Feature Selection using Binary Moth Flame Optimization with Time

Varying Flames Strategies

Ruba Abu Khurma

, Pedro A. Castillo

, Ahmad Sharieh

and Ibrahim Aljarah

King Abdullah II School for Information Technology,

The University of Jordan, Amman, Jordan

Department of Computer Architecture and Computer Technology, ETSIIT and CITIC,

University of Granada, Granada, Spain

Keywords:

Moth Flame Optimization, MFO, Feature Selection, Classiﬁcation, Flames Number, Optimization.

Abstract:

In this paper, a new feature selection (FS) approach is proposed based on the Moth Flame Optimization (MFO)

algorithm with time-varying ﬂames number strategies. FS is a data preprocessing technique that is applied to

minimize the number of features in a data set to enhance the performance of the learning algorithm (e.g classi-

ﬁer) and reduce the learning time. Finding the best feature subset is a challenging search process that requires

exponential running time if the complete search space is generated. Meta-heuristics algorithms are promis-

ing alternative solutions that have proven their performance in ﬁnding approximated optimal solutions within

a reasonable time. The MFO algorithm is a recently developed Swarm Intelligence (SI) algorithm that has

demonstrated effective performance in solving various optimization problems. This is due to its spiral update

strategy that enhances the convergence trends of the algorithm. The number of ﬂames is an important parame-

ter in the MFO algorithm that controls the balance between the exploration and exploitation phases during the

optimization process. In the standard MFO, the number of ﬂames linearly decreases throughout the iterations.

This paper proposes different time-varying strategies to update the number of ﬂames and analyzes their impact

on the performance of MFO when used to solve the FS problem. Seventeen medical benchmark data sets were

used to evaluate the performance of the proposed approach. The proposed approach is compared with other

well-regarded meta-heuristics and the results show promising performance in tackling the FS problem.

1 INTRODUCTION

Curse of dimensionality is a challenging problem for

data mining tasks (e.g classiﬁcation and clustering).

It means increasing the number of dimensions (fea-

tures) in a data set (Khurma et al., 2020). This will

lead to having noisy features that are either redun-

dant (highly correlated with each other) or irrelevant

(weakly related to the target class). The major nega-

tive consequences of this phenomenon are the degra-

dation in the performance of the learning algorithm

and the increasing of the learning time.

Feature selection (FS) is a preprocessing stage in

a data mining process to minimize the number of

features and improve the performance of the learn-

ing process. This is done by excluding the uninfor-

mative features and producing a smaller version of a

dataset that includes only the most representative fea-

tures (Aljarah et al., 2018b).

The FS process consists of two primary processes:

searching for the best feature subset and evaluating

the generated feature subset (Khurma. et al., 2020).

Looking at the evaluation process, there are two main

approaches to determine the goodness of a candidate

solution: ﬁlter and wrapper approaches. Filters per-

form the evaluation based on the intrinsic characteris-

tics of the features and their dependencies with each

other and with the target class. In literature, there is

a wide range of examples on ﬁlters such as F-score,

Information Gain (IG) and Chi-Square (Tang et al.,

2014). In wrapper approaches, the evaluation deci-

sion depends on the learning process. The involve-

ment of learning in wrappers contributes to better per-

formance and slower optimization time in comparison

with ﬁlters.

Considering the search process, two main ap-

proaches can be used: complete and meta-heuristic

search (Mafarja et al., 2018). Complete search ap-

proach (i.e brute force) generates the entire feature

space and applies an exhaustive search to determine

Khurma, R., Castillo, P., Sharieh, A. and Aljarah, I.

Feature Selection using Binary Moth Flame Optimization with Time Varying Flames Strategies.

DOI: 10.5220/0010021700170027

In Proceedings of the 12th International Joint Conference on Computational Intelligence (IJCCI 2020), pages 17-27

ISBN: 978-989-758-475-6

the best feature subset from all candidate feature sub-

sets (possible solutions). This is time-consuming

and impractical with large feature spaces. Formally

speaking, for a dataset with N features, the corre-

sponding feature space size is 2

The meta-heuristic search approach mitigated the

complexity problem of large feature spaces by gener-

ating random solutions. Although this approach may

lose the exact optimal solution it may reach to promis-

ing (near) optimal solution in a reasonable time. Thus,

it gives up the exact optimal in exchange for faster

learning time.

A common taxonomy for meta-heuristic algo-

rithms (MHs) are based on the inspiration source from

nature that divided MHs into two main categories

Evolutionary Algorithms (EA) and Swarm Intelli-

gence (SI) (Khurma et al., 2020). EAs are inspired by

Darwin’s theory of evolution. EAs use optimization

operators to evolve solutions such as crossover, muta-

tion and elitism. The most popular EAs are Genetic

Algorithm (GA) (Oliveira et al., 2010) and Differen-

tial Evolution (DE) (Khushaba et al., 2011).

SI category includes algorithms that are inspired

by the social behaviour of creatures that live in groups

such as schools of ﬁsh, the swarm of wolves, ﬂocks

of birds, colonies of bee, etc (Brezo

cnik et al., 2018).

