Keyframe-based Video Summarization with Human in the Loop

Antti E. Ainasoja, Antti Hietanen, Jukka Lankinen and Joni-Kristian K

ainen

Signal Processing Laboratory, Tampere University of Technology, PO Box 527, FI-33101 Tampere, Finland

Keywords:

Video Summarization, Visual Bag-of-Words, Region Descriptors, Optical Flow Descriptors.

Abstract:

In this work, we focus on the popular keyframe-based approach for video summarization. Keyframes repre-

sent important and diverse content of an input video and a summary is generated by temporally expanding the

keyframes to key shots which are merged to a continuous dynamic video summary. In our approach, keyframes

are selected from scenes that represent semantically similar content. For scene detection, we propose a simple

yet effective dynamic extension of a video Bag-of-Words (BoW) method which provides over segmentation

(high recall) for keyframe selection. For keyframe selection, we investigate two effective approaches: local

region descriptors (visual content) and optical ﬂow descriptors (motion content). We provide several inter-

esting ﬁndings. 1) While scenes (visually similar content) can be effectively detected by region descriptors,

optical ﬂow (motion changes) provides better keyframes. 2) However, the suitable parameters of the motion

descriptor based keyframe selection vary from one video to another and average performances remain low.

To avoid more complex processing, we introduce a human-in-the-loop step where user selects keyframes pro-

duced by the three best methods. 3) Our human assisted and learning-free method achieves superior accuracy

to learning-based methods and for many videos is on par with average human accuracy.

1 INTRODUCTION

Video summarization is a key technology to manu-

ally browse through multiple long videos – a user can

quickly decide whether a video is interesting or not

by viewing its summary. Summaries may also have

a more predominant role beyond retrieval since many

users have started to produce video data of their ev-

eryday life, hobbies and even for semi-professional

purposes (e.g., “How to change a tire”). In the light

of this, the original idea of informative summary must

be expanded to more generic summaries that are vi-

sually plausible and entertaining as such. The main

challenge is how to retain necessary visual and tem-

poral structure to “tell the original story” within the

requested duration (Figure 1).

There have been many video summarization ap-

proaches with various objectives (see the Truong et

al. survey (Truong and Venkatesh, 2007)), but their

evaluation or comparison is difﬁcult as users have var-

ious subjective preferences depending on their back-

ground, personal relation to the content, age, gen-

der etc. Most of the works report only qualita-

tive results or interview results from committees who

have graded or ranked the generated summaries. Re-

cently, Gygli et al. (Gygli et al., 2014) introduced the

SumMe dataset of three different types of YouTube

Figure 1: A static storyboard summary of the opening scene

of Star Wars which can be converted to dynamic video sum-

mary by temporally expanding the static keyframes.

uploaded user videos (egocentric camera, moving

camera, static camera) and asked several authors to

summarize the videos manually to establish quantita-

tive ground truth.

In this work, we adopt the popular keyframe-

based approach to video summarization (Guan et al.,

2013; Ma et al., 2005), and with the help of the

SumMe benchmark experimentally evaluate impor-

tant parts of the keyframe summarization pipeline.

We investigate the basic workﬂow and introduce its

human-in-the-loop variant to understand the semantic

gap between unsupervised summarization and super-

vised manual summarization. Local features gener-

Ainasoja, A., Hietanen, A., Lankinen, J. and Kämäräinen, J-K.

Keyframe-based Video Summarization with Human in the Loop.

DOI: 10.5220/0006619202870296

In Proceedings of the 13th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2018) - Volume 4: VISAPP, pages

287-296

ISBN: 978-989-758-290-5

287

ally perform well in detecting important scenes, but

motion analysis provides complementary cue provid-

ing better keyframes. Weak supervision in the form

of user-selected keyframes provides substantial per-

formance improvement with minimal manual work.

Our ﬁndings indicate that the both unsupervised and

human assisted approaches are needed as the ﬁrst can

provide automatic summaries online and the latter can

serve users who wish to convey their personal prefer-

ences or artistic view.

2 RELATED WORK

Figure 2: Temporal hierarchy of keyframe-based video

summarization: from whole video (top) to single frames.

The starting point of many summarization methods

is the hierarchical video structure illustrated in Fig-

ure 2 - still frames merge to continuous shots, shots

merge to scenes and scenes merge to a full video. A

popular approach to summarization is the keyframe-

based summarization (Guan et al., 2013; Ma et al.,

2005) where important keyframes are automatically

detected from the input video and then a summary

is constructed by temporally expanding keyframes to

“key shots”. The simplest method is to uniformly

assign keyframes, but that will over-emphasize long

shots that are not necessarily interesting. There-

fore the higher level information pieces, shots and

scenes (Figure 2), are more preferred starting points

for keyframe detection, e.g., the middle frame of each

shot/scene. Surveys for shot (Smeaton et al., 2010;

Duan et al., 2013) and scene detection (Fabro and

osz

ormenyi, 2013) provide overviews of the avail-

able methods. The deﬁnition of a video shot is more

technical (Smeaton et al., 2010) and therefore video

scenes that describe semantically and temporally co-

herent content are more meaningful data pieces for

summarization. There are many video applications

with similar objectives to summarization, for exam-

ple, video thumbnail generation (Liu et al., 2015),

video synopsis (temporal and spatial mixture) (Rav-

Acha et al., 2006), video-to-comics (Hong et al.,

2010; Herranz et al., 2012), and video-to-animated-

gif (Gygli et al., 2016), but we consider only the re-

cent video summarization and video scene detection

methods. We also omit the methods that utilize meta-

data in summarization (Wang et al., 2012; Zhu et al.,

2013; Bian et al., 2015).

