Heuristic Evaluation Checklist for Domain-speciﬁc Languages

Ildevana Poltronieri

1 a

, Avelino Francisco Zorzo

1 b

, Maicon Bernardino

2 c

, Bruno Medeiros

and

Marcia de Borba Campos

3 d

PUCRS, Av. Ipiranga, 6681, Partenon, Porto Alegre, RS, Brazil

UNIPAMPA, Av. Tiaraju, 810 - Ibirapuitã, Alegrete, RS, Brazil

CESUCA, Rua Silvério Manoel da Silva, 160, Colinas, Cachoeirinha, RS, Brazil

Keywords:

Checklist Heuristic, Empirical Method, Heuristic Evaluation, Domain-speciﬁc Language.

Abstract:

Usability evaluation of a Domain-Speciﬁc Language (DSL) is not a simple task, since DSL designers eﬀort

might not be viable in a project context. Hence, we ease DSL designers work by providing a fast and simple

way to evaluate their languages and, therefore, reduce eﬀort (spend time) when a new DSL is developed. In

order to do that, this paper presents a structured way to build a Heuristic Evaluation Checklist (HEC) for DSLs.

This checklist is diﬀerent from traditional checklists since it is focused on DSL. Once a checklist is provided,

the evaluators only follow a set of heuristics and freely point out the found errors when using the DSL. Basically,

the produced checklist provides a set of questions, based on the heuristics that direct an evaluation for a speciﬁc

domain. In order to show how our proposal can be applied to a DSL and to provide an initial evaluation of our

HEC, this paper shows also an instance to evaluate graphical and textual DSLs. Furthermore, this paper also

discusses the qualitative analysis of an initial evaluation for the proposed HEC through seven interviews with

Human-Computer Interaction (HCI) experts. Finally, a brief example of use applying the developed checklist is

presented.

1 INTRODUCTION

In recent years we have seen a signiﬁcant increase in

the development of DSLs. Along with this develop-

ment came the need to evaluate the usability of DSLs

under development, so that later they are implemented

and distributed to end users. Nonetheless, this type

of evaluation is still a problem for groups that de-

velop DSLs (Bariši

c et al., 2018) (Mosqueira-Rey and

Alonso-Ríos, 2020) (Poltronieri et al., 2018).

To help solving that problem, the Human-

Computer Interaction (HCI) ﬁeld (Sharp et al., 2019)

presents several approaches to evaluate the usability

of any artifact. Among them, the most common used

approaches for usability evaluation process are: Us-

ability Testing (UT) (Nielsen, 1993) and Heuristic

Evaluation (HE) (Nielsen and Molich, 1990). The

former is a black-box approach technique whose goal

is to observe real users using the product to uncover

https://orcid.org/0000-0002-8830-4230

https://orcid.org/0000-0002-0790-6759

https://orcid.org/0000-0003-2776-8020

https://orcid.org/0000-0002-5417-2524

potential issues and points for improvement. The latter

is a knowledge-based inspection method. Nielsen’s

heuristic evaluation method (Nielsen, 1994) is the best

known one, which is a heuristic-guided inspection that

provides general heuristic principles of good interface

design, i.e. aimed at maximizing usability of the eval-

uated software artifact.

Furthermore, the evolution of software systems

increasingly relies on the search for specialized solu-

tions to an application domain. Thus, Model-Driven

Engineering (MDE) (Schmidt, 2006) highlights the

important role played by Domain-Speciﬁc Languages

(DSL) (Van Deursen et al., 2000), which provide con-

structions based on notations and abstractions that are

speciﬁc to the problem domain. However, a research

gap is the process of evaluating such DSLs regarding

their usability.

In this context, some researchers have proposed

ways to evaluate or organize the evaluation of DSLs

(Mosqueira-Rey and Alonso-Ríos, 2020) (Poltronieri

et al., 2018). For example, the study proposed by

Poltronieri et al. (Poltronieri et al., 2018) describes an

Usa-DSL Framework composed of steps, phases and

Poltronieri, I., Zorzo, A., Bernardino, M., Medeiros, B. and Campos, M.

Heuristic Evaluation Checklist for Domain-speciﬁc Languages.

DOI: 10.5220/0010239400370048

In Proceedings of the 16th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2021) - Volume 2: HUCAPP, pages

37-48

ISBN: 978-989-758-488-6

activities to help in the usability evaluation of DSLs.

The framework structure is derived from the project

life-cycle process (Stone et al., 2005). In their frame-

work, steps are deﬁned in eleven (11) focus areas;

phases are composed of four (4) cycles of execution;

and, activities are formed by a set of thirty two (32)

concepts that are distributed among phases. The frame-

work was designed to be used based on the needs of

each assessment.

Usa-DSL Framework Evaluation was performed

through interviews and a focus group involving sub-

jects with experience in Human-Computer Interaction

(HCI) and Software Engineering (SE). The evalua-

tion aimed to present the framework and to obtain

the opinion of subjects as to its clarity, ease of use

and understanding. Based on those evaluations, the

authors concluded that such framework needed a sys-

tematic support for its execution. Thus, to systematize

its use, the Usa-DSL Process is needed. Such process

may provide guidelines for the phases, steps and ac-

tivities of the framework. In the process, deﬁnitions

were mapped to the proﬁles, the details of the tasks

performed by each activity, as well as the creation of

work products that support the inputs and outputs of

the process activities. Those work products are classi-

ﬁed in the process according to their type: templates,

checklists, tools, metrics, etc.

Therefore, the objective of this paper is to present

a checklist for usability evaluation called

Heuristic

Evaluation Checklist (HEC) for DSL

. Furthermore,

we also instantiated this HEC for one DSL to demon-

strate the applicability in one context. We also discuss

the results of the evaluation through interviews with

HCI experts to verify the completeness of the proposed

checklist for the heuristic evaluation process in DSLs.

This paper is organized as follows. Section 2

presents concepts on DSLs and HE, and highlights

related work. Section 3 introduces our HEC for graph-

ical and textual DSLs. Section 4 outlines a systematic

method for interviews, illustrates its testing via a pilot

test, presents proﬁle and discusses qualitative analysis.

