Using Abductive and Inductive Inference to Generate Policy

Explanations

Fabio Marﬁa

DEIB Department of Electronics, Information and Bioengineering, Politecnico di Milano, Milan, Italy

Keywords:

Policy Explanation, Access Control, Policy Languages, Reasoning.

Abstract:

Providing reliable explanations for the causes of an access response represents an important improvement of

applications usability and effectiveness, in a context where users are permitted or denied access to resources.

I present an approach composed by two different procedures, both relying on OWL-DL and SWRL Rules,

in order to generate policy explanations. The ﬁrst procedure makes use of OWL Explanation and abductive

reasoning. The second uses an algorithm of Association Rule Learning to identifying attributes and states

arising together with policy privileges, in an inductive way. The PosSecCo IT Policy language is used in

the present paper for representing the policies, but the approach is general enough to be applied in other

environments as well.

1 INTRODUCTION

Policies are a widespread approach for protecting

users privacy and security, and for allowing or en-

forcing users to abide by different norms and laws.

More and more complex and distributed scenarios are

requesting access control solutions, in the last years,

where a centralized framework is required to manage

a large set of functionalities related to policies. Those

functionalities include policy editing, storing, harmo-

nization, and decision making.

The more such a framework grows in complex-

ity, the more difﬁcult is for a common user to real-

ize what are the inner workings that result in speciﬁc

policy-dependent behaviors, as, e.g., an access deny

after a speciﬁc datum is requested. Also, even if the

data consumer is not a user, but, e.g., a software, any

chance to better understand speciﬁc outputs would be

appreciated by developers of applications with adap-

tive functionalities. Such applications have grown

more and more during the last years.

Providing an explanation together with a policy

decision would represent a useful service in complex

or distributed scenarios, even if not in every of them.

In fact, there are different cases in which the disclosed

information can be used to support illicit access to re-

sources. Anyway, it is easy to identify many environ-

ments in which the chance of returning valid policy

explanations would represent a signiﬁcant improve-

ment of the technology effectiveness and ease in its

whole.

I present an approach in this paper where OWL-

DL, SWRL Rules, OWL Explanation (Horridge et al.,

2008) and Association Rules (Agrawal et al., 1993)

are used in order to generate reliable explanations, ei-

ther in formal or natural language, about the causes

of an access permission or deny. The present work

makes use of the PoSecCo policy management frame-

work (Basile et al., 2012), but the approach is gen-

eral enough to be applied to other policy languages as

well, provided some constraints (see section 6).

The approach is based on two different logic pro-

cedures: the ﬁrst is an exact method based on abduc-

tive inference, where OWL Explanation is used in or-

der to identify the policies that are involved in a spe-

ciﬁc decision. The second is a probable method based

on inductive inference, where it is tried to identify,

between the theorems, the ones that characterize the

identities that have access to speciﬁc resources.

While the ﬁrst approach usually results in more re-

liable explanations, there is to notice that the number

of policies involved in a decision, in complex envi-

ronments, can be so high that the explanation can not

be always read by a common user with ease. So, the

second approach can be applied instead: attributes or

facts that distinguish the identities that are able to ac-

cess to speciﬁc resources can be identiﬁed. That gives

to a policy explanation tool the ability to explain why

an access permission or deny is returned without di-

rectly taking into account the policies involved.

457

Marﬁa F..

Using Abductive and Inductive Inference to Generate Policy Explanations.

DOI: 10.5220/0005116004570462

In Proceedings of the 11th International Conference on Security and Cryptography (SECRYPT-2014), pages 457-462

ISBN: 978-989-758-045-1

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 1: PoSecCo IT Policy classes related to authoriza-

tions and roles.

For instance, if every identity that can access to

a resource R is also the subject of a theorem T, and

a user U access request to R results in a deny, and

U is not subject of T, a reason why U can not ac-

cess to R could consist in the fact that he/she does

not present the peculiarity T, or something factually

linked to that. The identiﬁcation of theorems as T is

done with an algorithm of Association Rule Learning.

