HEXTRATO: Using Ontology-based Constraints to Improve Accuracy

on Learning Domain-speciﬁc Entity and Relationship Embedding

Representation for Knowledge Resolution

Hegler Tissot

C3SL, Universidade Federal do Paran

a, Curitiba, Brazil

Keywords:

Knowledge Resolution, Knowledge Embedding, Link Prediction, Knowledge Completion, Electronic Health

Records.

Abstract:

This paper focuses the problem of learning the knowledge low-dimensional embedding representation for

entities and relations extracted from domain-speciﬁc datasets. Existing embedding methods aim to represent

entities and relations from a knowledge graph as vectors in a continuous low-dimensional space. Different

approaches have been proposed, being usually evaluated on standard benchmark knowledge graphs, such as

Wordnet and Freebase. However, the nature of such data sources prevents those methods of taking advantage

of more detailed and enriched metadata, lacking more accurate results on the evaluation tasks. In this paper, we

propose HEXTRATO, a novel embedding approach that extends a traditional baseline model TransE by adding

ontology-based constraints in order to better capture the relationships between categorised entities and their

symbolic representation in the vector space. Our method is evaluated on an adapted version of Freebase, on a

publicly available dataset used on machine learning benchmarks, and on two datasets in the clinical domain.

Our method outperforms the state-of-the-art accuracy on the link prediction task, evidencing the learnt entity

and relation embedding representation can be used to improve more complex embedding models.

1 INTRODUCTION

The problem of representing multi-relational data has

gained more attention in the last decade as long as

more knowledge bases become available and useful

as supporting resources for a variety of machine lear-

ning related applications. A knowledge graph (KG)

is a multi-relational dataset composed by entities

(nodes) and relations (edges). Freebase (Bollacker

et al., 2008), Google Knowledge Graph (Dong et al.,

2014), Wordnet (Fellbaum, 1998), and YAGO (Su-

chanek et al., 2007) are some well-known exam-

ples of multi-relational data. They provide reaso-

ning ability and can be used for inference, supporting

applications such as information retrieval, question-

answering systems (Gardner and Mitchell, 2015), link

prediction (Taskar et al., 2003), and knowledge reso-

lution (Lin et al., 2017).

In multi-relational data, each entity represents an

abstract concept or concrete entity of the world and

relationships are predicates that represent facts invol-

ving two entities. KGs are described in the form of

triples (h, r, t) – h and t are the head and tail enti-

ties (also known as subject and object) and r is the

predicate that represents the relation between h and

t. Knowledge embedding methods aim to represent

entities (h and t) and relations (r) as vectors in a con-

tinuous vector space, enforcing the embedding com-

patibility by using distinct scoring (loss) functions

to evaluate their representations, which implies some

transformations on the triple constituents (h, r, t), and

distinct algorithms to optimize the margin-based ob-

jective function.

KGs are usually created based on facts extracted

from unstructured or semi-structured data sources, so

they are typically inaccurate and incomplete. Lear-

ning the distributed representation of multi-relational

data provides an efﬁcient tool to complete knowledge

bases without requiring extra knowledge. Thus, kno-

wledge base completion or link prediction became an

important task of automatically recovering missing

facts based on observed ones.

Embedding methods represent entities as a k-

dimensional vector in order to learn and operate on

the latent feature representation of the constituents

and on their semantic relatedness, by deﬁning a sco-

ring function f (h,t) to measure the plausibility of the

triplet (h, r, t), where f (h,t) implies a transforma-

Tissot, H.

HEXTRATO: Using Ontology-based Constraints to Improve Accuracy on Learning Domain-speciﬁc Entity and Relationship Embedding Representation for Knowledge Resolution.

DOI: 10.5220/0006923700720081

In Proceedings of the 10th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2018) - Volume 1: KDIR, pages 72-81

ISBN: 978-989-758-330-8

tion on the pair of entities which characterises the

relation r. TransE (Bordes et al., 2013) is one of

the usual baseline methods that uses simple assump-

tions to achieve accurate and scalable results, pro-

ving to be effective and efﬁcient even in complex

and heterogeneous multi-relational domains. After

providing the initial embedding representation in the

ﬁrst learning steps, TransE is usually extended by

more complex models that use distinct techniques

and embedding representations to obtain better link

prediction performance on the benchmark datasets.

TransH (Wang et al., 2014), TransR (Lin et al., 2015),

and STransE (Nguyen et al., 2016) are some exam-

ples of other methods designed to learn and operate

on embedding representations based on TransE.

Although embedding methods have driven the at-

tention to the widely used standard benchmark data-

sets, we aim to apply knowledge representation met-

hods over more structured datasets, built with data

extracted from domain-speciﬁc information systems.

Such source systems are able to provide enriched me-

tadata and produce more dense KGs rather than the

sparse ones usually employed in the traditional eva-

luation protocols. We are particularly interested on

evaluating embedding learning methods over data ex-

tracted from patient electronic health records (EHR)

in order to create more accurate prediction models in

the clinical domain.