Video Scene Detection – Video scene detection

methods analyze both temporal and spatial structures

to identify video scenes that are semantically and/or

temporarily coherent. Unsupervised scene detection

exploits standard unsupervised techniques such as

clustering (Gatica-Perez et al., 2003; Odobez et al.,

2003), Markov models (Shai and Shah, 2006) and

graphs (Gu et al., 2007; Ngo et al., 2005), and

can combine audio and video (Kyperountas et al.,

2007). Early scene detection methods were re-

viewed in the video summarization survey by Truong

and Venkatesh 2007 (Truong and Venkatesh, 2007).

These methods were based on various imagery fea-

tures and suitable for ofﬂine processing since they

process the whole input video at once. Ofﬂine scene

detection can be formulated as a structure optimiza-

tion problem (Gu et al., 2007; Ngo et al., 2005; Han

and Wu, 2011) and online detection as a reconstruc-

tion problem (Zhao and Xing, 2014) where a thresh-

old deﬁnes whether a current scene can be recon-

structed using the previous scenes.

Video Summarization – The early attempts of video

summarization are surveyed in Truong and Venkatesh

2007 (Truong and Venkatesh, 2007) and these meth-

ods often use simple rules for keyframe selection and

skimming. More recently, Shroff et al. (Shroff et al.,

2010) optimize trade-off between coverage and diver-

sity. Han et al. (Han et al., 2010) proposed an assisted

approach similar to our work, but in their system user

needs to browse through the original video and man-

ually select keyframes.

SIFT descriptors have been used in (Lu et al.,

2014) where the descriptors are weighted based on

their “importance” (a Bag-of-Importance model) and

importance mapping is learned from data. One of the

few online methods is by Zhao and Xing (Zhao and

Xing, 2014) who dynamically construct a codebook

from local image and optical ﬂow features similar to

us. However, their method selects keyframes using

the rule of whether new scene can be reconstructed

using codes of all previous scenes - that works for

informative summaries rather than for entertaining

home video summaries. Lee and Graugman (Lee and

Grauman, 2015) proposed a summarization for ego-

centric camera that optimizes summarization based

on visual content and metadata (location and time).

Meng et al. (Meng et al., 2016) replace keyframes

with “key objects” which are found by ﬁrst selecting

object region proposals and then clustering these into

key objects that then help to select keyframes. Gong

et al. (Gong et al., 2014) and Zhang et al. (Zhang

et al., 2016) introduce summarization as a supervised

VISAPP 2018 - International Conference on Computer Vision Theory and Applications

288

problem where human made summary in the train-

ing set is transferred to unseen video. Potapov et

al. (Potapov et al., 2014) use a supervised approach

where user needs to deﬁne one of the pre-deﬁned

video categories and category speciﬁc summarization

is then executed.

Gygli et al. (Gygli et al., 2014; Gygli et al., 2015)

introduced a new video summarization benchmark

SumMe and a learning based method for unsuper-

vised summarization. Their method is based on detec-

tion of “superframes” which are similar to key shots

constructed by keyframe expansion in our work and

merging of the superframes by optimizing various

motion and visual content based features.

Contributions – Our main contributions are:

• We propose a learning free method for video

summarization using local feature (SIFT) based

scene detection and motion feature (HOOF) based

keyframe selection. In the human-in-the-loop set-

ting suitable keyframes are selected by users.

• We introduce a high recall scene detection method

by extending our previous static video Bag-of-

Word (BoW) (Lankinen and K

ainen, 2013)

to dynamic video BoW that is an online method

and provides over segmentation to scenes.

• We quantitatively evaluate variants of SIFT local

regions (Lowe, 2004) and HOOF motion descrip-

tors (Chaudhry et al., 2009) in keyframe selection

for keyframe-based summarization.

3 OUR METHOD

input video

Scene boundary detection

Keyframe detection

Keyframe selection

Skimming

Scene SceneScene Scene Scene

Detected keyframes

Selected keyframes Selected keyframes

Video summary

Keyframe expansion

Figure 3: The summarization workﬂow used in this work.

The overall workﬂow of our method is illustrated in

Figure 3. At the ﬁrst stage, video scenes are detected

by our dynamic video Bag-of-Words (Section 3.1).

At the second stage, keyframes for each scene are se-

lected using either local feature or motion cues (Sec-

tion 3.2). In the unsupervised mode the detected

keyframes are expanded to key shots proportional to

the scene length (Section 3.4) and combined to form

a ﬁnal summary. In the human-in-the-loop mode

the keyframes are presented to a user (Section 3.3)

who selects the ﬁnal keyframes for the summariza-

tion. Otherwise the two modes are identical.