Section 5 presents a toy example to which our HEC

was applied to. Section 6 ﬁnalizes this paper.

2 BACKGROUND

This section presents the main concepts on Domain-

Speciﬁc Languages and Heuristic Evaluation. Also,

related work associated with our research is presented

in this section.

2.1 Domain-speciﬁc Languages

According to Van Deursen et al. (Van Deursen et al.,

2000) a Domain-Speciﬁc Language (DSL) is “a pro-

gramming language or executable speciﬁcation lan-

guage that oﬀers, through appropriate abstractions,

focused expressive power and usually it is restricted

to a speciﬁc problem domain”. Like other languages,

DSLs must have a set of sentences well known by their

own syntax and semantics. Fowler (Fowler, 2010)

asseverates that a DSL is deﬁned as “a computer pro-

gramming language with limited expressiveness and

focused on a particular problem domain”.

The application of DSLs allows software to be

developed faster and more eﬀectively. The major ad-

vantage observed in using a DSL is that the knowledge

required for its applicability is abstracted to another

level. In this way, domain experts can understand, val-

idate, and modify code, tailoring the model to their

needs, making the impact of change easier to under-

stand. There is still a signiﬁcant increase in productiv-

ity, reliability, ease of use and ﬂexibility (Van Deursen

et al., 2000). According to Mernik (Mernik et al.,

2005), DSLs can be classiﬁed under three diﬀerent di-

mensions: origin, appearance and implementation.

Regarding the

origin

of a DSL, it can be inter-

nal and external. An

internal

DSL is designed from

the syntactic and semantic rules of an existing lan-

guage, which may be a general purpose language, or

another DSL. An

external

DSL is language that relies

on its own infrastructure for lexical, syntactic, seman-

tic analysis, interpretation, compilation, optimization,

and code generation.

With regard to the

appearance

dimension, a DSL

can be classiﬁed as

textual

graphical

tabular

and

symbolic

. When in textual format, a DSL allows the

domain to be expressed with characters, which are then

combined to generate words, expressions, sentences

and instructions that follow the grammar rules previ-

ously established in the language. Non-textual DSLs

follow the same logic, but using graphical models to

allow the user to express the domain knowledge with

a higher level of understanding and using symbols,

tables, ﬁgures and connectors.

As far as the

implementation

dimension is con-

cerned, DSLs can be classiﬁed from the perspective

of their implementation. These classiﬁcations form

four groups: (i) well-known execution DSL; (ii) DSL

that serve as input to application generators; (iii) non-

executable DSLs but useful as input to application

generators; (iv) DSL not designed to be executed.

In general the main consideration for building a

DSL should be its origin as each approach has speciﬁc

advantages and disadvantages that are inherent in each

HUCAPP 2021 - 5th International Conference on Human Computer Interaction Theory and Applications

type (Fowler, 2010). Although external DSL may

have an eﬀort associated with building it many times

higher than that of an internal DSL, there are currently

tools that support DSL development. These tools are

known as

Language Workbenches (LWB)

and apply

language-oriented programming concepts to provide a

higher level of abstraction for complex infrastructure

issues (Fowler, 2005).

2.2 Heuristic Evaluation

Heuristics are based on practical knowledge that comes

from continued daily experience. Heuristic knowledge

builds over years of practice as a compilation of ‘what

works’ and ‘what does not’.

Heuristic Evaluation (HE) is an

inspection

method

that does not involve end users. In HE, analy-

sis is performed by experts who advocate for the user,

that is, knowing what the users’ wants and needs, and

knowing the possible HCI techniques they evaluate

whether a particular computational artifact provides a

good experience for the user (Sharp et al., 2019).

The purpose of a HE is to

identify problems

(for

a particular user proﬁle and task set), consisting of a

group of three (3) to ﬁve (5) HCI experts who inspect

the interface or, in this case, the DSL without involving

users using a heuristic list (guidelines), empirical basis

with the intention of generating as a result a report

of potential problems and recommendations for the

evaluated solution (Nielsen, 1993).

Heuristic evaluation is a method designed to ﬁnd

usability issues during an iterative design process. It is

a simple, fast and inexpensive method to evaluate HCI

when compared to empirical methods. The method is

based on a set of usability heuristics, which describe

desirable interaction and interface features.

The

heuristic evaluation method

was proposed

by Jakob Nielsen in 1994 (Nielsen, 1994). This is

a heuristic-driven inspection in which general prin-

ciples of good interface design aims at maximizing

artifact usability. Traditionally, ten (10) heuristics

(Nielsen, 1994) have been used to cover new technolo-

gies and computing environments. These heuristics

have already been altered and expanded since their

original proposal. In the literature, several papers (Sad-

owski and Kurniawan, 2011) (Sinha and Smidts, 2006)

have proposed heuristic checklists based on Nielsen’s

heuristics to inspect the usability of computational

solutions.

2.3 Related Work

Several works have applied usability evaluation meth-

ods to assess Domain-Speciﬁc Languages (DSLs). In

this section, we mention the ones that are directly re-

lated to our proposal.

Bariši

c et al. (Bariši

c et al., 2018) introduced a con-

ceptual framework, called USE-ME, which helps the

usability evaluation through an iterative incremental

development process of DSLs. The framework is a sys-

tematic approach based on user interface experimental

evaluation techniques. In their study, the authors pre-

sented the feasibility of the conceptual framework by

means of an industrial case study.

Hermawati and Lawson (Hermawati and Lawson,

2016) presented a systematic review of seventy (70)

studies related to usability heuristics for speciﬁc do-

mains. The study objective was to map the heuris-

tic evaluation processes applied to speciﬁc domains.

Their work identiﬁed points for improvements and fur-

ther research. The most important aspect pointed out

by the authors was the lack of validation eﬀort to ap-

ply heuristic evaluation as well as the robustness and

accuracy of the applied validation method.

Sadowski and Kurniawan (Sadowski and Kur-

niawan, 2011) derived eleven (11) Language Fea-

ture Heuristics through potential heuristics based on

Nielsen’s ten (10) heuristics and thirteen (13) cognitive

dimensions framework.

