The Performance of Anchor Model in Data Warehousing

Gladly Caren Rorimpandey, Jan Pieter Zwart, Julyeta Paulina Amelia Runtuwene, Ferdinan Ivan

Sangkop, Vivi Peggie Rantung, Parabelem Tinno Dolf Rompas, and Cindy Pamela C. Munaiseche

Universitas Negeri Manado, North Sulawesi, Indonesia

Keywords: Data Model, Data Warehouse, Anchor Model, Inferential Statistics, Post-Hoc Analysis, SQL Server

Abstract: Data model performance became one of essential to be future-proof criteria in data warehouse. The aim of

this research is to proof that the performance of Anchor Model as good as the performance of traditional

data models that used in data warehousing. The research method is inferential statistics which takes one

scenario to generate the sample of data by using SQL Server as the RDBMS. The performance result is

discussed by Post-hoc analysis. The experiment performed evidently shows that the Anchor Model has no

significantly different with Optimal Normal Form and Data Vault but it has significantly different with star

schema. It means the time execution in the SQL statement with more join tables will be shorter than the

SQL statement with less join tables. So, the companies that will design and develop data warehouse can be

consider to using Anchor Model as their data model in data warehousing.

1 INTRODUCTION

A data warehouse is a database used for reporting

and making analyse. It focuses on the modelling and

analysis of data for decision hence data warehouse

typically provide a simple and concise view of

particular subject issue by excluding data that are

not useful in the decision support process (Kujur and

Oraon, 2016). Nowadays, many companies are using

data warehouse (Bassil, 2012). The reason are: a

data warehouse can help to manage large amounts of

data in a structured way, needing less time to read

and analyse them compared to regular data

architecture.

Data model is the starting point for designing and

developing of data warehouses environment

(Rönnbäck et al.., 2010). Data model made the

designing of data warehouse become easier and

clearer. Inmon said it is like a roadmap of the data

warehouse development (Inmon, 2013). Data model

is used to support developers of OLAP, data mining,

and reporting system. Besides that, it acts as

documentation for the final data warehouse.

Therefore, data model performance is very important

to support the efficiency of data warehouse.

Anchor Model which the one of data model used

in data warehouses is a technique recently advocated

by Lars Rönnbäck. It uses 6 Normal Form (6NF)

databases which are generately expected to perform

badly. But, in October 2010 Lars Rönnbäck and

friends performed the result of their research that

Anchor Model performs substantially better than

databases constructed using traditional modeling

techniques (Rönnbäck et al.., 2010). More than that,

they claim however that query optimizers (SQL

Server) are so powerful that performance issues are

no longer important as for as table designs are

concerned. Our research that publish in early 2018

also found that lack of redudancy has influence to

the performance of data model in data warehouse, in

terms of accessing it (Rorimpandey et al.., 2018).

This reaseach is to extend the research of our group.

The aim of this research is to look into deep the

performance of Anchor Model in data warehousing

and compare with the traditional data model, such as

Star Schema, Data Vault and Optimal Normal Form

(ONF) by using post-hoc analysis. The scenario and

population method of this research will used same as

the previous research.

2 METHODS

The method of this research is using inferential

method is inferential statistics which takes one

scenario to generate the sample of data by using

SQL Server as the RDBMS. This research is start by

designing queries for Anchor Model and others to

298

Rorimpandey, G., Zwart, J., Runtuwene, J., Sangkop, F., Rantung, V., Rompas, P. and Munaiseche, C.

The Performance of Anchor Model in Data Warehousing.

DOI: 10.5220/0009010102980302

In Proceedings of the 7th Engineering International Conference on Education, Concept and Application on Green Technology (EIC 2018), pages 298-302

ISBN: 978-989-758-411-4

answer the 13 information needs. Then, the

performance will be analyzed with post-hoc analysis

because the previous research is done just ANOVA

analysis. The post-hoc analysis should be done if

there is significant different (Pereira, Afonso and

Medeiros, 2015). Therefore in this research, it‟s

needed to be tested because the previous research

shown that there is significant difference of lack

performance by star schema. The research design is

described by Figure 1. The data of time execution

will be automatically shown in SQL because the

query that designed is also for counting the duration

of time execution.

Figure 1: Research design.

3 RESULTS AND DISCUSSION

The scenario used in this research has taken from

previous research of performance comparison. The

original scenario has taken from Anchor Model

Team that used in online modeller. The Anchor

Model in this research is created from online tool of

Anchor Model. The Anchor Model in this research is

created from online tool of Anchor Model. From the

FCO-IM point of view, all the nominalized fact

types that absorb roles became anchors. The

absorbed roles which are played by label type

become static attributes. A knot is from a

nominalized fact type with one role covered by one

UC and has nominalized fact type that absorbed

roles. If it is connected to the nominalized fact type

that absorbed roles through a non-nominalized fact

type with time validity, then it is a historized knot

(Simanjuntak et al.., 2016). A non-nominalized fact

type that connected with two nominalized fact types

that absorbed roles become tie. If the non-

nominalized fact type has roles with time validity,

then it is a historized tie. Furthermore, if other role

of the non-nominalized fact type which is played by

label type, then make the role as anchor or knot

(depend on modeller).