3.1 Dynamic Video BoW

We extend our previous static video BoW (Lankinen

and K

ainen, 2013) to dynamic video BoW. The

static version uses a ﬁxed BoW codebook for a whole

input video while our dynamic video BoW constructs

a new codebook for every detected scene. A static

codebook can be global (ﬁxed globally) or video spe-

ciﬁc (codes computed from an input video). Video

speciﬁc codebooks were clearly superior in (Lanki-

nen and K

ainen, 2013), but they require ofﬂine

processing while our algorithm is online (video can

be processed simultaneously with uploading). More-

over, in our experiments our dynamic BoW performs

better in the high-recall region (recall ≥ 0.90) of the

precision-recall curve.

Our descriptor of choice is the dense SIFT that

performed well in video event detection (Tamrakar

et al., 2012), but can be replaced with any local fea-

ture detector-descriptor pair in OpenCV with negligi-

ble loss in accuracy. We process the input video V

as frames V =

{

}

i=0,...,N

where N together with the

frame rate (fps) deﬁne the video length in wall time.

We further divide the frames into non-overlapping

blocks (short processing windows W

) of N

frames

each W



j∗N

, F

j∗N

, . . . , F

j∗N

−1



where

the number of frames |W

| = N

corresponds to one

second. Our dynamic video BoW processes the win-

dows and either merges them together to a single

scene or assigns a scene boundary.

Each frame is rescaled to 300 × 300 image and

dense SIFT descriptors of the size 20 pixels with

10 pixels spacing are extracted. In the initial stage

and after each scene boundary detection a new BoW

codebook of 100 codes is generated using the stan-

dard c-means algorithm. A BoW histogram H(W

)

is computed for the current window W

using the

codes from all frames. Then processing advances to

the next window W

c+1

for which the BoW histogram

H(W

c+1

) is computed and compared to H(W

). For

histograms we adopt the L1-normalization and for

histogram comparison we use the L2 distance. If

the distance is ≥ τ

BoW

then a scene boundary is de-

tected, otherwise the windows are merged into the

Keyframe-based Video Summarization with Human in the Loop

289

same continuous scene and the method jumps to the

next window (W

c+1

). Whenever a scene boundary

is detected the codebook is recomputed and the pro-

cess continues until the whole video has been pro-

cessed. In our experiments we ﬁxed the threshold

to τ

BoW

= 0.76 that was found to provide high re-

call with the TRECVid 2007 dataset used in (Lank-

inen and K

ainen, 2013).

3.2 Keyframe Detection

The output of the previous step in Section 3.1

is a set of adjacent scenes

{

}

that consist of

one or multiple windows which again consist of

frames each, i.e. S



, W

j+1

, . . .





j∗N

, F

j∗N

, . . . , F

( j+1)∗N

, . . .



. The goal of this

step is to select one or multiple “keyframes” for each

scene, F

, F

, . . . , F

, that describe the spatio-

temporal content of the scene S

(Figure 1).

The keyframe detection serves two purposes;

Finding the frame which best describes the content

of the scene and ﬁnding the temporal location around

which the most interesting things in the scene happen.

We tested several techniques to detect these frames.

In its simplest form, “baseline”, we picked the mid-

dle frame from each scene. In order to better analyze

the video content we experiment dissimilarity given

by local region descriptors (SIFT) during scene de-

tection or optical ﬂow based motion analysis (HOOF

motion descriptors (Chaudhry et al., 2009)).

The dense SIFT performed well in scene detec-

tion and since the descriptors are available from that

stage it is justiﬁed to adopt them for keyframe selec-

tion as well. We can compute a scene BoW histogram

using various methods (average, median) and com-

pare each window histogram to that. For keyframe

selection also various strategies exist: the most simi-

lar window to the scene histogram or the least similar

(Figure 4). In the experimental part, we tested these

variants and effect of the frame rate (15 fps, 24 fps

and original fps).

Figure 4: Video BoW dissimilarity within a scene.

Motion Analysis – We based our motion analysis on

the popular Farneb

ack’s (Farneb

ack, 2003) dense op-

tical ﬂow (Figure 5). We tested four global criteria

in keyframe selection: frame with the minimum ﬂow,

the maximum ﬂow and the frames having the amount

of ﬂow nearest to the average and the median ﬂow

of the scene. Moreover, to account for the direction

of the motion, we also used motion histograms (Fig-

ure 5 bottom). We computed motion histograms by

assigning the optical ﬂow vectors to 8 discrete bins

according to their direction and summing up the mag-

nitudes within each bin (Chaudhry et al., 2009). The

use of the motion histograms enabled us to ﬁnd the

frames that most or least resemble the average motion

of a scene.

Figure 5: Computed optical ﬂow vectors in a frame and the

corresponding optical ﬂow histogram (below).