Sinha and Smidts (Sinha and Smidts, 2006) pre-

sented an approach that uses a measurement model

to evaluate usability indicators of a DSL. The authors

pointed out that usability measures were deﬁned for

their applications or, more speciﬁcally, for the graphi-

cal interfaces of these applications.

Poltronieri et al. (Poltronieri et al., 2018) presented

the Usa-DSL Framework to guide a systematic usabil-

ity evaluation for Textual and Graphic DSL. This is

the framework we will follow in our work.

Recently, Mosqueira-Rey and Alonso-

Ríos (Mosqueira-Rey and Alonso-Ríos, 2020)

worked in a set of usability heuristics for DSLs.

In their study, they introduced a case study for

evaluating their approach. The proposed approach is

based on the usability taxonomy published in their

previous work (Alonso-Ríos et al., 2009), which is

composed of the following attributes: Knowability,

Operability, Eﬃciency, Robustness, Safety and

Subjective Satisfaction.

Summarizing (see Table 1), Bariši

c et al. fo-

cuses on a conceptual framework process to support

usability evaluation in DSLs. Hermawati and Law-

son provide evidence of poor usability assessments

of DSLs developed on the basis of a secondary study.

Sadowski and Kurniawan discuss language feature

heuristics. Sinha and Smidts present the evaluation

on four heuristics proposed by Nielsen. Poltronieri

et al. present a systematic framework for usability

Heuristic Evaluation Checklist for Domain-speciﬁc Languages

Table 1: Related Work Summary.

Study Criteria Analysis

Usability Evaluation

Method

(Bariši

c et al., 2018) Introduce a conceptual framework Usability Evaluation

(Hermawati and Lawson,

2016)

Present a systematic review of seventy (70) studies

related to usability heuristics for speciﬁc domains

Heuristic Evaluation

(Sadowski and Kurni-

awan, 2011)

Present evidences from the evaluation of two parallel

programming case studies in order to evaluate the

usability problems in programming languages.

Heuristic Evaluation and

Cognitive Dimensions

(Sinha and Smidts, 2006)

Evaluation on four heuristics proposed by Nielsen Heuristic Evaluation

(Mosqueira-Rey and

Alonso-Ríos, 2020)

Present a set of usability heuristics for DSLs and

introduce a case study to evaluate their approach

Not Informed

(Poltronieri et al., 2018)

A usability evaluation framework for domain-

speciﬁc languages

Usability Test and

Heuristic Evaluation

evaluation. Mosqueira-Rey and Alonso-Ríos present a

heuristic evaluation based on a proposed usability tax-

onomy. The authors also present usability heuristics

based on a taxonomy they built, but the methodology

is very diﬀerent from our Checklist Heuristic. The

authors, also argue that their heuristics can help identi-

fying real problems of usability, including even simple

DSLs.

Complementary to these studies, the focus of our

approach is to present a Heuristic Evaluation Checklist

for DSL based on the concepts of the Nielsen’s ten

heuristics. The

diﬀerence of our checklist

is that we

direct the evaluation so that its results can be more

intuitive and ease to use for DSL designers who want

to know about the usability of their DSLs. As for

the related work, the development of the Heuristic

Checklist using Nielsen’s Heuristics is the key point of

our proposal, since those heuristics are consolidated in

the area and with that it facilitates the recognition of

its concepts when the evaluators apply our checklist.

3 HEURISTIC EVALUATION

CHECKLIST

The Heuristic Evaluation (HE) method is a widely used

approach for usability inspection, in which a group of

evaluators inspect an interface design based on a set

composed of ten (10) usability heuristics and a severity

score rating from 0 to 4 for each encountered problem

(Nielsen, 1994) (Nielsen and Molich, 1990).

Although heuristic evaluation is frequently used

for usability assessment, these heuristics are used to

evaluate user interfaces for many diﬀerent domains.

In some studies, heuristics adjustment are needed to

ensure that speciﬁc usability issues of certain domains

are not overlooked (Hermawati and Lawson, 2016).

Several authors use an informal process to develop or

adapt usability heuristics and do not follow an estab-

lished and systematic protocol for heuristic evaluation.

In our approach we

use a set of heuristics to evaluate

the usability of applications with speciﬁc features,

and speciﬁc aspects not covered by generic sets of

usability heuristics.

This adaptation was based on questions related to

our research domain and the 10 heuristics proposed

by Nielsen. One of the main goals of this checklist is

to enable teams that are part of diﬀerent phases of the

development process to understand and evaluate their

application. In our evaluation we apply that to DSLs.

This approach not only brings the DSL design team

closer to the HE method, but also assists the HCI ex-

perts who will evaluate the DSL in understanding the

problem domain that will be evaluated. For a better

understanding of the HE methodology extension, we

describe it in the next section.

The methodology to develop our Heuristic Eval-

uation Checklist follows the methodology proposed

by (Quiñones et al., 2018) (see Figure 1). The ﬁrst

steps were: to understand Heuristic Evaluation and

Domain-Speciﬁc Language concepts, to adapt existing

heuristics for the DSL domain, to produce a set of

questions based on a systematic literature review (Ro-

drigues et al., 2017), and to create our initial Heuristic

Evaluation Checklist. After that we submitted this

preliminary checklist to be evaluated by a set of HCI

experts through interviews. Finally, we got a modi-

ﬁed, and ﬁnal, Heuristic Evaluation Checklist that we

applied to an example of use.

3.1 A Heuristic Evaluation Checklist for

Graphical and Textual DSLs

Heuristic Evaluation Checklist (HEC) for graphical

and textual DSLs is based on extension of artifacts

from the HE method. This checklist is an artifact de-

HUCAPP 2021 - 5th International Conference on Human Computer Interaction Theory and Applications

Methodology

HEURISTIC

EVALUATION

(Nilesen)

Development

DSL

Checklist Initial

ADAPTATION

HEURISTIC

Evaluation Checklist

INTERVIEWS

HCI EXPERTS

QUESTION

Modiﬁed Checklist

HEC FOR

TEXTUAL

DSL

HEC FOR

GRAPHICAL

DSL

Example of Use

APPLY

CHECKLIST

HEC

FOR TEXTUAL

DSL

HECFOR

GRAPHICAL

DSL

Figure 1: Methodology.

signed to guide the heuristic evaluation of DSLs and

it must be used in the context of a usability evaluation

process for DSLs. This evaluation should be planned

by an analyst, developer or DSL tester, and be con-

ducted by heuristic evaluation experts.

