Non-functional Requirements for Real World Big Data Systems

An Investigation of Big Data Architectures at Facebook, Twitter and Netflix

Thalita Vergilio and Muthu Ramachandran

School of Computing, Creative Technologies and Engineering, Leeds Beckett University, Leeds, U.K.

Keywords: Big Data, Facebook, Twitter, Netflix, Scalability, Distribution, Fault Tolerance, Processing Guarantees.

Abstract: This research represents a unique contribution to the field of Software Engineering for Big Data in the form

of an investigation of the big data architectures of three well-known real-world companies: Facebook, Twitter

and Netflix. The purpose of this investigation is to gather significant non-functional requirements for real-

world big data systems, with an aim to addressing these requirements in the design of our own unique

architecture for big data processing in the cloud: MC-BDP (Multi-Cloud Big Data Processing). MC-BDP

represents an evolution of the PaaS-BDP architectural pattern, previously developed by the authors. However,

its presentation is not within the scope of this paper. The scope of this comparative study is limited to the

examination of academic papers, technical blogs, presentations, source code and documentation officially

published by the companies under investigation. Ten non-functional requirements are identified and discussed

in the context of these companies’ architectures: batch data, stream data, late and out-of-order data, processing

guarantees, integration and extensibility, distribution and scalability, cloud support and elasticity, fault-

tolerance, flow control, and flexibility and technology agnosticism. They are followed by the conclusion and

considerations for future work.

1 INTRODUCTION

Big data is defined as data that challenges existing

technology for being too large in volume, too fast, or

too varied in structure. Big data is also characterised

by its complexity, with associated issues and

problems that challenge current data science

processes and methods (Cao, 2017). Large internet-

based companies have the biggest and most complex

data, which explains their leading role in the

development of state-of-the-art big data technology.

This paper contributes to the existing knowledge

in the area of Software Engineering for Big Data by

performing a search of the existing literature

published by three major companies, and an outline

of the strategies devised by them to cope with the

technological challenges posed by big data in their

production systems. Non-Functional requirements

are important quality attributes which influence the

architectural design of a system (Chung and Prado

Leite, 2009). Ten non-functional requirements for big

data systems are identified and discussed in the

context of these real-world implementations. These

requirements are used to guide the design and

development of a new architecture for big data

processing in the cloud: MC-BDP. The presentation,

evaluation and discussion of MC-BDP shall be

addressed in a future paper.

The companies targeted for this study are

Facebook, Twitter and Netflix. The methodology

used in this comparative study is explained in Section

2, which covers the scope of this research, as well as

the selection criteria used. Section 4 presents the non-

functional requirements and discusses how they are

implemented by the three companies in their

production systems. Finally, section 5 presents the

conclusion and considerations for future work.

2 METHODOLOGY

This section starts by defining the scope of this

research. This is followed by an explanation of the

criteria used to select the companies under

examination.

2.1 Scope

The scope of this paper is limited to academic papers,

technical documentation, and presentations or blog

Vergilio, T. and Ramachandran, M.

Non-functional Requirements for Real World Big Data Systems - An Investigation of Big Data Architectures at Facebook, Twitter and Netﬂix.

DOI: 10.5220/0006825408330840

In Proceedings of the 13th International Conference on Software Technologies (ICSOFT 2018), pages 833-840

ISBN: 978-989-758-320-9

833

posts officially published by the companies under

evaluation. Table 1 shows a summary of the materials

used as source for this research, classified by type.

Table 1: Classification and summary of source materials.

Company

Academic Paper

Technical

Blog

Presentation

Code/

Documentation

Faceboo

2 2 1 1

Twitte

2 2 1 3

Netflix 1 8 2 0

2.2 Selection Criteria

An initial survey was conducted, limited to peer-

reviewed academic papers. Three search engines

were primarily used to perform the searches: Google

Scholar, IEEE Xplore Digital Library and ACM

Digital Library. The initial survey searched for terms

such as “big data”, “big data processing”, “big data

software” and “big data architecture”. For the sake of

thoroughness, synonyms were used to replace key

terms where appropriate, e.g. “system” for

“software”.

