Improving the Accuracy of Features Weighted k-Nearest Neighbor

using Distance Weight

K. U. Syaliman

, Ause Labellapansa

, Ana Yulianti

Department of Informatics, Politeknik Caltex Riau, Pekanbaru, Indonesia

Department of Informatics, Universitas Islam Riau, Pekanbaru, Indonesia

Keywords:

Accuracy, Distance Weight, FWk-NN, K-NN, Vote Majority

Abstract:

FWk-NN is an improvement of k-NN, where FWk-NN gives weight to each data feature thereby reducing the

inﬂuence of features that are less relevant to the target. Feature weighting is proven to be able to improve

the accuracy of k-NN. However, the FWK-NN still uses the majority vote system for class determination

to new data. Whereby the majority vote system is considered to have several weaknesses, it ignores the

similarity between data and the possibility of a double majority class. To overcome the issue of vote majority

at FWk-NN, the research will change the voting majority by using distance weight. This study uses a dataset

obtained from the UCI repository and a water quality data set. The data used from the UCI repository are iris,

ionosphere, hayes-Roth, and glass. Based on the tests carried out using UCI repository dataset it is proven that

FWk-NN using distance weight has averaged an increase about2%, with the highest increase of accuracy of

4.23% in the glass dataset. In water quality data, FWk-NN using distance weight can achieve an accuracy of

92.58% or has increased 2% from FWk-NN. From all the data tested, it is proven that the distance weight is

able to increase the accuracy of the FWk-NN with an average increase about 1.9%.

1 INTRODUCTION

k-Nearest Neighbor or commonly known as kNN is

one of the popular classiﬁcation methods for dealing

with problems in the ﬁeld of mining data, including

text categorization, pattern recognition, classiﬁcation,

etc (Bhatia and Vandana, 2010; Jabbar et al., 2013;

Rui-Jia and Xing, 2014; S

anchez et al., 2016; Zheng

et al., 2017). This is because kNN has advantages

including simple methods, quite interesting, easy to

implement, intuitive, can be exploited in various

domains, and is quite efﬁcient (Wang et al., 2007;

Garca-Pedrajas and Ortiz-Boyer, 2009; Ougiaroglou

and Evangelidis, 2012; Feng et al., 2016; Pan et al.,

2017; S

anchez et al., 2016; Song et al., 2017).

kNN still has weaknesses that make the results

of accuracy remain relatively low, even more so

when compared with other classiﬁcation algorithms.

(Danades et al., 2016; Tamatjita and Mahasta, 2016).

The low accuracy value of kNN is caused by several

factors. One of them is because each feature

has the same effect on determining the similarity

between data. The solution is to give weight to

each data feature or commonly called Feature Weight

k-NN (Kuhkan, 2016; Duneja and Puyalnithi, 2017;

Nababan et al., 2018).

FWk-NN is proven to improve the accuracy of

the kNN method. It can be seen in the research

conducted by Duneja (2017) and Nababan, et al

(2018) which gives weights for each data feature

using the Gain Ratio. In determining the class for

new data, FWk-NN still adopts the votes system,

where the majority vote system ignores the similarity

between data, and another problem is the possible

emergence of a double majority class(Gou and Xiong,

2011; Yan et al., 2015; Syaliman et al., 2017).

The solution to the majority vote system problem

has been done by Mitani et al. (2006) . In this

research, it was proposed to make a method change

in class determination for new data, initially used the

voting majority to be exchanged using local mean,

so the class for new data is no longer based on

the majority class, but is determined based on the

similarity of the local mean vector.The results of this

research proved that the local mean was able to reduce

misclassiﬁcation caused by the vote majority system.

Another solution to overcome the weaknesses

in the vote majority system is to use the method

proposed by Batista & Silva (2009). In this research

it is recommended to use a distance weight while to

326

Syaliman, K., Labellapansa, A. and Yulianti, A.

Improving the Accuracy of Features Weighted k-Nearest Neighbor using Distance Weight.

DOI: 10.5220/0009390903260330

In Proceedings of the Second International Conference on Science, Engineering and Technology (ICoSET 2019), pages 326-330

ISBN: 978-989-758-463-3

determine the new data class is based on the weight

of the distance between the data, it has proved that

it is able to overcome the problem in the majority

vote system which ignored the similarity between

data (Gou and Xiong, 2011; Syaliman et al., 2017).

Based on previous studies, the authors see that the

accuracy of the FWk-NN method can be improved,

where to improve the accuracy of FWk-NN, in this

research the author will replace the vote majority

system with a distance weight system. It is expected

that using distance weight is able to increase the

results of the classiﬁcation.