In this paper, we present HEXTRATO, a novel

embedding approach that extends the traditional ba-

seline model TransE by adding ontology-based con-

straints designed based on the source metadata in or-

der to better capture the relationships between enti-

ties and their symbolic representation in the vector

space. Experiments on the task of link prediction,

using an adapted version of Freebase, a publicly avai-

lable dataset used on machine learning benchmarks,

and two datasets from the clinical domain, show im-

provements of predictive accuracy over the traditional

baseline approach TransE and other similar approa-

ches. The results demonstrate our method improves

the accuracy on the evaluation task when dealing with

more structured data and metadata, evidencing the re-

sulting learnt entity and relation embedding represen-

tations can also be used to improve more complex em-

bedding models when dealing with domain-speciﬁc

categorised data.

2 RELATED WORK

Embedding models in general aim to represent enti-

ties in a k-dimensional vector space (or “embedding

space”), where k is a model hyper-parameter, so that

there is a speciﬁc similarity metric able to capture the

relationship between entities for any given relation

type, by learning how each entity interacts with other

entities with respect to all types of relations (Bordes

et al., 2011). Given a knowledge base set S of triplets

(h,r,t) composed of two entities h,t ∈ E and a rela-

tionship r ∈ R , where E denotes the set of entities

and R the set of relation types, the embedding mo-

del learns an embedding vector e ∈R

for each entity

and one or more embedding vectors (and/or matrices)

r ∈ R

(and/or r ∈ R

k×m

) for each relationship.

TransE (Bordes et al., 2013) is a baseline method

that uses simple assumptions to achieve accurate and

scalable results. TransE proved to be relatively ef-

fective and efﬁcient by representing entities h, t and

a relation r by translation vectors h,t,r ∈ R

, chosen

so that the pair of embedded entities in a triple (h,r,t)

can be connected by r with low error (Equation 1).

h + r ≈t (1)

Although TransE is very efﬁcient while achie-

ving predictive performance, it rifts on dealing with

certain kinds of relations, such as reﬂexive, one-

to-many, many-to-one, and many-to-many relations-

hips (Wang et al., 2014). Nevertheless, other met-

hods utilise TransE as a base model as part of the ﬁrst

learning steps in order to provide the initial embed-

dings, aiming to learn better knowledge representa-

tions for complicated semantic correlations between

knowledge triples – e.g. by projecting the entity em-

bedding vector into a relation space using relation-

speciﬁc matrices. Some of these translation-based

embedding models are brieﬂy described below.

TransH (Wang et al., 2014) models relations as

hyperplanes together with translation operations on

it. TransH overcomes the ﬂaws regarding to those

kinds of relationships that TransE does not perform

well, by preserving the mapping properties of rela-

tions, and keeping the same model complexity and

running time of TransE. Each entity can have distinct

distributed representations when involved in different

relations, which allows entities to play different roles

in different relations. Each relation r is represented

by a vector r on a hyperplane with w

as the normal

vector. The entity embedding vectors h and t are ﬁrst

projected to the hyperplane of w

⊥

and t

⊥

). The

score function is similar to that used in TransE, but

using the projected embedding vectors instead (Equa-

tion 2).

(h,t) = kh

⊥

+ r −t

⊥

(2)

TransR (Lin et al., 2015) and ETransR (Lin et al.,

2017) model entity and relation embedding represen-

tation into separate distinct vector spaces, bridged by

a relation-speciﬁc matrix M

(a k-dimensional space

HEXTRATO: Using Ontology-based Constraints to Improve Accuracy on Learning Domain-speciﬁc Entity and Relationship Embedding

Representation for Knowledge Resolution

for entities and a m-dimensional space for relations).

These methods are mainly focused on modelling sin-

gle knowledge in continuous space instead of model-

ling the semantic relatedness between knowledges. In

these models, the entity and relation embedding di-

mensions are not necessarily identical. In ETransR,

however, all the results report k = m, which lead us to

conclude that: a) projecting entity embedding vectors

into lower dimensional spaces can lose some precious

information, and b) using higher dimensional spaces

do not necessarily add any further useful information

to the embedding model.

Structured Embedding or SE (Bordes et al., 2011)

and STransE (Nguyen et al., 2016) intend to account

for relationship asymmetry by using two relation-

speciﬁc projection matrices for entities h and t. SE

deﬁnes the score function by using two projected vec-

tors, so that:

(h,t) = kW

r,1

h −W

r,2

tk (3)

where f

(h,t) is large for corrupted triplets (and small

otherwise) in some subspace that depends on the re-

lationship r. STransE combines SE and TransE by

using relation-speciﬁc matrices W

r,1

and W

r,2

to iden-

tify the relation-dependent aspects, and a vector r to

capture the relationship between the entities h and

t. In STransE, a score function f

(h,t) (Equation

4) is used to minimize the margin-based objective

function, and performs better than the SE, TransE and

other state-of-the-art link prediction models.

(h,t) = kW

r,1

h + r −W

r,2

1/2

(4)

TransT (Ma et al., 2017) is a recent attempt to in-

tegrate structured information and entity types in or-

der to describe the categories of entities. TransT con-

structs relation types from entity types and utilises

type-based semantic similarity to capture prior distri-

butions of entities and relations. However, it gerena-

tes multiple embedding representations of each entity

in different contexts.

Knowledge embedding methods are commonly

evaluated on standard benchmark datasets WN18 and

FB15K built with data extracted from Wordnet (Fel-

lbaum, 1998) and Freebase (Bollacker et al., 2008).