The checklist structure consists of ﬁve (5) columns

(see Table 3): the ﬁrst column contains the identiﬁ-

cation of the heuristic, the second column is related

to the description of the ten (10) Nielsen’s heuristics,

but adapted to the context of DSLs, the third column

refers to the questions that guide the evaluation and

related to each one of the heuristics, the fourth column

is the severity degree of the usability problems found

and the ﬁfth column is designed for the description of

issues found in the DSLs. A snippet of the Heuristic

Evaluation Checklist for graphical and textual DSLs

is shown in Table 3

This checklist is intended to guide the evaluation

of several kinds of DSL. Thus, three distinct versions

were created: Heuristic Evaluation Checklist for tex-

tual DSLs; Heuristic Evaluation Checklist for graph-

ical DSLs; and, Heuristic Evaluation Checklist for

graphical and textual DSLs.

The Heuristic Evaluation Checklist for graphical

and textual DSLs cover questions related to both types

of DSLs. In this checklist, the ﬁrst heuristic, “H1: Visi-

bility of system status”, for instance, has as description:

“The DSL should always keep users informed about

what is going on, through appropriate feedback within

reasonable time.” and it is guided by three distinct

questions.

The ﬁrst question is “Does the graphical DSL pro-

vide immediate and adequate feedback on their status

for each user action? (For example, after an include

or exclude task, the language displays a commit mes-

sage)?”. The second question: “Do the elements avail-

able for the user speciﬁcally execute only one com-

mand? (For example, the ‘undo’ button only performs

Due to space restrictions, only some information re-

lated to our HEC is presented in this paper. Our complete

HEC can be found at https://drive.google.com/drive/folders/

1obuVQ-67P49fnqMqB-SNJr7JHUhsFVHQ?usp=sharing.

undo actions)”. The last question (not shown in Table

3): “Does the textual DSL provide immediate and ade-

quate feedback on the status of each user action? (For

example, after an include or exclude task, the language

displays a commit message)?”.

The Heuristic Evaluation Checklist for textual

DSLs is composed of the same heuristics and descrip-

tions. However, two questions guide the ﬁrst heuristic

on the checklist for textual DSLs: “Does the Textual

DSL provide immediate and adequate feedback on

their status for each user action? (For example, after

an include or exclude task, does the language display

a commit message?)” and “Do the elements available

for the user speciﬁcally execute only one command?

(For example, do the keywords on the Textual DSL are

used for speciﬁc purposes?)”.

The same heuristic on the Heuristic Evaluation

Checklist for graphical DSLs has also two guiding

questions, which have the same content of the guiding

questions on the Heuristic Evaluation Checklist for

textual DSLs but focused on the visual aspects of the

DSL. To measure the severity degree of the found

usability problems Table 2 was used.

Table 2: Severity Degree.

Sev. Type Description

Not applicable

I don’t agree that this is a

usability problem at all

Cosmetic

problem only

Doesn’t need to be ﬁxed

unless extra time is available

on the project

Minor usability

problem

Fixing this should be given

low priority

Major usability

problem

Important to ﬁx, so should

be given high priority

Usability

catastrophe

Imperative to ﬁx this before

the product can be released

The use of our checklist is diﬀerent from previous

checklists since each of the heuristics is guided by

questions that direct the evaluation to what one seeks to

evaluate in a DSL. In the original heuristic evaluation,

Heuristic Evaluation Checklist for Domain-speciﬁc Languages

the evaluators only follow the heuristics and freely

point out the errors found when using the system.

This checklist was directed to a speciﬁc need, i.e.

to evaluate DSLs. Our methodology intends to make

the DSL evaluation clearer and more direct, easing the

evaluators task (HCI Experts), even for evaluators that

might not be familiar with the DSL domain. Therefore,

this study presents, as an example of use, a Heuristic

Evaluation Checklist for graphical and textual DSL.

4 METHOD: CHECKLIST

EVALUATION

To evaluate the Heuristic Evaluation Checklist for

graphical and textual DSL we used the qualitative

analysis approach that was performed through online

interviews. The Interview Method (Clark et al., 2019)

was chosen because the main goal of this study was to

obtain the respondents perception about the checklist

content and presentation. The interviewees were in-

vited from participants’ references, thus ensuring that

they were experts on HCI or at least had seen usability

evaluation before.

Before the interviews, the documents necessary to

the understanding of the analyzed domain, i.e. DSLs,

were sent to the interviewees, and also the tasks that

would be performed were clariﬁed. Thereafter, the par-

ticipants needed to perform the analysis of the check-

list and to provide their contribution during the inter-

view.

The list of documents that were provided to the

experts before the interviews were Informed Consent

Term (ICT) and Proﬁle Questionnaire, Survey Guide-

line, and Information on the Interview.

4.1 Pilot Test

The pilot test was a small trial to assure that the study

was viable. This test checked whether the procedure

and questionnaire questions were set properly, and to

identify if the process and documents had any potential

problem. Furthermore, during the pilot test, small

adjustments were made to the main study documents

and procedures. To validate the protocol and interview

documents, we performed a pilot test with an HCI

expert.

During the pilot test, the pilot subject had access to

the documents in the same way that actual participants

would have, in order to obtain the faithful perception

of what would be carried out during the interviews.

We veriﬁed the duration of the test, the understanding

of the messages sent by e-mail, the level of knowledge

on the topic to be evaluated and, ﬁnally, the analysis

of the checklist.

The pilot subject suggested some improvements

on the checklist, for example, to add some examples

and the include a text box at the end of the instrument,

so that the HCI expert could mention problems that

would not ﬁt the issues present in the questionnaire. In

general, the pilot subject believed that the instructions

on the invitation e-mail were clear and met the purpose

of the study, as well as the tasks and DSL examples

used to accomplish the tasks.