As mention in methods part, the first step of this

research is design queries for 13 information needs.

The testing is based on 13 information needs (suites)

which implemented to the historized tables. So, for

each model will be tested on historized „tables‟ by

thirteen information needs. Each model has different

SQL query because of the difference of table

structures for each model. The differences can be

found in the table below which shown testing query

for two information needs between Star Schema

model and Anchor Model.

Table 1 : Queries between star schema & anchor model

Star Schema

Anchor Model

SELECT

FROM_DATE, SSN,

USERNAME,

BIRTHDATE,

PROFESSIONAL_LE

VEL, GENDER,

ETHNICITY

FROM

STAR_HistorizationSc

enario..ACTOR_DIM

SELECT

T8.AC_ETH_C

hangedAt

,T2.AC_SSN_Acto

r_SocialSecurityNumb

,T3.AC_USR_Act

or_Username

,T4.AC_BIR_Acto

r_Birthdate

,T5.AC_PLV_Acto

r_ProfessionalLevel

,T7.GEN_Gender

,T9.ETH_Ethnicity

FROM

AM_HistorizationScen

ario..AC_Actor T1

INNER JOIN

AM_HistorizationScen

ario..AC_SSN_Actor_

SocialSecurityNumber

T1.AC_ID =

T2.AC_ID

INNER JOIN

AM_HistorizationScen

ario..AC_USR_Actor_

Username T3

T1.AC_ID =

T3.AC_ID

INNER JOIN

The Performance of Anchor Model in Data Warehousing

299

Star Schema

Anchor Model

AM_HistorizationScen

ario..AC_BIR_Actor_

Birthdate T4

T1.AC_ID =

T4.AC_ID

INNER JOIN

AM_HistorizationScen

ario..AC_PLV_Actor_

ProfessionalLevel T5

T1.AC_ID =

T5.AC_ID

INNER JOIN

AM_HistorizationScen

ario..AC_GEN_Actor_

Gender T6

T1.AC_ID =

T6.AC_ID

INNER JOIN

AM_HistorizationScen

ario..GEN_Gender T7

T6.GEN_ID =

T7.GEN_ID

INNER JOIN

AM_HistorizationScen

ario..AC_ETH_Actor_

Ethnicity T8

T1.AC_ID =

T8.AC_ID

INNER JOIN

AM_HistorizationScen

ario..ETH_Ethnicity T9

T8.ETH_ID =

T9.ETH_ID

SELECT

RATING,

PERFORMANCE_CO

DE ,

COUNT(PERFORMA

NCE_CODE) AS

TOTAL_RATING_PE

R_PCODE

,MAX(FROM

_DATE) AS

LASTDATE_RATIN

,MIN(FROM_

DATE) AS

FIRSTDATE_RATIN

FROM

SELECT

T5.RAT_Rating,

T3.PE_COD_Performa

nce_Code

,COUNT(T3.P

E_COD_Performance_

Code) AS

TOTAL_RATING_PE

R_PCODE

,MAX(T4.PE_

RAT_ChangedAt) AS

LASTDATE_RATING

,MIN(T4.PE_R

AT_ChangedAt) AS

FIRSTDATE_RATIN

FROM

Star Schema

Anchor Model

STAR_HistorizationSc

enario2..PERFORMA

NCE_DIM

WHERE

RATING <= 5

GROUP BY

RATING,

PERFORMANCE_CO

HAVING

COUNT(PERFORMA

NCE_CODE) >= ALL

(SELECT

COUNT(PERFORMA

NCE_CODE)

FROM

STAR_HistorizationSc

enario2..PERFORMA

NCE_DIM

WHERE

RATING <= 5

GROUP BY

RATING,

PERFORMANCE_CO

DE)

AM_HistorizationScen

ario2..PE_AUD_Perfor

mance_Audience T1

INNER JOIN

AM_HistorizationScen

ario2..PE_Performance

T1.PE_ID = T2.PE_ID

INNER JOIN

AM_HistorizationScen

ario2..PE_COD_Perfor

mance_Code T3

T1.PE_ID = T3.PE_ID

INNER JOIN

AM_HistorizationScen

ario2..PE_RAT_Perfor

mance_Rating T4

T1.PE_ID = T4.PE_ID

INNER JOIN

AM_HistorizationScen

ario2..RAT_Rating T5

T4.RAT_ID =

T5.RAT_ID

WHERE

T5.RAT_Rating <= 5

GROUP BY

T5.RAT_Rating,

T3.PE_COD_Performa

nce_Code

HAVING

COUNT(T3.PE_COD_

Performance_Code)>=

ALL

(SELECT

COUNT

(PE_COD_Performanc

e_Code)

