Reasoning about Inconsistency in RE

Separating the Wheat from the Chaff

Anna Zamansky

, Irit Hadar

and Daniel M. Berry

Information Systems Department, University of Haifa, Haifa, Israel

Cheriton School of Computer Science, University of Waterloo, Waterloo, Canada

Keywords: Human Aspects of Software Development, Inconsistency Management, Requirements Engineering,

Requirements Validation Formula.

Abstract: Inconsistency is a major challenge in requirements engineering. Traditionally, software requirements specifi-

cations (SRSs) are expected to be consistent, with the underlying assumption that this consistency is always

achievable. However, with the growing complexity of software systems it has become clear that this assump-

tion is not always realistic. This has led to new paradigms for inconsistency management, acknowledging that

it is not only inevitable, but also even desirable at times, to tolerate inconsistency, even temporarily. However,

for these paradigms to be widely accepted in industry, practicing software engineers must thoroughly under-

stand the nature of inconsistency in SRSs and the strategies for its handling. This paper proposes a research

agenda for preparing practicing software engineers to accept and successfully implement inconsistency man-

agement paradigms. As a first step in this direction, the paper describes an ongoing study in which we design

an intervention into the perceptions of inconsistency for practicing software engineers. The intervention builds

on teaching to them the Zave–Jackson requirements validation formula as an aid for analyzing the types of

inconsistency they face, and conducting an empirical study of the effect of this intervention on their incon-

sistency management.

1 INTRODUCTION

Handling inconsistencies is a key challenge in re-

quirements engineering (RE). Inconsistency in RE is

typically described in the literature as a situation in

which requirements or specifications contain con-

flicting or contradictory descriptions of the expected

behavior of the system or of its domain. Such con-

flicting descriptions may come as a result of, for ex-

ample, conflicting goals between different stakehold-

ers, and changes introduced during the evolution of

the requirements. (Nuseibeh et al., 2000; Nuseibeh et

al., 2001). Traditionally, handling inconsistencies

meant eliminating them all, with the underlying as-

sumption that this elimination is always achievable.

However, with the growing complexity of software

systems it has become clear that this assumption is not

always realistic. Indeed, over the last decades, a more

tolerant approach toward inconsistency has evolved

(e.g., Finkelstein et al. 1994; Nuseibeh et al. 2000;

Finkelstein, 2000; Easterbrook and Chechik, 2001;

Nuseibeh et al., 2001; Spanoudakis and Zisman,

2001; Ernst et al., 2012).

For a successful application of such approaches in

industry, however, a thorough understanding of the

notion of inconsistency by practitioners is required.

Recent research (Hadar and Zamansky, 2015) demon-

strates that this understanding is yet to be achieved.

More specifically, practitioners identify incon-

sistency at times in cases of incompleteness or incor-

rectness, e.g., when an implementation does not meet

the given set of requirements. The ability to distin-

guish inconsistency from other phenomena would en-

able effective inconsistency management in particu-

lar, and RE in general.

Research in RE has produced an explosion of on-

tological distinctions in requirements and their speci-

fications. These distinctions matter for inconsistency

management (Borgida et al., 2015), and therefore can

be recruited for tackling the challenge of incon-

sistency management. One prominent example is the

influential Zave–Jackson validation formula (ZJVF),

which distinguishes Requirements R, Specifications

S, and Domain Assumptions D (Zave and Jackson,

1997). Understanding the ZJVF provides:

1. a framework for partitioning a well formed soft-

ware requirements specification (SRS) into its R,

S, and D parts, and for validating that a system

Zamansky, A., Hadar, I. and Berry, D.

Reasoning about Inconsistency in RE - Separating the Wheat from the Chaff.

In Proceedings of the 11th International Conference on Evaluation of Novel Software Approaches to Software Engineering (ENASE 2016), pages 377-382

ISBN: 978-989-758-189-2

377

built according to S will result in R being met if

the system is run in an environment in which D

holds, and

2. a framework for reasoning about inconsistencies

in an SRS that makes it very clear what the options

are in order to resolve the inconsistencies, so that

that the stakeholders can make rational decisions

about the inconsistencies.

This paper explores the question of whether under-

standing the ZJVF and the ontological distinctions it

imposes help an analyst to understand and manage in-

consistency. Namely, it investigates how understand-

ing the ZJVF and its ontological distinctions may af-

fect analysts’ decision making processes, enabling

them to differentiate between inconsistencies and

other failures, which are currently perceived as incon-

sistency but are actually some forms of incomplete-

ness or incorrectness that need to be managed differ-

ently from inconsistencies. In addition, the paper pro-

poses a research agenda for finding means to guide

analysts’ understanding of inconsistency in RE and

for empirically evaluating these means. We start with

examining the ZJVF.

