Speech Application Programming Interface for English

Pronunciation Learning

Achmad Teguh Wibowo

, Moch Yasin

, Mohammad Khusnu Milad

, Muhammad Andik Izzuddin

and Faris Mushlihul Amin

Departement of Information System, UIN Sunan Ampel, Jl. A Yani 117, Surabaya, Indonesia

Keywords: Learning, Teaching, Media, Speech Application Programming Interface, Human-Computer Interaction.

Abstract: Teaching and learning activity is a compulsory activity that should be done by all citizens in Indonesia for at

least nine years. This activity involves a role of a teacher in teaching students. A learning material, such as

English language, should be practiced by students for better understanding, whereas the quality of English

teachers in Indonesia varies between people. This tends to make students have differing levels of skill mastery

in this language learning depending on the teacher, especially in pronunciation. Current development of

technologies allows people to be more interactive. One of these technologies is the Speech Application

Programming Interface. This technology allows people to talk to the computer. This research proposes a new

learning method that involves a computer system that displays a set of attractive images and has the ability to

listen to student’s voice. Voice input is converted into text and will be matched to the data using an if-then

method. If the text is in the data, the student’s answer is correct. Thus, human-computer interaction can

improve the learning process because students become happier and have more standardized pronunciation

skill results.

1 INTRODUCTION

In the learning and teaching activities at a school,

interactions take place between a teacher and students

or between a student and another when there is a

group learning activity. In these interactions, a

learning process occurs. Learning is generally defined

as a process that brings together cognitive, emotional,

and environmental influences and experiences to

obtain, improve, or make changes, knowledge, skills,

values, and worldviews (Illeris, 2000).

A teaching and learning process is a process of

action that is done intentionally, which then leads to

a change, the situation of which is different from the

actions caused by others (Suryabrata, 2001).From the

definition, not all changes refer to teaching and

learning. Some changes contain a conscious effort to

achieve certain goals. A teaching and learning

process will be more effective if it is not only taught,

but also practiced directly.

Current technological developments have been

able to facilitate teaching and learning activities to

become more interactive. One of such developments

is the Speech Application Programming Interface

(SAPI) technology. SAPI is the result of research

conducted by Microsoft Corporation in the form of

technology and standards for speech ingestion that

can be processed by a computer (speech-to-text)

(Syarif et al., 2011).

This research’s product is a computer-

/application-based learning medium. This application

will try to translate a user's speech into text, which

will be matched with the existing database. If the text

matches the data that appears, the user will get an

additional point. If it does not match, it will switch to

the next question without giving the user additional

points.

The use of the SAPI technology for the teaching

and learning of English pronunciation in the early

childhood education can be an interesting solution.

Because by utilizing computers a learning process can

be more interactive and less boring, the principle of

Human-Computer Interaction (HCI) is to make the

system engage in dialogues with the user in as

friendly and efficient a manner as possible.

Wibowo, A., Yasin, M., Milad, M., Izzuddin, M. and Amin, F.

Speech Application Programming Interface for English Pronunciation Learning.

DOI: 10.5220/0008903800002481

In Proceedings of the Built Environment, Science and Technology International Conference (BEST ICON 2018), pages 321-325

ISBN: 978-989-758-414-5

321

2 BASIC THEORY

2.1 Natural Language

Natural language is an interactive communicative

mechanism. The computer cannot understand the

instructions that humans use in everyday language.

Natural language can understand written input and

speech input (Dix, 2009). However, there are still

deficiencies in terms of ambiguity in syntactic and

semantic aspects. The oral dialogue system consists

of several components needed so that the system can

function successfully, including speech recognition

and text-to-speech systems (Mc Tear, 2004).

2.2 Speech Recognition

Each speech recognition system essentially runs a

process for recognizing human speech and turning it

into something that is understood by computers

(Amundsen, 1996). Research into effective speech

recognition algorithms and processing models has

lasted almost since computers were created. There are

4 key operations of listening and understanding

human speech.

