Extracting Body Text from Academic PDF Documents for Text Mining

Changfeng Yu, Cheng Zhang and Jie Wang

Department of Computer Science, University of Massachusetts, Lowell, MA, U.S.A.

Keywords:

Body-text Extraction, HTML Replication of PDF, Line Sweeping, Backward Traversal.

Abstract:

Accurate extraction of body text from PDF-formatted academic documents is essential in text-mining appli-

cations for deeper semantic understandings. The objective is to extract complete sentences in the body text

into a txt ﬁle with the original sentence ﬂow and paragraph boundaries. Existing tools for extracting text from

PDF documents would often mix body and nonbody texts. We devise and implement a system called PDFBoT

to detect multiple-column layouts using a line-sweeping technique, remove nonbody text using computed text

features and syntactic tagging in backward traversal, and align the remaining text back to sentences and para-

graphs. We show that PDFBoT is highly accurate with average F1 scores of, respectively, 0.99 on extracting

sentences, 0.96 on extracting paragraphs, and 0.98 on removing text on tables, ﬁgures, and charts over a corpus

of PDF documents randomly selected from arXiv.org across multiple academic disciplines.

1 INTRODUCTION

It is desirable for text mining applications to extract

complete sentences and correct boundaries of para-

graphs from the body text of a PDF document into

a txt ﬁle without hard breaks inside each paragraph.

Layered reading (http://dooyeed.com) and extractive

summarization, for example, are such applications.

Layered reading allows the reader to read the most

important layer of sentences ﬁrst based on sentence

rankings, then the layer of next important sentences

interleaving with the previous layers of sentences in

the original order of the document, and continue in

this fashion until the entire document is read.

By “body text” (BT in short) it means the main

text of an article, excluding “nonbondy text” (NBT in

short) such as headings, footings, sidings (i.e., text on

side margins), tables, ﬁgures, charts, captions, titles,

authors, afﬁliations, and math expressions in the dis-

play mode, among other things.

Most existing tools for extracting text from PDF

documents, including pdftotext (FooLabs, 2014) and

PDFBox (Apache, 2017), extract a mixture of both

BT and NBT texts. Identifying BT text from such

mixtures of texts is challenging, if not impossible.

Other tools extract texts according to rhetorical cate-

gories such as LA-PDFText (Burns, 2013) and logical

text blocks such as Icecite (Korzen, 2017), which only

provide a suboptimal solution to our applications.

Extracting BT text from PDF documents of ar-

bitary layouts is challenging, due to the utmost ﬂex-

ibility of PDF typesetting. Instead, we focus on BT

extraction from single-column and multiple column

research papers, reports, and case studies. We do so

by working with the location, font size, and font style

of each character, and the locations and sizes of other

objects. While a PDF ﬁle provides such information,

we ﬁnd it easier to work with HTML replications pro-

duced by an exiting tool named pdf2htmlEX (Wang,

2014), with almost the same look and feel of the orig-

inal PDF document, providing necessary formatting

information via HTML tags, classes, and id’s in the

underlying DOM tree.

We devise a system named PDFBoT (PDF to

Body Text) that, using pdf2htmlEX as a black box,

incorporates certain text formatting features produced

by it to identify NBT texts. We use a line-sweeping

method to detect multi-column layouts and the area

for printing the BT text. We also develop multiple

tests to identify NBT text inside the BT-text area and

use a backward traversal method to deploy these tests.

In addition, we use POS (Part-of-Speech) tagging to

help identify NBT text that are harder to distinguish.

The rest of the paper is organized as follows:

Section 2 is related work on text extractions from

PDF. Section 3 describes HTML replications via

pdf2htmlEX and Sections 4 presents the architecture

of PDFBoT and its features Section 5 is evaluation re-

sults with F1 scores and running time, and Section 6

is conclusions and ﬁnal remarks.

Yu, C., Zhang, C. and Wang, J.

Extracting Body Text from Academic PDF Documents for Text Mining.

DOI: 10.5220/0010131402350242

In Proceedings of the 12th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2020) - Volume 1: KDIR, pages 235-242

ISBN: 978-989-758-474-9

235

2 RELATED WORK

Existing tools, such as pdftotext (FooLabs, 2014) and

PDFBox (Apache, 2017) the two most widely-used

tools for extracting text from PDF, and a number of

other tools such as pdftohtml (Kruk, 2013), pdftoxml

(Dejean and Giguet, 2016), pdf2xml (Tiedemann,

2016), ParsCit (Kan, 2016), PDFMiner (Shinyama,

2016), pdfXtk (Hassan, 2013), pdf-extract (Ward,

2015), pdfx (Constantin et al, 2011), PDFExtract

(Berg, 2011), and Grobid (Lopez, 2017), extract text

from PDF extract BT text and NBT text together with-

out a clear distinction. PDFBox can extract text in

two-column layouts; some other tools extract text line

by line across columns.

