Human Factors Standards and the Hard Human Factor Problems:

Observations on Medical Usability Standards

Lorenzo Strigini

and Marwa Gadala

Centre for Software Reliability, City, University of London, Northampton Square, London, U.K.

Keywords: Usability, Medical Devices, Usability of Standards, Automation Bias.

Abstract: With increasing variety and sophistication of computer-based medical devices, and more diverse users and

use environments, usability is essential, especially to ensure safety. Usability standards and guidelines play

an important role. We reviewed several, focusing on the IEC 62366 and 60601 sets. It is plausible that these

standards have reduced risks for patients, but we raise concerns regarding: (1) complex design trade-offs that

are not addressed, (2) a focus on user interface design (e.g., making alarms audible) to the detriment of other

human factors (e.g., ensuring users actually act upon alarms they hear), and (3) some definitions and scope

restrictions that may create “blind spots”. We highlight potential related risks, e.g. that clear directives on

“easier to understand” risks, though useful, may preclude mitigating other, more “difficult” ones; but ask to

what extent these negative effects can be avoided by standard writers, given objective constraints. Our critique

is motivated by current research and incident reports, and considers standards from other domains and

countries. It is meant to highlight problems, relevant to designers, standards committees, and human factors

researchers, and to trigger discussion about the potential and limits of standards.

1 INTRODUCTION

Glucose meters, infusion pumps, and radiation

therapy systems are a few of the many computer-

based medical devices becoming increasingly

essential in medical practice. These devices are

evolving from simple, one-function designs to

sophisticated, multi-function abilities; their range of

users is expanding to less skilled users (including

patients); and smaller, more portable devices are

introducing a variety of new use environments.

In the Aggregated Quality Assurance for Systems

(AQUAS) project, which addresses engineering

challenges arising from the inter-dependence

between system safety, security and performance, one

use case concerns extensions to a blood pressure and

neuromuscular transmission monitoring device to

provide closed-loop control of these physiological

parameters via an infusion pump. We were tasked to

explore some human factor issues in the switch from

human to automated control. Of specific interest

were “exceptions” – situations involving extra user

interventions: for instance, scenarios in which a

device fails to perform as specified, or reverts to a

https://orcid.org/0000-0002-4246-2866

https://orcid.org/0000-0002-9148-6522

fallback mode of operation in response to detecting

failures, and/or an alarm requires intervention by a

clinician, and/or a clinician overrides a device

(rightly: e.g. due to a failure, or wrongly: e.g., a user

that mistrusts a device overrides some of its correct

decisions). This focus was linked to our own previous

research, about effects of warnings and so-called

“automation bias” (Alberdi, 2009; Povyakalo, 2013);

many of our examples will be in these areas, but some

observations are of more general relevance.

Our example in the abstract, that for an alarm to

be effective the designer has a responsibility not only

to ensure that it is audible, but that the overall device

design does not make it likely to be ignored, is but

one of a class of problems arising from the complex

interactions between the user, the device and the use

environment. These issues are known, to extents that

vary from references in the popular press to e.g. “cry-

wolf” events (users failing to intervene when they

should, because a high rate of false alarms “trained”

them to ignore alarms), to scientific literature about

“automation bias” (certain human errors becoming

more likely, or new errors being created, by use of

automated devices), “situation awareness”,

766

Strigini, L. and Gadala, M.

Human Factors Standards and the Hard Human Factor Problems: Observations on Medical Usability Standards.

DOI: 10.5220/0009179707660773

In Proceedings of the 13th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2020) - Volume 5: HEALTHINF, pages 766-773

ISBN: 978-989-758-398-8; ISSN: 2184-4305

“complacency” (user inaction when they should

intervene, attributed to users delegating to the

automated alarms their responsibility to monitor for

dangers), etc. A review of medical devices,

considering a subset of such phenomena, suggested

they affected as much as 6-11% of user decisions

(Goddard, 2014). These problems are due not only to

user interface design, but also to factors such as

accuracy of algorithms, user adaptation to the device,

etc. They are also not limited to alarm-emitting

devices but to a range of decision-support devices

providing prompts, warnings, advice, etc.; e.g., in

interpreting ECGs (Tsai, 2003) and screening

mammograms (Povyakalo, 2013).

