Structuring Documents from Short Texts

The Enel SpA Case Study

Silvia Calegari and Matteo Dominoni

DISCo, University of Milano-Bicocca, V.le Sarca 336 Building U14 I-20126, Milan, Italy

Keywords: XML, Structured Document, Logical Structure.

Abstract: Nowadays, structured documents are marked-up using XML. XML is the W3C standard that allows to give

a meaning about the stored content of a document by the definition of its logical structure. A logical

structure can be exploited to have a focused access to structured documents. For instance, in XML

Information Retrieval, the logical structure is aimed at retrieving the most relevant fragments within

documents as answers to queries, instead of the whole document. The problem arises when it is not possible

to automatically define the logical structure of a document by using the methodologies presented in the

literature. This position paper takes into account this situation and provides a possible solution adopted in

the Enel SpA energy company.

1 INTRODUCTION

Documents usually are based on two main features:

(1) content and (2) structure, respectively. The

content refers to the textual information of a

document, whereas the structure refers to the logical

structure of a document that is based on the analysis

of the content. There are two types of document

structures, i.e., the visible structure and the invisible

structure (Bradley, 2002). The former is related to

the document’s meaning to a human user, e.g., the

organization of a book into chapters, sections, and so

on. The latter is the use of tags to expose the

document’s meaning to a machine, e.g., the XML

(eXtensible Mark-up Language) (XML, 2014)

language for writing documents on the Web.

Our attention is focused on the definition of the

invisible structure of documents. The use of a logical

structure on documents can provide many

advantages. A structured document, for example,

allows us to:

• design sites rather than pages

• publish different portions of data

according to the context

• navigate documents according to their

meaning

• exchange focused information between

systems

An increasingly common way to encode the

structure is through the use of a mark-up language.

The HTML (Hypertext Markup Language) (HTML,

2013) is the first mark-up language used to encode

the content available on the Web. Although HTML

imposes some structure on a content, this structure is

used for presentation purposes and less for

representing the semantics of the text (Lalmas,

2009).

Nowadays, XML is the most widely used mark-

up language that allows to separate the logical

structure of a document from its layout/presentation.

In this way, the document logical structure can be

exploited to allow focused access to documents. For

instance, in the XML Information Retrieval area of

research, the document structure is analyzed with the

aim of improving the user’s request. The aim is to

return the most relevant fragments within

documents, i.e. returning XML elements, such as

sections and paragraphs, instead of whole documents

in response to a query. Such focused strategies are

suited for information repositories containing long

documents, or documents covering a wide variety of

topics.

In the last decade, researchers have focused on

the study of algorithms and tools devoted to

effectively define/access documents marked-up in

XML. Since 2002, a campaign called INEX

(Initiative for the Evaluation of XML Retrieval)

(INEX, 2014) has been established. The goal of

INEX is to provide a forum for the evaluation of

approaches specifically developed for XML

Information Retrieval. Researchears can access the

Calegari S. and Dominoni M..

Structuring Documents from Short Texts - The Enel SpA Case Study.

DOI: 10.5220/0005498800630068

In Proceedings of 4th International Conference on Data Management Technologies and Applications (DATA-2015), pages 63-68

ISBN: 978-989-758-103-8

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

INEX’s document repository to validate their

strategies. A drawback is that such collections store

documents where an XML structure is already

defined mainly by expert users. A challenging

research topic is on the automatic definition of the

invisible structure of a document.

How is it possible to automatically define an

XML structure? Which techniques have been

defined? This position paper gives a brief overview

of some solutions presented in the literature,

althougth some open issues still remain (Section 2).

What happens in the case of short textual

information? To automatically define an XML

structure of documents from short texts is not a

simple task; it means identifying its topics/sub-

topics by overcoming problems of semantics (e.g.,

ambiguity, polisemy, etc.). The strategies of XML

tag extraction are efficient only when long texts are

analyzed. This position paper opens a debate on this

issue and proposes a preliminary solution.

The paper is organised as follows. Section 2

gives an overview of the problem, whereas Section 3

presents a possible solution tested in the Enel SpA

energy company. Finally, in Section 4 some

conclusions are given.

2 OPEN ISSUE

The goal of an XML Information Retrieval system is

to exploit the invisible logical structure of XML

documents to retrieve XML elements, instead of

whole documents, in response to a user query. This

is useful in the case of information repositories

containing long documents, or documents covering a

wide variety of topics (e.g. books, user manuals,

technical documents, etc.). In fact, if a document is

retrieved by a search engine, it does not mean that

the whole content of the document is relevant for a

user. To discover the relevant paragraphs from long

documents can be a time consuming activity. The

goal is to identify the relevant content (i.e., the most

useful XML elements) within a document in order to

support the user search activity.

