Active Learning for Deep Object Detection

Clemens-Alexander Brust

, Christoph K

ading

1,2

and Joachim Denzler

1,2

Computer Vision Group, Friedrich Schiller University Jena, Germany

Michael Stifel Center Jena, Germany

Keywords:

Active Learning, Deep Learning, Object Detection, YOLO, Continuous Learning, Incremental Learning.

Abstract:

The great success that deep models have achieved in the past is mainly owed to large amounts of labeled

training data. However, the acquisition of labeled data for new tasks aside from existing benchmarks is both

challenging and costly. Active learning can make the process of labeling new data more efﬁcient by selecting

unlabeled samples which, when labeled, are expected to improve the model the most. In this paper, we

combine a novel method of active learning for object detection with an incremental learning scheme (K

ading

et al., 2016b) to enable continuous exploration of new unlabeled datasets. We propose a set of uncertainty-

based active learning metrics suitable for most object detectors. Furthermore, we present an approach to

leverage class imbalances during sample selection. All methods are evaluated systematically in a continuous

exploration context on the PASCAL VOC 2012 dataset (Everingham et al., 2010).

1 INTRODUCTION

Labeled training data is highly valuable and the ba-

sic requirement of supervised learning. Active lear-

ning aims to expedite the process of acquiring new

labeled data, ordering unlabeled samples by the ex-

pected value from annotating them. In this paper, we

propose novel active learning methods for object de-

tection. Our main contributions are (i) an incremental

learning scheme for deep object detectors without ca-

tastrophic forgetting based on (K

ading et al., 2016b),

(ii) active learning metrics for detection derived from

uncertainty estimates and (iii) an approach to leverage

selection imbalances for active learning.

While active learning is widely studied in classi-

ﬁcation tasks (Kovashka et al., 2016; Settles, 2009),

it has received much less attention in the domain of

deep object detection. In this work, we propose met-

hods that can be used with any object detector that

predicts a class probability distribution per object pro-

posal. Scores from individual detections are aggrega-

ted into a score for the whole image (see Fig. 1). All

methods rely on the intuition that model uncertainty

and valuable samples are likely to co-occur (Settles,

2009). Furthermore, we show how the balanced se-

lection of new samples can improve the resulting per-

formance of an incrementally learned system.

In continuous exploration application scenarios,

e.g., in camera streams, new data becomes available

over time or the distribution underlying the problem

changes itself. We simulate such an environment

using splits of the PASCAL VOC 2012 (Everingham

et al., 2010) dataset. With our proposed framework,

a deep object detection system can be trained in an

incremental manner while the proposed aggregation

schemes enable selection of valuable data for anno-

tation. In consequence, a deep object detector can

explore unknown data and adapt itself involving mi-

nimal human supervision. This combination results

in a complete system enabling continuously changing

scenarios.

1.1 Related Work

Object Detection using CNNs. An important con-

tribution to object detection based on deep learning

is R-CNN (Girshick et al., 2014). It delivers a con-

siderable improvement over previously published sli-

ding window-based approaches. R-CNN employs se-

lective search (Uijlings et al., 2013), an unsupervised

method to generate region proposals. A pre-trained

CNN performs feature extraction. Linear SVMs (one

per class) are used to score the extracted features and

a threshold is applied to ﬁlter the large number of

proposed regions. Fast R-CNN (Girshick, 2015) and

Faster R-CNN (Ren et al., 2015) offer further impro-

vements in speed and accuracy. Later on, R-CNN

is combined with feature pyramids to enable efﬁcient

Brust, C., Käding, C. and Denzler, J.

Active Learning for Deep Object Detection.

DOI: 10.5220/0007248601810190

In Proceedings of the 14th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2019), pages 181-190

ISBN: 978-989-758-354-4

181

dog

horse

cat

car

bicycle

Predict

unlabeled example

Calculate scores

for each detection

Aggregate individual

scores

Whole


score

Score from

margin sampling

(1-vs-2)

Figure 1: Our proposed system for continuous exploration scenarios. Unlabeled images are evaluated by an deep object de-

tection method. The margins of predictions (i.e., absolute difference of highest and second-highest class score) are aggregated

to identify valuable instances by combining scores of individual detections.

multi-scale detections (Lin et al., 2017). YOLO (Red-

mon et al., 2016) is a more recent deep learning-based

object detector. Instead of using a CNN as a black box

feature extractor, it is trained in an end-to-end fashion.

All detections are inferred in a single pass (hence the

name “You Only Look Once”) while detection and

classiﬁcation are capable of independent operation.

YOLOv2 (Redmon and Farhadi, 2017) and YOLOv3

(Redmon and Farhadi, 2018) improve upon the ori-

ginal YOLO in several aspects. These include among

others different network architectures, different priors

for bounding boxes and considering multiple scales

during training and detection. SSD (Liu et al., 2016)

is a single-pass approach comparable to YOLO intro-

ducing improvements like assumptions about the as-

pect ratio distribution of bounding boxes as well as

predictions on different scales. As a result of a series

of improvements, it is both faster and more accurate

than the original YOLO. DSSD (Fu et al., 2017) furt-

her improves upon SSD in focusing more on context

with the help of deconvolutional layers.

