Multitask Learning or Transfer Learning? Application to Cancer

Detection

Stephen Obonyo and Daniel Ruiru

Faculty of Information Technology, Strathmore University, Ole Sangale Link Road, Nairobi, Kenya

Keywords:

Multitask Learning, Transfer Learning, Deep Learning, Cancer Detection, Medical Imaging.

Abstract:

Multitask Learning (MTL) and Transfer Learning (TL) are two key Machine Learning (ML) approaches which

have been widely adopted to improve model’s performance. In Deep Learning (DL) context, these two learning

methods have contributed to competitive results in various areas of application even if the size of dataset is

relatively small. While MTL involves learning from a key task and other auxiliary tasks simultaneously and

sharing signals among them, TL focuses on the transfer of knowledge from already existing solution within

the same domain. In this paper, we present MTL and TL based models and their application to Invasive Ductal

Carcinoma (IDC) detection. During training, the key learning task in MTL was detection of IDC whereas

skin and brain tumor were auxiliary tasks. On the other hand, the TL-based model was trained on skin cancer

dataset and the learned representations transferred in order to detect IDC. The accuracy difference between

MTL-based model and TL-based model on IDC detection was 8.6% on validation set and 9.37% on training

set. On comparing the loss metric of the same models, a cross entropy of 0.18 and 0.08 was recorded on

validation set and training set respectively.

1 INTRODUCTION

In this study, we seek to investigate the effectiveness

of the application of Transfer Learning (TL) and Mul-

titask Learning (MTL) in Invasive Ductal Carcinoma

(IDC) cancer detection. Multitask Learning can be

deﬁned as a learning method where a model learns by

not only focusing on a single task T but other aux-

iliary tasks T

, T

... T

as well. The signals from

the auxiliary tasks generally improves model’s per-

formance on key task (Ruder, 2017). This characteri-

zation can be attributed to the fact that MTL architec-

ture allows for sharing of informative representations

among the tasks involved. Further, MTL has been

shown to improve the ability of the model to gener-

alize well on unseen instances (Ruder, 2017).

In contrast, Transfer Learning (TL) focuses on the

improvement of a model’s performance via transfer of

knowledge from an already existing solution (source

task) often within the same domain. Given a problem

(target task), the aim of TL is to improve the perfor-

mance by combining source task knowledge represen-

tations and related data (Torrey and Shavlik, 2010).

MTL and TL are somewhat related but the ﬂow of

information between the two is restricted as shown in

Figure 1. In TL, information is unidirectional i.e. the

ﬂow is from source (already learned representations)

to the target (new problem). On the other hand, in

MTL the information ﬂow is unrestricted and infor-

mation can ﬂow in any direction (among all the task

related models). This behaviour is captured by Figure

Figure 1: Multitask Learning vs Transfer learning. Source

(Torrey and Shavlik, 2010).

This research compares the application of both

MTL and TL to cancer detection. The tasks which

were involved include detection of i) Invasive Duc-

tal Carcinoma (a common sub-type of breast cancer),

ii) skin cancer and iii) brain tumour. Based on these

tasks both MTL-based and TL-based models were de-

veloped and their performance compared.

The key learning task for MTL-based model was

IDC detection. Skin and brain cancer detection were

auxiliary tasks. The TL-based model was developed

by ﬁrst training the base network to detect the skin

548

Obonyo, S. and Ruiru, D.

Multitask Learning or Transfer Learning? Application to Cancer Detection.

DOI: 10.5220/0008495805480555

In Proceedings of the 11th International Joint Conference on Computational Intelligence (IJCCI 2019), pages 548-555

ISBN: 978-989-758-384-1

cancer. The learned representations from the model

were transferred and used to detect IDC. The outcome

of these two learning methodologies were presented

and discussed on the results and discussion sections

of this document.

Cancer research is likely to beneﬁt from both

MTL and TL learning approaches since they hold

the potential towards developing robust models, even

when relatively smaller datasets are available. This

has translated to a development of stable models with

an ability to generalize well on unseen examples.

