Object Tracking using CSRT Tracker and RCNN

Khurshedjon Farkhodov

, Suk-Hwan Lee

and Ki-Ryong Kwon

Dept. of IT Convergence and Applications Engineering, Pukyong National University, South Korea

Dept. of Information Security, Tongmyong University, South Korea

Keywords: Object Tracking, Object Detection, CSRT, Faster RCNN, CSR-DCF, CNN, Opencv, Deep Learning, DNN

Module.

Abstract: Nowadays, Object tracking is one of the trendy and under investigation topic of Computer Vision that

challenges with several issues that should be considered while creating tracking systems, such as, visual

appearance, occlusions, camera motion, and so on. In several tracking algorithms Convolutional Neural

Network (CNN) has been applied to take advantage of its powerfulness in feature extraction that convolutional

layers can characterize the object from different perspectives and treat tracking process from misclassification.

To overcome these problems, we integrated the Region based CNN (Faster RCNN) pre-trained object

detection model that the OpenCV based CSRT (Channel and Spatial Reliability Tracking) tracker has a high

chance to identifying objects features, classes and locations as well. Basically, CSRT tracker is C++

implementation of the CSR-DCF (Channel and Spatial Reliability of Discriminative Correlation Filter)

tracking algorithm in OpenCV library. Experimental results demonstrated that CSRT tracker presents better

tracking outcomes with integration of object detection model, rather than using tracking algorithm or filter

itself.

1 INTRODUCTION

The main goal in this proposed tracking method is to

focus on exact object to track, furthermore because of

the real-time object tracking environment there are

some parameters should be considered, such as

camera movement, distance between object and

camera, and so on. As an object detector Faster R-

CNN have been used after comparing all object

detection methods, for instance Viola-Jones

algorithm: the first efficient face detector (P. Viola

and M. Jones, 2001), much more efficient detection

technique: Histograms of Oriented Gradients (N.

Dalal and B. Triggs, 2005), and from 2012 the deep

learning methods, which is called “Convolutional

Neural Networks” became the gold standard for

image classification after Kriszhevsky's CNN's

performance during ImageNet (A. Krizhevsky, et al.,

2012), While these results are impressive, image

classification is far simpler than the complexity and

diversity of true human visual understanding. A better

approach, R-CNN has been proposed (R. Girshick, et

al., 2013) after CNN realized. R-CNN creates

bounding boxes, or region proposals, using a process

called Selective Search. Later, where further merge of

R-CNN and Fast R-CNN into a single network by

sharing their convolutional features using the recently

popular terminology of neural networks with

“attention” mechanisms, the RPN component tells the

unified network where to look (R. Girshick, 2016). In

this paper, we propose an algorithm that to apply

OpenCV-based CSRT tracker into person detection

and tracking, which we combined with Faster R-CNN

based object detector with the support of OpenCV’s

DNN module and obtained trained object detector

model. With the great afford of deep learning-based

object detection technique that we can easily avoid

target misclassification and lost. Results of proposed

tracking method has gained remarkable outcome, and

tested in a different dataset with single and overlap-

ping images, also the tracking system experimented

with video and real-time sequence and got much

better performance that rather than using tracking

filter without any additional supporter like detector.

This article consists of following sections: our

suggested tracking system structure explained in

system overview section comes with related work.

section 3, the detailed results will be presented which

obtained during the experiments and we also

compared visual value with the conventional methods

performance, conclusion and reference follows as

well.

Farkhodov, K., Lee, S. and Kwon, K.

Object Tracking using CSRT Tracker and RCNN.

DOI: 10.5220/0009183802090212

In Proceedings of the 13th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2020) - Volume 2: BIOIMAGING, pages 209-212

ISBN: 978-989-758-398-8; ISSN: 2184-4305

209

2 RELATED WORKS

2.1 Overview of the Object Detection

Task

Object detection has applications in many areas of

computer vision, including image retrieval and video

surveillance. Variations in position, color, lighting

conditions, size, etc., greatly affect the performance

of the model. Object detection and tracking processes

should be fine-tuned, that depending on what kind of

problem is going to be solved. This is usually

determined by the characteristics of the target. For

instance, detecting vehicles require different

parameters tuning than detecting pedestrians, animals,

or faces, and so on. This feature-based technique

exploits a notable differentiation character of the

objects that taken from 2D pixel information in an

image (Gonzalez, R. C., and Woods, R. E., 2017).

While using feature points of 2D images, such as

color, intensity, background information it is easy

way to identify object from frames if it will not

change the appearance, position, and size as well.