Our work in AQUAS started with studying how

“exceptions” and security/safety/performance

interactions are covered in a set of human factors

standards that govern medical devices in the

European market: IEC 62366-1:2015 (Application of

Usability Engineering to Medical Devices) and

guidance on its application: IEC 62366-2:2016; IEC

60601-1-6:2010 (General Requirements for Basic

Safety and Essential Performance - Collateral

Standard: Usability), and IEC 60601-1-8:2007

(Collateral Standard: General requirements, tests and

guidance for alarm systems in medical electrical

equipment and medical electrical systems). For

brevity, we refer to these as “European medical

usability standards” or EMUSs.

Usability standards have important roles. They

expose designers to concerns and design principles

produced by the specialist human factors (HF)

community, particularly important for safety. It

seems plausible that these standards have reduced risk

for patients. However, our reading raised concerns,

broader than our initial focus implied, about whether

EMUSs may fail to deliver some benefits. The

following three sections detail concerns about:

complex design trade-offs arising within usability and

between usability and other system attributes; a focus

on user interface design risking relative neglect of

other causes of use errors; and some definitions of

terms and of the scope of the EMUSs that may create

“blind spots”. Last, we discuss challenges in dealing

with these concerns.

2 THE ISSUE OF TRADE-OFFS

The writers of EMUSs appear concerned with the

need to ‘sell’ usability to designers, by explaining its

many advantages (e.g. Section 5.2 of IEC 62366-2).

This is in line with frequent concerns in human

factors circles that technically trained designers may

regard usability as not needing special attention. But

this presentation may end up depicting usability as a

unidimensional quality, with compliance to

prescriptions being a win-win option, without

concern for possible needs for trade-offs. For

example, an important concern about exceptions is

the rate of false positive alarms, which can lead to

inappropriate user action. IEC 60601-1-8 states

“algorithms that determine alarm conditions should

be carefully optimized to provide, on balance, an

overall benefit to patient care” and “should be

designed to minimize the number of false negative

and false positive alarm conditions.” This latter

statement seems to mask: the necessary trade-offs

between rates of false positive and false negative

errors; experience that designers can make alarms

more sensitive, only to find user decisions become

less sensitive; and evidence that the best

sensitivity/specificity combination may vary between

users, suggesting that user-adjustable thresholds may

be advantageous, within constraints. We note that

elsewhere (Section 15.2.5 of the American HE75

standard) false alarms are addressed with a more

balanced approach, which discusses such trade-offs.

It seems dangerous that standards may be read as

reducing usability engineering to a set of design

precautions that will improve design from all

viewpoints. For instance, about different aspects of

usability itself, sometimes improving usability for

certain operations may only be achieved by reducing

it for others; e.g., putting obstacles in the way of

access to functions that change the settings of a device

may be required, for safety, so that more frequently

used features can be used quickly without

accidentally changing the settings.

The EMUSs do highlight some design trade-offs

in the interaction between usability and other system

attributes, such as safety or performance. A good

example (Section 5.1 of IEC 62366-2) is how design

for high performance in user tasks might make a

device safer, as it speeds up urgent therapy, but also

introduce hazards, if critical confirmation steps are

omitted. On the other hand, slow task performance

could “lead a well-meaning user to pass over steps in

a procedure to increase speed of the procedure. This

can result in a higher probability of use error linked

to a potentially unacceptable risk” (IEC 62366-2).

Emphasizing such relationships is important

because usability standards may be intended “to

provide a single easy-to-use source of human factors

design criteria” (Ahlstrom, 2008), separate from other

standards on, for example, safety or security;

however, considering each attribute in isolation can

lead, among other issues, to unidentified hazards.

Human Factors Standards and the Hard Human Factor Problems: Observations on Medical Usability Standards

767

The role of usability towards device safety,

mentioned for example in Section 5.1 of IEC 62366-

2, seems especially important to stress since “the

majority of medical device incident reports can

primarily be attributed to use error” (van der Peijl,

2012) but some designers may consider usability as a

secondary, almost cosmetic attribute: e.g. “keeping

users happy with a user interface”, much less critical

than e.g. “ensuring a pump delivers the correct dose”.