4.2 Proﬁle

For the interviews, seven (7) participants were re-

cruited by e-mail. This sample was selected look-

ing for experienced professionals in HCI (researchers

that published relevant papers on HCI conferences).

Furthermore, participants were also invited when rec-

ommended by other participants who were considered

experts. After acceptance, the documents for the in-

terview were sent to them. The Proﬁle Questionnaire

was used to identify the experience of the participant

and other relevant information. In order to obtain the

information regarding the participants’ experience, the

following questions were asked:

- What is your

name?;

- What is your work position?;

- Which

usability evaluation method(s) have you already par-

ticipated in (Heuristic Evaluation, Usability Testing

or None)?;

- Which usability evaluation method(s)

have you already conducted (Heuristic Evaluation, Us-

ability Testing or None)?;

- What is your level

of expertise related to HCI (Very Poor, Poor, Neutral,

Strong or Very Strong)?;

- What is your level of

expertise related to Usability (Very Poor, Poor, Neu-

tral, Strong or Very Strong)?; and,

- What is your

level of expertise related to Heuristic Evaluation (Very

Poor, Poor, Neutral, Strong or Very Strong)?

In this paper the answers of the proﬁle question-

naire, as well as the other answers of the study were

identiﬁed by the label attributed to each participant, i.e.

from P1 to P7 (see Table 4).

In this study, as mentioned before, the participants

were experts on HCI and most of them had already

performed a Heuristic Evaluation. One participant

had no experience on Heuristic Evaluation, but had

a strong level of expertise on HCI, and his consid-

eration on the checklist was relevant on the view of

a DSL designer. The other participant who had no

knowledge on Heuristic Evaluation had experience on

Usability Testing and a very deep knowledge on HCI.

The reported experience could be perceived from the

responses captured during the interviews.

HUCAPP 2021 - 5th International Conference on Human Computer Interaction Theory and Applications

Table 3: Snippet for our HEC.

Heuristic Description Question

Severity

(Check each of the

problems found)

Description

of each error

occurrence

0 1 2 3 4

H1:

Visibility

of system

status

The DSL should

always keep users

informed about what

is going on, through

appropriate feedback

within reasonable

time.

Does the DSL provide immediate

an adequate feedback on its

status for each user action?

For example, after an include

or exclude task the language

displays a commit message?

Do the elements available for

the user speciﬁcally execute

only one command? For example,

the “undo” button only

performs undo actions.

Table 4: Subjects Proﬁle.

Q1 Q2 Q3 Q4 Q5

HE UT

None

HE UT

None 5.1 5.2 5.3

P1 Professor HCI ﬁeld X X X X V V V

Quality Assurance Engineer

X X X S N N

Professor/Developer

X X N N N

P4 Professor HCI ﬁeld X X V S S

P5 Professor HCI ﬁeld X X X X S N N

P6 Professor HCI ﬁeld X X X X V S S

PhD.Candidate in Computer Science

X X X X S S V

HE - Heuristic Evaluation, UT - Usability Testing V - Very Strong, S - Strong, N - Neutral

4.3 Interviews

The interviews started after the pilot test and after

each participant had submitted the ICT. The interviews

were conducted over a period of six (6) months be-

tween December 2018 and June 2019. The execution

of the interviews were predominantly online (5 online

and 2 in-person). All interviews were audio recorded

in order to perform further analysis. Each interview

lasted an average of 60 minutes. The interviews were

semi-structured, providing a certain ﬂexibility to ad-

just questioning based on participant responses. Each

interview covered ﬁve central topics: (1) Deﬁnition of

heuristics; (2) Checklist’s structure and organization;

(3) Checklist’s content; (4) Amount of information

displayed; (5) Checklist’s template.

Each topic is guided by questions that direct the

interview purpose:

• Topic 1

- the ﬁrst topic was assessed by two ques-

tions:

T1Q1

- Are the heuristic deﬁnitions appro-

priate for assessing a DSL?

T1Q2

- Is it possible

to understand the objective of each heuristic after

reading its respective deﬁnition?

• Topic 2

- the second topic was assessed by three

questions:

T2Q1

- Does the order in which heuris-

tics are organized adequate?

T2Q2

- Do you think

heuristics should be grouped, for example, in rela-

tion to graphical aspects or documentation?

T2Q3

- If so, which heuristics should appear at the begin-

ning or end of the checklist?

• Topic 3

- the third topic was assessed by ﬁve ques-

tions:

T3Q1

- Do the questions that correspond to

each of the heuristics reﬂect their purpose?

T3Q2

- In your opinion, are the above questions linked to

heuristics clearly and unambiguously?

T3Q3

- Is

there any question you do not understand?

T3Q4

Would you add any question? Which ones?

T3Q5

- Would you remove any question? Which ones?

• Topic 4

- the forth topic was assessed by one ques-

tion:

T4Q1

- The checklist is guided by 10 heuris-

tics that are composed of around 32 questions in

the most extensive Checklist. Regarding the exten-

sion of the checklist, what is your opinion?

• Topic 5

- the last topic was assessed by one ques-

tion:

T5Q1

- What do you think about the way

the checklist is presented? (Heuristics, Deﬁnitions,

Questions, Degree of Severity and description of

Heuristic Evaluation Checklist for Domain-speciﬁc Languages

found errors).

After the interviews were completed, the opinions’

transcription were performed and organized according

to the Inductive Thematic Analysis method (Braun

and Clarke, 2006). These analyzes are presented in the

next section.

4.4 Qualitative Analysis

The interview analyses was performed using the In-

ductive Thematic Analysis method (Braun and Clarke,

2006), which categorizes the main themes gathered

from the experts’ responses. This approach is common

on HCI qualitative research (Clark et al., 2019) (Luger

and Sellen, 2016).

For the Inductive Thematic Analysis execution, the

audios from the interviews were transcribed. Then,

the content was coded by similarity, forming group

themes. As the last step, two (2) researchers reviewed

the created themes, making some adjustments to best

represent the obtained information. The analysis is

presented next.

Each theme has a summary description and quotes

that supports the theme’s objective.

