Mind the Regularized GAP, for Human Action Classiﬁcation and

Semi-supervised Localization based on Visual Saliency

Marc Moreaux

1,2,3

, Natalia Lyubova

, Isabelle Ferran

and Frederic Lerasle

Softbank Robotics Europe, 43 rue du colonel Pierre Avia, Paris, France

CNRS, LAAS, Univ. de Toulouse, Toulouse, France

IRIT, Univ. de Toulouse, Toulouse, France

Keywords:

Semi-supervised Class Localization, Image Classiﬁcation, Class Saliency, Global Average Pooling.

Abstract:

This work addresses the issue of image classiﬁcation and localization of human actions based on visual data

acquired from RGB sensors. Our approach is inspired by the success of deep learning in image classiﬁcation.

In this paper, we describe our method and how the concept of Global Average Pooling (GAP) applies in the

context of semi-supervised class localization. We benchmark it with respect to Class Activation Mapping

initiated in (Zhou et al., 2016), propose a regularization over the GAP maps to enhance the results, and study

whether a combination of these two ideas can result in a better classiﬁcation accuracy. The models are trained

and tested on the Stanford 40 Action dataset (Yao et al., 2011) describing people performing 40 different acti-

ons such as drinking, cooking or watching TV. Compared to the aforementioned baseline, our model improves

the classiﬁcation accuracy by 5.3 percent points, achieves a localization accuracy of 50.3%, and drastically

diminishes the computation needed to retrieve the class saliency from the base convolutional model.

1 INTRODUCTION

Nowadays, as intelligent systems are getting more and

more deeply involved in our everyday life, machine

vision becomes incredibly important. Intelligent sys-

tems could greatly beneﬁt from an ability to perceive

the human environment and its major actors, allowing

them to better understand what is happening around

them. A lot of work has been done in automatic image

labeling, namely ”image classiﬁcation”, and in auto-

matic estimation of the position of a class in an image,

namely ”class localization” (LeCun et al., 2015) and

it can be applied in the context of human action classi-

ﬁcation and localization (see Figure 1). In this paper,

we consider that most of the proposed architectures

made an extensive use of supervision in the training

process when localization could have been inferred

from a lower amount of information.

Since 2006, deep learning has increasingly grown

in use to become the most successful approach in

image classiﬁcation and localization. A vast majority

of networks used in this ﬁeld are composed by a stack

of Convolutional Neural Network (CNN) layers, fol-

lowed by one or several Fully Connected layers (FC),

also referred as Dense layer, resulting in a prediction

vector. More recently, the Global Average Pooling

Figure 1: Examples of drinking action localization and sa-

liency retrieved with our approach Inception-GAP5-L1 (see

Section 3).

(GAP) method has been used at the last layers of se-

veral networks (He et al., 2016; Zhou et al., 2016)

to perform classiﬁcation and have opened the possi-

bility to perform semi-supervised-localization, which

is deﬁned here as inferring a class localization wit-

hout training on localization data but only on labels

In contrast with weakly-supervised-localization lear-

ning which uses a reduced amount of data to train.

Moreaux, M., Lyubova, N., Ferrané, I. and Lerasle, F.

Mind the Regularized GAP, for Human Action Classiﬁcation and Semi-supervised Localization based on Visual Saliency.

DOI: 10.5220/0006548303070314

In Proceedings of the 13th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2018) - Volume 4: VISAPP, pages

307-314

ISBN: 978-989-758-290-5

307

hence, without a need of extensive localization anno-

tation. This kind of approach is interesting as it is

costly to have human annotators drawing bounding

boxes around objects in dense datasets.

Global Average Pooling (GAP), a mathematical

operation performing the average of a matrix (descri-

bed in Section 3), was ﬁrst presented as a structural

regularizer in NiN (Lin et al., 2013) and later used

in GoogLeNet (Szegedy and Liu, 2015). More re-

cently, it was used in ResNet (He et al., 2016) and

GoogLeNet-GAP (Zhou et al., 2016) before a fully

connected layer to perform object localization. In this

latter approach, it was preferred to max-pooling to

ﬁnd all the discriminative parts of a class instead of

the most discriminative one.