Active Learning for Object Detection. The aut-

hors of (Abramson and Freund, 2006) propose an

active learning system for pedestrian detection in vi-

deos taken by a camera mounted on the front of

a moving car. Their detection method is based on

AdaBoost while sampling of unlabeled instances is

realized by hand-tuned thresholding of detections.

Object detection using generalized Hough transform

in combination with randomized decision trees, cal-

led Hough forests, is presented in (Yao et al., 2012).

Here, costs are estimated for annotations, and instan-

ces with highest costs are selected for labeling. This

follows the intuition that those examples are most li-

kely to be difﬁcult and therefore considered most va-

luable. Another active learning approach for satellite

images using sliding windows in combination with

an SVM classiﬁer and margin sampling is proposed

in (Bietti, 2012). The combination of active learning

for object detection with crowd sourcing is presen-

ted in (Vijayanarasimhan and Grauman, 2014). A

part-based detector for SVM classiﬁers in combina-

tion with hashing is proposed for use in large-scale

settings. Active learning is realized by selecting the

most uncertain instances for labeling. In (Roy et al.,

2016), object detection is interpreted as a structured

prediction problem using a version space approach in

the so called “difference of features” space. The aut-

hors propose different margin sampling approaches

estimating the future margin of an SVM classiﬁer.

Like our proposed approach, most related met-

hods presented above rely on uncertainty indicators

like least conﬁdence or 1-vs-2. However, they are

designed for a speciﬁc type of object detection and

therefore can not be applied to deep object detection

methods in general whereas our method can. Addi-

tionally, our method does not propose single objects

to the human annotator. It presents whole images at

once and requests labels for every object.

Active Learning for Deep Architectures. In

(Wang and Shang, 2014) and (Wang et al., 2016),

uncertainty-based active learning criteria for deep

models are proposed. The authors offer several me-

trics to estimate model uncertainty, including least

conﬁdence, margin or entropy sampling. Wang et al.

additionally describe a self-taught learning scheme,

where the model’s prediction is used as a label for

further training if uncertainty is below a threshold.

Another type of margin sampling is presented in

(Stark et al., 2015). The authors propose querying

samples according to the quotient of the highest and

second-highest class probability. The visual detection

of defects using a ResNet is presented in (Feng et al.,

2017). The authors propose two methods: uncertainty

sampling (i.e., defect probability of 0.5) and positive

sampling (i.e., selecting every positive sample since

they are very rare) for querying unlabeled instances

as model update after labeling. Another work which

presents uncertainty sampling is (Liu et al., 2017). In

addition, a query by committee strategy as well as

active learning involving weighted incremental dicti-

onary learning for active learning are proposed. In the

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

182

work of (Gal et al., 2017), several uncertainty-related

measures for active learning are presented. Since they

use Bayesian CNNs, they can make use of the proba-

bilistic output and employ methods like variance sam-

pling, entropy sampling or maximizing mutual infor-

mation. Finally, the authors of (Beluch et al., 2018)

show that ensamble-based uncertainty measures are

able to perform best in their evaluation. All of the

works introduced above are tailored to active learning

in classiﬁcation scenarios. Most of them rely on mo-

del uncertainty, similar to our applied selection crite-

ria.

Besides estimating the uncertainty of the model,

further retraining-based approaches are maximizing

the expected model change (Huang et al., 2016) or the

expected model output change (K

ading et al., 2016a)

that unlabeled samples would cause after labeling.

Since each bounding box inside an image has to be

evaluated according its active learning score, both me-

asures would be impractical in terms of runtime wit-

hout further modiﬁcations. A more complete over-

view of general active learning strategies can be found

in (Kovashka et al., 2016; Settles, 2009).

2 PREREQUISITE: ACTIVE

LEARNING

In active learning, a value or metric v(x) is assigned

to any unlabeled example x to determine its possible

contribution to model improvement. The current mo-

del’s output can be used to estimate a value, as can

statistical properties of the example itself. A high v(x)

means that the example should be preferred during se-

lection because of its estimated value for the current

model.

In the following section, we propose a method to

adapt an active learning metric for classiﬁcation to ob-

ject detection using an aggregation process. This met-

hod is applicable to any object detector whose output

contains class scores for each detected object.

Classiﬁcation. For classiﬁcation, the model output

for a given example x is an estimated distribution of

class scores ˆp(c|x) over classes K. This distribution

can be analyzed to determine whether the model made

an uncertain prediction, a good indicator of a valua-

ble example. Different measures of uncertainty are

a common choice for selection, e.g., (Ertekin et al.,

2007; Fu and Yang, 2015; Hoi et al., 2006; Jain and

Kapoor, 2009; Kapoor et al., 2010; K

ading et al.,

2016c; Tong and Koller, 2001; Beluch et al., 2018).

