Evaluating Cross-lingual Semantic Annotation for Medical Forms

Ying-Chi Lin

1 a

, Victor Christen

1 b

, Anika Groß

2 c

, Toralf Kirsten

3,4 d

Silvio Domingos Cardoso

5,6 e

, C

edric Pruski

5 f

, Marcos Da Silveira

5 g

and Erhard Rahm

1 h

Department of Computer Science, Leipzig University, Germany

Department Computer Science and Languages, Anhalt University of Applied Sciences in Koethen/Anhalt, Germany

Faculty Applied Computer Sciences and Biosciences, Mittweida University of Applied Sciences, Germany

LIFE Research Centre for Civilization Diseases, Leipzig University, Germany

LIST, Luxembourg Institute of Science and Technology, Luxembourg

LRI, University of Paris-Sud XI, France

Keywords:

Cross-lingual Semantic Annotation, Medical Forms, UMLS, Machine Translation.

Abstract:

Annotating documents or datasets using concepts of biomedical ontologies has become increasingly important.

Such ontology-based semantic annotations can improve the interoperability and the quality of data integration

in health care practice and biomedical research. However, due to the restrictive coverage of non-English

ontologies and the lack of comparably good annotators as for English language, annotating non-English doc-

uments is even more challenging. In this paper we aim to annotate medical forms in German language. We

present a parallel corpus where all medical forms are in both German and English languages. We use three

annotators to automatically generate annotations and these annotations are manually veriﬁed to construct an

English Silver Standard Corpus (SSC). Based on the parallel corpus of German and English documents and

the SSC, we evaluate the quality of different annotation approaches, mainly 1) direct annotation using German

corpus and German ontologies and 2) integrating machine translators to translate German corpus and annotate

the translated corpus with English ontologies. The results show that using German ontologies only produces

very restricted results, whereas translation achieves better annotation quality and is able to retain almost 70%

of the annotations.

1 INTRODUCTION

Ontologies are an established means to formally

represent domain knowledge and they are used in-

tensely in the life sciences, in particular to seman-

tically describe or annotate biomedical documents.

Such semantic annotations are helpful to improve

interoperability and the quality of data integration,

e.g., in health care practice and biomedical research

(Hoehndorf et al., 2015). Biomedical annotations can

https://orcid.org/0000-0003-4921-5064

https://orcid.org/0000-0001-7175-7359

https://orcid.org/0000-0002-2684-8427

https://orcid.org/0000-0001-7117-4268

https://orcid.org/0000-0003-2643-9890

https://orcid.org/0000-0002-2103-0431

https://orcid.org/0000-0002-2604-3645

https://orcid.org/0000-0002-2665-1114

also enhance retrieval quality for semantic document

search (Jovanovi

c and Bagheri, 2017). For instance,

PubMed

, the search engine for MEDLINE database,

uses MeSH (Medical Subject Headings) terms to re-

trieve more relevant results. The Text Information Ex-

traction System (TIES)

of University of Pittsburgh

utilizes concepts from the NCI Metathesaurus and

their synonyms to obtain better recall of documents.

Further, using the hierarchy information within the

ontologies can further expand the potential matches.

The TIES has been applied to retrieve clinical data

of the Cancer Genome Atlas (TCGA) dataset and is

able to ﬁnd cases based on the semantic features of

the pathology report.

Annotating data across multiple disconnected

databases using concepts of the same ontologies sup-

PubMed https://www.ncbi.nlm.nih.gov/pubmed

TIES http://ties.dbmi.pitt.edu

Lin, Y., Christen, V., Groß, A., Kirsten, T., Cardoso, S., Pruski, C., Da Silveira, M. and Rahm, E.

Evaluating Cross-lingual Semantic Annotation for Medical Forms.

DOI: 10.5220/0008979901450155

In Proceedings of the 13th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2020) - Volume 5: HEALTHINF, pages 145-155

ISBN: 978-989-758-398-8; ISSN: 2184-4305

145

ports improved data integration. One example is the

German Biobank Alliance (GBA)

. The alliance con-

sists of biobanks from 15 German university hospitals

and two IT expert centres. The aim is to establish uni-

form quality standards and to make their biomaterials

available for biomedical research throughout Europe.

The information about the specimens, such as the di-

agnosis of the patients, are annotated with LOINC

(McDonald et al., 2003) and ICD-10

(World Health

Organization, 2004) codes. A search interface that in-

tegrates these codes allows researchers to extract in-

formation across all biobanks.

We use the term cross-lingual semantic annotation

task to denote the process of assigning concepts of

English ontologies to text segments of non-English

documents. This process is a necessity mainly be-

cause many biomedical ontologies are most well de-

veloped in English while ontologies in other lan-

guages are by far less comprehensive and do not cover

as much knowledge (Schulz et al., 2013; N

eol et al.,

2014b; Starlinger et al., 2017; N

eol et al., 2018 and

as we will also show later in this paper). For instance,

in the release version 2019AA of the Uniﬁed Medi-

cal Language System (UMLS) Metathesaurus, among

the total of 14.6 million terms, 71% of them are in

English, followed by 10% in Spanish. The other lan-

guages, such as French, Japanese or Portuguese, each

covers less than 3% of the total term amounts. In addi-

tion, the tools for annotating non-English biomedical

documents are not as well developed as tools for En-

glish documents (Jovanovi

c and Bagheri, 2017), such

as MetaMap (Aronson and Lang, 2010) or cTAKES

(Savova et al., 2010). For instance, there have been ef-

forts to adapt cTAKES for German corpora but further

improvement is still needed (Becker and B

ockmann,

2016). Overall, before UMLS has been adequately

extended to cover its concepts in non-English and

good quality annotators have been developed, cross-

lingual annotation is the current way to overcome

such deﬁciencies.

LIFE, stands for Leipzig Research Center for Civ-

ilization Diseases and conducts several epidemiolog-

ical studies including LIFE Adult Study (Loefﬂer

et al., 2015) and LIFE Heart Study (Beutner et al.,

2011). The goal of LIFE Adult Study is to investigate

the inﬂuence of genetic, environmental, social and

lifestyle factors on the healthy state of the local popu-

lation in the city of Leipzig, Germany. Since 2005, the

project has recruited more than 10,000 participants.