However, as an example, displaying dose limits on a

user interface not only “reduce[s] the burden on

users’ memory and increase[s] their confidence when

programming the pump”, but can also prevent a

harmful dose (IEC 62366-2).

EMUSs do not yet address the relationship

between usability and security, which presents a good

example of necessary trade-offs. Security has

attracted attention because the trend towards greater

integration and connectivity between medical devices

and networks brings benefits, but also security

challenges about patient safety and confidentiality. A

recent report (Francis, 2017) documents medical

devices being targeted by cybercriminals, and that

these attacks are rising. For example, blood gas

analyzers and radiology equipment were found to

offer backdoors into hospital networks allowing

attackers to send patient records to unknown locations

abroad.

HF issues with a need for trade-offs arise in user

authentication. Authentication may be needed to

prevent malicious use of a medical device (FDA,

2018). But requiring user authentication may be a

nuisance for users, especially if required often; may

delay necessary work, and, in emergencies, inhibit a

user’s ability to respond in a timely manner, thus

posing a safety hazard. User authentication in a

medical device is a good example of a many-way

trade-off that cannot be solved by focusing on a single

system attribute; a designer must consider the

interaction between safety, security, performance,

and usability.

Even for the purpose of security alone, trade-offs

arise in that stringent security policies can be self-

defeating if they reduce usability: they encourage

users to circumvent them. For example, users

required to memorise many complex passwords often

respond by sharing passwords, posting them on paper

notes, etc. (Zhang-Kennedy, 2016). These reactions

have prompted the U.S. National Institute of

Standards and Technology to reverse parts of their

previous advice on password policies (Grassi, 2017).

In conclusion, we suggest that usability be

presented as a multi-dimensional attribute, requiring

a balanced understanding of the various trade-offs

between effects of a design decision on multiple

aspects, both within usability and between usability

and other attributes including security.

3 CAUSES OF USE ERRORS AND

RISK OF TUNNEL VISION

An important, recurring term in the EMUSs is use

error, defined as “user action or lack of user action

while using the medical device that leads to a

different result than that intended by the manufacturer

or expected by the user” (IEC 62366-1). The term use

error is chosen over user error or human error to

educate designers to accept responsibility for

usability rather than blaming users: “although human

beings are imperfect, it is inappropriate to blame the

user when problems occur” (IEC 62366-2).

Removing any “blame the user” attitudes seems

indeed important for good design. But current

explanations seem to shift the blame from users to

user interface (UI) designers: this too may cause blind

spots in designers’ vision. UI design is mentioned

frequently both as cause of use errors – “much more

commonly, use errors are the direct result of poor user

interface design” (IEC 62366-1), “user interface

design shortcomings can lead to use errors” (IEC

62366-2) – and as the solution: “usability engineering

is a principle means to reduce [...] risk and improve

patient care by reducing the potential for harmful use

error through enlightened user interface design” (IEC

62366-2). Usability itself is defined as a

“characteristic of the user interface” (IEC 62366-1).

We are concerned that focusing readers’ attention on

user interfaces may come at the cost of neglecting

other, often harder to mitigate and/or more dangerous,

problems in human factors, which we discuss next.

3.1 Beyond User Interface Design

Research and incident reports indicate that thorough

identification of use errors must consider: (1) the

users (e.g. experience, functional state, biases

towards automation), (2) the use environment (e.g.

policies, time constraints, noise), (3) the device

design (e.g., user interface, device reliability, level of

automation) and (4) the complex interactions between

these three components (e.g. automation bias, user

adaptation, complacency). User interface design is

but one player in a web of potential causes of use

error. The EMUSs do mention some non-user

interface related causes of use errors (e.g., Section

6.5.1 and Annex H in IEC 62366-2), but our concern

HEALTHINF 2020 - 13th International Conference on Health Informatics

768

is that the focus on user interface as both a cause of,

and remedy for, use errors, and the relative ease of

prescriptive solutions about it (e.g., display colours,

pitch of auditory alarms) may divert designers’

attention from warnings about non-user interface

related causes, generally not accompanied by

prescriptions. We discuss examples related to

exceptions, close to our own expertise, without any

claim to exhausting the range of problems of interest.