For example, if the difference between the two

highest class scores is very low, the example may be

located close to a decision boundary. In this case, it

can be used to reﬁne the decision boundary and is the-

refore valuable. The metric is deﬁned using the hig-

hest scoring classes c

and c

1vs2

(x) =



1− (max

∈K

ˆp(c

|x) − max

∈K\c

ˆp(c

|x))



(1)

This procedure is known as 1-vs-2 or margin sam-

pling (Settles, 2009). We use 1-vs-2 as part of our

methods since its operation is intuitive and it can pro-

duce better estimates than e.g., least conﬁdence ap-

proaches (K

ading et al., 2016a). However, our propo-

sed aggregation method could be applied to any other

active learning measure.

3 ACTIVE LEARNING FOR DEEP

OBJECT DETECTION

Using a classiﬁcation metric on a single detection is

straightforward, if class scores are available. Though,

aggregating metrics of individual detections for a

complete image can be done in many different ways.

In the section below, we propose simple and efﬁcient

aggregation strategies. Afterwards, we discuss the

problem of class imbalance in datasets.

3.1 Aggregation of Detection Metrics

Possible aggregations include calculating the sum, the

average or the maximum over all detections. Ho-

wever, for some aggregations, it is not clear how an

image without any detections should be handled.

Sum. A straightforward method of aggregation is

the sum. Intuitively, this method prefers images with

lots of uncertain detections in them. When aggrega-

ting detections using a sum, empty examples should

be valued zero. It is the neutral element of addition,

making it a reasonable value for an empty sum. A low

valuation effectively delays the selection of empty ex-

amples until there are either no better examples left or

the model has improved enough to actually produce

detections on them. The value of a single example x

can be calculated from the detections D in the follo-

wing way:

Sum

(x) =

∑

i∈D

1vs2

) . (2)

Average. Another possibility is averaging each de-

tection’s scores. The average is not sensitive to the

number of detections, which may make scores more

comparable between images. If a sample does not

Active Learning for Deep Object Detection

183

contain any detections, it will be assigned a zero

score. This is an arbitrary rule because there is no true

neutral element w.r.t. averages. However, we choose

zero to keep the behavior in line with the other me-

trics:

Avg

(x) =

|D|

∑

i∈D

1vs2

) . (3)

Maximum. Finally, individual detection scores can

be aggregated by calculating the maximum. This can

result in a substantial information loss. However, it

may also prove beneﬁcial because of increased robus-

tness to noise from many detections. For the maxi-

mum aggregation, a zero score for empty examples is

valid. The maximum is not affected by zero valued

detections, because no single detection’s score can be

lower than zero:

Max

(x) = max

i∈D

1vs2

) . (4)

3.2 Handling Selection Imbalances

Class imbalances can lead to worse results for clas-

ses underrepresented in the training set. In a continu-

ous learning scenario, this imbalance can be counte-

red during selection by preferring instances where the

predicted class is underrepresented in the training set.

An instance is weighted by the following rule:

#instances+ #classes

#instances

+ 1

, (5)

where c denotes the predicted class. We assume a

symmetric Dirichlet prior with α = 1, meaning that

we have no prior knowledge of the class distribution,

and estimate the posterior after observing the total

number of training instances as well as the number

of instances of class c in the training set. The weight

is then deﬁned as the inverse of the posterior to

prefer underrepresented classes. It is multiplied with

1vs2

(x) before aggregation to obtain a ﬁnal score.

4 EXPERIMENTS

In the following, we present our evaluation. First we

show how the proposed aggregation metrics are able

to enhance recognition performance while selecting

new data for annotation. After this, we will analyze

the gained improvements when our proposed weig-

hting scheme is applied.

The code for our experiments is available

https://github.com/cvjena/cn24-active

Data. We use the PASCAL VOC 2012 dataset (Eve-

ringham et al., 2010) to assess the effects of our met-

hods on learning. To speciﬁcally measure incremen-

tal and active learning performance, both training and

validation set are split into parts A and B in two diffe-

rent random ways to obtain more general experimen-

tal results. Part B is considered “new” and is compri-

sed of images with the object classes bird, cow and

sheep (ﬁrst way) or tvmonitor, cat and boat (se-

cond way). Part A contains all other 17 classes and

is used for initial training. The training set for part B

contains 605 and 638 images for the ﬁrst and second

way, respectively. The decision towards VOC in favor

of recently published datasets was motivated by the

conditions of the dataset itself. Since it mainly con-

tains images showing fewer objects, it is possible to

split the data into a known and unknown part without

having images containing classes from both parts of

the splits.