The next section provides details on the ZJVF and

discusses it in the context of inconsistency manage-

ment in RE. Section 3 presents an outline of experi-

ments we plan to conduct for evaluating the contribu-

tion of the ZJVF for distinguishing between incon-

sistency types and between inconsistency and incor-

rectness or incompleteness, and deciding on the ap-

propriate strategies to manage them, based on this dis-

tinction. Section 4 discusses the potential contribu-

tion of the proposed research agenda and future re-

search steps.

2 THE ZAVE-JACKSON

VALIDATION FORMULA AND

INCONSISTENCY

MANAGEMENT

The ZJVF assumes that part of the world has been di-

vided into an environment, Env, and a system, Sys,

that overlap, i.e., intersect, at their interface, Intf, as is

shown in Figure 1. The Env is the part of the world

that is affecting and is affected by the Sys, and the Sys

is the computer-based system (CBS) that is desired by

the customer who provides the requirements. The el-

ements of the ZJVF, D,S⊢R, are the assertions D, S,

and R:

 D, domain assumptions, is what about the Env that

the Sys is allowed to assume in its execution in the

Env; it is written in the vocabulary of the Env.

 S, specification, is a description of the behavior of

the Sys; it is written in the vocabulary of the Intf,

which is the vocabulary shared by the Env and the

Sys.

 R, requirements, is a description of the customer’s

requirements for the Sys; it is written in the vocab-

ulary of the Env.

The formula says that the Sys is validated to meet its

requirements in the Env if given the holding of D, S

is sufficient to entail R.

Figure 1: The ZJVF Worldview.

A key point of the ZJVF framework is that a well

formed SRS has all of D, S, and R, and each sentence

in the SRS is identifiable as being one and only one

of D, S, and R. Typically, D is given in indicative

mood in present tense in sentences about the Env; S is

given in optative mood in sentences about the Sys us-

ing the verb “shall”; and R is given in optative mood

in sentences about the Env using the verb “will”.

There are other ways to make the distinctions clear.

It should be noted that in the formula D,S⊢R, each

of D, S, and R is an assertion written in a formal lan-

guage so that the required proof can be carried out. S,

being about a program, written in a human-made lan-

guage, is formal in that it is possible to carry out a

formal proof that a program P satisfies S. However,

as statements about the real world, each of D and R is

inherently informal, because we are never certain

about our knowledge of the real world, and what we

believe to be true about the real world is constantly

changing.

Moreover, each of D, S, and R, being an assertion,

can be either consistent (satisfiable) or inconsistent in

the classical logical sense. For example, the logical

formula AA is consistent, but AA is incon-

sistent.

Each of D and R, being an assertion about the real

world, if consistent, can be correct, incorrect, or un-

determined. An assertion A is correct if A is known to

accurately describe the real world. A is incorrect if A

is known to not accurately describe the real world

. A

is undetermined if whether A is correct or incorrect is

not known. For example “The earth is a sphere” is

Note that “incorrectness” can be considered as inconsistency with

the Env. Hence, there is a logic to calling all sorts of problems with

an SRS “inconsistency”.

COLAFORM 2016 - Special Session on Collaborative Aspects of Formal Methods

378

correct, “The earth is a disk” is false, and “There are

gravity waves” was undetermined prior to 2016.

However, as of 11 February 2016, the world learned

that scientists had determined that it is correct (Cho,

2016).

Thus, as opposed to consistency, correctness is

not a logical question, but an empirical one, which

can be answered only by observation. The job of sci-

ence is to determine whether a logically consistent as-

sertion, a.k.a. a theory, is correct. Experiments plus

statistical analysis of the data generated during the ex-

periments allow us to determine to whatever degree

of certainty we need, whether a theory is supported

by the data and thus whether the theory as an assertion

about the real world is correct. Even something re-

garded as correct at some level of detail may not be

correct at another level of detail. For example, “The

earth is a sphere” is correct for most purposes, but for

other purposes, it is incorrect, and instead, “The earth

is an oblate spheroid” is correct.

Finally, S can be OK or not OK with respect to D

and R. S is OK w.r.t. D and R if D,S⊢R and is not OK,

otherwise. In other words, an S, specifying a program

is OK if it causes R to be met when D holds, even if

in another D’, S may not be OK.

