TED: A Container based Tool to Perform Security Risk Assessment for

ELF Binaries

Daniele Mucci

and Bernhards Blumbergs

1,2

Centre for Digital Forensics and Cyber Security, Tallinn University of Technology, Estonia

CERT.LV, IMCS University of Latvia, Latvia

Keywords:

ELF Binary Analysis, GNU/Linux System Hardening, Vulnerability Assessment, Software Containers.

Abstract:

Attacks against binaries, including novel hardware based attacks (e.g., Meltdown), are still very common, with

hundreds of vulnerabilities discovered every year. This paper presents TED, an auditing tool which acts from

the defense perspective and veriﬁes whether proper defenses are in place for the GNU/Linux system and for

each ELF binary in it. Unlike other solutions proposed, TED aims to integrate several tools and techniques

by the use of software containers; this choice created the necessity to compare and analyze the most popular

container platforms to determine the most suitable for this use case. The containerization approach allows

to reduce complexity, gain ﬂexibility and extensibility at the cost of a negligible performance loss, while

signiﬁcantly reducing the dependencies needed. Performance and functionality tests, both in lab and real-

world environments, showed the feasibility of a container-based approach and the usefulness of TED in several

use cases.

1 MOTIVATION FOR THE

PROJECT

From the 1st of January 2017, around 150 differ-

ent vulnerabilities involving stack or heap overﬂows

and format string bugs have been reported (NIST,

2018). In addition, during this period several hard-

ware vulnerabilities which also involved binaries

have been found (e.g., Spectre/Meltdown, Throw-

/NetHammer). Also reverse engineering should al-

ways be considered as a possible option for target-

ing binaries, especially where intellectual property

is involved. Considering the enormous diffusion of

GNU/Linux based systems, it is clear that protecting

ELF binaries in such environment is of critical impor-

tance, and therefore this is the primary purpose of this

project.

2 INTRODUCTION

Many tools and techniques exist to protect systems

or binaries from a wide range of attacks, and many

more are continuously developed. However, despite

the large number of protection mechanisms designed,

a relatively small and consolidated set of features is

commonly used and deployed. This set includes de-

fenses such as Address Space Layout Randomization

(ASLR), Data Execution Prevention (DEP, NX/XD),

Stack Smashing Protector (SSP) or Stack canaries.

For the most recent Linux kernels, this set can be

extended with the microcode to protect against some

Spectre variants (e.g., Meltdown). On the other hand,

verifying whether all these measures are in place is

usually done either manually or by the aid of some

tools (e.g., Radare2, Lynis). This action has to be

performed separately for each tool used or individu-

ally for each binary, making it time consuming, error-

prone and inefﬁcient. Moreover, low-level tools of-

ten require speciﬁc dependencies for libraries or other

tools, which might not always be possible to satisfy or

whose installation might require additional time and

effort.

The solution proposed in this paper consists of

using software containers to address the issues men-

tioned, speciﬁcally to integrate and orchestrate multi-

ple tools, to collect and process the different results,

and most of all to greatly reduce the dependencies

required, allowing to individually pack the needed

tools with their dependencies, thus eliminating possi-

ble conﬂicts and the need for their installation. Given

the fact that software containers are still rarely used

outside cloud environments, a signiﬁcant amount of

Mucci, D. and Blumbergs, B.

TED: A Container based Tool to Perform Security Risk Assessment for ELF Binaries.

DOI: 10.5220/0007371603610369

In Proceedings of the 5th International Conference on Information Systems Security and Privacy (ICISSP 2019), pages 361-369

ISBN: 978-989-758-359-9

361

work consisted in analyzing and comparing the vari-

ous available container engines to select the one that

provided the needed functionalities and at the same

time did not represent a heavy dependency itself. The

tool here presented, TED, implements such solution

using Docker containers to perform all the necessary

tests aimed to verify whether a selected set of defense

measures are in place, and to consequently assess the

risk associated with each binary present in the system.

Proposed solution would be practically applicable to

the cyber security areas such as, vulnerability assess-

ment, incident response, system triaging, and security

baseline establishment.

This paper provides the following contributions:

1. discussion of software containers as execution en-

vironment and evaluation of the different con-

tainer engine platforms in the context of vulner-

ability assessment; and

2. container technology implementation for ELF bi-

nary security assessment in an open-source tool-

set TED.

This paper is organized as follows: Section 3 gives

an overview of related work; Section 4 describes the

container engine selection process, the design and the

implementation of TED; Section 5 provides the result

of the evaluation process; Section 6 concludes this pa-

per.

3 RELATED WORK

Extensive research already exists on binary security,

both from the attack and from the defense perspective.

However, very few projects, with a purpose similar to

the one presented in this paper, were found.