Active Exploration Protocol. Before an experi-

mental run, the part B datasets are divided randomly

into unlabeled batches of ten samples each. This ﬁxed

assignment decreases the probability of very similar

images being selected for the same batch compared

to always selecting the highest valued samples, which

would lead to less diverse batches. This is valuable

while dealing with data streams, e.g., from camera

traps, or data with low intra-class variance. The con-

struction of diverse unlabeled data batches is a well

known topic in batch-mode active learning (Settles,

2009). However, the construction of diverse batches

could lead to unintended side-effects and an evalua-

tion of those is beyond the scope of the current study.

The unlabeled batch size is a trade-off between a tight

feedback loop (smaller batches) and computational

efﬁciency (larger batches). As side-effect of the ﬁxed

batch assignment, there are some samples left over

during selection (i.e., ﬁve for ﬁrst way and eight for

second way of splitting).

The unlabeled batches are assigned a value using

the sum of the active learning metric over all images

in the corresponding batch as a meta-aggregation. Ot-

her functions such as average or maximum could be

considered too, but are also beyond the scope of this

paper.

The highest valued batch is selected for an incre-

mental training step (K

ading et al., 2016b). The net-

work is updated using the annotations from the dataset

in lieu of a human annotator. Please note, annotations

are not needed for update batch selection but for the

update itself. This process is repeated from the point

of batch valuation until there are no unlabeled batches

left. The assignment of samples to unlabeled batches

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

184

Algorithm 1: Detailed description of the experimental protocol. Please note that in an actual continuous learning scenario,

new examples are always added to U. The loop is never left because U is never exhausted. The described splitting process

would have to be applied regularly.

Require: Known labeled samples L, unknown samples U, initial model f

, active learning metric v

U = U

, U

, . . . ← split of U into random batches

f ← f

while U is not empty do

calculate scores for all batches in U using f

best

← highest scoring batch in U according to v

best

← annotations for U

best

human-machine interaction

f ← incrementally train f using L and (U

best

, Y

best

)

U ← U\U

best

L ← L ∪ (U

best

, Y

best

)

end while

is not changed during an experimental run.

Evaluation. We report mean average precision

(mAP) as described in (Everingham et al., 2010) and

validate each ﬁve new batches (i.e., 50 new samples).

The result is averaged over ﬁve runs for each active

learning metric and way of splitting for a total of ten

runs. As a baseline for comparison, we evaluate the

performance of random selection, since there is no ot-

her work suitable for direct comparison without any

adjustments as of yet.

Setup – Object Detector. We use YOLO as deep

object detection framework (Redmon et al., 2016).

More precisely, we use the YOLO-Small architecture

as an alternative to larger object detection networks,

because it allows for much faster training. Our ini-

tial model is obtained by ﬁne-tuning the Extraction

model

on part A of the VOC dataset for 24,000 ite-

rations using the Adam optimizer (Kingma and Ba,

2014), for each way of splitting the dataset into parts

A and B, resulting in two initial models. The ﬁrst half

of initial training is completed with a learning rate of

0.0001. The second half and all incremental experi-

ments use a lower learning rate of 0.00001 to prevent

divergence. Other hyperparameters match (Redmon

et al., 2016), including the augmentation of training

data using random crops, exposure or saturation ad-

justments.

Setup – Incremental Learning. Extending an exis-

ting CNN without sacriﬁcing performance on known

data is not a trivial task. Fine-tuning exclusively on

new data leads to a severe degradation of performance

on previously learned examples (Kirkpatrick et al.,

http://pjreddie.com/media/ﬁles/extraction.weights

2016; Shmelkov et al., 2017). We use a straightfor-

ward, but effective ﬁne-tuning method (K

ading et al.,

2016b) to implement incremental learning. With each

gradient step, the mini-batch is constructed by rand-

omly selecting from old and new examples with a

certain probability of λ or 1 − λ, respectively. After

completing the learning step, the new data is simply

considered old data for the next step. This method

can balance known and unknown data performance

successfully. We use a value of 0.5 for λ to make as

few assumptions as possible and perform 100 iterati-

ons per update. Algorithm 1 describes the protocol

in more detail. The method can be applied to YOLO

object detection with some adjustments. Mainly, the

architecture needs to be changed when new classes

are added. Because of the design of YOLO’s output

layer, we rearrange the weights to ﬁt new classes, ad-

ding 49 zero-initialized weights per class.

4.1 Results

We focus our analysis on the new, unknown data. Ho-

wever, not losing performance on known data is also

important. We analyze the performance on the known

part of the data (i.e., part A of the VOC dataset) to va-

lidate our method. In worst case, the mAP decreases

from 36.7% initially to 32.1% averaged across all ex-

perimental runs and methods although three new clas-

ses were introduced. We can see that the incremental

learning method from (K

ading et al., 2016b) causes

only minimal losses on known data. These losses in

performance are also referred to as “catastrophic for-

getting” in literature (Kirkpatrick et al., 2016). The

method from (K

ading et al., 2016b) does not require

additional model parameters or adjusted loss terms

for added samples like comparable approaches such

as (Shmelkov et al., 2017) do, which is important for

learning indeﬁnitely.

