S3D-R2R: An Automatic Stereoscopic 3D Image Recomposition to

Retargeting Method with Depth Modiﬁcation

Md. Baharul Islam

1,2 a

, Chee Onn Wong

and Md. Kabirul Islam

American University of Malta, Bormla 1013, Malta

Multimedia University, Cyberjaya 63100, Malaysia

Daffodil Int. University, Dhaka 1207, Bangladesh

Keywords:

Disparity, Image Aesthetics, Image Recomposition, Image Retargeting, Image Warping, Stereoscopic

Imaging.

Abstract:

Stereoscopic image adaptation to the target display devices while minimizing the distortion of signiﬁcant fea-

tures and stereoscopic properties is a challenging problem. Conventional methods either fail to preserve the

image context or unable to improve the image aesthetics with improved depth perception in the retargeted

images. In this paper, we present an automatic warping-based stereoscopic 3D image recomposition to retar-

geting method, shortly S3D-R2R that improves the stereo image composition in the retargeting results. Our

S3D-R2R method resizes both the left and right stereo image pair using a global optimization algorithm that

minimizes a set of aesthetic quality errors. These errors are formulated based on the selected photographic

composition rules and modify the depth perception. To improve the depth perception of the stereo image pair,

the disparity consistency has been modiﬁed within the comfort disparity range. Experimental results show

that our automatic method changes the position of the salient object in the target image scale and improves the

depth perception within the comfort depth range. Empirical user studies indicate that our retargeting results

receive more attention than state-of-the-art methods.

1 INTRODUCTION

Due to the rapid growth of 3D display devices, stereo-

scopic 3D image and video contents are widely avail-

able in online. The 3D viewing experience can vary

on different display devices with various aspect ratios

and sizes. Conventional monocular image retarget-

ing methods did not consider the stereoscopic prop-

erties when applied independently to the stereoscopic

left and right image pair. These methods can create

a discomfort 3D viewing experience and may result

the eyestrain and headache. Stereoscopic image retar-

geting requires additional attention for avoiding these

3D fatigues. The naive scaling of the stereoscopic

image distorts the objects shape and can be respon-

sible for the unpleasant 3D viewing experience. The

black box solution wastes the free space of the im-

ages. Stereo cropping (Niu et al., 2012b) utilizes the

cropping operator on both the left and right stereo im-

age based on some selected single and stereo photo-

graphic composition rules. This method works well

https://orcid.org/0000-0002-9928-5776

Figure 1: An example of our S3D-R2R result; (Left to

right) original anaglyph (red-cyan) image with some feature

points (white lines represent the rule of thirds composition),

depth distribution of those feature points in 2D space (L and

R represent the left and right eye view), retargeting result in

our S3D-R2R method (image width reduced by 20%), and

depth distribution of the corresponding feature points.

with the sufﬁcient uninteresting background. How-

ever, image cropping suffers the information loss and

may not be produced a good results when the salient

objects are spread all over the image frame. Besides,

the depth perception can be reduced if it is aggres-

sively cropped-off.

Content-driven warping (Yoo et al., 2013) pre-

served the disparity between the left and right stereo

image pair while object-coherence warping (Lin et al.,

2014) additionally used a shape preservation con-

straint to protect the shape of the salient objects.

Islam, M., Wong, C. and Islam, M.

S3D-R2R: An Automatic Stereoscopic 3D Image Recomposition to Retargeting Method with Depth Modiﬁcation.

DOI: 10.5220/0009170508270834

In Proceedings of the 15th Inter national Joint Conference on Computer Vision, Imaging and Computer Graphics Theor y and Applications (VISIGRAPP 2020) - Volume 4: VISAPP, pages

827-834

ISBN: 978-989-758-402-2; ISSN: 2184-4321

827

However, these methods did not consider the image

aesthetics in the retargeting process. Aesthtics-driven

warping (AWARP) (Islam et al., 2015) proposed to re-

target the stereoscopic image pair based on the photo

composition while preserving the disparity in their re-

sults. Although this method can change the spatial

position of the foreground objects, but it is also de-

sirable to modify depth perception within the comfort

depth zone of poorly taken (particularly, with lower

depth images) stereo photographs by amateurs.