Using heuristics is a common approach. For ex-

ample, the Java PDF library was used to obtain a

bounding box for each word, compute the distance

between neighboring words, connect them based on a

set of rules to form a larger text block, place them into

rhetorical categories, and connect these categories

following the order of the underlying document (Ra-

makrishnan et al., 2012). However, this method fails

to align broken sentence and determine text on formu-

las, tables, or ﬁgures. Using an intermediate HTML

representation generated by pdftohtml (Yildiz et al.,

2005). Text blocks may also be created by grouping

characters based on their relative positions (Shigarov

et al., 2016), while extracting the tables in PDF. These

two methods are focused only on extracting tables.

Other methods include rule-based and machine-

learning models. For example, text may be placed

into predeﬁned logical text blocks based on a set of

rules on the distance, positions, fonts of characters,

words, and text lines (Bast and Korzen, 2017). How-

ever, these rules also connect text on tables or ﬁg-

ures as BT text. A Conditional Random Field (CRF)

model is trained (Luong et al., 2011; Romary and

Lopez, 2015) to extract texts according to a prede-

ﬁned rhetorical category, such as title, abstract, and

other sections in the input document. However, this

model fails to determine paragraph boundaries or

align broken sentences, among other things.

CiteSeerX (Giles, 2006), a search engine, extracts

metadata from indexed articles in scientiﬁc docu-

ments for searching purpose, but not focused on the

accuracy of extracting body text. PDFﬁgures (Clark

and Divvala, 2015) chunks the text table and ﬁgure

into blocks, then classiﬁes these blocks into captions,

body text, and part-of-ﬁgure text. Recent studies have

shifted attentions to extracting certain types of text,

including titles (Yang et al., 2019) (but not text on ta-

bles or ﬁgures), and math expressions in the display

mode and the inline mode (Mali et al., 2020; Pfahler

et al., 2019; Wang et al., 2018; Phong et al., 2020).

In summary, previous methods, while meeting

with certain success, still fall short of the desired ac-

curacy required by text-mining applications relying

on clean extractions of complete sentences and cor-

rect boundaries of paragraphs in BT text.

3 HTML REPLICATION OF PDF

HTML technologies have been used to replicate PDF

layouts to facilitate online publishing. A PDF docu-

ment can be represented as a sequence of pages, with

each page being a DOM tree of objects with sufﬁcient

information for an HTML viewer to display the con-

tent (Wang and Liu, 2013). The text extracted from

PDF by pdf2htmlEX (Wang, 2014) are translated into

HTML text elements that are placed into the same po-

sitions as they are displayed by PDF.

Let F denote a PDF document and f the HTML

ﬁle produced by pdf2htmlEX on F. The DOM tree

for f , denoted by T

, is divided into four levels: doc-

ument, page, text line, and text block (TBK in short).

(1) Document Structure. T

starts with the following

tag as the root: hdiv id=“page-container”i, and each

of its children is the root of a subtree for a page, listed

in sequence, with an id indicating its page number

and a class name indicating the width and height of

a page. For example, a child node with hdiv id=“pf7”

class=“pf w0 h0 data-page-no=“7”i is the root of the

subtree for Page 7, where w0 and h0 are the width and

height of the page (specifying the printable area) with

the origin at the lower-left corner of the page.

(2) Page Structure. Each page starts with a page node,

followed by object nodes with contents to be printed.

Each object occupies a rectangular area (a bounding

box) speciﬁed on a coordinate system of pixels. The

text of the document is divided into TBKs as leaf

nodes. Each TBK is represented by a hdivi tag with

corresponding attributes, and so the text in a TBK are

either all BT text or all NBT text. Each object is iden-

tiﬁed by coordinates (x,y) at the lower-left corner of

the bounding box relative to the coordinates of its par-

ent node. In what follows, these coordinates are re-

ferred to as the starting point of the underlying object.

In addition to the starting point, a non-textual object is

speciﬁed by a width and a height, and a TBK is speci-

ﬁed with a height without a width, where the width is

implied by the enclosed text, font size and style, and

word spacing. The parent of each object may either be

the origin, a node for a ﬁgure or a table, or a node due

to some (probably invisible) formatting code. Thus,

the height of a page’s DOM tree could be greater than

3. Figure 1 is a schematic of page structure.

KDIR 2020 - 12th International Conference on Knowledge Discovery and Information Retrieval

236

Figure 1: Schematic of the page structure. The red square

is a ﬁgure with a TBK1 and subscript TBK2 inside the

square, where (x

),(x

) are absolute coordi-

nates, and (x

) (1 ≤ i ≤ 2) are relative to (x

). Thus,

the corresponding absolute locations, denoted by (x

are x

= x

+ x

and y

= y

+ y

for i = 1,2.

