Homogeneous Ensemble based Support Vector Machine in Breast

Cancer Diagnosis

Bouchra El Ouassif

, Ali Idri

1,2

and Mohamed Hosni

1,3

Software Project Management Research Team, ENSIAS, Mohammed V University, Rabat, Morocco

MSDA, Mohammed VI Polytechnic University, Ben Guerir, Morocco

MOSI, L2M3S, ENSAM-Meknes, Moulay Ismail University, Meknes, Morocco

Keywords: Breast Cancer, Classification, Support Vector Machine (SVM), SVM Ensemble, Combined Kernel.

Abstract: Breast Cancer (BC) is one of the most common forms of cancer and one of the leading causes of mortality

among women. Hence, detecting and accurately diagnosing BC at an early stage remain a major factor for

women's long-term survival. To this aim, numerous single techniques have been proposed and evaluated for

BC classification. However, none of them proved to be suitable in all situations. Currently, ensemble methods

have been widely investigated to help diagnosis BC and consists on generating one classification model by

combining more than one single technique by means of a combination rule. This paper evaluates

homogeneous ensembles whose members are four variants of the Support Vector Machine (SVM) classifier.

The four SVM variants used four different kernels: Linear Kernel, Normalized Polynomial Kernel, Radial

Basis Function Kernel, and Pearson VII function based Universal Kernel. A Multilayer Perceptron (MLP)

classifier is used for combining the outputs of the base classifiers to produce a ﬁnal decision. Four well-known

available BC datasets are used from online repositories. The findings of this study suggest that: (1) ensembles

provided a very promising performance compared to its base, and (2) there is no SVM ensemble with a

combination of kernels that have better performance in all datasets.

1 INTRODUCTION

Breast cancer (BC) remains the leading cause of

mortality among women in many parts of the world.

It is the most common invasive cancer, impacting 2.1

million women each year, and causes the greatest

number of cancer-related deaths among women. The

causes of BC are not fully understood. However,

there are certain factors known to increase the risk

of BC such as, age, genetic mutations, family history

of BC, overweight, late menopause, late age at first

childbirth (Sun et al., 2017). Because of this, it

becomes important to diagnose BC as early as

possible to provide a better chance for proper medical

treatment and to reduce the death rate caused by it

(Sun et al., 2017). When breast tumor is spotted,

physicians will need to find out whether it is Benign

or Malignant. Information technology in form of

computer-aided diagnosis (CAD) that was first

proposed by Johnston (1994), has made great changes

to clinical decision making. In fact, during these last

years , data mining models have been well used in

clinical (Hosni et al., 2019; Idri et al., 2019, 2020;

Kadi et al., 2017), various high-performance models

will help physicians detect and predict medical

situations, and provide a quick and accurate diagnosis

(Topol, 2019). BC is one of the diseases that benefit

from CAD, as well as many new data mining

techniques (Chlioui et al., 2020; Eltalhi & Kutrani,

2019; Oskouei et al., 2017)

Medical diagnosis is considered as an important

and complex task that needs to be carried out

accurately and efficiently. Different classification

techniques have been proposed and evaluated to

classify the breast tumor, using information provided

by the mammography to assist the physician to

accurately diagnosis BC. According to the systematic

map of Idri et al. (Idri et al., 2018), Support Vector

Machine (SVM) was the second most frequently

classification technique used for BC diagnosis with

25.56% of the 403 selected studies (Artificial Neural

Networks were the first with 26.80%). Moreover, it

was observed that the use of SVM for BC diagnosis

is gradually increasing due to its excellent learning

and generalization abilities (Idri et al., 2018). The

main advantage of SVM is its ability to model

352

El Ouassif, B., Idri, A. and Hosni, M.

Homogeneous Ensemble based Support Vector Machine in Breast Cancer Diagnosis.

DOI: 10.5220/0010230403520360

In Proceedings of the 14th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2021) - Volume 5: HEALTHINF, pages 352-360

ISBN: 978-989-758-490-9

complex nonlinear relationships by selecting a

suitable kernel function. Indeed, the Kernel function

transforms the training data so that a non-linear

decision surface is transformed to a linear equation in

a higher number of dimensions.