SI algorithm usually mimics the survival strategy of

swarm members and how they exchange information

to ﬁnd the food then convert that into a mathemat-

ical methodology for the SI algorithm. There are

many examples for SIs such as Gray Wolves Op-

timization(GWO) (Medjahed et al., 2016), Cuckoo

Search (CS) (Rodrigues et al., 2013) and Bat Algo-

rithm (BA) (Nakamura et al., 2012). SIs and EAs are

similar in that they are both follow the population-

based paradigm. The algorithm starts by initializing

a set of solutions (e.g. population) then the popula-

tion undergoes an iterative reﬁning process that sim-

ulates either evolutionary or swarming behavior that

the algorithm was originally inspired by. Updating

solutions continues until a predeﬁned stopping con-

dition is met. In any population-based algorithm,

there are two main phases for the optimization process

called exploration and exploitation (Khurma. et al.,

2020). These are conﬂicting milestones because the

optimizer in exploration searches globally to explore

different regions of the search space but in exploita-

tion, the search is made locally in the most promis-

ing region where the optimal solution is likely to be

found. A proper balance between exploration and ex-

ploitation will enhance the performance of the op-

timization process because a lot of exploration in-

creases the time of search and may lose the opti-

mal solution and excessive exploitation may lead to

stuck in local minima. Recently, MHs have been pro-

posed to solve various optimization problems includ-

ing the FS problem. MHs have been used to pro-

vide valid optimized solutions for the FS problem in

a wide range of applications such as Arabic hand-

written letter recognition (Tubishat et al., 2018), fa-

cial recognition (Mistry et al., 2017), ﬁnancial diag-

nosis (Wang and Tan, 2017; Al-Madi et al., 2018),

and medical application (Wang et al., 2017). In the

medical applications, the FS-MH approach has been

efﬁciently applied to minimize the size of a medi-

cal data set without causing degradation in the per-

formance of a learner. Moreover, FS-MH maintains

the readability of the medical data set by providing

the physician with the most useful features that are

able to diagnose the patient’s status without affect-

ing the original meaning of those features. In lit-

erature, researchers worked to enhance the MHs by

applying different modiﬁcation strategies: integrat-

ing new operators (e.g chaotic maps (Khurma. et al.,

2020), rough set (Inbarani et al., 2014) and Levy ﬂight

(Zhang et al., 2016)), hybridization with other algo-

rithm (e.g ﬁlter (Yang et al., 2010), MH (Zawbaa

et al., 2018) and classiﬁer (Aljarah et al., 2018a)),

using new initialization mechanism (Medjahed et al.,

2016) and adopting new update strategy such as the

time-varying strategy (Mafarja et al., 2017).

Moth Flame Optimization (MFO) is a recent SI

algorithm that was proposed in (Mirjalili and Lewis,

2013). MFO was originally developed to solve con-

tinuous optimization problems, then a binary version

called BMFO was proposed in (Reddy et al., 2018)

to solve the binary optimization problem such as FS.

Many modiﬁcations have been adopted to improve the

BMFO as a search algorithm in the FS process includ-

ing (Ewees et al., 2017; Zhang et al., 2016; Hassanien

et al., 2017; Sayed and Hassanien, 2018; Sayed et al.,

2016; Wang et al., 2017). For more information about

MFO, a reader can refer to the reviews (Mehne and

Mirjalili, 2020; Shehab et al., 2019). The MFO’s suc-

cess is mainly due to its spiral update strategy and

the adaptive parameters that control the adaptive con-

vergence of the algorithm and maintain the trade-off

between exploration and exploitation.

In MFO, moths represent the search agents that

change their positions in the search space. The best

positions obtained so far are called ﬂames. To guar-

antee the exploitation around the best positions, MFO

applies an adaptive mechanism to decrease the num-

ber of ﬂames over the course of iterations. Thus, there

will be N ﬂames in the initial iterations that are equal

to the number of moths then due to the gradual decre-

ments, the moths will update their positions with re-

spect to one ﬂame in the ﬁnal iterations. In the stan-

ECTA 2020 - 12th International Conference on Evolutionary Computation Theory and Applications

dard MFO, the adjustment for the number of ﬂames

is performed using a linear decreasing strategy. This

chapter proposes for the ﬁrst time different updating

strategies to control the number of ﬂames parame-

ter. The aim is to study the effect of using different

time variant functions for the number of ﬂames on the

MFO optimization process in the feature space. The

main contribution of this paper is the enhancement of

the MFO capability as a wrapper FS by utilizing its

spiral update strategy in combination with the time-

varying ﬂames strategy. The generated ﬁve variants

of BMFO are evaluated in terms of ﬁtness value, clas-

siﬁcation accuracy, number of selected features and

processing time. The KNN classiﬁer is used to assess

the accuracy of the different approaches when applied

on a seventeen benchmark medical data set. The ex-

perimental results show superior performance in tack-

ling the FS problem.

The paper is organized as follows: Section 2

presents an overview of the MFO algorithm. Section

3, describes the proposed approach. Section 4, shows

the experimental results. Finally, a conclusion and fu-

ture works are provided in Section 5.

2 MOTH FLAME OPTIMIZATION

Moth Flame Optimization (MFO) is a recent SI al-

gorithm that was developed in (Mirjalili and Lewis,

2013). The natural inspiration of MFO came from the

movements of moths at night. These moths travel in a

straight line and maintain a stable angle to the moon.

This movement strategy is called transfer orientation.

The transfer orientation is not useful if the source light

is close because the moth will try to maintain the same

angle with it, forcing it to move in a spiral way and

eventually die. Fig 1 shows the conceptual model of

the MFO algorithm.

Eq.1 describes mathematically the natural spiral

motion of moths around a ﬂame where M

represents

the i

moth, F

represents the j

ﬂame, and S is the

spiral function. Eq.2 formulates the spiral motion us-

ing a standard logarithmic function where D

is the

distance between the i

moth and the j

ﬂame as de-

scribed in Eq.3, b is a constant value for determining

the shape of the logarithmic spiral, and t is a random

number in the range [-1, 1]. The parameter t = −1

indicates the closest position of a moth to a ﬂame

where t = 1 indicates the farthest position between

a moth and a ﬂame. To achieve more exploitation in

the search space the t parameter is considered in the

range [r,1] where r is linearly decreased throughout

iterations from -1 to -2. Eq.8 shows gradual decre-

ments of the number of ﬂames throughout iterations.

Algorithm 1 shows the entire pseudo code of the MFO

algorithm.

= S(M

) (1)

S(M

) = D

× e

× cos(2π) + F

(2)

= |M

− F

| (3)

Algorithm 1: Pseudo-code of the MFO algorithm.