As an illustration of the complex interaction of

various factors to trigger a use error, consider a

scenario where a patient parameter, monitored by a

medical device, reaches a dangerously low level that

warrants immediate user action. To start with, user

action is likely influenced by whether the device

algorithm is designed to detect this danger with high

enough probability. If the device does detect this

danger, the alarm signal needs to be effectively

communicated. However, to prevent a hazardous

situation, it also matters whether, in practice, the

alarm leads to correct user action, with high enough

probability. This may depend on environmental

factors such as whether the user is busy dealing with

other, simultaneous tasks. It is also influenced by

user-related factors such as users’ mental models of

how the device works (IEC 60601-1-10). In turn,

mental models are based on users’ knowledge and

thus depend not only on training but also on users’

previous experience of interaction with the device.

There may well be a need for standards to

emphasise the role of sound user interface design, to

ensure that designers take certain precautions. But

Table 1: Various causes of specific use errors beyond shortcomings in user interface design. All quoted text is from Section

16.3 in IEC 62366-2.

Use Error

User Interface (UI)

Design Shortcomings

Other Possible Causes Not

Related to UI Design

Potential Mitigations Addressing the

Other Possible Causes

“Users fail to

detect a dangerous

increase in heart

rate because alarm

limit is set too high

and users do not

look at medical

device display

because they are

over-reliant on the

alarm system”

“User-adjusted high

and low alarm limits

on a heart-rate monitor

are not continuously

displayed”

(implicit solution:

continuously display

alarm limits)

User chose inappropriate

alarm limits either due to

inexperience or in an

effort to reduce the device

alarm rate which they find

distracting

- Consider how the alarm threshold

(sensitivity/specificity combination) is set

– not just choosing a more/less sensitive

threshold, but also considering default

settings, degrees of freedom by users, and

customization according to certain

attributes such as user ability.

“User ignored a

warning label

telling the user to

disconnect the

patient tube before

turning the medical

device off”

“The medical device

did not require the user

to confirm patient

disconnection before

powering-off”

(implicit solution: add

a verification step to

confirm patient

disconnection before

powering off is

allowed)

User, at the end of a long

medical procedure, is

fatigued and overlooks the

importance of this step.

Or other devices, to which

the user is accustomed,

dictate that equipment

must be turned off before

disconnecting from the

patient.

- Add a verification step to confirm

patient disconnection before powering off

is allowed.

- Redesign the device so that the order of

these operations does not matter.

“User disregarded

a warning symbol

and allowed a

portable medical

device to run out of

battery power”

“The warning symbol

was not sufficiently

attention-getting”

(implicit solution:

make the warning

symbol more

visible/audible to

attract the user’s

attention)

Lack of reaction to an

alarm due to factors such

as “cry wolf”. In other

words, it may not be that a

user did not see/hear the

warning, but that their

experience with the device

has led them to ignore it.

- Ensure that the time between when an

alarm is emitted and when the actual

danger occurs is so chosen as not to cause

users to ignore alarms/delay action, yet

gives them enough time to react.

- During user training, raise awareness

against behaviours such as “cry wolf”.

- Consider potential unwanted interactions

between different alarms, and how to

group/prioritise alarms to reduce them.

Human Factors Standards and the Hard Human Factor Problems: Observations on Medical Usability Standards

769

designers who focus solely on the role of user

interface are likely to overlook other causes of

hazards, and thus fail to address them properly.

Table 1 helps illustrate the danger of such tunnel

vision. The first two columns describe specific use

errors and user interface design shortcomings that

may cause them. They are taken from IEC 62366-2,

with our comments added in italics. We add the third

column to illustrate other plausible, non-user

interface causes of those errors, and the fourth column

for possible remedies against these latter causes.

Table 1 is not meant to deny the role of effective user

interface design, but to help shift the focus, using

concrete examples, emphasizing that:

• some use errors can result from non-UI causes,

• although some of these other causes can be

remedied by the same design mitigations that

address interface design shortcomings (e.g., Row

2), some require different remedies (e.g., Rows 1

and 3). In fact, in Row 3, making the warning

symbol more attention-getting not only does not

address the “cry wolf” phenomena, but may even

exacerbate it.

• mitigation strategies may extend beyond changes

to the user interface and instead address the user

or environment (e.g., Rows 1 and 3).

