Data Preparation for Fuzzy Modelling using Intervals

Arthur Yosef

, Moti Schneider

, Eli Shnaider

, Amos Baranes

and Rimona Palas

Tel Aviv-Yaffo Academic College, Israel

Netanya Academic College, Israel

Peres Academic Center, Israel

College of Law and Business, Israel

Keywords: Data Mining, Fuzzy Logic, Intervals, Central Tendency, Data Preparation.

Abstract: Model-building professionals are often facing a very difficult choice of selecting relevant variable/s from a

set of several similar variables. All those variables are supposedly representing the same factor but are

measured differently. They are based on different methodologies, baselines, conversion/comparability

methods, etc., thus leading to substantial differences in numerical values for essentially the same things. In

this study we introduce a method that utilizes intervals to capture all the relevant variables that represent the

same factor. First, we discuss the advantages utilizing intervals of values from the stand point of reliability,

better and more efficient data utilization, as well as substantial reduction in the complexity, and thus

improvement in our ability to interpret the results. In addition, we introduce an interval (range) reduction

algorithm, designed to reduce excessive size of intervals, thus bringing them closer to their central tendency

cluster. Following the theoretical component, we present a case study. The case study demonstrates the

process of converting the data into intervals for two broad economic variables (each consisting of several

data series) and two broad financial variables. Furthermore, it demonstrates the practical application of the

procedures addressed in this study and their effectiveness.

1 INTRODUCTION

1.1 Description of a Problem

The purpose of modelling is to explain behaviour of

a given dependent variable. We must determine on

theoretical grounds, what are the explanatory

variables that can explain such behaviour. After

determining theoretically, what variables should be

included in the model, the next step is to locate

numerical measurements of those variables (both

dependent and explanatory). It is not always simple

and straight-forward process. In the case study

presented below, we are presenting several examples

of variables which can be represented by several

(and in some cases large number) of data series. For

example, one of the variables presented in our case

study is: the measurements of aggregate economic

activity per capita, such as GDP per capita, or GNI

per capita (or in previous years – GNP per capita).

Those are very common and widely used

measurements. Which among the three is the most

appropriate? There are additional variations of data.

For example, if we are utilizing cross-national data,

and since all the values are presented in U.S. dollars,

there are additional differences among various data

series due to currency conversion methods or due to

different baselines. There are data in current U.S.

dollars (USD), as well as data in constant 1990

USD, in constant 1995 USD, in constant 2000 USD,

and in constant 2005 USD. There are data series

based on regular currency conversion method vs.

PPP (purchasing power parity) conversion method.

Also, several data series based on current USD were

downloaded in different years and differ

substantially from each other due to changes in

measurement methodology over time. Thus, despite

the fact, that all these measurements are (from our

perspective) measuring essentially the same thing,

there are very substantial differences among various

data series in terms of values, and even in their

scale. For example, for the year 1985, we ended up

with 17 different data series representing “aggregate

economic activity per capita”.

In most cases, modellers do not use all the

possible data series, but rather select one or several

such series. The question is: which of the various

data series to select? Most modellers either select

Yosef, A., Schneider, M., Shnaider, E., Baranes, A. and Palas, R.

Data Preparation for Fuzzy Modelling using Intervals.

DOI: 10.5220/0007947102470257

In Proceedings of the 11th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2019), pages 247-257

ISBN: 978-989-758-382-7

247

the most popular and easiest to obtain variables. In

some other cases the decision is based upon the

availability of data, amount of missing observations,

etc. The less legitimate approach is: to try several

different variables, and then select the ones

generating results that best facilitate the conclusions

these modelers want to reach. Of course, there is

always a possibility of criticism: why a given

selection among the data series was made, and not

another. The method introduced in this study

precludes such criticism, since all the data series are

utilized.

1.2 Advantages of Utilizing Intervals

In this study we introduce a method of converting

numerical vectors into ranges (intervals) of values

that are derived from all the available data series.

There are several important advantages of

transforming available data into intervals of values:

a. The very basic principle in the field of

Information Systems is: all available data are

valuable (unless suspected of being severely

distorted) and should be utilized in the modeling

process.

b. Confidence in the modelling results: when the

approach is inclusive and involves all the

available data series, then obviously the

confidence in results is greater vs. modelling

process involving selected data series while

ignoring others.

c. Efficient handling of missing observations: This

issue arises when in many data series there is a

large number of missing measurements. For

example, in our case study, we utilized

economic data from over 125 countries (for

variables: aggregate economic activity per

capita and exports per capita), but in many data

series (numerical vectors), we encountered a

problem of missing data for dozens of countries.