To address this limitation, we propose an auto-

matic, warping-based method that can enhance 3D

viewing experience in the retargeted stereo images

by modifying composition and depth. Our S3D-R2R

method minimizes aesthetic quality errors that are

formulated based on the photo composition using a

global optimization algorithm. The depth modiﬁ-

cation within the comfort depth range is considered

as an optimization problem in our method. Figure

1 shows an example of our retargeting result. The

salient object (bird) changes the optimal position ac-

cording to the rule of third composition. The depth

perception of the selected feature points (marked as

color dots) is also enhanced than the original coun-

terpart. The best view can be used an anaglyph (red-

cyan) glass to perceive the depth information in the

color version.

2 RELATED WORKS

A numerous single image retargeting methods have

been proposed from the last decade. The indepen-

dent application of these methods to the left and right

stereo image pair can easily destroy the stereoscopic

properties that cause eyestrain and headache. The

subjective (Islam et al., 2017) and/or objective evalua-

tion (Ma et al., 2012) of these methods had been con-

ducted. In this section, we only provide a brief sum-

mary of the non-aesthetic and aesthetic-based stereo-

scopic image retargeting, recomposition and depth

enhancement methods.

2.1 Stereoscopic Image Retargeting

Stereo cropping (Zhang et al., 2013) utilized the crop-

ping operator to resize the stereo image pair. This

method ensures to avoid stereoscopic violation. How-

ever, it was responsible to loss the information of

the resized image. Seam carving on stereo image

(Basha et al., 2011) extended the seam carving on

single image retargeting. The seam is a intercon-

nected pixels from top to bottom or left to right in

the image. They remove a pair of seams from both

the left and right stereo image pair for getting the re-

sized stereo image pair. Recently, seam carving also

applied on the stereoscopic video retargeting (Guthier

et al., 2013) that used an additional constraint to main-

tain temporal consistency between two consecutive

video frames. The noticeable features and geometric

distortions are visible in seam carving based methods

due to its discrete nature. A stereo image with large

disparity, shift-map (Qi and Ho, 2013) integrated the

retargeting results with depth adjustment simultane-

ously for reducing the large disparity of the original

images. This method may suffer geometric and se-

mantic distortions in the results.

Continuous methods generally optimize a set of

triangular/quad meshes, subject to a set of constraints.

Content-award methods (Li et al., 2015) used the

monocular warping-based image resizing to stereo-

scopic domain that aims to preserve stereoscopic

properties using two stereoscopic constraints; vertical

alignment for avoiding vertical artifact, and disparity

consistency between the left and right stereo image

pair. Niu et al. (Niu et al., 2012a) proposed an enable

warping to resize a stereo image which has a clear

objective to preserve prominent objects with its 3D

structure. Recently, a warping-based stereo video re-

targeting (Islam et al., 2019) has been proposed that

ensured the temporal consistency between two con-

secutive video frames in the retargeted video.

Scene warping (Lee et al., 2012) decomposed the

given image into several layers according to the depth

orders and each layer is warped according to its own

mesh deformation. The warped layers were then com-

posited together according to depth order to get the

retargeted images. This method ensures object pro-

tection, but it may not able to ensure the semantic

connectedness (e.g. shadow) between the foreground

object and its background environment. Then, se-

mantic preserving warping (Tan et al., 2015) has been

proposed to overcome this limitation. This method

ensured to protect objects, correct depth order, and

semantic connectedness between foreground objects

and its immediate background.