Active Learning for Deep Object Detection

185

Table 1: Validation results on part B of the VOC data (i.e., new classes only). Bold face indicates block-wise best results, i.e.,

best results with and without additional weighting (· + w). Underlined face highlights overall best results.

50 samples 100 samples 150 samples 200 samples 250 samples All samples

mAP/AULC mAP/AULC mAP/AULC mAP/AULC mAP/AULC mAP/AULC

Baseline

Random 8.7 / 4.3 12.4 / 14.9 15.5 / 28.8 18.7 / 45.9 21.9 / 66.2 32.4 / 264.0

Our Methods

Max 9.2 / 4.6 12.9 / 15.7 15.7 / 30.0 19.8 / 47.8 22.6 / 69.0 32.0 / 269.3

Avg 9.0 / 4.5 12.4 / 15.2 15.8 / 29.2 19.3 / 46.8 22.7 / 67.8 33.3 / 266.4

Sum 8.5 / 4.2 14.3 / 15.6 17.3 / 31.4 19.8 / 49.9 22.7 / 71.2 32.4 / 268.2

Max + w 9.2 / 4.6 13.0 / 15.7 17.0 / 30.7 20.6 / 49.5 23.2 / 71.4 33.0 / 271.0

Avg + w 8.7 / 4.3 12.5 / 14.9 16.6 / 29.4 19.9 / 47.7 22.4 / 68.8 32.7 / 267.1

Sum + w 8.7 / 4.4 13.7 / 15.6 17.5 / 31.2 20.9 / 50.4 24.3 / 72.9 32.7 / 273.6

Most valuable examples (highest score)

Sum(+ w)

Avg(+ w)

Max(+ w)

Least valuable examples (zero score)

All

Figure 2: Value of examples of cow, sheep and bird as determined by the Sum, Avg and Max metrics using the initial model.

The top seven selection is not affected by using our weighting method to counter training set class imbalaces.

Performance of active learning methods is usu-

ally evaluated by observing points on a learning curve

(i.e., performance over number of added samples). In

Table 1, we show the mAP for the new classes from

part B of VOC at several intermediate learning steps

as well as exhausting the unlabeled pool. In addition

we show the area under learning curve (AULC) to

further improve comparability among the methods. In

our experiments, the number of samples added equals

the number of images.

Quantitative Results – Fast Exploration. Gaining

accuracy as fast as possible while minimizing the hu-

man supervision is one of the main goals of active

learning. Moreover, in continuous exploration scena-

rios, like live camera feeds or other continuous auto-

matic measurements, it is assumed that new data is

always available. Hence, the pool of valuable exam-

ples will rarely be exhausted. To assess the perfor-

mance of our methods in this fast exploration context,

we evaluate the models after learning small amounts

of samples. At this point there is still a large number

of diverse samples for the methods to choose from,

which makes the following results much more rele-

vant for practical applications than results on the full

dataset.

In general, we can see that incremental learning

works in the context of the new classes in part B of

the data, meaning that we observe an improving per-

formance for all methods. After adding only 50 sam-

ples, Max and Avg are performing better than pas-

sive selection while the Sum metric is outperformed

marginally. When more and more samples are added

(i.e., 100 to 250 samples), we observe a superior per-

formance of the Sum aggregation. But also the two

other aggregation techniques are able to reach better

rates than mere random selection. We attribute the

fast increase of performance for the Sum metric to its

tendency to select samples with many object inside

which leads to more annotated bounding boxes. Ho-

wever, the target application is a scenario where the

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

186

New classes (part B) Known classes (part A)

bird cow sheep aeroplane car

Initial prediction

After 50 samples

After 150 samples

Figure 3: Evolution of detections on examples from validation set.

amount of unlabeled data is huge or new data is ap-

proaching continuously and hence a complete evalu-

ation by humans is infeasible. Here, we consider the

amount of images to be evaluated more critical as the

time needed to draw single bounding boxes. Anot-

her interesting fact is the almost equal performance

of Max and Avg which can be explained as follows:

the VOC dataset consists mostly of images with only

one object in them. Therefore, both metrics lead to a

similar score if objects are identiﬁed correctly.

We can also see that the proposed balance hand-

ling (i.e., ·+ w) causes slight losses in performance at

very early stages up to 100 samples. At subsequent

stages, it helps to gain noticeable improvements. Es-

pecially for the Sum method beneﬁts from the sam-

ple weighting scheme. A possible explanation for this

behavior would be the following: At early stages, the

classiﬁer has not seen many samples of each class and

therefore suffers more from miss-classiﬁcation errors.

Hence, the weighting scheme is not able to encourage

the selection of rare class samples since the classi-

ﬁer decisions are still too unstable. At later stages,

this problem becomes less severe and the weighting

scheme is much more helpful than in the beginning.

This could also explain the performance of Sum in

general. Further details on learning pace are given

later in a qualitative study on model evolution. Addi-

tionally, the Sum aggregation tends to select batches

with many detections in it. Hence, it is natural that

the improvement is noticeable the most with this ag-

gregation technique since it helps to ﬁnd batches with

many rare objects in it.