2 RELATED WORK

2.1 Machine Learning in Cancer

Medical Imaging

Cancer is by far the most adaptive and self-sustaining

conditions currently known within the medical ﬁeld.

It dynamically interacts with its micro-environments

to constantly thwart the efforts of practitioners, re-

searchers and most importantly the affected patients.

Various complexities associated with the disease

results in endless dilemmas at the different stages of

its management, including the need for reliable early

detection (Bi et al., 2019). Moreover, there are the

problems associated with the accurate identiﬁcation

of preneoplastic and neoplastic lesions; the tracking

of tumors; resistance to treatment; and the regulation

of inﬁltrative tumor margins in surgical procedures

etc. However, technological advances particularly in

medical imaging and the identiﬁcation of bio-markers

hold great promise in addressing these challenges.

Machine Learning and its sub-branches have the

ability to automate image analysis and this could

potentially bridge the gap between cancer medical

imaging and the accurate interpretation of conditions

(Klang, 2018). Currently, there is disparity in manual

cancer diagnosis. This hinders the treatment and the

probable recovery of patients. These conventional or

manual method of image evaluation rely heavily on

the qualitative features of tumor cells such as density,

pattern, cellular composition and anatomic relation-

ship, among others. These features are hard to accu-

rately determine due to the varying image dimensions.

In comparison, there exist radiomics which use

quantitative features to analyze radiographic images.

Broadly, radiomics uses the quantitative features of

size, shape and textual patterns to describe medical

images, which are better representations of tasks in

ML (Bi et al., 2019). These types of descriptors

could thus facilitate the role of Artiﬁcial Intelligence

in medicine as the ﬁeld has made great strides in au-

tomating the quantiﬁcation of medical patterns. Deep

learning in particular has the most promise having

developed various models for learning and match-

ing features in different problems. The ability of the

implemented algorithms even surpasses those of hu-

man expert which further deﬁnes their signiﬁcance in

task-speciﬁc functions as they can be specialized as

needed. Moreover, they are able to overcome the bar-

riers of large data sets including the ability to with-

stand noise in foundation truth tables. In all, the ca-

pabilities of deep learning could provide exceptional

insights into both qualitative and quantitative analy-

sis further helping medical evaluations. This facili-

tation could for instance be achieved by the precise

delineation of tumors, parallel tracking of lesions and

the cross-referencing of tumors in related ﬁelds. Ul-

timately, deep learning methods promise the greatest

generalization capabilities through the transfer of in-

sights across various medical domains. It is these ben-

eﬁts among others that could provide the health care

industry with the necessary tools for future break-

throughs.

2.2 Transfer Learning

The idea of generalizing models is an important ele-

ment of transfer learning which in recent times has in-

creased the popularity of the technique. Like in many

other domains, transfer learning in medical imaging

aims to transfer information from a particular clas-

siﬁcation problem(s) (source) to another (the target),

hence improve the performance of the ﬁnal classiﬁer.

In cancer treatments, this facilitation is important as

the ﬁeld has minimal data owing to the expenses in-

volved and the few breakthroughs seen so far.

2.2.1 Transfer Learning Approaches

Despite the progress made in transfer learning there

exist a lot of inconsistencies in the classiﬁcation of

its sub-branches. Traditionally, the categorization has

been done using three main groups which are based

on the similarities between domains and the availabil-

ity of labeled/unlabeled data. Inductive, transductive

and unsupervised transfer learning have thus been the

three main categories. However, advances in deep

learning have increased the scope of TL and today

have led to a more ﬂexible taxonomy having two main

categories (Asgarian, 2019). This new taxonomy is

based on the similarity of domains and has two major

groupings: Homogenous transfer learning and het-

erogeneous transfer learning.