2.2 Faster RCNN Object Detection

Architecture

Faster RCNN is becoming one of the most used and

popular an object detection architecture presented by

R. Girshick, Sh. Ren, K. He and J. Sun in 2015 that

uses Convolutional Neural Network like other

famous detectors, such as YOLO (You Look Only

Once), SSD (Single Shot Detector) and so on. In

general, Faster RCNN composed from three main

part at all that can be managed building object

detection model process. They are: a) convolution

layers; b) region proposal network; c) classes and

bounding boxes prediction (Faster RCNN, n.d.):

2.3 Training Dataset

We have used our own dataset (600 images) for

training (400) and testing (200) process, which has

been collected throughout internet sources, such as

blogs, posts, and so on. The difference between our

dataset apart from other datasets is that our dataset

images taken by drone camera and environment.

Training process speed and time depends on what

kind of CPU and GPU system we have, if our OS has

last version of GPU hardware system that means we

can get training results faster than using CPU system.

If your computer has no supporting hardware

platform or latest GPU system, we recommend you

do not use your computer for other high memory or

performance required processes while training, that

can affect to obtain training outcomes as well as it

could lead your training process to be time consuming.

Training classifier should train until the loss is

consistently below 0.05 or so that the law starts to

plateau out. A total loss graph estimates that while

learning training dataset images it can loss or

misidentify objects by their features, shapes and other

parameters in one average graph performance. The

total loss of training process performance together

with objectiveness loss, which can show us the

objectiveness score (4e-3≈0.004) of the dataset’s

images, to indicate if this box contains an object or

not while training process is given in Figure 1 below:

Figure 1: Performance of the total losses along with

objectiveness loss.

2.4 Proposed Object Tracking Method

The basis of our tracking method taken from the

Discriminative Correlation Filter with Channel and

Spatial Reliability (CSR-DCF) (A. Lukezic, et al.,

2018) tracking algorithm. Moreover, this algorithm has

been implemented in a C++ and integrated into Open

CV library as a DNN (Deep Neural Networks) module

(OpenCV dnn module, n.d.). We proposed a tracking

system that integration of Faster RCNN object

detection as an object detector and OpenCV_CSRT_

tracker as a tracking algorithm for tracking method.

Implemented object tracking process contains two

parts: first is already explained above, training object

classifier and generating object detection model from

training outcome file. From coming frame algorithm

takes blobs and gives it to object detection model to

predict location of object and classify as an object

class. Output predictions of the detection passes to

tracking algorithm to track predicted box of object

class and so on, any other circumstances of object

prediction changes tracker will invoke the object

classifier and restarts process from the beginning.

3 EXPERIMENTAL RESULTS

After finishing 200K times training our dataset we got

BIOIMAGING 2020 - 7th International Conference on Bioimaging

210

our object classifier model and we have tested our

object detection (classifier) model work by applying

images from different open source resources that

accomplishment of our detector demonstrated perfect

results, such as shown in Figure 2. We can see the

remarkable results of object detection model from

different sources; however, the object classifier is not

detecting all objects in frame at once in a section (c)

and accuracy rate is under 100%. While tracking we

may face thousands of positions, location, shape as

well that means it requires more quantity of images

on dataset with different position and environment

object located images to get perfect results.

Nevertheless, with 600 labeled images dataset gave

unusual result after training by Faster RCNN object

classifier model.

a) b) c) d)

Figure 2: Object detection results of the pre-trained Faster

RCNN object classifier: (a) image from internet sources

taken by drone camera; (b, c) picture taken from drone

video sequence; (d) image from VOT2018 dataset.

We have tested our tracking method with different

open source datasets and got good results and

compered with conventional tracker itself. The

experiments show that CSR-DCF tracker algorithm

cannot re-establish object once it gone from current

frame or tracks object not properly and if the shape or

appearance of the tracking object changes in a

noticeable drape tracker can’t track object properly

and consequently it will lose a target. We have tested

this situation on video sequence taken by drone, here

is some result of tested video shown in Figure 3 below:

0 485 981 1242

1611 1696 1854 2106

Figure 3: Qualitative results of conventional (CSR-DCF,

blue) and proposed (FRCNN_CSRT, green) trackers (0,

485, 981,… - frames).

Initially, conventional tracking method

performance was good, it tracked a target properly,

but after some movement of target frame by frame

and changing a foreground/background color of

frame the tracker could not predict properly (given in

1611, 1696, 1854 frames) a new location of target and

position of the maximum in correlation between

backgrounds and image patch features extraction on

position and weight by the channel reliability scores.

