Unsupervised Detection of Sub-pixel Objects in Hyper-spectral Images

via Diffusion Bases

Alon Schclar

and Amir Averbuch

School of Computer Science, The Academic College of Tel-Aviv Yaffo, POB 8401, Tel Aviv 61083, Israel

School of Computer Science, Tel Aviv University, POB 39040, Tel Aviv 69978, Israel

Keywords:

Image Processing, Subpixel, Segmentation, Anomaly Detection, Unsupervised, Sub-pixel Detection,

Diffusion Bases, Dimensionality Reduction, Hyper-spectral Sensing.

Abstract:

Sub-pixel objects are deﬁned as objects which due to their size and due to the resolution of the camera oc-

cupy a fraction of a pixel or partially span adjacent pixels. Unsupervised detection of sub-pixel objects can be

highly useful in areas such as medical imaging, and surveillance, to name a few. Hyper-spectral images offer

extensive intensity information by describing a scene at hundreds and even thousands of wavelengths. This

information can be utilized to obtain better sub-pixel detection results compared to those that are obtained us-

ing RGB images. Usually, only a small number of wavelengths contain the information that is required for the

detection. Furthermore, the intensity images of many wavelengths are noisy and contain very little informa-

tion. Accordingly, hyper-spectral images must be pre-processed ﬁrst in order to extract the information that is

needed for the sub-pixel detection. This extraction process produces an image where each pixel is represented

by a small number of features which allows the application of fast and efﬁcient detection algorithms. In this

paper we propose the Diffusion Bases (DB) dimensionality reduction algorithm in order to derive the essential

features for the sub-pixel detection. The effectiveness of the DB algorithm facilitates the application of a very

simple algorithm for the detection of sub-pixel objects in the feature space. The proposed approach does not

assume any distribution of the background pixels. We demonstrate the proposed framework for the detection

of cardboard objects in airborne hyper-spectral images of a desert terrain.

1 INTRODUCTION

Sub-pixel objects appear in images due to their rela-

tive small size compared to the resolution of the cam-

era and the camera’s distance from the objects. This is

commonly found in images of areas taken from high-

altitude cameras.

For example, in rescue missions of people lost in

open areas a camera is mounted on an airplane to

record images of the searched area. These images

are then analyzed by real-time object detection algo-

rithms. Due to the time-critical nature of such situ-

ations, large areas need to be covered quickly which

can be achieved by ﬂying a rescue plane at a high alti-

tude. However, the higher the plane ﬂies, the smaller

the objects appear in the images which may cause the

searched objects to occupy only a fraction of a pixel.

Thus, fast algorithms for the detection of sub-pixel

objects are required in such scenarios. Hyper-spectral

cameras can assist the detection of sub-pixel objects.

Such cameras capture an image in the visible spec-

trum as well as the invisible spectrum i.e. the infra-

red and ultra-violet spectrum sub-ranges. Body heat,

for example, can only be seen in the infra-red range.

Detection algorithms can combine the infra-red infor-

mation with the visible information to produce fast

and accurate detection results.

Unfortunately, processing large scale hyper-

spectral images incurs a computational cost that is

too high for most applications due to the high num-

ber of wavelengths. This is commonly known as the

curse of dimensionality. Furthermore, hyper-spectral

images usually contain noise due to poor lighting con-

ditions and physical conditions at the time the images

were taken. Hyper-spectral images also contain re-

dundant information since the number of wavelengths

is much higher than the actual degrees of freedom of

the data. Consider for example a task that separates

green objects from blue objects using an off-the-shelf

digital camera. In this case, the camera will produce,

in addition to the red and blue channels, a red channel,

which is unnecessary for this task. This phenomenon

496

Schclar, A. and Averbuch, A.

Unsupervised Detection of Sub-pixel Objects in Hyper-spectral Images via Diffusion Bases.

DOI: 10.5220/0008201604960501

In Proceedings of the 11th International Joint Conference on Computational Intelligence (IJCCI 2019), pages 496-501

ISBN: 978-989-758-384-1

is usually unavoidable since general purpose cameras

are used. Moreover, constructing a mission-speciﬁc

camera according to a-priori knowledge of the wave-

lengths that are necessary for the task is unfeasible.