BitBlaze is a platform developed by Song et

al. (Song et al., 2008) which uses both static and dy-

namic analysis to extract a wide range of security in-

formation from a program, without taking into con-

sideration the defense measures applied and relying

on custom techniques. The main purpose of Bit-

Blaze is to detect possible vulnerabilities in the pro-

gram and to identify their root cause, rather than de-

termining what security measures are applied. Bit-

Blaze has several components, in particular a static

analysis tool (VINE, available and not maintained for

4 years) and a dynamic analysis component (TEMU,

available and not maintained for 3 years). Young-

Hyun et al. (Choi et al., 2015) in 2015 developed a

project called DBA (Dynamic Binary Analyzer), ca-

pable of dynamically detecting vulnerabilities in bi-

naries with taint analysis, which targets x86 (32-bit)

Windows binaries. This project focuses on ﬁnding

vulnerabilities or detecting exploitation at runtime. To

perform its analysis, DBA uses QEMU virtual ma-

chine to emulate the execution environment for a sin-

gle binary. TEASER by Ulrich (Ulrich, 2017) is a

system, which aims to assess the exploitability of bi-

naries, performing a vulnerability assessment from

the perspective of an attacker. TEASER is limited

to identifying memory corruption vulnerabilities and

is meant to ease the process of detecting bugs which

might lead to exploits. It is built on top of other

tools, such as Valgrind, PANDA, ASan and LLVM, and

uses QEMU emulation for some steps of its execu-

tion. Tang et al. (Feng-Yi et al., 2016) and Wang et

al. (Wang et al., 2017) in their projects focused on

binary security analysis in terms of performing a di-

agnosis of memory vulnerabilities. The two projects

which can be compared with TED are checksec.sh

and Lynis

. The ﬁrst is a Bash shell script, which

shows technical information, including whether some

security measures are applied, regarding a binary, a

loaded library or the kernel. The main script is not

maintained anymore, but a forked and maintained ver-

sion

exists. Lynis, on the other hand, is a software

aimed to audit, hardening and testing for compliance

Unix systems. The software runs a wide range of tests

according to what tools are available on the system,

and it is publicly available.

In addition to the presented tools, there is a con-

spicuous number of proposals to protect binaries from

a wide range of attacks, however, an evident gap be-

tween the academia and the industry emerged. This

means that virtually all the novel tools or techniques,

such as (Marco-Gisbert and Ripoll, 2013; Solanki

et al., 2014; Younan et al., 2006; Chen et al., 2017;

Novark and Berger, 2010), developed in the academic

environment, independently by their efﬁcacy and se-

curity impact, are either unused or extremely rarely

deployed in the production environments.

In the related work, multiple limitations and draw-

backs have been identiﬁed, such as, the need for spe-

ciﬁc and numerous dependencies, the use of heavy

virtualization technologies (e.g., KVM/QEMU) and

their conﬁguration, the support only for Windows bi-

naries or for 32-bit architectures, the focus on sin-

gle binaries rather than on the whole system, the

lack of automation and the need of user interaction

and ﬁnally the use of technologies that make the tool

not portable, not easily extensible or not suitable for

cloud environments. TED aims to address all the gaps

identiﬁed by bundling all the tools and dependen-

cies needed inside Docker containers, which not only

http://www.trapkit.de/tools/checksec.html

https://cisofy.com/lynis/

https://github.com/slimm609/checksec.sh

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

362

make the application extremely portable, but avoid the

overhead of an hypervisor, reducing drastically the

performance loss; given this approach, the set of de-

pendencies of TED is ﬁxed and it is limited to the

Docker platform and a small number of Python pack-

ages. Furthermore, TED focuses on 64-bit executa-

bles and aims to automate the scanning process, with-

out requiring user interaction, in order to grant scal-

ability to the project and to allow users to run TED

periodically. Finally, TED not only collects and inte-

grates information about both the system and the bi-

naries in it, but also provides an assessment based on

the information gathered, to allow for easier planning

and better focus on critical parts of the system.

4 DESIGN AND

IMPLEMENTATION

The design and implementation of the tool proposed

here, TED, necessitated of several steps. First, the

most suitable container engine for the context in

which TED operates needed to be selected, then, it

was required to individuate the defense measures and

techniques to integrate in the tool, and furthermore to

establish a corresponding scoring system to measure

the system’s ELF binary state. Finally, the tool had to

be implemented.