2 FEATURE WEIGHTED K-NN

(FWK-NN)

FWk-NN is a method developed to overcome

problems in kNN that are sensitive to distance

functions because of the sensitivity inherent in

irrelevant features. FWk-NN is based on feature

weighting (Chen and Hao, 2017).The details of the

FWk-NN algorithm are as follows :

Step 1: Compute the weight of each feature using the

Gain Ratio. (Duneja and Puyalnithi, 2017;

Nababan et al., 2018).

Step 2: Determine the value of k, k is the number of

nearest neighbor (Syaliman and A., 2015).

Step 3: Compute distance using equations :

D(x − y) =

∑

i=1

f w

× (x

− y

)

(1)

where D(x − y) is the euclidean distance from x and

y, f is the number of features, f w is the weight of the

features.

Step 4: Sort the distance between data from the

smallest to the largest (ascending) depend on

the number of k.

Step 5: Compute the number of each class based on

the nearest neighbor k.

Step 6: Make the majority class a new data class.

FWk-NN gives each feature a different weight,

where features that have a greater inﬂuence on the

class will be given a feature weight greater than the

weight of other features. Thus the less relevant weight

can be reduced by its inﬂuence (Kuhkan, 2016).

3 DISTANCE WEIGHTED K-NN

(DWK-NN)

DWk-NN is also one of the improvements of

k-NN.Improve to the DWk-NN were carried out

to overcome the problem of the vote majority

system from k-NN (Lidya et al., 2015).In k-NN,

each nearest neighbor has the same inﬂuence in

class determination for new data, this is considered

irrational when viewed based on the similarity

between data (Pan et al., 2016). The details of the

FWk-NN algorithm are as follows:

Step 1: Determine the value of k

Step 2: Compute distance using equations :

D(x − y) = (

∑

i=1

− y

)

(2)

D(x − y) is the distance between x and y, f is the

number of features, r is lambda value (a positive

integer). r = 1 is known as Manhattan / City Block

distance, r = 2 is known as Euclidean distance and if

r = inﬁnity is known as Chebyshev distance (Merig

and Casanovas, 2008; Labellapansa et al., 2016;

Koteswara Rao, 2012).

Step 3: Sort the distance between data from the

smallest to the largest (ascending) depend on

the number of k

Step 4: Compute the weight of the distance between

data using equation (Batista and Silva, 2009):

dw =

d(x, y)

(3)

Step 5: Compute the average weights each data

class based on closest k neighbors using the

equation (4).

sum w

∑

i=1

, (c = c

) (4)

Step 6: Select the class with the highest average

weight value, then make it as a class for new

data.

The workﬂow of DWk-NN is quite similar to

k-NN. In K-NN class determination is based on

majority vote while in DWk-NN uses the highest

number of average distance weight values between

data.

4 PROPOSE METHOD

To further described the changes made to FWk-NN

using the distance weight will explain step by step in

this sub-chapter. The stages are in ﬁgure 1.

Improving the Accuracy of Features Weighted k-Nearest Neighbor using Distance Weight

327

Figure 1: Proposed Method

From ﬁgure 1, the modiﬁed Feature Weight

K-Nearest Neighbor (FWk-NN) and Distance Weight

have several stages,which are :

Step 1: Compute inﬂuence of features by using Gain

Ratio

Step 2: Compute the weight based on the gain ratio

using equation (5)

f w

− Min(G))

Max(G) − Min(G)

× 1 (5)

where f w

is features weight-i, G

is Gain Ratio-i,

Min(G) is the minimum gain ratio, and Max(G) is

the maximum gain ratio.

Step 3: Determine the value of k

Step 4: Compute distance using equations (1).

Step 5: Sort the distance between data from the

smallest to the largest (ascending) based on

the number of k

Step 6: Compute the weight of the distance between

data sorted by equation(3).

Step 7: Calculate the average weight for each

class based on the nearest neighbor kusing

equation(4).

Step 8: Select the class with the highest average

weight value, then make it as a class for new

data.

Step 1 to 5 is the contribution from FWk-NN,

while step 6 to step 8 are the steps of the distance

weight to determine the class for new data.

5 RESULT AND DISCUSSION

This research uses several datasets from the UCI

Machine Learning repository, such as ionosphere,

Haberman, hayes, glass, and iris. In addition, the

proposed method is also tested using real data from

a water quality status of Indonesia (Danades et al.,

2016). The detail of the data can be seen in table 1.