4.4.1 Checklist’s Description

This theme presents the opinions related to the descrip-

tions used in the heuristic checklist. As the proposed

checklist is an instrument customized to contemplate

all the Nielsen’s Heuristics focusing on the DSL do-

main, one of our main concerns was if the description

of the heuristics was appropriated. All participants

aﬃrmed that the descriptions created would be useful

for the checklist’s execution. Participants P1 and P7,

who have experience in HE and UT, highlighted the

following:

“I think the deﬁnitions are appropriated. They are

embracing and generic enough, following the pattern

created by Nielsen but with a focus on DSLs.” [P7]

“It is going to be natural for the evaluators to

execute the evaluation as they can evaluate in a broad

perspective and make annotations.” [P1]

4.4.2 Detailing

Five participants (P1, P2, P3, P4 and P5) reported the

need for more details related to the checklist presenta-

tion and also to its content. The main issues reported

are related to the severity rating usage and the lack of

questions in speciﬁc heuristics.

“It would be helpful to have a small text explaining

the severity rating.” [P3]

“The evaluator needs to describe the error in a

clear way in order to assimilate the severity rating.”

[P4]

“There should be more questions about consis-

tency. I notice that there are some questions related to

patterns, but there is a lack of questions about consis-

tency.” [P2]

The above quotes highlight some improvements to

be made to the checklist. While developing the cus-

tomized checklist, we tried to avoid extensive texts in

order to not cause fatigue when the evaluation process

occurs. However, the feedback received from HCI ex-

perts emphasized the need for clariﬁcation on certain

aspects of the checklist, such as the purpose of the

severity classiﬁcation and the extent of the questions.

4.4.3 Incomprehension

Four (4) participants (P1, P2, P4 and P6) made sugges-

tions for improvements to the checklist or its structure.

The suggestions were related to Heuristic 7 (Flexibil-

ity and Eﬃciency of Use) and on the execution of the

checklist according to the severity of the classiﬁcation

provided rating.

“I see the severity rating here, but imagine that I

did not ﬁnd any error... What should I mark?” [P6]

The feedback analysis provided by the HCI experts

led us to ask how the evaluators would perform the

DSL evaluation using this checklist.

Participant P1 reported that the classiﬁcation of the

provided severity scale was not intuitive to use, arguing

that it was diﬃcult to understand its use. We mitigated

this issue by applying the suggestions captured in the

previous theme (Detailing) and adding a small text to

guide the severity scale classiﬁcation.

Another interesting feedback collected was related

to Q3 and Q4 of Heuristics 7, as some evaluators dis-

agreed on their answers. The statements of the HCI

experts underline the need for minor modiﬁcations to

make their purpose clearer.

4.4.4 Evaluator’s Proﬁle

Although Participant P3 was not an expert in usability

evaluation, he had considerable experience in software

development. Hence, P3 stated that the evaluation

using the proposed checklist may be performed by any

professional with background in system evaluation,

even if this professional is not an expert in heuristic

evaluation.

“I think it could be used by evaluators who are

not experts in heuristic evaluations but have already

evaluated systems using other methods.” [P3]

The statement above highlights the adaptability

of this instrument for a wide-range of professionals

HUCAPP 2021 - 5th International Conference on Human Computer Interaction Theory and Applications

related to usability.

4.4.5 Content Changes

Two participants (P1 and P4) suggested changes on

the content of the heuristic checklist. In general, they

stated that some questions needed to be reformulated

and/or classiﬁed in another heuristic.

“Questions 3, 4 and 5 of Heuristic 3 must be clas-

siﬁed in Heuristic 5” [P1]

“Well, I think that the question presented in Heuris-

tic 10 needs to be reviewed.” [P4]

“When you ask about help and documentation... I

don’t think that documentation is important for this

kind of evaluation, when I read documentation I think

about a broad documentation about the system” [P4]

4.4.6 Template Changes

All participants reported the need of changing the order

of the visual components that compose the checklist

form. The main suggestions were related to the posi-

tion of the elements and the lack of space for adding

relevant information.

“I think that you could use colors to enhance the

reading of the heuristics” [P5]

“Maybe the severity description could be at the

beginning of the checklist, not at the end as it is. In

this way the access for this information will be easier”

[P7]

“It would be interesting to have a blank space for

the evaluator to add some relevant issues” [P3]

In order to mitigate these issues, we reviewed the

checklist’s template and followed the suggestions of

some participants, such as changing the order of prob-

lem description and severity rating, so that the check-

list would be more intuitive to use; and adding a blank

box for the evaluator to describe errors that were not

contemplated by the used heuristics.

4.4.7 Instrument’s Amplitude

Participant P7 pointed out one weakness of the check-

list by reporting that if evaluators follow narrowly the

questions presented in the checklist, maybe some er-

rors presented in the DSL would not be found. We

are aware of this weakness and we mitigated it by em-

phasizing that the role of the questions are to guide

the evaluators on common usability problems and the

evaluators must report other perceived problems in the

extra blank box.

“Perhaps, I don’t know if the evaluators would

ﬁnd all the errors if they followed only your questions.”

[P7]]

4.5 Discussion

This study presents the development of a HEC in

which the checklist is guided by questions that conduct

the evaluation for a speciﬁc domain.

The analyses performed on the interviews showed

that this HEC can assist evaluators to conduct DSL

evaluations. Furthermore, it was also noticed that a

checklist guided by questions directed to the context

of use provides a better understanding about the evalu-

ation.

Some changes proposed by the HCI experts were

applied to the ﬁnal HEC (presented in Section 3).

These changes were related to the content of the check-

lists, as well as, their structure and template. Such

changes were pertinent so that it was possible to carry

out the ﬁrst study through an example of use (see Sec-

tion 5), in which a textual DSL was analyzed. The

purpose of performing the evaluation of this example

of use was to get insights into the proposed Heuristic

Evaluation Checklists for DSLs.