Multitask Learning or Transfer Learning? Application to Cancer Detection

549

2.2.2 Homogeneous and Heterogeneous

In homogenous TL, both the source and target tasks

have the same feature and label space. As such, the

aim is usually to bridge the gap of data distribution

that exist in the two instances (source and target). The

somewhat reverse outcome is exhibited by heteroge-

neous TL as the source and target tasks have different

feature spaces (non-overlapping). However, for the

label space, a unique set up exists where the source

and target domains can either share or have different

data labels. From these broad classiﬁcations of TL,

the solutions offered by the technique can be summa-

rized into ﬁve different classes as outlined below.

1. Instance-based Approaches: Tries to re-weight

samples in source tasks to correct marginal dis-

tribution differences. These re-weight instances

are then directly applied in target domains during

training

2. Feature-based Approaches: Are applied in both

homogeneous and heterogeneous problems where

in the latter setup they aim to reduce the differ-

ences in feature spaces. In homogeneous prob-

lems they are then used to correct the marginal

and conditional distributions

3. Parameter-based Approaches: These approaches

transfer knowledge using the shared parameters of

the domains involved

4. Hybrid-based Approaches: These techniques

transfer knowledge through both the instances and

parameters shared by the tasks involved

5. Relational-based Approaches: These ﬁnal ap-

proaches use the common relationships between

the source and target domains to transfer knowl-

edge (Asgarian, 2019).

2.2.3 Empirical Results

Motivated by the current trends in deep learning, ma-

chine learning researchers have moved to develop al-

gorithms that automatically classify cancer medical

images. In particular, there has been a great empha-

sis on the transfer of features from pre-trained models

due to the limited datasets (training corpus) found in

the cancer domain. This borrowing of factors, bet-

ter known as transfer learning has yielded better clas-

siﬁcation results and even helped generalize models.

Take the example of transfer learning in the early gas-

tric cancer classiﬁcation as done by Liu et al. (2018).

Using Magnifying Narrow-Band Imaging Images (M-

NBI), this group of researchers were able to attain

higher prediction accuracy with TL as compared to

traditional ML methods. On average, a 96 percent

accuracy was achieved, a value that on occasion im-

proved by either ﬁne tuning the ﬁnal layers or all the

layers of the applied model (Convolutional neural net-

works (CNN)). To further test the credibility of the

result, different variations of CNN were used namely;

VGG-16, InceptionResNet-v2 and Inception-v3. Ul-

timately, the research conducted found that the per-

formance gain increased as the convolutional layers

were ﬁne-tuned with natural data (Liu et al., 2018).

Furthermore, the amount of the input data (images)

inﬂuenced the ﬁnal result of the deep learning models.

Since, the ﬁeld in question has limited data (cancer

and more speciﬁcally M-NBI), transfer learning pro-

vided the means to meet this functional requirements

and hence improved the models’ performance.

2.2.4 Theoretical Framework

TL is common in deep learning owing to the amount

of data needed to train models. Deep learning models

require lots of data to make any meaningful predic-

tions which often is not available. TL therefore works

because it enables networks to use features learned

in previous tasks by mixing and matching their func-

tions into new as well as meaningful combinations. It

is the new collaboration that helps improve the classi-

ﬁcation of a model. This outcome is observed in both

theory and practice as models converge faster and are

more accurate with TL as compared to when they

are randomly initialized. Therefore, TL not only im-

proves prediction results but also helps to train models

faster.

Its mathematical representation highlights its the-

oretical background. Deﬁning a domain D as a two el-

ement tuple consisting of a feature space x and prob-

ability P(X) (while space x = a sample data point),

then Domain D can be deﬁned as

D = x,P(X). (1)

Note: In probability

P(X), X = x

,. . . . . . . . . . . . , x

(2)

i.e.

εX (3)

Additionally, if X

is a speciﬁc vector. A task

T can be accurately deﬁned by corresponding tuples

of y as label space and n as the objective function.