We experimented with several histogram dis-

tance functions (1)-(5). For example, chi-square

is weighted so that distance is relational to the

overall magnitude and the amount of difference is

considered more meaningful when magnitudes are

low. Bhattacharyya as well weights distances, but

it is done based on the mean value of all his-

togram bins rather than per bin basis. Alternatively,

correlation and intersection distances compare the

shapes of the histograms disregarding the magnitudes.

d(H

, H

) =

∑

n=1

(n) − H

(n))

(1)

d(H

, H

) =

∑

n=1

(n) − H

(n))

(n)

chi-square

(2)

d(H

, H

) =

1 −

∑

n=1

(n)H

(n) Bhattacharyya

(3)

d(H

, H

) =

∑

n=1

(n) −

)(H

(n) −

)

∑

n=1

(n) −

)

∑

n=1

(n) −

)

correlation

(4)

d(H

, H

) =

∑

n=1

min(

(n)

) intersection

(5)

VISAPP 2018 - International Conference on Computer Vision Theory and Applications

290

3.3 Keyframe Selection

Figure 6: Screenshot of our GIU for keyframe selection in

human-in-the-loop video summarization.

For human-in-the-loop video summarization, we

chose the three best performing unsupervised

keyframe detection methods (one for each video type

in SumMe). One to three (removing replicates)

keyframes were presented to test subjects with a sim-

ple graphical user interface (Figure 6) that resembles

a static storyboard. Users were able to see a larger

preview of a keyframe by clicking the frame. Test

subjects selected their preferred keyframes by double-

clicking them (highlighted with green borders in Fig-

ure 6). A timeline of the original video and the sum-

mary based on the keyframe selections were shown at

the bottom of the user interface window.

3.4 Expansion of Keyframes

We expanded the selected keyframes into key shots

by taking video content around them. We divided the

target duration into each scene that had at least one

keyframe selected. The duration allocated to each

scene was proportional to the duration of the scene.

We distributed the allocated duration of each scene

uniformly to the selected keyframes forming shots

around each keyframe. We then shifted and combined

the acquired shots as necessary to avoid overlapping

and to ensure each shot stays within the boundaries of

the originally detected scene. Finally, we combined

the shots to create a dynamic summary (Figure 7).

Selected

keyframes

Selected

keyframes

Overlapping frames

Initial shots

around

keyframes

Adjusted shot

Overlap

adjustment

Figure 7: Overlapping shots around the keyframes are com-

bined into a single shot in the keyframe expansion.

4 EXPERIMENTS

4.1 Data and Performance Measures

There are many benchmark datasets available for

video processing and analysis tasks, for example,

Open Video Project (OVP, open-video.org), Kodak

Consumer Video (Kodak (Yanagawa et al., 2008)),

Youtube (de Avila et al., 2011a), CUS (Comparison of

User Summaries (de Avila et al., 2011b)), Columbia

Consumer Video (CCV (Jiang et al., 2011), an ex-

tension of Kodak), TRECVid (Over et al., 2015) and

SumMe (Gygli et al., 2014). OVP, Kodak, Youtube

and CUS provide user-selected keyframes as ground

truth and can be used in benchmarking static sto-

ryboard summarization methods (Luo et al., 2009;

Gong et al., 2014). Potapov et al. (Potapov et al.,

2014) constructed a MED-summaries dataset from

TRECVid 2011 where importance scores were intro-

duced for different video events (e.g., a kid blowing

birthday cake candles has high importance score in

the birthdays category) and used it in the evaluation

of dynamic summaries. Only the SumMe dataset by

Gygli et al. provides user made video summaries as

ground truth and therefore we selected SumMe for

our experiments. Moreover, since multiple (10-15)

summaries are provided for each video this allows

also to investigate the effect of subjective variance.

SumMe contains 25 user videos with little or no

editing. The durations of the videos range from 30

to 240 seconds totaling 1 hour, 6 minutes and 18 sec-

onds. 4 of the videos are recorded using egocentric, 4

using static and 17 using moving cameras. Each video

has 15 to 18 ground truth summaries with lengths of

5% to 15% of the original duration. The ground truth

summaries were manually created by human test sub-

jects in a controlled psychological experiment. The

dataset is used to evaluate the quality of a summary

by computing per-frame pairwise f-measure

∑

i=1

+ r

, (6)

where N is the number of ground truth summaries, p

is the precision and r the recall of the summary s being

evaluated. The precision p is computed according to

p =

∩ n

(7)

and recall r is computed as

r =

∩ n

, (8)

where n

is the number of frames in the ground truth

summary and n

the number of frames in the summary

Keyframe-based Video Summarization with Human in the Loop

291

Table 1: Comparison of approaches for video summarization using SumMe videos (per-frame pairwise f-measure performance

in (6)): average human performance computed against the SumMe ground truth, Gygli et al., random frame selection, and our

keyframe-based summarization (Section 3.2). We also mark the set of parameters for which the best result was achieved.

(Gygli et al., 2014)