The general idea is to discover the sequence/list

of sub-topical arguments that occur within one (or

more) main topic(s), with the indication of the

information (i.e., pages, paragraphs) where they

occur. Let us consider the example reported in

(Hearst, 1997), where a 21-paragraph science news

article, called “Stargazers”, is considered. The main

topic is the existence of life on Earth and other

planets. Its content has been described by the

following sub-topics (the numbers on the left side

indicate which paragraphs are defined):

1-3 Intro – the search for life in

space

4-5 The moon’s chemical composition

6-8 How early Earth-moon proximity

shaped the moon

9-12 How the moon helped life evolve

on Earth

13 Improbability of the Earth-moon

system

14-16 Binary/trinary star systems

make life unlikely

17-18 The low probability of non-

binary/trinary systems

19-20 Properties of Earth’s sun that

facilitate life

21 Summary

The ultimate step consists in labelling their

subject matter (Hearst, 1997), with the application of

subtopics classification algorithms (Lewis and

Hayes, 1994).

In the literature, XML Information Retrieval

refers to “passage retrieval” and “structured text

retrieval” (Lalmas, 2009). In passage retrieval, the

aim is to decompose documents into fragments

called passages. Passages are then retrieved as

answers to a query. In structured text retrieval, the

aim is related to the study of models for querying

and retrieving from structured text (Baeza-Yates and

Navarro, 1996) encoded with the use of mark-up

languages, such as XML.

There are several approaches that allow to

identify the relevant passages of a document, such as

fixed-size text windows of words (Callan, 1994),

fixed discourses such as paragraphs (Wilkinson,

1994), text-tiling through the application of a topic

segmentation algorithm (Hearst, 1997), or an

algorithm that finds chains of related terms via a

comprehensive thesaurus (Morris and Hirst, 1991).

These strategies can be summarized into three

phases: (1) tokenization into terms and sentence

sized units, (2) determination of a score for each

sentence sized unit, and (3) detection of sub-topic

boundaries from plotting the sentence units against

their score, thanks to the adoption of a thesaurus.

A drawback is that these techniques are mainly

based on the co-occurrence of words (i.e., approach

based on the frequency); thus, they are efficient only

for the analysis of long texts. Also the text analysis

using a semantic model either based on Latent

Dirichlet Allocation (LDA) (Tian et al., 2010) or

based on Latent Semantic Analysis (LSA) (Klein et

al, 2011) are not efficient in this context as it is

assumed the use of a large repository. The

DATA2015-4thInternationalConferenceonDataManagementTechnologiesandApplications

LDA/LSA are “methods for extracting and

representing the contextual-usage meaning of words

by statistical computations applied to a large

collection of texts” (Klein et al, 2011).

What happens when a large collection is not

available?

What happens in the case of short textual

information?

When there is the need to analyze short texts

without the support of a large repository, the

identification of the corresponding logical structure

can be more complicated. Some aspects have to be

considered:

• sub-topic/topic overlapping

• identification of relevant sub-topic/topic

• semantic issues related to polysemy

and/or homonymy

Let us consider the analysis of a text extracted

from a document in a Power Point format. This

particular type of document is mainly defined for

each slide only by short texts or images. To apply

strategies based on co-occurrence techniques for

discovering sub-topics/topics is not the best

approach.

There is growing interest in using these types of

documents in IT industries. They are used to mainly

synthetize the steps of long and complicated

business processes (e.g., during the training of new

technicians). The presentations of documents in the

Power Point format can be very long and, generally,

they are composed of many topics/subtopics

described only by short texts and images. For this

type of documents it can happen that humans

manually define a visible logical structure of the

presentation, or that the structure is automatically

generated by specific software, although the main

topics are not always explicitly defined. Generally,

the problem arises when there is not a logical

structure of the presentation, where the relevant

topics/sub-topics and the corresponding pages are

indicated explicitly. Let us imagine the scenario of a

call center, where a (new) technician has to identify

the right text (i.e., content of a slide) faster for

answering a user (Section 3). In the case of a long

Power Point document the technician is not able to

help the user in time. In the literature novel

strategies must be defined in order to establish a

solution for the analysis of these particular

documents.