In this work, we intend to increment the classiﬁca-

tion and localization research based on the GAP met-

hods by proposing a modiﬁed architecture and some

naive regularizations. Section 2 reviews former work

published on this topic. Section 3 introduces both our

architecture and a naive regularization term used for

localization. Section 4, describes our evaluations and

the proposed network. Finally, Section 5 concludes

our work.

2 RELATED WORK

In the context of visual perception, many approaches

based on CNNs have been used in the last years to

perform real-time object localization. Most of the

successful approaches used fully-supervised learning

to tackle theses problems. This section reviews the

architectures that have been used ﬁrst for supervised

and then for weakly or semi-supervised localization

in image processing in computer vision.

Fully-supervised Learning for Localization: In

recent literature, many architectures propose to per-

form image classiﬁcation and localization, at the same

time, using fully-supervised learning. Models like

AlexNet (Krizhevsky et al., 2012), VGGNet (Simo-

nyan and Zisserman, 2014) and GoogLeNet (Szegedy

and Liu, 2015) use a stack of convolutional layers fol-

lowed by fully connected layers to predict the class

instance and its location in images, using, for in-

stance, a regression on the bounding box (Sermanet

et al., 2013). Throughout time, these models compe-

ted in ILSVRC

(Simonyan and Zisserman, 2014) lo-

calization contest (won by (Krizhevsky et al., 2012)

and (Szegedy and Liu, 2015)). Other models, like

ResNet (He et al., 2016) introduced a similar appro-

ach, but with a GAP layer at the last convolutional

Imagenet Large-Scale Visual Recognition Challenge

layer of their networks, and set a new record in the

ILSVRC 2014 localization contest. It is clear that, in

such contest, researchers are using maximum of avai-

lable resources for training their approaches, however,

we would like our models to be less reliant on large

amount of annotated data. This is our motivation to

move towards semi-supervised learning.

Weakly and Semi Supervised Learning for Lo-

calization: Some architectures are designed to per-

form weakly-supervised localization, for example,

the model proposed by Oquab et al. (Oquab et al.,

2015) is trained in two steps. First, a traditional CNN

model, ﬁnishing with a softmax layer, is trained on

cropped images to learn to recognize a class based on

a ﬁxed receptive ﬁeld. The weights learned at this

step are frozen and the second training step consists

in convolving this model to a larger image in order to

produce a matrix of softmax predictions. From this

matrix, a new network is learned to predict the class

localization. This network includes a global max-

pooling operation made to retrieve the maximum pro-

bability of a class being present in the image. We

took inspiration from this work as (a1) the ﬁrst part

of the model is trained on images which do not in-

clude any contextual information (background remo-

ved at the cropping step) and (a2) the resulting model

produces a saliency map for every class present in an

image, based on a given receptive ﬁeld. Even though,

we consider that (b1) the two-step learning can be re-

duced to one step, (b2) the global max-pooling is a

bottleneck operation to obtain a one-shot learning mo-

del and (b3) the model should be able to learn with a

lower amount of pre-processed inputs.

These b1, b2, and b3 points have been taken

into account in (Zhou et al., 2016) where the aut-

hors propose a one-shot semi-supervised method to

perform image classiﬁcation and localization without

any annotation of localization. Their method, called

”GoogLeNet-GAP”, is a stack of CNNs ending with

a large amount of convolutional units where each out-

put map is averaged to a single value with Global

Average Pooling (GAP). The resulting values are then

fully connected to a softmax layer. We believe, that,

because of the GAP layer being fully connected to the

prediction layer, the last convolutional layer, which

is used for localization, shares too much information

with all the predictions resulting in an attention ﬁeld

broader than needed.

