Hybrid Feature based Pyramid Network for Nighttime Semantic

Segmentation

Yuqi Li, Yinan Ma, Jing Wu and Chengnian Long

∗

Department of Automation, Shanghai Jiao Tong University, Shanghai, China

Keywords:

Semantic Segmentation, Nighttime Dataset, Exposure-aware Network.

Abstract:

In recent years, considerable progress has been made on semantic segmentation tasks. However, most existing

works focus on only day-time images under favorable illumination conditions. In this work, we aim at night-

time semantic segmentation, which is remaining to be solved due to the problems of over- and under-exposures

caused by complex lighting conditions and the lack of trainable nighttime dataset as pixel-level annotation re-

quires extensive time and human effort. We (1) propose a hybrid network combining image pyramid network

and Gray Level Co-occurrence Matrix (GLCM). GLCM is a signiﬁcant descriptor of texture information, as

statistical features to compensate the missing texture information in the over- and under-exposures problem at

night. (2) design an exposure-awareness encoder network by fusing hybrid features hierarchically in GLCM

fusion layers. (3) elaborately generate a trainable nighttime dataset, Carla-based Synthesis Nighttime dataset

(CSN dataset), with 10027 synthesis images to resolve the problem of large-scale human annotations. To

check whether the network trained on synthesized images is effective in the real world we also collect a real-

world dataset called NightCampus with 500 nighttime images with annotations used as test dataset. We prove

that our network trained on synthetic dataset yielding top performances on our real-world dataset.

1 INTRODUCTION

Semantic segmentation is to assign a speciﬁc class

or category label to each pixel in the images accord-

ing to its semantic meanings. Credit to deep Convo-

lutional Neural Networks (CNNs) ﬁrst introduced in

this ﬁeld by FCN (Long et al., 2015), many semantic

segmentation methods have achieved real-time per-

formance without sacriﬁcing too much quality (Zhao

et al., 2018; Yu et al., 2018; Nekrasov et al., 2018).

However, in outdoor scenes we hardly see the appli-

cations of these computer vision works, which mainly

focusing on only day-time images under favorable il-

lumination conditions, exert their efﬁciency and reli-

ability, as their accuracy declines signiﬁcantly under

challenging lighting conditions like nighttime.

Most of the current night semantic segmentation

methods tend to use Far-Infrared (FIR) camera in-

stead of visible light camera. However, FIR cam-

eras are expensive and infrared images lack color in-

formation and texture information. Their contrast

and signal-to-noise ratio are relatively low. So the

methods based on infrared images is not suitable for

semantic segmentation with high resolution require-

ments. In this work, we are focusing on nighttime

Figure 1: Examples in NightCampus dataset. Nighttime im-

ages have both over-exposure problems and under-exposure

problems. The texture and color information of vegetation

almost disappear because there is no light source, while the

street lights and headlight of cars area also loss texture in-

formation.

semantic segmentation with RGB images.

There are two main challenges to the problem of

semantic segmentation of RGB images at night:

First, the reason why semantic segmentation using

visible light cameras do not perform well at night-

time scenes is that extremely weak illuminance will

degrade the structure, texture and color characteris-

tics of input images. Nighttime images have both

over-exposure problems and under-exposure prob-

Li, Y., Ma, Y., Wu, J. and Long, C.

Hybrid Feature based Pyramid Network for Nighttime Semantic Segmentation.

DOI: 10.5220/0010248503210328

In Proceedings of the 16th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2021) - Volume 4: VISAPP, pages

321-328

ISBN: 978-989-758-488-6

321

lems. For example, in Figure. 1, the texture and color

information of vegetation almost disappear because

there is no light source, seems like an empty black re-

gion. The same situation happens in the street lights

and headlight of cars area, but looks like an empty

white region. Therefore, how to solve the problem of

those information loss caused by over-exposure and

under-exposure is the primary issue of semantic seg-

mentation in nighttime scene.

Second, there are no large-scale labeled datasets

available for nighttime scenes. Existing large data sets

for semantic segmentation mainly contain daytime

images, with little or no nighttime images. While the

training of deep neural network is dependent on the

input data. Therefore, the lack of trainable datasets in

this ﬁeld has impeded the development of nighttime

semantic segmentation.