Input:Max iteration, n (number of moths), d (number

of dimensions)

Output:Approximated global solution

Initialize the position of moths

while l ≤ Max iteration do

Update ﬂame no using Eq.8

OM = FitnessFunction(M);

if l == 1 then

F = sort(M);

OF = sort(OM);

else

F = sort(M

l−1

);

OF = sort(OM

l−1

,OM

);

end if

for i = 1: n do

for j = 1: d do

Update r and t;

Calculate D using Eq.3 with respect to the

corresponding moth;

Update M(i, j) using Eqs.1 and Eqs.2 with

respect to the corresponding moth;

end for

l = l + 1;

end while

2.1 Binary Moth Flame Optimization

The original MFO was designed to solve global op-

timization problems (Mirjalili, 2015). In such cases,

the individual elements are real values. Thus, the opti-

mizer’s task is to verify that the upper and lower limits

of each element are not exceeded in the initialization

and update processes. However, for binary optimiza-

tion problems, the case is different because each in-

dividual’s elements are restricted to either “0” or “1”.

To enable the MFO algorithm to optimize in a binary

feature space, the MFO needs to integrate some op-

erators with it. The most common binary operator

used to convert continuous optimizers into binary is

the transfer function (TF) (Mirjalili and Lewis, 2013).

The main reason for using TFs is that they are easy

to implement without affecting the essence of the al-

gorithm. In this paper, the used TF is the sigmoid

Feature Selection using Binary Moth Flame Optimization with Time Varying Flames Strategies

Figure 1: The conceptual model for the movement behaviour of moths.

function which was originally used in (Kennedy and

Eberhart, 1997) to generate the binary PSO (BPSO).

In the MFO algorithm, the ﬁrst term of Eq.2 repre-

sents the step vector which is redeﬁned in Eq.4. The

function of the sigmoid is to determine a probability

value in the range [0,1] for each element of the solu-

tion. Eq.5 shows the formula of the sigmoid function.

Each moth updates its position based on Eq.6 which

takes the output of Eq.5 as its input.

∆ M = D

× e

× cos(2π) (4)

T F(∆ M

) = 1/(1 + e

∆ M

) (5)

(t + 1) =

(

0, if rand < T F(∆ M

t+1

)

1, if rand > T F(∆ M

t+1

)

(6)

2.2 Binary Moth Flame Optimization

for Feature Selection

For an FS problem, there are two important issues to

consider to establish a correct optimization process:

the representation of the individual and the evalua-

tion of it. Usually, the individual in the FS problem

is represented using a 1-d array. The value of each

element can be assigned to two values, either ”0” or

”1”. The value ”0” indicates that the feature is not

selected while the value ”1” indicates that the feature

is selected. The evaluation of the individual in an FS

problem depends on using a ﬁtness function that max-

imizes the performance of a classiﬁer and minimizes

the number of selected features simultaneously.

Eq.7 formulates the FS problem where αγ

(D) is

the error rate of the classiﬁcation produced by a clas-

siﬁer, |R| is the number of selected features in the re-

duced data set, and |C| is the number of features in the

original data set, and α ∈ [0,1], β = (1 − α) are two

parameters for representing the importance of classiﬁ-

cation performance and length of feature subset based

on recommendations (Faris et al., 2019).

Fitness = αγ

(D) + β

|R|

|C|

(7)

3 THE PROPOSED APPROACH

The optimization process of the population-based

meta-heuristic algorithms has two conﬂicting mile-

stones: exploration and exploitation. In exploration,

the optimizer searches globally and explores several

regions of the search space to determine the most

promising region where a global solution might ex-

ist. In contrast, the optimizer in exploitation searches

locally within these regions to ﬁnd the (near) global

optima. A good balance between exploration and ex-

ploitation will enable the optimizer to achieve better

convergence results in a reasonable time. Usually,

a meta-heuristic algorithm has one or more param-

eters that control the transition between exploration

and exploitation. The ideal behavior is to extend

the exploration phase in the early stages of the op-

timization process to navigate to more regions in the

search space and then seamlessly switch to the ex-

ploitation phase to focus on a speciﬁc region until it

comes very close to the optimal solution. In MFO,

the ﬂames number is the parameter that controls the

balance between exploration and exploitation. In the

standard MFO algorithm, the number of ﬂames is up-

dated using a linear decreasing formula. Different up-

date strategies are proposed in this paper for the ﬁrst

time to guarantee the gradual decrements of the num-

ber of ﬂames throughout iterations.

• Flames number with linearly decreasing strategy.

This is the standard formula used in the original

MFO algorithm. As appears in Eq.8, there will

be more exploration for the search space in the

early optimization stages while there will be more

exploitation in the ﬁnal stages. The ﬂames no is

decreased linearly across iterations (Shi and Eber-

hart, 1999). Flames no at each iteration is deﬁned

ECTA 2020 - 12th International Conference on Evolutionary Computation Theory and Applications

as in Eq.8 where l is the current number of itera-

tion, N is the maximum number of ﬂames and T

is the maximum number of iterations.

Flames no = round



N −







N − 1



(8)

• Flames number with Non-linear coefﬁcient de-

creasing strategy.

The Non-linear coefﬁcient decreasing strategy is

proposed instead of the standard Linear updating

strategy (Yang et al., 2015). Flames no at each

iteration is deﬁned as in Eq.9 where α is suggested

by the authors to be α = 1/π

Flames no = round



N −







N − 1



(9)

• Flames number with Decreasing strategy.

This strategy uses a nonlinear formula to decrease

the ﬂames number over the iterations (Fan and

Chiu, 2007). Flames no at each iteration is de-

ﬁned as in Eq.10.

Flames no = round





0.3

(10)

• Flames number with Oscillating strategy.

The Oscillating strategy uses a sinusoidal function

to update ﬂames number during the search pro-

cess instead of monotonically decreasing it (Kent-

zoglanakis and Poole, 2009). The ﬂames number

at each iteration is deﬁned as in Eq.11 where k is

set by the authors to 7.

Flames no = round



N −cos



2πl(4k + 6)





N −1



(11)

• Flames number with Logarithmic strategy.

The Logarithmic decreasing strategy (Gao et al.,

2008) to update the ﬂames number is shown in

Eq.12 where a is a constant that set to 1 by the

authors.