3.2 Potential Mitigation Strategies

It is useful for standards to mention difficult human

factors issues, but equally important is discussing

how they may be mitigated. Such mitigations may

address: (1) user characteristics (e.g., via effective

training), (2) device properties (e.g., manipulating the

level of automation, adjusting alarms to focus on

hazards that are difficult for unaided users to detect –

i.e., increasing diversity between the device and the

user), and (3) environmental factors (e.g., more

effective policies on device use such as detailing how

best to integrate a device into a user’s workflow)

Importantly, when considering mitigation

strategies, designers will need to consider the effect

of human adaptation to automation– a critical issue

that seems to be left implicit in these standards. The

presence of automation makes people adapt their

working procedures and cognitive processes

(consciously or not) in ways that may, at times,

negatively affect their performance. For instance, a

very reliable alarm system may cause users to adapt

to completely rely on it to detect dangers, which could

result in users failing to react to dangers not alerted

by the device – even dangers that they would have

tackled properly without the alarm system

(Povyakalo, 2013). We note that many adaptations,

even when unintentional, can be defended as

“rational” in that they improve some aspect of

performance, e.g. time or resources. Yet, they may

also increase the risk from use error, even compared

to the unaided user, at least for some category of

situations (the device, while possibly reducing overall

risk, could transfer risks between kinds of situations,

and possibly kinds of patients) (Povyakalo, 2013).

Testing that only incorporates a single, often first-

time, use is unlikely to reveal dangerous effects such

as complacency, overreliance, automation bias, etc.;

instead, these may only become apparent in post-

production testing and evaluation of device logs. We

suggest that it would be advantageous to encourage

such focused post-production evaluation/testing.

To illustrate the significance of human adaptation

on user decisions, consider a clinician’s mental model

of a computer-aided detection (CAD) device for

cancer. Understanding mental models is important in

addressing use errors (e.g., dealing with false prompts

based on a user’s mental model may cause a user to

miss a true prompt in an area habitually known to

have false prompts (Alberdi, 2014). The user may

start with a sceptical view of the CAD device’s

capabilities, but after interacting with the device, find

that it highlights difficult to find masses. This

interaction shapes the user’s understanding of the

device’s capabilities and is also likely to increase the

user’s trust in the device. However, even a single

error may then reverse this trust (Parasuraman, 2010),

which can be difficult to regain (Wiegmann 2002).

The EMUSs state that, “Ideally, an operator’s

mental model can be easily created through

interaction with the [device] or it can be acquired

through explanation from training or the

accompanying documents” (IEC 60601-1-10). But

non-ideal situations may exist in which a correct

mental model is hard to create and maintain. E.g.,

users may easily learn about deterministic functions

of a device from trial use of it, but be unable to

conceptualise how likely some very infrequent error

modes are. The dynamic nature of mental models also

matters: they may change over time and depend on

factors such as number and type of error committed

by the device; it may be useful to alert designers to

possible discrepancies between users’ mental models

and the true abilities of devices. E.g., a study found

that users’ explanations of how a CAD device

behaved were based on false notions of its capability

to detect breast asymmetries (Hartswood, 1997).

Such complexities may prompt designers to

choose a “simple” solution: to give users more

information regarding a device’s capabilities and

algorithms. The difficult question is: exactly how

HEALTHINF 2020 - 13th International Conference on Health Informatics

770

much information? The standards suggest, in a

similar manner to win-win examples presented in

Section 2, that “reporting the false positive and false

negative alarm condition accuracy in a standardized

format allows operators and responsible

organizations to understand the performance of

equipment” (IEC 60601-1-8). But, by the same token,

informing users of these rates can paradoxically lead

to probability matching (users agreeing with the

device at a rate equal to the device’s reliability),

which can result in decreased overall performance

(Wiegmann, 2002). Furthermore, good explanations

of device behaviour can make inaccurate device

advice more convincing and thus increase the chance

of automation bias. Providing too much information

can also lead to unnecessary complexity and

jeopardize users’ acceptance of device advice

(Alberdi, 2014). In conclusion, dealing with users’

mental models by giving users more information is

one example of the difficult trade-off decisions

inherent in the application of most mitigation

strategies for difficult human factors issues.