Identifying the most appropriate Kernel function

to implement SVM in a given context is a challenging

task. In fact, the good choice of the Kernel function

can improve the performance of a SVM based

classification (Bhavsar & Amit Ganatra, 2016;

Trivedi & Dey, 2013). However, few studies in

literature of BC classification have dealt with the

evaluation of the performance of SVM using various

kernel functions (Hussain et al., 2011; Rana et al.,

2019), and generally they used one dataset to assess

the accuracy of their developed models, which does

not allow the findings to be generalized to other

contexts. For instance, (Hussain et al., 2011)

presented a comparative study of different kernel

functions for BC detection; the focus of their study

was on classification using SVM with different kernel

functions; they employed four kernels (RBF,

polynomial, Mahalanobis, and sigmoid) and showed

the performance of each of them. They have

conducted their experiments on the Wisconsin dataset

and they found that SVM with sigmoid kernel showed

the best results. Moreover, they suggested the use of

a combination of different kernels for better detection

results. Rana et al. (Rana et al., 2019) investigated

three machine learning algorithms k-nearest neighbor

(KNN), MLP and SVM. SVM has been investigated

using a linear and quadratic kernel. They used the

machine learning algorithms over a Microwave

Breast Imaging Clinical Data. The purpose of their

study was to develop an intelligent classification

system to help clinicians to recognize breasts with

lesions. They found that the SVM with the quadratic

kernel achieved a higher accuracy when compared to

other classification techniques used in the study.

Moreover, it is known that Ensemble Classifiers

(EC) have attracted a huge research in the last decade

and in general outperformed single classifiers

(Dietterich, 2000; Hosni et al., 2019). To address the

challenge of searching the most appropriate Kernel

function for implementing SVM, the present study

aimed to develop and evaluate homogeneous

ensembles whose members are four variants of SVM.

The four SVM variants used four different kernels:

Linear Kernel, Normalized Polynomial Kernel,

Radial Basis Function Kernel, and Pearson VII

function based Universal Kernel. A MLP is used to

combine the outputs of the base classifiers to provide

the ensemble decision. The experiments were

conducted on four well-known BC datasets available

from online repositories.

To this end, we discuss the following research

questions (RQs):

RQ1: Does SVM ensembles combining different

kernels types perform better than single SVMs?

RQ2: Among the combinations of SVM kernels

to construct ensembles, which of them provides a

better performance?

The rest of this paper is structured as follows:

Section 2 briefly presents the SVM classifier as well

as its kernels, and the ensemble concept used. Section

3 presents an overview of related work investigating

ensemble techniques in BC classification. Section 4

presents the experimental design followed in this

empirical evaluation. Section 5 presents and discusses

the empirical results. Conclusions and future works

are presented in Section 6.

2 BACKGROUND

2.1 SVM

SVMs are a set of supervised learning methods

characterized by the usage of kernels. The first

formulation of SVM was proposed in 1992, called

maximal margin classifier (Vapnik, 1992). SVMs are

based on the search for the optimal margin

hyperplane which, when possible, classifies or

separates the data correctly while being as far as

possible from all observations. The use of a margin-

based criterion by SVMs, is attractive for many

classification applications like Handwritten digit

recognition, Bio-sequence analysis and Speaker

Identification, (El Idrissi & Idri, 2020; Luxburg &

Schölkopf, 2011; Yu & Kim, 2012). Although SVMs

were originally used for linearly separable datasets to

find the optimal separating hyper-plane (Bhavsar &

Amit Ganatra, 2016) from the large number of

separating hyper-plane, that optimally separates the

data into two areas SVMs can be generalized to non-

linear decision functions by using the so-called kernel

trick (Schölkopf & Alexander, 2001).

2.2 Kernel Functions

SVMs are unable to find a linear hyper-plane that can

separate the input data into classes in some cases

(Kudo & Matsumoto, 2000). This problem can be

tackled by transforming the input data that exists in

high dimensional space by using some non-linear

transformation function. By this process, the input

data can be separated out in such a way that linear

Homogeneous Ensemble based Support Vector Machine in Breast Cancer Diagnosis

353

separable hyper planes can be found in that

transformed space (Trivedi & Dey, 2013). However,

due to the high dimensionality of the feature space,

computation of inner products of two transformed

data vectors would be practically unfeasible. This

problem is tackled using “Kernel Functions” that can

be used in place of the inner product of two

transformed data vectors in feature space.