Probable explanation should be always considered

cum grano salis by a user and it should be preferred

to exact explanation only in environments where ab-

ductive inference is an unsuitable solution, according

to the principle that a probable answer is better than

no answer at all.

The paper proceeds as follows: the PoSecCo en-

vironment is presented in section 2, together with the

PoSecCo IT Policy tool for representing policies. A

procedure for inferring all the proper access privileges

and states from a collection of axioms, policies and

facts is described in section 3. The abductive gener-

ation of explanations is described in section 4, while

the alternativeinductiveprocedure is described in sec-

tion 5. Applicability of the approach to other lan-

guages is discussed in section 6. Related work is pre-

sented in section 7, and future work in section 8.

2 POLICY REPRESENTATION

PoSecCo is a policy managementenvironment that al-

lows the design of rules for access control at different

levels of abstraction. For the purposes of this paper,

only the PoSecCo IT Policy level is taken into con-

sideration (Neri et al., 2013). PoSecCo IT Policy al-

lows the speciﬁcation of Identity-Based Access Con-

trol (IBAC) and Role-Based Access Control (RBAC).

In such level of abstraction, a rule

(ITSystemAuthorization

) is a quadruple of the

form P = hµ, π,ρ,σi, where:

• µ is an identity (ITSingleId

), a group of identities

(ITGroupId) or a role (ITAuthzRole);

• π is a privilege (ITPrivilege

);

• ρ is a resource or a group of resources

(ITResourceObject

);

• σ is the sign of the rule (positive or negative).

An identity can be assigned to one or more roles;

furthermore, a role can be speciﬁed as a subset of

another role, allowing to generate role hierarchies

(ITRoleAuthorization

). The cited PoSecCo IT Policy

classes are represented in Figure 1.

3 INFERRING ACCESS

PRIVILEGES

In order to generate reliable explanations for access

responses, it is necessary to have an OWL-DL ontol-

ogy Γ in which all the access privileges can be cor-

rectly inferred. In order to do so, the subsequent steps

are foreseen:

1. Collection of all the necessary axioms in a set T ,

as a TBOX ontology;

2. Policy design, and collection of the policies in an

ABOX set A;

3. Verbose descriptions, in the form of OWL annota-

tions, are added to A; they are necessary for gen-

erating natural language responses;

4. SWRL Rules, generatedin order to infer all access

privileges, are added to A;

5. States of facts are added to A;

6. The ﬁnal ontology is obtained as Γ = T ∪ A.

One step is described deeper in the the subsequent

subsection: it is step 3 about verbose annotations.

3.1 Verbose Annotation

When the policy design is done, policies and at-

tributes can be manually enriched with special anno-

tations in order to generate the explanations in natural

language, and as much clear as it is possible. In order

to do this, the subsequent vocabulary of OWL anno-

tations is deﬁned:

•

IT EXPL rule description

: it represents a ver-

bose description of a security rule.

•

IT EXPL role auth description

: it represents

a verbose description of a role assignment to an-

other role or an identity.

•

IT EXPL identity description

: it represents a

verbose description of an identity.

SECRYPT2014-InternationalConferenceonSecurityandCryptography

458

•

IT EXPL role description

: it represents a ver-

bose description of a role.

•

IT EXPL attribute description

: it represents

a verbose description of an identity attribute.

4 ABDUCTIVE EXPLANATION

After the process described in section 3, the procedure

of policy decision reduces itself to a task of checking

whether Γ logically entails two speciﬁc statements.

They are the two propositions explicitly asserting that

the requesting user can do and can not do the re-

quested action with the requested resource. I call

them respectively α and ¬α. The subsequent condi-

tion must occur for an access to be permitted:

Γ |= α.

While the subsequent conditions must occur for an

access to be denied:

Γ |= ¬α∨ (Γ 6|= ¬α ∧ Γ 6|= α) .