All participants took part at an extensive core assess-

GBA https://www.bbmri.de

Logical Observation Identiﬁer Names and Codes

International Statistical Classiﬁcation of Diseases:

tenth revision

ment program including structured interviews, ques-

tionnaires, physical examinations, and biospecimen

collection. In this paper, we aim to annotate some

of the medical forms used in the LIFE Adult Study.

Since these LIFE forms are in German and we try

to produce annotations as comprehensively and well-

covered as possible, we decided to tackle the task as a

cross-lingual semantic annotation problem.

In this study, we report different strategies to an-

notate German forms and also investigate the quality

change of using machine translation in such annota-

tion workﬂow. Our work has the following main con-

tributions:

1) We manually build a parallel corpus in both En-

glish and German of medical forms used in a large

epidemiological study.

2) We manually build a Silver Standard Corpus (SSC)

that provides good quality annotations to evaluate

cross-lingual semantic annotation tasks.

3) Based on 1) and 2), we are able to compare the an-

notation quality for using German ontologies on Ger-

man forms versus the use of English ontologies.

4) We also investigate the annotation quality when us-

ing machine translation.

5) While questions in medical forms are typically an-

notated with several concepts we also consider the

special case where questions correspond to a single

concept. We determine a Gold Standard Corpus for

such question-as-concept annotations and provide an

initial evaluation for them.

In the following Section 2 we present related work

on building our SSC and previous studies on cross-

lingual semantic annotations. Section 3 describes

ﬁrstly the parallel corpus and the ontologies we used

for annotation. We then explain the methods used

to build the Silver Standard and the various annota-

tion tasks we applied to annotate non-English medical

forms. In Section 4 we present the SSC. We further

show the results of the various annotation tasks and

compare them to the SSC. Finally, in Section 5 we

summarize our ﬁndings and discuss directions for fu-

ture research.

2 RELATED WORK

Silver Standard Corpus (SSC)

Building a manually annotated Gold Standard Corpus

(GSC) is laborious, costly and needs human exper-

tise. Hence, GSC can only cover a small number of

semantic groups and is limited in the number of doc-

uments (Rebholz-Schuhmann et al., 2011). To over-

come these shortcomings, the construction of Silver

Standard Corpora (SSC) has been proposed. The term

HEALTHINF 2020 - 13th International Conference on Health Informatics

146

”Silver Standard” has been referred to corpora that

are generated using several annotation tools and their

outputs are then harmonized automatically (Rebholz-

Schuhmann et al., 2010; Lewin et al., 2013; Oellrich

et al., 2015).

The ”Collaborative Annotation of a Large Scale

Biomedical Corpus” (CALBC) is one of the ﬁrst

attempts to generate a large-scale automated anno-

tated biomedical SSC (Rebholz-Schuhmann et al.,

2010). The researchers applied four annotation tools

on 150,000 MEDLINE abstracts and the resulting

annotations are included in the ﬁnal SSC based on

their cosine similarity and at least two annotators

agree on the same annotation (2-vote-agreement).

In 2013, an English SSC was developed for the

multilingual CLEF-ER named entity recognition

challenge (Lewin et al., 2013). In total six annotation

tools were used to generate the annotations. The

annotations were chosen with a voting threshold of

3 tools and by applying a centroid algorithm (Lewin

et al., 2012, 2013). Simpler methods were applied in

(Oellrich et al., 2015) where 2-vote-agreement was

used as inclusion criterion by using four annotators

and the annotations have to be exact or partially

matched. To be able to determine the annotation

quality of the cross-lingual annotation tasks, we

also built an English SSC. As in previous works, we

use automatic annotation tools to generate a set of

annotations ﬁrst. But differently, we then manually

veriﬁed the generated annotations. In this way we can

avoid the problem that using voting agreement for

inclusion might only reveal the closeness of the tools

but not necessarily the correctness of the annotations

(Oellrich et al., 2015).

Biomedical Cross-lingual Semantic Annotation

The CLEF (Conference and Labs of the Evaluation

Forum) has hosted several challenges on cross-lingual

annotation of biomedical named entities. The CLEF-

ER 2013 evaluation lab (Rebholz-Schuhmann et al.,

2013) was organized as part of the EU project ”Multi-

lingual Annotation of Named Entities and Terminol-

ogy Resources Acquisition” (MANTRA). The orga-

nizers provided parallel corpora including MEDLINE

titles, EMEA (European Medicines Agency) drug la-

bels and patent claims in English, German, French,

Spanish and Dutch. These documents were annotated

using terms from ten UMLS Semantic Groups, in both

English and non-English concepts. An English SSC

was also prepared by the organizers (Lewin et al.,

2013). The seven systems submitted to the challenge

showed high heterogeneity (Hellrich et al., 2014).

The CLEF-ER 2013 resulted in a small multilin-

gual gold standard corpus (the Mantra GSC) that con-

tains 5530 annotations in the above mentioned ﬁve

languages (Kors et al., 2015) and the QUAERO cor-

pus, a larger GSC with 26,281 annotations in French

eol et al., 2014a). The QUAERO corpus was

used in CLEF eHealth 2015 Task 1b (N

eol et al.,

2015) and 2016 Task 2 (N

eol et al., 2016), the fur-

ther cross-lingual annotation challenges. The best so-

lution in 2015 (Afzal et al., 2015) used the intersec-

tion of two translators, i.e. Google Translator and

Bing Translate, to expand the UMLS terminology into

French. The annotations were generated by a rule

based dictionary lookup system, Peregrine (Schuemie

et al., 2007). The generated annotations went through

several post-processing steps to reduce false positives.

The challenge in 2016 used the same training set as in

2015 but took the test set provided in 2015 as the de-

velopment set. The test set in 2016 was a new one,

hence, the results between the two years cannot be

compared directly. The winning team in 2016 (Cabot

et al., 2016) used ECMT (Extracting Concepts with

Multiple Terminologies) that relies on bag-of-words

and pattern-matching to extract concept. The system

integrates up to 13 terminologies that were translated

into French.

