annotations.

@Local

and

@Remote

on the BI success success

5e While it is expected that the bean class will typically implement its business interface(s), if the bean class uses annotations or the deployment descriptor to

designate its business interface(s), it is not required that the bean class also be speciﬁed as implementing the interface(s).

Local success success

Remote success success

TestingConformanceofEJB3EnterpriseApplicationServers

275

Client & server-side

application package

Expected behaviour

TestC ase

Client application

path

1. Deploy package

3. Compare results with

expected behaviour

Tool

2. Run client

Deploy command

Log ﬁle

ASConﬁguration

Run client command

4. Print test results

Figure 2: The tool supporting conformance testing.

this behaviour should succeed to indicate requirement

compliance. Similarly, when a requirement prohibits

certain behaviour, the server-side test application im-

plementing this behaviour should fail to indicate re-

quirement compliance. In any case, the server-side

test application should have a test method logging a

message upon invocation. Second, a client application

for the server-side application is designed. The client

application invokes the server-side test method which

logs a message upon invocation. Then, the client ap-

plication and server-side test application are packaged

in a portable archive which is deployed on an applica-

tion server, and the client application is run. Finally,

the test results are compared with the expected be-

haviour. Test results include the messages logged by

the server-side application, as well as error messages

reported by the application server itself.

We extend this approach by treating test cases and

application servers independently of each other. To

facilitate application of the approach we have im-

plemented a tool (Figure 2) which automatically de-

ploys, runs, and analyses results for a set of test

cases and a set of application servers. A TestCase

consists of the packed client and server-side applica-

tions, a path to the client application and the expected

behaviour. An ASConﬁguration (application server

conﬁguration) consists of a deployment command, a

command which extracts and runs the client applica-

tion from the package and a path to the server’s log

ﬁle. For all TestCases and all ASConﬁgurations steps

1 to 4 are performed.

Since test cases do not rely on any application

server they must be portable. In EJB, the portable way

of distributing applications is by packaging the appli-

cation in a portable archive such as a Web Archive

(WAR) or an Enterprise Archive (EAR).

4 MOTIVATING EXAMPLE

To illustrate the approach we show its application for

requirement 5d in Table 1:

The same business interface cannot be both a local

and a remote business interface of the bean. It is also

an error if the

Local

and/or

Remote

annotations are

speciﬁed both on the bean class and on the referenced

interface and the values differ.

Corresponding to the ﬁrst step of the approach, we

ﬁrst develop the server-side application which does

not adhere to the given requirement. For the discus-

sion of the example we focus on violating the require-

ment by means of annotations. The requirement dis-

tinguishes between the locations where a business in-

terface can be declared: on the bean class or on the

business interface. This gives rise to four distinct

ways to construct a server-side application by means

of annotations such that the ﬁrst part of the require-

ment is violated: both the

Local

annotation and the

Remote

annotation are declared on the bean class; the

Local

annotation is declared on the bean class while

the

Remote

annotation—on the business interface; the

Local

annotation is declared on the business interface

while the

Remote

annotation—on the bean class; both

the

Local

annotation and the

Remote

annotation are

declared on the business interface.

For the sake of an example, we continue with the

case where the

Local

annotation is on the bean class

and the

Remote

annotation is on the business inter-

face. The business interface

BI 5d

is both a local and

a remote interface of the session bean

SB 5d

bean: the

Local

annotation on the bean class exposing the ref-

erenced as a local business interface, while the inter-

face itself is annotated with

Remote

exposing the in-

terface as a remote business interface. This clearly

violates requirement 5d.

@Remote

public interface

BI_5d{

public void

testMethod ();

}

@Stateless

@Local(BI_5d.

class

)

public class

SB_5d

implements

BI_5d{

public void

testMethod (){

System.out.println("testM invoked");

}

Next, we develop the client applications for this

session bean according to the second step of the ap-

proach. Requirement 5d mentions both the local and

the remote business interfaces. Hence, we develop

both a local client and a remote client obtaining eight

distinct test cases in total. We obtain a reference to the

business interface by means of dependency injection

through the

@EJB

annotation.

The local client

LC 5d

is a web application

extending

javax.servlet.http.HttpServlet

and

residing in the same jar ﬁle as the bean application.

The

doGet

method is invoked when the server re-

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

276

ceives a HTTP GET request. The remote client

RC 5d

is a plain Java class:

public class

LC_5d

extends

HttpServlet{

@EJB

private

BI_5d bi;

protected void

doGet(...)

throws

ServletException {

bi.testMethod ();

}

public class

RC_5d{

@EJB

static private

BI_5d bi;

public static void

main(...){

bi.testMethod ();

}

We package the client application together with

the server-side application and deploy the package

onto the GlassFish 3.1.2 application server. The lo-

cal client application and server-side application are

packaged in a Web Archive (WAR). The remote client

application and server-side application are packaged

together in a Enterprise Archive (EAR).