The first classification which became apparent

was in terms of who developed the solutions

presented. The results found comprised technologies

developed 1) by academia, 2) by real-world big data

companies, 3) by industry experts as open-source

projects, or 4) by a combination of the above. This

research focuses on category number 2.

A further classification can be drawn from the

academic papers reviewed, this time in terms of how

the contributions presented were evaluated. Three

cases were encountered:

A) cases where there is no empirical evaluation of the

proposed solution.

B) cases where the empirical evaluation of the

proposed solution is purely experimental.

C) cases where peer-reviewed published material

was found describing the results of implementing

the proposed solution in large-scale commercial

big data settings.

In order to select suitable companies to include in this

study, the focus of this research was limited to

category C.

Three companies or cases were selected within the

criteria characterised above: Facebook, Twitter and

Netflix. These were selected from a wider pool of

qualifying companies which included Microsoft

(Eliot, 2010), (Bernstein et al., 2014), Google

(Akidau et al., 2013), (Akidau et al., 2015), and

Santander (Cheng et al., 2015). The rationale for

choosing the three aforementioned companies is

based on the quantity, quality and clarity of the

information encountered, as well as availability of

technical material online such as project

documentation and architectural diagrams.

3 NON-FUNCTIONAL

REQUIREMENTS

This section presents ten non-functional requirements

discussed in the literature published by the three

companies selected in section 2.2. It then examines

how they implemented these requirements and

compares the different solutions.

3.1 Batch Data

This requirement refers to the capability to process

data which is finite and usually large in volume, e.g.

data archived in distributed file systems or databases.

Both Facebook and Twitter estimate that the finite

data they hold on disk reaches hundreds of petabytes,

with a daily processing volume of tens of petabytes

(Krishnan, 2016). Netflix’s big data is one order of

magnitude smaller, with tens of petabytes in store and

daily reads of approximately 3 petabytes (Gianos and

Weeks, 2016).

Facebook uses a combination of three

independent, but communicating systems to manage

its stored data: an Operational Data Store (ODS),

Scuba, Hive and Laser (Chen et al., 2016).

Twitter’s batch data is stored in Hadoop clusters

and traditional databases, and is processed using

Scalding and Presto (Krishnan, 2016). Scalding is a

Scala library developed in-house to facilitate the

specification of map-reduce jobs (Twitter, Inc.,

2018). Presto, on the other hand, was originally

developed by Facebook. It was open-sourced in 2013

(Pearce, 2013), and has since been adopted not only

by Twitter, but also by Netflix (Tse et al., 2014).

Differently from the previous two companies,

Netflix’s Hadoop installation is cloud-based, and it

uses an in-house developed system called Genie to

manage query jobs submitted via Hadoop, Hive or

Pig. Data is also persisted in Amazon S3 databases

(Krishnan and Tse, 2013).

3.2 Stream Data

This requirement refers to the capability to process

data which is potentially infinite and usually flowing

at high velocity, e.g. monitoring data captured and

SE-CLOUD 2018 - Special Session on Software Engineering for Service and Cloud Computing

834

processed in real-time, or close to real-time.

Stream processing at Facebook is done by a suite

of in-house developed applications: Puma, Swift and

Stylus. Puma is a stream processing application with

a SQL-like query language optimised for compiled

queries. Swift is a much simpler application, used for

checkpointing. Finally, Stylus is a stream processing

framework which combines stateful or stateless units

of processing into more complex DAGs (Chen et al.,

2016).

Storm, one of the most popular stream processing

frameworks in use today, was developed by Twitter

(Toshniwal et al., 2014). Less than five years after the

initial release of Storm, however, Twitter announced

that it had replaced it with a better performing system,

Heron, and that Storm had been officially

decommissioned (Fu et al., 2017). Heron uses Mesos,

an open-source cluster management tool designed for

large clusters. It also uses Aurora, a Mesos

framework developed by Twitter to schedule jobs on

a distributed cluster.

Netflix also uses Mesos to manage its large cluster

of cloud resources. Scheduling is done by a custom

library called Fenzo, whereas stream processing is

done by Mantis, which is also custom-developed.