Flames no = round



N −



log



a +

10l





N − 1



(12)

4 EXPERIMENTAL SETUP AND

RESULTS

In this paper, seventeen medical data sets were used

to evaluate the proposed wrapper approaches. The

datasets were downloaded from well-regarded data

repositories: UCI, Kaggle and Keel. Table 1 lists

these data sets and shows their number of features,

instances, and classes. Table 2 shows the param-

eters setting of three well known meta-heuristic al-

gorithms: BGWO, BCS and BBA. These wrapper

based approaches were used to validate the proposed

approaches by conducting fair comparisons between

them. Therefore, all the experiments were executed

on a personal machine with AMD Athlon Dual-Core

QL-60 CPU at 1.90 GHz and memory of 2 GB

running Windows7 Ultimate 64 bit operating sys-

tem. The optimization algorithms have been all im-

plemented in Python in the EvoloPy-FS framework

(Khurma et al., 2020). The maximum number of it-

erations and the population size were set to 100 and

10 respectively. In this work, the K-NN classiﬁer (K =

5(Aljarah et al., 2018a)) is used to assess the goodness

of each solution in the wrapper FS approach. Each

data set is randomly divided into two parts; 66% for

training and 34% for testing. To obtain statistically

signiﬁcant results, this division was repeated 30 inde-

pendent times. Therefore, the ﬁnal statistical results

were obtained over 30 independent runs. The α and

β parameters in the ﬁtness equation is set to 0.99 and

0.01, respectively (Mafarja et al., 2020). The used

evaluation measures are ﬁtness values (see Eq. 13),

classiﬁcation accuracy (see Eq. 14), number of se-

lected features (see Eq. 15) and CPU time (see Eq.

16).

∑

j=1

Fit

(13)

where M is the number of runs, Fit

is the ﬁtness value

of the best solution in the i

run.

∑

j=1

∑

i=1

= L

) (14)

where M is the number of runs for MFO to ﬁnd the

optimal subset of features, N is the number of data

set instances, C

is the predictive class, and L

is the

actual class in the labeled data.

∑

i=1

(15)

where M is the number of runs, d

is the number of

selected features in the best solution from the i

h run,

and D is the total number of features in the original

dataset.

∑

i=1

(16)

where M is the number of runs, RT

is the running time

required for the i

run to be completed.

Feature Selection using Binary Moth Flame Optimization with Time Varying Flames Strategies

In this section, the impact of the number of

ﬂames parameter using different time-varying update

strategies is studied. Furthermore, a comparison is

conducted between these strategies and three well-

regarded wrapper methods (e.g, BGWO, BCS and

BBA). The best results in tables are highlighted in

bold.

Considering Table 3, it can be seen that using

BMFO with a Linear strategy outperformed other ap-

proaches in 35% of the data sets, followed by the De-

creasing strategy that got the best results in four data

sets. The Decreasing strategy is a variant of the Non-

decreasing strategy that reduces the number of ﬂames

during the optimization process based on the current

iteration. It doesn’t include the maximum number

of iterations. Other strategies reduce the number of

ﬂames using the ratio of the current iteration (l) to the

maximum number of iteration (T). Logarithm came

third and Oscillating and Non-linear strategies came

last. Inspecting Table 7 and Fig 2, it can be seen, in

general, that the Linear-based BMFO approach out-

performed BGOW, BCS, and BBA in terms of classi-

ﬁcation accuracy across 41% of the data sets. BGOW,

BCS, and BBA obtained the best result in ﬁve, three

and two data sets respectively.

Because FS is a minimization optimization prob-

lem, the target is to achieve a minimal ﬁtness value.

In other words, FS is seeking to determine the most

informative features that reveal the highest classiﬁca-

tion accuracy. By comparing the BMFO strategies to-

gether in terms of ﬁtness values, it can be seen in Ta-

ble 4 that the Linear strategy was the best on six data

sets then came the Logarithm and Oscillating strate-

gies which were the best on ﬁve and four data sets re-

spectively. Following them are the Nonlinear and De-

creasing approaches which were the best only on two

and one data sets respectively. From Table 8 and Fig

3, it appears that the best ﬁtness values were obtained

by the BCS which outperformed the others across

53% of data sets. The Linear-based BMFO came next

and outperformed other approaches across 29% of the

data sets. The decline in the ﬁtness results of BMFO

compared to BCS can be explained that they were not

superior to BCS either in minimizing the number of

selected features or maximizing the classiﬁcation ac-

curacy. This is because the ﬁtness function combines

the error rate and the size of the feature subset. Since

Linear BMFO is superior to other methods in terms

of classiﬁcation accuracy, then it was not superior in

terms of the number of selected features. Fig 4 il-

lustrates the convergence behavior of all the studied

wrapper approaches on all data sets. Each subﬁgure

shows the changes in ﬁtness value for each approach

across all iterations on a speciﬁed data set. In all data

sets, BMFO based approaches and BCS show the best

convergence trends. This can be realized from the

convergence curves that achieve the minimum ﬁtness

values in the ﬁnal iterations of the optimization pro-

cess. On the other hand, premature convergence and

entrapment in local minima can be guessed from the

convergence behavior of BGWO and BBA.

When examining the results of the number of se-

lected features recorded in Table 5, the Decreasing-

based BMFO was ranked ﬁrst with the best results

reported across 41% of the data sets. However, Ta-

ble 9 shows that the BBA was the best approach to

reduce the dimensionality of the medical data sets.

BBA was superior to other approaches over 59% of

the data sets.

In this section, the running time is carefully an-

alyzed because this is a serious factor especially

when the data sets become larger. In Table 6, the

Decreasing-based BMFO achieved the smallest run-

ning time on eight data sets. Oscillating and linear

approaches came next, and they achieved the min-

imum running time on ﬁve and three data sets re-

spectively. Logarithm achieved the minimum running

time over the SPECTF Heart data set only. The Non-

linear approach was not the best across any of the data

sets. From Table 10, It can be observed that the De-

creasing BMFO approach achieved the shortest run-

ning time over twelve data sets. The BBA approach

achieved the minim running time over ﬁve data sets

while BGWO and BCS were not the best over any

data sets.