Quantitative Results – All Available Samples. In

our case, active learning only affects the sequence of

unlabeled batches if we train until there is no new data

available. Therefore, there are only very small diffe-

rences between each method’s results for mAP after

training has completed. The small differences indi-

cate that the chosen incremental learning technique

ading et al., 2016b) is suitable for the faced scena-

rio. In continuous exploration, it is usually assumed

that there will be more new unlabeled data available

than can be processed. Nevertheless, evaluating the

long term performance of our metrics is important to

detect possible deterioration over time compared to

random selection. In contrast to this, the differences

in AULC arise from the improvements of the different

methods during the experimental run and therefore

should be considered as distinctive feature implying

the performance over the whole experiment. Having

this in mind, we can still see that Sum performs best

while the weighting generally leads to improvements.

Quantitative Results — Class-wise Analysis To

validate the efﬁcacy of our sample weighting strategy

as discussed in Section 3.2, it is important to mea-

sure not only overall performance, but to look at me-

trics for individual classes. Fig. 4 shows the perfor-

mance over time on the validation set for each indi-

vidual class. For reference, we also provide the class

distribution over the relevant part of the VOC data-

set, indicated by number of object instances in total as

well as number of images with at least one instance in

it.

In the ﬁrst row, we observe an advantage for the

weighted method when looking at the performance of

cow. Out of the three classes in this way of splitting

cow has the fewest instances in the dataset. The per-

formance of tvmonitor in the second row shows a si-

milar pattern, where it is also the class with the lowest

number of object instances in the dataset. Analyzing

bird and cat, the top classes by number of instan-

ces in each way of splitting, we observe only small

differences in performance. Thus, we can show evi-

dence that our balancing scheme is able to improve

performance on rare classes while it does not effect

performance on frequent classes.

Active Learning for Deep Object Detection

187

0 250 500

# samples

AP (%)

bird

Sum

Sum + w

0 250 500

# samples

AP (%)

cow

Sum

Sum + w

0 250 500

# samples

AP (%)

sheep

Sum

Sum + w

0 250 500

# samples

AP (%)

boat

Sum

Sum + w

0 250 500

# samples

AP (%)

cat

Sum

Sum + w

0 250 500

# samples

AP (%)

tvmonitor

Sum

Sum + w

bird cow sheep boat cat tvmonitor

500

1000

# samples

Number of samples in VOC dataset by class

Objects

Images

Figure 4: Class-wise validation results on part B of the VOC

dataset (i.e.,, unknown classes). The ﬁrst row details the

ﬁrst way of splitting (bird,cow,sheep) while the second

row shows the second way (boat,cat,tvmonitor). For re-

ference, the distribution of samples (object instances as well

as images with at least one instance) over the VOC dataset

is provided in the third row.

Intuitively, these observations are in line with our

expectations regarding our handling of class imbalan-

ces, where examples of rare classes should be prefer-

red during selection. We start to observe the advanta-

ges after around 100 training examples, because, for

the selection to happen correctly, the prediction of the

rare class needs to be correct in the ﬁrst place.

Qualitative Results – Sample Valuation We cal-

culate whole image scores over bird, cow and sheep

samples using our corresponding initial model trained

on the remaining classes for the ﬁrst way of splitting.

Figure 2 shows those images that the three aggrega-

tion metrics consider the most valuable. Additionally,

common zero scoring images are shown. The least

valuable images shown here are representative of all

proposed metrics because they do not lead to any de-

tections using the initial model. Note that there are

more than seven images with zero score in the trai-

ning dataset. The images shown in the ﬁgure have

been selected randomly.

Intuitively, the Sum metric should prefer images

with many objects in them over single objects, even if

individual detection values are low. Although VOC

contains mostly of images with a single object, all

seven of the highest scoring images contain at le-

ast three objects. The Average and Maximum metric

prefer almost identical images since the average and

maximum are used to be nearly equal for few detecti-

ons. With few exceptions, the most valuable images

contain pristine examples of each object. They are

well lit and isolated. The objects in the zero scoring

images are more noisy and hard to identify even for

the human viewer, resulting in fewer reliable detecti-

ons.

Qualitative Results – Model Evolution. Obser-

ving the change in model output as new data is lear-

ned can help estimate the number of samples needed

to learn new classes and identify possible confusions.

Fig. 3 shows the evolution from initial guesses to cor-

rect detections after learning 150 samples, correspon-

ding to an fast exploration scenario. For selection, the

Sum metric is used.

The class confusions shown in the ﬁgure are typi-

cal for this scenario. cow and sheep are recognized

as visually similar dog, horse and cat. bird is often

classiﬁed as aeroplane. After selecting and learning

150 samples, the objects are detected and classiﬁed

correctly and reliably.