In addition, the set of missing countries was not

the same in different data series. However, the

problem of missing data was resolved by

constructing intervals for every country, for

which there was at least one measurement. Of

course, in some intervals there were more data

points and in others less, but we included all

these countries in the modeling process, and

thus increased our confidence in the results.

d. It is much easier to reach meaningful and

unambiguous conclusion due to the drastic

reduction of the amount of regression runs. For

example, if our dependent variable is “aggregate

economic activity per capita” (17 data series),

and our explanatory variable is “exports per

capita” (12 data series), then when trying all

possible combinations of these variables, we

will have to perform over 200 regression runs.

The problem here is not only the amount of

work, but also the question of how to

summarize so many results and to reach

meaningful conclusion? However, when using

the method presented here, the amount of

regression runs drops to 4:

1. Regression using only Minimum values

2. Regression using only Maximum values

3. Regression of Minimum for dependent variable

vs. Maximum of explanatory variables

4. Regression of Maximum for dependent variable

vs. Minimum of explanatory variables

Note: It does not matter how many explanatory

variables are expressed in terms of intervals, the

method will still require only four regression runs.

The four regression runs generate four results,

which again can be reduced to an interval

between the minimum and the maximum value

of the results, and this interval can be used to

draw conclusions as well as for further

computations.

1.3 Literature Survey

The idea of utilizing intervals in fuzzy information

processing is not new. Schneider and Kandel (1993)

introduced the idea of utilizing Fuzzy Expected

Intervals (FEI) in order to handle higher degrees of

uncertainty in Fuzzy Expert Systems. Wagman et al.

(1994) proposed to generate intervals of real

numbers to be processed by the fuzzy matching

algorithm.

Nguyen and Kreinovich (1996) address the issue

of estimating intervals within the domain of physical

measurements during the manufacturing process. If

here is a variable , which cannot be measured

directly, (or very difficult to measure directly) then it

is estimated indirectly (the procedure is called

“indirect measurement”), using a related variable .

Due to imprecision of measurements, numerical

values of  are measured in terms of intervals, and

the authors address the issue of estimating the

corresponding intervals of the computed variable .

Hans and Gottwald (1995), define theoretically

various implementations of fuzzy intervals. The

authors present ways to define fuzzy interval, such

as (a) defining a crisp interval to form the kernel,

from which the membership function decreases to

zero, or (b) by two fuzzy numbers representing the

edges of interval. The authors also describe

KDIR 2019 - 11th International Conference on Knowledge Discovery and Information Retrieval

248

mathematical operations on fuzzy numbers as well

as fuzzy intervals. They discuss “interval

mathematics” which is a field of numerical

mathematics that originated out of the usual calculus

of errors and is based on the idea to work directly

with intervals (instead of real numbers and their

error bounds).

Ip et al. (2003) postulate, that when data are

scattered, the obtained regression model generates a

possibility range that is too wide. Thus, they apply

fuzzy linear regression with fuzzy intervals and used

validation experiments to demonstrate effectiveness

of the method Bustince and Burillo (1995) introduce

the concepts of correlation and correlation

coefficients of interval-valued intuitionistic fuzzy

sets.

Grzegorzewski (2002) addresses a problem of

interval approximation of fuzzy numbers. He

proposes a new interval approximation operator

designed as a measure of distance between fuzzy

values. Cheng and Mon (1993) introduce approach

of evaluating fuzzy system reliability by interval

arithmetic and α-cuts. They demonstrate through

theoretical analysis as well as an example the

simplicity and generality of their proposed approach.

D’Urso et al. (2015) introduce a fuzzy clustering

model for interval-valued data. In order to avoid

negative effects of possible outliers on the clustering

process, they propose a robust method with a

trimming rule.

Fuzzy logic and the theory of Fuzzy sets were

introduced by Zadeh (1965) and since then have

been widely applied in various branches of

information processing. The modelling method

based on Soft Regression, where historical data is

converted into intervals and where interval related

problems are extensively discussed is presented in

Shnaider. and Yosef (2018).

2 THE METHOD FOR

CONSTRUCTING INTERVALS

2.1 Constructing the Matrix of

Intervals

When preparing data for modeling, every variable is

treated as a numerical vector. In other words, it is a

column of numbers. In the case when several

numerical vectors supposedly represent the same

thing, we can construct a matrix, such that each

numerical vector is a column in that matrix. For

example, in our case study, we utilize 17 variables

representing aggregate economic activity per capita

for the year 1985. Thus, we create a matrix, where

17 variables appear as columns in that matrix, while

each row represents a data for a given country.

Therefore, for countries, which appear in all 17

variables (columns), we can construct an interval of

values, which consists of 17 numbers. The interval

will be defined by its smallest value and its largest

value. Obviously, similar intervals can be created for

countries that do not appear in all 17 variables –

those will be intervals containing fewer

measurements. In the extreme cases, where a

country appears in only one numerical vector (out of

17), then its range will be represented by the same

value as the minimum and the maximum. Thus, the

matrix of 17 columns can be transformed into the

matrix of two columns: column of minimum values

for each row, and column of maximum values of

each row.

