WCFB: A Wide Block Encryption for Large Data Sets
Andrey Jivsov
Symantec Corporation, 350 Ellis Street, Mountain View, CA 94043, U.S.A.
Abstract. We define a model for applications that process large data sets in a way
that enables additional optimizations of encryption operations. We show how to
take advantage of identified characteristics with a new construction of a strong
pseudo-random tweakable permutation, WCFB, that is built with 2m + 1 block
cipher invocation for m cipherblocks, plus ≈ 5m XOR operations.
WCFB mode has simple structure and is fast in practice. WCFB can benefit from
repeated operations on the same wide block and known plaintext.
1 Introduction
Systems that process large data sets often have the following characteristics:
(A) The data set is read and modified in smaller portions, or blocks, located at any
index in the data set. This applies more to database storage, disk volumes, or cloud
storage, as opposed to small files or short messages. An example of a block here is
a sector on a disk volume.
(B) On average multiple blocks are accessed in one request. This might be because
blocks are organized into clusters at a higher level of the system and a cluster is a
typical unit that is processed.
(C) While data integrity is important, a common requirement is no expansion of the
block size, i.e. due to authentication tags. For example, such an expansion prop-
erty would be unsuitable in many plug-in style application, when the encryption
layer is added as an intermediate layer to a system that doesn’t support integrity
funcionality at that layer.
(D) Encryption of known plaintext is common. For example, consider the encryption
of newly allocated blocks, which are filled with zeros. In general, we are trying to
take advantage of any caching of intermediate results.
(E) We are interested in the performance of the entire encryption layer on general-
purpose CPUs. We count not only the block-cipher calls, but all other operations
including these that simply ”mix” data.
Examples of a system that fit the above criteria are database systems, cloud storage,
whole disk, volume, or transparent file encryption products; content streaming appli-
cation, and network proxies. The above characteristics of the system define a target
application, which performance we seek to optimize here.
In this paper we focus on tweakable wide block encryption as a solution to data
confidentiality in large data sets.
Jivsov A..
WCFB: A Wide Block Encryption for Large Data Sets.
DOI: 10.5220/0004968900750082
In Proceedings of the 11th International Workshop on Security in Information Systems (WOSIS-2014), pages 75-82
ISBN: 978-989-758-031-4
Copyright
c
 2014 SCITEPRESS (Science and Technology Publications, Lda.)

The concrete contribution of this paper is a practical encryption mode WCFB,
which stands for Wide Cipher FeedBack, that is optimized for the above requiremens.
Discussion of practical results calls for further clarification of the operating environ-
ment in which the implementation of an encryption algorithm is executing. We assume
that the operating environment has the following characteristics:
(a) the block cipher (BC) performance is fast
(b) given a generic GF(2
n
) multiplication (GF2mul), the time to perform 2 GF2mul is
comparable to 1 BC
(c) XOR is fast.
(See section 2 for notations used above; the reason for comparing BC with GF2mul
will be explained in section 3). Our operating environment is justified by the expectation
that large data set should be processed on powerful systems with some level of hardware
support to make BC fast.
2 Notations
In this paper we consider a new wide block cipher, as compared to the (underlying)
block cipher. The size of the wide block cipher is l = n ∗ m bits. In practical applica-
tions the l/8 ≥ 512 bytes, is a power of two, and is usually a fixed value for a given
operating system/hardware/data set. Wide block ciphers work with an underlying block
cipher, such as AES-128. One such underlying block cipher call is identified by one
BC in section 1. Each wide block P, C is represented by m n-bit blocks, which are
denoted as P
i
, C
i
: i ∈ [0, m − 1]. P
i
denotes the block of the plaintext such that
P = P
0
||P
1
|| · · · ||P
m−1
, with similar definition for the C. P
0
refers to the block that
occupies the lowest n/8 bytes of the memory range in which P resides. This indexing
is known as a little-endian notation.
The WCFB mode is defined with the following types of operations: the underlying
block cipher encryption or decryption and GF(2
n
) additions (XOR or ⊕).
WCFB is a secret key permutation. Besides using underlying block cipher with its
key k, it has a set of m + 1 derived subkeys k
i
, each n bits long regardless of the key
k. There is a key schedule for k that the underlying block cipher uses and a set of the
subkeys k
i
(which is can be viewed as some other key schedule).