Aimed on the above challenges, we proposed a hy-

brid network combining image pyramid network and

Gray Level Co-occurrence Matrix (GLCM). GLCM

is a signiﬁcant descriptor of texture information, as

statistical features to compensate the missing infor-

mation in the over- and under-exposures convolution

and decline overﬁtting problems. Texture is an in-

herent global feature of an image and almost cannot

be affected by noise. So its an important information

used in the segmentation task, especially in nighttime

tasks where color information is hardly exist. The

Pyramid structure allow the multi-resolution input of

original images and thus enable the network consider

both global information and local detailed features,

learning the weight between global and local infor-

mation. We design an exposure-awareness encoder

network by fusing hybrid features in GLCM fusion

layers in a single hierarchy. The GLCM fusion layer

is introduced to guide the network to learn where is

the over-and under-exposure region in order to sup-

plement GLCM features.

Besides, to tackle the lack of trainable nighttime

dataset, and to solve the problem of extensive time

and human effort wasted when annotating large train-

able nighttime dataset, we elaborately generate 10072

synthesis campus-like nighttime images called CSN

dataset based on Carla simulator instead. The CSN

dataset is pixel-wise annotated by computer and has

no annotation errors undoubtedly. To check whether

the network trained on synthesized images is effec-

tive in the real world, we collect a real-world dataset

called NightCampus with 500 real-world nighttime

images with pixel-level label annotations used as test

dataset.

We prove that our Hybrid Feature based Pyramid

Network (HFPNet) trained on synthetic dataset yield-

ing top performances on our real-world dataset. As

shown in our experiments, our work slightly superior

to other real-time algorithms in daytime as we got

73.9% mIoU at 32 FPS on CityScapes test dataset,

and substantially improved performance on nighttime

scenes as we obtained nearly 5% mIoU improvement

comparing to the other dattime methods on CSN vali-

dation dataset and 88.3% mIoU on NightCampus test

dataset.

2 RELATED WORKS

Infrared Information based Fusion Methods for

Nighttime. Most of the current night semantic seg-

mentation algorithms use thermal imaging images

based on infrared cameras. (Zhiyi Liu, 2020) pro-

posed a semantic segmentation algorithm for un-

manned vehicle night infrared images based on the

improved DeepLabv3+ network. A monocular vi-

sion system (Ge et al., 2009) is proposed for real-time

pedestrian detection and tracking using near infrared

(NIR) cameras while driving at night. Xu F. et al. (Xu

and Fujimura, 2002) proposed a method for pedes-

trian detection and tracking using a single night vi-

sion camera mounted on a vehicle. (Wang, ) collected

infrared scene image data sets, combined with the

ideas of InceptionNet and ResNet, proposed a 100-

layer parallel residual network structure PresNet-100,

and constructed a multi-scale semantic segmentation

network Multi-PresNet based on PresNet.

However, infrared images contrast and signal-to-

noise ratio are relatively low. Most of them it needs

to be aligned and merged with RGB images, the op-

eration of which is more complicated. Also data they

used are usually in subdivided scenes. So the methods

based on infrared images is not suitable for semantic

segmentation with high resolution requirements.

GAN based Day-night Conversion Methods for

Nighttime. Although most existing works focus on

the standard daytime conditions under favorable il-

lumination, there are also some works that address

the challenging scenarios. Christos Sakaridis1 et al.

(Sakaridis et al., 2019) designed a Curriculum frame-

work by adapting daytime models to nighttime scenes

without using nighttime scene annotations by GAN.

They also collected the dark Zurich dataset, which in-

cluded 151 pixel-level annotated night image as test

dataset (dataset keeps private). Lei Sun et al.(Sun

et al., 2019) trained a day-night conversion network

by CycleGAN. CycleGANs are used to transfer night-

time images to the daytime and different ratio of day-

time images in the dataset to the nighttime while

keeping their label.