Therefore, for the given domain (D), Task T can be

represented as

T = y,P(Y |X) = y, nY = y

,. . . . . . .,y

εY (4)

NCTA 2019 - 11th International Conference on Neural Computation Theory and Applications

550

2.3 Multitask Learning

Deep learning models use a combination of many hid-

den layers and parameters in their learning process to

give results. As such, they require lots of data. Can-

cer like many other medical ﬁelds does not meet this

data requirement more so, because it applies manual

labor to label data instances (Zhang and Yang, 2017).

It is therefore, a perfect case for applying multitask

learning (MTL) where useful information from mul-

tiple relevant tasks are used to alleviate the problem of

data sparsity. MTL has been a promising ﬁeld in ma-

chine learning since its initial formulation by Caruana

(1997). Broadly, the goal of MTL is to leverage use-

ful data/information found in multiple learning tasks

to get more accurate learners. Of course, this ob-

jective assumes that the tasks (or their subsets) are

related. Empirically and theoretically, jointly learn-

ing various tasks has been found to give better per-

formances than when learning is done independently.

Moreover, based on the tasks, MTL can take differ-

ent setup which outlines its effective classiﬁcation as:

MTL supervised learning, MTL unsupervised learn-

ing, MTL semi-supervised learning and MTL online

learning among others.

MTL helps to promote the notion that machines

can mimic human learning activities as people trans-

fer knowledge from different tasks to further others.

For instance, the skills of long jump and, running

track and ﬁeld can facilitate each other, hence im-

prove the performance of an athlete. Thus, MTL is

simply an inductive transfer mechanism that aims to

improve the generalization of machine learning mod-

els (Caruana, 1997). A concept (generalization) that

it fulﬁlls by leveraging domain-speciﬁc data from re-

lated activities through parallel training. Therefore,

the training power of the additional tasks acts as an in-

ductive bias. In this case, an inductive bias hails from

its general deﬁnition which is anything that inﬂuences

an inductive learner to prefer certain hypotheses as

compared to others.

2.3.1 Empirical Studies

Most of observation studies of MTL have focused

on feature selection problems where some attributes

in multi-source data have been used in classiﬁcation

of regression experiments. In most cases, the fea-

tures in question have been related even though they

are derived from different data sources. Based on

these underlying relations, it has been found to be

easier to jointly select the necessary attributes (fea-

tures) from various sources using joint selection reg-

ularizers. These regularizers, which are simply select

constraints, have been found to improve the perfor-

mance of classiﬁcation models as compared to other

conventional techniques that evaluate features indi-

vidually based on their data sources. Examples of

regularizers commonly introduced include joint spar-

sity, graph sparse coding, graph self-representation

and low rank. It is the inclusion of these elements that

has helped MTL deal with complex worldly problems

such as the diagnosis of neurodegenerative diseases

(Bib, 2019). Using structural Magnetic Resonance

Imaging (sMRI), researchers have been able to pre-

dict the values of various types of clinical scores in

these conditions, including their speciﬁc subject di-

agnostic labels. An example of this success is high-

lighted by the study of Alzheimer disease (AD) where

clinical scores such as Mini-Mental State Examina-

tion (MMSE) and Dementia Rating Scale (DRS) have

been used to grade the healthiness (functionality) of

the brain.

As speciﬁed by MTL principles, the classiﬁcation

in this instance is based on the prediction of a target

output. Because the target outputs, such as diagnos-

tic labels and clinical score, are related then one gets

better results unlike when each task is learned inde-

pendently. It is this ’similar’ approach that has led

to the recent success of self-driving automation sys-

tems. In this case, images from cameras attached to

subjects are used to detect objects (road signs, trafﬁc

lights etc.) which are then fed into neural networks to

train a model for autonomous driving. A more robust

system is acquired because the model gets to learn

multiple objects simultaneously.