There is a very important issue that must be

addressed when constructing intervals as discussed

above: it is critical to make sure that before we

construct the intervals, all variables are converted

into the same scale, otherwise the interval is

distorted and meaningless. In general, bringing all

the different numerical vectors into the same scale is

possible by recalculating all of them based on the

same reference point. Selected reference point

should be reasonable and reliable. When utilizing

method based on fuzzy logic (such as Soft

Regression, Fuzzy linear regression, Fuzzy

Cognitive Maps, etc.), defining all the numerical

vectors in terms of membership in the same fuzzy

set is an additional (and very effective) way to

address the scale problem.

Once all the values of the matrix are converted

into the grades of membership, then we can sort

values in each row from the smallest to the largest

since now they are all members of the same fuzzy

set. This way, for every row, we construct intervals

consisting of grades of membership.

2.2 Outliers vs. Central Tendency of

Intervals

By including all the available information (including

unavoidable outliers) we will necessarily end up in

some cases with intervals that are very extensive,

and therefore not very helpful for modeling.

Normalizing the data, which is part of the process to

convert the numerical vectors into fuzzy sets allows

us to reduce and contain to some extent the problem

of outliers by redefining each variable in terms of

membership of its elements in pre-defined fuzzy set.

Data Preparation for Fuzzy Modelling using Intervals

249

Moreover, in order to perform successful modeling,

it is desirable to identify the core area of each

interval which represents, even in approximate

terms, its central tendency. Narrow intervals do not

differ much from their core central tendency.

However, very extensive intervals require additional

work of interval reduction in order (if and when

possible) to create a better reflection of their central

tendency.

Therefore, we introduce additional steps

designed to reduce the extent of the original range,

while attempting at the same time to assure that

minimum of valuable information is lost. In other

words, the purpose of reduction process is to

eliminate outliers as carefully as possible without

distorting the central tendency of the interval in the

process. The algorithm of interval reduction is

presented below.

3 RANGE REDUCTION

ALGORITHM (RRA)

The algorithm of range reduction consists of the

following main components:

1. Preparation Stage

2. Identifying and eliminating outlying identical

(or almost identical) vectors.

3. Reducing range: Deleting outlying elements

4. Additional reduction of the range and deletion

of over-extended intervals

3.1 Preparation Stage

Let’s assume that we have  numerical vectors, each

consisting of  elements (In other words, we have a

matrix 







where  is a number of rows

and  is a number of columns). First, we normalize

all the numerical vectors by applying relevant

membership function, such that the resulting

elements of the numerical vectors will consist of

values [0,1], which represent degree of membership

in the same fuzzy set, i.e., A fuzzy matrix of  is a

matrix:













(1)

Where















(2)

for all  and 



is a membership

functionfor all .

3.2 Identifying and Eliminating

Outlying Identical (or Almost

Identical) Vectors

The idea behind this part of the algorithm is to

correct possible distortion, when due to unique

methodology, conversion methods, etc., some

vectors become outliers for all or most of their

elements. If only one such numerical vector appears

in our data, the interval reduction procedure

presented in stage 3 will handle it. However, if two

or more vectors like that appear, and they are

identical or almost identical, then the method

presented in stage 3 will not perform effectively.

This problem might arise when collecting data series

that are having different names, but are essentially

the same mathematically. They might differ in scale,

which makes it difficult to detect the similarity

among them. However, once these data series are

normalized, they might become almost identical.

Thus our objective at this stage is to locate possible

outlying pairs or groups of vectors that are identical

or almost identical and delete the redundant

elements. We should note that having identical or

almost identical vectors does not constitute a

problem as long as they are confined mostly to the

internal portion of the interval. However, if they are

located on the edges, they will imperil our ability to

reduce the interval, because once we delete a given

element, there will remain another one which is

almost the same, and then there could be an

additional one, etc.

Another important point to consider: when

deleting elements from the matrix, we must keep in

mind that some rows might consist of very few

measurements. No element should be deleted, if in

that row, there are only four measurements or less.

The reason for that is: our objective is to attain better

representation of the central tendency, but we want

to achieve it without possible loss of information.

When amount of elements in a given interval is

large, then deleting several outlying elements only

brings us closer to the core of the “central

tendency”. However, when the amount of elements

is small (four or less), then deleting a single element

can potentially lead to a loss of important

information and distort our view of central tendency.

In this case it is preferable to keep the whole original

interval.

a. Sort each row of the matrix from the lowest

value on the left side to the highest value on the

right side while arranging all rows to be left-

justified. Denote the sorted matrix as:

KDIR 2019 - 11th International Conference on Knowledge Discovery and Information Retrieval

250

















(3)

Note: Following the stage above, the new matrix

loses its original structure by its initial vectors. Now

we have a matrix, such that in each row, the first

element on the left side is the minimum value for

that row, the next one is the second smallest value

and so on until we reach the last value on the right

side, which is the maximum for that row.

b. 

c. Consider the columns 1 and  in matrix 

































 











Then

1. delete from the column  all the elements

from the rows where there are 7 measurements or

more (we say that columns 1 and  are almost

identical)

2.    