Reporting results (Lin et al., 2015; Nguyen et al.,

2016), however, evidence the lack of accuracy when

dealing with non-categorised data available in this tra-

ditional benchmark datasets. Type-based constraints

can support the statistical modelling with latent vari-

able models, by integrating prior knowledge on entity

and relation types, signiﬁcantly improving these mo-

dels up to about 70% in link prediction tasks, especi-

ally when a low model complexity is enforced (Krom-

paß et al., 2015).

3 HEXTRATO

Our method couples the baseline embedding method

TransE with a set of ontology-based constraints in-

herited from the source metadata in order to improve

both the accuracy and validation performance when

dealing with more structured and well categorized

domain-speciﬁc data.

3.1 Ontology-based Constraints

3.1.1 Typed Entities

As long as the source database provides categorised

data and metadata, each resulting triple in the kno-

wledge base has both head and tail entities h and t

identiﬁed by a type. Each resulting triple is presen-

ted in the form (c

:h, r, c

:t), where c

and c

repre-

sent the types of h and t. Besides providing a cate-

gorised set of entities, the metadata also enriches the

deﬁnition of each relation r, by restricting the dom-

ain and range of r to set of entities h ∈ c

: E and

t ∈ c

: E , respectively. In the following example,

the relation hasGender is constrained by the dom-

ain patient and the range gender: (patient:P01,

hasGender, gender:male).

HEXTRATO uses independent vector spaces to

project each entity type, thus leading to a substan-

tial processing time improvement along the validation

process – related work models usually perform the

validation process every each 100 cycles along the

training step, whilst our method performs validation

after each 20 training cycles with similar processing

time comparing to previous works.

3.1.2 Isolating Values

Speciﬁc set of tail values can share the same entity

names and types when involved in different relations.

A very simple example to illustrate this condition is

the boolean type. When multiple relations r

and r

are deﬁned with same range boolean, they end up by

sharing the possible entities boolean:true and bool-

ean:false in the boolean vector space. However, this

correlation between r

and r

does not necessarily ex-

ist. We set the relations sharing tail types that should

be taken as independent relations, by isolating the as-

sociated values in relation-speciﬁc types. Effectively,

given two relations r

and r

both deﬁned with the

same range type

of tail entities, we set each relation

to isolate the tail values by creating an independent

set of tail entities for each relation, i.e. independent

vector spaces for each relation.

For example, the relations isPregnant and

isSmoker are both deﬁned with the same range

KDIR 2018 - 10th International Conference on Knowledge Discovery and Information Retrieval

boolean: (patient:?,isPregnant,boolean:?)

and (patient:?,isSmoker,boolean:?). Howe-

ver, isPregnant and isSmoker should be taken as

independent properties for a given patient, and it

should not be expected to have any correlations

between those entities by sharing the tail enti-

ties boolean:true and boolean:false. By isolating

their values, each relation creates its own set of

boolean values, boolean:isPregnant true and bool-

ean:isPregnant false for the relation isPregnant, and

boolean:isSmoker true and boolean:isSmoker false

for the relation isSmoker.

3.1.3 Disjoint Sets

By learning the distributed representation of multi-

relational data, knowledge embedding models can ef-

ﬁciently deal with the semantic relatedness of their

constituents. Similar entities are expected to be found

near to each other in the vector space, while dissi-

milar entities should be placed apart. However, this

expected result can be harmed when learning the em-

bedding representation for dense graphs, especially

when combining independent types of relations to

describe the subject entities. By imposing a minimum

disjoint dissimilarity (distance margin) among the en-

tities belonging to speciﬁc types on the tail side, we

avoid the model converging to undesirable solutions.

In very dense graphs, we observed multiple tail values

associated with uncorrelated types of relations found

very close to each other, leading to a model that mi-

mics a random probability of choices.

For instance, by setting the type gender as a

disjoint set, a minimum disjoint margin distance be-

tween the entities gender:male and gender:female is

enforced in the beginning of each training step. The

disjoint margin is an additional hyper-parameter in

our approach, but for the experimental results it was

ﬁxed as

√

for each k-dimensional space evaluated.

3.1.4 Functional Relations

In a functional relation r, for each head entity h, there

can be at most one distinct tail entity t such that (h,r,t)

is true, which is equivalent of saying the cardinality of

the relation r is ≤ 1. Combining typed and functional

relations with disjoint tail sets proved to be very ef-

fective on learning the embedding representation of

multi-relational data, by narrowing the process of se-

lecting corrupted triples along the training process.

By way of illustration, considering the following

true positive triple (patient:P01, hasGender,

gender:male), in which the relation hasGender is

set as functional and the type gender is a disjoint set,

the process of electing a corrupted tail along the trai-

ning process is straightly redirect to pick up all the re-

maining tail entities from the gender set, in this case

gender:female would be the only alternative.

3.2 Embedding Representation

Among previous embedding methods, TransE is a

promising baseline, as it is simple and efﬁcient

while achieving predictive performance. However,

we ﬁnd that there are ﬂaws in TransE when dealing

with relations mapping properties of reﬂexive/one-

to-many/many-to-one/many-to-many. Few previous

works discuss the role of these mapping properties in

embedding. Some advanced models with more free

parameters are capable of preserving these mapping

properties, e.g. TransH (Wang et al., 2014). Howe-

ver, the model complexity and running time is signi-

ﬁcantly increased accordingly. Our method follows

the idea presented by TransE, coupling this baseline

model with the ontology-based constraints previously

described in order to improve accuracy in domain-

speciﬁc knowledge bases.