2.3.2 Multitask Learning Approaches

From the discussion above, MTL is simply a type

of inductive transfer which improves algorithms by

adding an inductive bias. This bias helps a model dis-

criminate some attributes and thus, prefer some hy-

potheses over others. `

regularization is the most

common type of inductive bias known in ML and is

often used to get preferences for various sparse so-

lutions. In contrast, MTL attains its inductive bias

through auxiliary tasks which through their contri-

butions models certain hypotheses inclinations. To

achieve its goals, MTL commonly employs two con-

trasting ways in deep neural networks. They are; hard

and soft parameter sharing (Ruder, 2017) The shared

element comes from segmentation (sharing) of hidden

layers.

1. Hard Parameter Sharing: Its application in neu-

ral networks goes back to Caruana (1997). It

shares the hidden layers between all tasks in-

volved but also maintains a few task-speciﬁc out-

put layers. Because of its efﬁciency and simplicity

Multitask Learning or Transfer Learning? Application to Cancer Detection

551

it is the most common approach of MTL. It also

reduces the risks of over-ﬁtting, a result that stems

from the ability to develop a model that represents

all tasks and not just the original concept (task).

2. Soft Parameter Sharing: On the other hand, this

approach sees each task having its own model plus

their own set of parameters. To encourage a sim-

ilarity between the distinct parameters, the dis-

tance between them in the overall model is regu-

larized using a bias function say `

. This applica-

tion of inductive bias functions, explains the huge

inspiration that regularization techniques have had

on the constraints of soft parameter sharing, an

outcome that still stands today.

2.3.3 Empirical Results

As highlighted before, MTL helps with the simulta-

neous solving of multiple tasks by optimizing several

loss functions instead of one. It is this application that

has seen it applied in several ﬁelds such as cancer di-

agnostics. Khosravan and Bagci (2018) speciﬁcally

applied the technique in lung cancer and eventually

were able to overcome their limitations of labeled data

for task segmentation.

Having the highest mortality rate among cancer

afﬁliated deaths, lung cancer has invoked a lot of re-

search in attempts to yield conclusive results. This

interest has produced many systems and models but

they all seem to suffer from the same problem of

false positive results. Additionally, the limitations of

data segmentation (initial step of data quantiﬁcation)

lower the performance of the developed model. Khos-

ravan and Bagci (2018) improved on this available

models by incorporating MTL into their 3D encoder-

decoder CNN structure. In doing so, they shared un-

derlying features of tasks and trained single models

using shared features that are essential in lung can-

cer screening. Eventually, the ﬁnding of their study

saw the importance of MTL in semi-supervised learn-

ing where improved results are obtained even with-

out large data sets. Essentially, minimal labeled data

is needed when features are shared between tasks as

they get to learn from one another. Moreover, the ﬁ-

nal model was easily generalized not accounting for

the reduced false positive result.

2.3.4 Theoretical Framework

Most learning algorithms will perform poorly when

faced with tasks having minimal data labels as well

as high dimensional space. This is a familiar outcome

in medical image analysis as seen before. MTL works

in such instances by sharing attributes and features be-

tween tasks. Caruana (1997) best summarized the im-

portance of MTL by highlighting it as technique that

simultaneously learns tasks (parallel learning) while

sharing low dimensional representations (Bib, 2019).

Thus, a common assumption that is held by MTL is

that tasks or their subsets, associate with each other

and share information. This collaboration facilitates

a joint learning process that also compares functions

eventually producing optimal independent models.

This idea of jointly learning problems can be for-

mulated as shown below. Taking N as the number of

supervised tasks. The training set for each and every

task can be denoted as T

= (x

n, y

n). Where I = 1: k

(kn being the number of training samples for all the

tasks).

Because x

n is an element in the set of X(n) i.e.

n part of X(n) and, y

n part of Y (n). Then the overall

problem of multitask learning can be summarized to

an optimization problem as deﬁned below:

min

∑

n=1

L(Y

(n)

, f (X

(n)

+ λ k f k) (5)

L is the loss function that measures the pre-task pre-

diction error, while f is the actual multitask model. W

on the other hand is the algorithm’s parameter set.