3. Go-to step (c)

where 









is a number of values in row  of

matrix 





,  is a cardinal of the set .

Note: In the expression 













 











,  can be replaced by , based on

specific characteristics of a given data

d. Create similar matrix where all the values of







are right-justified (Matrix is denoted by

















e.  

f. Consider the columns  and  in matrix







if 

〖



〗

 

 













 











where 









is a number of values in

row  of matrix 





Then

1. delete from the column  all the elements

from the rows where there are 7 measurements or

more (we say that columns  and  are almost

identical)

2.   

3. Go-to step (f)

g. Create a new matrix where all the values are left

justified (in other words, if there are empty cells

in a given row, they appear on the right-hand

side of the row). The resulting matrix is denoted

















when 

3.3 Reducing Range: Deleting Outlying

Elements

a. Create additional matrix 

















such

that 











 





. (In other words, we

will compute differences in the matrix 



for

each row , between element 





and

element 





 for  ).

b. For any given row  having 









amount of elements, we can delete





 









elements, where 







is a number of

values in row  of matrix 



and







is a ceiling

function. We evaluate

 



































































(4)

when 





- is the last element of the interval in

row  of matrix



. In (4) the first term represents,

for any given row , sum of 



elements on the left

side of the matrix, the second term represents sum of





elements on the right side of the matrix, and the

third term represents all the possible permutations of

sums of elements from the left side and the right side

such that the total amount of elements remains



Then delete from matrix 



, 



elements that

correspond to the maximum term found in (4).

The Matrix resulting from the reducing range of

individual intervals, is denoted as















where 







 



.

(5)

3.4 Additional Reduction of the

Interval

For every row , find the new interval by subtracting





 



 



(



is the last value of

interval in row of 



). We consider interval size of





 as excessively large (See note

below).

a. 

If 



 and 









where 







is a number of values in row 

of matrix 



Data Preparation for Fuzzy Modelling using Intervals

251

Then

If 



 



> 



 



Then

1. delete 



2. 















 

3.  

Else

1. delete 



2. 















 

3.  

b. If 



 



 



(the new range after

deletion) is still > then if the interval greatly

exceeds, the user might consider deleting

that row from the matrix. The user may leave the

new interval as is, if it exceeds  only to a

minor degree. The selection of  is based on

individual reasoning by a modelling professional

and could differ based on circumstances and

constrains. In our studies we selected 0.3 as a cut-

off point. In other words, if after all the deletions

of the RRA there was still an interval wider than

0.3, then the whole row was deleted from the

data.

Note: the very wide range (above – which is

a large portion of the entire numerical domain [0,1])

means that there must be some very serious problem

of measurement or error associated with that

particular row in the matrix. We must keep in mind,

that measurements appearing in a given row represent

(from our perspective) different measurements of the

same thing and therefore such a wide discrepancy is

unreasonable. If such discrepancies appear in just few

rows and are relatively small fraction of our data, then

we can justify deletion of these intervals (which is a

common practice in modelling when there is a

reasonable suspicion of problematic data). If, on the

other hand, even after applying interval reduction

algorithm, - large portion of intervals are still

characterized by excessive ranges, then we obviously

have a modelling problem, which requires to re-

specify the model - redefine the variables included in

the model. In our case study, for each of the variables,

we deleted only a very small percentage of the rows

in all the variables (see Tables 3a and 3b) – which is

not expected to affect final results of the modelling. It

also can be seen in Table 3b, that for a variable, which

was inappropriate for RRA reduction process, the

percentage of deleted rows is substantially higher.

The matrix created as a result of applying RRA

procedure presented above, is denoted as























(6)

where 



, 



are a number of rows and columns

that remain following the RRA process.

Following the range reduction by applying RRA

algorithm, we define two vectors on matrix 







































































where 

















and 













(7)







 (In other words, 





is the minimum

value for each row and 





is the maximum value

for each row).

4 CASE STUDY

In this study we present examples of using intervals in

two domains: economics and finance. In particular,

we emphasize heuristics when defining a membership

function, such that the data transformation

corresponds to the logic of predefined fuzzy set, and

the integrity of the data is maintained.

As an example, we present two economic

variables and two finance variables. Each of the

variables is represented by a number of data series

(numerical vectors) as presented in Tables 1 and 2.

Aggregate Economic Activity per Capita

(AEA/Cap): The variables that represent aggregate

economic activity per capita are: GDP/Cap, GNI/Cap

and GNP/Cap. All of them are considered common

and legitimate measurements. Some of these data

series are in current U.S. dollars (USD), while others

are in constant 1990 USD, in constant 1995 USD, in

constant 2000 USD, and in constant 2005 USD. There

are data series based on regular currency conversion

method vs. PPP (purchasing power parity) conversion

method. Also, since we are using data bases,

downloaded in different years (2004, 2009, 2015),

there probably were differences in measurement

methodology because the numbers were different.