By taking all the results together, we conclude that

the update strategy of the number of ﬂames affects

the robustness and the convergence of the BMFO al-

gorithm. In the proposed approaches, ﬁve strategies

were employed to update the number of ﬂames in

the BMFO algorithm. The Linear strategy was able

to outperform other strategies in terms of classiﬁca-

tion accuracy and ﬁtness values, while the Decreas-

ing strategy obtained the best results in terms of the

number of selected features and average running time.

Here, we can remark that the enhanced performance

of the proposed approach is because the Linear strat-

egy enhanced the ability of the BMFO algorithm to

balance the exploration and exploitation. This is done

by gradually reducing the number of ﬂames through-

out iterations. Also, allowing more exploration in the

early iterations, while exploitation is emphasized in

the later iterations. The results showed the competi-

tive performance of the proposed BMFO approaches

when compared to other well-regarded approaches.

ECTA 2020 - 12th International Conference on Evolutionary Computation Theory and Applications

Table 1: Description of the used data sets.

NO Dataset Name No features No instances No classes

1 Diagnostic 30 569 2

2 Original 9 699 2

3 Coimbra 9 115 2

4 BreastEW 30 596 2

5 Dermatology 34 366 6

6 Liver 10 583 2

7 Lymphography 18 148 4

8 Parkinsons 22 194 2

9 SPECT 22 267 2

10 HeartEW 13 270 2

11 Hepatitis 18 79 2

12 SAHeart 9 461 2

13 SPECTF 43 266 2

14 Heart 13 302 5

15 Diabetes 9 768 2

16 Colon 2000 62 2

17 Leukemia 7129 72 2

Table 2: Parameter settings.

Algorithm

Parameter Value

GWO α [2,0]

BA Qmin Frequency minimum 0

Qmax Frequency maximum 2

A Loudness 0.5

r Pulse rate 0.5

CS pa 0.25

β 3/2

Table 3: Average classiﬁcation accuracy from 30 runs for

all approaches.

Dataset Name Linear

Non-linear

coefﬁcient

Decreasing Oscillating Logarithm

1 Diagnostic 0.907 0.906 0.906 0.904 0.907

2 Original 0.969 0.970 0.971 0.970 0.964

3 Coimbra 0.775 0.775 0.775 0.775 0.775

4 BreastEW 0.935 0.932 0.933 0.932 0.932

5 Dermatology 0.972 0.970 0.970 0.972 0.970

6 Liver 0.774 0.652 0.653 0.653 0.653

7 Lymphography 0.673 0.667 0.664 0.667 0.675

8 Parkinsons 0.776 0.776 0.776 0.776 0.776

9 SPECT 0.657 0.657 0.675 0.658 0.656

10 HeartEW 0.788 0.779 0.781 0.786 0.778

11 Hepatitis 0.824 0.821 0.818 0.815 0.844

12 SAHeart 0.627 0.627 0.627 0.627 0.627

13 SPECTF 0.768 0.764 0.771 0.766 0.764

14 Heart 0.741 0.759 0.742 0.754 0.758

15 Diabetes 0.725 0.726 0.726 0.725 0.725

16 Colon 0.652 0.645 0.644 0.638 0.632

17 Leukemia 0.852 0.845 0.849 0.859 0.849

Table 4: Average ﬁtness values from 30 runs for all ap-

proaches.

Dataset Name Linear

Non-linear

coefﬁcient

Decreasing Oscillating Logarithm

1 Diagnostic 0.038 0.041 0.040 0.050 0.037

2 Original 0.049 0.049 0.046 0.048 0.048

3 Coimbra 0.287 0.287 0.287 0.287 0.287

4 BreastEW 0.071 0.072 0.075 0.075 0.075

5 Dermatology 0.061 0.062 0.065 0.066 0.066

6 Liver 0.348 0.345 0.345 0.345 0.345

7 Lymphography 0.405 0.419 0.423 0.429 0.431

8 Parkinsons 0.348 0.348 0.348 0.348 0.348

9 SPECT 0.371 0.356 0.362 0.372 0.366

10 HeartEW 0.196 0.185 0.184 0.190 0.176

11 Hepatitis 0.202 0.202 0.202 0.202 0.202

12 SAHeart 0.406 0.408 0.408 0.408 0.408

13 SPECTF Heart 0.303 0.301 0.270 0.292 0.296

14 Heart 0.243 0.214 0.240 0.204 0.209

15 Diabetes 0.258 0.260 0.260 0.258 0.258

16 Colon 0.377 0.377 0.377 0.377 0.377

17 Leukemia 0.115 0.115 0.119 0.115 0.115

Table 5: Average number of selected features from 30 runs

for all approaches.

Dataset Name Linear

Non-linear

coefﬁcient

Decreasing Oscillating Logarithm

1 Diagnostic 16.500 15.467 15.367 16.167 16.533

2 Original 4.400 4.567 4.733 4.600 4.333

3 Coimbra 3.667 4.000 4.000 4.033 4.033

4 BreastEW 19.433 19.700 19.500 19.733 20.233

5 Dermatology 22.167 22.167 21.600 21.567 22.567

6 Liver 3.967 4.000 4.000 4.000 2.467

7 Lymphography 9.367 9.233 8.733 9.067 9.333

8 Parkinsons 8.233 8.067 7.967 8.367 8.724

9 SPECT 14.167 13.333 13.733 14.300 13.867

10 HeartEW 7.767 7.433 7.167 7.667 7.333

11 Hepatitis 7.800 7.733 7.167 8.067 7.900

12 SAHeart 4.033 4.000 4.000 4.000 4.000

13 SPECTF 29.500 28.500 27.067 28.933 29.267

14 Heart 5.700 5.400 5.567 5.833 5.667

15 Diabetes 6.500 4.033 4.033 4.000 4.000

16 Colon 1082.067 1116.033 1150.433 1152.233 1115.657

17 Leukemia 3506.367 3510.667 3497.700 3491.767 3492.933

Table 6: Average computational time from 30 runs for all

approaches.