1. Word separation is the process of creating

discreet from human speech. Each section can be

a large or small phrase as a single syllable or a

word part.

2. Vocabulary is a list of sound items that can be

identified by speech recognition engines.

3. Word matching is a speech recognition system

method that is used to search for voice parts in the

vocabulary system.

4. Speaker dependence is the extent to which speech

recognition machines depend on vocal tones and

individual speech patterns.

The last element of speech recognition is grammar

rules. Grammar rules are used by speech recognition

software to analyze human speech input in the

process of trying to understand what someone is

saying. There are many grammar rules, each of which

consists of a set of pronunciation rules. One of them

is the context-free grammar (CFG). The main

elements of CFG are the following:

1. Word, a list of valid cases to say;

2. Rules, greeting structures for words used; and

3. List, word list for use in rules.

2.3 Speech Application Programming

Interface (SAPI)

Two basic types of SAPI machines are text-to-speech

and speech recognition. The TTS system synthesizes

text strings and files into speech audios using

synthetic sounds. On the other hand, speech

recognition converts human-spoken audios into

readable text strings. The application can control text-

to-speech by using ISpVoice's Component Object

Model (COM). After the application is created, call

ISpVoice: Speak to generate speech output from

some text data.

An application has two choices of speech

recognition engine types (ISpRecognizer). A shared

recognition that might be shared with other speech

recognition applications is recommended for most

speech recognition applications. To create an

ISpRecoContext for a shared ISpRecognizer (shared),

the application only needs to make a

CoCreateInstance COM call to the

CLSID_SpSharedRecoContext component. For large

server applications that will run alone on a system,

where performance is the key, the InProc speech

recognition engine is more appropriate. In order to

create ISpRecoContext for ISpRecognizer InProc,

firstly, the application must call CoCreateInstance on

the CLSID_SpInprocRecoInstance component to

create its own ISpRecognizer InProc. Next, the

application can call ISpRecognizer:

CreateRecoContext to get an ISpRecoContext.

Finally, a speech recognition application must

create, load, and activate ISpRecoGrammar, which

basically shows the type of utterance to be

recognized, namely dictation or command and

control. First, this application creates

ISpRecoGrammar using ISpRecoContext:

CreateGrammar. Then, it loads the appropriate

grammar application either by calling

ISpRecoGrammar: loadDictation for dictation or one

of the methods ISpRecoGrammar: LoadCmdxxx for

commands and controls. Finally, this grammar rule is

activated so that speech recognition data starts the

application for commands and controls (Syarif et al.,

2011).

3 RESEARCH CONCEPT

3.1 Thinking Framework

The framework for thinking in this research is shown

in Figure 1.

3.2 Flow Chart and Problem Solution

Flow charts and problem solutions from the Speech

Application Programming Interface for English

Pronunciation Learning appear in Figure 2 starting

BEST ICON 2018 - Built Environment, Science and Technology International Conference 2018

322

from the user giving the voice captured by the

microphone. The data captured by the microphone is

processed by the SAPI which changes speech to text.

The resulting text will be captured into the input form

that will be matched into the database. If the text

matches the database, the points will increase and the

next question will be shown. However, if it does not

match, the user is given time to say the word again

within a specified time period (±15 seconds). If the

data input until the time is over is still wrong, the user

should proceed to the next question without getting

additional points.

Figure 1: Framework for Thinking.

Figure 2: Flowchart and Problem Solution.

4 RESULTS

4.1 View of Home

Figure 3 is the view of home of the application. In the

application view, there is a navigation that shows the

total points that are used for displaying the points

obtained by the user in using this application. There

is also a folder that is used to navigate the questions

in the application. There are other games to choose

and a timer that functions as a counter next to the

problem if the user does not answer correctly.

Figure 3: View of Home.

4.2 Wrong Answer

Figure 4 is the view of wrong answer of the

application. In the application display, it can be seen

that the map number 1 is red, which indicates that the

answer is wrong. Figure 4 can be seen below.