Our tracker performance precision (accuracy) has

been calculated by the ability of our tracking model

that to identify only the relevant objects. It is the

percentage of correct positive predictions. Precision

calculation equation given below:

 =



 + 





Here, TP is a True Positive – a correct detection,

detection with intersection over union (IOU ≥

threshold); FP is a False Positive – a wrong detection,

detection with IOU < threshold.

Furthermore, a proposed tracking method has

been tested with several well-known open source

datasets, like OTB (Object Tracking Benchmark),

VOT (Visual Object Tracking), and others. However,

we have compared results in Table 1 with some open

source datasets which conventional method has been

tested and posted as a final approach performance in

several internet blogs. We can see the comparison

results of conventional and proposed tracking

methods in Table 1, where has been tested with three

different open source datasets that the main difference

between two methods is deep learning-based

approach and real time frames per second as well. As

we can see below in the first column of TABLE 1

results of CVRP2013 dataset while conventional

method presents 80 percent accuracy, proposed

method gained 89 percent tracking accuracy

respectively. Furthermore, outcomes of the tested

technique performance can be seen in next two

column with some of systems feature.

Table 1: Comparsion Results.

Tracker

Precision-

CVPR2013

Precision-

OTB100

Precision

-OTB50

Deep

Learning

(Yes/No)

Real

Time

CSR-DCF 0.8 0.733 N Y(13)

Proposed 0.89 0.829 0.81 Y Y(30)

Object Tracking using CSRT Tracker and RCNN

211

4 CONCLUSIONS

In conclusion, we can say that our proposed tracking

method has gained good performance as well as

comparable results. Our trained object classifier

model has showed excellent work by training 200K

times only 400 images for training and 200 images for

testing. In this method we have integrated deep

learning-based object classifier model with CSRT

tracker OpenCV implementation version of CSR-

DCF algorithm with the support of OpenCV DNN

module. We have compared performance of CSR-

DCF tracking algorithm with our integrated tracking

method. Comparison results showed a much better

performance in proposed tracking method that in

tracking process an object classifier gives exact

location of the target in frame with the benefit of pre-

trained object classifier. In the future work we will try

to create CNN tracker that can be work without pre-

trained model.

ACKNOWLEDGEMENTS

This research was supported by the MSIT (Ministry

of Science and ICT), Korea, under the ICT

Consilience Creative program (IITP-2020-2016-0-

00318) supervised by the IITP (Institute for

Information & communications Technology Planning

& Evaluation), and Basic Science Research Program

through the National Research Foundation of Korea

(NRF) funded by the Ministry of Science, ICT &

Future Planning (2016R1D1A3B03931003, No.

2017R1A2B2012456), and Ministry of Trade,

Industry and Energy for its financial support of the

project titled “the establishment of advanced marine

industry open laboratory and development of realistic

convergence content”

REFERENCES

P. Viola and M. Jones, July 13, 2001. “Robust Real-time

Object Detection,” Second international workshop on

statistical and computational theories of vision –

modeling, learning, computing, and sampling,

Vancouver, Canada, IJCV 2001 See pp 1-3.

N. Dalal and B. Triggs, Jun, 2005. “Histograms of Oriented

Gradients for Human Detection,” International

Conference on Computer Vision & Pattern Recognition

(CVPR '05), San Diego, United States. pp.886-893.

A. Krizhevsky, I. Sutskever, Geoffrey E. Hinton, 2012.

“ImageNet Classification with Deep Convolutional

Neural Networks” - Part of: Advances in Neural

Information Processing Systems 25 (NIPS),

DOI: 10.1145/3065386.

R. Girshick, J. Donahue, T. Darrell, and J. Malik,

November 2013. “Rich feature hierarchies for accurate

object detection and semantic segmentation”,

DOI: 10.1109/CVPR.2014.81.

R. Girshick, 6 Jan. 2016. “Faster R-CNN: Towards Real-

Time Object Detection with Region Proposal

Networks,” - Computer Vision and Pattern Recognition

(cs.CV), arXiv:1506.01497 [cs.CV].

Gonzalez, R.C., and Woods, R.E., 2017: Digital Image

Processing. Pearson, 4

edition.

Faster RCNN, https://towardsdatascience.com/faster-rcnn-

object-detection- f865e5ed7fc4

A. Lukezic, T. Vojır, L. C. Zajc, J. Matas, and M. Kristan,

July 2018. “Discriminative Correlation Filter Tracker

with Channel and Spatial Reliability,” International

Journal of Computer Vision: Volume 126, Issue 7, pp

671–688.

OpenCV dnn module, cv::dnn::Net Class Reference,

https://docs.opencv.org/master/db/d30/classcv_1_1dnn

_1_1Net.html

BIOIMAGING 2020 - 7th International Conference on Bioimaging

212