Despite the great expressiveness of the previously

proposed embedding models, they can be complex

to model, hard to interpret, and expensive in terms

of training computational costs. Besides, we ob-

served in empirical experiments they are susceptible

to either overﬁtting in higher embedding spaces, or

under-ﬁtting due to multiple local minima along the

optimization process. Indeed, according to (Bengio

et al., 2005), lower k-dimensional spaces are appro-

priate for achieving good results because a density

estimator can misbehave in high dimensions when

there is no smooth low-dimensional manifold captu-

ring the distribution. In our approach, we target lower

k-dimensional models (e.g. k < 100) favouring a dis-

tributed representation that is rather cheap in memory

and potentially keep the generalization ability.

Given a training set S of triplets (c

:h, r, c

:t) our

model learns embedding vectors for the entities and

the relations. Each categorised entity c:e is represen-

ted by a embedding vector e

∈ R

, and each rela-

tion r is represented by a embedding vector r ∈ R

Similarly as it was deﬁned in TransE, for each rela-

tion r there is a score function f

(Equation 5) that

represents a dissimilarity using a p-norm metric (in

our experiments we used p = 2), such that the score

) of a plausible triple (c

:h, r, c

:t) is smaller

than the score f

) of a implausible triple (c

:h’,

r, c

:t’).

) = kh

+ r −t

(5)

HEXTRATO: Using Ontology-based Constraints to Improve Accuracy on Learning Domain-speciﬁc Entity and Relationship Embedding

Representation for Knowledge Resolution

In order to learn knowledge embedding represen-

tation, our method uses Stochastic Gradient Descent

(SGD) (Robbins and Monro, 1951) to minimize a

margin-based loss functions L:

L =

∑

:h,r,c

:t)∈S

,r,c

)∈S

[γ + f

) − f

)]

(6)

where, γ is the margin parameter, S is the set

of correct triples, S

is the set of incorrect triples

:h’,r,c

:t) ∪ (c

:h,r,c

:t’), and [x]

= max(0,x).

In TransE, incorrect triples ((h

,r,t)∪(h, r,t

)) are

generated by randomly corrupting either h or t in a

correct triple (h,r,t) ∈ S using different probabilities

for entity replacement (Wang et al., 2014). We follow

the same idea as presented in TransE, but the entity

replacement is randomly chosen from the set of enti-

ties belong to the corresponding type of each relation

domain and range instead.

Entity and relation embedding vectors are initia-

lised with the random uniform normalized initializa-

tion (Glorot and Bengio, 2010). The set of golden

triples is then randomly traversed multiple times al-

ong the training process up to the maximum of 1,000

iterations, such that each training step produces a cor-

rupted triple for each correct triple. HEXTRATO in-

troduces a disjoint veriﬁcation step, performed once

before each training cycle, in which the disjoint mar-

gin is enforced among each set of disjoint entity types.

Finally, at the end of each training iteration, we

impose a L2-norm constraint for the embedding vec-

tors of each entity (khk

≤ q and ktk

≤ q) in order

to prevent the training process to minimize the loss

function L by artiﬁcially increasing the entity embed-

ding norms (no regularization constraint is given to

the relation embedding vectors). The constant q = 1

is commonly used in previous work, but it tends to

produce small embedding vector values for higher va-

lues of k in a k-dimensional space. In order to better

exploit the range of possible embedding values in the

interval [-1,+1], we deﬁne the max magnitude con-

straint for each entity as:

q = max



√



(7)

3.3 Evaluation Datasets

In order to evaluate the effectiveness of our method

and the ability of improving the baseline accuracy

obtained from TransE in domain-speciﬁc data, we

conducted experiments on two real datasets extracted

from InfoSaude (Tissot and Dobson, 2018), a Electro-

nic Health Record (EHR) system.

The system mana-

ges and tracks patient records, being used to meet

the needs of several integrated public health centres

in the city of Florianopolis/Brazil by integrating dif-

ferent information structures to provide required out-

puts, such as the Outpatient Information and Ambu-

latory Care Individual reports, and summarizing data

on the type of care, pregnancies, procedures perfor-

med on the patient, applied vaccines and drug pres-

criptions. Statistics about the evaluation datasets are

given in Table 1:

Table 1: Statistics of domain-speciﬁc benchmark datasets,

given by the number of entities, relations, and triples in

each dataset split – training (LRN), validation (LVD), tu-

ning (TUN) and test (TST) sets.

EHR Datasets

# Demographics Pregnancy

Entities 2237 3088

Relations 6 5

LRN 13875 14588

VLD 463 1997

TUN 475 2093

TST 532 2090

Both EHR datasets are totally de-identiﬁed. Ages

are converted to a range of values to avoid determi-

ning the actual year of birth. New independent se-

quential IDs are assigned to each patient – patients

with more than one admission have distinct IDs in

each EHR dataset. No additional sensitive patient

data is included in any of the datasets. Table 2 pre-

sents the types of entities involved in each kind of re-

lation in the evaluations datasets, as well as the num-

ber of triples available for each kind of relation.

In addition to the EHR datasets, we used an adap-

ted version of FB15K dataset (FB15K-Typed), in

which each entity was categorised based on the des-

cripton of their corresponding relations, so that ma-

king it possible to compare our results with previous

work. We also report results on the Mushroom

da-

taset in order to motivate further experiments and im-

provements in the link prediction task. Both datasets

are available for download.