In our approach, we aim at developing, ﬁrst, one-

shot semi-supervised training for class localization as

in (Zhou et al., 2016). Second, we want to reduce the

attention ﬁeld in our localization mechanism by remo-

ving the Dense layer following the GAP layer, in or-

der to have an attention model similar to (Oquab et al.,

VISAPP 2018 - International Conference on Computer Vision Theory and Applications

308

2015), and we refer to this modiﬁcation as ”unsha-

red GAP layer”. Third, we would like our model

to decrease the computation, comparatively to (Zhou

et al., 2016), for retrieving the localization of the clas-

ses. Our models (eg. ”Inception-GAP5”) will be

compared to both ”GoogleLeNet-GAP”, introduced

in (Zhou et al., 2016), and ”Inception-GAP-Zhou”,

our implementation of the former.

3 OUR MODEL ARCHITECTURE

In our approach, the architecture is designed to per-

form semi-supervised learning for localization from a

classiﬁcation problem (see Figure 2).

The proposed architecture follows the all-

convolutional trend observed in deep-learning and

push it forward removing every dense layer present

on the network. To do so, we select a deep learning

architecture whose structure and training procedure is

known (InceptionV3) as our base model, up until a

desired layer and add a new convolutional layer with

c ∗ m kernels (c being the amount of classes in our

classiﬁcation task, and m, the amount of kernels used

per class) followed by a GAP layer and m sums re-

sulting in c values, used as prediction values.

To build our model, we applied the recommendati-

ons given in (Zhou et al., 2016) for GoogLeNet (Sze-

gedy and Liu, 2015) to InceptionV3. Hence, our ar-

chitecture is composed by the initial stack of CNNs

(shown by the blue parallelepipeds in Figure 2) des-

cribed in (Szegedy et al., 2016) up until the layer

called Inception4e. Following the recommendations,

this layer is followed by a [3 × 3] convolutional layer

of stride 1 whose resulting matrix contains saliency

maps for each class (shown by orange squares in Fi-

gure 2). These maps are averaged with GAP, clustered

(summing them) in c values, one per class, and fed to

a softmax layer for classiﬁcation.

If this model has m = 5 maps per layer per class,

we refer to it as ”Inception-GAP5” where ”Inception”

indicate that InceptionV3 is the base model. For in-

stance, GAP1 architecture would correspond to the

original approach developed in NiN (Lin et al., 2013)

where they state that each of these maps ”can be ea-

sily interpreted as categories conﬁdence maps”. To

keep track of the introduced names of the models, Ta-

ble 1 gives a short description of them.

Formally, the last layers of the network are deﬁ-

ned as follows : lets f

(x, y) be the activation of unit k

with {k ∈ N : k < m · c} in the last convolutional layer

at the spatial location (x,y). Then, the GAP vector g

with g ∈ R

m·c

is deﬁned by :

∑

x=0

∑

y=0

(x, y)

X ·Y

(1)

Where X and Y are the sizes of the preceding convo-

lutional layers. Then, we cluster g in a vector g

∈ R

∑

(2)

This vector is fed to a softmax function to compute

the class predictions p

= softmax

) (3)

The activation f

(x, y) we chose is Rectiﬁed Linear

Unit (ReLu) (Nair and Hinton, 2010).

Figure 2: The architecture of the proposed model with two

maps per class (m = 2) and four classes (c = 4) as an exam-

ple.

3.1 Class Activation Mapping

In (Zhou et al., 2016), the authors described a proce-

dure to retrieve some regions of interest with a met-

hod they call class activation mapping. This met-

hod is re-adapted to our architecture and described

below, yet, to fairly compare each other results, the

aforementioned architecture is slightly modiﬁed and

re-implemented in ”Inception-GAP-Zhou”. In this

model, the GoogLeNet (Szegedy and Liu, 2015) they

used is swapped with the InceptionV3 base which is

followed by a convolutional layer composed of 1024

units whose outputs are averaged with GAP, then fully

connected to the predictions and then transformed

into predictions with a softmax layer.

The procedure they called ”Class Activation Map-

pings” (CAM) aim to indicate ”the discriminative

image regions used by the CNN to identify” action

classes. In our model, we adapt this equation such that

a CAM becomes, for each class c, and each spatial lo-

calization (x, y), the sum of the n activation functions.