2.2 Recomposition to Retargeting

The unpleasant stereo image (due to poor composi-

tion with lower depth perception) can be aesthetically

pleasing by using the aesthetics-driven stereo image

recomposition to retargeting. An automatic stereo

cropping (Niu et al., 2012b) utilized the cropping op-

erator to recompose both the left and right stereo im-

ages based on the some single and stereoscopic photo-

graphic composition rules. This approach may suffer

content loss and not useful when a single or multi-

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

828

ple objects are spread out a signiﬁcant portion in the

image frame. Then, AWARP (Islam et al., 2015) pre-

served the global image context. Both of the above

methods only allowed for changing the optimal posi-

tion of the salient objects and preserving the disparity

in their results. Due to preserving disparity, the 3D

viewing experience of the retargeting results is sim-

ilar to the original stereo images in these methods.

Recently, a hybrid stereoscopic image recomposition

(Islam et al., 2018) method has been proposed that

not only modify the spatial composition but also depth

remapping.

2.3 Depth Modiﬁcation

The cause behind the visual discomfort and 3D fa-

tigue (e.g. excessive display screen, accommodation

and convergence/divergence mismatch, out of com-

fort depth zone) of stereoscopic images are details

discussed in (Lambooij et al., 2007). Recently, some

promising automatic and interactive depth enhance-

ment methods have been proposed. A warping-based

method (Du et al., 2013) used to change the perspec-

tive of the stereo images through some advanced cam-

era effects such as dolly zoom and wide angle effects.

The shift-map stereo image editing (Yan et al., 2013)

adjusted the depth (especially for images with large

disparity) and preserves the 3D scene structure in their

results. All of these methods only considered to en-

hancing the depth perception without retargeting and

recomposition. 3D Copy&Paste (Lo et al., 2010) is an

end-to-end billboard system that segments the objects

from a source stereo image pair and paste back to the

target stereo image pair while preserves the stereo-

scopic properties. StereoPasting (Tong et al., 2013)

slightly improved the stereo 3D Copy&Paste that did

not require the input stereo image pair. It segments the

foreground objects from a 2D image and then pastes

the segmented objects onto the 3D background scene.

Figure 2: An overview of the comfort depth zone in the

binocular vision system. The object appears in front of the

display device (blue dot rectangle) for negative parallax (red

dot lines) and behind the screen (yellow dot rectangle) for

positive parallax (green dot lines). The brown arcs represent

the comfort depth perception range in human vision system.

3 COMFORT DEPTH ZONE

Due to horizontally separated of the human eyes by

65mm (for adult), they perceive two slightly differ-

ent images (in 2D space) of the same scene from the

left and right view. These two 2D images are fused

into the human brain to perceive the depth informa-

tion. The difference between the left and right im-

age is called binocular disparity. An object can ap-

pear in front and/or behind the screen in the 3D vir-

tual world depending on the nature of disparity (neg-

ative/positive parallax). The human vision system

comfortably perceives a limited amount of depth in-

formation, namely comfort depth zone/range. The

disparity more than human interpupillary distance (65

mm) defuses the left and right view in human brain

and may result discomfort 3D viewing experience and

3D fatigue. The depth perception of the binocular im-

age also depends on the distance between the viewer

and the location of the display device (Mendiburu,

2012). Figure 2 shows the stereoscopic comfort depth

range of the human binocular vision system. The

square is a binocular object, perceived by both left

and right eyes with negative parallax (red dots lines)

on the display device. The object (blue square) can

appear in front of the display device in the 3D vir-

tual world. After shifting the left and right views,

the object (orange square) can appear behind the dis-

play device due to positive parallax on the display

device (green dots lines). The state-of-the-art auto-

matic stereo retargeting methods relocate the salient

objects and preserve the disparity for getting simi-

lar 3D viewing experience as an original stereo im-

age. The object relocation may be not enough for the

aesthetics-driven retargeting, especially for the stereo

image with lower depth perception. In this S3D-R2R

method, we modify the depth perception within the

comfort depth zone with changing the object position.