(3) Line Structure. Each horizontal text line is made

up of one or more TBKs, and no horizontal TBK con-

tains text across multiple lines. But TBKs in the NBT

text could span across multiple lines, which are either

vertical or diagonal, speciﬁed by webkit-transform ro-

tations, which rotates the text box around the center

of the text box. For example, the background text of

“Unpublished working draft” and “Not for distribu-

tion” on certain documents are two diagonal TBKs

on top of BT text.

(4) Text-block Structure. Each TBK is speciﬁed

by exactly eleven classes of features, where each fea-

ture class consists of one or more features, including

starting point (x,y) relative to the starting point of its

parent, height, font size, font style, font color, and

word spacing. Enclosed in TBK are text and addi-

tional spacing between words. A TBK ends either at

the end of a line or at the beginning of a subscript, a

superscript, and a citation.

4 PDFBoT

PDFBoT consists of ﬁve major components: Pre-

processing, Multi-Column Detection, Text Features,

Deep Removal, and BT Alignment & POS-based Re-

moval. Figure 2 depicts the architecture and data ﬂow

diagram of PDFBoT.

4.1 Preprocessing

(1) Address Resolution. On each page in the DOM

tree T

, each object occupies a rectangular area, spec-

iﬁed by the starting point relative to the starting point

of its parent node, and some other formatting features.

The Preprocessing component calculates the absolute

starting point of each object by a breadth-ﬁrst search

of the DOM tree. The starting points of the objects at

the ﬁrst level are already absolute. For each object at

the second level or below, let (x,y) be its relative start-

ing point and (x

) the absolute starting point of its

parent. Then its absolute starting point is determined

by (x

) = (x + x

,y + y

). In what follows, when

we mention a starting point of a TBK, we will mean

its absolute starting point, unless otherwise stated.

Figure 2: PDFBoT architecture and data ﬂow diagram.

(2) Font-size Statistics. This module computes the

frequency of each font size (over the total number of

characters) by traversing each TBK to obtain its font

size and the number of characters in the text it en-

closes. The font size with the highest frequency, de-

noted by BASE FS, is the font size for BT.

(3) Shallow Removal. This module removes all non-

textual objects (images and lines) and all TBKs with

font size beyond the interval

= (BASE FS − ∆

,BASE FS + ∆

where ∆

is a threshold value (e.g., ∆

= 3), or with a

rotated display, which can be checked by its webkit-

transform matrix. Headings, sidings, and footings

tend to have smaller font sizes than BASE FS − ∆

(except page numbers) and so they are removed by

this module.

Remark. The abstract may have a slightly smaller font

size than BASE FS (such as 3 pt smaller as in this pa-

per). Setting an appropriate value of ∆

can resolve

this problem. We may also deal with the abstract

separately, regardless its font size, using the keyword

“Abstract” and the keyword “Introduction” to extract

the abstract.

Extracting Body Text from Academic PDF Documents for Text Mining

237

4.2 Multi-column Detection

Most lines on a given column are aligned ﬂush left,

except that the ﬁrst line in a paragraph may be in-

dented. Start a vertical line sweep on each page from

the left edge to the right-hand edge one pixel at a time.

Let n

(i) denote the number of x-coordinates in the

starting points of TBKs that are equal to i on page p,

where i starts from 0 and ends at W one pixel at a

time, and W is the width of the printable area of the

page (typically just the width of the page). Note that a

TBK does not have coordinates at the right-hand side.

A line is aligned ﬂush left to a column if the x-

coordinate of the starting point of the leftmost TBK in

the line is equal to the x-coordinate of the left bound-

ary of the said column. It is reasonable to assume

that (1) the left boundary of a corresponding column

is at the same x-coordinate on all pages and (2) over

one-half of the lines in any column across all pages

are aligned ﬂush left on each page. We also assume

the following: Let j be the left boundary of a col-

umn. If i is not the left boundary of a column, then

∑

(i) (summing up n

(i) over all pages) is sub-

stantially smaller than

∑

( j).

Proposition 4.1. A document has k columns (k ≥ 1)

iff the function

∑

(i) has exactly k peaks with about

the same values, and the i-th x-coordinate that regis-

ters a peak is the left boundary of the i-th column.