Dataset Name Linear

Non-linear

coefﬁcient

Decreasing Oscillating Logarithm

1 Diagnostic 21.476 21.429 20.804 20.892 21.317

2 Original 23.241 23.362 22.498 22.566 23.321

3 Coimbra 7.918 8.021 7.912 7.884 8.054

4 BreastEW 23.493 23.644 22.984 22.922 23.677

5 Dermatology 16.038 16.090 15.785 15.755 16.126

6 Liver 13.724 13.875 13.439 13.423 13.668

7 Lymphography 9.146 9.0655 8.820 9.113 9.698

8 Parkinsons 10.572 10.637 10.387 10.410 10.525

9 SPECT 12.418 12.682 12.482 12.482 16.958

10 HeartEW 11.848 12.313 11.954 11.990 12.154

11 Hepatitis 7.423 7.423 7.322 7.345 7.377

12 SAHeart 16.354 17.100 16.519 16.562 16.958

13 SPECTF 13.866 14.204 13.837 13.874 13.597

14 Heart 12.165 12.075 11.867 11.892 12.012

15 Diabetes 24.727 24.937 24.224 24.216 24.894

16 Colon 76.932 73.013 70.149 75.816 73.726

17 Leukemia 265.892 260.067 251.403 266.039 264.390

Table 7: Comparison of Linear based MFO with other algo-

rithms based on the average accuracy values.

Dataset Name Linear BGWO BCS BBA

1 Diagnostic 0.907 0.904 0.896 0.760

2 Original 0.969 0.963 0.971 0.939

3 Coimbra 0.775 0.707 0.777 0.583

4 BreastEW 0.935 0.925 0.923 0.896

5 Dermatology 0.972 0.956 0.961 0.739

6 Liver 0.774 0.591 0.653 0.582

7 Lymphography 0.673 0.682 0.690 0.705

8 Parkinsons 0.776 0.799 0.776 0.786

9 SPECT 0.657 0.656 0.653 0.624

10 HeartEW 0.788 0.770 0.778 0.709

11 Hepatitis 0.824 0.805 0.826 0.838

12 SAHeart 0.627 0.647 0.627 0.622

13 SPECTF 0.768 0.767 0.760 0.748

14 Heart 0.741 0.723 0.769 0.645

15 Diabetes 0.725 0.750 0.725 0.664

16 Colon 0.652 0.655 0.632 0.645

17 Leukemia 0.852 0.856 0.853 0.715

Table 8: Comparison of Linear based MFO with other algo-

rithms based on the average ﬁtness values.

Dataset Name Linear BGWO BCS BBA

1 Diagnostic 0.038 0.074 0.085 0.322

2 Original 0.049 0.069 0.042 0.079

3 Coimbra 0.287 0.276 0.287 0.557

4 BreastEW 0.071 0.075 0.068 0.093

5 Dermatology 0.061 0.090 0.070 0.436

6 Liver 0.348 0.407 0.345 0.414

7 Lymphography 0.405 0.405 0.433 0.431

8 Parkinsons 0.348 0.329 0.347 0.366

9 SPECT 0.371 0.358 0.374 0.351

10 HeartEW 0.196 0.194 0.154 0.290

11 Hepatitis 0.202 0.202 0.201 0.204

12 SAHeart 0.406 0.400 0.404 0.371

13 SPECTF 0.303 0.276 0.264 0.272

14 Heart 0.243 0.278 0.182 0.456

15 Diabetes 0.258 0.261 0.258 0.386

16 Colon 0.377 0.376 0.376 0.376

17 Leukemia 0.115 0.115 0.118 0.328

Feature Selection using Binary Moth Flame Optimization with Time Varying Flames Strategies

Figure 2: Comparison of time-variant BMFO approaches

with other optimizers in terms of the classiﬁcation accuracy.

Table 9: Comparison of Decreasing based MFO with other

algorithms based on the average number of selected Fea-

tures.

Dataset Name Decreasing BGWO BCS BBA

1 Diagnostic 15.367 14.733 11.533 14.533

2 Original 4.733 5.667 3.933 3.633

3 Coimbra 4.000 4.333 4.133 4.600

4 BreastEW 19.500 15.600 14.933 12.500

5 Dermatology 21.600 17.267 16.667 14.367

6 Liver 4.000 3.533 4.000 2.467

7 Lymphography 8.733 9.767 7.000 6.600

8 Parkinsons 7.967 9.333 5.800 10.400

9 SPECT 13.733 10.667 10.400 9.000

10 HeartEW 7.167 7.100 6.200 5.467

11 Hepatitis 7.167 6.467 5.300 10.300

12 SAHeart 4.000 4.433 4.100 4.167

13 SPECTF 27.067 22.033 19.933 17.900

14 Heart 5.567 4.767 5.467 5.967

15 Diabetes 4.033 4.033 4.033 3.767

16 Colon 1150.433 970.867 961.867 974.233

17 Leukemia 3497.700 3495.567 3422.367 1241.767

Figure 3: Comparison of time-variant BMFO approaches

with other optimizers in terms of ﬁtness values.

Table 10: Comparison of Decreasing based MFO with other

algorithms based on the average computational Time.