In 2018, Roller et al. (2018) proposed a sequential

concept normalization system that outperformed the

winning teams in the CLEF challenges in 2015 and

2016 in most of the corpora. They use Solr to lookup

concepts sequentially, i.e. the French term to be an-

notated is ﬁrstly searched in the French UMLS, then

the English version of the UMLS and ﬁnally the term

is translated into English using a self-developed neu-

ral translation model for further searching in the En-

glish UMLS. Similar post-processing procedures as

in (Afzal et al., 2015) were also applied.

Most recently, Perez et al. (2019) evaluated two

approaches to annotate Spanish biomedical docu-

ments with concepts in the Spanish UMLS. The

ﬁrst approach integrates a NLP pipeline in the pre-

processing, Apache Lucene for concept indexing and

a word-sense disambiguation component. The sec-

ond approach uses machine translation to obtain En-

glish documents and these documents are annotated

using MetaMap with the same Spanish UMLS sub-

set but the English version. Finally, the generated

English annotations are transferred back to Spanish.

The combination of the results using union of these

two approaches performed best (F-measure of 67.1%)

on the MEDLINE sub-corpus in the Spanish Mantra

GSC. On the other hand, Roller et al. (2018) achieved

69.1% in F-measure on the same sub-corpus.

As mentioned above, machine translators have

been mostly applied to translate the ontologies into

the corresponding language in the cross-lingual anno-

Evaluating Cross-lingual Semantic Annotation for Medical Forms

147

example_1

Page 1

Question Associated UMLS concepts

English Feeling nervous, anxious, or on edge

1 C0027769 nervous

2 C0003467 anxious

3 C3812214 Feeling nervous, anxious or on edge

German Nervosität, Ängstlichkeit oder Anspannung

1 C0027769 Nervosität

2 C0087092 Ängstlichkeit

DeepL nervousness, anxiety or tension

1 C0027769 nervous

2 C0003467 anxious

Figure 1: An example question from the form ”Generalized Anxiety Disorder” in original English, German and after DeepL

translation. The associated UMLS concepts to each version of the question are also presented.

tation tasks (e.g. Hellrich and Hahn, 2013; van Mul-

ligen et al., 2013; Afzal et al., 2015). In contrast to

previous work, we choose to translate the corpus but

not the ontologies. This is mainly because with our

parallel corpus and the advantage of having manually

veriﬁed SSC, we are able to examine the impact on

annotation quality of utilizing machine translators.

3 METHODS

3.1 Corpus and Ontology

The corpus used in this study includes 37 forms and

728 questions in German. These forms were used in

the LIFE Adult Study (see Section 1). We selected

the assessment forms that are available in multiple

languages including English and German or are orig-

inally in English and have been translated into Ger-

man. Hence, we can build a parallel corpus consisting

of forms in both English and German. Some exam-

ples of these forms are the standardized instruments

used in clinical studies such as the Patient Health

Questionnaire (PHQ, Kroenke et al., 2002) and the

form ”Generalized Anxiety Disorder” (GAD-7, L

owe

et al., 2008). Figure 1 shows an example question

from GAD-7 in three different versions: English, Ger-

man and the German-translated version using the ma-

chine translator DeepL (see Section 3.3 for further de-

tail). It also presents the associated UMLS concepts

for each version of the question.

The goal of the annotation task is to ﬁnd as

many annotations as possible per question of a form

so that we can maximize semantic interoperabil-

ity for our corpus. We choose UMLS Metathe-

saurus as ontology source and use three annota-

tion tools, namely MetaMap (Aronson and Lang,

2010), cTAKES (Becker and B

ockmann, 2016) and

AnnoMap (Christen et al., 2015, 2016), to annotate

the forms. UMLS integrates many biomedical ontolo-

gies. We use its version 2017AA which contains 201

source vocabularies with approximately 3.47 million

concepts. For different annotation tasks we utilize dif-

ferent subsets of UMLS as explained in Section 3.3

below.

3.2 The Silver Standard Corpus

The SSC is constructed using the English corpus and

the English version of UMLS. Since UMLS is very

large and not all contained ontologies are relevant, we

select a subset of it to optimize efﬁciency. In a pre-

vious study, Lin et al. (2017) compared the three an-

notators that we also use in this work. The results

showed that cTAKES generates the best recall. Con-

sequently, we use cTAKES to determine a subset of

the UMLS that covers approximately 99% of the an-

notations that were found by using the entire UMLS.

The subset includes 1.03 million concepts from six

ontologies: 1) UMLS Metathesaurus

, 2) MeSH, 3)

NCI Thesaurus, 4) LOINC, 5) SNOMED CT US, and

6) Consumer Health Vocabulary. We call this subset

selected UMLS subset.

We use three tools: MetaMap, cTAKES and

AnnoMap to annotate the English forms with the

selected UMLS subset. A detailed description and

tests of the parameters of these three tools can be

found in our previous publication (Lin et al., 2017).

Since we will manually verify the pre-annotations

produced by the automatic annotators, we set up the

tools in a way that they can produce good recall but

not extremely bad precision. For each annotation can-

didate, MetaMap computes a score considering lin-

guistic metrics and the scores range between 0 and

1000. We use a ﬁltering score of 700 for MetaMap,

i.e. only candidates having scores of more than 700

will be included in the result set. Based on our initial

study, the annotation results using a ﬁltering score 700

also gained better F-measure than those using ﬁltering

scores 800 and 900 (which are subsets of 700). Be-

cause cTAKES tends to return many false positives,

we use longestMatch and without overlap to get the

best precision. With longestMatch setting, we allow

cTAKES to return only the concept with the longest

This is a subset of the UMLS Metathesaurus with the

Root Source Abbreviation (RSAB) as ”MTH”

HEALTHINF 2020 - 13th International Conference on Health Informatics

148

– MetaMap

– cTAKES

– AnnoMap

– DeepL

– Microsoft

Translator

Output

Annotation

mappings

!ℳ

,&'()

…

!ℳ

,&'()

Set of

German forms

…

UMLS

Translated

English forms

…

Machine

translator

Annotator

Figure 2: Workﬂow for cross-lingual semantic annotation using machine translators.

matched span and without overlap avoids the matches

on discontiguous spans.

For AnnoMap, we investigate two conﬁgu-

rations: 1) AnnoMapQuestion that uses whole

questions to ﬁnd matching concepts for annota-

tion and 2) AnnoMapWindow that matches frag-

ments of questions within a deﬁned window size.