EHR-Demographics

This dataset comprises a set of 2,185 randomly se-

lected patients who had at least one admission bet-

ween 2014 and 2016. Each patient is described by a

Not publicly available – a synthetic sample is available

at https://github.com/HeglerTissot/hextrato

https://archive.ics.uci.edu/ml/datasets/mushroom

https://github.com/HeglerTissot/hextrato/

KDIR 2018 - 10th International Conference on Knowledge Discovery and Information Retrieval

Table 2: Relations and corresponding entity types (domain and range) found in each domain-speciﬁc benchmark datasets.

Relation Domain (head type) Range (tail type) # Triples

hasGender patient gender 2,185

ageRange patient interval 2,185

hasMaritalStatus patient maritalStatus 1,844

hasMaxEducation patient education 1,815

isSmoker patient boolean 2,185

isPregnant patient boolean 506

inSocialGroup (N:N) patient socialGroup 4,625

(a) EHR-Demographics dataset

Relation Domain (head type) Range (tail type) # Triples

ageYearsWhenLMP patient interval 2,879

hadAbortion patient boolean 2,879

ageWeeksWhenInterrupted patient interval 2,879

ICDBeforeLMP (N:N) patient ICD 5,776

ICDAfterLMP (N:N) patient ICD 6,355

(b) EHR-Pregnancy dataset

set of basic demographic information, including gen-

der, age (range in years) in the admission, marital sta-

tus (unknown for about 15% of the patients), educa-

tion level, and two ﬂags indicating whether the patient

is known to be either a smoker or pregnant, and the

social group. Social groups are assigned to each pa-

tient according to a diverse set of rules mainly based

on demographic and historical data. Social groups are

further used to determine which social programs each

patient can be offered to join.

EHR-Pregnancy

This dataset includes a set of 2,879 randomly selected

pregnant female patients from which pregnancy was

inadvertently and abnormally interrupted before the

expected date of birth. Each patient is described by

age (range in years) by the known date of last men-

strual period (LMP), whether the patient had an abor-

tion (regardless of reason), and a list of ICD-10 (Inter-

national Classiﬁcation of Diseases) codes

registered

either before or after the LMP date. This dataset has

been used in order to identify correlations between

pre and post clinical conditions on pregnant patients

with abnormal pregnancy termination.

3.4 Evaluation Protocol

A commonly used evaluation protocol for knowledge

embedding methods includes a Link Prediction (LP)

task on the test set. LP is a typical question answering

task which aims at completing a triple (h, r,t) with

http://www.who.int/classiﬁcations/icd/en/

h or t missing, by predicting t given (h, r, ?) or pre-

dicting h given (?,r,t), where ? denotes the missing

element. Rather than giving one best answer, this task

is focused on ranking the plausibility of a set of can-

didate entities in descending order of similarity sco-

res, calculated by inducing the score function f

(h,t)

and recording the rank of the correct missing entity.

HEXTRATO is evaluated by predicting t given (c

:h,

r, c

:?) or predicting h given (c

:?, r, c

:t).

Overall results in the related work are usually pre-

sented by reporting the following commonly used

scores as evaluation metrics: a) Mean Rank (MR); b)

Mean Reciprocal Rank (MRR) of correct entities; and

c) the proportion of correct entities in top-N ranked

entities (Hits@N, with N usually equals 10). MRR is

an improved measure of Mean Rank [8] which calcu-

lates the average rank of all the entities (relations) and

calculates the average reciprocal rank of all the enti-

ties (relations). Compared with Mean Rank, MRR is

less sensitive to outliers. A good link predictor should

achieve lower MR or higher MRR and Hits@N. As

long as we aim to deal with more consistent and ca-

tegorised data, we also focus on achieving better per-

formance on the prediction task by comparing ranking

metrics with lower values of N, such as Hits@1 and

Hits@3.

Corrupted triples may also exist in a KG, which

should be also considered as correct from the training

set for instance, ﬂawing the evaluation metrics. Thus,

the LP task may under-estimate those approaches that

rank corrupted but correct triples high. Hence, in or-

der to avoid such a misleading behaviour, all the tri-

ples that appear either in the training, validation, tu-

ning or test set are usually removed from the list of

corrupted triples, ensuring that all corrupted triples do

HEXTRATO: Using Ontology-based Constraints to Improve Accuracy on Learning Domain-speciﬁc Entity and Relationship Embedding

Representation for Knowledge Resolution

Table 3: Evaluation results for the Link Prediction task – Mean Reciprocal Rank (MRR), Mean Rank (MR), Hits@1 (H@1),

Hits@3 (H@3), Hits@10 (H@10) on two EHR datasets.

EHR-Demographics EHR-Pregnancy

MRR MR H@1 H@3 H@10 MRR MR H@1 H@3 H@10

TransE 0.3787 6.01 0.1523 0.4812 0.9173 0.227 103.87 0.103 0.264 0.457

HEXTRATO

(H1) 0.492 3.44 0.266 0.635 0.9530 0.260 27.29 0.146 0.273 0.498

(H2) 0.469 3.65 0.261 0.560 0.9530 0.236 28.17 0.119 0.244 0.502

(H3) 0.505 3.43 0.281 0.634 0.9530 0.270 27.80 0.150 0.288 0.537

(H4) 0.506 3.42 0.282 0.635 0.9531 0.279 26.30 0.153 0.303 0.555

not belong to the data set. In previous works, results

on the evaluation datasets are usually reported as both

“Raw” (possibly ﬂawed) and “Filtered”. In this work,

we report the results referring to the former (“Raw”),

which we believe it provides a clearer view on the

ranking performance for categorised datasets.