3 DATASET & PREPROCESSING

3.1 Dataset

Different types of datasets were used in this study.

The First dataset was Invasive Ductal Carcinoma

(IDC). It was composed of 198,738 negative samples

and 78,786 positive samples. IDC is one of the most

prevalent of breast cancer sub-type.

The second dataset was skin cancer with a total of

3297 training samples. Out of this 1497 were benign

while the remaining 1800 were malignant. The third

dataset, brain MRI, was relatively smaller in compari-

son to the ﬁrst and the second one. It was composed of

155 brain MRI images that are tumorous and 98 brain

MRI images that are non-tumorous. All the datasets

used in this study were obtained from various compe-

titions listed on Kaggle.

The skin, brain tumor and IDC datasets were

used in building MTL-based and TL-based models.

Succinctly, the key learning task for the MTL-based

model was detection of IDC and the corresponding

dataset was used. The same applied to the auxiliary

tasks: detection of skin and brain cancer.

Skin dataset was again used in building the TL-

based model. It was used to train the base model.

The learned representations from the base model were

NCTA 2019 - 11th International Conference on Neural Computation Theory and Applications

552

transferred and used to train a new model to detect

IDC.

3.2 Preprocessing

All the images in this study were resized to 32x32x3.

This was based on the fact that most of the tumor cells

usually occupies a very small segment given a sample

image. Apart from resizing the images, other image

preprocessing techniques applied during training in-

cluded: i) Random cropping with a padding (4), ii)

Random Horizontal Flip, iii) Random Rotation and

iv) Normalization with a mean and standard deviation

of 0.5.

4 MODEL ARCHITECTURE &

TRAINING

Two sets of models were built in this study; Multitask

Learning (MTL) and Transfer Learning (TL) based

models. These two models had a similar goal: IDC

detection.

The MTL-based model was inspired by the clas-

sical research done by Caruana (1997). The model

was built with IDC detection as the main task and

skin and brain cancer as auxiliary tasks. TL-based

model on the other hand, was built by ﬁrst training

a model to detect skin cancer then the learned repre-

sentations were transferred to a new model which was

further trained (with additional layers) to detect IDC.

MTL and TL-based model’s base architecture were

designed based on ResNext network model.

ResNext, a deep neural network architecture, was

inspired by another network model called ResNet.

The ResNet network design is a deep learning model

which overcame the challenges associated with train-

ing very deep neural networks. Based on its design,

the output of successive layers is concatenated with

the original input then fed to the next layer and the

same process repeated while going deeper into the

network (He et al., 2016). This design behaviour

proved effective in training a neural network with over

a hundred and even a thousand layers. Figure 2 shows

a ResNet block.

ResNeXt leverages on a split-transform-merge

strategy where branched paths are used within cells.

Instead of performing convolutions on the full input

feature map, the input block is projected over a se-

ries of lower dimensional representations which sep-

arately apply a few convolutional ﬁlters before merg-

ing them into the ﬁnal result (Xie et al., 2017). Fig-

ure 3 captures the key difference between ResNet and

ResNext Architecture.

Figure 2: ResNet Block Source He et al. (2016).

Figure 3: ResNet Vs ResNext Source Xie et al. (2017).

4.1 MTL-based Model

MTL-based model was designed to learn to detect

IDC (key task), brain tumour and skin cancer (auxil-

iary tasks). The aforementioned tasks shared common

base representations (parameters) with each having a

unique last layer composed of a Fully Connected (FC)

Layer. The MTL parameter sharing technique used in

this context was hard parameter.