Next, we run the client applications corresponding

to the fourth step of the approach. The local client is

run by submitting a HTTP GET request to the server.

The remote client is run through the appclient pro-

gram which is required to be present for any EJB 3.1

application server.

Finally, we compare the test results with the ex-

pected behaviour as described in the ﬁnal step of the

approach. Since the requirement 5d prohibits cer-

tain behaviour (“It is also an error...”) if the server-

side application conforms to requirement 5d, the test

method should not be invoked. It turns out that de-

ployment fails in the remote client case, therefore,

the test method is not invoked. However, in the lo-

cal client case, we ﬁnd evidence of the invocation of

the test method, i.e., “testM invoked” is present in the

server log. Hence, GlassFish passes the test for the

remote client, but fails the test for the local client.

5 CASE STUDY

To answer RQ2 and RQ3 we apply our approach on

a larger scale.

5.1 Setup

We apply the approach to two “Java EE 6

Full Proﬁle”-compatible application servers: Glass-

Fish 3.1.2, and JBoss AS 7.1.1. Both servers are

tested for conformance to the requirements for the

Session bean’s business interface. The exposure of

client view interfaces through the deployment de-

scriptor is not considered. Hence, only the exposures

of client view interfaces through annotations is stud-

ied. Additional client views and exposure of client

views through the deployment descriptor will be con-

sidered in a follow-up study.

A session bean is either stateful, stateless or sin-

gleton. In our experiments we consider stateless ses-

sion beans only, and the local and remote client view

interfaces of these beans. The requirements for the

session bean’s business interfaces are shown in Ta-

ble 1. We test every requirement with both a Remote

and a Local client whenever the requirement does not

explicitly mention the client view it applies to.

5.2 Results

Answering RQ2 Table 1 presents the results of our

requirements tests. The Requirement column refers

to Table 1 with the client type used between parenthe-

ses. In the

Setup variation

column variations of

a test case’s setup are shown. We abbreviate session

bean’s class to BC and session bean’s business inter-

face to BI. Indication fail means that the test applica-

tion provides evidence that the application server does

not adhere to the speciﬁc requirement, success—that

the test application adheres to the speciﬁc requirement

with respect to the application server.

Of the 21 test GlassFish 3.1.2 fails at eight tests

corresponding to requirements 1, 5b, and 5d. The

JBoss AS 7.1.1 application server fails at two tests

corresponding to requirement 1. In the case of re-

quirements 1 and 5d GlassFish 3.1.2 is inconsistent:

its conformance depends on whether a local or a re-

mote client is used. In the remote case of require-

ment 5d the results even show inconsistencies for dif-

ferent combinations of the

Local

and

Remote

annota-

tions on bean class and/or business interface. In JBoss

AS 7.1.1 no such inconsistencies are found.

5.3 Discussion

We proceed with the discussion of RQ3. We dis-

cuss the implications of the lack of conformance to

requirements 1, 5b, and 5d. To illustrate the effects

of the lack of conformance on developers we quote

StackOverﬂow questions as indications of the devel-

opers’ confusion

and discuss a small use case for

each of the requirements.

Requirement 1. The lack of conformance to re-

quirement 1 makes developers doubt whether a busi-

None of the authors has been involved in asking or an-

swering these questions.

TestingConformanceofEJB3EnterpriseApplicationServers

277

ness interface must or must not extend

EJBObject

EJBLocalObject

Prohibition of

EJBObject

and

EJBLocalObject

extension is most crucial for appli-

cations ported from EJB 2.x, as EJB 2.x beans are

required to extend

EJBObject

EJBLocalObject

Use Case. Alice wants to migrate a set of re-

mote EJB applications from JBoss AS to GlassFish.

As both JBoss AS and GlassFish are “Java EE 6 Full

Proﬁle”-compatible application servers she attempts

to deploy the applications on GlassFish. To her sur-

prise the deployment on GlassFish fails while the ap-

plications deploy and run correctly on JBoss AS.

Requirement 5b. GlassFish does not conform to

requirement 5b: when a bean class has multiple inter-

faces it allows implicit designation of all implemented

interfaces as Local or Remote. As a results, confused

developers ask Can an EJB bean implement multiple

interfaces?

Moreover, the portability of the applica-

tion is lost.