4 S3D-R2R METHOD

The aim of our S3D-R2R method is to retarget both

left and right stereo images within the target im-

age scale for enhancing image aesthetics and modify

depth perception of the retargeted images. Figure 3

shows an overview of the S3D-R2R method. Given a

stereo image pair, we ﬁrst compute the Sum of Ab-

solute Difference (SAD) between the left and right

stereo image. Then, the triangular meshes are formu-

lated over both the left and right image pair based on

the SAD. In the second stage, we minimize a set of

errors includes warping, aesthetic quality, and stereo

errors, subject to a set of constraints.

S3D-R2R: An Automatic Stereoscopic 3D Image Recomposition to Retargeting Method with Depth Modiﬁcation

829

Figure 3: An overview of our proposed S3D-R2R method. It has mainly two steps: (1) signiﬁcance mesh computation, (2)

warping based minimization of a set of errors, subject to a set of constraints.

4.1 Signiﬁcance Mesh Computation

The SAD between the left, I

and right, I

stereo im-

age pair is calculated using equation 1. Delauney tri-

angular meshes, M

is constructed to represent the

left stereo image I

. We employ the simpliﬁed vi-

sual saliency (Harel et al., 2006) on I

. A pixel with

high saliency value is considered as a signiﬁcant im-

age pixel. The corresponding triangular meshes, M

and saliency to the right image I

is then automati-

cally propagated based on the SAD information. A

set of pixels in a triangle with high saliency is con-

sidered as a signiﬁcant triangle. Figure 2 shows the

signiﬁcant triangular meshes, S

= {s

,...s

} from

∪ M

, where n is the total number of signiﬁcant

triangular meshes. In order to avoid the distortion of

salient objects, the signiﬁcant triangles keep as rigid

as possible during the optimization process.

d =

∑

(x,y)εW



(x,y) − I

(x + i,y + j)



(1)

where (x,y) is representing the pixel location in the

left image I

while (x + i,y + j) is the corresponding

pixels in I

. W is the window size in I

∪ I

4.2 Non-homogeneous Warping

The left and right meshes, M

∪ M

constrain a set

of vertex, V = {v

,...v

}. In the warping process,

the source triangular meshes, M

∪ M

are mapped

to the target meshes

∪

respectively. Let, the

set of triangle meshes T = {t

,...t

}, set of signif-

icant triangles S = {s

,...s

}, and set of objects

O = {o

,...o

}. Ideally, the signiﬁcant triangles

in M

∪ M

could be homogeneously and other trian-

gles could be non-homogeneously scaled along with

x− and/or y−directions without rotation.

4.2.1 Warping Errors

The warping errors consist the scale transformation

and smoothness error. For each triangle tεT , we

perform non-uniform scaling s

and s

in x− and

y−direction, respectively. To avoid the discontinu-

ity between two neighbouring triangles t and s, we

constrain mesh transformation smoothly to the target

mesh,

∪

. The scale transformation, E

and

smoothness error, E

are deﬁned as,

∑

tεT

− G

(2)

∑

t,sεT

− G

(3)

where A

is the area of triangle t,

is the Frobenius

norm, J

is a 2×2 Jacobian matrix that maps a triangle

to its corresponding triangle in the output mesh

∪

, A

= (A

+ A

)/2, and s,t are adjacent triangles.

4.2.2 Recomposition Errors

Employing photographic composition rules to stereo

images can enhance image aesthetics in the retarget-

ing results. We apply two photo composition rules in

our S3D-R2R method. Besides, we also consider the

depth modiﬁcation within the comfort depth range in

the optimization process.

Figure 4: Rule of thirds and visual balance composition;

(Left to right) the rule of thirds composition, four red dots

are representing the power points, unbalanced composition

of two objects (triangle and rectangle), and visually bal-

anced composition.

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

830

Rule of Thirds Error: In this rule, the image frame

is divided by two vertical and two horizontal lines that

create four intersection points, namely power points.

Photographers are encouraged to place the center of

mass of most salient objects on these points. Figure

4 shows the rule of thirds composition. In our S3D-

R2R method, we minimize the distance between the

power point and the center of salient objects. The rule

of thirds error is deﬁned as,

∑

oεO,sεS

− O

(4)

where D

is the power points, O

centroid of objects,

is the area of important triangle s.