4.1 Container Engine Selection

The idea of software isolation was born during the

1980s, however, the ﬁrst use of containers dates back

to the early 2000s. Despite this, only from 2015

containers have become a popular and ubiquitous

technology, therefore the market is still relatively

young, leading to the ﬂourishing of many container

engines and orchestration systems. Among these, ﬁve

available platforms have been taken into considera-

tion: Docker

, Rkt

, LXC

, OpenVZ

and Garden

OpenVZ and Garden have been discarded before the

detailed evaluation for the following technical rea-

sons: OpenVZ has limited functionalities if it is not

run on a speciﬁc kernel, imposing a heavy constraint

for a tool that aims to be generic and portable; Gar-

den on the other hand is not yet a mature project and

it is virtually not used, despite it aims to represent an

alternative to Docker.

https://www.docker.com/

https://coreos.com/rkt/

https://linuxcontainers.org/

https://openvz.org/

https://github.com/cloudfoundry/garden

The remaining platforms – LXC, Docker and Rkt,

have been evaluated using three parameters:

1. Availability: what needs to be done to get and in-

stall the platform, what dependencies need to be

satisﬁed and also whether there are public repos-

itories from which container images can be ob-

tained.

2. Functionality: whether and how the container en-

gine provides capabilities such as building im-

ages, collecting logs and events and sharing por-

tion of the ﬁle system with the host.

3. Performance: the overhead caused by executing

code inside a container for each engine is mea-

sured running 1000 times a test script and compar-

ing its execution time with a baseline established

running the same script on the native machine.

The most important criterion is the functionality,

since a lack of features would impact the capabili-

ties of TED or increase its complexity. Following

the functionality, the availability is considered, as this

impacts the dependencies needed by TED, which are

meant to be as few as possible. Finally, performances

are considered of secondary importance, since the dif-

ference in performances between technologies which

are fundamentally similar is expected to be small.

Docker. Docker is the most popular container en-

gine and the current industry standard. It can be in-

stalled in most cases from the package manager and

does not need any particular Kernel feature, although

root access is necessary to run the Docker daemon.

The necessity of root access and its security implica-

tions are well documented

and require special atten-

tion. It is important to note that Docker is included

in many cloud-oriented operating systems, such as

CoreOS Container Linux

and RancherOS

. Con-

tainer images that can be run by Docker are pub-

licly available online from a public repository called

Docker Hub; the Docker Hub makes extremely easy

to ﬁnd, run and publish an extensive set of images

through HTTP. The Docker engine is focused on pro-

viding an execution environment for one process only,

meaning that in general there should be a 1:1 ratio

between Docker containers and applications running,

and also that a container terminates when the process

with PID 1 exits. Docker offers a rich set of func-

tionalities, including an API to build, run and man-

age containers; in particular, it offers a simple way to

start and stop containers, extract logs or outputs from

https://docs.docker.com/engine/security/security/

#docker-daemon-attack-surface

https://coreos.com/os/docs/latest/

https://rancher.com/rancher-os/

TED: A Container based Tool to Perform Security Risk Assessment for ELF Binaries

363

them, build new container images and share portions

of the ﬁle system with the host.

LXC. LXC is deﬁned as ”a userspace interface for

the Linux kernel containment features” (LXC-Doc,

2018). Unlike Docker, the purpose of LXC is to pro-

vide a full virtual environment without the burden of

running a separate kernel and a hypervisor. Thus, in

this case, several applications can run inside one sin-

gle container. There are few hard dependencies for

LXC which are likely to be fulﬁlled on most systems

and therefore do not impose a hard constraint. In-

stalling LXC is generally possible through the pack-

age manager, although no operating system comes

with LXC pre-installed. It is possible to import public

”templates” for different operating systems, but there

is not any public repository for already made contain-

ers, however, it is still possible to distribute images

via HTTP with a private web server. The functional-

ities offered by LXC are many and powerful, but in

general require a careful conﬁguration. The building

process for an image is very different from the one

offered by Docker: with LXC it is possible to ”ex-

port” and then ”import” an image. The export pro-

duces usually a tar.xz ﬁle or two tarballs that can be

imported, which are more similar to a snapshot of the

running container, rather than to a fresh image. Infor-

mation about container events can usually be found

in the host journal, while, unless manually speciﬁed,

container logs need to be extracted directly from in-

side the containers. It is possible to share a portion of

the ﬁle system with the host by simply mounting it in-

side the container, provided that a correct permission

conﬁguration is in place.

Rkt. Rkt (Rkt-Doc, 2018), read ”rocket”, is a con-

tainer engine developer by CoreOS Container Linux

team, and – apart from low-level details – it is very

similar to Docker. Rkt containers are meant to run

a single application on which their lifecycle depends.

Rkt is available from the package manager in most

Linux distributions, with the exception of Ubuntu and

CentOS, and it is pre-installed on CoreOS Container

Linux. The only dependency for running Rkt con-

tainers is a kernel version 3.18 or later. Rkt can run

both Application Container Images (ACI) and Docker

containers. For the ﬁrsts, the location of the container

needs to be known a priori to be downloaded, since

a public repository of images is not available, while

for the latter it is possible to use the Docker Hub.

The functionalities of Rkt, especially from the per-

spective of this project, are very similar to the ones

offered by Docker, except for building a new image.