In concluding Section 3, we note that some of

these difficult HF issues are highlighted in the

aviation domain. The HF standard approved for use

by the Federal Aviation Administration states that

“complacency is a major concern with automation”

(HF-STD-001B). This standard also has relevant

references alerting designers to design decisions that

may promote “complacency and may cause users to

monitor automation with less vigilance”; although

focus is mostly on training users “to recognize

inappropriate uses of an automated device including

automation bias”, instead of improving by adapting

the device.

We note that in a recently proposed amendment to

IEC 60601-1-8 (not yet to be regarded as a standard,

but released for public feedback until January 2019),

new terms, such as “alarm fatigue”, “alarm flood”,

and “nuisance alarm signal”, have been added to

address some of these difficult concepts. We

welcome these recent additions, but reason that to

help designers appreciate the true danger of these

issues, the definitions need to be accompanied with

examples, explanations and potential mitigations.

4 DEFINITIONS, SCOPE AND

RISK OF BLIND SPOTS

Standards try to define precisely concepts they use

and the scope of each rule. But precise definitions

may do harm if they are inappropriate or inconsistent.

We found examples of definitions that, while they

may cause no confusion for an experienced designer

in a safety-aware company, are otherwise liable to

cause similar dangers to those discussed earlier:

missed or mis-prioritized hazards.

4.1 Conceptual Gaps from Definitions

Alarm condition is defined as: “state of the alarm

system when it has determined that a potential or

actual hazardous situation exists for which operator

awareness or response is required” (IEC 60601-1-8).

As noted directly after the definition, this suggests

that an alarm condition can be invalid (a false

positive). However, another note states that an alarm

condition may also be missed (a false negative). But

the definition implies that if the alarm system has not

detected the hazardous situation then the situation is

not an alarm condition. There is a logical

inconsistency. One could think that false negatives

can at least be attributed to an alarm signal; but this

is defined as “type of signal generated by the alarm

system to indicate the presence (or occurrence) of an

alarm condition”, thus excluding false negatives,

when an alarm signal is absent despite there being a

hazard. This could reduce attention to problems like

mode confusion due to lack of a clear alert that a

device entered fallback mode (IEC 60601-1-10); an

error type known to cause accidents.

To be sure, alarm system is defined as “parts of

[..] a medical electrical system that detect alarm

conditions and, as appropriate, generate alarm

signals”: the intended meaning must be that alarm

conditions exist in a device’s environment, rather

than inside it as in the definition of alarm condition.

We note that this inconsistency remains in the current

draft amendment to IEC 60601-1-8.

4.2 Scope: What Is “Abnormal”?

EMUSs are written to assess and mitigate risks

caused by normal use, and to help identify but not

asses or mitigate risks associated with abnormal use

(IEC 60601-1-6); “abnormal use” is defined as

“conscious, intentional act or intentional omission

[...] that is counter to or violates normal use and is

also beyond any further reasonable means of user

interface-related risk control by the manufacturer”

followed by a note that “an intended but erroneous

action that is not abnormal use is considered a type of

use error”. The standards suggest that abnormal use

can be distinguished from normal use through a post-

test interview which establishes whether “the user

understood appropriate use and made a conscious

Human Factors Standards and the Hard Human Factor Problems: Observations on Medical Usability Standards

771

decision to act (or not act) in opposition” (IEC 62366-

1). But this criterion may exclude scenarios that we

(and perhaps the authors of the standard, depending

on how one reads the complex definition) think

should be covered by risk mitigation rules.

For example, consider a device that allows users

to adjust an alarm threshold for some patient

parameters. A user that finds the device’s alarms

dangerously distracting could consciously set wider

alarm thresholds than ideal for a given patient, to

reduce the distraction from spurious alarms (IEC

60601-1-8). Such a conscious (perhaps safety-

motivated) decision is likely a result of design

choices: perhaps too high a false alarm rate (to

achieve high sensitivity), or alarms displayed in a

distracting manner. The user’s conscious,

inappropriate choice of threshold may cause a

hazardous situation where a patient whose parameters

reach a dangerous level goes unnoticed. To

complicate the scenario, such user behaviour is likely

to change over time depending on experience with the

device and factors such as trust in the device. We

think that controlling such risks should be considered

in the usability engineering process. Despite the

“conscious decision to act [...] in opposition”, this

behaviour is not necessarily “beyond any additional

means of risk control by the manufacturers”; careful

consideration of the device’s alarm rate is one way

manufacturers can address this risk.