By the data set we mean a set of logically related wide blocks P, C. The same key
k will be used for a given data set. An encrypted storage disk is an example of a data
set.
A tweak is denoted by T . Typically it is an offset in a data set, or a block index.
Description of loops in iterative algorithms use compact notation defined next. All
loops in this paper are based on the default iteration from 0 to m − 1 in the ascending
direction. The default loop is for i = 0, 1, · · · , m − 1, inclusive; it is noted as ∀i y.
The same loop in the reverse direction is noted as ∀i x. When the range of indexes
is different from the default one, it is always explicitly noted. When the direction is
omitted, such as in ∀i, it is not important (and so the random order is possible).
We use the following symbols, respectively, for a definition, equality, assignment:
.
=, =, ←.
76

3 Comparison with Other Modes
Many wide encryption modes were introduced during the first decade of 2000. Modes
with provable security are CMC [1], EME2 [2], PEP [3], TET [4], HEH [5], XCB [6],
HCTR [7], HCH [8]. EME2 is standardized in the IEEE 1619.2 section ”Wide-Block
Encryption” of the IEEE P1619 standard.
There are modes that do not offer security proofs, such as Elephant+CBC [9], modes
that do not offer the benefit of a full block permutation such as XTS [10] (XTS is stan-
dardized by the IEEE 1619 standard and by NIST), and there are even uses of standard
CBC for wide block encryption, motivated by users’ dissatisfaction with performance
of more secure schemes. Considering the use of wide encryption modes in whole disk
encryption products, the overhead of the the crypto code appears as substantial to end-
users, especially with now common solid-state storage media. We are not aware of any
existing whole disk product that offers a wide block encryption mode.
An overview of current modes is provided in the Table 1 of HEH [5]. Counting two
GF2mul as one BC call, the best mode under this accounting is CMC [1] at 2m + 1
BC operations for a 2-key variant and 2m + 2 for a 1-key variant. [5] lists HEHfp as
m + 1 BC, 2(m− 1) GF2mul, which by our accounting is equivalent to 2m BC, but it is
ignoring other operations that are more complex than XORs. Most importantly, it does
not account for additional 2(m − 1) GF2mul that have one of the multiplication factors
random but fixed per the data set. This processing is similiar to EME2’s, discussed later
in this section. In addition, HEHfp includes (m−1) · ⊗ x operations. Finally, it has ≈ 6
XORs per BC.
This brings us back to CMC. Among positives, CMC has m + 1 BC and a lean
mixing layer (3 data-dependent XORs). On the other hand, CMC has two key schedules
(for m + 1 BC) and is unable to take any advantage of caching. CMC’s first encryption
pass is performed in CBC mode with T added at the first step. This denies any benefit
of caching of ciphertexts for known plaintext. CMC has ≈ 3m XORs for the mixing
layer, which is equivalent to WCFB’s XORs on modern architectures, because WCFB’s
2m XORs are data-independent.
Although this may not account for much in practice, two iterations in WCFB are
simple back-and-forth pass over the blocks, with the data from an n-bit block used only
for the adjacent one, for the ideal CPU cache utilization. CMC performs the mirroring
of the block indices between passes.
EME2 mode is close to CMC as a suitable alternative for our operating environment
at 2m+1+m/n BC. EME2 matches WCFB’s caching capability at the first encryption
layer. An implementation optimized for bulk performance will use ≈ 3m XORs, plus
bit operations for m data-dependent GF2mul. One of the factors in these GF2mul is of
special form y(x) = x
i
, so that these m GF2mul can be implemented at a minimum of
2m bitwise shifts and m XORs in a sequential manner. While the sequential process-
ing in EME2 contradicts its main design goal, only a small constant-degree parallelism
(per CPU core) may practically be realizable and this limited parallelism can be ac-
complished with reasonable supporting data structures. Overall, WCFB’s mixing layer
compares well with EME2 and HEHfp: it is a simple XOR sum of n-bit blocks, fully
parallelizable.
77

WCFB is a single-key mode that achieves 2m + 1 BC and ≈ 5m XORs with 2m
of them data-independent. WCFB has excellent caching capabilities under update sce-
narios and other repeated access patterns: in the worst case WCFB saves at least one
encryption during an update (which corresponds to the encrypted T ), while in the best
case WCFB can reuse ciphertexts from m + 1 encryptions of the n-bit plaintext blocks
and T .