We used a grid search on validation set

in order to select the learning rate λ among

{0.001,0.01,0.1}, the margin hyper-parameter γ

among {0.5,1.0,2.0,4.0}, and selected the best mo-

del by early stopping using the average of MMR score

calculated on predicting t on the validation sets, the

embedding dimension k among {8,16,32, 64}. The

dissimilarity measure was set to the L2-norm dis-

tance, and the optimal parameters are determined ac-

cording to performance accuracy on the validation set.

Ten distinct instances of each model were indepen-

dently trained for each set of hyper-parameters. After

traversing all the training triplets at most 1,000 epo-

chs, the best model is chosen by comparing the scores

against a tuning set. Final results are then calculated

over the test set.

4 RESULTS

In order to compare HEXTRATO against previous

works, we performed an initial experiment using an

adapted version of FB15K dataset (FB15K-Typed).

Table 4 compares the link prediction results of

HEXTRATO with results reported in previous work.

The lowest mean rank on the validation set was obtai-

ned when using the L2-norm, k = 32, λ = 0.01, γ =

2.0. Although HEXTRATO does not use projection

matrices for each relation as usually reported by other

methods that extend TransE, it outperforms previous

state-of-the-art methods in “Raw” scores.

Overall results for the EHR datasets in Table 3 re-

port the “raw” Mean Reciprocal Rank, Mean Rank,

and Hists@N scores calculated as the score for pre-

dicting t subtask. The lowest mean rank on the tuning

set was obtained when using the L2-norm, k = 32,

Table 4: Link prediction results – “Raw” Mean Rank (MR)

and Hits@10 (H@10) on FB15K.

Method MR H@10

TransE (Bordes et al., 2013) 243 0.349

SE (Bordes et al., 2011) 273 0.288

TransH (Wang et al., 2014) 212 0.457

TransR (Lin et al., 2015) 198 0.482

STransE (Nguyen et al., 2016) 219 0.516

TransT (Ma et al., 2017) 199 0.533

HEXTRATO (H1) 116 0.535

λ = 0.01, γ = 1.0. We started by running the origi-

nal TransE model on the two evaluation datasets. We

then applied our approach, cumulatively adding each

constraint described in Section 3:

(H1) We added types to each entity, which im-

plicitly set range and domain for each relation, and

restrict the set of ranked entities being evaluated al-

ong the link prediction task. This constraint added

substantial improvement comparatively to the origi-

nal TransE model in both EHR datasets.

(H2) We then coupled the previous attempt (H1)

with disjoint sets of tail entities. All tail types were

set as disjoint groups in both datasets – the patient

type was kept as a non-disjoint set, so that the model

would not enforce minimum disjoint distance among

the patients, allowing them to converge into semantic

similar clusters.

(H3) The disjoint set model (H2) was extended,

so that some of the relations were deﬁned as functio-

nal. Although no signiﬁcant improvement in the sco-

res could be observed, this constraint proved to faci-

litate the step of choosing corrupted tails in order to

produce incorrect triples along the training process.

(H4) We reached the best scores by isolating va-

lues from those relations that originally share types,

such as boolean and interval.

At the current stage we are only evaluating our

model against the baseline TransE model for the EHR

datasets. Further experiments are required in order to

test more complex models that usually extend or use

TransE as a baseline and check whether our proposal

KDIR 2018 - 10th International Conference on Knowledge Discovery and Information Retrieval

Table 5: Resulting scores for each relation in the EHR-Demographics dataset – Mean Reciprocal Rank (MRR), Mean Rank

(MR), Hits@1 (H@1), and Hits@3 (H@3) for the best model (H4) in the Link Prediction task.

EHR-Demographics

Relations MRR MR H@1 H@3

hasGender 0.8194 1.36 0.6389 N/A

ageRange 0.2339 9.42 0.0930 0.2326

hasMaritalStatus 0.5747 2.10 0.2414 0.8621

hasMaxEducation 0.3966 3.63 0.1852 0.3704

isSmoker 0.9286 1.14 0.8571 N/A

inSocialGroup 0.4557 3.28 0.1994 0.6168

Table 6: Resulting scores for each relation in the EHR-Pregnancy dataset – Mean Reciprocal Rank (MRR), Mean Rank (MR),

Hits@1 (H@1), and Hits@3 (H@3) for the best model (H4) in the Link Prediction task.

EHR-Pregnancy

Relations MRR MR H@1 H@3

ageYearsWhenLMP 0.3869 4.08 0.1623 0.4755

hadAbortion 0.8401 1.32 0.6801 N/A

ageWeeksWhenInterrupted 0.3603 5.66 0.1628 0.4286

ICDBeforeLMP 0.0784 52.30 0.0117 0.0417

ICDAfterLMP 0.1218 32.56 0.0319 0.0909

ﬁts into them.