Visual Balance Error: The center of the visual mass

of all salient objects should be placed on the image

center that creates harmony between objects. Figure

4 shows an unbalanced and a balanced composition

for two salient objects. The visual balance error, E

is deﬁned as,

∑

oεO

C(I) −C(O)

(5)

where C(I) is the image center, C(O

) is weighted

centroid of salient objects O, and A

is the area of

important triangle s. The visual balance error, E

= 0

for the image with only one object.

4.2.3 Depth Modiﬁcation

The depth perception depends on the disparity and the

distance between the position of the viewers and the

display device (discussed in Section 2.3). Firstly, we

change the disparity from pixel domain to the physical

domain by dividing the pixel density of our display

device. The boundary vertices, B in input meshes,

∪ M

are constrained to the boundary vertices in

the output meshes,

∪

. The number of the opti-

mizable vertices, N = V−B. If the SAD (as disparity)

of a particular vertex vεN is d

, then the average depth

perception, E

is deﬁned as,

∑

vεN

e − d

(6)

= s

(7)

where e is the interpupilary distance between human

eyes, D is the distance between the viewer and the dis-

play device, and s

is the depth modiﬁcation scale. We

set e = 6.5 and D = 100 in our experiment. The com-

fort depth range, R is set to 78 − 140cm (Lambooij

et al., 2007) in the physical domain for the above set-

ting.

4.2.4 Stereoscopic Quality Error

It is required to minimize the changes between the left

and right warped meshes

∪

for avoiding 3D fa-

tigue. Let, (v

) and ( ¯v

, ¯v

) denote the set of the

corresponding vertex of the input meshes M

∪ M

and output meshes,

∪

respectively. For each

vεN, we minimize the changes of vertical alignment

between the left and right meshes,

∪

. The ver-

tical alignment error is deﬁned as,

) =



¯v

(y) − ¯v

(y)



(8)

where (y) refers the y coordinate values in

∪

4.3 Error Minimization

The total error is formulated as the combination of

warping, aesthetic, and stereoscopic quality errors.

= w

+ w

(9)

where w

, and w

are the correspond-

ing weights of warping, aesthetic and stereoscopic

quality errors.

The boundary vertices in M

∪M

keep as bound-

ary vertices in

∪

. For each boundary vertex

vεB of the input mesh M

∪ M

, we apply the bound-

ary position constraint to the left, right, top and bot-

tom border vertices, respectively. The total error func-

tion in Equation 9 is a convex quadratic function. We

utilize the cvx optimization (Grant et al., 2008) to ﬁnd

the solution to the quadratic function. The warping

error weights w

and w

are set to 1 and 0.5, the aes-

thetic error weights w

, w

, and w

are set to 0.5, 0.5

and 0.1, and the vertical alignment weight is set to 1

in our experiment respectively.

5 EXPERIMENTAL RESULTS

Our S3D-R2R method is tested on an Intel i7 CPU,

3.40GHz with 12GB memory. The computation time

is about 2-6 seconds to obtain the recomposition to

retargeting results. The computation time depends on

both left and right triangular meshes and image res-

olution. For a stereoscopic image size 1024 × 681,

the computation time is 5.32s including signiﬁcance

mesh computation prior optimization.