Consequently, a hyper-spectral image must initially

be pre-processed in order to remove the noise and re-

dundant information and extract the smallest amount

of information needed to facilitate the efﬁcient detec-

tion of the sought-after objects. This process is com-

monly known as feature extraction or dimensional-

ity reduction and its output concisely describes each

original data item - in our case pixels - by a small

number of attributes instead of original high number

of values.

Every substance in nature has a unique spec-

tral signature that is described by the substance re-

ﬂectance values at the different wavelengths of the

spectrum. Spectral signatures are often described

by hundreds or even thousands of wavelengths de-

pending on the hyper-spectral acquisition instrument.

Considering each signature as a vector, the number of

wavelengths deﬁnes the dimensionality of the signa-

ture.

Methods for detecting sub-pixel objects in hyper-

spectral images can be divided into two categories

- supervised and unsupervised. Supervised methods

commonly utilize the uniqueness of spectral signa-

tures. Speciﬁcally, these methods use a-priori spec-

tral information of the sought-after objects. Unsuper-

vised techniques, on the other hand, do not utilize any

a-priori information and rely on the fact that the spec-

tral signature of sub-pixel objects differs from those

of their neighboring pixels. The algorithm proposed

in this paper falls into the latter category.

The proposed algorithm initially applies the re-

cently introduced Diffusion Bases (DB) dimensional-

ity reduction algorithm (Schclar and Averbuch, 2015;

Schclar and Averbuch, 2017b; Schclar and Averbuch,

2017a) to extract a small number of features. The DB

algorithm is chosen since it efﬁciently captures non-

linear inter-wavelength correlations and produces a

low-dimensional representation in which the amount

of noise is drastically reduced. The main contribu-

tion of this paper is the application of the DB algo-

rithm since it produces a low-dimensional represta-

tion where sub-pixel objects appear as pixels that are

substantially different from their neighboring pixels.

The sub-pixel objects can then be detected using a

very simple procedure.

This paper is organized as follows: in section 2

we present a survey of related work on detection of

sub-pixel objects in hyper-spectral images. The DB

algorithm is described in section 3. In section 4 we

introduce the two phase sub-pixel object detection al-

gorithm. Section 5 contains experimental results and

concluding remarks are given in section 6.

2 RELATED WORKS

Subpixel segments are also regarded in the literature

as anomalies. Different approaches have been pro-

posed to detect subpixel segments.

The Reed-Xiaoli detector (Reed and Yu, 1990) is

considered the baseline to many algorithms that fol-

lowed. Speciﬁcally, this detector assumes that the

background follows a Gaussian distribution and uses

the Mahalanobis distance of each pixel to its neigh-

bors to detect sub-pixel objects. The covariance ma-

trix is calculated globally for the entire background.

In (Zhao et al., 2015) a variation of the Reed-Xiaoli

detector is proposed for situations in which the Gaus-

sian distribution assumption does not hold globally.

Namely, the covariance matrix is only calculated in

a local neighborhood of each pixel. A kernelized

version of the Reed-Xiaoli detector is presented in

(Kwon and Nasrabadi, 2005). The pixels are implic-

itly embedded in high-dimensional space where they

can be detected using a simple Euclidean distance.

This approach generalized the baseline Reed-Xiaoli

to cases where straightforward application of the Eu-

clidean distance fails to detect sub-pixel segments.

More recently, Ma et al. (Ma et al., 2018) pro-

posed a Deep Belief Network (DBN) to detect sub-

pixel objects. An autoencoder is used to extract

high-level features. Then, sub-pixels segments are

determined according to their weighted distance to

their neighboring pixels. Olson et al. (Olson et al.,

2018) proposed a manifold learning approach cou-

pled with sampling and out-of-sample extension to

model the background. Sampling can derive a back-

ground model that is more accurate than using the

entire image since the sample will be dominated by

background pixels.

3 THE DB DIMENSIONALITY

REDUCTION ALGORITHM

The DB algorithm (Schclar and Averbuch, 2015) uti-

lizes and preserves non-linear inter-coordinate corre-

lations to reduce the dimensionality of a given dataset

(it is dual to the Diffusion Maps algorithm (Coif-

man and Lafon, 2006; Schclar, 2008; Schclar et al.,

2010)). Since the uniqueness of each signature is

also inherent in its inter-wavelength correlations, the

DB algorithm is highly effective as a pre-processing

Unsupervised Detection of Sub-pixel Objects in Hyper-spectral Images via Diffusion Bases

497

tool for hyper-spectral images (Schclar and Averbuch,

2017b). Speciﬁcally, applying the DB algorithm to

hyper-spectral images reduces their dimensionality

while maintaining the vital spectral information of the

captured scene.