3.3 Late and out of Order Data

This requirement relates to stream processing and

refers to the capability to process data which arrives

late or in a different order from that in which it was

emitted. Streaming data from mobile users, for

example, could be delayed if the user loses reception

for a moment. In order to handle late and out of order

data, a system must have been designed with this

requirement in mind.

All three streaming architectures utilise the

concept of windows of data to transform infinite

streaming data into finite windows that can be

processed individually.

For handling late and out of order data,

Facebook’s Stylus utilises low watermarks. No

mention was found in Twitter Heron’s academic

paper of whether it provides a mechanism for dealing

with late or out of order data. However, looking at the

source code for the Heron API, the

BaseWindowedBolt class, merged into the master

project in 2017, has a method called withLag(), which

allows the developer to specify the maximum amount

of time by which a record can be out of order (Peng,

2017).

No mention was found in documentation

published by Netflix of Mantis’s strategy for dealing

with late and out of order data. Because the source

code for Mantis is proprietary, further investigation

was limited.

3.4 Processing Guarantees

This requirement refers to a stream system’s

capability to offer processing guarantees, i.e. exactly

once, at least once and at most once. While exactly

once processing is ideal, it comes at a cost which

could translate into increased latency.

Exactly once semantics involves some level of

checkpointing to persist state. There is therefore an

inherent latency cost associated with it, which is why

not all use-cases are implemented this way. Scuba at

Facebook, for example, is a system where data is

intended to be sampled, so completeness of the data

is not a requirement. Duplication, however, would not

be acceptable. In this case, at most once is a more

fitting processing guarantee than exactly once (Chen

et al., 2016). Stylus is the only real-time system at

Facebook designed with optimisations to provide at

least once processing semantics. This is enabled by

Swift’s use of Scribe as a messaging system, which is

backed by Swift for checkpointing. (Chen et al.,

2016).

At Twitter, both Storm and its successor, Heron,

offered at least once and at most once guarantees.

Identified as a shortcoming by Kulkarni et al., (2015),

the lack of exactly once semantics in Heron was

recently addressed and implemented as “effectively

once semantics”. This means that data may be

processed more than once (the topology would

undergo a rewind in case of failure), but it is only

delivered once (2018).

Netflix uses Kafka as its stream platform and

messaging system (Wu et al., 2016), which means it

provides inherent support for exactly once processing

through idempotency and atomic transactions

(Woodie, 2017).

3.5 Integration and Extensibility

This requirement refers to the capability to integrate

with existing services and components. It also refers

to provisions made to facilitate the extension of the

existing architecture to incorporate different

components in the future.

Although Facebook’s real-time architecture is

composed of many systems, they are integrated

thanks to Scribe. Scribe works as a messaging system:

all of Facebook’s streaming systems write to Scribe,

and they also read from Scribe. This allows for the

creation of complex pipelines to cater for a multitude

of use-cases (Chen et al., 2016). In terms of

Non-functional Requirements for Real World Big Data Systems - An Investigation of Big Data Architectures at Facebook, Twitter and

Netﬂix

835

extensibility, any service developed to use Scribe as

data source and output could integrate seamlessly

with Facebook’s architecture.

As part of a process to make Heron open-source,

Twitter introduced a number of improvements to

make it more flexible and adaptable to different

infrastructures and use-cases. By adopting a general-

purpose modular architecture, Heron achieved

significant decoupling between its internal

components, and increased its potential for adoption

and extension by other companies (Fu et al., 2017).

Netflix’s high level architecture is somewhat rigid

in that there is no alternative to using Mesos as an

orchestration and cluster management tool.

Additionally, Titus must run as a single framework on

top of Mesos. This limitation however was introduced

by design. With Titus running as a single framework

on Mesos, it can allocate tasks more efficiently, with

visibility of resources across the entire cluster (Leung

et al., 2017). At the time of writing, Titus is not yet

open-source, so decoupling its components from

Netflix-specific infrastructure and use-cases is not a

requirement.