Remarks. (1) Columns may begin at different x-

coordinates for pages that are even or odd numbered.

Just treat pages of even (and odd) numbered as one

document and then Proposition 4.1 applies to them re-

spectively. (2) A two-column layout may have a one-

column layout inserted, such as a one-column abstract

in a two-column academic paper. This can be detected

by checking the locations of TBKs. If most of them

do not match with the x-coordinate for the second col-

umn, then the underlying portion of the text is a single

column. Single-column text is processed in the same

way as the left-column text. (3) A more sophisticated

method is to use a shorter vertical line segment to

cover a sufﬁcient number of lines for sweeping each

time, and move this line segment as a vertical sliding

window.

4.3 Text Features

(1) Line-spacing Statistics. This module lines up

TBKs according to their starting points to form lines

in sequence. Let (x

) and (x

) be the start-

ing points of two text blocks B

and B

, respectively.

Then B

and B

are on the same line iff |y

−y

| ≤ ∆

for a small ﬁxed value of ∆

. The purpose of allowing

a small variation is to make typesetting more ﬂexible

to adjust and beautify the overall layout (e.g., ∆

= 5).

Suppose that they are on the same line, then B

is at

the left-side of B

iff x

< x

. If they are not on the

same line, then B

is on a line above that of B

iff

−y

> ∆

. This gives rise to a Page-Line-TBK tree

structure of depth 2, where the Page node has Lines as

children, and each Line node has one or more TBKs

as children.

The module then computes the gap between every

two consecutive lines in each column and obtains the

frequency for each gap. The most common gap is the

line spacing in the body text, denoted by BASE LS.

(2) Char-TBK Density. This module computes, for

each line L, the number of non-whitespace charac-

ters over the number of TBKs contained in L. Denote

by #Char

and #TBK

, respectively, the number of

non-whitespace characters and the number of TBKs

contained in L. Deﬁne by D

the following density:

= #Char

/#TBK

. Let BASE CBD denote the av-

erage Char-TBK density for the entire document.

4.4 Deep Removal

This module removes NBT text with font sizes within

the range of I

. It is reasonable to assume the fol-

lowing features on a PDF document adhering to con-

ventional formatting styles: (1) Math expressions in

the display mode, text on tables, text of ﬁgures, text

on charts, authors, and afﬁliations are indented by at

least a pixel from the left boundary of the underlying

column. (2) Every sentence ends with a punctuation.

If a sentence ends with a math expression in the dis-

play mode, then the last line of the math expression

must end with a punctuation. (3) The ﬁrst line of text

followed a standalone title is aligned ﬂush left.

(1) Remove Sidings. The BT area on each page is a

rectangular area within which the BT text are printed.

Depending on how the majority of the BT text are dis-

played, the underlying document is of either single

column or multiple columns. A column for printing

the BT text is referred to as a major column. A col-

umn on a side margin (such as the line numbers on

some documents) is referred to as a minor column,

where TBKs are in red boxes. It is reasonable to

assume that the width of a major column cannot be

smaller than a certain value Γ

(e.g., Γ

= 1.5 inch

= 144 pixels). It is reasonable to assume that side

margins are symmetrical. Namely, in the printable

area, the width of the left margin is the same as that

of the right-hand margin. Without loss of generality,

assume that the width of a side margin is less than Γ

Most documents have either one major-column or two

major-columns. For a magazine layout, three major-

columns may also be used. For example, the layout

KDIR 2020 - 12th International Conference on Knowledge Discovery and Information Retrieval

238

of this submission is of two columns.

Proposition 4.2. Let k be the number of columns (as

detected by line sweeping as in Proposition 4.1). Let

denote the width of a side margin. Initially, set

← x

, the x-coordinate of the left boundary of the

ﬁrst column. If k > 1, let x

be the x-coordinate of the

left boundary of the second column. If x

− x

< Γ

then set w

← x

. The BT area is from w

to W −w

where W is the width of the printable area of the page.

Note that if k > 1 and x

− x

< Γ

, then the ﬁrst

column is not a major column. Any TBKs with an x-

coordinate of its starting point less than w

is on the

left margin and any TBKs with an x-coordinate of its

starting point greater than W −w

is on the right-hand

margin. For example, this method removes line num-

bers. On a different formatting we have encountered,

such as on the L

Xtemplate for submitting drafts to

a journal by the IOS Press, a line number is a TBK

with a starting x-coordinate in the left margin, where

the text enclosed is a pair of the same number with a

long whitespace inserted in between that crosses over

the entire BT text from left to right. This pair of num-

bers will also be removed because its starting point is

in the left margin.