Since Rkt can run Docker images, it is possible to use

Docker build feature, but in a more general process,

the build of a new container needs to be done through

acbuild

tool, that appears to be not maintained. The

logs of Rkt containers can generally be read through

the host journal and most of the operations necessary

to manage containers can be performed through the

Rkt Command Line Interface (CLI) while an API with

read-only capabilities is available. Events and log col-

lection is done in a similar fashion to Docker, and sim-

ilarly volumes are used to share the ﬁle system with

the host.

Performance Overview. To measure and com-

pare the performances of the different platforms, a

simple script which emulates some functionalities of

TED has been created. This script has then been ex-

ecuted 1000 times on the native machine and inside a

container run with each of the engines presented. The

average execution time on the native operating system

was 3.8s, whereas Rkt and Docker offered faster per-

formances – 3.33s (-12.4%) and 3.5s (-7.9%) respec-

tively. The slowest result was obtained by the LXC

container, which took an average of 3.9s (+2.6%) to

execute the script.

Conclusions. Taking into account both the cri-

teria to evaluate the platforms, the information gath-

ered and the results from the performance tests, it is

possible to observe that LXC – in addition to being

the slowest platform – requires a heavier conﬁgura-

tion from the host side compared to Rkt and Docker.

In particular, the work required to conﬁgure the con-

tainer network is a consistent overhead to the deploy-

ment of the application. Moreover, the way LXC tem-

plates are distributed implies that not only a public

service needs to be set in place, but also that a new

template should be downloaded every time an update

to the application is performed. Rkt and Docker, on

the other hand, offer similar functionalities and per-

formances, making the choice between them less ob-

vious. However not only the Rkt CLI offers lim-

ited capabilities compared to the Docker API, but Rkt

has also a much less capillary diffusion and user-base

than Docker, it is less tested and it is used mainly

in the context of CoreOS Container Linux, whereas

Docker is widespread and battle-tested on a vast array

of platforms. In the context of this project, Docker

does not present any of the drawbacks identiﬁed in the

other platforms, offers all the functionalities needed,

including good performances and a convenient way

to manage and distribute images. For all the reasons

above, it is clear that Docker results the most suitable

candidate to be used in TED.

https://github.com/containers/build

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

364

4.2 Defense Measures Selection and

Scoring System

The main functionality of TED is to verify whether

certain protection mechanisms for binaries are in

place, therefore selecting the appropriate measures

becomes of critical importance to ensure the qual-

ity of the results. To choose the most suitable de-

fenses, both their popularity and their efﬁcacy have

been taken into consideration, to avoid as much as

possible false positive results. It is possible to divide

the defense measures taken in consideration for being

integrated in TED in three main categories: system

defenses, ELF defenses against vulnerability exploit

and ELF defenses against reverse engineering.

System Wide Defenses. This category includes

those measures used by the kernel or applied to all

the executables running in a given machine. Their

purpose is to offer some level of protection to the

environment in which the binaries run, without con-

sidering the defenses that each speciﬁc binary might

or might not include. These include Address Space

Layout Randomization (ASLR) and its analogue for

the kernel (KASLR), hardware based memory pro-

tection (e.g., NX – No eXec, XD – Execute Dis-

able) and a novel mechanism originally designed

to increase kernel security, which later was recog-

nized also as a protection from the Meltdown attack,

KAISER/KPTI (Gruss et al., 2017). (K)ALSR and

NX/XD have been chosen because they offer a good

degree of protection from a wide range of memory

exploitation attacks, including those belonging to the

ret2* family; however, more advanced attacks ex-

ists (e.g., ROP and derivatives) but the defense mea-

sures against this kind of attacks are not commonly

found on systems and therefore have not been taken

into consideration. Finally, KAISER/KPTI at the mo-

ment is the only existing defense against Meltdown

for Linux systems, and given the critical impact of

such attack, it has been included in TED.

Executable Defenses against Vulnerability Ex-

ploits. This set includes the measures which are ap-

plied individually to each executable, for example

during or after compilation time, and that aim to pro-

tect them from exploits that target vulnerabilities in

the code. These measures offer a certain degree of

protection independently from the system in which

the binary is run. The most popular and commonly

used techniques are software canaries, in particular

the Stack Smashing Protector (SSP), the software

based Data Execution Prevention and its corollary,

the WˆX (Writable XOR eXecutable) principle. Sim-

ilarly to what it has been discussed previously, more

advanced and novel protections for binaries have been

designed, but none of this can be considered as a stan-

dard or as commonly deployed, and therefore they

have not been integrated into TED.