Figure 4 is a diagrammatic illustration of the

MTL-based model. It is composed of two major parts:

i) the base and ii) head. The base sub-section is com-

Figure 4: MTL-based Model.

posed ResNext architecture (depth: 29, cardinality: 8,

base width: 64 , widening factor: 4) shared by all the

tasks. The head part on the other hand is composed

of three different fully connected (FC) layers: FC0,

FC1 and FC2, each representing IDC, skin, brain de-

tection model respectively. All the FC layers shares

a common base while focusing on different tasks. In

essence the learning signals from skin, IDC and brain

affects the base weights as the head focuses on a more

speciﬁc tasks. The model design was inﬂuenced by

the question, Can learning from different tasks im-

prove model’s performance? which is theoretically

and empirically underlined by Caruana (1997).

Multitask Learning or Transfer Learning? Application to Cancer Detection

553

4.2 TL-based Model

The second model which was designed in this study

is TL-based model. In contrast to the ﬁrst model

(MTL-based), it was ﬁrst trained to detect skin cancer.

The learned representations were then transferred and

used to train a new model-with additional layers. The

new model was ﬁne-tuned to detect IDC by adding the

following layers: i) two FC’s, ii) RELU , iii) Dropout

and iv) Batch Norm. Figure 5 shows the high level

architecture of the TL-based model. Similar to the

Figure 5: TL-based Model.

MTL-based model architecture, the TL’s base model

(where knowledge is transferred from) is made up of

ResNext architecture as well. The key difference is

that MTL-based model is focused on multiple tasks

while TL-based model simply reuses to source knowl-

edge to enhance the new model’s performance.

4.3 Training

The models were trained for 40 epochs. Their learn-

ing rates were varied over time (signiﬁcantly lowered

as the loss gradually decreases) on the range between

0.0001 - 0.01. All the experiments were carried out

using PyTorch version 1.0 hosted on AWS’s p2.xlarge

GPU machine. Vanilla Stochastic Gradient Descent

with momentum of 0.9 was used as the optimization

algorithm for the two models.

5 RESULTS

MTL-based model was trained to detect brain tu-

mor, skin and IDC. The model’s key task was detec-

tion of IDC whereas skin and brain tumor detection

were auxiliary tasks. Skin, brain and IDC sub-models

shared common base but different last layers as de-

picted in Figure 4. Table 1 shows the result summary

of the MTL-based model performance.

The TL-based model on the other was ﬁrst trained

on skin cancer dataset and the knowledge representa-

tions transferred (as a base model) to a new model.

The latter was ﬁne-tuned by adding two Fully Con-

nected Layers (FC’s), RELU, Dropout and Batch

Norm. Table 2 summarizes the results of the TL-

based model.

6 DISCUSSION

Multitask Learning (MTL) and Transfer Learning

(TL) are key learning methods which have been

widely adopted to enhance model’s performance. In

this study, we designed MTL-based model and TL-

based model and compared their results in detection

of IDC. The results of the two models were tabulated

in Table 1 and Table 2 respectively.

From Table 1, the MTL-based model on IDC de-

tection recorded cross entropy training loss of 0.26,

validation loss: 0.6, validation accuracy:75.99, and

training accuracy of 88.50. Comparatively, the TL-

based model recorded a cross entropy training loss of

0.43, validation loss of 0.51, validation accuracy of

67.38 and training accuracy of 79.12. Moreover, the

results of auxiliary tasks (skin and brain tumor) can

be read from Table 1. In addition, the performance of

base model used to transfer knowledge to TL-based

model can also be read from Table 2.

Based on the results, the accuracy difference be-

tween MTL-based model and TL-based model on

IDC detection was 8.6 on validation set and 9.37 on

the training set. On comparing the loss metric of the

same models, a cross entropy of 0.18 was recorded on

validation set and 0.08 on the training set. Consider-

ing the accuracy of the two models’ on IDC detection,

MTL-based model performed was better as compared

to the TL-based model.

Even though the results follow logically from

the theoretical and empirical foundation presented

by Caruana (1997) and Ruder (2017), more experi-

ments need to be conducted to absolutely conclude

that MTL-based models are generally better than TL-

based models in the context of cancer detection. This

is based on the fact that ﬁrst: there are other cancer

classes which were not considered in this study. Two,

TL-based model has the potent to yield the quite com-

petitive results (as shown in Table 2). Lastly, the skin

dataset and brain MRI dataset used in this study was

relatively small as compared to datasets which might

be available for other cancer classes.