3 A CASE STUDY

The issue is to establish a strategy in order to

retrieve documents and their portions (i.e., passages)

with the intent to support the user’s searches. In

particular, when a user has to find the exact section

related to her/his information needs it becomes a

time consuming activity. The criticality arises when

a long document is composed of short textual

descriptions, lists, images, etc. In this case, the

classic methodologies applied in the literature are

not efficient for defining the logical structure of such

documents (see Section 2).

A real case study has been considered with Enel

SpA company (Calegari et al, 2014) (Calegari and

Dominoni, 2014). The CRM (Customer Relationship

Management) is a crucial software product in the

Enel SpA, as it is the access point to some key

functionalities, such as the creation of energy

contracts for new users, and the identification of

relevant documents used by technicians for people’s

practical problems on the phone. Our attention is

focused on this last case, where technicians need to

discover the contents they are interested in faster and

easier. In fact, technicians have a few minutes to

answer a user. The problem is that the relevant

documents that are useful for the solution to a

specific task are very long, and technicians do not

have time to read and identify the right portion of

the text in 2-3 minutes during telephone assistance.

The definition of a logical structure of the analyzed

document, as the one reported on page 2 (Section 2),

can simplify the technician’s activity. Let us

consider the scenario where, during a phone call,

each technician has the visibility of the

topics/subtopics (with the corresponding pages) of

each document used to specific business processes;

then, thanks to this summarization, the technician is

easily supported in her/his work.

In the Enel SpA the whole set of documents used

in the CRM module is called “script”. A script is a

document in the Power Point format made up of

(about) 80-100 slides. During a phone call it is a

hard task for a technician to identify the right slide

in a few minutes, with the consequence that 90% of

the requests processed via phone have to be

analyzed off-line.

3.1 Additional Information on a

“Script” Document

To obtain a logical structure of a script document,

we have added some information to each slide. Our

attempt is aimed at retrieving the script document

related to the critical business process for assistance

over the phone and the topics/sub-topics with the

corresponding number of pages.

StructuringDocumentsfromShortTexts-TheEnelSpACaseStudy

Siebel CRM 8 (Siebel, 2009) is the CRM used in

Enel SpA. A new service has been integrated in the

native Siebel software in order to create logical

communication between the CRM and the search

engine owned by Enel SpA (the search engine has

been developed within the open source edition of the

Liferay 6.1 C.E. portal (Liferay, 2013) by the

Lucene library (Lucene, 2013)). The idea is very

simple, when a technician is using the CRM for

assistance over the phone, he/she in any instant can

invoke the search engine to retrieve the document

(and its passages) useful for her/his objectives, then

the results are displayed in the CRM layout. In order

to satisfy this requirement, we have developed a

Web Service that is able to logically link the CRM

with the search engine by specific SOAP (Simple

Object Access Protocol) actions via the WSDL

(Web Services Description Language) interfaces,

which is the XML format for describing network

services (Section 3.1.2).

To allow the search engine to identify the right

document and its portions some steps have been

performed. Our solution consists in three main

phases (Section 3.1.1): (1) addition of specific

information on each script document by expert

users, (2) the indexing of these ‘new’ scripts

documents, and (3) a procedure able to read the

index in order to parse the added text in a proper

way for retrieving the passages.

3.1.1 Labelling “Script” Document

Each slide of the script document is labelled with a

specific syntax by expert users. When a script

document is in write mode, then a specific

annotation has to be added in the “page note” section

as follows:

---BEGIN-ANNOTATION---

---section: section_name---

---title: title_name---

---slide: number---

where,

‘

section_name’ is the topic;

‘

title_name’ is the sub-topic;

‘

number’ is the slide number.

If the fields ‘

section_name’ or ‘title_name’ are

empties, then the content of the new slide is related

to the previous ones, where topics or sub-topics are

explicitly indicated. The insertion of this specific

syntax is not a time consuming activity for expert

users. Indeed, these fields are filled in with the

content related to the slide under examination.