Table 1: Detail of Data

Data Features Class Total Data

Ionosphere 34 2 351

Iris 4 3 150

Hayes 4 3 160

Glass 10 6 214

Water Quality Status 8 4 120

In this study used 10-fold cross-validation, and the

value of k is only worth 1 to 10. The average accuracy

of each data can be seen in ﬁgure 2.

Figure 2: Accuracy from Dataset

Based on ﬁgure 2,the proposed method or

FWk-NN using distance weight has higher accuracy

than FWk-NN, where the highest improved of

accuracy obtained in Glass dataset is worth 4.23%,

and the lowest improved of accuracy obtained in the

iris dataset of 0.4%. From all dataset, the accuracy

increase is 2%.

Based on the testing by using the dataset from UCI

was knowing, the proposed method is better than the

original FWk-NN. To know with certainty whether

the proposed method is better to make predictions in

the real data from water quality status in Indonesia, it

ICoSET 2019 - The Second International Conference on Science, Engineering and Technology

328

will be compared with original FWk-NN. Details of

the test results can be seen in table 2.

Table 2: Comparison of Accuracy

Accuracy

Best Method

FWk-NN

(1)

Proposed

Method

(2)

1 94.20% 96.67% (2)

2 92.50% 96.67% (2)

3 95.00% 95.83% (2)

4 90.00% 93.33% (2)

5 92.50% 93.33% (2)

6 87.50% 90.83% (2)

7 90.80% 89.17% (1)

8 88.30% 90.00% (2)

9 89.20% 90.00% (2)

10 85.80% 90.00% (2)

Avg 90.58% 92.58%

Based on table 2, the proposed method gives

the best prediction results in determining of Data.

Although when the value of k is 7, the accuracy of the

proposed method is decreased by 1.63%, overall the

proposed method was able to improve the accuracy

worth 2%, whereby the highest difference of accuracy

is 4.20% when k is 10.

6 CONCLUSIONS

Referring result and discussion in the previous

chapter can be concluded that distance weights can

improve the accuracy of FWk-NN. Based on the test,

the highest accuracy is obtained at about 4.23% in

the glass data.Distance weights also have proven to

be successful in improving accuracy on water quality

status data. The highest accuracy occurs when k is

ten by 4.2% with the average increase is 2%.In all

tests that have been carried out, it has proven that the

distance weights applied to FWk-NN provide better

accuracy results than the majority vote system with

the average accuracy of all data used is 1.9%.

ACKNOWLEDGMENTS

High appreciation should be given to Universitas

Islam Riau (UIR) especially Department of

Informatics for their support on the dissemination of

this research work as well as the facilities provided.

REFERENCES

Batista, G. and Silva, D. F. (2009). How k-nearest

neighbor parameters affect its performance. Argentine

Symposium on Artiﬁcial Intelligence, pages 95–106.

Bhatia, N. and Vandana (2010). Survey of nearest neighbor

techniques. International Jurnal of Computer Science

and Information Security (IJCSIS).

Chen, Y. and Hao, Y. (2017). A Feature Weighted Support

Vector Machine and K-Nearest Neighbor Algorithm

for Stock Market Indices Prediction. Expert Systems

With Applications : 1-29.

Danades, A., Pratama, D., Anggraini, D., and Anggraini,

D. (2016). Comparison of Accuracy Level K-Nearest

Neighbor Algorithm and Support Vector Machine

Algorithm in Classiﬁcation Water Quality Status.

International Conference on System Engineering and

Technology.

Duneja, A. and Puyalnithi, T. (2017). Enhancing

Classiﬁcation Accuracy of K-Nearest Neighbors

Algorithm Using Ga in Ratio. International Research

Journal of Engineering and Technology (IRJET).

Feng, Y., Jian-Chang, L., and ming L., D. (2016). An

Approach for Fault Diagnosis Based on an Improved

k-Nearest Neighbor Algorithm. Control Conference

(CCC).

Garca-Pedrajas, N. and Ortiz-Boyer, D. (2009). Boosting

K-Nearest Neighbor Classiﬁer By Means Of

Input Space Projection. Expert System With

Application37(7):.

Gou, J. and Xiong, T. (2011). A Novel Weighted Voting for

K-Nearest Neighbor Rule. Journal of Computer6(5):

833-840.

Jabbar, M. A., Deekshatulu, B., and Chandra, P.

(2013). Classiﬁcation of Heart Disease Using K-

Nearest Neighbor and Genetic Algorithm. Procedia

Technology, 10:85–94.

Koteswara Rao, M. (2012). Face Recognition Using

Different Local Features with Different Distance

Techniques. International Journal of Computer

Science, Engineering and Information Technology,

2(1):67–74.