7 CONCLUSION

In this paper, we investigated how MTL and TL based

models performance compare when applied to the

IDC detection. Following the obtained results, MTL-

based model recorded a better performance. TL-

based model yielded relatively competitive results.

Even though the outcome of this research coin-

cided with the theoretical and empirical underpin-

nings of other studies, there is still the need to con-

NCTA 2019 - 11th International Conference on Neural Computation Theory and Applications

554

Table 1: MTL-based Model Results.

Model Skin Brain IDC

Training Loss 0.27 0.6 0.26

Validation Loss 0.48 0.9 0.6

Validation Accuracy 75.92 62.5 75.99

Training Accuracy 86.90 60.7 88.50

Table 2: TL-based Model Results.

Model Base Model (on skin dataset) IDC

Training Loss 0.19 0.43

Validation Loss 0.17 0.51

Validation Accuracy 81.12 67.38

Training Accuracy 93.77 79.12

duct more experiments with different types of cancer

on much larger datasets. This would allow drawing

more general conclusions about the performance of

MTL-based and TL-based models in the context of

cancer research.

8 FUTURE WORK

Following the obtained results, MTL-based model

yielded much better outcome compared to TL-based.

In future work, we seek to research on the mod-

els’ performance based other cancer sub-types and on

much larger datasets. This would allow drawing con-

clusive remarks on TL-based or MTL-based model

performance in the context of cancer research.

REFERENCES

(2019). (1) (PDF) A brief review on multi-task learning.

[Online; accessed 10. Jul. 2019].

Asgarian, A. (2019). Transfer Learning—part 1. Medium.

Bi, W. L., Hosny, A., Schabath, M. B., Giger, M. L., Birk-

bak, N. J., Mehrtash, A., Allison, T., Arnaout, O.,

Abbosh, C., Dunn, I. F., et al. (2019). Artiﬁcial in-

telligence in cancer imaging: clinical challenges and

applications. CA: a cancer journal for clinicians,

69(2):127–157.

Caruana, R. (1997). Multitask learning. Machine learning,

28(1):41–75.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In Proceedings of

the IEEE conference on computer vision and pattern

recognition, pages 770–778.

Khosravan, N. and Bagci, U. (2018). Semi-supervised

multi-task learning for lung cancer diagnosis. In 2018

40th Annual International Conference of the IEEE En-

gineering in Medicine and Biology Society (EMBC),

pages 710–713. IEEE.

Klang, E. (2018). Deep learning and medical imaging.

Journal of thoracic disease, 10(3):1325.

Liu, X., Wang, C., Hu, Y., Zeng, Z., Bai, J., and Liao, G.

(2018). Transfer learning with convolutional neural

network for early gastric cancer classiﬁcation on mag-

niﬁying narrow-band imaging images. In 2018 25th

IEEE International Conference on Image Processing

(ICIP), pages 1388–1392. IEEE.

Ruder, S. (2017). An overview of multi-task learn-

ing in deep neural networks. arXiv preprint

arXiv:1706.05098.

Torrey, L. and Shavlik, J. (2010). Transfer learning. In

Handbook of research on machine learning appli-

cations and trends: algorithms, methods, and tech-

niques, pages 242–264. IGI Global.

Xie, S., Girshick, R., Doll

ar, P., Tu, Z., and He, K. (2017).

Aggregated residual transformations for deep neural

networks. In Proceedings of the IEEE conference on

computer vision and pattern recognition, pages 1492–

1500.

Zhang, Y. and Yang, Q. (2017). An overview of multi-task

learning. National Science Review, 5(1):30–43.

Multitask Learning or Transfer Learning? Application to Cancer Detection

555