Let us consider the example where a portion of the

script ‘Request for change in product Enel Gas’ is

analyzed. The slides are related to the following

arguments (but not limited to): ‘contractual

processes’ and ‘customer needs’, respectively. Then,

the related syntax is:

---BEGIN-ANNOTATION---

---section: Request for change in

product Enel Gas---

---title: contractual processes---

---slide: 10---

---BEGIN-ANNOTATION---

---section: ---

---title: ---

---slide: 11---

…

---BEGIN-ANNOTATION---

---section: ---

---title: customer needs---

---slide: 25---

…

When the writing of a script document is finished,

this document is indexed by using the Lucene

library, as developed in the Liferay portal. The

indexing phase is performed in a standard way

without changing the native code. This assumption

is possible thanks to the addition, for each slide, of

the annotation syntax in the ‘page note’ section. For

the Lucene library the text inserted in the ‘page note’

section is considered a textual description as well as

the one inserted within a slide like content. During a

phone call, a technician finds, by invoking the

search engine, the script document related to the

problem corresponding to the user’s criticality. For

each retrieved script document the output displayed

is its logical structure. By considering the previous

example, we have:

Title:Request for change in product

Enel Gas

- contractual processes 10-24

- customer needs 25-53

…

3.1.2 Web Service:

Interfaces of Communications

The link between the CRM and the search engine

has been provided by the development of a Web

Service via SOA (Service Oriented Architecture)

technology. Then, the communication is performed

by SOAP messages by using XML interfaces. In

detail, the following actions ‘searchScript’ and

‘searchScriptResponse’ have been defined (see

Figure 1).

DATA2015-4thInternationalConferenceonDataManagementTechnologiesandApplications

Figure 1: Web Service interface.

The ‘searchScript’ action sends the request (for a

specific user’s problem) from the client (CRM) to

the provider (search engine); whereas, the

‘searchScriptResponse’ action sends the answer (i.e.,

the script document with its portions/passages) from

the provider to the client.

The I/O actions satisfy a specific XML syntax. By

considering the example of Section 3.1.1, we have:

INPUT

…

<SOAP-ENV:Body>

<ns1:searchScript>

<processList>Product Enel

Gas</processList>

</ns1:searchScript>

</SOAP-ENV:Body>

…

OUTPUT

<soap:Envelope

xmlns:soap="http://schemas.xmlsoap.org/

soap/envelope/">

<soap:Body>

<ns2:searchScriptResponse

xmlns:ns2="http://searchws.kbms.org/">

<title>Request for change in product

Enel Gas</title>

<url>http://kbms2.risorse.enel/document

s/10179/87480/

Request+for+change+in+product+Enel+G

as<url/>

<title>contractual

processes</title>

</paragraph>

<title>customer needs</title>

</paragraph>

</section>

</result>

<error>

</error>

</return>

</ns2:searchScriptResponse>

</soap:Body>

</soap:Envelope>

The input phase is related to the user’s request

during telephone assistance. In detail, a technician

(identified by the tag ‘

userId’) invokes the search

engine with the following query: “Product Enel

Gas”. The query is encoded by the XML syntax

defined in the Web Service interface and sent to the

search engine. Then the index file is analyzed to

retrieve the script documents related to the query.

The list of results are encoded according to the XML

syntax of the Web Service interface and sent to the

CRM. The script document is identified by its title

and url (see tags ‘

title’ and ‘url’), whereas its

passages are identified by the tag ‘

paragraph’. The

definition of the searchScriptResponse in the XML

is realized thanks to the annotation presented in

Section 3.1.1. In fact, when a script document is

considered as relevant for the query, then its content

is parsed by identifying the text related to the

information of its structure. The tag ‘

error’ allows

to monitor eventual communications problems.

At the end, the XML answer will be parsed and

displayed to the technician as presented in Section

3.1.1.

4 CONCLUSIONS

This position paper aims to open a debate related to

the definition of the logical structure of a document.

A logical structure gives a meaning about the

content of a document, and it can be exploited to

retrieve fragments of text, instead of the whole

document. The problem arises when the standard

methodologies, based on frequency analysis or based

on LDA/LSA methods, presented in the literature

are not efficient for identifying portions of the

document, especially in case of the absence of a

large collection. It can happen when long documents

contain short textual information: it becomes very

difficult to establish the topic/sub-topic of the

document without having problems of semantics,

overlapping content, etc.

In this position paper a preliminary solution has

been presented by considering Power Point

documents. This type of document is mainly written

by short texts; thus, it can be a good candidate for

testing the effectiveness of our preliminary

approach. We have defined a very simple syntax that

can be added during the writing of each slide. The

StructuringDocumentsfromShortTexts-TheEnelSpACaseStudy

Power Point document is then indexed with standard

methodologies to be available for a search engine.