WCFB’s only operation is XORs on the n-bit blocks. WCFB has no data-dependent
lookup, and thus offers an exellent protection against side-channel attacks.
Although this is not critical in the defined operating environment, WCFB and CMC
allow full parallelization for 2 out of 3 layers of the encrypt-mix-encrypt processing
within each wide block. Despite not achieving clear 3 out of 3 layer full parallelism,
EME2 allows parallel execution of either block cipher layers.
The security of WCFB is quadratic in the number of queries, a typical boundary in
this category.
Finally, WCFB has the concept of the IV of the data set, which binds the wide block
to a respected data set, a unique feature to WCFB.
4 Our Contribution
Our main goal is to make encryption of large data sets faster in practice. Two contribu-
tions towards this goal are presented here.
First, we defined the target applications and operating environment in such terms
that allow additional optimizations. For example, the wide encryption modes were tra-
ditionally valuing the internal parallelism of the mode, i.e. its ability to process multiple
n-bit blocks within the nm-wide block, however, section 1 asks if the multi-wide-block
parallelism is better concept to exploit the parallelism. We argue that it is the case for
many target applications, and this assumption allows simplification of the mode.
Second, we propose the new mode WCFB, which is a ”tweakable” mode to allow
changes to random ”wide” blocks in an encrypted data set. We describe the WCFB in
details and highlight its advantages for processing large data sets. Some design ideas
employed in WCFB, in particular the ability to cache the ciphertexts or subkeys without
any overhead for this option, are general techniques with applications beyond WCFB.
For the operating environment defined in section 1 WCFB is a wide encryption
mode that has operation count of 2m + 1 BC with a lean mixing layer at ≈ 5mXORs
(see section 3 for the comparison with other modes).
2m + 1 operation count is a reasonable threshold for a tweakable wide encryption
mode of encrypt-mix-encrypt, given that there is a mixing step, a tweak, and an IV that
need to be ”processed”. We show next how caching lowers the metric to 2m or lower
BC.
There are two likely events that can be relied on in this respect: a favorable usage
pattern and low entropy (n-bit) plaintexts.
Consider the update usage pattern, which we define as subsequent decrypt and en-
crypt operations on the same nm-bit block, either performed as a unified operation, or
close enough in time so that some intermediate results can be efficiently re-used. This
78

particular order corresponds to a very common access pattern to encrypted data set:
reading a random block in an encrypted data set, decrypting it, making modifications to
the plaintext, encrypting it, and then writing back at the same position. Further, consider
an application that only adds data to a file. While an application adds a byte at a time
to a file, at the lower level of the operating system the storage can only be accessed in
blocks, given that the storage devices are block devices. If the wide block encryption
is employed for the protection of the disk blocks, even consecutive minor file append
operations will likely result in update (or write only) operations to the same disk block.
The encryption of low-entropy data is quite common in practice as well. Any fixed-
size data set is expected to use a fixed-value padding, typically with zeros. There are
many high-level operations that fall into this category, such as zeroization of data set
blocks; WCFB will only need m BC to accomplish a zeroization request on a wide
block, on par with CBC performance.
WCFB implementations can fully benefit from caching, primarily owing to WCFB’s
ECB-style first pass of encryption.
5 Specification of WCFB
The algorithm is defined in Fig. 1.
The WCFB follows the encrypt-mix-encrypt approach. It is built from two passes
over n-bit blocks that are CFB-like and CBC-like. The mix step corresponds to the XOR
of intermediate n-bit values. WCFB can be viewed as having a double nested structure
WCFB[
ˆ
E[E]], where WCFB is, by and large, defined in terms of
ˆ
E.
The run-time data-dependent input to WCFB encryption or decryption is a wide
block P or C, respectively (steps 5-10), and the corresponding tweak T .
Other input values, κ and IV, are fixed for a given data set; they are pre-processed
during initialization, steps 1-4. Additional values may need to be calculated to take
advantage of caching features of WCFB.