Dataset Name Decreasing BGWO BCS BBA

1 Diagnostic 20.804 23.426 41.084 21.125

2 Original 22.498 24.175 45.724 23.015

3 Coimbra 7.912 8.690 15.852 8.274

4 BreastEW 22.984 24.955 43.112 22.147

5 Dermatology 15.785 18.405 30.140 15.607

6 Liver 13.439 14.249 27.131 14.001

7 Lymphography 8.820 10.775 17.249 9.206

8 Parkinsons 10.387 13.064 20.188 10.628

9 SPECT 12.482 14.483 24.256 12.674

10 HeartEW 11.954 13.625 23.590 12.395

11 Hepatitis 7.322 9.331 14.065 7.556

12 SAHeart 16.519 17.198 33.451 17.170

13 SPECTF 13.837 18.002 25.759 13.597

14 Heart 11.867 13.562 23.625 12.324

15 Diabetes 24.224 25.043 49.313 24.964

16 Colon 70.149 274.127 73.273 55.723

17 Leukemia 251.403 964.913 245.912 189.204

5 CONCLUSIONS

This work presents a new wrapper based FS approach

based on an enhanced MFO algorithm. The enhance-

ment step is based on adopting the time-varying func-

tions for updating the number of ﬂames. This parame-

ter plays an important role in controlling the transition

between exploration and exploitation phases during

the optimization process. Achieving a good balance

between exploration and exploitation will positively

affect the performance of MFO and contributes to im-

proved classiﬁcation performance. In this paper, the

impact of ﬁve different updating strategies for ﬂames

number is investigated. For evaluation purposes, sev-

enteen medical benchmark data sets are used. The

results show that the Linear update strategy that grad-

ually decreases the ﬂames number can improve the

exploration and exploitation of the BMFO for FS

tasks. The reported results show that BMFO methods

achieve competitive results in comparison with other

well-regarded wrapper-based approaches in terms of

the classiﬁcation accuracy, the ﬁtness value, and the

running time.

ACKNOWLEDGMENTS

This work is supported by the Ministerio espa

nol de

Econom

ıa y Competitividad under project TIN2017-

85727-C4-2-P (UGR-DeepBio).

ECTA 2020 - 12th International Conference on Evolutionary Computation Theory and Applications

(a) Diagnostic (b) Original (c) Coimbra (d) BreastEW

(e) Dermatology (f) Liver (g) Lymph (h) Parkinsons

(i) SPECT (j) HeartEW (k) Hepatitis (l) SAHeart

(m) SPECTF (n) Heart (o) Diabetes (p) Colon

(q) Leukemia

Figure 4: Convergence curves for the time-variant BMFO and other wrapper-based approaches on the used medical data sets.

REFERENCES

Al-Madi, N., Faris, H., and Abukhurma, R. (2018).

Cost-sensitive genetic programming for churn predic-

tion and identiﬁcation of the inﬂuencing factors in

telecommunication market. International Journal of

Advanced Science and Technology, pages 13–28.

Aljarah, I., Ala

M, A.-Z., Faris, H., Hassonah, M. A., Mir-

jalili, S., and Saadeh, H. (2018a). Simultaneous fea-

ture selection and support vector machine optimiza-

tion using the grasshopper optimization algorithm.

Cognitive Computation, pages 1–18.

Aljarah, I., Mafarja, M., Heidari, A. A., Faris, H., Zhang, Y.,

and Mirjalili, S. (2018b). Asynchronous accelerating

multi-leader salp chains for feature selection. Applied

Soft Computing, 71:964–979.

Brezo

cnik, L., Fister, I., and Podgorelec, V. (2018). Swarm

intelligence algorithms for feature selection: A re-

view. Applied Sciences, 8(9):1521.

Ewees, A. A., Sahlol, A. T., and Amasha, M. A. (2017).

A bio-inspired moth-ﬂame optimization algorithm for

arabic handwritten letter recognition. In Control,

Artiﬁcial Intelligence, Robotics & Optimization (IC-

CAIRO), 2017 International Conference on, pages

Feature Selection using Binary Moth Flame Optimization with Time Varying Flames Strategies

154–159. IEEE.

Fan, S.-K. S. and Chiu, Y.-Y. (2007). A decreasing inertia

weight particle swarm optimizer. Engineering Opti-

mization, 39(2):203–228.

Faris, H., Ala’M, A.-Z., Heidari, A. A., Aljarah, I., Mafarja,

M., Hassonah, M. A., and Fujita, H. (2019). An intel-

ligent system for spam detection and identiﬁcation of

the most relevant features based on evolutionary ran-

dom weight networks. Information Fusion, 48:67–83.

Gao, Y.-l., An, X.-h., and Liu, J.-m. (2008). A parti-

cle swarm optimization algorithm with logarithm de-

creasing inertia weight and chaos mutation. In 2008

International Conference on Computational Intelli-

gence and Security, volume 1, pages 61–65. IEEE.

Hassanien, A. E., Gaber, T., Mokhtar, U., and Hefny, H.

(2017). An improved moth ﬂame optimization al-

gorithm based on rough sets for tomato diseases de-

tection. Computers and Electronics in Agriculture,

136:86–96.

Inbarani, H. H., Azar, A. T., and Jothi, G. (2014). Super-

vised hybrid feature selection based on pso and rough

sets for medical diagnosis. Computer methods and

programs in biomedicine, 113(1):175–185.

Kennedy, J. and Eberhart, R. C. (1997). A discrete binary

version of the particle swarm algorithm. In Systems,

Man, and Cybernetics, 1997. Computational Cyber-

netics and Simulation., 1997 IEEE International Con-

ference on, volume 5, pages 4104–4108. IEEE.

Kentzoglanakis, K. and Poole, M. (2009). Particle swarm

optimization with an oscillating inertia weight. In Pro-

ceedings of the 11th Annual conference on Genetic

and evolutionary computation, pages 1749–1750.

Khurma., R. A., Aljarah., I., and Sharieh., A. (2020).

An efﬁcient moth ﬂame optimization algorithm us-

ing chaotic maps for feature selection in the medical

applications. In Proceedings of the 9th International

Conference on Pattern Recognition Applications and

Methods - Volume 1: ICPRAM,, pages 175–182. IN-

STICC, SciTePress.

Khurma, R. A., Aljarah, I., Sharieh, A., and Mirjalili, S.

(2020). Evolopy-fs: An open-source nature-inspired

optimization framework in python for feature selec-

tion. In Evolutionary Machine Learning Techniques,

pages 131–173. Springer.

Khushaba, R. N., Al-Ani, A., and Al-Jumaily, A. (2011).

Feature subset selection using differential evolution

and a statistical repair mechanism. Expert Systems

with Applications, 38(9):11515–11526.

Mafarja, M., Aljarah, I., Heidari, A. A., Hammouri, A. I.,

Faris, H., Ala

M, A.-Z., and Mirjalili, S. (2018). Evo-

lutionary population dynamics and grasshopper opti-

mization approaches for feature selection problems.