Use Case:. Bob is a novice EJB developer who

recently became proﬁcient with GlassFish. Work-

ing with GlassFish Bob has learned that it is possi-

ble to expose all interfaces of a bean as local busi-

ness interfaces by adding the

Local

annotation with

no arguments, and used this to his advantage. Char-

lotte, Bob’s senior, wants to gain more understand-

ing of the application Bob is developing by calculat-

ing business-method-based metrics (Roubtsov et al.,

2013). The metric tool she uses presents alarming re-

sults when analysing Bob’s application. After a while,

they ﬁnd out that the metric tool, designed based on

the EJB speciﬁcation, does not detect the expected

number of business methods. As GlassFish exposes

more business interfaces than the requirements pre-

scribes, the calculated metrics are invalid.

Requirement 5d. Requirement 5d states that busi-

ness interface should not be annotated with both the

Local

and

Remote

annotations. However, this incon-

sistent annotation is erroneously accepted by Glass-

Fish. Access via a local client seems to completely

disrespect the requirement. In the remote case adher-

ence even depends on where the

Local

and

Remote

annotations are speciﬁed. Additionally, developers

may feel that a single business interface for both local

and remote access is more convenient

. Nevertheless,

local interfaces pass objects by reference and remote

interface pass objects by value. Evaluation of objects

becomes ambiguous when an interface is both local

and remote. Hence, it is important to separate local

and remote interfaces.

Use Case. Derek has developed a local EJB ap-

http://goo.gl/awxc3G.

http://goo.gl/R8iDKT.

http://goo.gl/A8FbTJ.

plication which is to be deployed on GlassFish. The

business interface of this application is annotated as

Local

. Derek receives a request for remote access to

the functionality of a bean implementing the business

interface. Thus, Derek decides to expose the func-

tionality of the bean by annotating the bean with the

the

Remote

annotation. After successfully testing the

application Derek re-factors his code such that both

annotations are on the bean class. Testing the applica-

tion again reveals that the remote clients can no longer

access the bean for no apparent reason.

The three StackOverﬂow questions referenced

above have been answered after 2254, 166 and 80

hours, i.e., signiﬁcantly longer than the median time

of 11 minutes reported for StackOverﬂow(Mamykina

et al., 2011) or even the median time of 47 minutes

reported for a subcommunity of StackOverﬂow ded-

icated to R, a popular statistics software (Vasilescu

et al., 2014). This suggests that questions pertaining

to conformance (or lack thereof) of the EJB 3 applica-

tion servers to the EJB speciﬁcation are more complex

than the “average” StackOverﬂow questions.

6 RELATED WORK

Portability problems in EJB have been identiﬁed al-

ready for EJB 1.0 (Dorda et al., 1999): the portability

problems have been caused by the vagueness of the

EJB 1.0 speciﬁcation. Portability issues in EJB 2.0

are discussed in (Roeser, 2005), and are attributed to

different deployment descriptors and container/server

conﬁgurations amongst application servers (Krastev

and Galletly, 2003). Unfortunately, in both cases dis-

cussion stays at the anecdotal level: evidence of porta-

bility problems is provided, but the evidence is ob-

tained by manual inspection. Therefore, complete-

ness of the approach or its automation remain outside

the discussion. As opposed to these results we present

a structured approach based on the EJB-speciﬁcation

for testing portability of application servers. While

in the case study we focus on the most recent EJB

3.1 speciﬁcation and two application servers (Glass-

Fish and JBoss AS), the methodology can be applied

to other versions of the speciﬁcation or other applica-

tion servers.

Outside of the portability domain several discrep-

ancies between the EJB 3.1 speciﬁcation and the ap-

plication server GlassFish, the reference implemen-

tation, were found in (Serebrenik et al., 2009). How-

ever, this research focused on sequence diagram re-

construction for EJB-based applications with inter-

ceptors and also merely reported on the discrepancies

rather than presenting an approach for the systematic

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

278

discovery of those. As opposed to reconstructing a se-

quence diagram for one business method (Serebrenik

et al., 2009), subsequent research on reverseengineer-

ing sequence diagrams for EJB-based applications

with interceptors (Roubtsov et al., 2011; Roubtsov

et al., 2013) advocated interceptor-based metric (sce-

nario depth) and large-scale empirical studies of the

interceptor use. Speciﬁcally, for large-scale empiri-

cal studies of the use of business method interceptors

one ﬁrst has to identify all business methods within

a given project as only invocations of business meth-

ods can be intercepted by business method intercep-

tors. Identiﬁcation of business methods, however, re-

quires checking whether a business interface adheres

to the business interface requirements shown on Ta-

ble 1. As shown in Table 1 adherence to require-

ments, and hence, the distribution of scenarios’ depth

is implementation dependent. Hence, when compar-

ing the way interceptors are used in a given system

with benchmark systems one should take the deploy-

ment application server into account.