Finally, Tables 5 and 6 detail the resulting scores

for each relation for the best model (H4) highlighted

boldface in Table 3. For the relations where tail en-

tities belong to the type boolean (isSmoker in EHR-

Demographics and hadAbortion in EHR-Pregnancy)

or gender (hasGender in EHR-Demographics) we do

not present the score Hits@3 – it is not applicable as

these relations have only two possible values to be

ranked, so that the resulting score is obviously equals

1. Within the EHR-Demographics dataset, there were

no examples of triples with relation hadAbortion in

the test set, so that the resulting scores for this speci-

ﬁc relation is not being presented in Table 5.

By analysing the results from Table 6, it

becomes evident those many-to-many relations

(ICDBeforeLMP and ICDBeforeLMP) impose most

of the challenge on the LP task. However, the re-

sults presented in Table 5 contrast that assumption

(inSocialGroup). Within the EHR-Demographics da-

taset, both ageRange and inSocialGroup relations

have approximately 20 possible tail values each. Alt-

hough the relation inSocialGroup has cardinality N:N,

it presents better scores than the results referring to

the relation ageRange, which has cardinality (N:1).

Firstly, the social groups assigned to each patient take

into consideration both demographic and clinical his-

torical data, so that, as long as some of this demo-

graphic data is available within the dataset, the re-

sulting model can more easily reason on predicting

what groups should be assigned to each patient. Fi-

nally, the relation ageRange went through a discreti-

sation of a continuous variable age with original va-

lues ranging from 0 to 99. Embedding models are not

designed to deal with continuous values and some in-

formation is supposedly lost along the discretisation

process.

In order to motivate further experiments on publi-

cly available datasets we ﬁnally report the preliminary

results on the Mushroom dataset. Table 7 compares

HEXTRATO and TransE based on “raw” Mean Re-

ciprocal Rank, Mean Rank, and Hists@N scores cal-

culated as the score for predicting t subtask. In ad-

dition we also present the accuracy of each model,

based on the Hists@1 score for the relation has class.

The highest accuracy on the tuning set was obtained

when using the L2-norm, k = 64, λ = 0.1, γ = 1.0

for TransE, and using the L2-norm, k = 64, λ = 0.01,

γ = 2.0 for HEXTRATO (H4). Results from the at-

tempts using distinct values ok k along this described

set of hyperarameters are also presented to demon-

strate how changes increasing the dimensionality of

the low embedding space positively affect our model.

5 CONCLUSIONS

In this paper, we present HEXTRATO, a novel know-

ledge embedding approach that couples previous ba-

seline TransE model with ontology-based constraints

in order to better capture the relationships between

entities and their symbolic representation in the vec-

tor space.

Experimental benchmark results on an adapted

HEXTRATO: Using Ontology-based Constraints to Improve Accuracy on Learning Domain-speciﬁc Entity and Relationship Embedding

Representation for Knowledge Resolution

Table 7: Evaluation results for the Link Prediction task on the Mushroom dataset (Entities=8487, Relations=23, Tri-

ples={153057, 9525, 9564, 18942} for training, validation, tuning and test sets) – Mean Reciprocal Rank (MRR), Mean

Rank (MR), Hits@1, Hits@3, Hits@5, Hits@10, and Accuracy (equivalent to Hits@1 on predicting the relation has class).

MRR MR Hits@1 Hits@3 Hits@5 Hits@10 Accuracy

TransE 0.565 472.32 0.466 0.643 0.682 0.718 53.1%

HEXTRATO (H4)

k = 8 0.717 2.054 0.553 0.856 0.955 0.993 88.6%

k = 16 0.763 1.856 0.619 0.892 0.961 0.994 89.3%

k = 32 0.804 1.712 0.683 0.914 0.964 0.994 90.7%

k = 64 0.814 1.688 0.703 0.915 0.965 0.996 95.3%

version of Freebase, on a publicly available da-

taset, and on two domain-speciﬁc datasets show

HEXTRATO outperforms previous state-or-the-art

methods in the link prediction task when using cate-

gorised entities. Some of the directions in which this

work can be extended include:

TransE-like extended models. Learning embed-

ding representation from more structured knowledge

sources can beneﬁt from the inherit enriched meta-

data. HEXTRATO is a constraint-based method that

extends TransE in order to obtain an initial baseline

for the evaluation task when dealing with domain-

speciﬁc categorised datasets. We plan to evaluate our

method coupled with more complex embedding mo-

dels originated from TransE.

Many-to-many relationships. Normalising N:N

relations can make an embedding model more ﬂexi-

ble. However, it adds additional level of complexity

in terms of learning semantically related entities. Alt-

hough preliminary experiments did not show effective

improvement over previously applied constraints, we

believe further investigation can demonstrate whether

more speciﬁc conditions can lead our model to reach

better results.

Activation functions. More complex embedding

models deal with projection matrices and rely on sim-

ple linear neural networks. We plan to investigate

whether alternatively coupling ontology-based con-

straints with non-linear activation functions, such as

RELUs, Sigmoid, or Tanh, can improve the embed-

ding model performance on domain-speciﬁc datasets.

Hybrid approaches. Distinct sets of relation em-

bedding representations can be more effectively learnt

from distinct approaches. Tightening state-of-the-art

bounds by combining different methods into a hybrid

approach in which each relation can be represented by

a distinct embedding model can produce models that

are more ﬂexible on learning distinct types of relati-

onships between entities within a dataset.

Unseen entities. The primordial assumption when

dealing with any kind of machine learning model is

the ability of such resulting model on generalising.