AnnoMapQuestion constructs a similarity score from

three string similarity functions: TF/IDF, Trigram and

LCS (longest common substring) similarity. It re-

tains all annotation candidates with a score above

a given threshold δ. For this work we set three

ﬁltering thresholds (δ) of 0.5, 0.6, and 0.7 for the

AnnoMapQuestion. AnnoMapWindow uses Soft

TF/IDF to match words/phrases within a deﬁned win-

dow size. We consider three window sizes of 2, 3,

and 5 words. An annotation is kept if its Soft TF/IDF

similarity is larger than 0.7. A further ﬁltering mecha-

nism in AnnoMap called group-based selection is also

applied to improve precision (Christen et al., 2015).

The annotated results are veriﬁed manually to

build the SSC. The manual veriﬁcation is done by

two human annotators with assistance of a GUI

application for annotation selection (Geistert, 2018).

An annotation is included in the SSC if both human

annotators consented. For the manual selection of the

annotations, we use the following principles:

1. Use the context to select the most appropriate

concept: if there are several concepts assigned to the

same segment of text, choose the one with the most

precise description based on deﬁnition, synonym and

semantic types.

2. If more than one concept ﬁts perfectly to the same

mention, keep all of those concepts: this is the case

when concepts are of different but suitable semantic

types. For instance, for the question ”Shortness

of breath” in the form PHQ, the UMLS concept

with CUI (Concept Unique Identiﬁer) C0013404 of

semantic type ”Sign or Symptom” and C3274920 of

semantic type ”Intellectual Product” are both correct

and are both retained as annotations.

3. If the whole question matches to a UMLS concept,

we also include concepts that match and thus anno-

tate fragments of the question. For example, UMLS

concept C3812214 is named ”Feeling nervous,

anxious or on edge” and corresponds to a whole

question in form GAD-7 (see Figure 1). We call

such concepts questionAsConcept-type annotations

(QaC-annotations) in this paper. In the manual

veriﬁcation process, we not only keep such concepts,

but also the concepts which covers fragments of the

question, e.g. the concepts C0027769 for ”nervous”

and C0003467 for ”anxious”.

We calculate the Inter-Annotator Agreement be-

tween the two human annotators using Cohen’s

Kappa (Cohen, 1960).

3.3 Annotating German Medical Forms

We investigate two approaches to annotate German

forms. Firstly, we explore the feasibility of annotating

the corpus of German forms with the German UMLS.

Secondly, we investigate the annotation of machine-

translated corpora with English UMLS versions.

Using the SSC as the reference mapping, we are able

to comparatively evaluate the annotation quality of

both approaches. We note that the annotation quality

is also inﬂuenced by the translation from the original

English corpus to the German version. However, it

is difﬁcult to quantify this quality change due to the

lack of corresponding subset of German UMLS.

Annotating German Corpus: To annotate the

German corpus, we use all available German on-

tologies in UMLS (German UMLS). They include

1) DMDICD10 (ICD-10), 2) ICPCGER (ICPC),

3) LNC-DE (LOINC), 4) MDRGER (MedDRA),

5) MSHGER (MeSH), 6) DMDUMD (UMDNS)

and 7) WHOGER (WHOART). Since cTAKES and

MetaMap are designed to annotate English corpora,

we use AnnoMapQuestion to annotate the German

corpus. The annotations found by AnnoMapQuestion

are veriﬁed manually to obtain only correct annota-

tions. Further, we use the same method and the same

seven ontologies but in English (German UMLS in

English) to annotate the parallel English corpus to

produce comparable results as to the German corpus.

Evaluating Cross-lingual Semantic Annotation for Medical Forms

149

These annotations are also manually veriﬁed.

Annotation using Machine Translated Corpora:

Figure 2 shows our workﬂow for cross-lingual an-

notation using machine translators. We translate the

German forms using machine translators and annotate

the translated forms using the English UMLS. To be

comparable, we use the same method to annotate the

translated corpora as for the SSC, i.e. use selected

UMLS subset as ontologies and the three annotation

tools with the same parameter settings.

For the selection of suitable machine translators,

we ﬁrst randomly selected 50 questions from our Ger-

man corpus and translated them into English using

ﬁve machine translators: DeepL

, Microsoft Trans-

lator

, Google Translate

, Yandex

and Moses

We manually checked the translated results. The

translators that produced the best translations of a

question (most similar to the original English text)

was graded with one point. Finally, we selected

the best two translators with the highest number of

points for further experiments. They are DeepL and

Microsoft Translator.

Lin et al. (2017) showed that combining anno-

tations generated by three annotators using 2-vote-

agreement (at least found by two of the three anno-

tators) can obtain better F-measure than using single

tools. Hence, we combine the results from MetaMap,

cTAKES, AnnoMapQuestion and AnnoMapWindow

using this method. Further, combining annotation re-

sults using union can improve recall. Hence, we fur-

ther combine the results from the annotators using

union to see how many correct annotations are re-

tained after translation. In addition to combining the

results from the tools, the results from using different

translators can also be combined. For example, Afzal

et al. (2015) took the union of concepts translated by

both Google Translate and Microsoft Bing to achieve

good recall for annotating the QUAERO corpus. Sim-

ilarly, we will consider the combination of DeepL and

Microsoft Translator results using union.

3.4 QuestionAsConcept-type

Annotations

QaC-annotations can be very useful for data integra-

tion applications. For example, to compare the results

of the same question/questionnaire from different re-

search studies, the annotations can be applied in the

https://www.deepl.com/translator

https://www.microsoft.com/en-us/translator/

https://translate.google.com

https://translate.yandex.com

http://www.statmt.org/moses/

372

446

167

330

873

468

467

AnnoMap cTAKES

MetaMap

Figure 3: Number of annotations generated by each an-

notator in the Silver Standard Corpus. The result of

AnnoMap is the union of the results of AnnoMapQuestion

and AnnoMapWindow.

item matching process. Furthermore, cross-country

comparisons can also be possible if questions of dif-

ferent languages can be mapped to the same UMLS

concept. Therefore, we manually built a Gold Stan-

dard Corpus consisting of questionAsConcept-type of

annotations. We ﬁrst identiﬁed the forms that have

such concepts in UMLS based on the AnnoMap re-

sults in the SSC. We then used keywords of the ques-

tions to search the correct QaC-annotations in the

UMLS UTS Metathesaurus Browser

. The questions

with QaC-annotations were included in the GSC. We

then evaluate how the annotators perform on ﬁnding

such QaC-annotations. We again use the same way

we pre-annotate the SSC to annotate these questions

and only the QaC-annotations are counted as true pos-

itive. Further, we also investigate the annotation qual-

ity with machine translators using the same methods

mentioned in Section 3.3.