5 EXAMPLE OF USE

In order to verify the applicability of the proposed

HEC, we asked ﬁve subjects to experiment it on an

example of use. The example of use is a well-known

DSL in the academic environment, i.e., LaTeX. This

language was chosen since all the participants had

previous experience on using it. The following arti-

facts were chosen for this example of use: informed

consent term, participants proﬁle questionnaire, DSL

guide, list of task to be performed, and a copy of the

Heuristic Evaluation Checklist for textual DSLs

It is worth mentioning that since the main objective

of this study was to obtain a ﬁrst view of the feasibility

of the Heuristic Evaluation Checklist for textual DSL.

Thus, we only sent the documentation via e-mail and

collected the participants’ perceptions regarding the

heuristic evaluation of LaTeX through our checklist

proposal. Hence, from the responses from the partici-

pants, we performed a qualitative analysis regarding

each of the found problems and their severity.

5.1 Analysis

Before discussing the results for each of the ten heuris-

tics in our HEC, we describe the participants proﬁle:

Due to space restrictions, only the main information

related to the example of use is presented in this paper - all

example of use can be found at https://drive.google.com/

ﬁle/d/1KKhse6OgnKbqRtreW-zZOGCehmFnILWS/view?

usp=sharing.

Heuristic Evaluation Checklist for Domain-speciﬁc Languages

one is undergraduate student and four are master stu-

dents in Software Engineering; the average time of ex-

perience using or designing DSL is 2.4 years; all partic-

ipants have experience in performing or participating

in usability evaluation; three participants have just one

year experience in usability evaluation; two of them

have already participated on usability evaluation using

usability testing; two of them have have already partici-

pated of usability evaluation using heuristic evaluation;

just one of the participants has already conducted a

usability evaluation using heuristic evaluation.

The analysis of the results points for each heuristic

as follows:

Q2: Participants E2, E3 and E5 agreed that there

is no undo button and mentioned that the action is

only possible using the Ctrl + Z keys. Regarding

the degree of severity, two of the participants be-

lieved that ﬁxing this should be given low priority.

Q3: Participant E5 considered that LaTeX has ab-

breviated keywords, and that this makes it diﬃcult

for other users to adopt this language. He also re-

ported that it is important to ﬁx this problem, i.e.

it should be given high priority.

Q6: Participant E3 reported that some errors are

shown in real time and others only after compi-

lation. The participant also indicated that LaTeX

does not provide information about commit, and

this may be part of the tool that instantiates the

language. Regarding the degree of severity for this

problem, the participant considered it a cosmetic

problem.

Q7: Regarding H3, four participants (E1, E2, E3

and E5) reported that there are synchronization

problems, the environment warns that changes are

made in a certain period of time and that they

may not have been saved. Furthermore, they also

stated that the changes are saved automatically,

but if there are internet connection problem, the

re-connection message may not be accurate and

changes in the document might not have been

saved. E1 mentions: “The problems are only

showed after the .tex compilation”. This question

had disagreement of the degree of severity among

participants, i.e. 1, 2 and 4. Hence, there was no

consensus among them related to this question.

H4 No problem found.

Q11: Participants E1, E4 and E5 mentioned that

the environment does not have conﬁrmation boxes

or buttons for actions. E1 assigned severity degree

2, while E4 and E5 assigned severity degree 1.

H6 No problem found.

Q16: The participants mentioned the following

for this question: E2 mentions that if someone

considers the generated pdf as an output, in this

case the changes do occur; E4 states that there

is no graphic DSL, only the preview of the text

written in the generated pdf; and, E5 considers

that only when the changes to the textual DSL are

compiled, they are observed in the graphical DSL.

The severity degree assigned is zero, so they do

not consider any usability problem here.

Q19: Participants E2 and E3 mentioned that to

have a color change, LaTeX commands must be

entered. These participants considered that this is

not a usability problem and attributed zero to the

degree of severity.

Q20: Participants E2, E3 and E4 stated that the

error messages are not intuitive or easy to under-

stand, on the contrary they are confusing and hin-

der rather than help. Such messages are diﬃcult

to quickly identify the problem, so it is often nec-

essary to have technical knowledge to deal with

errors. Therefore, E2 assigned 3 to the degree of

severity, while E3 and E4 assigned 2 to the degree

of severity.

Q21: Participants E1, E2 and E5 mentioned that

there is no tutorial for LaTeX, however the tem-

plates have it. Moreover, related to the degree of

severity attributed by those who say there is no

documentation ranges from cosmetics to usability

catastrophe.

5.2 Discussion on the Example of Use

Our Heuristic Evaluation Checklist helped the partic-

ipants to respond more adequately the questions re-

garding the evaluation of the DSL. The ones that had

previous experience on heuristic evaluation performed

better than the ones that did not have previous expe-

rience. Hence, it seems that, despite our HEC help-

ing the participants to evaluate a DSL, it needs some

further instructions on how to ﬁll the questionnaires.

Maybe this can help not so experienced participants to

better understand and answer the questions.

6 CONCLUSION

The Heuristic Evaluation (HE) method is a widely

used approach for usability inspection. This method

is easy to perform and it allows the discovering of

various usability issues. The HE method is freely

applied by the evaluators. These evaluators go through

HUCAPP 2021 - 5th International Conference on Human Computer Interaction Theory and Applications

the application interface pointing out the errors, and

consequently classifying them to the degree of severity.

Although Heuristic Evaluation is frequently used

for usability evaluation, heuristics are used to evaluate

user interfaces for many diﬀerent domains. For this

reason, many researchers adapt the heuristics to their

application domain. Several authors use an informal

process to develop or adapt usability heuristics and do

not follow an established and systematic protocol for

heuristic assessment.

Our approach presents a diﬀerent strategy to apply

HE. The proposal provides a checklist that is diﬀerent

from existing solutions. In our proposal, each heuris-

tic is guided by questions that direct the evaluator to

eﬀectively evaluate the DSL.

Regarding the evaluation of the created HEC, we

performed 7 (seven) interviews with researchers and

professionals on HCI. These interviews were analyzed

using the Inductive Thematic Analysis method,which

resulted in a group of common themes of opinions,

suggestions and ideas discussed in this study. These

results led us to make improvements in the HEC.