Initialization Vector
WCFB requires a unique IV per data set for the same κ (κ is the shared secret, defined
bellow). The uniqueness v.s. randomness condition on the IV is justified because it is
only used as a value
ˆ
E
k,k
0
(IV) in a standard CFB mode with n-bit block size. IV offers
an additional method to segregate data sets, in addition to using a different κ. Note that
this handling of IV adds robustness in practice because high-quality nounces are not
critical for WCFB.
Key Set up at the Step 2
WCFB mode uses a single symmetric key κ. This key is ”expanded” into the main
key k, and m + 1 subkeys k
i
using a key derivation function KDF(κ, IV, i), where the
parameter i is the index or the returned material. This step is performed once per data
set.
The precise details of the KDF are unimportant, as long as {k, k
0
, . . . , k
m
} are
indistinguishable from selected uniformly at random, even when the attacker has access
79

Fig. 1. WCFB algorithm.
Encryption Decryption
1: C
−1
.
= IV
2: k ← KDF(κ, IV, 0), ∀
m
i=0
i : k
i
← KDF(κ, IV, i + 1)
3: define
ˆ
E
k,k
i
(·)
.
= E
k
(· ⊕ k
i
),
ˆ
E
−1
k,k
i
(·) is its inverse
4: P
m
.
=
ˆ
E
k,k
m
(T )
5: ∀i x: P
0
i
←
ˆ
E
k,k
i
(P
i
) ⊕ P
i+1
6: ∀i : P
i
← P
0
i
7: P
m−1
← P
m−1
⊕ P
0
8: S ←
ˆ
E
k,k
m
(⊕
m−1
i=1
P
i
)
9: P
0
← P
0
⊕ S
10: ∀i y: C
i
←
ˆ
E
k,k
i
(C
i−1
) ⊕ P
i
∀i y: P
i
←
ˆ
E
k,k
i
(C
i−1
) ⊕ C
i
S ←
ˆ
E
k,k
m
(⊕
m−1
i=1
P
i
)
P
0
← P
0
⊕ S
P
m−1
← P
m−1
⊕ P
0
∀i x: P
i
←
ˆ
E
−1
k,k
i
(P
i
⊕ P
i+1
)
to an oracle providing E
k
(·), E
−1
k
(·). The last clause is necessary because the discovery
of one subkey enables an oracle for E
k
(·), E
−1
k
(·), and this may help provide additional
information on other subkeys (a trivial case of k
i
= E
k
(i) is a poor choice for this
reason).
We offer flexibility in selecting the KDF to meet external requirements on key
derivation. In many cases, such as when the shared secret κ is obtained through a
higher-level key exchange protocol, a KDF is already defined. In these cases the KDF
is executed more times to get the needed key material.
Alternatively, we could instantiate WCFB as a two-key mode with some κ
0
and κ
1
and avoid the KDF entirely.
Operation Count
There are 2m + 1 encryptions, plus one encryption of the IV, P
m
=
ˆ
E
k,k
0
(IV), which
is fixed for the data set, and which lifecycle is identical to the lifecycle of the subkeys
k
i
. It should be cached along with the subkeys.
The rest of operations are ≈ 5m XORs and assignments. Each of
ˆ
E includes one
XOR, therefore, only ≈ 3m XORs are data-dependent, and only m block cipher oper-
ations cannot be fully parallelized (as is the case for CBC encryption).
Update scenario, introduced in section 4, allows for the caching of plaintexts/ciphertext
pairs that are shared between decryption of some ciphertext to corresponding plaintext
P , followed by the encryption of a similar to P plaintext, for the same T . In the worst
case, we always can reuse P
m
(Fig.1, step 4) that corresponds to (data-independent) T.
The best case scenario represents changes to a single n-bit plaintext block. The first step
in the encryption direction is identical to CBC decryption, and in this case only one of
the m encryptions on line 5 will be for the new plaintext. Thus, m out of m + 1 prior
n-bit ciphertexts can be reused at the step 5 of encryption in the best case.
Concrete Security
Most of the remaining content of the paper is the proof of (1) in section 6. This upper
bound means that in order to distinguish 512-byte WCFB with AES-128 from a random
80

permutation with probability of 0.5 an attacker must obtain 2
54
plaintext/ciphertexts
pairs, 512 bytes each, assuming that there is no better attack on the AES-128. This is
2 × 2
33
TiB, well above today’s storage capability.