Using the above terms, the ZJVF is based on two

assumptions, which are crucial for our purpose:

1. Each of D, S, and R is consistent, so that it is pos-

sible for D and S to be correct and S to be OK.

2. D is correct in the Env, and R can be correct in the

Env

; that is, D accurately describes the existing

Env, and there is nothing in the world that would

prevent R from accurately describing a future Env.

Each way that one or both of the above assumptions

does not hold gives rise to different types of what is

called “inconsistency” in the literature cited in Sec-

tion 1.

The following simple examples demonstrate the

different types.

Consider the following requirements:

R1. The GPA of every student will be reported.

R2:

r2a. The GPA of every student will be reported.

r2b. The GPA of any student who has not taken

any courses will not be reported.

R3:

r3a. The GPA of every student who has taken at

least one course will be reported.

r3b. The GPA of any student who has not taken

any courses will not be reported.

R4. A useful, accurate letter of recommendation will

be generated automatically (i.e., with artificial intel-

ligence (AI)) for each student.

R1 is consistent. R2 is inconsistent. R3 is consistent,

and R4 is consistent.

R1 can be correct. R2 cannot be correct, because it is

inconsistent. R3 can be correct. R4 cannot be correct,

because automatically generating useful, accurate let-

ters of recommendation is beyond the capabilities of

software.

Let us now consider the following domain as-

sumptions:

D1. Each student takes at least one course.

D2. Each student takes zero or more courses.

D1 is consistent. D2 is consistent

D1 can be correct. D2 can be correct. If D1 is correct,

then D2 is correct, but not necessarily the reverse. If

D1 is incorrect, then D2 can still be correct.

Finally, consider the following specifications:

S1. The program shall report a student’s GPA as the

sum of the grades in her courses divided by the num-

ber of courses she took.

S2. For a student who took at least one course, the

program shall report the student’s GPA as the sum of

the grades in her courses divided by the number of

courses she took. For a student who took no courses,

the program shall report that the student’s GPA is not

defined.

S1 can be OK if it is never asked to compute the

GPA of any student who took no courses. S2 is OK

regardless of the number of courses taken by the stu-

dent, whose GPA is to be computed.

Let us systematically explore various SRSs with

these Ds, Ss and Rs, in each case starting with an R,

observing a D, and then picking an S. With each, we

describe the conclusion that an analyst should draw

and what his or her resulting course of action should

be.

Taking R as R1

Suppose that D1 is correct. Then, D1, S1⊢R1, and S1

is OK, even though S1 can be not OK, because given

D1, S1’s not OK state cannot occur.

Suppose, on the other hand, that D2 is correct. Then,

it is not the case that D2, S1⊢R1, in particular because

S1’s not OK state can occur. Also, if indeed there are

students who have not taken any courses, their GPA

cannot be reported as required by R1. In this case, the

customer must be asked to choose between two re-

sponses:

1. If students who have not taken any courses are ex-

tremely rare, then tolerate

that D2 is incorrect

and treat the student who has not taken any

courses manually. This toleration is achieved by

replacing D2 by an admittedly incorrect D1 and

Reasoning about Inconsistency in RE - Separating the Wheat from the Chaff

379

falling back to D1, S1⊢R1.

2. Weaken R1 to an R that does not require that a

GPA be reported for all students and then have

software that checks for a student’s taking zero

courses, such as that specified by S2.

In this example, the customer knows that a student not

taking any courses is not rare at all and that it is better

that the software handles the case. Therefore, the cus-

tomer chooses to weaken R and to use software spec-

ified by S2.

Taking R as R2

An initial attempt to weaken R leads to R2, which is

inconsistent. Fixing the inconsistency leads to R3.

Taking R as R3

Suppose again that D2 is correct. Then, D2, S2⊢R3.

Interestingly, S2 is sufficiently robust that by itself,

S2⊢R3. That is, the distinction between D1 and D2 is

irrelevant.

Taking R as R4

No S can entail R4, because, as mentioned above, it is

simply not possible to algorithmically generate use-

ful, accurate letters of recommendation. Thus, the

customer must be told that his or her requirement can-

not possibly be met and to find another requirement.

A possible achievable requirement is to print human-

composed letters of recommendation that are already

stored in a database.