3.6 Distribution and Scalability

This requirement refers to the capability to distribute

data processing amongst different machines, located

in different data centres, in a multi-clustered

architecture. Dynamic scaling, which addresses the

possibility of adding or removing nodes to a running

system without any downtime, is also addressed as

part of this requirement.

Scalability was one of the driving factors behind

the development of Scribe as a messaging system at

Facebook. Similarly to Kafka, Scribe can be scaled

up by increasing the number of buckets (brokers)

running, thus increasing the level of parallelism

(Chen et al., 2016). There is no mechanism in place

for dynamic scaling of Puma and Stylus systems

(Chen et al., 2016).

Heron was developed as a more efficient and

scalable alternative to Storm. Heron, uses an in-house

developed proprietary framework called Dhalion to

help determine whether the cluster needs to be scaled

up or down (Graham, 2017).

As Netflix’s architecture is cloud-based, it is

inherently elastic and scalable. Fenzo is responsible

for dynamically scaling resources by adding or

removing EC2 nodes to the Mesos infrastructure as

needed (Schmaus et al., 2016).

3.7 Cloud Support and Elasticity

This requirement refers to the capability to move the

architecture (or part of it) into the cloud to take

advantage of the many benefits associated with its

economies of scale. Elasticity in particular is a cloud

property which allows a system to scale up and down

according to demand. Since the user only pays for

resources actually used, there is less wastage and it is

theoretically cheaper than running the entire

infrastructure locally with enough idle capacity to

cover for any eventual spike. While scalability can be

gained by increasing the number of nodes in any

traditional architecture, it becomes much more

powerful when combined with the elasticity of the

cloud.

Based on the material examined, Neflix’s

architecture is the only which is predominantly cloud-

based. Having started with services running on AWS

virtual machines, they are now undergoing a shift

towards a container-based approach, with a few

services now running in containers on AWS

infrastructure (Leung et al., 2017). Twitter has also

undergone a shift towards a containerised

architecture, albeit not cloud-based, with the

development and implementation of Heron. As

containers become more widespread, the risk of

vendor lock-in is lowered, since containers enable the

decoupling of the processing framework from the

infrastructure they run in. Future migration to a safer

multi-cloud setup is not only possible, but desirable

(Vergilio and Ramachandran, 2018).

3.8 Fault Tolerance

This requirements refers to the capability of a system

to continue to operate should one or more nodes fail.

Ideally, the system should recover gracefully, with

minimal repercussions on the user experience.

Fault-tolerance is a requirement of Facebook’s

real-time systems, currently implemented through

node independence, and by using Scribe for all

communication between systems. Scribe persists data

to disk and is backed by Swift, a stream platform

designed to provide checkpointing for Scribe. (Chen

et al., 2016).

At Twitter, fault tolerance is addressed at different

levels. At architectural level, a modular distributed

architecture provides better fault tolerance than a

monolithic design. At container level, resource

provisioning and job scheduling are decoupled, with

the scheduler responsible for monitoring the status of

running containers and for trying to restart any failed

ones, along with the processes they were running. At

JVM level, Heron limits task processing to one per

JVM. This way, should failure occur, it is much easier

to isolate the failed task and the JVM where it was

running (Fu et al., 2017). At topology level, the

SE-CLOUD 2018 - Special Session on Software Engineering for Service and Cloud Computing

836

management of running topologies is decentralised,

with one Topology Master per topology, which

means failure of one topology does not affect others

(Kulkarni et al., 2015).

As Netflix’s production systems are cloud-based,

fault tolerance is addressed from the perspective of a

cloud consumer. The Active-Active project was

launched by Netflix with the aim of achieving fault

tolerance through isolation and redundancy by

deploying services to the US across two AWS

regions: US-East-1 and US-West-2 (Meshenberg et

al., 2013). This project was later expanded to

incorporate the EU-West-1 region, as European

locations were still subjected to single points of

failure (Stout, 2016). With this latest development,

traffic could be routed between any of the three

regions across the globe, increasing the resilience of

Netflix’s architecture.

3.9 Flow Control

This requirement refers to the capability to handle

scenarios where the data source is emitting records

faster than the system can consume. Architectures

typically provide strategies for dealing with

backpressure, e.g. dropping records, sampling,

applying source backpressure, etc.