During the learning process, there are also

unknown objects. Please note, being able to mark

objects as unknown is a direct consequence of using

YOLO. Those objects have a detection conﬁdence

above the required threshold, but no classiﬁcation is

certain enough. This property of YOLO is important

for the discovery of objects of new classes. Nevert-

heless, if similar information is available from other

detection methods, our techniques could easily be ap-

plied.

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

188

5 CONCLUSIONS

In this paper, we propose several uncertainty-based

active learning metrics for object detection. They

only require a distribution of classiﬁcation scores per

detection. Depending on the speciﬁc task, an object

detector that will report objects of unknown classes

is also important. Additionally, we propose a sample

weighting scheme to balance selections among clas-

ses.

We evaluate the proposed metrics on the PASCAL

VOC 2012 dataset (Everingham et al., 2010) and offer

quantitative and qualitative results and analysis. We

show that the proposed metrics are able to guide the

annotation process efﬁciently which leads to superior

performance in comparison to a random selection ba-

seline. In our experimental evaluation, the Sum me-

tric is able to achieve best results overall which can

be attributed to the fact that it tends to select batches

with many single objects in it. However, the targe-

ted scenario is an application with huge amounts of

unlabeled data where we consider the amount of ima-

ges to be evaluated as more critical than the time nee-

ded to draw single bounding boxes. Examples would

be camera streams or camera trap data. To expedite

annotation, our approach could be combined with a

weakly supervised learning approach as presented in

(Papadopoulos et al., 2016). We also showed that our

weighting scheme leads to even increased accuracies.

All presented metrics could be applied to other

deep object detectors, such as the variants of SSD

(Liu et al., 2016), the improved R-CNNs e.g., (Ren

et al., 2015) or the newer versions of YOLO (Red-

mon and Farhadi, 2017). Moreover, our proposed me-

trics are not restricted to deep object detection and

could be applied to arbitrary object detection met-

hods if they fulﬁll the requirements. It only requires

a complete distribution of classiﬁcations scores per

detection. Also the underlying uncertainty measure

could be replaced with arbitrary active learning me-

trics to be aggregated afterwards. Depending on the

speciﬁc task, an object detector that will report objects

of unknown classes is also important.

The proposed aggregation strategies also genera-

lize to selection of images based on segmentation re-

sults or any other type of image partition. The re-

sulting scores could also be applied in a novelty de-

tection scenario.

REFERENCES

Abramson, Y. and Freund, Y. (2006). Active learning for

visual object detection. Technical report, University

of California, San Diego.

Beluch, W. H., Genewein, T., N

urnberger, A., and K

ohler,

J. M. (2018). The power of ensembles for active lear-

ning in image classiﬁcation. In Computer Vision and

Pattern Recognition (CVPR).

Bietti, A. (2012). Active learning for object detection on

satellite images. Technical report, California Institute

of Technology, Pasadena.

Ertekin, S., Huang, J., Bottou, L., and Giles, L. (2007). Le-

arning on the border: active learning in imbalanced

data classiﬁcation. In Conference on Information and

Knowledge Management.

Everingham, M., Van Gool, L., Williams, C. K. I., Winn,

J., and Zisserman, A. (2010). The pascal visual ob-

ject classes (voc) challenge. International Journal of

Computer Vision (IJCV).

Feng, C., Liu, M.-Y., Kao, C.-C., and Lee, T.-Y. (2017).

Deep active learning for civil infrastructure defect de-

tection and classiﬁcation. In International Workshop

on Computing in Civil Engineering (IWCCE).

Fu, C.-J. and Yang, Y.-P. (2015). A batch-mode active le-

arning svm method based on semi-supervised cluste-

ring. Intelligent Data Analysis.

Fu, C.-Y., Liu, W., Ranga, A., Tyagi, A., and Berg, A. C.

(2017). Dssd: Deconvolutional single shot detector.

arXiv preprint arXiv:1701.06659.

Gal, Y., Islam, R., and Ghahramani, Z. (2017). Deep bay-

esian active learning with image data. arXiv preprint

arXiv:1703.02910.

Girshick, R. (2015). Fast R-CNN. In International Confe-

rence on Computer Vision (ICCV).

Girshick, R., Donahue, J., Darrell, T., and Malik, J. (2014).

Rich feature hierarchies for accurate object detection

and semantic segmentation. In Computer Vision and

Pattern Recognition (CVPR).

Hoi, S. C., Jin, R., and Lyu, M. R. (2006). Large-scale text

categorization by batch mode active learning. In In-

ternational Conference on World Wide Web (WWW).

Huang, J., Child, R., Rao, V., Liu, H., Satheesh, S., and

Coates, A. (2016). Active learning for speech re-

cognition: the power of gradients. arXiv preprint

arXiv:1612.03226.