So, if the can do statement logically follows from Γ

the access is permitted. If the can not do statement

logically follows from Γ , or no logical consequence is

found (no information available), the access is denied.

Three different cases can be identiﬁed then:

1. An access response is returned after a can do

statement logically follows from the ontology

(Γ |= α);

2. A deny response is returned after a can not do

statement logically follows from the ontology

(Γ |= ¬α);

3. A deny response is returned after no logical con-

sequence is found (Γ 6|= ¬α∧ Γ 6|= α).

According to which situation happens, a suitable pro-

cedure must be called in order to return a reliable ex-

planation together with the access response. In fact,

while cases 1 and 2 can be managed by the same pro-

cedure, case 3 must be necessarily considered for its

own.

In any situation, the present approach makes use

of OWL Explanation. It is a procedure that is able

to generate one or more justiﬁcations for a theorem

in an OWL-DL ontology. A justiﬁcation is described

as a minimal subset of the ontology that is sufﬁcient

for a speciﬁc inference to hold. It is easy to under-

stand that if a policy or a state of facts is involved in

a speciﬁc access permission or deny, that policy or

state will necessarily appear in the subset of the on-

tology generated as a justiﬁcation for that permission

or deny. That principle is used in order to isolate and

Figure 2: Sample company organogram.

identify the policies that are to be returned in an ex-

planation.

In the two subsequent subsections I present the

two cases separately in which the logical consequence

of α or ¬α is obtained from Γ (section 4.1) or not (sec-

tion 4.2).

4.1 Abductive Explanation from a

Reference Statement

The ﬁrst case taken into consideration is when the

logical consequence of a can do statement is veriﬁed

from Γ and an access response results in a permission,

or the logical consequence of a can not do statement

is veriﬁed from Γ and the response is a deny. I call

such α or ¬α statement reference statement. In order

to return an explanation, the subsequent passages are

done:

1. OWL explanation is used to generating one or

more justiﬁcations for the reference statement in

Γ , every justiﬁcation γ

is put in a set J ;

2. For every γ

∈ J all the rules, role authorizations

and state of facts listed in that justiﬁcation are

identiﬁed and put in a set S

of propositions;

3. All S

sets are examined: if two sets are equal, one

is removed; if a set is a subset of another set, it is

removed;

4. One explanation is generated for every remaining

set, if the explanations are more than one they

are all returned in parallel.

Rules, role authorizations and state of facts can be

presented as an explanation either in the form of an

ontology or a set of natural language propositions. In

the latter case, the verbose description of every single

element has to be retrieved from its

IT EXPL

annota-

tion (see section 3.1).

4.1.1 Example

I deﬁne a ﬁctitious company where every employee is

assigned to a security role that can be of three dif-

ferent types:

Level C

Level B

, or

Level A

. Ev-

ery level inherits every privilege from the underly-

ing roles. So,

Level B

employees have every priv-

ilege that is released to

Level C

role, and a

Level A

UsingAbductiveandInductiveInferencetoGeneratePolicyExplanations

459

employee has every privilege that is released both to

Level B

and

Level C

roles. A sample organogram

of such a company is shown in Figure 2.

Let us consider a policy that allows

Level B

em-

ployees to read the document

managementDocument

IT CEO

, of

Level A

role, wants to read

managementDocument

. The answer is a permit,

inheriting

Level A

all the

Level B

privileges. We

want now to return to

IT CEO

also the causes of such

a response.

OWL Explanation identiﬁes one justiﬁcation with

one rule and two role authorizations:

Rule: all Level B users can read

managementDocument;

Role Authorization: Level A users have

all privileges of Level B users;

Role Authorization: IT

CEO is a Level A

user.

The ﬁnal explanation can be returned with the access

response:

Access permitted for reading

managementDocument. Your access is

granted as a consequence of the

subsequent conditions and policies:

- all Level B users can read

managementDocument;

- Level A users have all privileges of

Level B users;

- You are a Level A user.