A hyper-spectral image can be represented as in-

dividual monochromatic images - one for each wave-

length. Each image is composed of the reﬂectance

values of the scene at a speciﬁc wavelength range.

The DB algorithm ﬁrst constructs a graph in which

the wavelength images constitute the vertices and the

weights are determined according to a fast decay sim-

ilarity function. Next, it calculates the eigenvectors

of the graph Laplacian. The eigenvectors are sorted

in descending order according to the magnitude of

their eigenvalues and only the eigenvectors whose

eigenvalues are above a given threshold are main-

tained. These eigenvectors capture the non-linear

inter-wavelength variability of the original data. The

selected eigenvectors are used as an orthonormal sys-

tem on which the pixels of the original image are pro-

jected. The projected values constitute the extracted

features.

Although baring some similarity to PCA, this pro-

cess produces better results than PCA due to: (a) its

ability to capture non-linear correlations within the

data by local exploration of each coordinate; and (b)

its robustness to noise. Furthermore, the DB algo-

rithm is more general than PCA and they coincide

when the weights in the graph are determined using

the inner product weight function.

We denote by H =

{

}

i=1

, x

∈ R

the dataset of

the pixels in the hyper-spectral image. Let x

( j) be

the j-th coordinate (the reﬂectance value at the j-th

wavelength) of x

, 1 ≤ j ≤ n. We deﬁne the vector

, (x

( j), . . . , x

( j)) as the j-th coordinate of all

the points in H i.e. the image corresponding to the

j-th wavelength. We denote the set of wavelength im-

ages by





j=1

. (1)

Let w

, x

), be a weight function which measures

the similarity between the points x

and x

in H

. Ide-

ally, w

, x

) → 1 when x

and x

are similar and

, x

) → 0 otherwise, where σ deﬁnes the size of

the local neighborhood of each data point. We denote

by w

the weight matrix that is composed of all pair-

wise similarities in H. A common choice of w

is the

Gaussian, however, other kernels that follow a similar

decay property can be chosen. A detailed discussion

regarding the choice of w

and σ is given in (Schclar

and Averbuch, 2015).

A Markov transition matrix P is constructed by

normalizing the sum of each row in the matrix w

be 1:



, x





, x



d (x

)

, i, j = 1, . . . , n

where d (x

) =

∑

j=1



, x



is the degree of x

Next, the eigen-decomposition of p



, x



is calcu-

lated



, x



≡

∑

k=1









where

{

}

and

{

}

denote the left and the right

eigenvectors of P, respectively, and

{

}

k=1,...,n

are

the eigenvalues of P in descending order of mag-

nitude. We make use of the eigenvalue decay

property of the eigen-decomposition and construct

the orthonormal system containing only the ﬁrst

ν eigenvectors B ,

{

}

k=1,...,ν

. These eigenvec-

tors capture the non-linear directions with the high-

est variability of the coordinates of the original

dataset H. We project the original data H onto

the orthonormal system B. Let H

{

}

i=1

, g

∈

be the set of these projections where g

(

, r

, . . . ,

, r

), i = 1, . . . , m and

·, ·

denotes

the inner product operator. H

is the dimension re-

duced representation of H and the coordinates of each

pixel contain the extracted features. The DB algo-

rithm is summarized in Algorithm 1.

4 THE DB SUB-PIXEL OBJECT

DETECTION ALGORITHM

We introduce a simple and efﬁcient algorithm for the

detection of sub-pixel objects in hyper-spectral im-

ages. First, the algorithm normalizes each wavelength

image so that its values will be in the range [0, 1].