Embedding models are weak regarding to this aspect.

Validation and test sets are required to be designed

with entities and relations that appear at least once in

the training set. We plan to investigate how embed-

ding models coupled with ontology-based constraints

can be used to learn low-embedding representation

for unseen entities along the validation, tuning and

test steps.

REFERENCES

Bengio, Y., Larochelle, H., and Vincent, P. (2005). Non-

local manifold parzen windows. In Weiss, Y.,

Sch

olkopf, B., and Platt, J., editors, Advances in

Neural Information Processing Systems 18 (NIPS’05),

Cambridge, MA. MIT Press.

Bollacker, K., Evans, C., Paritosh, P., Sturge, T., and Taylor,

J. (2008). Freebase: A collaboratively created graph

database for structuring human knowledge. In Procee-

dings of the 2008 ACM SIGMOD International Con-

ference on Management of Data, SIGMOD ’08, pages

1247–1250, New York, NY, USA. ACM.

Bordes, A., Usunier, N., Garcia-Duran, A., Weston, J., and

Yakhnenko, O. (2013). Translating embeddings for

modeling multi-relational data. In Burges, C. J. C.,

Bottou, L., Welling, M., Ghahramani, Z., and Wein-

berger, K. Q., editors, Advances in Neural Information

Processing Systems 26, pages 2787–2795. Curran As-

sociates, Inc.

Bordes, A., Weston, J., Collobert, R., and Bengio, Y.

(2011). Learning structured embeddings of know-

ledge bases. In Conference on Artiﬁcial Intelligence.

Dong, X., Gabrilovich, E., Heitz, G., Horn, W., Lao, N.,

Murphy, K., Strohmann, T., Sun, S., and Zhang, W.

(2014). Knowledge vault: A web-scale approach to

probabilistic knowledge fusion. In Proceedings of

the 20th ACM SIGKDD International Conference on

Knowledge Discovery and Data Mining, KDD ’14,

pages 601–610, New York, NY, USA. ACM.

Fellbaum, C., editor (1998). WordNet: an electronic lexical

database. MIT Press.

Gardner, M. and Mitchell, T. (2015). Efﬁcient and expres-

sive knowledge base completion using subgraph fe-

ature extraction. In Proceedings of the 2015 Con-

ference on Empirical Methods in Natural Language

Processing, pages 1488–1498. Association for Com-

putational Linguistics.

KDIR 2018 - 10th International Conference on Knowledge Discovery and Information Retrieval

Glorot, X. and Bengio, Y. (2010). Understanding the dif-

ﬁculty of training deep feedforward neural networks.

In Teh, Y. W. and Titterington, D. M., editors, Pro-

ceedings of the Thirteenth International Conference

on Artiﬁcial Intelligence and Statistics (AISTATS-10),

volume 9, pages 249–256.

Krompaß, D., Baier, S., and Tresp, V. (2015). Type-

constrained representation learning in knowledge

graphs. In Proceedings of the 13th International Se-

mantic Web Conference (ISWC).

Lin, H., Liu, Y., Wang, W., Yue, Y., and Lin, Z. (2017). Le-

arning entity and relation embeddings for knowledge

resolution. Procedia Computer Science, 108(Supple-

ment C):345 – 354. International Conference on Com-

putational Science, ICCS 2017, 12-14 June 2017, Zu-

rich, Switzerland.

Lin, Y., Liu, Z., Sun, M., Liu, Y., and Zhu, X. (2015). Le-

arning entity and relation embeddings for knowledge

graph completion. In Proceedings of the Twenty-Ninth

AAAI Conference on Artiﬁcial Intelligence, AAAI’15,

pages 2181–2187. AAAI Press.

Ma, S., Ding, J., Jia, W., Wang, K., and Guo, M. (2017).

Transt: Type-based multiple embedding representati-

ons for knowledge graph completion. In The Euro-

pean Conference on Machine Learning and Principles

and Practice of Knowledge Discovery in Databases.

Nguyen, D. Q., Sirts, K., Qu, L., and Johnson, M. (2016).

Stranse: a novel embedding model of entities and rela-

tionships in knowledge bases. CoRR, abs/1606.08140.

Robbins, H. and Monro, S. (1951). A stochastic approxi-

mation method. Ann. Math. Statist., 22(3):400–407.

Suchanek, F. M., Kasneci, G., and Weikum, G. (2007).

Yago: A core of semantic knowledge. In Procee-

dings of the 16th International Conference on World

Wide Web, WWW ’07, pages 697–706, New York,

NY, USA. ACM.

Taskar, B., fai Wong, M., Abbeel, P., and Koller, D. (2003).

Link prediction in relational data. In in Neural Infor-

mation Processing Systems.

Tissot, H. and Dobson, R. (2018). Identifying misspelt

names of drugs in medical records written in portu-

guese. HealTAC-2018: Unlocking Evidence Contai-

ned in Healthcare Free-text.

Wang, Z., Zhang, J., Feng, J., and Chen, Z. (2014). Know-

ledge graph embedding by translating on hyperplanes.

In Brodley, C. E. and Stone, P., editors, AAAI, pages

1112–1119. AAAI Press.

HEXTRATO: Using Ontology-based Constraints to Improve Accuracy on Learning Domain-speciﬁc Entity and Relationship Embedding

Representation for Knowledge Resolution