4.2 Abductive Explanation with no

Reference Statement

An access deny can occur also when no statement

that explicitly asserts an access permission or deny is

found as a logical consequence of Γ . That implies that

there is no information in Γ about the user rights to ac-

cess to the requested resource, and the access can not

be granted. In that case, there is no theorem on which

apply abductive inference. Anyway, we can however

generate an explanation, relying on the consideration

that explaining why a user can not access to a re-

source can be done showing him/her in what he/she

differ from who can access to the same resource. So,

even if nothing can be said about the requesting user,

we can look at other users that have access to the re-

source and identify what are the differences of role or

attributes between them and the requesting user. So,

an explanation can be generated with the subsequent

passages:

1. Identiﬁcation of the statements that assert that any

subject can do the requested action with the re-

quested resource, between all the privileges that

can be inferred from Γ ; every such α

statement is

put in a set L;

2. OWL explanation is used to generating one or

more justiﬁcations for every α

∈ L, every gen-

erated justiﬁcation γ

is put in a set J ;

3. For every γ

∈ J all the rules, role authorizations

and state of facts listed in that justiﬁcation are

identiﬁed and put in a set S

of propositions;

4. All S

sets are examined: if two sets are equal, one

is removed; if a set is a subset of another set, it is

removed;

5. One explanation is generated for every remaining

set, if the explanations are more than one they

are all returned in parallel;

6. For every explanation, information about the at-

tributes of the user that are involved in the propo-

sitions found is added, in order to make the user

able to compare it against the provided status.

Again, rules, role authorizations and state of facts can

be presented as an explanation either in the form of an

ontology or a set of natural language propositions. In

the latter case, the description of every single element

has to be retrieved from its

IT EXPL

annotation (see

section 3.1).

It is described, in step 6, that the explanation must

be enriched with information about the attributes of

the user that are involved in the propositions found, in

order to make the user able to compare them against

the provided status. For example, if at least one role

authorization appears in the explanation, the user has

to receive its own roles as an additional information;

if an attribute appears in the explanation, the user has

to receive its value for that attribute, or the informa-

tion that the attribute was not found, if that is the case.

Again, verbose explanations require the presence of

IT EXPL

annotations for roles and attributes to be re-

turned.

5 INDUCTIVE EXPLANATION

Abductive explanation can generate usable explana-

tions in many use cases. Anyway, it can be under-

stood that the presence of a considerable number of

policies and states of facts can easily make such types

of explanation unreadable for a common user.

Given that, I propose a different procedure,

that generates probable, but more user-friendly and

policy-independent explanations. The method con-

sists in looking for the attributes and roles that appear

more frequently, between all the theorems inferred

SECRYPT2014-InternationalConferenceonSecurityandCryptography

460

from Γ , together with the access conditions requested.

Those attributes and roles can be presented as proba-

bly necessary conditions for the access to be granted.

The user can use them to understand the causes of an

access response.

More formally, given an access condition α, we

have to look for association rules of the form (π

∧

∧ . ..π

) ⇒ α between all the theorems inferred

from Γ , where π

is a proposition in Γ that express

an attribute, a role, a state of facts about an identity, a

group or an identity template (ITPrincipal).

In order to do that, the Apriori algorithm of Asso-

ciation Rule Learning (Agrawal and Srikant, 1994) is

used for looking for propositions in the ontology that

appear frequently with α. The algorithm starts with

an empty set S. Then:

1. For every pair of propositions σ

= {π

,α}, the

number of ITPrincipal

that are subject in the on-

tology of both the propositions is counted. Every

pair with a number of subjects higher or equal to

a subject count threshold δ

is added to S.