The above examples demonstrate how the analy-

sis of the RE problem through the lens of the ZJVF

induces different strategies for inconsistency man-

agement. While it may be sensible, and even desirable

in some cases, to tolerate incorrectness, inconsistency

in an SRS is an indication of an inherent, serious

problem. At the very least, the analyst discovering the

inconsistency must make a memo to the project that

the inconsistency exists so that all are aware of it and

can take it into account in their work. In this way, the

inconsistency is tolerated temporarily during an in-

vestigation into ways to resolve the inconsistency. Ul-

timately though, the inconsistency must be resolved

before the SRS can be considered as delivered. That

resolution may involve tolerating incorrectness,

changing the software, or abandoning or changing a

requirement. All these activities can be regarded as

managing an SRS’s inconsistency, in the more gen-

eral sense of the word “inconsistency”.

Admittedly, for such a small, easily fixed problem, this choice is

clearly preposterous. However, in real life, there are statistically

rare situations that no man-made system can handle correctly in

every case for which a decision to tolerate the failures that will re-

sult in the situations is a reasonable choice. An example is the pos-

sibility that a flying aircraft will hit a bird and crash.

3 THE EXPERIMENT

Previous research has shown that practitioners in-

clude in their personal definitions of inconsistency

cases of incorrectness (Hadar and Zamansky, 2015).

For effective inconsistency management to be viable,

it is important that requirement analysts would fully

understand the difference between inconsistency and

incorrectness. We believe that a requirement analyst

who understands the ZJVF will make better distinc-

tions between inconsistency and incorrectness, lead-

ing to better strategies for handling these cases.

Therefore, we propose an intervention, that is, teach-

ing requirements analysts the ZJVF and how to use it

for identifying and understanding inconsistencies in

SRSs. Balaban et al., (2014) have shown how teach-

ing patterns to UML modelers led to the modelers’

producing better quality UML models. We plan to

employ a similar strategy here.

Thus, we propose empirical research addressing

the research question (RQ):

Does teaching a requirement analyst the ZJVF

improve his or her ability to identify and deal

with inconsistencies in SRSs?

To answer this RQ, we are considering an experiment

outline as described below.

The planned experiment is a pre-test–post-test ex-

periment, with the intervention occurring between the

tests (Shadish et al., 2002).

Pre-test:

a. The test presents examples of SRSs, in which in-

consistencies and incorrectness may exist. While

each SRS is divided into its D, S, and R parts, the

sentences of the SRS are not directly labeled as to

which of D, S, and R it is part of. Rather, linguistic

clues of some kind are provided e.g., “is” vs.

“shall” vs. “will”.

b. For each of these SRSs, the test asks if there is a

problem in the SRS, and if there is, what it is and

what should be done to solve it.

For the pre-test, it is hypothesized that most partici-

pants will not distinguish between inconsistency and

incorrectness, and between different types of incon-

sistency, leading to proposed strategies that may be

ineffective or irrelevant to the problem at hand, in-

cluding those that indicate that they have no clue as

to what is going on.

Intervention: Teaching the ZJVF, with emphases on

the distinction between R, S, and D and on how to use

the formula to find problems in an SRS and to suggest

resolutions to these problems.

Post-test: The test is the same as the pre-test.

COLAFORM 2016 - Special Session on Collaborative Aspects of Formal Methods

380

For the post-test, however, it is hypothesized that the

participants will demonstrate an enhanced ability to

distinguish between different cases calling for differ-

ent solutions, that provide answers that are well fo-

cused as the example analyses given at the end of Sec-

tion 2.

At the time of this writing, we are running a series of

pilot studies of this experiment in order to

 refine the SRSs used in the experiment,

 refine the questions asked of each SRS,

 determine suitable hypotheses to test, and

 determine suitable measures of the participants’

responses that will allow testing the hypotheses.

4 INITIAL LESSONS LEARNED

From a pilot study already conducted, we have

learned several important lessons about conducting

the planned experiment and considerations to be

taken in order to achieve valid and insightful findings.

It is hard to create good SRSs for this purpose;

each SRS should be

 small enough to be dealt with in the few minutes

that are realistic for the short duration of a con-

trolled experiment,

 complex enough to have real problems that can be

found, but

 not so complex that there is a good chance that

participants will not find the problems.

It is hard to judge the computer-science background

of the participants, the background that is needed to

know

 the kind of defects that software can have,

 the limits of what software can do,

 the limits of what current hardware can do.

This information is needed to know whether it is rea-

sonable to expect participants to be able to find some

of the inconsistencies and incorrectnesses that can be

included in a proposed SRS.