Thus, we ended up with 17 variables representing

aggregate economic activity per capita in 1985.

Exports per Capita: The variables that represent

“exports per capita”, are: Merchandise Exports,

Exports of Goods and Services, Exports of Goods and

Services-BoP, Exports of Goods, Services and

Income- BoP. We found these variables in current

USD, in constant 1995 USD, in constant 2000 USD

and in constant 2005 USD. Also, similarly to the

case above, since we are using data bases,

KDIR 2019 - 11th International Conference on Knowledge Discovery and Information Retrieval

252

Table 1: Economic data series (1985).

Aggregate Economic activity per capita

Exports per capita

1. GNP/Cap. WDR 1987. Current USD

2. GDP/Cap. 1990 intl. Geary-Khamis $

3. GDP/Cap (constant 1995 US$)

4. GNI/Cap – Atlas (current US$ - 2004)

5. GDP/Cap, PPP (constant 1995 intl. $)

6. GDP/Cap, PPP (current intl. $ - 2004)

7. GNI/Cap, PPP (current intl. $ - 2004)

8. GDP/Cap (current US$ - 2004)

9. GDP/Cap (constant 2000 US$)

10. GNI/Cap, Atlas (current US$ - 2009)

11. GDP/Cap, PPP (constant 2005 intl. $)

12. GDP/Cap, PPP (current intl. $ - 2009)

13. GNI/Cap, PPP (current intl. $ - 2009)

14. GDP/Cap (current US$ - 2015)

15. GDP/Cap (constant 2005 US$)

16. GNI/Cap, Atlas (current US$ - 2015)

17. GNI/Cap (constant 2005 US$)

1. Merchandise Exports per capita (current USD), WDR 1987.

2. Exports of goods and services per capita (BoP, current US$ - 2004)

3. Exports of goods and services per capita (constant 1995 US$)

4. Exports of goods, services and income per capita (BoP, current

US$ - 2004)

5. Merchandise exports per capita (current US$ - 2004)

6. Exports of goods and services per capita (BoP, current US$ - 2009)

7. Exports of goods and services per capita (constant 2000 US$)

8. Exports of goods, services and income per capita (BoP, current

US$ - 2009)

9. Exports of goods and services per capita (current US$ - 2009)

10. Exports of goods and services per capita (constant 2005 US$)

11. Exports of goods and services per capita (current US$ - 2015)

12. Merchandise exports per capita (current US$- 2015)

GDP/Cap, GNI/Cap and GNP/Cap are GNP per capita, GNI per capita and GNP per capita, respectively.

Table 2: Finance data series (2012).

Solvency

Profitability

1. Interest Coverage Ratio

2. Cash from Operations (CFO) to Total Debt

1. ROA (Return on Assets)

2. Pre-taxes income over Sales

3. Net Profit Margin

4.Research & Development Expense to Sales

5. Operating Income to Total Assets

6. EBITDA Margin Ratio: (Earnings Before Interest, Taxes,

Depreciation and Amortization) to Total Revenue

downloaded in different years (2004, 2009, 2015),

there probably were differences in measurement

methodology because the numbers were different.

Thus, we ended up with 12 Export per capita

variables in 1985.

Profitability: Profitability ratios represent the

relative measures of the earnings the company

created, and therefore have the closest association

with the profits. Each one of the above proxy

variables explains some aspects of profitability.

Since there are six proxy variables, the RRA

reduction process is applicable.

Solvency: The company's solvency is represented by

the Interest Coverage Ratio and the Cash Flow from

Operations to total debt.

a. The first ratio measures the proportionate

amount of operating income that is used to

cover interest payments, since these interest

payments are usually made on a long-term

basis, they are often treated as an ongoing

expense.

b. The second ratio representing the company’s

solvency is: Cash Flow from operations to total debt.

It indicates how long it will take the company to pay

off all of its debt if it devotes all of its cash flow

from operations to debt repayment, this ratio

provides a snapshot of the overall financial health of

the company.

Since this variable consists of only two data

series, the RRA is not applicable in this case.

4.1 Normalizing Economic Data

As discussed above, in order to create intervals, it is

necessary to bring all the different numerical vectors

representing a given variable into the same scale.

When utilizing computing methods based on fuzzy

logic, defining all the data series of a variable as

members of the same fuzzy set actually brings all of

them into the same scale.

For the economic variables presented in this

study, we define a fuzzy set of “Successful

Economies”. The conversion of data series from

numerical vectors consisting of raw data into

numerical data of the elements of fuzzy set is done

via process of data normalizing. We normalize data

Data Preparation for Fuzzy Modelling using Intervals

253

by introducing the heuristically determined

maximum and minimum thresholds.