All real-time systems at Facebook read and write

to Scribe. As described by Chen et al., this central use

of a persistent messaging system makes Facebook’s

real-time architecture resilient to backpressure. Since

nodes are independent, if one node slows down, the

job is simply allocated to a different node, instead of

the slowing down the whole pipeline (2016). The

exact strategy used by Scribe to implement flow

control is not made explicit in the paper.

Heron was designed with a flow control

mechanism as an improvement over Storm, where

producers dropped data if consumers were too busy

to receive it. When Heron is in backpressure mode,

the Stream Manager tightens the furthest upstream

component (the spout) to slow down the flow of data

through the topology. The data processing speed is

thus reduced to the speed of the slowest component.

Once backpressure is relieved and Heron exits

backpressure mode, the spout is set back to emit

records at its normal rate (Kulkarni et al., 2015).

Mantis jobs at Netflix are written using

ReactiveX, a collection of powerful open-source

reactive libraries for the JVM (Christiansen and

Husain, 2013). RxJava, one of the libraries in

ReactiveX originally developed by Netflix, offers a

variety of strategies for dealing with backpressure

such as, for example, the concept of a cold

observable, which only starts emitting data if it is

being observed, and at a rate controlled by the

observer. For hot observables which emit data

regardless of whether or not they are being observed,

RxJava provides the options to buffer, sample,

debounce or window the incoming data (Gross and

Karnok, 2016).

3.10 Flexibility and Technology

Agnosticism

This criterion refers to the capability of an

architecture to use different technology in place of

existing components.

Out of the three architectures investigated,

Facebook’s setup is the least flexible and the least

technologically agnostic. With the exception of Hive

and its ODS, built on HBase (Tang, 2012),

Facebook’s data systems were developed in-house to

cater for very specific use-cases. This is perhaps the

reason why, at the time of writing, only Scribe has

been made open-source (Johnson, 2008), although it

was not developed further, and the source-code is

archived (Facebook Archive, 2014).

Heron’s modular architecture is flexible by

design, and the technologies chosen for Twitter’s

particular implementation, Aurora and Mesos are not

compulsory for other implementations. Heron’s

flexibility is evidenced by its adoption by large scale

companies such as Microsoft (Ramasamy, 2016), and

its technology agnosticism is evidenced by its

successful implementation on a Kubernetes cluster

(Kellogg, 2017).

At programming level, Netflix is an active

participant of the Reactive Streams initiative, which

aims to standardise reactive libraries with an aim to

rendering them interoperable. Considering that JDK

9, released in September 2017, is also compatible

with Reactive Streams, there is potential for Mantis’s

jobs to be defined in standard Java.

At cloud infrastructure level, the use of containers

as a deployment abstraction reduces the tight

coupling between Netflix’s artifacts and specific

virtual machine offerings provided by AWS. This is

defined by Leung et al., (2017) as a shift to a more

application-centric deployment.

At architecture level, because Titus is not open-

source, it is difficult to evaluate whether essential

parts of its architecture such as the Mantis, Fenzo or

the Mesos cluster could be replaced with an

equivalent. Work however is under way to make the

project open-source (Netflix TechBlog, 2017), which

could attract important contributions from the

Non-functional Requirements for Real World Big Data Systems - An Investigation of Big Data Architectures at Facebook, Twitter and

Netﬂix

837

community and enhance its flexibility and technology

agnosticism.

4 CONCLUSION AND FUTURE

WORK

This paper presented the results of a literature search

for non-functional requirements relevant to real-

world big-data implementations. Three companies

were selected for this comparative study: Facebook,

Twitter and Netflix. Their specific implementations

of the non-functional requirements selected were

compared and discussed in detail, and are

summarised in this section.

Facebook and Twitter process the largest volume

of data, with Twitter having the lowest requirement

for latency. These two architectures were also

explicitly designed to handle late and out of order

data. In terms of processing guarantees, all three

architectures support exactly-once semantics.