5.1 Retargeting Results

Figure 5 shows the different recomposition to retar-

geting results of two stereo images with single and

S3D-R2R: An Automatic Stereoscopic 3D Image Recomposition to Retargeting Method with Depth Modiﬁcation

831

Figure 5: Different recomposition to retargeting results of our S3D-R2R method to a single and multiple salient objects;

(Row 1, 3) anaglyph (red-cyan) image with some feature points, (Row 2, 4) depth distribution of selected feature points. (Left

to right) original stereo image, recomposition result, recomposition to retargeting results by reducing image width at 20% and

30%, respectively.

multiple salient objects. The original stereoscopic im-

ages are recomposed and retarget by reducing the im-

age width at 20%, and 30% respectively. Our method

relocates the salient objects to an optimal position ac-

cording to the composition rules: rule of thirds and

visual balance. The single salient object (bird) is cap-

tured without following the rule of thirds composi-

tion in the original stereo image. In our recomposi-

tion and retargeting results, the salient object is relo-

cated to the left power points. The depth perception

range is also modiﬁed within the comfort depth range

in our results. The bird in our results is closer to the

viewer position than the original stereo image. Please

refer to the depth distribution of the selected feature

points (color dots). The user can perceive the depth by

wearing an anaglyph (red-cyan) glass in the color ver-

sion. In the second example, the salient objects (two

horses) are visually unbalanced in the original stereo

image. Besides, the depth perception of selected fea-

ture points is also poor (refer the selected feature

points). Our results are visually balanced compared to

the original stereo image. Besides, the depth percep-

tion range is also improved within the comfort depth

range.

Figure 6: Retargeting results with different depth scale s

;

(Left to right) original stereo image, the image width is re-

duced by 20% with s

= 0.01, s

= 0.03, and s

= 0.05

respectively. (Top) anaglyph (red-cyan) image with three

selected feature points, and (bottom) depth distribution of

those feature points.

Figure 6 shows retargeting results with different

depth scale s

. The original anaglyph (red-cyan) im-

age width is reduced by 20%. The salient object

(ﬂower) is appeared in front of the display device of

the original anaglyph (red-cyan) image. Our retarget-

ing result by setting s

= 0.01 slightly improves the

perceive depth range compared than original stereo

image. The ﬂower is appeared closer to the viewer

position at s

= 0.03 and s

= 0.05, respectively. Best

view may perceive by wearing an anaglyph (red-cyan)

glass in the color version.

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

832

5.2 Comparison

We compare our recomposition to retargeting results

with the state-of-the-art non-aesthetic based retarget-

ing methods. Figure 7 shows the comparison of our

method with non-aesthetic based retargeting methods.

The stereo image width is reduced by 20%. Linear

Scaling (LS) destroy the shape of the salient objects

and reduce the depth perception in the resized im-

age. The selected feature points are slightly moved

towards the display device. We recommend readers

either wearing anaglyph (red-cyan) glass or carefully

follow the depth distribution of the selected feature

points. The noticeable objects (two men) distortion

are founded by geometrically consistent seam carv-

ing (Basha et al., 2011). This method may not able

to protect the salient objects due to its discrete na-

ture. The content-driven stereo warping (Yoo et al.,

2013) produces comparative better results than seam

carving. For protecting foreground objects and scene

consistency, semantic-preserving stereo warping (Tan

et al., 2015) has been proposed to ensure the semantic

connectedness between the foreground objects and its

background layers. All these methods didn’t consider

the recomposition of the retargeted images. Besides,

results of the state-of-the-art methods are visually un-

balanced. In our method, the results not only change

the optimal position of the salient objects (two men)

and but also modify the depth perception within the

comfort depth range. The depth distribution of the se-

lected feature points is closer to the viewer than the

state-of-art retargeting methods.

Figure 7: Compare our S3D-R2R result with the state-

of-the-art non-aesthetics based retargeting results. (Top to

bottom) stereoscopic left image, anaglyph (red-cyan) image

with some feature points, and depth distribution of those

feature points. (Left to right) original, linear scaling (LC),

seam carving (SC) (Basha et al., 2011), traditional warping

(WARP) (Yoo et al., 2013), semantic-preserving warping

(TWARP) (Tan et al., 2015), and ours.

In Figure 8, we compare our result with state-of-

the-art automatic aesthetic-driven retargeting results.