Executable Defenses against Reverse Engineer-

ing. The last category contains the protections aimed

to counter or make more difﬁcult the reverse engi-

neering of a binary. The only measure which TED

checks is the stripping of the binary. Stripping is an

extremely weak defense, which makes the debugging

of the program slightly more difﬁcult, but it is the

only common measure applied. The reason for which

no other techniques are considered is that no standard

binary protector for Unix systems exist, and that the

focus of the research in this ﬁeld is on software obfus-

cation. Unfortunately, TED is run on binaries whose

content is in general unknown, and therefore it is not

possible (or very complex) to verify whether the code

is obfuscated or not. This limitation effectively leave

stripping as the only measure veriﬁable by TED.

Additional Tests. In addition to verify whether

the measures mentioned are in place, TED also checks

if the kernel is vulnerable to known exploits or to

different Spectre variants. The rationale behind this

choice is that this is not only a way to verify kernel bi-

naries security, but also a decision which derives from

the observation that generic binary attacks can have

higher impact on machines where the kernel is vulner-

able to exploits, especially to Privilege Escalation ex-

ploits. Finally, Spectre attacks could be used to com-

promise the machine leveraging hardware faults that

are not mitigated by the defenses mentioned above

(except for Meltdown).

4.3 Scoring System

To convert the information that TED gathers into a

value that helps the TED user to make plans, two scor-

ing systems are deﬁned – a system score and an ELF

score. Each score is computed on a total of 100 points,

where a higher score implies a higher chance of ex-

ploitation, while 0 means that all the defenses that

TED is able to verify are in place. The assignment

of a score to each (lack of) defense is purely quali-

tative and decided after a careful consideration. The

system score is so composed:

1. Kernel exploits (40 points). For each conﬁrmed

kernel exploit found, a score of 15/2

n−1

is as-

signed, with n ∈ [1,∞], which represents the n-

th exploit found. Each potential kernel exploit

found will add 5/2

n−1

points. Kernel exploits

usually have a very big impact on the security of

the machine. However, establishing a linear de-

pendency between the number of exploits and the

score would generate misleading results. For this

TED: A Container based Tool to Perform Security Risk Assessment for ELF Binaries

365

reason, the ﬁrst exploit found will signiﬁcantly in-

crease the risk score, while each additional exploit

will contribute with a continuously lower weight.

2. Spectre (20 points). Each variant of Spectre to

which the system is vulnerable adds 3 points,

while 8 points are added if the system is vulner-

able to Meltdown. At the time of this writing, 5

variants of Spectre are known. Although Spec-

tre attacks can lead to a severe compromise of

the system, because there are not yet known ex-

ploits for them, the score assigned is relatively

low. Meltdown contributes with a higher score be-

cause it is relatively simpler to exploit.

3. ASLR (20 points).The ASLR conﬁguration can

lead to a maximum of 20 points, depending on

how the randomization is enabled. Speciﬁcally,

20 points are assigned if ASLR is disabled, 15 if it

is partially enabled (i.e., only on stack, virtual dy-

namic shared object page, and shared memory),

5 if it is enabled also for the heap and data seg-

ment and 0 points if ASLR is enabled fully and

additional patches have been applied. ASLR is

an effective measure that should be enabled on all

the systems, however, the different ASLR conﬁg-

urations restrict or enlarge the attack surface, and

therefore are taken in consideration in the assign-

ment of the risk score.

4. NX/XD (20 points). The lack of support from the

CPU for the NX/XD bit on memory pages adds 20

points, while no points are added if its support is

conﬁrmed. The capability to restrict the execution

of certain memory page is a very important mea-

sure to stop the simplest attacks and to build ad-

ditional defenses, and therefore a signiﬁcant score

is assigned in case of missing support for NX/XD.

The binary score is composed as follows:

1. DEP/WˆX (50 points). If the binary is compiled

with the stack marked as executable (violating

DEP), 30 points are added. If there is any section

both writable and executable (violating WˆX), 20

points are added. The possibility to write on the

stack contributes with a big score as it enables the

most basic attacks. The capability to write on an

executable memory section is still a severe vulner-

ability but in general it is less trivial to exploit and

therefore contributes with a lower score.

2. Canaries/SSP (40 points). If the binary is com-

piled without canaries and without using the Stack

Smashing Protector, 40 points are added. Ca-

naries are an orthogonal measure to DEP and also

represent an important measure to detect exploit

attempts. For this, the lack of canaries increases

signiﬁcantly the risk score of the binary.

3. Stripping (10 points). If the binary is not stripped,

10 points are added. The low score reﬂects the

low effectiveness of stripping a binary to counter

reverse engineering.