This is necessary since different wavelength sensors

can produce values at different scales. We denote

H =

{

}

i=1

∈ R

the set of normalized wave-

length images. Next, features are extracted from

using the DB algorithm be letting H

H in Algo-

rithm 1. The extracted features capture the required

information for the detection. Let

{

}

i=1

∈ R

be the set of pixels whose coordinates are composed

of the extracted features. We denote by





i=1,...,m

the values of the k-th feature of all the

pixels. We normalize each

to be in [0, 1] and de-

note the the result by





i=1,...,m

. We refer to

as the k-th feature image.

NCTA 2019 - 11th International Conference on Neural Computation Theory and Applications

498

Algorithm 1: The Diffusion Basis algorithm.

Input:

- A dataset where each wavelength image is a data item

- A similarity function

σ - The local neighborhod size of each point

ν - The number of extracted features

Output:

- The reduced dimension representation

=======================

DiffusionBasis(H

, w

, σ, ν)

1. Calculate the weight function w



, x



, i, j = 1, . . . n where x

and x

are the i-th and j-th wavelength images.

2. Construct a Markov transition matrix P by normalizing each row in w

to sum to 1:



, x





, x



d (x

)

where d (x

) =

∑

j=1



, x



3. Perform eigen-decomposition of p



, x





, x



≡

∑

k=1





where the left and the right eigenvectors of P are given by

{

}

and

{

}

, respectively, and

{

}

are the

eigenvalues of P in descending order of magnitude.

4. Project the original data H onto the orthonormal system B ,

{

}

k=1,...,ν

to obtain

{

}

i=1

, g

∈ R

where

= (

, r

, . . . ,

, r

), i = 1, . . . , m, r

∈ B, 1 ≤ k ≤ ν

and

·, ·

is the inner product.

5. return H

The effectiveness of the DB feature extraction al-

lows us to employ a very simple algorithm in order to

detect sub-pixel objects. The algorithm makes use of

the fact the

sub-pixel objects are substantially different from

the hyper-pixels in their local neighborhood. This dif-

ference is apparent in a number of their features and it

is visible when inspecting some of the individual fea-

ture images. This is due to the difference in their cor-

relations with the vectors in the diffusion basis which

stems from the difference between the spectral signa-

ture of the sub-pixel object and the spectral signature

of its neighboring hyper-pixels.

The detection of sub-pixel objects is composed of

the following steps. We deﬁne the α-neighborhood of

to be





i − j

≤ α

where

i − j

denotes the distance between pixel i

and pixel j. Next, we compute the number of pix-

els in α





whose differences from

are above a

given threshold τ

. We denote this number by

∆







−



> τ

∈ α



o



If the size of ∆





is larger than a given threshold

then

is classiﬁed as a sub-pixel object candidate.

determines the number of pixels that are required

to be different from

in its neighborhood, in order

for

to be classiﬁed a sub-pixel object candidate.

Finally, a pixel i is classiﬁed as a sub-pixel ob-

ject if it is a candidate in at least two different feature

images. This ﬁnal requirement prevents the misclas-

siﬁcation of noisy pixels as sub-pixel objects.

5 EXPERIMENTAL RESULTS

In order to simulate sub-pixel objects, twenty four

cardboards were placed in a desert terrain. The color

of the cardboards resembled the color of the sand

in order to make their detection harder using only

Unsupervised Detection of Sub-pixel Objects in Hyper-spectral Images via Diffusion Bases

499

Figure 1: The WAV of a hyper-spectral image of a mountain

terrain which contains 24 sub-pixel objects. The sub-pixel

objects are visually undetectable.

the visible spectrum. A 121 wavelengths 300 × 300

hyper-spectral image of the terrain was taken from a

high altitude airplane. The altitude was determined

according to the camera resolution and the size of the

cardboards so that the cardboards will appear as sub-

pixel objects in the image.

In order to display the geometry (objects, back-

ground, etc.) of the hyper-spectral image we use a

300 × 300 gray image which is derived as the av-

erage of the 121 wavelength images. We refer to

it as the wavelength-averaged-version (WAV) of the

hyper-spectral image.

The similarity function that was used by the

DB algorithm was the Gaussian kernel w

, x

) =

exp



−

−x

2σ



. where σ was chosen according to

the procedure that is described in (Schclar and Aver-

buch, 2015).

The image and the results are given in Fig. 1-4.

Figure 1 shows the WAV of the image. Figures 2 and

3 show the 35

and 50

wavelengths, respectively.