CAM

(x, y) =

c.m−1

∑

k=(c−1)m

(x, y) (4)

Mind the Regularized GAP, for Human Action Classiﬁcation and Semi-supervised Localization based on Visual Saliency

309

Table 1: Description of the models evaluated and compared in this work.

Model name Description

Inception-GAP5 Our GAP architecture with 5 maps per neurons built on top of InceptionV3

Inception-GAP5-L1 Inception-GAP5 whose GAP layer has a L1 penalty on its outputs

Inception-GAP5-L2 Inception-GAP5 whose GAP layer has a L2 penalty on its outputs

Inception-GAP-Zhou Gap method, as proposed in (Zhou et al., 2016), build on top of InceptionV3

Inception-GAP-Zhou-L1 Inception-GAP-Zhou whose GAP layer has a L1 penalty on its outputs

Inception-GAP-Zhou-L2 Inception-GAP-Zhou whose GAP layer has a L2 penalty on its outputs

GoogLeNet-GAP-Zhou Architecture proposed in (Zhou et al., 2016)

Retrieving CAM

: In comparison to the loca-

lization method introduced in (Zhou et al., 2016),

the amount of operations used to retrieve these CAM

maps from the computational graph, is signiﬁcantly

reduced. Due to the design of InceptionV3, used

as a base model in our approach, the default input

image resolution is 299 × 299 pixels (Szegedy et al.,

2016). In our architecture, we cut InceptionV3 to the

Inception2-5 layer, resulting in a matrix with a shape

of 17 × 17 × k kernels. Therefore, the amount of ope-

rations needed to retrieve the CAM are :

• For Inception-GAP5, the CAM method relies on

summing 5 convolutional kernel outputs through

the 17 x and 17 y coordinates, resulting in 5 ×

17 ×17 = 1445 sums.

• For Inception-GAP-Zhou (Sec.4), the CAM met-

hod is the result of (a) weighting all the k = 1024

convolutional kernel outputs (of size 17×17) with

its corresponding weights on the dense layer, re-

sulting in (1024× 17 ×17) = 295, 936 multiplica-

tions and (b) summing these 1024 maps through

each of the 17 x and 17 y coordinates, resulting in

(1024 ×17 × 17) = 295, 936 sums.

In this sense, GAP5 is more computationally efﬁcient

than GAP-Zhou.

3.2 Regularization

The softmax operator, or normalized exponential as

mentioned in (Bishop, 2006), forces the exponentials

of the activations (g

in our case) to be properly se-

parated, yet it does not constrain the class activations

to be centered on some particular value. In our mo-

del, we want the f

(x, y) activations to provide us with

insights on the probability of a class to be present at

a given position. Therefore, we add a regularization

term on the f

(x, y) values.

As in (Raina et al., 2007), where the authors con-

strain the activations with a L1 regularization, we pro-

pose to force the last convolutional layer of our model

to be sparse. Such property should help in having a

clear visualization of the CAMs and rendering whet-

her a class is present or not at a given spatial location

(x, y). To render this property, we introduce either a

L1 or a L2 regularization term to the outputs of the

last convolutional layer produced by f

(z(x, y)), with

z being the input to last convolutional layer.

The L1 regularization, applied to our last convolu-

tional layer, whose k kernels are weighted by W

and

followed by their ReLu activation, is as follows :

= α

∑



∑

x,y

(z(x, y))



= α

∑



∑

x,y

max(0,W

∗ z(x, y))



(5)

Whereas the L2 activity regularization is :

= α

∑

x,y

(z(x, y))

= α

∑

x,y

max



0, (W

∗ z(x, y))



(6)

With the ReLU activation, in both cases the W

weights are penalized only if the kernel k returns a

map which sum is above zero.

The loss function of our model is the same as (Sze-

gedy et al., 2016), namely, the cross-entropy l =

−

∑

log(p

) with Y

the one hot vector class corre-

sponding to a sample X

. The regularization term des-

cribed above is added to this loss and the alpha term

weights the importance of the regularization with re-

spect to the categorical cross entropy. After evalua-

tion, we tuned empirically α to be equal to 10

−7

for

both the L1 and the L2 regularization terms.