4.4 Implementation

The implementation of TED has been performed us-

ing mainly Python language, for which a library

which implements all the operations normally per-

formed through the Docker command or API is avail-

able. It is important to note that TED is especially

suitable for cloud environments because of several

reasons: the ﬁrst is that in such environments Docker

is commonly present, allowing TED to be deployed

in a matter of seconds; the second reason is that even

though the tools run inside containers, TED can scan

and analyze all the binaries in the system, includ-

ing those inside other containers, without the need to

modify the employed container images or their con-

ﬁguration. Moreover, the approach of TED to an-

alyze both the system and the binaries is especially

relevant in containerized environments since most of

the container-escape strategies rely on kernel/system

vulnerabilities. The program is composed by several

modules that perform specialized operations. These

operations include the acquisition of user input, the

collection of the binaries to analyze, the execution of

TED’s checks, the collection of the results and the

score computation. Each check that TED performs

aims to verify whether one or more defense measures

are in place, therefore they match the defense tech-

niques mentioned in the previous section. In total,

ﬁve different tests are implemented at the moment,

each of which is run inside its own Docker container.

Kernelpop Test. A custom version of Ker-

nelpop

is used to verify whether the kernel is vul-

nerable to known exploits. This tool has been cho-

sen because it provides fast and accurate results, it is

maintained and its code is publicly available.

Spectre Test. The bash script spectre-meltdown-

checker.sh

is used to verify whether the system is

vulnerable to 5 different Spectre variants. This script

is comprehensive and actively maintained, and pro-

vides results in json format and therefore it is very

suitable for being integrated inside TED.

NX/XD Support Test. The standard

/proc/cpuinfo is used to verify whether the CPU

supports the nx bit. Given the fact that containers

share the kernel with the host, the information

https://github.com/docker/docker-py

https://github.com/Sudneo/kernelpop

https://github.com/speed47/spectre-meltdown-checker

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

366

obtained by /proc virtual ﬁles is accurate and no

external tools are needed.

ASLR Test. In this test both the standard sysctl

tool and a custom binary are used to detect the ASLR

conﬁguration active in the system. While the sysctl

result provides the information from the kernel per-

spective, the custom binary uses a direct approach to

observe the pattern in addresses assigned to the stack,

to malloc() calls (heap) and to the environment vari-

ables. Analyzing these address and checking for rep-

etitions allows to detect if ASLR is disabled or if it is

enabled partially. The two perspectives are compared

to provide a more accurate result for one of the most

critical defenses.

ELF Test. In this test rabin2, one tool which is

part of the radare2

framework, is used to extract

some information from the binaries, together with the

standard objdump tool. The purpose of this test is

to verify whether the binary has been compiled with

DEP and WˆX, whether canaries are used (and in par-

ticular the SSP) and if the binary is stripped. The ﬁrst

test consists in inspecting the ﬂags of the binary sec-

tions/segments, the second consists in disassembling

the binary and verifying the presence of canary check

functions, while the binary is considered stripped if

no symbol sections are found. Radare2 has been cho-

sen because it is one of the most popular tools for re-

verse engineering in Unix environment and it is ac-

tively maintained.

The main accomplishment of TED is not only to

integrate and orchestrate the tools mentioned, but also

to use containers to pack the needed tools with their

dependencies in separate environments. This strat-

egy allows to run easily these tools and also to use

at the same time libraries or programs with differ-

ent versions without creating conﬂicts. To provide

such functionality, several Docker images have been

built, while in the cases where a specialized image

was not necessary the public debian:latest image has

been used. The code of TED is publicly available and

can be found on a public Github repository

and all

the Docker images are available either on the public

Docker Hub

or on the authors’ Docker Hub page

5 EVALUATION

To verify the feasibility of a container based approach

for a security tool and the usefulness of the tool pre-

https://github.com/radare/radare2

https://github.com/Sudneo/TED

https://hub.docker.com/

https://hub.docker.com/u/sudneo/

sented in this paper, several tests with different scopes

and use-cases have been performed.

5.1 Performance Benchmark

The ﬁrst test is a quantitative analysis with the aim

of computing the overhead caused by running the

needed tools inside containers. The four heaviest

checks (excluding the NX/XD support check) that

TED performs have been executed both inside a con-

tainer and on the native operating system, measuring

and comparing the respective execution times. Each

check has been executed 100 times, and the average

value has then been computed. The results are sum-

marized in Table 1, where the average value for each

different check is reported. It can be observed that

the overhead added by running inside a Docker con-

tainer is noticeable in relative terms; however, for

each of these tests, a new container has been cre-

ated and then destroyed. It was therefore possible to

suppose that the overhead was caused by the Docker

bootstrap routine. To conﬁrm this hypothesis, the two

checks with the major absolute difference between

values have been modiﬁed to be executed inside the

same container and the test has been repeated. The re-

sult obtained, also shown in Table 1, clearly conﬁrms

the hypothesis formulated. If the container bootstrap

process is not factored in the execution time, the dif-

ference between running the checks inside containers

or on the native machine becomes negligible. More-

over, the assumption of reusing a container for multi-

ple tests does not represent a constraint, in fact, TED

uses the same approach for its own execution. In con-

clusion, the performance analysis showed that execut-

ing the needed tools inside a container the way that

TED does, causes an overhead in the order of few sec-

onds per tool run, which in a non real-time processing

context and compared to a global execution time po-

tentially in the order of hours, can be considered neg-

ligible; therefore, the container based approach can

be considered feasible from the performance perspec-

tive.