Figure 4: View of Wrong answer.

4.3 Right Answer

Figure 5 is the view of correct answer of the

application. In the application, it can be seen that

maps number 1, 2, and 3 are blue, which indicates that

the user's answers are correct. Correct answers will

affect the total points. In this view, the user gets total

points of 60, which come from 3 correct answers.

Learning Media

Application

NUI HCI BCI

SAPI

Finish

Research

Purpose

Speech Application Programming Interface for English Pronunciation Learning

323

Each answer is worth 20 points. Figure 5 can be seen

below.

Figure 5: View of Right answer.

4.4 Finish View of the Application

Figure 6 is the finish view of the application. In the

application view, the total points that were

successfully obtained by the user are displayed, and

in the map, it is shown that there are 3 correct

answers, with the maps turning blue, and 2 incorrect

answers, with the maps turning red. In addition, there

is a message of total wages earned. Figure 6 can be

seen as follow.

Figure 6: Finish View of the Application.

4.5 System Testing

Application testing was conducted using computer

devices in the form of laptops and all-in-one desktop

computers with the following specifications: For

laptop we used Lenovo IdeaPad Z480 laptops,

hereinafter referred to as Laptop (specification as

seen on table 1) and Lenovo IdeaCentre desktop PCs,

hereinafter referred to as Desktop, with the the

specification can be seen on table 2/.

Table 1: Laptops specification.

Processor Intel Core i7

GPU Nvidia GeForce Cuda

Internal RAM 8 Gb

Wi-fi Ready

Bluetooth Ready

USB USB 2 and USB 3

Connectivity HDMI, camera, microphone,

Ethernet and USB

Storage HDD 500 GB

OS Windows 7

Table 2: Desktop computers specification.

Processor Intel Core i7

GPU Nvidia GForce Cuda

Internal RAM 4 Gb

Wi-fi Ready

Bluetoth Ready

USB USB 2 and USB 3

Connectivity HDMI, camera, microphone,

Ethernet and USB

Storage HDD 250 GB

OS Windows 10

The application testing result can be seen on table

Table 3: Results of application testing.

Features Laptop Desktop

Display the start page

 

Change points if the answer

is correct

 

The application keeps

countering if the answer is

wrong

 

Change the map to blue if

the answer is correct

 

Change the map to red if the

answer is wrong

 

Display the total points if

all questions are done

 

Use a man’s voice  

Use a woman's voice  

5 CONCLUSIONS

From the test results, it can be concluded that the

Speech Application Programming Interface for

English pronunciation learning has been completed.

It is suggested that future research should add

BEST ICON 2018 - Built Environment, Science and Technology International Conference 2018

324

facilities to make more applications such as vehicles,

animals, etc. and that this application should be

developed into a mobile-based application. The SAPI

technology can be used not only to learn English but

also to learn other languages such as Javanese,

Chinese, Arabic, etc.

REFERENCES

Amundsen, Michael C. MAPI, (1996) . SAPI and TAPI

Developer’s Guide, Indianapolis, Sams Publishing

Dix, Alan, Janet Finlay, Gregory D. Abowd, and Russle

Beale. (2009). Human Computer Interaction, Third

Edition, New Delhi, Pearson Education

Hadi, Rahadian. (2005). Panduan Bagi Pemrograman

Microsoft Windows Common Control, Jakarta, Alex

Media Komputindo

Hendrayudi. (2009). VB 2008 untuk Berbagai Keperluan

Programming, Jakarta, Alex Media Komputindo

McTear, Michael F. (2004). Spoken Dialogue Technology

Toward the Conversational User Interface, London,

Springer

Syarif A, Daryanto T, Arifin MZ. (2011). Aplikasi Speech

Application Programming Interface (SAPI) 5.1 Sebagai

Perintah Untuk Pengoperasian Aplikasi Berbasis

Windows, Yogyakarta, SNATI 2011

Speech Application Programming Interface for English Pronunciation Learning

325