Stereo cropping (Niu et al., 2012b) suffers the content

loss. The salient object (climb man) is cropped off

in the retargeting result. The AWARP (Islam et al.,

2015) generates comparatively better results than the

Figure 8: Compare our S3D-R2R method with the state-of-

the-art aesthetics-driven retargeting methods. (Top to bot-

tom) left stereo image, anaglyph (red-cyan) image with se-

lected feature points, depth distribution of the selected fea-

ture points. The image width is reduced by 30%. (Left to

right) original, results of stereo cropping (Niu et al., 2012b),

AWARP (Islam et al., 2015) and ours.

CR and free from loss of information. Both of the

above methods preserve the disparity consistency in

their results. Our method modiﬁes the depth percep-

tion within the comfort depth zone in the retargeted

images. The selected feature points represents the

more depth perception in our result.

5.3 Empirical User Study

Due to subjectivity of stereo image aesthetics, we

conduct two empirical tests in our S3D-R2R method.

We invite 30 independent subjects to compare our re-

sults with the AWARP (Islam et al., 2015). We ob-

serve that all the subjects had prior 3D viewing expe-

rience by watching 3D commercialized movies. We

provide an NVIDIA GeForce 3D shutter glass to the

subject. We test total 18 recomposition (without re-

sizing) and 15 retargeting (through recomposition) re-

sults with single and multiple objects. We randomly

display two sets of stereoscopic 3D images (AWARP,

and our results) side by side and ask the subjects to

pick the best retargeting results.

In our ﬁrst study, we compare our recomposition

results with AWARP. On average, subject’s are pre-

ferred our results over the AWARP method at 17 out

of 18 images (94.44%). For two recomposition re-

sults, 100% subjects prefer our results. In the sec-

ond study, we compare our retargeting results with

AWARP. On average, subject’s prefer our results over

the AWARP method 13 out of 15 images (86.66%).

For two images (image no. 2 and 14 ), the results of

AWARP method are preferred than our results.

S3D-R2R: An Automatic Stereoscopic 3D Image Recomposition to Retargeting Method with Depth Modiﬁcation

833

6 CONCLUSION

In this paper, we present an automatic, recomposition

to retargeting method for stereoscopic images using

a global optimization algorithm, namely S3D-R2R.

To maximize stereo image composition, we minimize

a set of aesthetic quality errors formulated based on

two photo composition rules during the warping pro-

cess. Besides, our method can modify the depth per-

ception in 3D space. It also minimizes the changes the

vertical alignment between the left and right stereo

image pair. Compared to stereo cropping and warp-

ing, our method can better preserve the global im-

age context and able to modify depth perception for

better 3D viewing experiences. The unavoidable fea-

ture distortions are found for the large scale warping,

particularly stereoscopic images with complex/ geo-

metric structures. Moreover, the aspect ratio of the

salient objects can not be protected in our method. A

shape preservation constraint and/or object segmenta-

tion can be used to solve this problem. In the future

work, we would explore the stereoscopic video retar-

geting through recomposition.

REFERENCES

Basha, T., Moses, Y., and Avidan, S. (2011). Geometrically

consistent stereo seam carving. In IEEE International

Conference on Computer Vision (ICCV), pages 1816–

1823.

Du, S.-P., Hu, S.-M., and Martin, R. R. (2013). Chang-

ing perspective in stereoscopic images. IEEE Trans-

actions on Visualization and Computer Graphics,

19(8):1288–1297.

Grant, M., Boyd, S., and Ye, Y. (2008). Cvx: Matlab soft-

ware for disciplined convex programming.

Guthier, B., Kiess, J., Kopf, S., and Effelsberg, W. (2013).

Seam carving for stereoscopic video. In 11th IEEE

IVMSP Workshop, pages 1–4. IEEE.

Harel, J., Koch, C., and Perona, P. (2006). A saliency im-

plementation in matlab.

Islam, M. B., Lai-Kuan, W., and Chee-Onn, W. (2017).

A survey of aesthetics-driven image recomposition.

Multimedia Tools and Applications, 76(7):9517–

9542.