4 EVALUATION

4.1 The Silver Standard Corpus

In total 12,551 unique annotations are found by three

annotators and eight different settings, i.e. same an-

notation found by several annotators or with differ-

ent settings are counted as a unique annotation. From

those, we identiﬁed 3,123 manually veriﬁed anno-

tations as the Silver Standard. The Inter-Annotator

Agreement (IAA) between the two human annotators

is 93.9 Kappa. Since the annotation principles are

concise and the human annotators only have to decide

if an annotation is correct or not (dichotomous), the

IAA is relatively high. Figure 3 presents the contri-

bution of each annotator in the SSC where the result

of AnnoMap is the union of AnnoMapQuestion and

UMLS Terminology Services https://uts.nlm.nih.gov/

metathesaurus.html

HEALTHINF 2020 - 13th International Conference on Health Informatics

150

Table 1: Annotating German corpus and the original English forms using different UMLS subsets. The annotations are gener-

ated by AnnoMapQuestion with δ = {0.5, 0.6, 0.7} and then manually veriﬁed. German UMLS contains all available German

ontologies in 2017AA UMLS. German UMLS in English are the same ontologies as in German UMLS but the English ver-

sion. The selected UMLS subset is the subset of UMLS that used to build SSC. Hence, the results in the last row equates

to the results of SSC.

Corpus UMLS subset No. of concepts in ontologies No. of annotations

German German UMLS 111,079 81

Original English German UMLS in English 604,452 249

Original English selected UMLS subset 1,031,097 395

AnnoMapWindow. In total, MetaMap contributes the

most (2,138 annotations) while cTAKES the fewest

(1,954 annotations) to the SSC. More than one-fourth

of the annotations in SSC are found by all three

tools (873 annotations, 28.0%). Importantly, approx-

imately one-third of the annotations are only found

by single tools (1,006 annotations, 32.2%). These

annotations would have been missed out if a 2-vote-

agreement was applied for the inclusion in the SSC.

Notably, MetaMap, which is designed for annotation

tasks using UMLS, is able to ﬁnd 467 annotations that

are not found by the other two tools.

Figure 4 shows the number of annotations found

by each annotator in the SSC with respect to the num-

ber of words of the found annotations. The number

of words of an annotation is calculated by averaging

the number of words of its concept name and all its

synonyms. The annotations found by MetaMap are

mostly consisting of less than 2 or 3 words and it can

not ﬁnd any annotations that are longer than 5 words.

The reason of not ﬁnding longer annotations is be-

cause MetaMap splits the input text into phrases ﬁrst

and these phrases are the basic units for the annota-

tion generation. cTAKES is able to ﬁnd annotations

longer than 5 words but relatively few. The results

of AnnoMapWindow on the distribution of number

of annotations against annotation length is similar to

those of cTAKES but AnnoMapWindow is able to

ﬁnd more annotations longer than 5 words. In con-

trast, AnnoMapQuestion generates few short annota-

tions but contributes the most for the annotations with

5 or more words due to its focus to annotate entire

questions.

4.2 Annotating German Corpus

In this section we investigate the annotation results of

the German corpus using German UMLS and com-

pare them to the results from the parallel English cor-

pus. Table 1 shows the number of concepts in the

different UMLS subsets and the number of manually

veriﬁed annotations. In total, 81 correct annotations

are obtained when the 37 German forms are anno-

1000

2000

3000

1 2 3 4 5

No. of words

No. of annotations

AnnoMapQuestion

AnnoMapWindow

cTAKES

MetaMap

Figure 4: Number of annotations generated by each annota-

tor for different number of words of the annotations in the

SSC. Note that no. of words = 1 in x-axis represents the

average word number less than 2 and no. of words = 2 rep-

resents the average word number larger than 2 but less than

3 and so on. No. of words = 5 includes all annotations with

average word number larger than 5.

tated using all UMLS ontologies that are available in

German (German UMLS). Using the same UMLS on-

tologies but in English (German UMLS in English)

to annotate the English corpus produces 249 correct

annotations, i.e., about three times as many as for the

German corpus. This is because the German UMLS

version contains much fewer concepts (111,079) than

those in English version (604,452) despite the restric-

tion to the same set of seven ontologies. Similarly,

German version has only 1/7 number of entries as

in the English version (217,171 vs. 1,463,453). For

instance, the German version of MeSH is translated

from the English version. The main keyword of each

concept is 1:1 translated but the number of synonyms

differ in two languages. Further, many of the de-

scriptions, references and deﬁnitions are not trans-

lated from the original version (DIMDI, 2019). A

further observation is that the German annotations are

mostly short concepts with one or two words and do

not include any QaC-annotations. It indicates that

such concepts do not exist in the German UMLS, as

opposed to the results we see from the respective En-

glish UMLS.

We also annotated the English corpus using the

selected UMLS subset that was used to build the

SSC. Using this subset, we obtained 395 correct an-

notations. This number reveals that the respective

Evaluating Cross-lingual Semantic Annotation for Medical Forms

151

Table 2: Annotation quality by using the translated corpora, DeepL and Microsoft Translator (MT). The results of MetaMap

are obtained using ﬁltering score of 700. The AnnoMapWindow (AnnoMapW) results are from three window sizes 2, 3 and

5 and the AnnoMapQuestion (AnnoMapQ) results are from three similarity thresholds, i.e. δ = {0.5, 0.6, 0.7}. The results

of SSC (in gray) are also presented for comparison. In addition, the annotation quality of the combination of tools using 2-

vote-agreement (2VoteAgree) and union are shown as rows and that of the combination of both translators (union) are shown

in column.