5 DISCUSSION

In our review of some medical usability standards for

difficult human factor issues (including issues such as

automation bias, complacency, human adaptation,

triggered/unmotivated user interventions, etc.), we

identified a broader set of concerns than our initial

focus implied, regarding: the complex design trade-

offs inherent in usability decisions, a focus on UI

design to the possible detriment of difficult HF issues,

and finally definitions and scope. We highlighted

potential risks but wish here to discuss the possible

challenges in addressing them.

Easy to understand and articulate use-related

hazards are not necessarily the greatest risks, and

dealing with them should not preclude mitigating

other, more obscure use-related hazards (HE75).

Many of our observations above are in the form “this

‘hard’ topic is not fully addressed” followed by “in

fairness, these standards refer to the problem in

various passages, but lack focus or do not give a

coherent warning or approach”. The “obvious”

remedy, “give as much concrete advice about these

issues as about the simpler topics” may however be

difficult because:

• Writing and following prescriptions about known

solutions to well-understood problems is easier

than prescribing a valid approach to complex

problems; and there is a lack of consensus

between researchers about how to address many

of these difficult HF issues.

• Providing practical solutions is not trivial (such as

the dilemma whether to provide users with more

information regarding device capabilities).

• Testing for these issues is difficult; it needs to

incorporate the effect of time on user behaviour,

often requiring post-production analysis, which

may be infeasible and/or expensive.

• Standards need to be simple - many of these

standards are already over 100 pages, contributing

to the “usability paradox of usability standards”

(Ahlstrom, 2008) - but this is difficult to achieve

without neglecting key concepts or masking the

true complexity of issues, as we exemplified in

our discussions.

We nonetheless offer some ideas of possible

improvements for discussion. Regarding how “hard”

issues may be de-emphasised by being only raised in

terms of somewhat vague warnings, a possible

improvement could be to have sections individually

dedicated to them and to proposed solutions, so as to

add emphasis and make it easier for designers to

follow a coherent approach to these problems.

We especially noted some concerns about effects

of time and human adaptation. Possible

improvements could be:

• adding to existing lists of questions that designers

should ask themselves others like: “Does the

device design encourage unnecessary

interventions that may reduce the overall benefit

of the device and/or increase the probability of

hazards?”; “Does the device help users in

situations where help is indeed useful/most

needed (i.e., is there adequate diversity between

the device and the user)?”.

• highlighting the need for post-production analysis

that focuses on identifying risks introduced by

evolving user behaviour and adaptation to

devices.

The easiest problem to solve seems that of

inconsistent definitions or vague restricting

exemptions, although the latter may also be related to

contentious issues of limits to the responsibility and

liability of manufacturers.

As frequent in standards, the scientific

bibliography is rather old, and not necessarily

HEALTHINF 2020 - 13th International Conference on Health Informatics

772

because limited to authoritative or seminal papers.

This highlights the problem of separation between the

standard writing process and large sectors of the

research community that could provide scrutiny of the

scientific basis of prescriptions, if appropriate reward

mechanisms could be organised.

Certainly important to understand is how

standards shape designers’ decisions, focus their

attention, and shift their priorities. Sociological

research seems necessary. This paper is one step

towards addressing challenging human factors

concepts in medical standards.

ACKNOWLEDGEMENTS

We thank Dr. Sebastian Hunt for his insightful advice

to this work. The AQUAS project is funded by

ECSEL JU under grant agreement No 737475. This

paper is derived from an oral presentation at the

Human Factors and Ergonomics European Meeting

held in Nantes, France in October 2019, and we are

grateful for comments received from that audience.

REFERENCES

Alberdi, E., Strigini, L., Povyakalo, A. A., & Ayton, P.

(2009, September). Why are people’s decisions

sometimes worse with computer support?.

In International Conference on Computer Safety,

Reliability, and Security (pp. 18-31). Springer, Berlin,

Heidelberg.