3.3 Implementation

This work was implemented on Keras

back-ended

with Tensorﬂow (Abadi, 2015). To implement our

model, we used InceptionV3, available in Keras and

pre-trained on ImageNet (Krizhevsky et al., 2012). As

in InceptionV3, our models are trained and tested with

images resized to 299 ×299 RGB pixels.

Nadam was chosen to train our model because of

its fast convergence speed. The parameters used in

CHOLLET, Francois. Keras (2015). http://keras.io.

VISAPP 2018 - International Conference on Computer Vision Theory and Applications

310

our approach are those proposed by default in Keras,

except for the learning rate, which was decayed every

second epoch, as in (Szegedy et al., 2016).

During the ﬁrst 10 epochs, the weights of incepti-

onV3 are ﬁxed in such way that the GAP layer is ini-

tialized with respect to the pre-trained network. Af-

terwards, all the weights in the model are subjected

to optimization. We empirically ﬁx the maximum

amount of epochs to be 125 (when the loss stopped

decreasing) and report in the following Section the

results obtained for each model we trained, with and

without regularization. The results are achieved by

the combination of weights scoring the lowest loss on

the validation set.

4 ACTION DATASET AND

ASSOCIATED EVALUATIONS

This section presents both quantitative and quali-

tative results obtained with our models applied on

”The Stanford 40 Action” (Yao et al., 2011) data-

set. Inception-GAP5 built on top of InceptionV3 with

5 maps per class was preferred to Inception-GAP10

as we noticed that increasing the amount m of maps

per class (10 instead of 5) did not improve results

in our classiﬁcation task. Inception-GAP5 achieved

an accuracy of 75.9% when Inception-GAP10 scored

1.3 points lower and Inception-GAP5-L1 achieved an

accuracy of 75.5% when Inception-GAP10-L1 scored

0.7 point more. For fair comparison, we also imple-

mented the method proposed in (Zhou et al., 2016)

on-top of InceptionV3 and trained it using the same

optimizer as the one used for our model, referred as

Inception-GAP-Zhou.

First the dataset is presented then comes the com-

parison of two one-shot and semi-supervised training

methods, one based on a fully shared GAP layer

(GoogleNet-GAP-Zhou (Zhou et al., 2016) and our

implementation of Inception-GAP-Zhou) and the ot-

her based on an unshared GAP Layer (our Inception-

GAP5). Section 4.3 is a quantitative evaluation

of the regularization introduced in Section 3.2 and

Section 4.4 assesses the localization abilities of some

of the models used up until then.

Hereafter, 5 metrics are used : accuracy, preci-

sion, recall, Mean average Precision (MaP), and In-

tersection over Union (IoU). Precision and recall, are

computed such that we only consider a label to be true

if the probability of its prediction is over 50% (as in

the Keras1 implementation). This 50% threshold pro-

bability acts as a measure based on the conﬁdence of

the model. Along with these metrics, we compute the

Mean average Precision which also reﬂects how con-

ﬁdent a model is towards its predictions. The higher

the MaP score is, the more conﬁdence we can have on

the ranked predictions of the model. Finally, we use

Intersection over Union, which is a common localiza-

tion metric in the literature, to evaluate the localiza-

tion abilities of our model. The IoU is deﬁned as the

fraction of the overlap area of ground truth bounding-

box with the predicted bounding-box over the area of

their union. To be considered as correctly localized,

the IoU of a predicted bounding-box should be over

0.5.

4.1 Action 40 Dataset

The Stanford 40 Action (Yao et al., 2011) dataset

has been used to perform training and testing of the

networks. This dataset is composed of 9532 images

(4000 used for training, and 5532 for testing) of pe-

ople performing one of 40 actions such as drinking,

cooking, reading, phoning, or brushing teeth. We

split the test images into two subsets : one with 3532

images used for validation and 2000 (50 images per

class) for the test stage. In the dataset, all images are

provided with a class label and a bounding box around

the person performing the corresponding action.