Annotator

Precision Recall F-Measure

SSC DeepL MT union SSC DeepL MT union SSC DeepL MT union

MetaMap 57.2 26.3 24.9 22.7 68.5 40.5 38.9 45.1 62.3 31.9 30.4 30.2

cTAKES 41.5 18.3 16.9 15.9 62.6 36.9 35.7 42.7 49.9 24.5 23.0 23.1

AnnoMapW 23.9 9.5 9.3 8.0 62.6 35.2 32.6 41.5 34.6 15.0 14.4 13.4

AnnoMapQ 36.8 14.3 12.0 11.8 12.6 6.1 4.8 7.5 18.8 8.5 6.9 9.2

2VoteAgree 59.3 25.6 23.7 22.7 71.1 40.0 38.2 46.6 64.7 31.3 29.3 30.6

union 24.9 10.6 10.1 9.3 100.0 58.0 54.1 68.3 39.8 17.9 17.0 16.4

German UMLS subset in English (German UMLS in

English) lacks many of the most relevant ontologies,

such as NCI Thesaurus or SNOMED CT US. There-

fore, it is crucial to include all ontologies in UMLS

that are relevant for a given annotation task.

4.3 Using Machine Translators

In this section we report the annotation results of

using the two selected machine translators, DeepL

and Microsoft Translator. DeepL, which produced

the best translation result in the machine trans-

lator selection process, also performs better than

Microsoft Translator (Table 2). Annotating using

DeepL translated corpus results in better precision

and recall and consequently also the F-measure is bet-

ter. This indicates that using only a small amount of

translated samples (in our case, 50 questions) can al-

ready determine the suitability of a translator. (Meth-

ods described in Section 3.3).

By translating the German corpus into English

and annotate them using the English UMLS, we are

able to ﬁnd more correct annotations than by anno-

tating the German forms directly using the German

UMLS. In contrast to the 81 annotations found us-

ing German corpus by AnnoMapQuestion (reported

in Section 4.2), translating the German forms using

DeepL and Microsoft Translator, AnnoMapQuestion

obtained 190 and 150 correct annotations, respec-

tively (data not shown). Combining the results from

different tools using 2-vote-agreement on the results

from original English corpus (SSC in Table 2) im-

proves precision, recall and F-measure of single tools.

The best single tool result is generated by MetaMap

with F-measure of 62.3% while 2-vote-agreement is

able to achieve 64.7%. Interestingly, this is differ-

ent for the translated corpora where MetaMap alone

produces slightly better results than the combina-

tion 2-vote-agreement. The best F-measure for trans-

lated corpora is obtained by MetaMap using DeepL

(31.9%) and that of the 2-vote-agreement is 31.3%.

The recall results of the row union in Table 2

shows how many annotations are retained from all

tools after translation. In total, 58.0% of the anno-

tations in SSC are retained using DeepL and 54.1%

by using Microsoft Translator and even 68.3% if we

take the union for the two translators. This is a very

promising result and substantially better than using

only one of the annotators or only one of the transla-

tor tools (e.g. MetaMap using DeepL is restricted to

a recall of 40.5%).

The precision results (and as a consequence the F-

measure results) in Table 2 are relatively low when

using the translated forms. However, this is of less

importance if we apply a manual selection and veri-

ﬁcation of the automatically found annotation candi-

dates as we did in building the SSC. With such a man-

ual veriﬁcation, we can ideally achieve a precision for

the translated corpora of 100%. In combination with

the recall of 68.3% this would result in a F-measure

of as good as 81.2%.

4.4 QuestionAsConcept-type

Annotations

Finding questionAsConcept-type of annotations is of

highest priority in terms of meta-anlysis or data in-

tegration across multiple databases. We built a Gold

Standard Corpus that contains 205 questions and 214

QaC-annotations. Since QaC-annotations are deﬁned

to map a whole question, there is deviation in the

number of questions and the number of annotations

in the GSC. The main reason is that there are multi-

ple QaC-annotations that are of different but suitable

semantic types mapped to the same questions.

We then examine the three annotators for their

HEALTHINF 2020 - 13th International Conference on Health Informatics

152

MetaMap

cTAKES

AmW

AmQ(0.5)

AmQ(0.6)

AmQ(0.7)

100

Precision

Recall

F−measure

Figure 5: Annotation quality of three annotators for

QaC-annotations using original English corpus. MetaMap

is with ﬁltering score of 700. AmQ denotes the annotator

AnnoMapQuestion and the numbers in the parentheses in-

dicate the threshold δ used in post-processing. AmW refers

to AnnoMapWindow.

ability to ﬁnd such annotations. Figure 5 shows the

results. AnnoMapQuestion is the most suitable tool

to ﬁnd annotations that have longer text. With the in-

crease of the threshold δ from 0.5 to 0.7, the preci-

sion improves signiﬁcantly (from 50.8% to 82.7%).

On the other hand, the recall results do not vary

much, with 85.6% using δ = 0.5 and 82.3% using

δ = 0.7. As a consequence, the best F-measure,

82.5%, is achieved using δ = 0.7. AnnoMapWindow

is able to ﬁnd 159 QaC-annotations (74.0% recall)

while cTAKES only found 86 (40.0% recall). Since

MetaMap can only annotate short phrases, it only

found 23 QaC-annotations (10.7% recall).

We also investigate the annotation quality on

QaC-annotations if machine translators are involved.

Since AnnoMapQuestion is the most suitable tool,

we report only the best results from it, i.e. with

δ = 0.7 (Figure 6). Again, the results using DeepL

are better than those of Microsoft Translator. Trans-

lation has more impact on recall than on preci-

sion. This might be explained by the fact that even

with AnnoMapQuestion that already considers simi-

larity measures such as trigram, TF/IDF and a LCS

(Longest Common Substring) (Christen et al., 2015),

the change of the wording and the sequence of the

words after translation hinder the annotator to ﬁnd

the correct match. Many true positives have become

false negatives. Using DeepL alone, we are able to

retain only 26.5% recall. Even by combining the

Microsoft Translator results, the recall of the union

can only reach 30.7%.