2. Frequent triples are identiﬁed, taking into con-

sideration every τ

i, j

= {π

,π

,α} set, given that

∃σ

∈ S : π

∈ σ

∧ ∃σ

∈ S : π

∈ σ

. For ev-

ery triple τ

i, j

/∈ S, the number of ITPrincipal

that

are subject in the ontology of every proposition is

counted. Every triple with a subject count higher

than δ

is added to S.

3. Frequent quadruples are identiﬁed, taking into

consideration every proposition that appear at

least in a τ

i, j

∈ S triple, and so on... the algorithm

stops when no set is added to S in a step.

From every set {π

,π

,. ..π

,α} ∈ S the association

rule (π

∧ π

∧ ...π

) ⇒ α is identiﬁed. The conﬁ-

dence of every association rule is computed, and ev-

ery association rule with a conﬁdence higher than a

threshold δ

is kept and used to generate the explana-

tion.

Conﬁdence of an association rule is computed as:

conf(X ⇒ Y) =

supp(X ∪Y)

supp(X)

(1)

where supp(X) is the support of the proposition X,

that is, in our case, the number of ITPrincipal

that are

subject of such proposition, divided by the number of

all ITPrincipal

in the ontology.

Every identiﬁed association rule represents a dif-

ferent explanation, in which are expressed the con-

ditions π

,π

,. ..π

that are, with a certain mea-

sured conﬁdence, necessary for the presence of α.

,π

,. ..π

can be expressed in an explanation, even-

tually in a verbose description identifying the corre-

sponding

IT EXPL

annotations, as presented in sec-

tion 3.1.

5.1 Example

I consider again the company in Figure 2, and a policy

that allows

Level B

employees to read the document

managementDocument

IT Manager Marketing

Level C

role, asks for the possibility to read

managementDocument

. The answer is a deny, being

IT Manager Marketing

assigned to a level lower

than

Level B

. In that case, proposition α is:

α =

IT canRead(USER,

managementDocument)

We want to generate a probable explanation, with

threshold set as δ

= 3. The algorithm identiﬁes

the co-occurrence of α with the proposition β with

count 3 in the ontology, where β is:

β =

is a(USER, Level B)

The algorithm adds β to S . No other co-occurrence

count is higher or equal to δ

Conﬁdence of the association rule β ⇒ α is com-

puted as:

conf(β ⇒ α) =

3/9

= 100% (2)

Conﬁdence is 100%, so it is higher or equal to every

that can be chosen. β can be returned then as

an explanation, presented as a probable necessary

peculiarity to be able to read

managementDocument

Access denied while trying to read

managementDocument. Level B role

co-occurs with a 100% confidence with

such privilege, and may be a necessary

condition. Your role is Level C.

6 APPLICABILITY OF THE

APPROACH TO OTHER

POLICY LANGUAGES

Many policy languages are present in the access con-

trol scenario, with different expressiveness and func-

tionalities (Coi and Olmedilla, 2008). Every policy

language relying on Description Logics with a syntax

no more expressive than SH OI N (D) logic, is, in

principle, a language on which the present approach

can be applied, supporting a subset or the whole of its

functionalities.

UsingAbductiveandInductiveInferencetoGeneratePolicyExplanations

461

There is to add that, being involved a reasoning

procedure, one must ensure that all the data types

(e.g. numbers, dates, geo-locations) in the ontology

are correctly managed by an OWL reasoner in order

to generate complete inferences.

7 RELATED WORK

Bonatti, Olmedilla and Peer (Bonatti et al., 2006) an-

alyzed the possibility of generating policy explana-

tions, with the Protune policy language, using abduc-

tive logic procedures. They do not rely on standard

abductive tools, explaining that “There is no support

for explaining inﬁnite failed derivations” (p. 1). The

problem is resolved in the present work with the dif-

ferent approach of reasoning on the identities that are

able to access to speciﬁc resources, and then explain-

ing in what the current user is different, as presented

in section 4.2. Also, they do not deal with the problem

of non user-friendly explanations, while the present

work proposes the different approach of inductiverea-

soning. Furthermore, their approach is not able to

manage speciﬁc data types and data constraint, as,

e.g., expressing that a user must have a minimum age

to access to a resource.