A good choice of Kernel function is very important

for effective SVM based classification. An

appropriate Kernel function provides learning

capability to SVM (Trivedi & Dey, 2013). In the

literature, several Kernels have been proposed. In this

paper, we attempt to investigate the best choice

among SVM kernels namely LK, PUK, NP, and RBF.

2.3 Ensemble Techniques

An ensemble techniques is a machine

learning technique that combines several single

techniques by means of an aggregation rule in order

to produce one optimal predictive model (Idri et al.,

2016; Kuncheva, 2014).

Ensemble methods can be categorized into two types

Homogeneous or Heterogeneous (Idri et al., 2016;

Zhou, 2012): (1) The homogeneous ensemble refers

to: (1.a) an ensemble that combines one base method

with at least two different configurations or different

variants or (1.b) ensemble that combines one base

learning model with one meta ensemble, such as

Boosting (Schapire & E., 1999), Bagging (Breiman,

1996). (2) The heterogeneous ensemble, meanwhile,

refers to an ensemble that combines at least two

different base learning models. The current study

concerns homogeneous ensembles and for the trained

combining rule, a MLP was used to combine the

output of the classifiers.

3 EXPERIMENTAL DESIGN

3.1 Performance Measures

To evaluate the accuracy of single and ensembles

techniques, we use the performance metrics:

Accuracy, Recall and Precision defined by Equations

1 to 3 respectively (Hosni et al., 2019).

𝐴𝑐𝑐𝑢𝑟𝑎𝑐𝑦 





(1)

Recall 





(2)

Precision Prec 





(3)

Where FP refers to False positive, TP refers to True

positive FN to False Negative and TN to True

negative

3.2 Proposed Ensembles

The purpose of this study was to develop and evaluate

SVM homogeneous ensembles with different kernel

types: LK, NP, RBF, and PUK. We build eleven SVM

ensembles: six ensembles with two members (i.e. two

different kernels) each one, four ensembles with three

members each one (i.e. three different kernels), and

one ensemble with four members (i.e. four kernels).

The MLP was used as a combination rule to provide

the output of each ensemble. The use of MLP as a

combiner rule has been widely investigated in the

literature of ensembles (Canuto et al., 2007; Santana

et al., 2008; Tsymbal et al., 2005).

To shorten the names of ensembles, the following

abbreviation rules were used:

E-Kernel Type1KernelType2

E-Kernel Type1KernelType2 Kernel Type3

E-Kernel Type1 KernelType2 Kernel Type3

Kernel Type4

Where kernel types were abbreviated as follow: L

for Linear kernel, N for Normalized Polynomial

Kernel, P for PUK and R for RBF

For example, ELNR refers to the ensembles

constructed by the three variants of SVM using linear

kernel, Normalized polynomial kernel, and RBF

kernel respectively.

3.3 Methodology Used for Comparison

The purpose of this empirical study is to build

ensembles based on SVMs with different kernels

(LK, NP, RBF, PUK) using MLP as a combiner rule,

and to compare them with the four single SVM

techniques (SVM-LK, SVM-PUK, SVM-NP and

SVM-RFB). The comparison is based on the three

performance criteria: Accuracy, Recall and Precision.

Moreover, we evaluate the statistical significance

between ensemble and single SVM techniques by

clustering them using the Scott–Knott (SK) test based

on error rate (the percent of incorrect classifications;

Error rate = 1 - Accuracy). Thereafter, we rank the

techniques belonging to the SK best clusters by

means of Borda Count based on Accuracy, Recall and

Precision. The statistical test was conducted using the

R Software and Weka (version 3.9.3) tool was used

to conduct the empirical evaluations. Figure 1

presents the experimental process we followed.

HEALTHINF 2021 - 14th International Conference on Health Informatics

354

3.4 Datasets Descriptions

In this study, three datasets were used to assess the

performance of ensemble and single SVM techniques.

These datasets were obtained from the online UCI

repository and were the most frequently adopted by

researchers (Idri et al., 2018).

Table 1 reports the characteristics of each dataset

including number of instances, number of features,

and the number of missing values. It is worth noting

that before we conducted all the experiments, the

missing values were removed since their number was

very low in each dataset (column “Missing Data” of

Table 1). Moreover, the three datasets: BCD,

Wisconsin and WPBC represent unbalanced datasets.

To address this issue, the SMOTE (Chawla et al.,

2002) algorithm was used.

Table 1: Datasets Description.