Although the existing systems at Facebook and

Netflix are integrated, they were not designed as a

unified modular framework. Heron, on the other

hand, was developed by Twitter as an improvement

over Storm, which suffered from bottlenecks and

single points of failure. Heron’s modular architecture

makes it more flexible and technologically agnostic,

as well as a stronger candidate for adoption by other

companies.

Differently from Facebook and Twitter, which

provide mechanisms for scalability and fault

tolerance in their infrastructures, Netflix approaches

this concept from a cloud consumer’s perspective,

since its architecture is cloud-based. Netflix’s

deployments are distributed over multiple regions,

although support for multi-cloud is still lacking.

All three architectures provide mechanisms for

flow control. Facebook and Twitter control

backpressure from an infrastructure level, whereas

Netflix provides methods and constructs to achieve

this programmatically.

Our next step in this research is to use the non-

functional requirements discussed in this study to

guide the design and implementation of a new

architecture for big data processing in the cloud: MC-

BDP. MC-BDP is an evolution of the PaaS-BDP

architectural pattern originally proposed by the

authors. While PaaS-BDP introduced a framework-

agnostic programming model and enabled different

frameworks to share a pool of location and provider-

independent resources (Vergilio and Ramachandran,

2018), MC-BDP expands this model by explicitly

prescribing a pooled environment where nodes are

deployed to multiple clouds.

ACKNOWLEDGEMENTS

This work made use of the Open Science Data Cloud

(OSDC) which is an Open Commons Consortium

(OCC)-sponsored project.

Cloud computing resources were provided by a

Microsoft Azure for Research award.

Container and cloud native technologies were

provided by Weaveworks.

REFERENCES

Akidau, T., Bradshaw, R., Chambers, C., Chernyak, S.,

Fernández-Moctezuma, R. J., Lax, R., McVeety, S.,

Mills, D., Perry, F., Schmidt, E. and Whittle, S. (2015)

The Dataflow Model: A Practical Approach to

Balancing Correctness, Latency, and Cost in Massive-

Scale, Unbounded, Out-of-Order Data Processing.

Proceedings of the VLDB Endowment, 8, pp. 1792–

1803.

Akidau, T., Whittle, S., Balikov, A., Bekiroğlu, K.,

Chernyak, S., Haberman, J., Lax, R., McVeety, S.,

Mills, D. and Nordstrom, P. (2013) MillWheel: Fault-

Tolerant Stream Processing at Internet Scale.

Proceedings of the VLDB Endowment, 6 (11) August,

pp. 1033–1044.

Bernstein, P., Bykov, S., Geller, A., Kliot, G. and Thelin, J.

(2014) Orleans: Distributed Virtual Actors for

Programmability and Scalability [Online]. Available

from: <https://www.microsoft.com/en-us/research/pu

blication/orleans-distributed-virtual-actors-for-progra

mmability-and-scalability/>.

Cao, L. (2017) Data Science: Challenges and Directions.

Communications of the ACM, 60 (8) July, pp. 59–68.

Chen, G. J., Wiener, J. L., Iyer, S., Jaiswal, A., Lei, R.,

Simha, N., Wang, W., Wilfong, K., Williamson, T. and

Yilmaz, S. (2016) Realtime Data Processing at

Facebook. In: Proceedings of the 2016 International

Conference on Management of Data, 2016. New York,

NY, USA: ACM, pp. 1087–1098.

Cheng, B., Longo, S., Cirillo, F., Bauer, M. and Kovacs, E.

(2015) Building a Big Data Platform for Smart Cities:

Experience and Lessons from Santander. In: 2015 IEEE

International Congress on Big Data, June 2015. pp.

592–599.

Christiansen, B. and Husain, J. (2013) Reactive

Programming in the Netflix API with RxJava. Netflix

TechBlog, 4 December [Online blog]. Available from:

<https://medium.com/netflix-techblog/reactive-

programming-in-the-netflix-api-with-rxjava-

7811c3a1496a> [Accessed 16 February 2018].

SE-CLOUD 2018 - Special Session on Software Engineering for Service and Cloud Computing

838

Chung, L. and Prado Leite, J. C. (2009) Conceptual

Modeling: Foundations and Applications. Berlin,

Heidelberg: Springer-Verlag, pp. 363–379.