Islam, M. B., Lai-Kuan, W., Chee-Onn, W., and Low, K.-

L. (2015). Stereoscopic image warping for enhancing

composition aesthetics. In 2015 3rd IAPR Asian Con-

ference on Pattern Recognition (ACPR), pages 645–

649. IEEE.

Islam, M. B., Wong, L.-K., Low, K.-L., and Wong, C.-O.

(2018). Aesthetics-driven stereoscopic 3-d image re-

composition with depth adaptation. IEEE Transac-

tions on Multimedia, 20(11):2964–2979.

Islam, M. B., Wong, L.-K., Low, K.-L., and Wong, C. O.

(2019). Warping-based stereoscopic 3d video retarget-

ing with depth remapping. In 2019 IEEE Winter Con-

ference on Applications of Computer Vision (WACV),

pages 1655–1663. IEEE.

Lambooij, M. T., IJsselsteijn, W. A., and Heynderickx, I.

(2007). Visual discomfort in stereoscopic displays: a

review. In Electronic Imaging, pages 64900I–64900I.

International Society for Optics and Photonics.

Lee, K. Y., Chung, C. D., and Chuang, Y. Y. (2012). Scene

warping: Layer-based stereoscopic image resizing. In

Proceedings of the IEEE Computer Society Confer-

ence on Computer Vision and Pattern Recognition,

pages 49–56.

Li, B., Duan, L.-Y., Lin, C.-W., Huang, T., and Gao, W.

(2015). Depth-preserving warping for stereo image

retargeting. IEEE Transactions on Image Processing,

24(9):2811–2826.

Lin, S. S., Lin, C. H., Chang, S. H., and Lee, T. Y. (2014).

Object-coherence warping for stereoscopic image re-

targeting. IEEE Transactions on Circuits and Systems

for Video Technology, 24(5):759–768.

Lo, W.-Y., van Baar, J., Knaus, C., Zwicker, M., and Gross,

M. (2010). Stereoscopic 3D copy & paste.

Ma, L., Lin, W., Deng, C., and Ngan, K. N. (2012). Im-

age retargeting quality assessment: a study of subjec-

tive scores and objective metrics. IEEE Journal of

Selected Topics in Signal Processing, 6(6):626–639.

Mendiburu, B. (2012). 3D movie making: stereoscopic dig-

ital cinema from script to screen. CRC Press.

Niu, Y., Feng, W.-C., and Liu, F. (2012a). Enabling warping

on stereoscopic images. ACM Transactions on Graph-

ics (TOG), 31(6):183.

Niu, Y., Liu, F., Feng, W. C., and Jin, H. (2012b).

Aesthetics-based stereoscopic photo cropping for het-

erogeneous displays. IEEE Transactions on Multime-

dia, 14(3):783–796.

Qi, S. and Ho, J. (2013). Shift-map based stereo image

retargeting with disparity adjustment. In 11th Asian

Conference on Computer Vision (ACCV), pages 457–

469.

Tan, C.-H., Islam, M. B., Wong, L.-K., and Low, K.-

L. (2015). Semantics-preserving warping for stereo-

scopic image retargeting. In Image and Video Tech-

nology, pages 257–268. Springer.

Tong, R.-F., Zhang, Y., and Cheng, K.-L. (2013). Stere-

oPasting: interactive composition in stereoscopic im-

ages. IEEE Transactions on Visualization and Com-

puter Graphics, 19(8):1375–85.

Yan, T., He, S., Lau, R. W., and Xu, Y. (2013). Consistent

stereo image editing. In Proceedings of the 21st ACM

international conference on Multimedia, pages 677–

680. ACM.

Yoo, J. W., Yea, S., and Park, I. K. (2013). Content-Driven

Retargeting of Stereoscopic Images. IEEE Signal Pro-

cessing Letters, 20(5):519–522.

Zhang, F., Niu, Y., and Liu, F. (2013). Making stereo photo

cropping easy. In IEEE International Conference on

Multimedia and Expo (ICME), pages 1–6. IEEE.

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

834