The first step in the normalizing process is: we

define 



as the value in a given vector such that

all elements equal to or greater than 



are

assigned the value of one (they are full members of

the fuzzy set “Successful Economies”. We selected

“Average of High-Income Economies” as our





for the both economic variables in this study.

Such average values appear in the data bases and

hard copy publications of the World Bank for all

variables. By turning all the numbers above





into 1, we neutralize the negative effect of the

outliers having excessively high values without

deleting these data points.

Similarly, we define 



as the value in

numerical vector such that all elements equal to or

smaller than 



are assigned value of zero, which

means they definitely do not belong to the category

of “Successful Economies”. We selected “Average

of Low-Income economies as our 



. Those

average values also appear in the data bases and hard

copy publications of the World Bank for all

variables. By turning all the numbers below





into 0, we neutralize the negative effect of the

outliers having excessively low values without

deleting these data points.

In this case, a membership functions (in (1) and

(2)) for the relevant data series are:



















 



































 







(8)

where







is a matrix and 







are

the Maximum cut-off point and Minimum cut-off

point as explained above.

We emphasize again: 



and 



must be

determined based on logic and common sense for

each domain (for every variable), so as not to distort

the data. They also depend on what we are trying to

model. If the objective is to build cross-national

model involving various world economies, then the

procedure presented above is appropriate and

logical. All countries can be evaluated in reference

to the best performers (High income) and the worst

performers (Low income). However, if we are trying

to model the best performers within the set of “High-

Income Economies” in comparison to other

countries within the same group of “High-Income

Economies”, then the normalizing procedure

presented above would be inappropriate and illogical

for such task, and different membership function

would be required.

4.2 Normalizing Financial Data

The financial variables in this case study were used

to construct a model to evaluate earnings of

corporations traded in the major U.S. stock markets

(AMEX, NASDAQ, and NYSE). The data was

extracted from the data base (XBRL) containing

financial reports the companies traded in the stock

market are required to submit. The data for 1585

manufacturing industry companies were downloaded

(years 2012 – 2016).

All the downloaded companies were divided into

three groups:

1. The group of “Winners”: companies which were

continuously profitable, reported a positive net

income, on annual basis for every year between

2012 to 2016 (including 2012 and 2016).

2. The group of “Losers”: contains companies that

reported a negative net income on annual basis

for every year between 2012 to 2016 (including

2012 and 2016).

3. All the remaining companies, the “Middle

Group”.

We ended up with 622 companies having

positive operating income for consecutive 5 years

(2012-2016), 246 companies with negative operating

income for consecutive 5 years, and 398 companies

that had positive and negative operating income over

the 5 years.





for the year 2012 was determined as

follows (for every variable): the values of the

companies belonging to the group of “Winners”

were arranged from the lowest to the highest, and

then divided into four quarters. The highest value of

the lowest quarter (i.e., the 25th percentile or the

first quartile) was selected as 









for the year 2012 was determined as

follows (for every variable): the values of the

companies belonging to the group of “Losers” were

arranged from lowest to highest, and then divided

into four quarters. The lowest value of the highest

quarter (i.e., the 75th percentile or the third quartile)

was selected as





Justification: As was stated above, the process

must be in line with human logic and common sense

and modellers should be capable of defending their

decisions. For example, for 



, instead of

selection made above, we could have selected the

minimum measure of the all companies in the

category of “Winners”. Such selection would

KDIR 2019 - 11th International Conference on Knowledge Discovery and Information Retrieval

254

include all the companies in the group “Winners” as

a full member in the Fuzzy Set of “Winners”.

However, such a selection would include unknown

amount of borderline cases, whose corresponding

values of explanatory variables (which reflect their

performance) often intermix with the more

successful performers from the “Middle Group”. On

the other hand, by defining only the higher 75% of

the “Winners” as the full members of the fuzzy set

representing the Winner Group, we prevent the vast

majority of the borderline cases from being

considered as full members of the group, thus

making the identification of the group more clear-

cut. Moreover, the 25% of the “Winners” which are

not assigned the value of 1, which represents the full

membership in the fuzzy set, will be assigned grade

of membership close to 1, still reflecting accurately

the relative strength of their performance, and hence

the integrity of the data is maintained. All this in

contrast to the Boolean method, where all those who

are not assigned the value of 1, get value of 0, thus

becoming an important source of distortions in

numerous statistical methods.

Similar, but inverse reasoning applies to 



4.3 A Note regarding the Normalizing

Process of Inversely Related

Variables

When we define fuzzy sets for the purpose of

explaining the behaviour of a dependent variable,

corresponding fuzzy sets are defined for the

explanatory variables, so that the modelling be

meaningful. In the case of the four variables

presented in this case study, the relations between

the relevant variables are direct, and the normalizing

procedure presented above is logical and

meaningful. However, when there is an inverse

relation between a dependent variable and an

explanatory variable, applying the same exactly

process as in the case of directly related variables

will not work. For example, in economic model

when there is a direct relation, then 



(reflecting

“High Income Economies”) are associated with high

number and 



(reflecting “Low Income

Economies”) are associated with low numbers.