4.5 Result Summary

The presented evaluation showed that the three con-

sidered annotator tools are able to ﬁnd both concepts

for short phrases (i.e. using MetaMap, cTAKES and

AnnoMapWindow) and also concepts that annotate

100

Precision Recall F−measure

GSC

DeepL

Microsoft

Union

Figure 6: Annotation quality of QaC-annotations using

translated corpora from DeepL, Microsoft Translator and

the union of them. The results of using original English

corpus (GSC) is also shown for reference. Used annotator

is AnnoMapQuestion with δ = 0.7.

whole questions (using AnnoMapQuestion). Based

on a parallel corpus and the determined SSC, we

could evaluate the annotation quality of different an-

notation approaches. We investigated two possible

ways to annotate the German forms, i.e. 1) direct

annotation using German UMLS ontologies and 2)

integrating machine translators into annotation work-

ﬂow. Due to the current restriction on the coverage of

UMLS in other languages than English, direct anno-

tations using the original non-English corpus can only

produce very restricted results. The cross-lingual an-

notation approach provides two advantages. Firstly, it

gives the possibility to use the English version of the

UMLS, which is much more comprehensive than in

other languages. Secondly, one is able to apply many

annotators as most of them are designed to annotate

English corpora. This is a better option than using

just the non-English UMLS, as we have shown in this

study. With translation, we are able to obtain a recall

of 68.3%. This indicates an F-measure of 81.2% is

possible using machine translators.

5 CONCLUSIONS

In this study we present a parallel corpus of medical

forms used in epidemiological study or clinical inves-

tigations. We use three annotators to automatically

generate annotations ﬁrst and then manually veriﬁed

them to build an English SSC. The obtained annota-

tions in the SSC have been integrated into the LIFE

Datenportal

and will be used to enhance the search

function in the future. For future work, we seek to de-

velop further methods to improve the annotation qual-

ity on such cross-lingual annotation tasks. As we have

shown in this study, due to translation the paraphrase

of the questions signiﬁcantly decreases the chance of

annotators to ﬁnd the correct concepts. We will there-

https://ldp.life.uni-leipzig.de

Evaluating Cross-lingual Semantic Annotation for Medical Forms

153

fore include additional semantic matching mechanism

to enhance matching probability and hence to obtain

even better recall and good precision.

ACKNOWLEDGEMENTS

This work is funded by German Federal Min-

istry of Education and Research (BMBF) (grant

031L0026, ”Leipzig Health Atlas”), the German

Research Foundation (DFG) (grant RA 497/22-1,

”ELISA - Evolution of Semantic Annotations”), and

National Research Fund Luxembourg (FNR) (grant

C13/IS/5809134).

REFERENCES

Afzal, Z., Akhondi, S. A., van Haagen, H., van Mulligen,

E. M., and Kors, J. A. (2015). Biomedical concept

recognition in French text using automatic translation

of English terms. In CLEF (Working Notes).

Aronson, A. R. and Lang, F.-M. (2010). An overview of

MetaMap: historical perspective and recent advances.

Journal of the American Medical Informatics Associ-

ation, 17(3):229–236.

Becker, M. and B

ockmann, B. (2016). Extraction of

UMLSr concepts using Apache cTAKES

for Ger-

man language. Studies in Health Technology and In-

formatics, 223:71–76.

Beutner, F., Teupser, D., Gielen, S., Holdt, L. M., Scholz,

M., Boudriot, E., Schuler, G., and Thiery, J. (2011).

Rationale and design of the Leipzig (LIFE) Heart

Study: phenotyping and cardiovascular characteristics

of patients with coronary artery disease. PLoS One,

6(12):e29070.

Cabot, C., Soualmia, L. F., Dahamna, B., and Darmoni, S. J.

(2016). SIBM at CLEF eHealth Evaluation Lab 2016:

Extracting concepts in French medical texts with ecmt

and cimind. In CLEF (Working Notes), pages 47–60.

Christen, V., Groß, A., and Rahm, E. (2016). A reuse-based

annotation approach for medical documents. In Inter-

national Semantic Web Conference, pages 135–150.

Springer.

Christen, V., Groß, A., Varghese, J., Dugas, M., and Rahm,

E. (2015). Annotating medical forms using UMLS. In

International Conference on Data Integration in the

Life Sciences, pages 55–69. Springer.

Cohen, J. (1960). A coefﬁcient of agreement for nominal

scales. Educational and Psychological Measurement,

20(1):37–46.

DIMDI (2019). Medical Subject Headings. In

https://www.dimdi.de/dynamic/de/klassiﬁkationen/weitere-

klassiﬁkationen-und-standards/mesh/.

Geistert, D. (2018). Visualisierung von Annotation - Map-

pings f

ur klinische Formulare. Bachelor’s Thesis,

Universit

at Leipzig, Germany.

Hellrich, J., Clematide, S., Hahn, U., and Rebholz-

Schuhmann, D. (2014). Collaboratively annotating

multilingual parallel corpora in the biomedical do-

main—some MANTRAs. In LREC, pages 4033–

4040.

Hellrich, J. and Hahn, U. (2013). The JULIE LAB

MANTRA System for the CLEF-ER 2013 Challenge.

In CLEF (Working Notes).

Hoehndorf, R., Schoﬁeld, P. N., and Gkoutos, G. V. (2015).

The role of ontologies in biological and biomedical

research: a functional perspective. Brieﬁngs in Bioin-

formatics, 16(6):1069–1080.

Jovanovi

c, J. and Bagheri, E. (2017). Semantic annota-

tion in biomedicine: the current landscape. Journal

of Biomedical Semantics, 8(1):1–18.

Kors, J. A., Clematide, S., Akhondi, S. A., Van Mulligen,

E. M., and Rebholz-Schuhmann, D. (2015). A mul-

tilingual gold-standard corpus for biomedical concept

recognition: the Mantra GSC. Journal of the Ameri-

can Medical Informatics Association, 22(5):948–956.

Kroenke, K., Spitzer, R. L., and Williams, J. B. W. (2002).

The PHQ-15: validity of a new measure for evaluating

the severity of somatic symptoms. Psychosom Med,

64(2):258–66.

Lewin, I., Clematide, S., Forner, P., Navigli, R., and Tu-

ﬁs, D. (2013). Deriving an english biomedical silver

standard corpus for CLEF-ER. University of Zurich.

Lewin, I., Kafkas, S¸., and Rebholz-Schuhmann, D. (2012).