(2) Remove References. The simplest way to detect

references is to search for a line that consists of only

one word “References” that is either on the ﬁrst line

of a column or has a larger space than BASE LS. Re-

move everything after (this may remove appendices,

which for our purpose is acceptable). A more sophis-

ticated method is to use the following line-sweeping

method to detect the area of references. by detecting

nested columns within a major column and Proposi-

tion 4.2): Start from one pixel after the left bound-

ary of a major column, sweep the column from left

to right with a vertical line on the entire paper. If a

local peak occurs with the same x-coordinate on con-

secutive lines, each line from the left boundary of the

column to this x-coordinate is either null or a num-

bering TBK. A numbering TBK contains a number

inside. Then any line that has this property is a ref-

erence. To improve detection accuracy, we may also

use a named-entity tagger (Peters et al., 2017) to de-

termine if the text right after a numbering TBK are

tagged as person(s).

(3) Remove Special Lines. Let x

be the x-coordi-

nate of the left boundary of the column that line L

belongs to, and x

be the x-coordinate in the start-

ing point of the leftmost TBK in L. If x

− x

> Γ

for a ﬁxed value of Γ

larger than normal indentation

(e.g., Γ

= 50; normal indentation for a paragraph is

48 pixels or less), then remove L. This module re-

moves most of the math expressions in the display

mode, certain author names and afﬁliations, as well

as text on ﬁgures with the same font size as the BT

text, for in this case the leftmost TBK would have a

large indentation due to the space taken by the y-axis

and a vertical title.

If line L contains a TBK that includes a whites-

pace greater than a certain threshold Γ

(e.g. Γ

50), speciﬁed by a hspani tag, then remove L. It is

evident that such a TBK is NBT.

(4) Remove Lines by Backward Scans and NBT Tests.

The following tests are used in certain combination to

determine NBT text lines.

(a) Line-spacing Test. An NBT line typically

has larger line spacing (gap) from the immediate line

above and from the immediate line below. A line L

passes the line-spacing test If the gap from L to the

immediate line above (if it exists) and the immediate

line below (if it exists) is either too large or too small;

namely, it is beyond an interval

= (BASE LS − Γ

,BASE LS + Γ

)

for a certain threshold Γ

(e.g., Γ

= ∆

= 3).

(b) Char-TBK Density Test. A line L in math ex-

pression in the display mode typically consists of a

larger number of short TBKs because of the presence

of subscripts and superscripts, where each word or

symbol would be by itself a TBK. Thus, the char-TBK

density D

would be much smaller than BASE CBD,

the average Char-TBK density. L passes this test if

< Γ

· BASE CBD for a threshold value of Γ

(e.g., Γ

= 10).

tion test if the rightmost TBK in L does not end with

a punctuation.

(d) Indentation Test. A line L passes the indenta-

tion test if the x-coordinate in the starting point of its

leftmost TBK is greater than that of the left boundary

of the underlying column.

NBT-Tests-based Removal Algorithm. On a given

document, scan text from the line preceding the list of

references and move backward one page at a time to

the ﬁrst line on the ﬁrst page. On each page, scan from

the bottom line in the rightmost column and move

up one line at a time. Once it reaches the top line,

scan from the bottom line in the column on the left

and move up one line at a time. When the top line

on the leftmost column is reached, move backward to

the preceding page and repeat. Let P be a Boolean

variable. Initially, set P ← 0. Scan text lines in the

aforementioned order of traversal. In general, if a line

is kept, then set P to 0. If a line is removed, then set

P to 1, unless otherwise stated.

In particular, do the following during scanning:

(1) If L passes both of the indentation test and the

char-TBK density test, then remove L and set P ← 1.

Extracting Body Text from Academic PDF Documents for Text Mining

239

(2) If P = 0 and L passes the line-spacing test and the

punctuation test, then remove L and set P ← 0. (3)

Otherwise, keep L and set P ← 0.

Rule 1 removes page numbers, authors and afﬁlia-

tions, text on tables, text on ﬁgures, and text on charts

that pass both of the indentation test and the char-

TBK density test. This rule also removes math ex-

pressions in the display mode. It does not remove the

last line of a paragraph because such a line fails the

indentation test. It does not remove a single-sentence

paragraph as long as it is not too short and does not

contain multiple TBKs, for it would defy the small

char-TBK density test. It does not remove a text line

that contains an inline math expression as long as it is

not the ﬁrst line in an indented paragraph.