KNOW System (Kapadia et al., 2004) is a method

for providing feedback to users who are denied ac-

cess to resources, using Ordered Binary Decision Di-

agrams. The feedback returned consists in a set of

policy changes, that are sufﬁcient and necessary to

obtain a permission. No verbose explanation is fore-

seen; also, they make use of no reasoning procedure.

8 FUTURE WORK

Computational resources required for OWL reasoning

are usually consistent for large ontologies. Needing

the present work to eventually generate all the pos-

sible privileges and theorems for even large knowl-

edge bases, the performances in a real environment

are to be evaluated, and ways to lower the compu-

tational load are eventually to be identiﬁed. The us-

age of SPARQL-DL query language (Sirin and Parsia,

2007), allowing queries for inferred knowledge, rep-

resents a possible way.

Moreover, the approach must be tested in real en-

vironments also to evaluating interfaces usability and

user satisfaction.

Also, the possibility to expand further the ex-

pressivity of the used policy language, starting from

PoSecCo IT Policy, has to be studied. For example, as

presented in section 6, some languages express obli-

gations to be fulﬁlled by the user. Other advance-

ments must concern general environment states, as,

e.g., generation of policy decisions as a consequence

of current date and time.

Finally, applicability to other policy languages

(see section 6) has to be studied in deep, especially for

the most widespread policy languages, as XACML.

REFERENCES

Agrawal, R., Imieli´nski, T., and Swami, A. (1993). Min-

ing association rules between sets of items in large

databases. SIGMOD Rec., 22(2):207–216.

Agrawal, R. and Srikant, R. (1994). Fast algorithms for

mining association rules in large databases. In Pro-

ceedings of the 20th International Conference on Very

Large Data Bases, VLDB ’94, pages 487–499, San

Francisco, CA, USA. Morgan Kaufmann Publishers

Inc.

Basile, C., Lioy, A., and Paraboschi, S. (2012). The posecco

security decision support system. In Reimer, H.,

Pohlmann, N., and Schneider, W., editors, ISSE 2012

Securing Electronic Business Processes, pages 64–74.

Springer Fachmedien Wiesbaden.

Bonatti, P. A., Olmedilla, D., and Peer, J. (2006). Advanced

policy explanations on the web. In Proceedings of the

2006 Conference on ECAI 2006: 17th European Con-

ference on Artiﬁcial Intelligence August 29 – Septem-

ber 1, 2006, Riva Del Garda, Italy, pages 200–204,

Amsterdam, The Netherlands, The Netherlands. IOS

Press.

Coi, J. L. D. and Olmedilla, D. (2008). A review of trust

management, security and privacy policy languages.

In International Conference on Security and Cryptog-

raphy (SECRYPT 2008). INSTICC Press.

Horridge, M., Parsia, B., and Sattler, U. (2008). Laconic

and precise justiﬁcations in owl. In Proceedings of

the 7th International Conference on The Semantic

Web, ISWC ’08, pages 323–338, Berlin, Heidelberg.

Springer-Verlag.

Kapadia, A., Sampemane, G., and Campbell, R. H. (2004).

Know why your access was denied: Regulating feed-

back for usable security. In Proceedings of the 11th

ACM Conference on Computer and Communications

Security, CCS ’04, pages 52–61, New York, NY, USA.

ACM.

Neri, Mutti, Psaila, Salvaneschi, Verdicchio, and Basile

(2013). D2.5 - IT Policy Meta-Model and Language.

PoSecCo WP2, Business and IT level policies.

Sirin, E. and Parsia, B. (2007). Sparql-dl: Sparql query for

owl-dl. In In 3rd OWL Experiences and Directions

Workshop (OWLED-2007).

SECRYPT2014-InternationalConferenceonSecurityandCryptography

462