It is hard to compose questions about an SRS;

each question should

 not reveal so much that someone can guess the an-

swer without at least an intuitive understanding of

the ZJVF, but

 not be so open ended that there is a good chance

for irrelevant answers.

It is hard to teach the ZJVF in the short period that is

realistic for the short duration of a controlled experi-

ment, to teach it well enough that participants are able

to apply it in order to correctly analyze SRSs and re-

solve their inconsistencies and incorrectnesses.

Finally, it is hard to motivate student participants

to answer post-test questions with other than “the

same as in the pre-test”.

5 DISCUSSION AND FUTURE

WORK

It is clear that inconsistency management should be

explicitly addressed in RE and techniques for doing

so should be included in the toolbox available to re-

quirements analysts.

This paper suggests that understanding the ZJVF

allows a requirements analyst to identify the sources

of a problem, i.e., an inconsistency or incorrectness,

in an SRS, and to know what needs to be done to re-

solve the problem. If the problem is an incorrect SRS,

the analyst can fix it directly. If resolving the problem

requires a decision from the customer, the analyst

knows what options can be offered to the customer

for the resolution.

The proposed research agenda can be seen as

complementary to the various theoretical frameworks

proposed for inconsistency management in RE, to-

ward bridging the gap between theory and practice.

More generally, the research is situated in the milieu

of research on how effective are the techniques in the

SE toolbox, e.g., as did Balaban et al. when they em-

pirically tested whether their pattern-based approach

for identifying abstractions helped students make bet-

ter UML class diagrams.

REFERENCES

Balaban, M., Maraee, A., Sturm, A. and Jelnov, P., 2014. A

pattern-based approach for improving model quality.

Software & Systems Modeling, Online: DOI

10.1007/s10270-013-0390.

Borgida, A., Jureta, I. and Zamansky, A., 2015. Towards a

general formal framework of Coherence Management

in RE. In Proceedings of the 23rd IEEE International

Requirements Engineering Conference (pp. 274–277)

IEEE.

Cho, A., 11 Feb. 2016. Gravitational waves, Einstein's rip-

ples in spacetime, spotted for first time. Science Maga-

zine, http://www.sciencemag.org/news/2016/02/gravi-

tational-waves-einstein-s-ripples-spacetime-spotted-

first-time.

Easterbrook, S., and Chechik, M., 2001. A framework for

multi-valued reasoning over inconsistent viewpoints. In

Reasoning about Inconsistency in RE - Separating the Wheat from the Chaff

381

Proceedings of the 23rd International Conference on

Software Engineering (pp. 411–420) IEEE.

Ernst, N. A., Borgida, A., Mylopoulos, J. and Jureta, I. J.,

2012. Agile requirements evolution via paraconsistent

reasoning. In Advanced Information Systems Engineer-

ing (pp. 382–397) Springer.

Finkelstein, A., 2000. A foolish consistency: Technical

challenges in consistency management. In Database

and Expert Systems Applications (pp. 1–5) Springer.

Finkelstein, A. C., Gabbay, D., Hunter, A., Kramer, J., and

Nuseibeh, B., 1994. Inconsistency handling in mul-

tiperspective specifications. IEEE Transactions onSoft-

ware Engineering, 20(8), 569–578.

Hadar, I. and Zamansky, A., 2015. Cognitive factors in in-

consistency management. In Proceedings of the 23rd

IEEE International Requirements Engineering Confer-

ence (pp. 226–229) IEEE.

Nuseibeh, B., Easterbrook, S. and Russo, A., 2000. Lever-

aging inconsistency in software develoment. Computer,

33(4), 24–29.

Nuseibeh, B., Easterbrook, S and Russo, A., 2001. Making

inconsistency respectable in software development.

Journal of Systems and Software, 58(2), 171–180.

Shadish, W. R., Cook, T. D., Campbell, D. T., 2002. Exper-

imental and Quasi-Experimental Designs for General-

ized Causal Inference. Boston: Houghton Mifflin.

ISBN 0-395-61556-9.

Spanoudakis, G. and Zisman, A. (2001). Inconsistency

management in software engineering: Survey and open

research issues. Handbook of software engineering and

knowledge engineering, 1, 329–380.

Zave, P. and Jackson, M., 1997. Four dark corners of re-

quirements engineering. ACM Transactions on Soft-

ware Engineering and Methodology, 6(1), 1–30.

COLAFORM 2016 - Special Session on Collaborative Aspects of Formal Methods

382