Rule 2 removes standalone one-line and two-line

titles that are not ended with a punctuation in each line

for the following reason: By assumption, the ﬁrst text

line below a standalone title is aligned ﬂushed left and

so it will not be removed, which means that P = 0 (see

Rule 3). Likewise, this rule also removes captions

without punctuation at the end of each line, if its suc-

cessor line is not removed, which implies that P = 0

(see Item 3 below). This rule does not remove the

last line in a math expression in the display mode for

this line must end with a punctuation by assumption,

which means that P = 1. This ensures that the line

preceding the displayed math expression that doesn’t

end with a punctuation is not removed by this rule.

4.5 BT Alignment & Syntactic Removal

After Deep Removal, PDFBoT aligns BT lines to re-

store sentences and paragraphs without hard breaks.

Recall that lines are formed according to columns.

For each page, BT Alignment starts from the ﬁrst line

in the leftmost column one line at a time and removes

hard breaks within a paragraph until the last line in the

current column. Then it moves to the next column (if

there is any) and repeat the same procedure until the

last line in the last column. In addition to removing

hard breaks within a paragraph, it also needs to take

special care of hyphens at the end of a line and bound-

aries of paragraphs. Removing hyphens at the end of

lines is the easiest way. While this might break a hy-

phenated word into two words, doing so has a minor

impact on our task while having a much larger beneﬁt

of restoring a word. We may also use a dictionary to

determine if a hyphen at the end of a line belongs to a

hyphenated word and keep it if it does.

If a line L meets one of the following three condi-

tions, then it is the ﬁrst sentence of a paragraph: (1)

The gap between L and the immediate line above is

greater than BASE LS + Γ

. (2) The x-coordinate of

the leftmost TBK in L is larger than that of the left-

most TBK in the line immediately above. The rest

is text extraction from each TBK in the order of line

locations. Denote by f

the txt ﬁle from this process.

While Shallow Removal and Deep Removal can

remove most of the NBT-text lines, captions that end

with punctuation could still remain in BT text. To

remove all captions, we use the line-spacing rule to

group lines in a caption in f

into a paragraph. In

this paragraph, the ﬁrst keyword would be one of the

followings: “Table”, “Figure”, “Fig.”, followed by a

string of digits and dot. If the third word in the ﬁrst

line of such a paragraph is not a verb, then this para-

graph is deemed to be a caption. We use an existing

tool (Toutanova et al., 2003) to obtain part-of-speech

(POS) tags for each such paragraph, and remove it ac-

cordingly. Let BT.txt be the output.

Let T

(F) and T

( f

) denote, respectively, the time

complexities of pdf2htmlEX on PDF ﬁle F and POS

tagging on paragraphs starting with “Table”, “Fig-

ure”, or “Fig.” in f

Proposition 4.3. PDFBoT runs in T

(F) + T

( f

) +

O(np) time on an input PDF document F, where n

is the number of pixels in the printable area of a page

and p is the number of pages contained in f generated

by pdf2htmlEX.

4.6 Display Sentences in Colors

An optional component of PDFBoT, sentences may

be colored in the original layout of the HTML repli-

cate by adding appropriate color tags in f . Let B =

i=1

represent the string of character objects of the

BT text, where C

= (c

) with c

being the t

-th

character in the text contained in the b

-th TBK. Let

S = hl

j=1

be the sentence to be highlighted, where

is the i-th character in S. Use a string-matching al-

gorithm to ﬁnd ` such that hC

,...,C

`+|S|−1

i = S. Let

start point = C

and end point = C

`+|S|−1

To color S with a chosen color, change the corre-

sponding elements in f as follows: If start point and

endingpoint are in the same TBK, add all the char-

acters between start point and endingpoint to a new

tag with an appropriate color attribute. Otherwise,

for the start point block, add all the characters after

start point in the block to a new tag with a color at-

tribute; for the endingpoint block, add all the char-

acters before endingpoint in the block to a new tag

with the same color attribute; and wrap all the TBKs

between the start point block and endingpoint block

with a new tag with the same color attribute.

KDIR 2020 - 12th International Conference on Knowledge Discovery and Information Retrieval

240

5 EVALUATION

We evaluate the accuracies of PDFBoT on the fol-

lowing tasks with a given document: (1) Extracting

complete sentences in the BT text. (2) Getting correct

boundaries of paragraphs. (3) Removing text on ta-

bles and ﬁgures. To do so, we ﬁrst need to determine

an evaluation dataset. To the best of our knowledge,

no existing benchmarks are appropriate for evaluating

PDFBoT. Bast and Korzen (Bast and Korzen, 2017)

presented a dataset on PDF articles collected from

arXiv.org, where they worked out a method to gener-

ate texts from the underlying T

Xor L

Xﬁles as the

ground-truth txt ﬁles for evaluating extraction. How-

ever, this dataset does not meet our need for the fol-

lowing reasons: (1) Most of the txt ﬁles do not con-

tain Abstracts of the underlying PDF documents, and

Abstracts are an important part of the BT text. (2)

Some txt ﬁles contain authors and afﬁliations, and

some don’t, resulting in an inconsistency for evalu-

ation. (3) The txt ﬁles treat the text after a math ex-

pression in the display mode as a new paragraph when

it should not be.