This solution is nontrivial, but it is a first attempt to

solve this complex problem for a real case study

where a positive judgement from users has been

obtained. In fact, this solution has been tested with

Enel SpA energy company, where encouraging

preliminary results have been obtained. The scenario

considered is a call center, where a technician has to

identify the right content in a few minutes during

telephone assistance. At the moment, we have

conducted some interviews with technicians who are

using the new service that implements our solution,

receiving positive feedback. In the future, we are

planning to validate the preliminary positive

feedback with robust analysis.

The work presented in this position paper could

open a debate in order to establish new

methodologies aimed at solving the problem related

to the automatic definition of a structure from

documents made up of short textual descriptions,

titles, images, etc. The difficulties arise when the

standard approaches (based on the frequency of text

analysis or based on LDA/LSA methods) presented

in the literature are not efficient for this specific

task. A discussion to improve the preliminary

attempt presented in this position paper that is based

on a specific syntax to annotate this particular type

of documents could stimulate the definition of new

methodologies.

ACKNOWLEDGEMENTS

This paper was written within the Enel SpA Project,

and we wish to thank all the people who worked

with us on the development of the software.

REFERENCES

Baeza-Yates, R. A., Navarro, G., 1996. Integrating

contents and structure in text retrieval. In Newsletter

ACM SIGMOD Record, Volume 25, Issue 1, ACM

New York, NY, USA, 67–79.

Bradley, N., 2002. The book, The XML companion, 3

edition, In Pearson Education limited.

Calegari, S., Dominoni, M., Panzeri, E., 2014. Towards

the Design of an Advanced Knowledge-Based Portal

for Enterprises: The KBMS 2.0 Project. In

Proceedings of the 27th International Conference on

Industrial Engineering and Other Applications of

Applied Intelligent Systems, Part II, IEA/AIE, LNCS,

Springer, VOLUME 8482, ISBN 978-3-31907466-5,

Kaohsiung, Taiwan, pp. 58-67.

Calegari, S., Dominoni, M., 2014. Modeling Ontology-

based User Profiles from Company Knowledge. In

Proceedings of the 6th International Conference on

Advances in Databases, Knowledge, and Data

Applications, DBKDA 2014, ISBN 978-1-61208-334-

6, IARIA, Chamonix, France, pp. 26-29.

Callan, J., 1994. Passage-level evidence in document

retrieval. In Proceedings of the 17th annual

International ACM SIGIR conference on Research and

development in Information Retrieval, Springer-

Verlag New York, Inc., 302–310.

Hearst, M., 1997. TextTiling: Segmenting Text into Multi-

Paragraph Subtopic Passages. In Journal

Computational Linguistics. Volume 23, Issue 1, MIT

Press Cambridge, MA, USA, 33–64.

HTML, 2013. http://www.w3.org/html/

INEX, 2014. https://inex.mmci.uni-saarland.de/

Klein, R., Kyrilov, A., Tokman, M., 2011. Automated

assessment of short free-text responses in computer

science using latent semantic analysis. In Proceedings

of the 16th annual joint conference on Innovation and

technology in computer science education (ITiCSE

'11). ACM, New York, NY, USA, 158-162.

Lalmas, M., 2009. The book, XML Information Retrieval,

In Encyclopedia of Library and Information Sciences.

Taylor and Francis Group.

Lewis, D.D., Hayes, P.J., 1994. Special issue of ACM:

Transactions on Information Systems on text

categorization, Volume 12, Issue 1, ACM New York,

NY, USA.

Liferay, 2013. http://www.liferay.com.

Lucene, 2013. http://lucene.apache.org/core/

Morris, J., Hirst, G., 1991. Lexical cohesion computed by

thesaural relations as an indicator of the structure of

text. In Journal Computational Linguistics, Volume

17, Issue 1, MIT Press Cambridge, MA, USA, 21-48.

Siebel, 2009. http://www.oracle.com/partners/en/knowle

dge-zone/applications/siebel/default-329117.html.

Tian, Y., Wang, W., Wang, X., Rao, J., Chen, C., Ma, J.,

2010. Topic detection and organization of mobile text

messages. In Proceedings of the 19th ACM

international conference on Information and

knowledge management (CIKM '10). ACM, New

York, NY, USA, 1877-1880.

Wilkinson, R., 1994. Effective retrieval of structured

documents. In Proceedings of the 17th annual

International ACM SIGIR conference on Research and

development in Information Retrieval, Springer-

Verlag New York, Inc., 311–317.

XML, 2014. www.w3.org/XML/

DATA2015-4thInternationalConferenceonDataManagementTechnologiesandApplications