Datasets #Features Missing

data?

Instances

BCD 12 Yes(9) 286

WDBC 32 NO 569

Wisconsin 11 Yes(16) 699

WPBC 34 Yes (4) 198

3.5 Single Technique Parameters

The tuning of SVM and MLP parameters is given in

Table 2. For SVM, four type of kernels were used

(RBF, LK, PUK and NP), while the parameter values

of MLP were the default values of Weka.

Table 2: Parameters settings of SVM and MLP.

Technique Parameters

SVM Epsilon: 1.0E-12; Complexity : 1.0

Kernel :{RBF, LK, PUK, NP)

MLP Lerning rate :0.3;Momentum :0.2

Hidden layers:a; Validation threshold: 20

a = (#attributes + #classes)/2

4 EMPIRICAL RESULTS

4.1 WDBC Dataset

Table 3 shows the performance in terms of three

criteria (Accuracy, Recall and Precision) of the four

SVM single techniques (SVM-LK, SVM-NP, SVM-

RBF and SVM-PUK), as well as the performance of

the eleven SVM ensemble. As can be seen from Table

3, the best results were obtained by SVM ensembles

combining: LK and NP (ELN); LK and RBF (ELR);

LK, NP and RBF (ELNR), since they produce the

high performance with accuracy, recall and precision

values equal to 98.07%, 98,1% and 98.1%

respectively. We observe that the SVM ensembles

ELN, ELR and ELNR outperform all the Single SVM

techniques and all other SVM ensembles. Moreover,

the results from the Table 5 show that the

performance of the SVM single with linear kernel is

also high 97.89%, 97.9% and 97.9% for accuracy,

recall and precision respectively.

Figure 1: Experimental process.

Moreover, Figure 2 shows the results of the SK test

performed based on error rate. We observe that SK

test identified three clusters which means that there is

a significant difference between ensemble and single

SVM classifiers. The best cluster contains all SVM

ensembles except the ensemble combining NP and

RBF. Moreover, the best cluster included also two

single SVM classifiers: SVM-PUK and SVM-LK.

Whereas the worst cluster contained only one single

SVM technique: SVM-RBF.

Figure 2: SK test of SVM single and SVM ensemble models

on WDBC dataset.

Homogeneous Ensemble based Support Vector Machine in Breast Cancer Diagnosis

355

4.2 BCD Dataset

Table 4 presents the performance of single and

ensemble SVM techniques over the BCD dataset. As

it can be observed from Table 4, the two SVM

ensembles ENPR and ELNPR were ranked first with

the highest performances: ENPR comes first with

85.43%, 85.4% and 85.7% for accuracy, recall and

precision respectively; and ELNPR comes next with

85.18%, 85.2% and 85.4% for Accuracy, Recall and

Precision respectively. We note that the single SVM-

PUK shows the best performance compared to the

other three single SVMs and outperforms six SVM

ensembles (ELN, ELR, ELP, ENR, ERP, ELNR).

Table 3: Performance results: WDBC dataset.

Tech. Accurac

Recall Prec

Single

SVM-L

97.89 97.9 97.9

SVM-NP 93.4 93.5 93.5

SVM-RBF 92.09 92.1 92.8

SVM-PU

97.54 97.5 97.5

Ensemble

ELN 98.07 98.1 98.1

ELR 98.07 98.1 98.1

ELP 97.71 97.7 97.7

ENR 94.38 94.4 94.4

ENP 97.54 97.5 97.5

ERP 97.54 97.5 97.5

ELNR 98.07 98.1 98.1

ENPR 97.54 97.5 97.5

ELNP 97.71 97.7 97.7

ELPR 97.71 97.7 97.7

ELNPR 97.71 97.7 97.7

Table 4: Performance results: BCD dataset.

Tech. Accurac

Recall Prec

Single

SVM-L

78.76 78.8 78.9

SVM-NP 80 80 79.9

SVM-RBF 79.26 79.3 79.2

SVM-PU

83.21 83.2 84.1

Ensemble

ELN 79.51 79.5 79.4

ELR 79.75 79.8 79.7

ELP 81.73 81.7 82.3

ENR 80 80 79.9

ENP 83.46 83.5 83.7

ERP 82.96 83 83.3

ELNR 79.51 79.5 79.4

ENPR 85.43 85.4 85.7

ELNP 84.44 84.4 84.7

ELPR 84.44 84.4 84.8

ELNPR 85.18 85.2 85.4

Figure 3 displays the result of the SK test on BCD

dataset. Two clusters were identified and the best

cluster contains six SVM ensembles (ENPR, ELNPR,

ELPR, ELNP, ENP and ERP) and one single SVM

(SVM-PUK); the worst cluster contains three single

SVM (SVM-LK, SVM-RBFand SVM-NP) and the

five SVM ensembles (ELP, ENR, ELR, ELNR and

ELN).