Some of the most important questions provided by

the HCI experts were related to the depth and ampli-

tude of the questions and how the evaluators would

use the checklist to perform the heuristic evaluation on

a DSL. Suggestions regarding the checklist’s template,

such as changing the order the columns and providing

the evaluator with a blank box to freely report prob-

lems not yet classiﬁed, were discussed and accepted.

Moreover, we also engaged in a deep discussion

around covering all the aspects of Textual and Graphi-

cal DSLs using the Nielsen’s heuristics. We decided

to create more questions for speciﬁc heuristics, such

as Flexibility and Eﬃciency of Use (H7). However, it

must be stated that the checklists created must be seen

by the evaluators as a guidance to perform the inspec-

tion and if they ﬁnd usability problems not covered by

the content of the checklist, they must describe them

in the provided blank box.

Based on the opinions obtained through the inter-

views, we made some changes to the HEC, which were

suggested by the interviewees. After completing these

changes, we applied the proposed checklist using an

example of use, in order to understand its behavior

when used in a context close to a real one. Thus, this

usage example included (5) participants, who used the

Latex textual DSL. Preliminary results showed that our

HEC helps experienced and non experienced usability

evaluators, but some improvements are needed for non

experienced usability evaluators.

As future work, we aim to apply some Norman

design principles (Norman, 2013) to our proposal,

i.e. aﬀordance, cognitive overload, and visibility. We

still intend the analyze the applicability of the created

checklists in several real scenarios in order to under-

stand how the evaluation procedure will be performed

with those artifacts.

ACKNOWLEDGEMENTS

This study was ﬁnanced in part by the Coordenação

de Aperfeiçoamento de Pessoal de Nível Superior -

Brasil (CAPES) - Finance Code 001. Avelino F. Zorzo

is supported by CNPq (315192/2018-6).

REFERENCES

Alonso-Ríos, D., Vázquez-García, A., Mosqueira-Rey, E.,

and Moret-Bonillo, V. (2009). Usability: A critical

analysis and a taxonomy. International Journal of

Human-Computer Interaction, 26(1):53–74.

Bariši

c, A., Amaral, V., and Goulao, M. (2018). Usabil-

ity driven dsl development with use-me. Computer

Languages, Systems & Structures, 51:118–157.

Braun, V. and Clarke, V. (2006). Using thematic analysis

in psychology. Qualitative Research in Psychology,

3(2):77–101.

Clark, L., Pantidi, N., Cooney, O., Doyle, P., Garaialde, D.,

Edwards, J., Spillane, B., Gilmartin, E., Murad, C.,

Munteanu, C., Wade, V., and Cowan, B. R. (2019).

What makes a good conversation?: Challenges in de-

signing truly conversational agents. In Conference on

Human Factors in Computing Systems (CHI), pages

475:1–475:12. ACM.

Fowler, M. (2005). Language Workbenches: The Killer-App

for Domain Speciﬁc Languages?

Fowler, M. (2010). Domain Speciﬁc Languages. Addison-

Wesley Professional, 1st edition.

Hermawati, S. and Lawson, G. (2016). Establishing usability

heuristics for heuristics evaluation in a speciﬁc domain:

Is there a consensus? Applied Ergonomics, 56:34 – 51.

Luger, E. and Sellen, A. (2016). “like having a really bad

pa”: The gulf between user expectation and experience

of conversational agents. In Conference on Human Fac-

tors in Computing Systems (CHI), pages 5286–5297.

ACM.

Mernik, M., Heering, J., and Sloane, A. M. (2005). When

and how to develop domain-speciﬁc languages. ACM

Computing Surveys, 37(4):316–344.

Mosqueira-Rey, E. and Alonso-Ríos, D. (2020). Usability

heuristics for domain-speciﬁc languages (dsls). In SAC,

pages 1340—-1343.

Nielsen, J. (1993). Usability Engineering. Morgan Kauf-

mann Publishers Inc., San Francisco, CA, USA.

Nielsen, J. (1994). 10 Usability Heuristics for User Inter-

face Design. Available in: https://www.nngroup.com/

articles/ten-usability-heuristics/.

Heuristic Evaluation Checklist for Domain-speciﬁc Languages

Nielsen, J. and Molich, R. (1990). Heuristic evaluation of

user interfaces. In Conference on Human Factors in

Computing Systems, pages 249–256. ACM.

Norman, D. (2013). The Design of Everyday Things: Revised

and Expanded Edition. Basic Books.

Poltronieri, I., Zorzo, A. F., Bernardino, M., and

de Borba Campos, M. (2018). Usa-DSL: Usability

Evaluation Framework for Domain-speciﬁc Languages.

In SAC, pages 2013–2021. ACM.

Quiñones, D., Rusu, C., and Rusu, V. (2018). A method-

ology to develop usability/user experience heuristics.

Computer Standards & Interfaces, 59:109 – 129.

Rodrigues, I., Campos, M. B., and Zorzo, A. (2017). Us-

ability Evaluation of Domain-Speciﬁc Languages: a

Systematic Literature Review. In International Confer-

ence on Human-Computer Interaction, pages 522–534.

Springer.

Sadowski, C. and Kurniawan, S. (2011). Heuristic evalua-

tion of programming language features: Two parallel

programming case studies. In Workshop on Evaluation

and Usability of Programming Languages and Tools,

pages 9–14. ACM.

Schmidt, D. C. (2006). Guest editor’s introduction: Model-

driven engineering. Computer, 39:25–31.

Sharp, H., Preece, J., and Rogers, Y. (2019). Interaction

Design: Beyond Human - Computer Interaction. Wiley

Publishing, 5th edition.

Sinha, A. and Smidts, C. (2006). An experimental evalua-

tion of a higher-ordered-typed-functional speciﬁcation-

based test-generation technique. Empirical Software

Engineering, 11(2):173–202.

Stone, D., Jarrett, C., Woodroﬀe, M., and Minocha, S. (2005).

User Interface Design and Evaluation. Interactive

Technologies. Elsevier Science.

Van Deursen, A., Klint, P., and Visser, J. (2000). Domain-

speciﬁc languages: An annotated bibliography. SIG-

PLAN Notes, 35(6):26–36.

HUCAPP 2021 - 5th International Conference on Human Computer Interaction Theory and Applications