4.2 Comparing Inception-GAP5 and

Inception-GAP-Zhou

This section describes our comparison of Inception-

GAP5 and Inception-GAP-Zhou, and reports the re-

sults given in (Zhou et al., 2016) with GoogLeNet-

GAP. In Table 2, our model shows better performance

than Inception-GAP-Zhou with respect to the the ﬁrst

three of metrics aforementioned (accuracy, precision

and recall), meaning that Inception-GAP5 is better

at classifying the dataset and that its classiﬁcation is

more reliable.

Table 2: Comparison of our architecture (Inception-GAP5)

with respect to both the original GoogLeNet-GAP (Zhou

et al., 2016) and its variant Inception-GAP-Zhou evaluated

on Stanford Action 40 dataset. (Acc. stands for Accuracy).

Model name Acc. Precision Recall

Inception-GAP5 75.9% 80.1% 74.2%

Inception-GAP-Zhou 73.7% 75.7% 72.8%

GoogLeNet-GAP-Zhou 70.6% - -

4.3 Impact of Regularization on GAP

Models

This section presents the impact of L1 and L2

regularization terms on both Inception-GAP5 and

Inception-GAP-Zhou.

Mind the Regularized GAP, for Human Action Classiﬁcation and Semi-supervised Localization based on Visual Saliency

311

One of the expected behaviors mentioned in

Section 3.2 is to observe a sharper class separation

by forcing the activations of the GAP maps, and the-

refore the activations of the softmax, to be close to

zero. Such effect is seen in Table 3, where we ob-

serve the precision of both architectures increasing

when applied the regularization term. Even though

such phenomenon could result in an accuracy drop,

this trend is not observed here. The accuracy and

the precision of the Inception-GAP-Zhou model and

its L1-regularized counterpart (Inception-GAP-Zhou-

L1) both improved gaining 2.1 points in accuracy, 7.1

points in precision and 9.9 points in its Mean average

Precision, whereas Inception-GAP5 only dropped by

0.4 points in accuracy, and gained 8.7 points in pre-

cision and 14.3 points in its Mean average Precision

with the L1 regularization. Such results clearly de-

monstrate the beneﬁt of L1 regularization on classiﬁ-

cation.

Table 3: The impact of L1 and L2 regularization terms eva-

luated on Inception-GAP5 and Inception-GAP-Zhou archi-

tectures. (Acc. stands for Accuracy, Prec. for Precision and

MaP. for Mean Average Precision).

Inception-... Acc. Prec. Recall MaP.

GAP5 75.9% 80.1% 74.2% 63.8%

GAP5-L1 75.5% 88.8% 63.5% 78.1%

GAP5-L2 73.5% 88.1% 61.1% 77.0%

GAP-Zhou 73.7% 75.7% 72.8% 66.6%

GAP-Zhou-L1 75.8% 82.8% 70.5% 76.5%

GAP-Zhou-L2 73.5% 77.3% 71.2% 72.4%

The effect of regularization is also visible on the

Class Activation Maps (Figure 3) where we plot the

40 action CAMs corresponding to the processing of

the same image by each of six different models. We

observe the absolute values of the CAMs, ranging

from zero, up to the maximum value observed in all

the CAMs for the model and image (max( f

(x, y))).

In other terms, all CAMs are divided by the same

maximum value of the observed CAMs for an image

and a model.

Similar effects appears in both Inception-GAP5

and Inception-GAP-Zhou when applying the same re-

gularization. When L1 regularization is applied (Fi-

gure 3b and 3e), all the neuron activations produ-

cing the CAMs becomes close to zero except the neu-

ron recognizing a class, here the class is ”playing-

guitar”. We believe these activations are closer to re-

ality as absent classes do not activate their neurons.

The use of L2 regularization (Figure 3c and 3f) re-

sults in CAMs that are not sparse, that magniﬁes the

receptive ﬁelds of a neuron and do not discriminate

classes as properly as L1 regularization does.