Figure 3: SK test of SVM single and SVM ensemble models

on BDC dataset.

4.3 Wisconsin Dataset

Table 5 shows the performance criteria values of the

ensemble and single SVM techniques over the

Wisconsin dataset. As can be seen from Table 5, we

observe that the SVM ensembles ERP and ELNP

outperform all other techniques, they produce an

accuracy, recall and precision values of 97.07%,

97.1% and 97.1% respectively. The remaining

ensembles and single techniques showed almost the

same performances.

Table 5: Performance results: Wisconsin dataset.

Tech. Accuracy Recall Prec

Single

SVM-L

96.92 96.9 96.9

SVM-NP 96.92 96.9 97

SVM-RBF 96.34 96.3 96.3

SVM-PU

96.92 96.9 97

Ensemble

ELN 96.49 96.5 96.5

ELR 96.92 96.9 96.9

ELP 96.49 96.5 96.5

ENR 95.46 95.5 95.5

ENP 96.63 96.6 96.7

ERP 97.07 97.1 97.1

ELNR 96.49 96.5 96.5

ENPR 96.63 96.6 96.7

ELNP 97.07 97.1 97.1

ELPR 96.92 96.9 97

ELNPR 96.92 96.9 97

Figure 4 displays the results when applying the SK

test on ensemble and single SVM techniques over

Wisconsin dataset. SK identified only one cluster that

included all techniques (single and ensemble SVMs),

which implies that there is no important difference

between them.

HEALTHINF 2021 - 14th International Conference on Health Informatics

356

Figure 4: SK test of ensemble and single SVM techniques

over Wisconsin dataset

4.4 WPBC Dataset

Table 6 presents the performance results of ensembles

and single SVM techniques over the WPBC dataset.

We observe that four SVM ensembles (ELP, ENP,

ERP, ENRP and ELPR) and the single SVM (SVM-

PUK) seem to perform better than all other

techniques; they achieved an accuracy, recall and

precision of 90.88%, 90.9% and 90.9% respectively.

The two SVM ensembles (ELNP and ELNPR)

achieved the second best performances with an

accuracy, recall and precision of 90.54%, 90.5% and

90.6% of accuracy, recall and precision respectively.

Table 6: Performance results: WPBC dataset.

Tech. Accuracy Recall Prec

SVM single

SVM-L

74.66 74.8 74.7

SVM-NP 77.03 77 77.2

SVM-RBF 65.88 65.9 66.5

SVM-PU

90.88 90.9 90.9

SVM ensemble

ELN 77.36 77.4 77.4

ELR 74.66 74.7 74.8

ELP 90.88 90.9 90.9

ENR 76.69 76.7 76.8

ENP 90.88 90.9 90.9

ERP 90.88 90.9 90.9

ELNR 77.70 77.7 77.7

ENPR 90.88 90.9 90.9

ELNP 90.54 90.5 90.6

ELPR 90.88 90.9 90.9

ELNPR 90.54 90.5 90.6

Figure 5 reports the results of the SK test on

ensemble and single SVM techniques over WPBC

dataset. SK identified three clusters, the best one

contains seven SVM ensembles (ELNP, ELNPR,

ELP, ELPR, ENP, ENPR and ERP) and one single

SVM (SVM-RBF), while the worst cluster only

contains one single SVM (SVM-RBF).

Figure 5: SK test of ensemble and single SVM techniques

over WPBC dataset.

4.5 Comparing Ensemble and Single

SVM Techniques

In order to investigate the effect of the four kernel

techniques L, N, P and R on the performance of

ensembles and single SVM techniques, we counted

the number of occurrences of each kernel technique

in the best SK cluster of each dataset. From Table 7,

we note that the P kernel was ranked first in all

datasets. However, all the kernels have the same

number of occurrences in Wisconsin, and the kernel

L was also ranked first in WDBC. Furthermore, the

kernels N and R have the same number of occurrences

in all datasets.