We construct a dataset by selecting independently

at random from arXiv.org 100 two-column PDF arti-

cles in the disciplines of biology, computer science,

ﬁnance, physics, and mathematics with the following

statistics on document sizes: (1) the average number

of pages in an article: 8.28; (2) the median number of

pages: 8; (3) the maximum number of pages: 17, and

the minimum number of pages: 4; the standard devi-

ation: 2.94. We manually compare the extracted text

with the text in original academic PDF documents un-

der three categories: sentences, paragraphs, and text

on tables and ﬁgures.

Possible outcomes for sentence and paragraph ex-

tractions are (1) correct, (2) erroneous, and (3) miss-

ing, where “correct” means that the sentences (para-

graphs) extracted are BT text as the way they should

be; “erroneous” for sentences means that either the

sentence extracted is BT text but with an error, re-

ferred to as incomplete, or it should not be extracted

at all, referred to as extra, while “erroneous” for para-

graphs means that the paragraph extracted is BT text

but should not be a paragraph; and “missing” means

that a sentence (paragraph) should be extracted but

isn’t. Correct extraction is true positive (tp), erro-

neous extraction is false positive (fp), and extraction

that is missing is false negative (fn).

Table 1 is the statistics on extractions of sentences

and paragraphs, where Total means the total number

of true sentences and paragraphs, respectively, in the

original articles.

On removing text on tables, ﬁgures, and charts,

Table 1: Statistics on extractions of sentences and para-

graphs, where “Incpl” means incomplete.

Total

Correct Erroneous Missing

(tp) (fp) (fn)

Sentences

19,564 19,158

341 (Incpl)

205 (Extra)

Paragraphs

4,596 4,580 370 19

possible outcomes are (1) removed and (2) remained,

where removed means that the text is correctly re-

moved as it should be and remained means that the

text that should be removed remains. Removed is true

positive and remained is false negative. Since every

text on a table or a ﬁgure/chart should be removed,

there is no false positive. There are 9.469 TBKs on

tables, ﬁgures, and charts in the corpus with 8,986

TBKs correctly removed and 483 TBKs remained.

Table 2 is the statistics of precision, recall, and

F1 score, which are computed individually and then

rounded to the second decimal place, unless otherwise

stated to avoid writing 1.00 due to rounding.

Table 2: Sentence statistics of precision, recall, and F1

score.

Avg Med Max Min Std

Sentences

Precision 0.97 0.98 1 0.92 0.02

Recall 0.999 1 1 0.95 0.01

F1 score 0.99 0.99 1 0.96 0.01

Paragraphs

Precision 0.93 0.93 1 0.70 0.05

Recall 0.99 1 1 0.81 0.03

F1 score 0.96 0.96 1 0.83 0.03

Text on tables/ﬁgures/charts

Precision 0.93 0.93 1 0.70 0.05

Recall 0.99 1 1 0.81 0.03

F1 score 0.96 0.96 1 0.83 0.03

We note that in certain styles, paragraphs are not

indented, but separated by an obvious line of whites-

pace. In this case, a text line that is not a new para-

graph and after a math expression in display mode

could be mistakenly considered as a new paragraph.

Table 3 is the running times incurred, respectively,

by pdf2htmlEX and PDFBoT after pdf2htmlEX gen-

erates a txt ﬁle on a 2015 commonplace laptop Mac-

Book Pro with a 2.7 GHz Dual-Core Intel Core i5

CPU and 8 GB RAM, where MAX represents the

maximum running time in seconds processing a docu-

ment in this dataset, MIN the minimum running time,

Avg the average running time, Med the median run-

ning time, and Std the standard deviation.

Extracting Body Text from Academic PDF Documents for Text Mining

241

Table 3: Running time statistics (in seconds).

Avg Med Max Min Std

pdf2htmlEX 3.00 1.90 13.8 0.80 2.47

PDFBoT 10.3 6.80 106 2.60 12.5

We note that the running time depends on how

complex the content of the underlying document

would be. It would take a substantially longer time

to process if a document contains signiﬁcantly more

math expressions or tables. A total of six documents

each takes longer than 25 seconds for PDFBoT to run.