Video Human-avg Gygli

Rand Our Motion SIFT Dist Hist Crit fps

Egocentric Base jumping 0.646 0.304 0.362 0.729 X L2 - med orig

Bike polo 0.640 0.708 0.266 0.553 X Int avg min 24

Scuba 0.561 0.475 0.357 0.651 X corr med max orig

Valparaiso downhill 0.637 0.567 0.333 0.698 X Int avg max orig

Moving Bearpark climbing 0.630 0.358 0.445 0.818 X Int med max orig

Bus in Rock Tunnel 0.552 0.376 0.376 0.588 X Bhat med max 15

Car railcrossing 0.693 0.703 0.272 0.553 X L2 - avg orig

Cockpit Landing 0.630 0.388 0.307 0.596 X L2 avg min 24

Cooking 0.718 0.608 0.275 0.602 X χ avg max orig

Eiffel Tower 0.668 0.632 0.278 0.561 X L2 avg min orig

Excavators river crossing 0.737 0.460 0.350 0.450 X L2 - med orig

Jumps 0.791 0.699 0.244 0.429 X L2 med min 15

Kids playing in leaves 0.734 0.226 0.353 1.000 X corr avg max 15

Playing on water slide 0.574 0.588 0.394 0.668 X χ avg min 15

Saving dolphines 0.601 0.463 0.460 0.930 X Int avg max orig

St Maarten Landing 0.795 0.502 0.229 0.537 X Int avg min orig

Statue of Liberty 0.554 0.578 0.367 0.572 X Int avg max 24

Uncut Evening Flight 0.692 0.536 0.259 0.573 X Int avg max 24

paluma jump 0.769 0.273 0.210 0.648 X χ med min 15

playing ball 0.672 0.432 0.360 0.779 X L2 avg max 15

Notre Dame 0.642 0.653 0.381 0.528 X L2 med med orig

Static Air Force One 0.678 0.649 0.294 0.755 X L2 avg max orig

Fire domino 0.767 0.253 0.282 0.527 X L2 avg max orig

car over camera 0.706 0.759 0.273 0.563 X L2 - max orig

Paintball 0.725 0.582 0.231 0.527 X L2 - avg orig

being evaluated. The higher f-measure values imply

better performance in comparison to human annota-

tion based ground truth summaries.

4.2 Unsupervised Summarization

In the ﬁrst experiment, we executed our scene de-

tection (Section 3.1) to all SumMe video clips and

then tested variants of the SIFT and motion analy-

sis based keyframe selection (Section 3.2). The re-

sults for the clips are collected into Table 1. The

ﬁrst ﬁnding is that our simple keyframe detection and

video expansion perform surprisingly well being on

par to average human and outperforming the state-of-

the-art learning based method by Gygli et al. (Gygli

et al., 2014). However, it is noteworthy that the best

keyframe selection method varies from one video to

another and their average performances remain be-

tween the random and state-of-the-art learning-based

methods (Figure 8). The second and more impor-

tant ﬁnding is that motion features generally per-

form better than region features - motion features pro-

vide the best result for 21 out of 25 clips. The lo-

cal feature based keyframes were better for the fol-

lowing four videos: Bike polo (0.553), St Maarden

Landing (0.537), Statue of Liberty (0.572) and Un-

cut evening ﬂight (0.573), but the best motion based

keyframes achieved similar accuracies: 0.495 (10%

worse), 0.460 (14% worse), 0.563 (2% worse) and

0.555 (3% worse), respectively.

The average performances over all videos for the

local feature and motion based keyframes are compa-

rable except for egocentric camera and static camera

cases for which motion analysis is clearly better (see

Figure 8). However, the average results indicate that

no single keyframe selection method can succeed and

therefore we need to use multiple of them.

4.3 Motion based Keyframe Selection

From the previous experiment, we found that the mo-

tion analysis based keyframes provide better results,

which can be explained by their complementary cue

Table 2: Highest ranked methods for videos recorded with

different types of cameras when using various frame rates.

Camera type

fps egosentric moving static

15 min corre-

lation with

median

histogram

min ﬂow min. L2 dis-

tance to avg

histogram

24 min in-

tersection

with median

histogram

min corre-

lation with

median

histogram

max L2

distance

to median

histogram

orig. min Bhat-

tacharyya

distance

to mean

histogram

min. ﬂow max L2

distance

to median

histogram

VISAPP 2018 - International Conference on Computer Vision Theory and Applications

292

egocentric moving static all

0.2

0.3

0.4

0.5

0.6

0.7

F value

min SIFT 15 max SIFT15 middle frame 15

min SIFT 24 maxSIFT 24 middle frame 24

min SIFT max SIFT middle frame

Random Gygli et al.

Avg Human

(a)

egocentric moving static all

0.2

0.3

0.4

0.5

0.6

0.7

F value

min χ

from mean

min ∩ from median max ∩ from mean

min ﬂow max L2 from median max L2 from mean

mean ﬂow Random Gygli et al.

Avg Human

(b)

Figure 8: Overall performance using variants of (a) local feature (SIFT) and (b) motion based keyframe selection.

egocentric

moving

static

all

0.2

0.4

0.6

F value

egocentric

moving

static

all

egocentric

moving

static

all

15 fps

24 fps

Orig fps

egocentric moving

static

Figure 9: Comparison of the best motion based keyframes

for the different video types and frame rates.

(motion) to the local regions that were used in scene

detection. From the results in the previous experi-

ment (Table 1, Figure 8) we selected the best motion

analysis methods from each action type: egocentric,

moving and static camera. The best methods with dif-

ferent parameter settings are shown in Table 2 and a

comparison between the highest ranking methods in

Figure 9. Using different frame rates did not yield

signiﬁcant differences in the results and therefore us-

ing the original frame rate of each video was used in

the remaining experiments as it simpliﬁes the prepro-

cessing step and the composition of the ﬁnal skim.