We can conclude that:

(1) The use of the P kernel instead of L, N and P to

build SVM ensembles and single SVM often led to

more accurate diagnosis; and

(2) The L, N and R kernels seem have the same

impact on the performances of ensemble and single

SVM techniques.

Table 7: Number of occurrences of each kernel technique

in the best cluster of SK test for each dataset.

Dataset Kernel technique

LN P R

WDBC 86 8 6

BCD 34 7 4

Wisconsin 88 8 8

WPBC 44 8 4

Total 23 22 31 22

In order to identify which techniques are the best

on all datasets, we ranked the techniques of the best

SK cluster of each dataset by using the Borda Count

voting system based on Accuracy, Recall and

Precision. Table 8 presents the ranking results for

each dataset. We observe that:

a. By comparing the number of occurrences of

ensembles and single techniques in the best

cluster of each dataset, we found that ensembles

are the most frequent in the best clusters of all

Homogeneous Ensemble based Support Vector Machine in Breast Cancer Diagnosis

357

datasets: for WDBC, nine ensembles (ELNR,

ELR, ELN, ELP, ELNP, ELPR, ELNPR, ENP,

ERP and ENPR) were identified in the best cluster

versus two single techniques (SVM-LK and

SVM-PUK); for BCD, five ensembles (ENPR,

ELNPR, ELPR, ELNP, ENP and ERP) were

identified in the best cluster versus one single

technique (SVM-PUK); for Wisconsin, eleven

ensembles (ERP, ELNP, ELPR, ELNPR , ELR,

ENP, ENPR, ELN, ELP, ELNR and ENR) were

identified versus four single techniques (SVM-

NP, SVM-PUK, SVM-LK and SVM-RBF); and

for WPBC, seven ensembles (ERP, ENP, ELP,

ENPR, ELPR, ELNP and ELNPR) were

identified versus one single technique (SVM-

PUK).

b. SVM ensembles outperformed single SVM

classifiers in all datasets since the first ranked

techniques were ensembles in all datasets: (e.g.

ELNR, ELR and ELNR in WDBC).

c. ERP/ENPR ensemble outperformed all the other

SVM single and ensemble classifiers in two

datasets: Wisconsin and WPBC/BCD.

d. The SVM ensemble ELNPR with four members

(i.e. four kernels) was present in the best clusters

of all datasets. Moreover, among the 6/4

ensembles with two/three members, 5/4, 2/3, 6/4

and 3/3 were presents in the best clusters of

WDBC, BCD, Wisconsin and WPBC

respectively.

e. SVM-PUK single technique

was present is all the

best clusters and was ranked first in WPBC and

second in Wisconsin.

To summarize the main findings, we can conclude

that:

(1) Ensembles are more accurate than the single

classifiers; this confirms the finding of the

systematic literature review of (Idri et al.,

2016b);

(2) There is no kernels combination (i.e. no SVM

ensembles) that outperformed all the others in all

datasets. However, the combination P and R

seems to perform better.

(3) The use of P kernel instead of L, N and P seems

to improve the accuracy of SVM ensembles.

(4) It seems that the performance of SVM ensembles

increases with the number of members (i.e.

number of kernels).

(5) The best single SVM was SVM-PUK and can be

used to overcome the intensive calculation of

ensembles.

Table 8: Number of occurrences of each kernel technique

in the best cluster of SK test for each dataset.

Rank WDBC BCD Wisconsin WPBC

1 ELNR

ENPR ERP ERP

2 ELR

ELNPR ELNP ENP

3 ELN

ELPR ELPR

ELP

4SVM-L

ELNP ELNPR

ENPR

5 ELPb ENP SVM-NP

ELPR

6 ELNP

ERP SVM-PUK

SVM-

7 ELPR

SVM-

SVM-LK

ELNP

8 ELNPR

ELR

ELNPR

9ENP

ENP

10 ERP

ENPR

11 SVM-PU

ELN

12 ENPR

ELP

13 ELNR

14 SVM-RBF

a,b,c

and

mean the same ranks

5 CONCLUSION AND FUTURE

WORK

This paper proposed and evaluated SVM ensembles

using four kernels (LK, NP, RBF, and PUK) and

MLP as a combiner rule over four historical datasets.