5.2 Functionality Tests

The second phase of testing included a set of real-

world experiments to verify the usefulness of TED in

real environments. For this, two main scenarios have

been used: the ﬁrst consisted of using TED to assess

the security of the binaries present on a public web

server and to consequently establish an action plan

to resolve eventual issues found; in the second case,

TED has been used on a portion of the infrastructure

used for the NATO Locked Shields 2018 cyber exer-

TED: A Container based Tool to Perform Security Risk Assessment for ELF Binaries

367

Table 1: Summary result for the benchmark checks.

Check Physical Docker Relative ∆ Absolute ∆ Docker no startup Relative ∆ Absolute ∆

ASLR 0.031s 0.469s +1418% 0.438s - - -

Kernelpop 0.112s 1.559s +1284% 1.447s 0.134s +16.4% 0.022s

Spectre 4.745s 6.066s +27.8% 1.320s 4.485s -5.8% 0.260s

ELF 0.00060s 0.00055s -8.4% 0.00005s - - -

cise

to determine whether it would be a good ﬁt in

a complex environment.

Public Web Server. TED full scan on the web

server took 84m and 2s to complete and found the is-

sues summarized in Table 2, where the actions that

have been established to mitigate them are also re-

ported. In Table 2 it is possible to observe that all

the actions deﬁned involve the system and the ker-

nel, while no actions were planned for the ELFs com-

piled without defenses. The reason for this is multi-

faced; ﬁrst, most of the binaries were used for local

commands and were not facing the public. Second,

none of the binaries had the setuid bit set, and ﬁnally,

to take action and recompile the binaries, a more in

depth inspection was necessary to make sure that re-

compiling the code with DEP or SSP enabled would

not have broken any compatibility. For a matter of

simplicity, further actions like conﬁguring SELinux

proﬁles or AppArmor for speciﬁc binaries, had not

been considered. After performing the actions pre-

sented in Table 2, all the addressed issues have been

resolved, and the following TED scan, which took

152m and 52s, reported a much lower risk level. It

was therefore possible to conclude that TED allowed

to effectively detect vulnerabilities in the system and

also it facilitated the creation of an action plan com-

posed of informed choices.

Locked Shields Infrastructure. This test con-

sisted of running TED on two sets of machines used

during the cyber exercise: the ﬁrst set included un-

defended machines, whereas the other set was com-

posed by two machines which belonged to and had

been defended by the winning team. The machines

used for testing were web servers which run their ap-

plications inside Docker containers. It is worth men-

tioning that all the four servers used for this test did

not have any Internet connection (after the game ﬁn-

ished) and were accessible only through SSH once

connected to the closed virtualized environment host-

ing the game-network. This condition presented the

opportunity to successfully prove that an Internet con-

nection does not represent a hard dependency for

TED. Comparing the results of TED’s scans on the

ﬁrst server of each set it was possible to observe that

the blue team performed some updates (e.g., sshd and

https://ccdcoe.org/largest-international-live-ﬁre-cyber-

defence-exercise-world-be-launched-next-week.html

apache2 binaries had been modiﬁed) and of course

installed new software (e.g., ossec, splunk), but no

major modiﬁcations to binaries to reinforce their de-

fenses had been performed. One exception was rep-

resented by the mysql binary that scored 40 points in

the undefended machine, but only 20 in the defended

one, where canaries had been added. The most in-

teresting observation is that in both cases the system

score reported by TED was the same, in particular,

the same kernel vulnerabilities were present in all the

machines, among which the most interesting was the

dirtyCOW. This exploit grants a privilege escalation

and is especially relevant in contexts where applica-

tions run inside Docker containers, since it can allow

attackers to break out of such containers

. The same

observations could be done for the second pair of ma-

chines, where the exact same differences could be ob-

served.

Conclusions. The results of the real-world tests

showed that TED has very limited dependencies, can

run without an Internet connection, effectively detects

vulnerabilities in the system and helps creating an ac-

tion plan to resolve them. Despite this, it might be

needed to integrate more tools into TED to provide

more detailed information, for example about what

changed in each binary or whether each executable

is malicious or not. It is reasonable to conclude that

TED could ﬁt in contexts such as The Locked Shields

especially if the defending team knows on which bi-

naries to focus (e.g., web server binaries), reducing

the scope of the report and improving the capability

to quickly assess the risk on meaningful binaries, to

individuate possible system vulnerabilities and to cor-

relate the ﬁndings.