Eliot, S. (2010) Microsoft Cosmos: Petabytes Perfectly

Processed Perfunctorily [Online blog]. Available from:

<https://blogs.msdn.

microsoft.com/seliot/2010/11/05/microsoft-cosmos-

petabytes-perfectly-processed-perfunctorily/>

[Accessed 24 January 2018].

Facebook Archive (2014) Scribe [Online]. Facebook

Archive. Available from: <https://github. com/face

bookarchive/scribe> [Accessed 15 February 2018].

Fu, M., Agrawal, A., Floratou, A., Graham, B., Jorgensen,

A., Li, M., Lu, N., Ramasamy, K., Rao, S. and Wang,

C. (2017) Twitter Heron: Towards Extensible

Streaming Engines. In: 2017 IEEE 33rd International

Conference on Data Engineering (ICDE), April 2017.

pp. 1165–1172.

Gianos, T. and Weeks, D. (2016) Petabytes Scale Analytics

Infrastructure @Netflix [Online]. Presented at: QCon,

August 11, 2016, San Francisco. Available from:

<https://www.infoq.com/presentations/netflix-big-

data-infrastructure> [Accessed 12 February 2018].

Graham, B. (2017) From Rivulets to Rivers: Elastic Stream

Processing in Heron [Online]. Available from:

<https://www.slideshare.net/billonahill/from-rivulets-

to-rivers-elastic-stream-processing-in-heron>

[Accessed 14 February 2018].

Gross, D. and Karnok, D. (2016) Backpressure [Online].

ReactiveX/RxJava Wiki. Available from:

<https://github.com/ReactiveX/RxJava/wiki/Backpress

ure> [Accessed 15 February 2018].

Heron Documentation - Heron Delivery Semantics (2018)

[Online]. Available from: <https://twitter.github.io/

heron/docs/concepts/delivery-semantics/> [Accessed

14 February 2018].

Johnson, R. (2008) Facebook’s Scribe Technology Now

Open Source. Facebook Code, 24 October [Online

blog]. Available from: <https://code.facebook.com/

posts/214389698718537/facebook-s-scribe-technology

-now-open-source/> [Accessed 15 February 2018].

Kellogg, C. (2017) The Heron Stream Processing Engine

on Google Kubernetes Engine. Streamlio, 28

November [Online blog]. Available from:

<https://streaml.io/blog/heron-on-gke-power-by-

kubernetes/> [Accessed 15 February 2018].

Krishnan, S. (2016) Discovery and Consumption of

Analytics Data at Twitter. 29 June [Online blog].

Available from: <https://blog.twitter.

com/engineering/en_us/topics/insights/2016/discovery

-and-consumption-of-analytics-data-at-twitter.html>

[Accessed 9 February 2018].

Krishnan, S. and Tse, E. (2013) Hadoop Platform as a

Service in the Cloud. The Netflix Tech Blog, 10 January

[Online blog]. Available from: <http://techblog.netflix.

com/2013/01/hadoop-platform-as-service-in-cloud.ht

ml> [Accessed 30 October 2016].

Kulkarni, S., Bhagat, N., Fu, M., Kedigehalli, V., Kellogg,

C., Mittal, S., Patel, J. M., Ramasamy, K. and Taneja,

S. (2015) Twitter Heron: Stream Processing at Scale.

In: Proceedings of the 2015 ACM SIGMOD

International Conference on Management of Data,

2015. New York, NY, USA: ACM, pp. 239–250.

Leung, A., Spyker, A. and Bozarth, T. (2017) Titus:

Introducing Containers to the Netflix Cloud. Queue, 15

(5) October, pp. 30:53–30:77.

Meshenberg, R., Gopalani, N. and Kosewski, L. (2013)

Active-Active for Multi-Regional Resiliency. Netflix

TechBlog, 2 December [Online blog]. Available from:

<https://medium.com/netflix-techblog/active-active-

for-multi-regional-resiliency-c47719f6685b>

[Accessed 15 February 2018].