Kuhkan, M. (2016). A method to improve the accuracy of k

- nearest neighbor algorithm. Internatonal Journal of

Computer Engineering and Information Technology.

Labellapansa, A., Efendi, A., Yulianti, A., and Kadir,

E. A. (2016). Lambda Value Analysis on Weighted

Minkowski Distance Model in CBR of Schizophrenia

Type Diagnosis. Fourth International Conference

on Information and Communication Technologies

(ICoICT).

Lidya, S. K., Sitompul, O. S., and Efendi, S. (2015).

Sentiment analysis pada teks bahasa indonesia

menggunakan support vector machine (svm) dan

k-nearest neighbor (k-nn). In Seminar Nasional

Teknologi Informasi dan Komunikasi. (In Bahasa).

Improving the Accuracy of Features Weighted k-Nearest Neighbor using Distance Weight

329

Merig

o, J. M. and Casanovas, M. (2008). The induced

minkowski ordered weighted averaging distance

operator. In Proceedings of the ESTYLF Conference,

pages 35–41.

Mitani, Y. and Hamamoto, Y. (2006). A Local Mean-Based

Nonparametric Classiﬁer. Patern Recognition

Letter27(10): 1151-1159.

Nababan, A. A., Sitompul, O. S., and Tulus (2018).

Attribute Weighting Based K-Nearest Neighbor Using

Gain Ratio. Journal of Physics: Conference Series,

1007(1).

Ougiaroglou, S. and Evangelidis, G. (2012). Fast

and Accuratek-Nearest Neighbor Classiﬁcation using

Prototype Selection by Clustering. Panhellenic

Conference on Informatics.

Pan, Z., Wang, Y., and Ku, W. (2016). A New

K-Harmonic Nearest Neighbor Classifer Based On

The Multi-Local Means. Expert Systems With

Applications67:115-125.

Pan, Z., Wang, Y., and Ku, W. (2017). A new

general nearest neighbor classiﬁcation based on the

mutual neighborhood information. Knowledge-Based

Systems, 121:142–152.

Rui-Jia, W. and Xing, W. (2014). Radar Emitter

Recognition in Airborne RWR/ESM Based on

Improved K Nearest Neighbor Algorithm. Conference

on Computer and Information Technology (CIT).

anchez, A. S., Iglesias-Rodr

ıguez, F. J., Fern

andez,

P. R., and de Cos Juez, F. (2016). Applying the

k-nearest neighbor technique to the classiﬁcation

of workers according to their risk of suffering

musculoskeletal disorders. International Journal of

Industrial Ergonomics, 52:92–99.

Song, Y., Liang, J., Lu, J., and Zhao, X. (2017). An Efﬁcient

Instance Selection Algorithm For K Nearest Neighbor

Regression. Neurocomputing251:26-34.

Syaliman, K. U. and A., L. (2015). Analisa Nilai Lamda

Model Jarak Minkowsky Untuk Penentuan Jurusan

SMA (Studi Kasus di SMA Negeri 2 Tualang). Jurnal

Teknik Informatika dan Sistem Informasi (JuTISI)

1(2) : 163-171 (In Bahasa).

Syaliman, K. U., Sitompul, O. S., and Nababan, E. B.

(2017). Improving the accuracy of k-nearest neighbor

using local mean based and distance weight. 2nd

International Conference on Computing and Applied

Informatics 2017 (ICCAI).

Tamatjita, E. N. and Mahasta, A. W. (2016). Comparison Of

Music Genre Classiﬁcation Using Nearest Centroid

Classiﬁer And K-Nearest Neighbors. International

Conference on Information Management and

Technology (ICIMTech).

Wang, J., Neskovic, P., and Cooper, L. N. (2007).

Improving nearest neighbor rule with a simple

adaptive distance measure. Pattern Recognition

Letters, 28(2):207–213.

Yan, Z. H. C., L., Y., and Zhao, J. T. (2015). Using Improved

K-nearest Neighbor Method to Identify Anti- and

Pro-apoptosis Proteins. 8th International Conference

on BioMedical Engineering and Informatics (BMEI

2015).

Zheng, K. S., Diao, G., Zhou, L., Chen, Z., J., and W.,

Y. (2017). Applications Of Support Vector Machine

And Improvedk-Nearest Neighbor Algorithm In Fault

Diagnosis And fault Degree Evaluation Of Gas

Insulated Switchgear. 1st International Conference

on Electrical Materials and Power Equipment - Xi’an

China.

ICoSET 2019 - The Second International Conference on Science, Engineering and Technology

330