The noise in the image is due to atmospheric condi-

tions at the time the image was taken. These prob-

lems can be found in most of the wavelengths. The

sub-pixel segments are manifested in the image as iso-

lated points. Figure 4 displays the 2

feature image

with squares around the sub-pixel segments that

were found. The number of extracted features was

empirically set to ν = 6. The sub-pixel detection was

obtained using τ

= 0.04, τ

= 3. These values were

found empirically. The algorithm detected all twenty

four sub-pixel objects.

6 FUTURE RESEARCH

The values of ν, τ

and τ

were found empirically.

Naturally, the optimal values for these parameters are

Figure 2: The 35

wavelength of Fig. 1.

Figure 3: The 50

wavelength of Fig. 1.

Figure 4:

of Fig. 1 with squares around the detected

sub-pixel segments. The parameters that were used are: ν =

6,τ

= 0.04, τ

= 3.

data driven (similarly to choosing ε in (Schclar and

Averbuch, 2015)) i.e. they depends on the given

hyper-spectral image .Automatic choice of these pa-

rameter can simplify and accelerate the detection of

sub-pixel objects. A rigorous way for choosing them

is currently being investigated by the authors.

The results in section 5 were obtained using a

Gaussian kernel. However, it is shown in (Coifman

and Lafon, 2006) that any positive semi-deﬁnite ker-

nel may be used for the dimensionality reduction.

Rigorous analysis of families of kernels to facilitate

NCTA 2019 - 11th International Conference on Neural Computation Theory and Applications

500

the derivation of an optimal kernel for a given image

H is currently an open problem that should be inves-

tigated.

REFERENCES

Coifman, R. R. and Lafon, S. (2006). Diffusion maps. Ap-

plied and Computational Harmonic Analysis: special

issue on Diffusion Maps and Wavelets, 21:5–30.

Kwon, H. and Nasrabadi, N. M. (2005). Kernel rx-

algorithm: A nonlinear anomaly detector for hyper-

spectral imagery. IEEE Transactions on Geoscience

and Remote Sensing, 43:388–397.

Ma, N., Peng, Y., Wang, S., and Leong, P. H. W. (2018).

An unsupervised deep hyperspectral anomaly detec-

tor. Sensors, 18(3):693.

Olson, C. C., Judd, K. P., and Nichols, J. M. (2018). Mani-

fold learning techniques for unsupervised anomaly de-

tection. Expert Systems and Applications, 91(C):374–

385.

Reed, I. S. and Yu, X. (1990). Adaptive multiple-band cfar

detection of an optical pattern with unknown spectral

distribution. IEEE Transactions on Acoustics, Speech,

and Signal Processing, 38(10):1760–1770.

Schclar, A. (2008). A Diffusion Framework for Dimension-

ality Reduction, pages 315–325. Springer US, Boston,

MA.

Schclar, A. and Averbuch, A. (2015). Diffusion bases di-

mensionality reduction. In Proceedings of the 7th In-

ternational Joint Conference on Computational Intel-

ligence, IJCCI 2015, Lisbon, Portugal, November 12-

14, 2015., pages 151–156.

Schclar, A. and Averbuch, A. (2017a). A diffusion approach

to unsupervised segmentation of hyper-spectral im-

ages. In Computational Intelligence - 9th Inter-

national Joint Conference, IJCCI 2017 Funchal-

Madeira, Portugal, November 1-3, 2017 Revised Se-

lected Papers, pages 163–178.

Schclar, A. and Averbuch, A. (2017b). Unsupervised

segmentation of hyper-spectral images via diffusion

bases. In Proceedings of the 9th International Joint

Conference on Computational Intelligence, IJCCI

2017, Funchal, Portugal, 1-3 November, 2017., pages

151–156.

Schclar, A., Averbuch, A., Hochman, K., Rabin, N., and

Zheludev, V. (2010). A diffusion framework for de-

tection of moving vehicles. Digital Signal Process-

ing,, 20(1):111–122.

Zhao, C., Wang, Y., Qi, B., and Wang, J. (2015). Global and

local real-time anomaly detectors for hyperspectral re-

mote sensing imagery. Remote Sensing, 7(4):3966–

3985.

Unsupervised Detection of Sub-pixel Objects in Hyper-spectral Images via Diffusion Bases

501