Alberdi, E. P. A., Strigini, L., & Ayton, P. (2014). CAD:

risks and benefits for radiologists’ decision. In Samei,

E., & Krupinski, E. A. (Eds.), The handbook of medical

image perception and techniques (pp 326-330).

Cambridge University Press.

Ahlstrom, V. (2008, September). The usability paradox of

the Human Factors Standard. In Proceedings of the

Human Factors and Ergonomics Society Annual

Meeting (Vol. 52, No. 24, pp. 1994-1998). Sage CA:

Los Angeles, CA: SAGE Publications.

ANSI/AAMI. (2009). Human Factors Engineering –

Design of Medical Devices. (HE75)

FAA. (2016). U.S. Department of Transportation Federal

Aviation Administration. Human Factors Design

Standard. (HF-STD-001B).

FDA. (2018). Content of Premarket Submissions for

Management of Cybersecurity in Medical Devices.

Francis, R. (2017). Hospital devices left vulnerable, leave

patients at risk. Retrieved on June 30, 2019 from

https://www.csoonline.com/article/ 3167911/hospital-

devices-left-vulnerable-leave-patients-vulnerable.html.

Goddard, K., Roudsari, A., & Wyatt, J. C. (2014).

Automation bias: empirical results assessing

influencing factors. International journal of medical

informatics, 83(5), 368-375.

Grassi, P. A., Perlner, R. A., Newton, E. M., Regenscheid,

A. R., Burr, W. E., Richer, J. P., ... & Theofanos, M. F.

(2017). Digital Identity Guidelines: Authentication and

Lifecycle Management [including updates as of 12-01-

2017] (No. Special Publication (NIST SP)-800-63B).

Hartswood, M., Procter, R., Williams, L., Prescott, R., &

Dixon, P. (1997). Drawing the line between perception

and interpretation in computer-aided mammography.

In Proceedings of the First International Conference on

Allocation of Functions (pp. 275-291).

IEC. (2007). The International Electrotechnical

Commission. General Requirements for Basic Safety

and Essential Performance - Collateral Standard:

General requirements, tests and guidance for alarm

systems in medical electrical equipment and medical

electrical systems. (IEC 60601-1-8).

IEC. (2008). The International Electrotechnical

Commission. General Requirements for Basic Safety

and Essential Performance - Collateral Standard:

Requirements for the development of physiologic

closed-loop controllers. (IEC 60601-1-10).

IEC. (2010). The International Electrotechnical

Commission. General Requirements for Basic Safety

and Essential Performance - Collateral Standard:

Usability. (IEC 60601-1-6).

IEC. (2015). The International Electrotechnical

Commission. Application of Usability Engineering to

Medical Devices. (IEC 62366-1).

IEC. (2016). The International Electrotechnical

Commission. Guidance on the Application of Usability

Engineering to Medical Devices. (IEC 62366-2).

Parasuraman, R., & Manzey, D. H. (2010). Complacency

and bias in human use of automation: An attentional

integration. Human factors, 52(3), 381-410.

Povyakalo, A. A., Alberdi, E., Strigini, L., & Ayton, P.

(2013). How to discriminate between computer-aided

and computer-hindered decisions: a case study in

mammography. Medical Decision Making, 33(1), 98-

107.

Tsai, T. L., Fridsma, D. B., & Gatti, G. (2003). Computer

decision support as a source of interpretation error: the

case of electrocardiograms. Journal of the American

Medical Informatics Association, 10(5), 478-483.

van der Peijl, J., Klein, J., Grass, C., & Freudenthal, A.

(2012). Design for risk control: the role of usability

engineering in the management of use-related

risks. Journal of biomedical informatics, 45(4), 795-

812.

Wiegmann, D. A. (2002). Agreeing with automated

diagnostic aids: A study of users' concurrence

strategies. Human Factors, 44(1), 44-50.

Zhang-Kennedy, L., Chiasson, S., & van Oorschot, P.

(2016, June). Revisiting password rules: facilitating

human management of passwords. In 2016 APWG

symposium on electronic crime research (eCrime) (pp.

1-10). IEEE.

Human Factors Standards and the Hard Human Factor Problems: Observations on Medical Usability Standards

773