4.4 Human-in-the-loop

The previous experiments veriﬁed that dynamic video

BoW based scene detection and motion analysis

based keyframe selection provide a powerful process-

ing pipeline for video summarization and they can be

run in online mode. However, the best motion based

keyframes varied from one video to another and there-

fore the online method needs to be run using several

best of them. We selected the three best methods pro-

viding 1-3 keyframes for each scene (less than three

Figure 10: Our weakly supervised and all learning-based

methods fail to detect the subtle movement of the diver clut-

tered by the water fall motion ﬁeld.

if two or more detect the same frame). By the sim-

ple selection GUI in Section 3.3 users can quickly

select their preferred keyframes. In this experiment,

we tested how well this assisted setting works. We

collected annotations from 5 independent annotators

and report the results in Table 3. It is noteworthy,

that the best human annotator is comparable to the

average human annotator in the SumMe groundtruth

where annotators carefully watched the whole video

and dedicatedly selected parts of the full video to

be included to the ﬁnal summary. Their supervised

summarization was signiﬁcantly more time consum-

ing (hours) than ours (from seconds to minutes).

Assisted summarization is clearly superior to the

state-of-the-art learning-based methods by Gygli et

al. (Gygli et al., 2014) and Ejaz et al. (Ejaz et al.,

2013). The average performance of Ejaz et al. is

clearly inferior to ours and SumMe. There was

only one video for which all methods are clearly be-

low average human performance, Paluma jump, and

only one additional video for which our method is

clearly worse than SumMe Uncut Evening Flight.

The main reason for lower performance is obvious -

static keyframes cannot represent dynamic contents

and, in particular, subtle “motion inside motion” that

happens in Paluma jump where there is a large mo-

tion ﬁeld (water fall) and a distant person jumping

along the water fall (Figure 10). For the evening ﬂight

scene our annotators reported that “the whole video is

Keyframe-based Video Summarization with Human in the Loop

293

Table 3: Weakly supervised keyframe-based video summarization results including average time used for keyframe selection.

Avg human corresponds to average performance of all SumMe annotators (ideal performance), ours (best) is the best summary

achieved by one of our annotators and ours (avg) is average performance of our annotators.

(Gygli et al., 2014),

(Ejaz et al., 2013)

Video Avg Human Gygli

Ejaz

Rand Our (best) Our (avg) Avg time

Egocentric Base jumping 0.646 0.304 0.487 0.362 0.505 0.413 01:27

Bike polo 0.640 0.708 0.151 0.266 0.594 0.278 01:10

Scuba 0.561 0.475 0.517 0.357 0.403 0.318 00:47

Valparaiso downhill 0.637 0.567 0.541 0.333 0.677 0.492 00:18

Moving Bearpark climbing 0.630 0.358 0.688 0.445 0.630 0.571 00:28

Bus in Rock Tunnel 0.552 0.376 0.312 0.376 0.613 0.451 00:54

Car railcrossing 0.693 0.703 0.124 0.272 0.596 0.339 00:55

Cockpit Landing 0.630 0.388 0.262 0.307 0.779 0.493 01:12

Cooking 0.718 0.608 0.223 0.275 0.705 0.348 00:26

Eiffel Tower 0.668 0.632 0.291 0.278 0.606 0.400 00:55

Excavators river crossing 0.737 0.460 0.100 0.350 0.937 0.546 01:46

Jumps 0.791 0.699 0.398 0.244 0.791 0.351 00:27

Kids playing in leaves 0.734 0.226 0.213 0.353 0.876 0.628 00:18

Playing on water slide 0.574 0.588 0.365 0.394 0.515 0.486 00:37

Saving dolphines 0.601 0.463 0.492 0.460 0.530 0.467 00:16

St Maarten Landing 0.795 0.502 0.671 0.229 0.651 0.346 00:20

Statue of Liberty 0.554 0.578 0.250 0.367 0.467 0.386 00:56

Uncut Evening Flight 0.692 0.536 0.591 0.259 0.249 0.228 00:34

paluma jump 0.769 0.273 0.042 0.210 0.231 0.121 00:09

playing ball 0.672 0.432 0.347 0.360 0.479 0.382 00:37

Notre Dame 0.642 0.653 0.383 0.381 0.533 0.431 01:13

Static Air Force One 0.678 0.649 0.439 0.294 0.755 0.704 00:19

Fire domino 0.767 0.253 0.490 0.282 0.687 0.342 00:22

car over camera 0.706 0.759 0.410 0.273 0.824 0.656 00:34

Paintball 0.725 0.582 0.511 0.231 0.589 0.419 00:35

Figure 11: Keyframes-based summarization cannot prop-

erly capture temporal saliency that might play more crucial

role in videos that are “boring to watch” for users without

personal interest to the content.

boring”, and since no visual cues exist, the tempo-

ral saliency perhaps plays a more important role (Fig-

ure 11). The average results are shown in Figure 12

where single person performance is always superior

to Ejaz et al. and comparable or better to Gygli et al.

- the best human-in-the-loop summary is always su-

perior to all other methods indicating that there is still

signiﬁcant subjective variation between users.

egocentric moving static all

0.3

0.4

0.5

0.6

0.7

F value

Avg Human

Random Gygli et al.