The SVM ensembles and single SVMs methods were

also compared using three criteria: accuracy,

precision and recall criteria. The SK test and Borda

Count were used to carry out the significance tests

and rank the best classifiers respectively. The

findings of this study are as follows:

RQ1: SVM ensembles outperformed single

SVMs. This means that the use of a combination of

kernels with different kernels often lead to better

classifiers. Moreover, it seems that the performance

of SVM ensembles increases with the number of

kernels (i.e. members). Given that ensembles are in

general time consuming, the single SVM-PUK can be

used.

RQ2: We found that no SVM ensembles (i.e. no

combination of kernels) outperformed all the others.

However, the use of P and R kernels seems to increase

the performance of SVM ensembles. Ongoing work

focuses on assessing and comparing homogeneous

and heterogeneous ensembles in BC diagnosis.

Moreover, the impact of parameters tuning using

optimization techniques such as particle swarm and

genetic algorithms on the performance of ensemble

BC classifiers will be also assessed.

HEALTHINF 2021 - 14th International Conference on Health Informatics

358

REFERENCES

Bhavsar, H., & Amit Ganatra. (2016). Radial Basis

Polynomial Kernel (RBPK): A Generalized Kernel for

Support Vector Machine. International Journal of

Computer Science and Information Security, 14(April).

Breiman, L. (1996). Bagging Predictors. Machine

Learning, 24(2), 123–140.

Canuto, A. M. P., Abreu, M. C. C., de Melo Oliveira, L.,

Xavier, J. C., & Santos, A. de M. (2007). Investigating

the influence of the choice of the ensemble members in

accuracy and diversity of selection-based and fusion-

based methods for ensembles. Pattern Recognition

Letters, 28(4), 472–486.

Chawla, N. V, Bowyer, K. W., Hall, L. O., & Kegelmeyer,

W. P. (2002). SMOTE: Synthetic Minority Over-

sampling Technique. In Journal of Artificial

Intelligence Research (Vol. 16).

Chlioui, I., Idri, A., & Abnane, I. (2020). Data

preprocessing in knowledge discovery in breast cancer:

systematic mapping study. Computer Methods in

Biomechanics and Biomedical Engineering: Imaging

and Visualization, 00(00), 1–15. https://doi.org/

10.1080/21681163.2020.1730974

Dietterich, T. G. (2000). Ensemble methods in machine

learning. Lecture Notes in Computer Science (Including

Subseries Lecture Notes in Artificial Intelligence and

Lecture Notes in Bioinformatics), 1857 LNCS, 1–15.

El Idrissi, T., & Idri, A. (2020). Deep Learning for Blood

Glucose Prediction: CNN vs LSTM. Lecture Notes in

Computer Science (Including Subseries Lecture Notes

in Artificial Intelligence and Lecture Notes in

Bioinformatics), 12250 LNCS, 379–393.

https://doi.org/10.1007/978-3-030-58802-1_28

Eltalhi, S., & Kutrani, H. (2019). Breast Cancer Diagnosis

and Prediction Using Machine Learning and Data

Mining Techniques: A Review. IOSR Journal of Dental

and Medical Sciences (IOSR-JDMS) e-ISSN, 18, 85–94.

Hosni, M., Abnane, I., Idri, A., Carrillo de Gea, J. M., &

Fernández-Alemán, J. L. (2019). Reviewing ensemble

classification methods in breast cancer. Computer

Methods and Programs in Biomedicine, 177, 89–112.

Hosni, M., García-Mateos, G., Carrillo-de-Gea, J. M., Idri,

A., & Fernández-Alemán, J. L. (2020). A mapping

study of ensemble classification methods in lung cancer

decision support systems. In Medical and Biological

Engineering and Computing (Vol. 58, Issue 10, pp.

2177–2193). Springer Science and Business Media

Deutschland GmbH. https://doi.org/10.1007/s11517-

020-02223-8

Hussain, M., Wajid, S. K., Elzaart, A., & Berbar, M. (2011).

A comparison of SVM kernel functions for breast

cancer detection. International Conference on

Computer Graphics, Imaging and Visualization, 145–

150.

Idri, A., Bouchra, E. O., Hosni, M., & Abnane, I. (2020).

Assessing the impact of parameters tuning in ensemble

based breast Cancer classification. Health and

Technology, 10(5), 1239–1255. https://doi.org/10.