4.4 Evaluation of Action Localization

The localization properties of our model are evaluated

and shown in Table 4 and Figure 4. On the one hand,

the table reports the results of the center of mass of

the CAMs being in the ground-truth bounding-box,

on the other hand, the Figure 4 reports how accurate

we are in deﬁning a bounding box around a class.

To draw a bounding box around the predicted class,

we threshold the CAM of the prediction by a given

percentage of its maximum value and consider the

bounding box to be smallest rectangle surrounding all

these points (as in (Zhou et al., 2016)).

It is important to observe that, in the Stanford 40

Action (Yao et al., 2011) dataset, the discriminative

parts of an action are mostly located next to the hu-

man performing the action (e.g. the ﬁshing action is

mostly determined and localized, with our method, by

the presence of a ﬁshing rod; instead of a person).

Yet, as mentioned in Section 4.1, the ground-truth

bounding-boxes provided are surrounding the person

performing the action, and not the action, hence, our

weakly supervised localization is penalized by its fo-

cus on the object rather than on the human.

The accuracies reported in Table 4, show that

our model without regularization, called Inception-

GAP5, which is based on unshared GAP layer, per-

forms better than Inception-GAP-Zhou, and based on

a shared GAP layer, by 6.3 points on prediction kno-

wing the class ground-truth and 2.8 points not kno-

wing it. Interestingly, the L1 regularized versions

of Inception-GAP5 and Inception-GAP-Zhou do not

show the same results. Yet, we believe that in both

cases the regularization term constrained the last con-

volutional layer to be more attentive to discriminative

elements due to the sparse constraints on the weig-

hts. In the case of Inception-GAP5, the networks is

forced to be attentive to the object rather than the hu-

man, while, in the case of Inception-GAP-Zhou, the

network is constrained to be more attentive on the hu-

man performing the action.

Table 4: Class localization accuracies. The second column

shows the evaluation results when knowing the ground truth

class and the third column considers the class predicted by

the model.

based on the based on the

Inception-... ground truth prediction only

GAP5 72.8% 50.3%

GAP5-L1 65.1% 46.6%

GAP5-L2 70.3% 49.6%

GAP-Zhou 66.5% 47.5%

GAP-Zhou-L1 68.1% 47.6%

GAP-Zhou-L2 67.4% 45.8%

VISAPP 2018 - International Conference on Computer Vision Theory and Applications

312

(a) Inception-GAP5 (b) Inception-GAP5-L1 (c) Inception-GAP5-L2

(d) Inception-GAP-Zhou (e) Inception-GAP-Zhou-L1 (f) Inception-GAP-Zhou-L2

(g) Example

Figure 3: Visualization of the CAMs obtained with Inception-GAP5 (Figure 3a, 3b and 3c) and Inception-GAP-Zhou (Fi-

gure 3d, 3e and 3f) with and without L1 or L2 regularization terms to an image of people playing guitar (Figure 3g). Each

map corresponds to one of the 40 classes. The mostly activated class is ”people playing guitar”.

The same conclusions may be drawn from Fi-

gure 4 where we test the IoU localization metric

with different threshold values. In the best case,

Inception-GAP5 is better than Inception-GAP-Zhou

by 2.7 points, the regularized version of Inception-

GAP-Zhou is better than its non-regularized counter-

part by 3 points, and that the regularized version

of Inception-GAP5 is worse than its non-regularized

counter-part, by 2.25 points. Here also, we explain

these differences by the models being more attentive

to discriminative elements - which may lead to a de-

tection outside of the ground truth bounding box.

5 CONCLUSION AND FUTURE

WORK

This work presented semi-supervised image classi-

ﬁcation and localization on RGB images using an

unshared GAP layers. Based on evaluations, we im-

prove upon existing approaches in terms of the per-

formance for both image classiﬁcation and localiza-

tion, in the context of human action localization, we

hypothesize that the increased performance is due to

the unshared GAP layer and to the reduced attention

ﬁeld in the model, which makes our model similar

Figure 4: Percentage of correctly localized images based on

the IoU metric depending on the threshold value selected to

extract our prediction bounding-box.

to (Oquab et al., 2015). This increased performance

also exists even though the amount of parameters is

reduced and the visualization method needs less com-

putation.