However, when the relation between variables is

inverse, “High Income Economies” group will be

associated with low numbers, and “Low Income

Economies” will be associated with high numbers.

The membership function as defined above still

remains the same, but the relevant fuzzy set is

defined in inverse: Full members of the fuzzy set are

the economies that are definitely not members in

“High Income Economies” group. Therefore, the

“Low Income Economies” will be defined as full

members of this fuzzy set and be assigned the value

of 1.

Thus, the Average of Low Income Economies will

become 



, and conversely, the Average of High

Income Economies” will become 



. Hence, the

equation (8) applies in both cases – direct and

inverse.

In the case of Financial model, if a given

variable is characterized by large values in the group

of “Losers” and small values in the group of

“Winners”, then we have an inverse relation.

In this case we define 



and 





follows:





: the values of the companies belonging to

the group of “Losers” are arranged from lowest to

highest, and then divided into four quarters. The

highest value of the lowest quarter is selected as











: the values of the companies belonging to

the group of “Winners” were arranged from lowest

to highest, and then divided into four quarters. The

lowest value of the highest quarter was selected

as





5 SOME RESULTS

Tables 3a and 3b demonstrate the effectiveness of

range reduction process. In particular, the two tables

focus on the amount of intervals characterized by an

excessive range. In the Table 3a, the variable

“Economic Activity per Capita” consists of 17 data

series. Following the normalizing process (which

reduced the problem of outliers to some extent),

there were still 28 intervals (out of 131) having

excessive ranges. However, the RRA process

reduced the amount of excessive intervals to 7.

Eventually, 4 intervals out of 7 were retained

because their range did not exceed the bench-mark

of 0.3, while 3 rows had still excessive intervals and

were deleted.

Variable “Exports per Capita” consists of 12 data

series. Following the data normalizing process, 22

intervals still had excessive ranges. However, the

RRA procedure reduced the amount of the excessive

intervals to just 2, and eventually only one row was

deleted.

Data Preparation for Fuzzy Modelling using Intervals

255

Table 3a: Interval Reduction – Economic Variables.

1985

Amount

Columns

Amount of

Countries

Amount of

Excessive

Ranges before

reduction

Amount of

Excessive

Ranges after

reduction

Amount of retained

excessive intervals

(range<0.3)

Amount of

deleted rows

(range>=0.3)

AEA/Cap

131

Exports/Cap

131

Table 3b: Interval Reduction – Finance Variable.

2012

Amount

Columns

Amount of

Companies

Amount of

Excessive

Ranges before

reduction

Amount of

Excessive

Ranges after

reduction

Amount of retained

excessive intervals

(range<0.3)

Amount of

deleted rows

(range>=0.3)

Profitability

6331

1641

253

232

Solvency

6331

652

Table 4a: Singapore.

1985

income/output per capita

Num. of Elements

Interval

Range

Raw Data

6466.3, 6781.8, …,12192.9, 12333

[6466.3, 12333]

5867.2

Normalizing Data

0.520, 0.521, …, 0.819, 0.848

[0.520, 0.848]

0.328

After RRA

0.520, 0.521,…, 0.683, 0.735

[0.520, 0.735]

0.215

Table 4b: India.

1985

income/output per capita

Num. of Elements

Interval

Range

Raw Data

264.8, 266.3, …, 1003.5, 1078

[264.8, 1078.6]

813.8

Normalizing Data

0, 0, …, 0.006, 0.008

[0, 0.008]

0.008

After RRA

0, 0,…, 0.001, 0..005

[0, 0.005]

0.005

The variable “Profitability” consists of 6 data

series, and therefore still allows to apply RRA

procedure. Following the normalizing procedure,

there were still 1641 intervals having excessive

ranges. RRA procedure reduced this amount to

merely 253 intervals. Since most of those intervals

did not exceed our bench-mark of 0.3, only 21 rows

(out of 6331) were deleted.

The results for Solvency are much worse. The

reason is: the variable “Solvency” consists of only

two data series, and therefore, the RRA procedure is

not applicable. Therefore 652 rows were eventually

deleted. The contrast vs. other variables presented

above demonstrates the effectiveness of the RRA

procedure.