1007/s12553-020-00453-2

Idri, A., Hosni, M., & Abnane, I. (2019). Impact of

Parameter Tuning on Machine Learning Based Breast

Cancer Classification (pp. 115–125). Springer, Cham.

https://doi.org/10.1007/978-3-030-16187-3_12

Idri, A., Hosni, M., & Abran, A. (2016). Systematic

literature review of ensemble effort estimation. Journal

of Systems and Software, 118, 151–175.

Idri, Chlioui, I., & EL Ouassif, B. (2018). A systematic map

of data analytics in breast cancer. Proceedings of the

Australasian Computer Science Week Multiconference

on - ACSW ’18, 1–10.

Kadi, I., Idri, A., & Fernandez-Aleman, J. L. (2017).

Knowledge discovery in cardiology: A systematic

literature review. International Journal of Medical

Informatics, 97, 12–32. https://doi.org/10.1016/

j.ijmedinf.2016.09.005

Kudo, T., & Matsumoto, Y. (2000). Japanese dependency

structure analysis based on support vector machines.

Proceedings of the 2000 Joint SIGDAT Conference on

Empirical Methods in Natural Language Processing

and Very Large Corpora Held in Conjunction with the

38th Annual Meeting of the Association for

Computational Linguistics -, 13, 18–25.

Kuncheva, L. I. (2014). Combining Pattern Classifiers.

John Wiley & Sons, Inc.

Luxburg, U. von, & Schölkopf, B. (2011). Statistical

Learning Theory: Models, Concepts, and Results. In

Handbook of the History of Logic (Vol. 10).

Oskouei, R. J., Kor, N. M., & Maleki, S. A. (2017). Data

mining and medical world: breast cancers’ diagnosis,

treatment, prognosis and challenges. American Journal

of Cancer Research, 7(3), 610–627.

Rana, S. P., Dey, M., Tiberi, G., Sani, L., Vispa, A., Raspa,

G., Duranti, M., Ghavami, M., & Dudley, S. (2019).

Machine Learning Approaches for Automated Lesion

Detection in Microwave Breast Imaging Clinical Data.

Scientific Reports, 9(1), 1–12.

Santana, L. E. A., Canuto, A. M. P., & Xavier, J. C. (2008).

Using feature distribution methods in ensemble systems

combined by fusion and selection-based methods.

Lecture Notes in Computer Science (Including

Subseries Lecture Notes in Artificial Intelligence and

Lecture Notes in Bioinformatics), 5163 LNCS(PART

1), 245–254.

Schapire, & E., R. (1999). A brief introduction to boosting.

In Proceedings of the 16th international joint

conference on Artificial intelligence - Volume 2 (pp.

1401–1406).

Schölkopf, B., & Alexander, J. S. (2001). Support Vector

Machines, Regularization, Optimization, and Beyond.

Learning with Kernels (pp. 1–27).

Sun, Y. S., Zhao, Z., Yang, Z. N., Xu, F., Lu, H. J., Zhu, Z.

Y., Shi, W., Jiang, J., Yao, P. P., & Zhu, H. P. (2017).

Risk factors and preventions of breast cancer.

International Journal of Biological Sciences, 13(11),

1387–1397.

Topol, E. J. (2019). High-performance medicine: the

convergence of human and artificial intelligence. In

Nature Medicine (Vol. 25, Issue 1, pp. 44–56).

Homogeneous Ensemble based Support Vector Machine in Breast Cancer Diagnosis

359

Trivedi, S., & Dey, S. (2013). Effect of Various Kernels and

Feature Selection Methods on SVM Performance for

Detecting Email Spams. International Journal of

Computer Applications, 66(21), 18–23.

Tsymbal, A., Pechenizkiy, M., & Cunningham, P. (2005).

Diversity in search strategies for ensemble feature

selection. Information Fusion, 6(1), 83–98.

Vapnik, V. (1992). Principles of risk minimization for

learning theory, in Advances in neural information

processing systems, .

Yu, H., & Kim, S. (2012). SVM tutorial-classification,

regression and ranking. In Handbook of Natural

Computing (Vols. 1–4, pp. 479–506).

Zhou, Z.-H. (Computer scientist). (2012). Ensemble

methods : foundations and algorithms. Taylor &

Francis.

HEALTHINF 2021 - 14th International Conference on Health Informatics

360