FROM

AM_HistorizationScen

ario2..PE_RAT_Perfor

mance_Rating T11

INNER

JOIN

AM_HistorizationScen

ario2..PE_Performance

T12

ON T11.PE_ID

= T12.PE_ID

INNER

JOIN

AM_HistorizationScen

EIC 2018 - The 7th Engineering International Conference (EIC), Engineering International Conference on Education, Concept and

Application on Green Technology

300

Star Schema

Anchor Model

ario2..PE_COD_Perfor

mance_Code T13

ON T11.PE_ID

= T13.PE_ID

INNER

JOIN

AM_HistorizationScen

ario2..RAT_Rating

T15

T11.RAT_ID =

T15.RAT_ID

WHERE

T15.RAT_Rating <= 5

GROUP BY

T15.RAT_Rating,

T13.PE_COD_Perform

ance_Code)

From the Table 1, it shows that the differences of

writing SQL query between the models are

significant different. Anchor Model needs more join

tables to get information need than star schema

which the information need can be found in one

table. Based on the testing queries, the Anchor

Model performance is shown by Figure 2.

The result of this performance comparison is

based on time execution in milliseconds. Time

execution is called duration which took time

between start time and end time. Start time is the

time when the query starts to execute, while end

time is the time when the query finishes the

execution. The result of the previous research, The

rejected null-hypothesis means it was established

that some difference between these four models does

indeed exist. No information about what difference

that is can be obtained in the way however. For that,

the post-hoc analysis is needed in this experiment

(Rorimpandey et al.., 2018).

Figure 2: Performance of anchor model.

The post-hoc analysis was done using Sidak‟s

multi comparisons test in GraphPad Prism 6. This is

essentially a series of paired tests, taking multi

comparison aspects into account somehow. The

Figure 3 below has shown the post-hoc analysis.

Figure 3: Post-hoc analysis.

Based on this result of the experiment, the analysis by

post-hoc, data models with the lack of redundancy has

significant influence to the performance of data model in

data warehousing, in terms of accessing it. Furthermore,

data models in data warehousing is a part of online

transaction processing (OLTP) systems which have many

writes, or frequent updates, may not be able to take

advantage of indexed views because of the increased

maintenance cost associated with updating both the view

and underlying base tables. It evidently shows by the

result of information need 12. So, the indexes will short

the performances of data models in accessing some of the

information needs in data models of data warehousing but

not all information needs. The performance between the

ONF, the Anchor Model, and the Data Vault is not

significantly different. So, the Anchor Model performance

is good as Data Vault and ONF but can be better than Star

Schema.

4 CONCLUSIONS

Based on the results of this research the main

question can be answered: “Is anchor model will

perform better than the traditional data model in data

warehousing?” The analysis testing shown that

anchor model has same performance with Data

Model and ONF but, Star Schema has bad

performance. This also proof that the query

execution will be shorter if there are many join

tables than less join tables. So, the companies that

will design and develop data warehouse can be

consider to using Anchor Model as their data model

in data warehousing.

The Performance of Anchor Model in Data Warehousing

301

REFERENCES

Bassil, Y., 2012. A Data Warehouse Design for A typical

University Information System. Journal of Computer

Science & Research., Vol 6(2), pp 12-17.

Inmon, W., . Building the data warehouse, Wiley

Publishing. Canada, 4

edition.

Kujur, A G P., Oraon, A., 2016, A Data Warehouse

Design and Usagel. International Research Journal of

Engineering and Technology. IRJE, Vol 3(11), pp

335-337

Pereira, D G., Afonso, A., 2015. Overview of friedman’s

Test and Post hoc Analysis. Communication in

statistics-simulation and computation, Vol 44(10), pp

2636-2653

Ronnback, L., Johannesson, P., Regardt, O., Wohed, P.,

2010. Anchor Modeling-Agile Information modelling

in Envolving Data Environment. Journal of Data and

Knowledge Engineering. Research Gate, Vol 69(12),

pp 1229-1253

Rorimpandey, G C., Sangkop, F I., Rantung, V P., Zwart,

J P., Liando, O E S., Mewengkang, A., 2018. Data

Model Performance in Data Warehousing. IOP Conf.

Series: Materials Sciences and Engineering. IOP

Publishing, Vol 306., pp 1-6

EIC 2018 - The 7th Engineering International Conference (EIC), Engineering International Conference on Education, Concept and

Application on Green Technology

302