As our next step, we are going to asses this mo-

diﬁcation on a larger dataset such as Imagenet, then,

explore the use of shallower models (models with less

convolutional layers) to tackle this problem. We will

explore whether, in the context of shallower models,

increasing the amount m of maps per neuron shows

Mind the Regularized GAP, for Human Action Classiﬁcation and Semi-supervised Localization based on Visual Saliency

313

beneﬁts. We have strong assumptions that a wider

GAP layer will perform better than a narrower one in

the context of shallow neural network.

In the context of human action localization, it will

also be interesting to generate a prediction based on

a coherence of several consecutive frames rather than

on a single frame. Our future work will consider both

an aspect of time and coherence between consecutive

images and an associated audio coherence where we

consider to transpose it from the semi-supervised spa-

tial localization in images to semi-supervised tempo-

ral localization in audio events.

REFERENCES

Abadi, M. (2015). TensorFlow: Large-scale machine le-

arning on heterogeneous systems. Software available

from tensorﬂow.org.

Bishop, C. M. (2006). Pattern recognition. Machine Lear-

ning, 2006, vol. 128, p. 1-58.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resi-

dual learning for image recognition. In Proceedings of

the IEEE Conference on Computer Vision and Pattern

Recognition, pages 770–778.

Krizhevsky, A., Sutskever, I., and Hinton, G. E. (2012).

Imagenet classiﬁcation with deep convolutional neu-

ral networks. In Advances in neural information pro-

cessing systems, pages 1097–1105.

LeCun, Y., Bengio, Y., and Hinton, G. (2015). Deep lear-

ning. Nature, 521(7553):436–444.

Lin, M., Chen, Q., and Yan, S. (2013). Network in network.

CoRR, abs/1312.4400.

Nair, V. and Hinton, G. E. (2010). Rectiﬁed linear units im-

prove restricted boltzmann machines. In Proceedings

of the 27th international conference on machine lear-

ning (ICML-10), pages 807–814.

Oquab, M., Bottou, L., Laptev, I., and Sivic, J. (2015). Is ob-

ject localization for free?-weakly-supervised learning

with convolutional neural networks. In Proceedings of

the IEEE Conference on Computer Vision and Pattern

Recognition, pages 685–694.

Raina, R., Battle, A., Lee, H., Packer, B., and Ng, A. Y.

(2007). Self-taught learning: transfer learning from

unlabeled data. In Proceedings of the 24th internatio-

nal conference on Machine learning, pages 759–766.

ACM.

Sermanet, P., Eigen, D., Zhang, X., Mathieu, M., Fergus,

R., and LeCun, Y. (2013). Overfeat: Integrated recog-

nition, localization and detection using convolutional

networks. CoRR, abs/1312.6229.

Simonyan, K. and Zisserman, A. (2014). Very deep con-

volutional networks for large-scale image recognition.

CoRR, abs/1409.1556.

Szegedy, C. and Liu, W. (2015). Going deeper with con-

volutions. In Proceedings of the IEEE Conference on

Computer Vision and Pattern Recognition, pages 1–9.

Szegedy, C., Vanhoucke, V., Ioffe, S., Shlens, J., and Wo-

jna, Z. (2016). Rethinking the inception architecture

for computer vision. In Proceedings of the IEEE Con-

ference on Computer Vision and Pattern Recognition,

pages 2818–2826.

Yao, B., Jiang, X., Khosla, A., Lin, A. L., Guibas, L., and

Fei-Fei, L. (2011). Human action recognition by lear-

ning bases of action attributes and parts. In Computer

Vision (ICCV), 2011 IEEE International Conference

on, pages 1331–1338. IEEE.

Zhou, B., Khosla, A., Lapedriza, A., Oliva, A., and

Torralba, A. (2016). Learning deep features for dis-

criminative localization. In Proceedings of the IEEE

Conference on Computer Vision and Pattern Recogni-

tion, pages 2921–2929.

VISAPP 2018 - International Conference on Computer Vision Theory and Applications

314