Jain, P. and Kapoor, A. (2009). Active learning for large

multi-class problems. In Computer Vision and Pattern

Recognition (CVPR).

ading, C., Freytag, A., Rodner, E., Perino, A., and Den-

zler, J. (2016a). Large-scale active learning with ap-

proximated expected model output changes. In Ger-

man Conference on Pattern Recognition (GCPR).

ading, C., Rodner, E., Freytag, A., and Denzler, J.

(2016b). Fine-tuning deep neural networks in con-

tinuous learning scenarios. In ACCV Workshop on

Interpretation and Visualization of Deep Neural Nets

(ACCV-WS).

ading, C., Rodner, E., Freytag, A., and Denzler, J.

(2016c). Watch, ask, learn, and improve: A lifelong

learning cycle for visual recognition. In European

Symposium on Artiﬁcial Neural Networks (ESANN).

Active Learning for Deep Object Detection

189

Kapoor, A., Grauman, K., Urtasun, R., and Darrell, T.

(2010). Gaussian processes for object categorization.

International Journal of Computer Vision (IJCV).

Kingma, D. P. and Ba, J. (2014). Adam: A method

for stochastic optimization. arXiv preprint arXiv:

1412.6980.

Kirkpatrick, J., Pascanu, R., Rabinowitz, N. C., Veness, J.,

Desjardins, G., Rusu, A. A., Milan, K., Quan, J., Ra-

malho, T., Grabska-Barwinska, A., Hassabis, D., Clo-

path, C., Kumaran, D., and Hadsell, R. (2016). Over-

coming catastrophic forgetting in neural networks.

arXiv preprint arXiv:1612.00796.

Kovashka, A., Russakovsky, O., Fei-Fei, L., and Grauman,

K. (2016). Crowdsourcing in computer vision. Foun-

dations and Trends in Computer Graphics and Vision.

Lin, T.-Y., Doll

ar, P., Girshick, R., He, K., Hariharan, B.,

and Belongie, S. (2017). Feature pyramid networks

for object detection. In CVPR.

Liu, P., Zhang, H., and Eom, K. B. (2017). Active deep le-

arning for classiﬁcation of hyperspectral images. Se-

lected Topics in Applied Earth Observations and Re-

mote Sensing.

Liu, W., Anguelov, D., Erhan, D., Szegedy, C., Reed, S., Fu,

C.-Y., and Berg, A. C. (2016). SSD: Single shot mul-

tibox detector. In European Conference on Computer

Vision (ECCV).

Papadopoulos, D. P., Uijlings, J. R. R., Keller, F., and Fer-

rari, V. (2016). We dont need no bounding-boxes:

Training object class detectors using only human veri-

ﬁcation. In Computer Vision and Pattern Recognition

(CVPR).

Redmon, J., Divvala, S., Girshick, R., and Farhadi, A.

(2016). You only look once: Uniﬁed, real-time object

detection. In Computer Vision and Pattern Recogni-

tion (CVPR).

Redmon, J. and Farhadi, A. (2017). Yolo9000: Better, fas-

ter, stronger. In Computer Vision and Pattern Recog-

nition (CVPR).

Redmon, J. and Farhadi, A. (2018). Yolov3: An incremental

improvement. arXiv preprint arXiv:1804.02767.

Ren, S., He, K., Girshick, R., and Sun, J. (2015). Faster R-

CNN: Towards real-time object detection with region

proposal networks. In Neural Information Processing

Systems (NIPS).

Roy, S., Namboodiri, V. P., and Biswas, A. (2016). Active

learning with version spaces for object detection.

arXiv preprint arXiv:1611.07285.

Settles, B. (2009). Active learning literature survey. Techni-

cal report, University of Wisconsin–Madison.

Shmelkov, K., Schmid, C., and Alahari, K. (2017). In-

cremental learning of object detectors without cata-

strophic forgetting. In International Conference on

Computer Vision (ICCV).

Stark, F., Hazırbas, C., Triebel, R., and Cremers, D. (2015).

Captcha recognition with active deep learning. In

Workshop New Challenges in Neural Computation.

Tong, S. and Koller, D. (2001). Support vector machine

active learning with applications to text classiﬁcation.

Journal of Machine Learning Research (JMLR).

Uijlings, J. R., Van De Sande, K. E., Gevers, T., and Smeul-

ders, A. W. (2013). Selective search for object re-

cognition. International Journal of Computer Vision

(IJCV), 104(2):154–171.

Vijayanarasimhan, S. and Grauman, K. (2014). Large-scale

live active learning: Training object detectors with

crawled data and crowds. International Journal of

Computer Vision (IJCV).

Wang, D. and Shang, Y. (2014). A new active labeling met-

hod for deep learning. In International Joint Confe-

rence on Neural Networks (IJCNN).

Wang, K., Zhang, D., Li, Y., Zhang, R., and Lin, L. (2016).

Cost-effective active learning for deep image classiﬁ-

cation. Circuits and Systems for Video Technology.

Yao, A., Gall, J., Leistner, C., and Van Gool, L. (2012).

Interactive object detection. In Computer Vision and

Pattern Recognition (CVPR).

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

190