6 CONCLUSIONS AND FUTURE

WORK

In this paper a novel approach to vulnerability assess-

ment – using software containers, is discussed, to-

gether with the selection process for the most suitable

containers platform, and the design, implementation

and veriﬁcation in multiple use cases of a tool, TED,

which implements this approach. The planned im-

https://github.com/scumjr/dirtycow-vdso

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

368

Table 2: TED’s ﬁndings on the public web server.

Type Description Action

System Kernel vulnerable to dirtyCOW and dirtyCOW poke variant Upgrade kernel

System

Kernel vulnerable to CVE20177308

Disable user namespace usage

to unprivileged users.

System

Kernel vulnerable to CVE20162384

Update kernel or restrict USB

access.

System

Kernel vulnerable to CVE20176074

Disable kernel DCCP module.

System Machine vulnerable to Spectre variant 1,2 and Meltdown Upgrade kernel, enable KPTI

ELFs 71 binaries compiled without canaries of which 26 without NX -

provements to TED include automated detection of

malicious binaries through the integration of an an-

tivirus such as ClamAV. Moreover, to improve the

accuracy of the ELFs tests, the capability to analyze

each binary to verify that no unsafe functions are used

will be added. From the functionality perspective,

despite TED runs all the checks it performs inside

containers, the main application still runs on the na-

tive machine. Fully containerizing TED, including

the supporting functionalities, will reduce the depen-

dencies needed to the sole Docker platform, making

the tool even more suitable for cloud environments,

where containers are already used in many cases and

where the Docker platform often is pre-installed, and

would allow TED do be easily deployed with orches-

tration tools such as Kubernetes, increasing drasti-

cally the scope and the target audience. Finally, fu-

ture work includes research on protections of binaries

from reverse engineering, which at the moment are

noticeably scarce, exception made for code obfusca-

tion techniques.

REFERENCES

Chen, X., Xue, R., and Wu, C. (2017). Timely address space

rerandomization for resisting code reuse attacks. Con-

currency and Computation, 29(16).

Choi, Y.-H., Park, M.-W., Eom, J.-H., and Chung, T.-M.

(2015). Dynamic binary analyzer for scanning vul-

nerabilities with taint analysis. Multimedia Tools and

Applications, 74(7):2301–2320.

Feng-Yi, T., Chao, F., and Chao-Jing, T. (2016). Memory

vulnerability diagnosis for binary program. ITM Web

of Conferences, 7.

Gruss, D., Lipp, M., Schwarz, M., Fellner, R., Maurice, C.,

and Mangard, S. (2017). Kaslr is dead: Long live

kaslr. volume 10379, pages 161–176. Springer Ver-

lag.

LXC-Doc (2018). Lxc ofﬁcial reference. https://

linuxcontainers.org/lxc/introduction/. Accessed on

20/10/2018.

Marco-Gisbert, H. and Ripoll, I. (2013). Preventing brute

force attacks against stack canary protection on net-

working servers. In 2013 IEEE 12th International

Symposium on Network Computing and Applications,

pages 243–250.

NIST (2018). Nist nvd, vulnerabilities statistics. https://

nvd.nist.gov/vuln/. Accessed: 10/06/2018.

Novark, G. and Berger, E. D. (2010). Dieharder: Securing

the heap. In Proceedings of the 17th ACM Conference

on Computer and Communications Security, CCS ’10,

pages 573–584, New York, NY, USA. ACM.

Rkt-Doc (2018). Rkt ofﬁcial reference. https://coreos.com/

rkt/docs/latest/. Accessed on 20/10/2018.

Solanki, J., Shah, A., and Lal Das, M. (2014). Secure pa-

trol: Patrolling against buffer overﬂow exploits. Infor-

mation Security Journal: A Global Perspective, pages

1–11.

Song, D., Brumley, D., Yin, H., Caballero, J., Jager, I.,

Kang, M. G., Liang, Z., Newsome, J., Poosankam, P.,

and Saxena, P. (2008). Bitblaze: A new approach to

computer security via binary analysis. In Sekar, R.

and Pujari, A. K., editors, Information Systems Secu-

rity, pages 1–25, Berlin, Heidelberg. Springer Berlin

Heidelberg.

Ulrich, F. (2017). Exploitability Assessment with TEASER.

Msc thesis, Northeastern University.

Wang, R., Liu, P., Zhao, L., Cheng, Y., and Wang, L. (2017).

deexploit: Identifying misuses of input data to diag-

nose memory-corruption exploits at the binary level.

The Journal of Systems & Software, 124:153–168.

Younan, Y., Pozza, D., Piessens, F., and Joosen, W. (2006).

Extended protection against stack smashing attacks

without performance loss. In 2006 22nd Annual Com-

puter Security Applications Conference (ACSAC’06),

pages 429–438.

TED: A Container based Tool to Perform Security Risk Assessment for ELF Binaries

369