Knowledge-Based Systems, 145:25–45.

Mafarja, M., Qasem, A., Heidari, A. A., Aljarah, I., Faris,

H., and Mirjalili, S. (2020). Efﬁcient hybrid nature-

inspired binary optimizers for feature selection. Cog-

nitive Computation, 12(1):150–175.

Mafarja, M. M., Eleyan, D., Jaber, I., Hammouri, A., and

Mirjalili, S. (2017). Binary dragonﬂy algorithm for

feature selection. In New Trends in Computing Sci-

ences (ICTCS), 2017 International Conference on,

pages 12–17. IEEE.

Medjahed, S. A., Saadi, T. A., Benyettou, A., and Ouali, M.

(2016). Gray wolf optimizer for hyperspectral band

selection. Applied Soft Computing, 40:178–186.

Mehne, S. H. H. and Mirjalili, S. (2020). Moth-ﬂame op-

timization algorithm: theory, literature review, and

application in optimal nonlinear feedback control de-

sign. In Nature-Inspired Optimizers, pages 143–166.

Springer.

Mirjalili, S. (2015). Moth-ﬂame optimization algorithm: A

novel nature-inspired heuristic paradigm. Knowledge-

Based Systems, 89:228–249.

Mirjalili, S. and Lewis, A. (2013). S-shaped versus v-

shaped transfer functions for binary particle swarm

optimization. Swarm and Evolutionary Computation,

9:1–14.

Mistry, K., Zhang, L., Neoh, S. C., Lim, C. P., and Fielding,

B. (2017). A micro-ga embedded pso feature selec-

tion approach to intelligent facial emotion recognition.

IEEE transactions on cybernetics, 47(6):1496–1509.

Nakamura, R. Y., Pereira, L. A., Costa, K., Rodrigues, D.,

Papa, J. P., and Yang, X.-S. (2012). Bba: a binary

bat algorithm for feature selection. In 2012 25th SIB-

GRAPI conference on graphics, Patterns and Images,

pages 291–297. IEEE.

Oliveira, A. L., Braga, P. L., Lima, R. M., and Corn

elio,

M. L. (2010). Ga-based method for feature selection

and parameters optimization for machine learning re-

gression applied to software effort estimation. infor-

mation and Software Technology, 52(11):1155–1166.

Reddy, S., Panwar, L. K., Panigrahi, B. K., and Kumar, R.

(2018). Solution to unit commitment in power sys-

tem operation planning using binary coded modiﬁed

moth ﬂame optimization algorithm (bmmfoa): a ﬂame

selection based computational technique. Journal of

Computational Science, 25:298–317.

Rodrigues, D., Pereira, L. A., Almeida, T., Papa, J. P.,

Souza, A., Ramos, C. C., and Yang, X.-S. (2013).

Bcs: A binary cuckoo search algorithm for feature se-

lection. In Circuits and Systems (ISCAS), 2013 IEEE

International Symposium on, pages 465–468. IEEE.

Sayed, G. I. and Hassanien, A. E. (2018). A hybrid sa-

mfo algorithm for function optimization and engineer-

ing design problems. Complex & Intelligent Systems,

pages 1–18.

Sayed, G. I., Hassanien, A. E., Nassef, T. M., and Pan,

J.-S. (2016). Alzheimer

s disease diagnosis based on

moth ﬂame optimization. In International Conference

on Genetic and Evolutionary Computing, pages 298–

305. Springer.

Shehab, M., Abualigah, L., Al Hamad, H., Alabool, H., Al-

shinwan, M., and Khasawneh, A. M. (2019). Moth–

ﬂame optimization algorithm: variants and applica-

tions. Neural Computing and Applications, pages 1–

26.

Shi, Y. and Eberhart, R. C. (1999). Empirical study of parti-

cle swarm optimization. In Proceedings of the 1999

ECTA 2020 - 12th International Conference on Evolutionary Computation Theory and Applications

congress on evolutionary computation-CEC99 (Cat.

No. 99TH8406), volume 3, pages 1945–1950. IEEE.

Tang, J., Alelyani, S., and Liu, H. (2014). Feature selec-

tion for classiﬁcation: A review. Data classiﬁcation:

Algorithms and applications, page 37.

Tubishat, M., Abushariah, M. A., Idris, N., and Aljarah, I.

(2018). Improved whale optimization algorithm for

feature selection in arabic sentiment analysis. Applied

Intelligence, pages 1–20.

Wang, G.-G. and Tan, Y. (2017). Improving metaheuristic

algorithms with information feedback models. IEEE

Transactions on Cybernetics.

Wang, M., Chen, H., Yang, B., Zhao, X., Hu, L., Cai, Z.,

Huang, H., and Tong, C. (2017). Toward an opti-

mal kernel extreme learning machine using a chaotic

moth-ﬂame optimization strategy with applications in

medical diagnoses. Neurocomputing, 267:69–84.

Yang, C., Gao, W., Liu, N., and Song, C. (2015). Low-

discrepancy sequence initialized particle swarm op-

timization algorithm with high-order nonlinear time-

varying inertia weight. Applied Soft Computing,

29:386–394.

Yang, C.-H., Chuang, L.-Y., Yang, C. H., et al. (2010). Ig-

ga: a hybrid ﬁlter/wrapper method for feature selec-

tion of microarray data. Journal of Medical and Bio-

logical Engineering, 30(1):23–28.

Zawbaa, H. M., Emary, E., Grosan, C., and Snasel,

V. (2018). Large-dimensionality small-instance set

feature selection: A hybrid bio-inspired heuristic

approach. Swarm and Evolutionary Computation,

42:29–42.

Zhang, L., Mistry, K., Neoh, S. C., and Lim, C. P.

(2016). Intelligent facial emotion recognition using

moth-ﬁreﬂy optimization. Knowledge-Based Systems,

111:248–267.

Feature Selection using Binary Moth Flame Optimization with Time Varying Flames Strategies