6 Security of WCFB
Theorem 1. For any attacker A that can perform up to q queries consisting of mn-bit
request/response pairs, it holds that the A’s advantage to distinguish a WCFB instanti-
ated with a random PRP operating on a n-bit domain from a random tweakable PRP
operating on a nm-bit domain has the following upper bound:
Adv
±
f
prp
WCFB[Perm(n)]
(q) < 1.5q
2
(m + 1)
2
2
−n
(1)
The theorem means that when we instantiate WCFB with an ideal primitive mod-
eling a block cipher, we get the insecurity directly attributed to WCFB as specified in
(1).
Other related ”advantage notions” can be obtained from (1) by plugging (1) into in-
equalities that were proven to hold for wide encryption modes in general. For example,
if WCFB is instantiated with a block cipher, we use results from (1) as follows:
Adv
±
f
prp
WCFB[E]
(t, q) < Adv
±
f
prp
WCFB[Perm(n)]
(q) + 2Adv
±prp
E
(t
0
, q) (2)
(2) comes from the [1], where we refer the reader in the interest of saving space.
The result of theorem 1 is that WCFB provides birthday-bound security in terms
of the underlying block cipher, typical boundary for wide encryption modes. The proof
is constructed by showing that inner operations of the WCFB behave as PRF when
the number of queries q is bound, provided that the m-bit block cipher is modeled as
a PRF. Under these bounds the insecurity is the probablilty to distinguish inner PRFs
from a random function. The inner probalbilities are combined with the distinquishing
advantage of PRP v.s. PRF to arrive at (1). The proof is provided in the full version of
this paper.
References
1. Halevi, S., Rogaway, P.: A tweakable enciphering mode. In Boneh, D., ed.: Advances in
Cryptology - CRYPTO 2003. Volume 2729 of Lecture Notes in Computer Science. Springer
Berlin Heidelberg (2003) 482–499
2. Halevi, S.: Eme*: Extending eme to handle arbitrary-length messages with associated data.
In Canteaut, A., Viswanathan, K., eds.: Progress in Cryptology - INDOCRYPT 2004. Volume
3348 of Lecture Notes in Computer Science. Springer Berlin Heidelberg (2005) 315–327
3. Chakraborty, D., Sarkar, P.: A new mode of encryption providing a tweakable strong pseudo-
random permutation. In Robshaw, M., ed.: Fast Software Encryption. Volume 4047 of Lec-
ture Notes in Computer Science. Springer Berlin Heidelberg (2006) 293–309
4. Halevi, S.: Invertible universal hashing and the tet encryption mode. In Menezes, A., ed.: Ad-
vances in Cryptology - CRYPTO 2007. Volume 4622 of Lecture Notes in Computer Science.
Springer Berlin Heidelberg (2007) 412–429
81

5. Sarkar, P.: Improving upon the tet mode of operation. In Nam, K.H., Rhee, G., eds.: Infor-
mation Security and Cryptology - ICISC 2007. Volume 4817 of Lecture Notes in Computer
Science. Springer Berlin Heidelberg (2007) 180–192
6. McGrew, D., Fluhrer, S.: The security of the extended codebook (xcb) mode of operation.
In Adams, C., Miri, A., Wiener, M., eds.: Selected Areas in Cryptography. Volume 4876 of
Lecture Notes in Computer Science. Springer Berlin Heidelberg (2007) 311–327
7. Wang, P., Feng, D., Wu, W.: Hctr: A variable-input-length enciphering mode. In Feng, D.,
Lin, D., Yung, M., eds.: Information Security and Cryptology. Volume 3822 of Lecture Notes
in Computer Science. Springer Berlin Heidelberg (2005) 175–188
8. Chakraborty, D., Sarkar, P.: Hch: A new tweakable enciphering scheme using the hash-
encrypt-hash approach. In Barua, R., Lange, T., eds.: Progress in Cryptology - INDOCRYPT
2006. Volume 4329 of Lecture Notes in Computer Science. Springer Berlin Heidelberg
(2006) 287–302
9. Ferguson, N.: Aes-cbc + elephant diffuser: A disk encryption algorithm for windows vista
(2006)
10. Martin, L.: Xts: A mode of aes for encrypting hard disks. Security Privacy, IEEE 8 (2010)
68–69
82