Ejaz et al. Our (avg) Our (best single)

Our (best) Our (unsupervised)

Figure 12: The average performances of state-of-the-art

learning-based methods, various variants of our unsuper-

vised and weakly supervised methods and average human

video summaries for SumMe dataset. Our (best single) cor-

responds to the best single user performance.

5 CONCLUSIONS

In this work we evaluated the contribution of each

processing stage in keyframe-based video summa-

rization: scene detection, keyframe selection and

human supervision in selecting the best keyframes.

For scene detection we proposed a dynamic video

BoW method which provides high recall and there-

VISAPP 2018 - International Conference on Computer Vision Theory and Applications

294

fore over segmentation to scenes that capture subtle

changes in the visual content. For keyframe selec-

tion, we found that motion descriptors are superior

over region features used in scene detection which

can be explained by their complementary informa-

tion. However, we also found that average perfor-

mance of keyframe selection methods is substantially

lower than with learning-based state-of-the-arts. We

also found that original frame rate provides good re-

sults. We introduced a GUI for fast (from 9 seconds to

less than two minutes) human-in-the-loop keyframe

selection which provides superior/on par performance

to state-of-the-art learning-based methods while re-

taining user control over personal preferences.

REFERENCES

Bian, J., Yang, Y., Zhang, H., and Chua, T.-S. (2015). Mul-

timedia summarization for social events in microblog

stream. IEEE Trans. on Multimedia, 17(2).

Chaudhry, R., Ravichandran, A., Hager, G., and Vidal, R.

(2009). Histograms of oriented optical ﬂow and binet-

cauchy kernels on nonlinear dynamical systems for

the recognition of human actions. In The IEEE Con-

ference on Computer Vision and Pattern Recognition

(CVPR).

de Avila, S., Lopes, A., and et al. (2011a). VSUMM:

A mechanism designed to produce static video sum-

maries and a novel evaluation method. Pattern Recog-

nition Letters, 32(1):56–68.

de Avila, S. E. F., Lopes, A. P. B., da Luz Jr., A., and de Al-

buquerque Araajo, A. (2011b). VSUMM: A mecha-

nism designed to produce static video summaries and

a novel evaluation method. Pattern Recognition Let-

ters, 32(1).

Duan, X., Lin, L., and Chao, H. (2013). Discovering video

shot categories by unsupervised stochastic graph par-

tition. IEEE Trans. on Multimedia, 15(1).

Ejaz, N., Mehmood, I., and Baik, S. W. (2013). Efﬁcient

visual attention based framework for extracting key

frames from videos. Image Commun., 28(1):34–44.

Fabro, M. D. and B

osz

ormenyi, L. (2013). State-of-the-

art and future challenges in video scene detection: a

survey. Multimedia Systems, 19:427–454.

Farneb

ack, G. (2003). Two-frame motion estimation based

on polynomial expansion. In Proceedings of the 13th

Scandinavian Conference on Image Analysis (SCIA).

Gatica-Perez, D., Loui, A., and Sun, M.-T. (2003). Finding

structure in home videos by probabilistic hierarchical

clustering. IEEE Trans. on Circuits and Systems for

Video Technology, 13(6).

Gong, B., Chao, W.-L., Grauman, K., and Sha, F. (2014).

Diverse sequential subset selection for supervised

video summarization. In Conference on Neural In-

formation Processing Systems (NIPS).

Gu, Z., Mei, T., Hua, X.-S., Wu, X., and Li, S. (2007). Ems:

Energy minimization based video scene segmentation.

In ICME.

Guan, G., Wang, Z., Liu, S., Deng, J. D., and Feng, D.

(2013). Keypoint-based keyframe selection. IEEE

Trans. on Circuits and Systems for Video Technology,

24(4).

Gygli, M., Grabner, H., Riemenschneider, H., and

Van Gool, L. (2014). Creating summaries from user

videos. In European Conference on Computer Vision

(ECCV).

Gygli, M., Grabner, H., and Van Gool, L. (2015). Video

summarization by learning submodular mixtures of

objectives. In The IEEE Conference on Computer Vi-

sion and Pattern Recognition (CVPR).

Gygli, M., Song, Y., and Cao, L. (2016). Video2gif: Au-

tomatic generation of animated gifs from video. In

The IEEE Conference on Computer Vision and Pat-

tern Recognition (CVPR).

Han, B., Hamm, J., and Sim, J. (2010). Personalized video

summarization with human in the loop. In IEEE Work-

shop on Applications of Computer Vision(WACV).

Han, B. and Wu, W. (2011). Video scene segmentation us-

ing a novel boundary evaluation criterion and dynamic

programming. In ICME.

Herranz, L., Calic, J., Martinez, J., and Mrak, M. (2012).

Scalable comic-like video summaries and layout dis-

turbance. IEEE Trans. on Multimedia, 14(4).

Hong, R., Yuan, X.-T., Xu, M., and Wang, M. (2010).

Movie2comics: A feast of multimedia artwork. In

ACM Multimedia (ACMMM).

Jiang, Y.-G., Ye, G., Chang, S.-F., Ellis, D., and Loui, A.

(2011). Consumer video understanding: A benchmark

database and an evaluation of human and machine per-

formance. In ACM International Conference on Mul-

timedia Retrieval (ICMR).

Kyperountas, M., Kotropoulos, C., and Pitas, I. (2007).