7 CONCLUSION

In this paper we presented a testing approach for ver-

ifying requirements for EJB applications and EJB ap-

plication servers with focus on portability. Testing

portability required a novel approach to recovering

information from EJB application servers. Using the

approach developed we have established discrepan-

cies between the application server behaviour as pre-

scribed by the speciﬁcation and as implemented in

two popular “Java EE 6 Full Proﬁle”-compatible EJB

application servers, GlassFish and JBoss. Lack of

conformance to the EJB speciﬁcation compromises

the portability of the EJB applications, deviates from

the portability philosophy of Java, leads to unex-

pected behaviour. Furthermore, lack of conformance

may cause semantic differences between application

servers, limiting program understanding and hinder-

ing the learning process of novice EJB developers.

A number of directions can be considered as fu-

ture work. The ﬁrst direction is related to application

of the approach developed to additional requirements

and application servers, and using the information ob-

tained. Application of the approach to additional re-

quirements and application servers will allow us to

obtain a more comprehensive picture of portability in

EJB 3.1. Analysis tools and techniques based on the

EJB speciﬁcation such as (Sutii et al., 2013) can be

adapted to speciﬁcs of different application servers.

Second, the approach itself can be fully automated

by generating test cases based on formally speciﬁed

requirements.

REFERENCES

Dorda, S. C., Robert, J., and Seacord, R. (1999). Theory and

Practice of Enterprise JavaBean™: Portability. Tech-

nical Report CMU/SEI-99-TN-005, CMU.

EJB 3.1 Expert Group (2009). EJB 3.1 Expert Group. JSR-

318 Enterprise JavaBeans, Version 3.1.

Hamilton, M. A. (1996). Java and the shift to net-centric

computing. Computer, 29(8):31–39.

International Software Testing Qualiﬁcations Board (2011).

Certiﬁed Tester Foundation Level Syllabus. Interna-

tional Software Testing Qualiﬁcations Board. version

2011.

Kounev, S., Weis, B., and Buchmann, A. (2004). Perfor-

mance tuning and optimization of J2EE applications

on the JBoss platform. Journal of Computer Resource

Management, 113:40–49.

Krastev, A. and Galletly, J. (2003). Do we really need EJB?

In CompSysTech, pages 190–195. ACM.

Mamykina, L., Manoim, B., Mittal, M., Hripcsak, G., and

Hartmann, B. (2011). Design lessons from the fastest

Q&A site in the West. In CHI, pages 2857–2866.

ACM.

Matena, V. and Harper, M. (1998). Enterprise JavaBeans.

version 1.

Roeser, T. (2005). Portierbarkeit von J2EE-

basierten Applikationen am Beispiel des mobilen

Ged¨achtnishilfesystems MEMOS.

Roubtsov, S. A., Serebrenik, A., Mazoyer, A., and van den

Brand, M. G. J. (2011). I2SD: Reverse Engineering

Sequence Diagrams from Enterprise Java Beans with

Interceptors. In SCAM, pages 155–164. IEEE.

Roubtsov, S. A., Serebrenik, A., Mazoyer, A., van den

Brand, M. G. J., and Roubtsova, E. (2013). I2SD:

Reverse Engineering Sequence Diagrams from En-

terprise Java Beans with Interceptors. IET Sofware,

7(3):1–17.

Serebrenik, A., Roubtsov, S. A., Roubtsova, E. E., and

van den Brand, M. G. J. (2009). Reverse engineer-

ing sequence diagrams for Enterprise JavaBeans with

business method interceptors. In WCRE, pages 269–

273. IEEE.

Sutii, A., Roubtsov, S. A., and Serebrenik, A. (2013).

Detecting dependencies in enterprise javabeans with

squavisit. In WCRE, pages 485–486. IEEE.

Vasilescu, B., Serebrenik, A., Devanbu, P. T., and Filkov, V.

(2014). How social Q&A sites are changing knowl-

edge sharing in open source software communities. In

CSCW. ACM.

Xian, F., Srisa-an, W., and Jiang, H. (2006). Investigat-

ing throughput degradation behavior of java applica-

tion servers: a view from inside a virtual machine. In

PPPJ, pages 40–49. ACM.

TestingConformanceofEJB3EnterpriseApplicationServers

279