Checking these documents, we found that they con-

tain a large number of math expressions, tables, or

supplemental materials after the references. The one

extreme outlier that runs 106 seconds on PDFBoT but

only 9.42 seconds on pdf2htmlEX is a 10-page PDF

document. The reason is likely due to complex fea-

tures used to describe the document by pdf2htmlEX.

While generating the HTML ﬁle would not be too

costly, analyzing the CSS3 ﬁles to extract features for

this particular document has taken more time, which

needs to be investigated further. Overall, PDFBoT in-

curs 10.3 seconds on average.

6 CONCLUSIONS AND FINAL

REMARKS

PDFBoT uses certain formatting features, text-

block statistics, syntactic features, the line-sweeping

method, and the backward traversal method to achieve

accurate extraction. PDFBoT is available for public

access at http://dooyeed.com:10080/pdfbot.

While the majority of the academic PDF docu-

ments satisfy the assumptions listed in the paper, it

is not always the case and so some of the extraction

mechanisms could fail. To further improve accuracy

of detecting NBT text, particularly on a document that

violates some of the assumptions, we may explore

deeper features in CSS3 ﬁles in addition to those we

have used. For example, it would be useful to inves-

tigate how to compute the width of a TBK. Neural-

network classiﬁers such as CNN models may also be

explored to identify certain types of NBT text residing

in the BT text area.

REFERENCES

Bast, H. and Korzen, C. (2017). A benchmark and evalua-

tion for text extraction from PDF. In ACM/IEEE Joint

Conference on Digital Libraries (JCDL), pages 1–10.

Clark, C. and Divvala, S. (2015). Looking beyond text:

Extracting ﬁgures, tables, and captions from computer

science paper.

Giles, C. L. (2006). The future of citeseer: Citeseerx.

In F

urnkranz, J., Scheffer, T., and Spiliopoulou, M.,

editors, Knowledge Discovery in Databases: PKDD

2006, pages 2–2, Berlin, Heidelberg. Springer Berlin

Heidelberg.

Luong, M.-T., Nguyen, T. D., and Kan, M.-Y. (2011). Log-

ical structure recovery in scholarly articles with rich

document features. International Journal of Digital

Library Systems (IJDLS), pages 1–23.

Mali, P., Kukkadapu, P., Mahdavi, M., and Zanibbi, R.

(2020). ScanSSD: scanning single shot detector for

mathematical formulas in PDF document images.

Peters, M. E., Ammar, W., Bhagavatula, C., and Power,

R. (2017). Semi-supervised sequence tagging with

bidirectional language models. arXiv preprint

arXiv:1705.00108.

Pfahler, L., Schill, J., and Mori, K. (2019). The search

for equations-learning to identify similarities between

mathematical expressions.

Phong, B. H., Hoang, T. M., and Le, T. (2020). A hy-

brid method for mathematical expression detection in

scientiﬁc document images. IEEE Access, 8:83663–

83684.

Ramakrishnan, C., Patnia, A., Hovy, E., and Burns, G.

(2012). Layout-aware text extraction from full-text

PDF of scientiﬁc articles. Source Code for Biology

and Medicine.

Romary, L. and Lopez, P. (2015). Grobid – information

extraction from scientiﬁc publications. ERCIM News,

100. ffhal-01673305.

Shigarov, A., Mikhailov, A., and Altaev, A. (2016). Con-

ﬁgurable table structure recognition in untagged pdf

documents.

Toutanova, K., Klein, D., Manning, C. D., and Singer, Y.

(2003). Feature-rich part-of-speech tagging with a

cyclic dependency network. In Proceedings of the

2003 conference of the North American chapter of

the association for computational linguistics on hu-

man language technology-volume 1, pages 173–180.

Association for Computational Linguistics.

Wang, L. and Liu, W. (2013). Online publishing via

pdf2htmlEX. TUGboat, 34:313–324.

Wang, L., Wang, Y., Cai, D., Zhang, D., and Liu, X. (2018).

Translating math word problem to expression tree.

pages 1064—-1069.

Yang, H., Aguirre, C. A., Torre, M. F. D. L., Christensen,

D., Bobadilla, L., Davich, E., Roth, J., Luo, L., Theis,

Y., Lam, A., Han, T. Y.-J., Buttler, D., and Hsu, W. H.

(2019). Pipelines for procedural information extrac-

tion from scientiﬁc literature: towards recipes using

machine learning and data science. pages 41–46.

Yildiz, B., Kaiser, K., and Miksch, S. (2005). pdf2table:

A method to extract table information from pdf ﬁles.

pages 1773–1785.

KDIR 2020 - 12th International Conference on Knowledge Discovery and Information Retrieval

242