Enhanced eigen-audioframes for audiovisual scene

change detection. IEEE Trans. on Multimedia, 9(4).

Lankinen, J. and K

ainen, J.-K. (2013). Video shot

boundary detection using visual bag-of-words. In Int.

Conf. on Computer Vision Theory and Applications

(VISAPP).

Lee, Y. and Grauman, K. (2015). Multimedia summariza-

tion for social events in microblog stream. Int J Com-

put Vis, 114:38–55.

Liu, W., Mei, T., Zhang, Y., Che, C., and Luo, J. (2015).

Multi-task deep visual-semantic embedding for video

thumbnail selection. In The IEEE Conference on

Computer Vision and Pattern Recognition (CVPR).

Lowe, D. (2004). Distinctive image features from scale-

invariant keypoints. Int J Comput Vis, 60(2):91–110.

Lu, S., Wang, Z., Mei, T., Guan, G., and Feng, D. (2014).

A bag-of-importance model with locality-constrained

coding based feature learning for video summariza-

tion. IEEE Trans. on Multimedia, 16(6).

Luo, J., Papin, C., and Costello, K. (2009). Towards ex-

tracting semantically meaningful key frames from per-

sonal video clips: from humans to computers. IEEE

Trans. on Circuits and Systems for Video Technology,

19(2):289–301.

Keyframe-based Video Summarization with Human in the Loop

295

Ma, Y.-F., Hua, X.-S., Lu, L., and Zhang, H.-J. (2005).

A generic framework of user attention model and its

application in video summarization. IEEE Trans. on

Multimedia, 7(5).

Meng, J., Wang, H., Yuan, J., and Tan, Y.-P. (2016). From

keyframes to key objects: Video summarization by

representative object proposal selection. In The IEEE

Conference on Computer Vision and Pattern Recogni-

tion (CVPR).

Ngo, C.-W., Ma, Y.-F., and Zhang, H.-J. (2005). Video

summarization and scene detection by graph model-

ing. IEEE Trans. on Circuits and Systems for Video

Technology, 15(2).

Odobez, J.-M., Gatica-Perez, D., and Guillemot, M. (2003).

On spectral methods and the structuring of home

videos. In Int. Conf. on Image and Video Retrieval

(CIVR).

Over, P., Awad, G., Michel, M., Fiscus, J., Kraaij, W.,

Smeaton, A. F., Quenot, G., and Ordelman, R. (2015).

Trecvid 2015 – an overview of the goals, tasks, data,

evaluation mechanisms and metrics. In Proceedings

of TRECVID 2015. NIST, USA.

Potapov, D., Douze, M., Harchaoui, Z., and Schmid, C.

(2014). Category-speciﬁc video summarization. In

European Conference on Computer Vision (ECCV).

Rav-Acha, A., Pritch, Y., and Peleg, S. (2006). Making a

long video short: Dynamic video synopsis. In The

IEEE Conference on Computer Vision and Pattern

Recognition (CVPR).

Shai, Y. and Shah, M. (2006). Video scene segmentation us-

ing Markov chain Monte Carlo. IEEE Trans. on Mul-

timedia, 8(4).

Shroff, N., Turaga, P., and Chellappa, R. (2010). Video

ecis: Highlighting diverse aspects of videos. IEEE

Trans. on Multimedia, 12(8).

Smeaton, A. F., Over, P., and Doherty, A. (2010). Video

shot boundary detection: Seven years of TRECVid

activity. Computer Vision and Image Understanding,

114(4).

Tamrakar, A., Ali, S., Yu, Q., Liu, J., Javed, O., Divakaran,

A., Cheng, H., and Sawhney, H. (2012). Evaluation of

low-level features and their combinations for complex

event detection in open source videos. In The IEEE

Conference on Computer Vision and Pattern Recogni-

tion (CVPR).

Truong, B. T. and Venkatesh, S. (2007). Video abstraction:

A systematic review and classiﬁcation. ACM Trans.

Multimedia Comput. Commun. Appl., 3(1).

Wang, M., Hong, R., Li, G., Zha, Z.-J., Yan, S., and Chua,

T.-S. (2012). Event driven web video summarization

by tag localization and key-shot identiﬁcation. IEEE

Trans. on Multimedia, 14(4).

Yanagawa, A., Loui, A., Luo, J., Chang, S.-F., Ellis, D.,

Jiang, W., Kennedy, L., and Lee, K. (2008). Kodak

consumer video benckmark data set: concept deﬁni-

tion and annotation. Technical report, Columbia Uni-

versity. ADVENT Technical Report 246-2008-4.

Zhang, K., Chao, W.-L., and Grauman, K. (2016). Sum-

mary transfer: Exemplar-based subset selection for

video summarization. In The IEEE Conference on

Computer Vision and Pattern Recognition (CVPR).

Zhao, B. and Xing, E. (2014). Quasi real-time summariza-

tion for consumer videos. In The IEEE Conference on

Computer Vision and Pattern Recognition (CVPR).

Zhu, X., Loy, C., and Gong, S. (2013). Video synopsis by

heterogeneous multi-source correlation. In Int. Conf.

on Computer Vision (ICCV).

VISAPP 2018 - International Conference on Computer Vision Theory and Applications

296