Centroids: Gold standards with distributional vari-

ation. In Proceedings of the Eighth International

Conference on Language Resources and Evaluation

(LREC-2012), pages 3894–3900, Istanbul, Turkey.

European Languages Resources Association (ELRA).

Lin, Y.-C., Christen, V., Groß, A., Cardoso, S. D., Pruski,

C., Da Silveira, M., and Rahm, E. (2017). Evaluat-

ing and improving annotation tools for medical forms.

In Proc. Data Integration in the Life Science (DILS

2017), pages 1–16. Springer.

Loefﬂer, M., Engel, C., Ahnert, P., Alfermann, D., Are-

lin, K., Baber, R., Beutner, F., Binder, H., Br

ahler,

E., Burkhardt, R., et al. (2015). The LIFE-Adult-

Study: objectives and design of a population-based

cohort study with 10,000 deeply phenotyped adults in

Germany. BMC Public Health, 15(1):691.

owe, B., Decker, O., M

uller, S., Br

ahler, E., Schellberg,

D., Herzog, W., and Herzberg, P. Y. (2008). Valida-

tion and standardization of the Generalized Anxiety

Disorder Screener (GAD-7) in the general population.

Medical Care, 46(3):266–274.

McDonald, C. J., Huff, S. M., Suico, J. G., Hill, G.,

Leavelle, D., Aller, R., Forrey, A., Mercer, K., De-

Moor, G., Hook, J., et al. (2003). LOINC, a universal

standard for identifying laboratory observations: a 5-

year update. Clinical Chemistry, 49(4):624–633.

eol, A., Cohen, K. B., Grouin, C., Hamon, T., Lavergne,

T., Kelly, L., Goeuriot, L., Rey, G., Robert, A., Tan-

nier, X., and Zweigenbaum, P. (2016). Clinical infor-

mation extraction at the CLEF eHealth Evaluation lab

2016. CEUR Workshop Proceedings, 1609:28–42.

HEALTHINF 2020 - 13th International Conference on Health Informatics

154

eol, A., Dalianis, H., Velupillai, S., Savova, G., and

Zweigenbaum, P. (2018). Clinical natural language

processing in languages other than English: opportu-

nities and challenges. Journal of Biomedical Seman-

tics, 9(1):12.

eol, A., Grosjean, J., Darmoni, S. J., Zweigenbaum, P.,

et al. (2014a). Language resources for French in the

biomedical domain. In LREC, pages 2146–2151.

eol, A., Grouin, C., Leixa, J., Rosset, S., and Zweigen-

baum, P. (2014b). The QUAERO French medical cor-

pus: A ressource for medical entity recognition and

normalization. In In Proc BioTextM, Reykjavik. Cite-

seer.

eol, A., Grouin, C., Tannier, X., Hamon, T., Kelly, L.,

Goeuriot, L., and Zweigenbaum, P. (2015). CLEF

eHealth Evaluation Lab 2015 Task 1b: Clinical named

entity recognition. In CLEF (Working Notes).

Oellrich, A., Collier, N., Smedley, D., and Groza, T.

(2015). Generation of silver standard concept anno-

tations from biomedical texts with special relevance

to phenotypes. PloS one, 10(1):e0116040.

Perez, N., Accuosto, P., Bravo,

A., Cuadros, M., Mart

ınez-

Garc

ıa, E., Saggion, H., and Rigau, G. (2019). Cross-

lingual semantic annotation of biomedical literature:

experiments in Spanish and English. Bioinformatics.

Rebholz-Schuhmann, D., Clematide, S., Rinaldi, F.,

Kafkas, S., van Mulligen, E. M., Bui, C., Hellrich,

J., Lewin, I., Milward, D., Poprat, M., et al. (2013).

Entity recognition in parallel multi-lingual biomedical

corpora: The CLEF-ER laboratory overview. In Inter-

national Conference of the Cross-Language Evalua-

tion Forum for European Languages, pages 353–367.

Rebholz-Schuhmann, D., Jimeno-Yepes, A. J., van Mul-

ligen, E., Kang, N., Kors, J., Milward, D., Cor-

bett, P., Buyko, E., Tomanek, K., Beisswanger, E.,

et al. (2010). The CALBC silver standard corpus

for biomedical named entities-a study in harmonizing

the contributions from four independent named en-

tity taggers. Proceedings of the Seventh Conference

on International Language Resources and Evaluation

(LREC’10).

Rebholz-Schuhmann, D., Yepes, A. J., Li, C., Kafkas, S.,

Lewin, I., Kang, N., Corbett, P., Milward, D., Buyko,

E., and Beisswanger, E. (2011). Assessment of NER

solutions against the ﬁrst and second CALBC silver

standard corpus. Journal of Biomedical Semantics,

2(5):1.

Roller, R., Kittner, M., Weissenborn, D., and Leser, U.

(2018). Cross-lingual candidate search for biomedi-

cal concept normalization. CoRR, abs/1805.01646.

Savova, G. K., Masanz, J. J., Ogren, P. V., Zheng, J., Sohn,

S., Kipper-Schuler, K. C., and Chute, C. G. (2010).

Mayo clinical Text Analysis and Knowledge Extrac-

tion System (cTAKES): architecture, component eval-

uation and applications. Journal of the American Med-

ical Informatics Association, 17(5):507–513.

Schuemie, M. J., Jelier, R., and Kors, J. A. (2007). Pere-

grine: Lightweight gene name normalization by dic-

tionary lookup. In Proc of the Second BioCreative

Challenge Evaluation Workshop, pages 131–133.

Schulz, S., Ingenerf, J., Thun, S., and Daumke, P. (2013).

German-language content in biomedical vocabularies.

In CLEF (Working Notes).

Starlinger, J., Kittner, M., Blankenstein, O., and Leser, U.

(2017). How to improve information extraction from

german medical records. it-Information Technology,

59(4):171–179.

van Mulligen, E. M., Bui, Q.-C., and Kors, J. A. (2013).

Machine translation of Bio-Thesauri. In CLEF (Work-

ing Notes).

World Health Organization (2004). ICD-10 : international

statistical classiﬁcation of diseases and related health

problems : tenth revision.

Evaluating Cross-lingual Semantic Annotation for Medical Forms

155