Pearce, J. (2013) 2013: A Year of Open Source at Facebook

[Online]. Facebook Code. Available from:

<https://code.facebook.com

/posts/604847252884576/2013-a-year-of-open-source-

at-facebook/> [Accessed 12 February 2018].

Peng, B. (2017) [ISSUE-1124] - Windows Bolt Support

#2241 [Online] [Heron]. Twitter, Inc. Available from:

<https://github.com/twitter/heron/pull/2241>

[Accessed 12 February 2018].

Ramasamy, K. (2016) Open Sourcing Twitter Heron.

Twitter Engineering Blog, 25 May [Online blog].

Available from: <https://blog.twitter.com/engineering/

en_us/topics/open-source/2016/open-sourcing-twitter-

heron.html> [Accessed 15 February 2018].

Schmaus, B., Carey, C., Joshi, N., Mahilani, N. and Podila,

S. (2016) Stream-Processing with Mantis. Netflix

TechBlog, 14 March [Online blog]. Available from:

<https://medium.com/netflix-techblog/stream-

processing-with-mantis-78af913f51a6> [Accessed 31

January 2018].

Stout, P. (2016) Global Cloud — Active-Active and

Beyond. Netflix TechBlog, 30 March [Online blog].

Available from: <https://medium.com/netflix-

techblog/global-cloud-active-active-and-beyond-

a0fdfa2c3a45> [Accessed 15 February 2018].

Tang, L. (2012) Facebook’s Large Scale Monitoring

System Built on HBase [Online]. Presented at: Strata

Conference + Hadoop World, October 24, 2012, New

York, NY, USA.

Toshniwal, A., Taneja, S., Shukla, A., Ramasamy, K.,

Patel, J. M., Kulkarni, S., Jackson, J., Gade, K., Fu, M.,

Donham, J., Bhagat, N., Mittal, S. and Ryaboy, D.

(2014) Storm@Twitter. In: Proceedings of the 2014

ACM SIGMOD International Conference on

Management of Data, 2014. New York, NY, USA:

ACM, pp. 147–156.

Tse, E., Luo, Z. and Yigitbasi, N. (2014) Using Presto in

Our Big Data Platform on AWS. The Netflix Tech Blog,

10 July [Online blog]. Available from:

<https://medium.com/netflix-techblog/using-presto-in-

our-big-data-platform-on-aws-938035909fd4>

[Accessed 12 February 2018].

Twitter, Inc. (2018) Scalding: A Scala API for Cascading

[Online]. Twitter, Inc. Available from:

<https://github.com/twitter/scalding> [Accessed 12

February 2018].

Updates on Netflix’s Container Management Platform

(2017) Netflix TechBlog, 14 November [Online blog].

Non-functional Requirements for Real World Big Data Systems - An Investigation of Big Data Architectures at Facebook, Twitter and

Netﬂix

839

Available from: <https://medium.com/netflix-

techblog/updates-on-netflixs-container-management-

platform-a91738360bd8> [Accessed 16 February

2018].

Vergilio, T. and Ramachandran, M. (2018) PaaS-BDP - A

Multi-Cloud Architectural Pattern for Big Data

Processing on a Platform-as-a-Service Model. In:

Proceedings of the 3nd International Conference on

Complexity, Future Information Systems and Risk -

Volume 1: COMPLEXIS, ISBN 978-989-758-297-4,

pp. 45-52.

Woodie, A. (2017) A Peek Inside Kafka’s New ‘Exactly

Once’ Feature. Datanami, 7 March [Online blog].

Available from: <https://www.datanami.com/

2017/07/03/peek-inside-kafkas-new-exactly-feature/>

[Accessed 14 February 2018].

Wu, S., Wang, A., Daxini, M., Alexar, M., Xu, Z., Patel, J.,

Guraja, N., Bond, J., Zimmer, M. and Bakas, P. (2016)

The Netflix Tech Blog: Evolution of the Netflix Data

Pipeline [Online]. Available from:

<http://techblog.netflix.com/2016/02/evolution-of-

netflix-data-pipeline.html> [Accessed 30 October

2016].

SE-CLOUD 2018 - Special Session on Software Engineering for Service and Cloud Computing

840