Tables 4a-4e demonstrate the effectiveness of

the RRA algorithm in terms of individual cases. We

decided to choose as an example the variable

“Economic Activity per Capita”, because this

variable consists of 17 data series. First thing we can

observe is that the original raw data are

characterized by a very wide discrepancy, even by

orders of magnitude. Therefore, without normalizing

the data, the intervals will be meaningless group of

numbers. In some of the examples below, just the

process of normalizing creates a narrow interval

instead of wide range visible in raw data (see India

and Switzerland below). In our example (for year

1985), the second stage of RRA was inactive

because the conditions were not applicable (there

were no numerical vectors on the edges that were

almost identical). Therefore, we present an example

of Hungary for the year 2000, where before applying

RRA there were 20 elements in the interval, 9

elements were deleted during the stage 2 of RRA

(due to almost identical numerical vectors on the

edges of data matrix) and 3 elements were deleted

during the stage 3of RRA. This example

demonstrates the capability of the RRA to prevent a

bias in determining the central tendency of interval

due to the prevalence of large number of very

similar data series that can potentially misrepresent

the interval due to their quantity in one of the edges

of the data matrix.

KDIR 2019 - 11th International Conference on Knowledge Discovery and Information Retrieval

256

Table 4c: Switzerland.

1985

income/output per capita

Num. of Elements

Interval

Range

Raw Data

14921, 16340, …, 44897, 46496

[14921,46496]

31575

Normalizing Data

1, 1,…, 1, 1

[1, 1]

After RRA

1, 1,…, 1, 1

[1, 1]

Table 4d: Hungary.

1985

income/output per capita

Num. of Elements

Interval

Range

Raw Data

1880, 1880, …, 9759.7, 11845.9

[1880, 11845.9]

9965.9

Normalizing Data

0.146, 0.148, …, 0.508, 0.526

[0.146, 0.526]

0.38

After RRA

0.146, 0.148, …, 0.209, 0.377

[0.146, 0.377]

0.231

Table 4e: Hungary.

2000

income/output per capita

Num. of Elements

Interval

Range

Raw Data

4620, 4650.2, …,16838.1, 17706

[4620, 17706.9]

13086.9

Normalizing Data

0.161, 0.162, …, 0.496, 0.538

[0.161, 0.538]

0.377

After RRA

0.163, 0.169, …, 0.257, 0.359

[0.163, 0.359]

0.196

6 SUMMARY AND

CONCLUSIONS

In this paper we presented a method for data

preparation when the variables are represented as

intervals. First we have discussed the advantages of

utilizing intervals for variables. Then we presented

the algorithm for converting singletons into

intervals. This included a description of the methods

to handle outliers and different scales for

representing information. Following the explanation

of the algorithm for creating the intervals, we

showed an algorithm to reduce the intervals. Finally,

a case study was presented to demonstrate practical

use of the process presented in this article. The case

study demonstrated effectiveness and efficiency of

the techniques presented in this study within the

domain of economic and financial modeling.

REFERENCES

Bustince H. and Burillo P. (1995). “Correlation of

interval-valued intuitionistic fuzzy sets”, Fuzzy Sets

and Systems, vol. 74, Issue 2, pages 237-244.

Cheng C.H. and Mon D.L.(1993). “Fuzzy system

reliability analysis by interval of confidence”, Fuzzy

Sets and Systems, vol. 56, Issue 1, pages 29-35.

D’Urso P., Giovanni L. D. and Massari R. (2015).

“Trimmed fuzzy clustering for interval-valued data”,

Advances in Data Analysis and Classification, vol.

9, Issue 1, pages 21–40.

Grzegorzewski P. (2002). “Nearest interval approximation

of a fuzzy number”, Fuzzy Sets and Systems, vol. 130,

Issue 3, pages 321-330.

Hans B. and Gottwald S. (1995), “Fuzzy sets, fuzzy logic,

fuzzy methods”. Chichester: Wiley.

Ip C.K.W., Kwong C.K., Bai H. and Tsim Y. C. (2003).

“The process modelling of epoxy dispensing for

microchip encapsulation using fuzzy linear regression

with fuzzy intervals”, The International Journal of

Advanced Manufacturing Technology, vol.

22, Issue 5–6, pages 417–423.

Nguyen H. T. and Kreinovich V. (1996). "Nested intervals

and sets: concepts, relations to fuzzy sets, and

applications." Applications of interval computations.

Springer, Boston, MA, pages 245-290.

Schneider M. and Kandel A. (1993). “Expectations in

Fuzzy Environments”, Journal of Fuzzy Logic and

Intelligent Systems, vol. 3, num. 1, pages. 76-89.

Shnaider E. and Yosef A. (2018). “Utilizing Intervals of

Values in modeling due to Diversity of

Measurements”, Fuzzy Economic Review,

International Association for Fuzzy-set Management

and Economy (SIGEF). vol. 23, num. 2, pages 3-26.

Wagman D., Schneider M. and Shnaider E. (1994). “On

the use of interval mathematics in fuzzy expert

systems”, International Journal of Intelligent Systems,

vol. 9, Issue 2, pages 241–259.

Zadeh L. A. (1965). “Fuzzy sets”, Information and Control

8 (3), pages 338-353.

Data Preparation for Fuzzy Modelling using Intervals

257