They require pixel-level matches, images corre-

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

322

Figure 2: Our Hybrid Feature based Pyramid Network pipline. Given RGB images, ResNet extracts 4 resolution feature

maps which form an image pyramid and corresponding Laplacian pyramid in the shallowest two layers. GLCM feature maps

calculated by gray level input images are used as a mask of the fused feature maps in GLCM fusion layer. L1,L2 are Laplacian

pyramid feature maps, blue line represent up-sampling.

sponding to the same position and the same angle

during the daytime and other periods, which is harsh

for dataset collecting. And their networks are mainly

used to generate datasets, does not directly solve

the problem of information loss caused by over- and

under-exposure at nighttime.

Image Pyramid Structure. FPNNet (Lin et al.,

2017) fuse the low-resolution feature maps with

strong semantic information and the high-resolution

feature maps with weak semantic information but rich

spatial information under the premise of increasing

less computational complexity. Or

c et al.(Or

c and

Segvic, 2020) proposed a approach based on shared

pyramidal representation and fusion of heterogeneous

features along the upsampling path. The proposed

pyramidal fusion approach is especially effective for

dense inference in images with large scale variance

due to strong regularization effects induced by feature

sharing across the resolution pyramid.

3 HYBRID FEATURE BASED

PYRAMID NETWORK

We propose a hybrid network (HFPNet), which com-

bines an image pyramid network and GLCM. The

pipeline of HFPNet is shown in Fig. 2. The well-

designed exposure-awareness decoder network in HF-

PNet consists of GLCM fusion layers and Fusion

Blocks hierarchically to force encoder network learn

effective features in image pyramid.

Figure 3: The calculation process of co-occurrence matrix.

3.1 Gray Level Co-occurrence Matrix

Feature Map

The gray-level co-occurrence matrix is based on stud-

ies of the statistics of pixel intensity distributions. It

is a matrix describing the gray-scale relationship be-

tween a pixel in a local or whole area of an image

and neighboring pixels or pixels within a certain dis-

tance d. The co-occurrence matrices provide raw

numerical data on the texture, however in practical

applications, from the perspective of the calculation

efﬁciency of texture features and the storage of the

GLCM matrix, the gray level of the original image is

usually ﬁrst compressed. For example, from 8-bit im-

ages with gray levels of 0 −255 to 5-bit images with

gray levels of 0-31, the dimension of the correspond-

ing co-occurrence matrix is reduced from 256 ×256

to 32 ×32.

Calculation of GLCM. During the graying process,

we use the formula

Gray = 0.114B + 0.587G + 0.299R, (1)

where R,G,B are the value of three channel of RGB

Hybrid Feature based Pyramid Network for Nighttime Semantic Segmentation

323

image. In order to construct a co-occurrence matrix, it

is necessary to consider the ﬁxed distance of all pixel

pairs from each other, without considering the relative

direction formed by the line connecting them and the

image reference direction, which means that the only

parameter is the distance d, the system can have any

number of optional matrices:

C (k, l;d) =

∑

δ(k −g(i, j))δ(l −(g((i, j) + d ˆn)),

(2)

where ˆn is the unit vector pointing in a chosen direc-

tion, g(i, j) is the gray value of pixel (i, j), (g((i, j) +

d ˆn)) is the gray value of another pixel that is at dis-

tance from pixel (i, j) and at the orientation deﬁned by

unit vector ˆn (e.g. assume ˆn = (0, 1), representing the

horizontal direction, thus g((i, j) + d ˆn) = g(i, j + 1),

and C (k, l; d) is the total number of pairs of pixels

at distance d from each other identiﬁed in the image,

such that the ﬁrst one has gray value k and the second

has gray value l, as shown in Figure. 3. δ(x) repre-

sents the Dirac delta function, it equal to 1 if x = 0

and results in 0 when x 6= 0.

GLCM Feature. The 9 statistical attributes of texture

features calculated form GLCM matrix used in this

paper are Mean, Variance, Std, Homogeneity, Con-

trast, Dissimilarity, Entropy, Angular Second Mo-

ment, Correlation. Thus each pixel is associated to

9 statistical features obtained from GLCM, forming a

9 ×s ×s global feature map, where s is the size of

original image. During the graying process, if the

gray value of the target point is directly divided, it

will cause the image sharpness to be reduced. There-

fore, we ﬁrst convert the picture to perform histogram

equalization, so as to increase the dynamic range of

the gray value, which increases the overall contrast

effect of the image. Different textures shows distin-

guishing features, thus proving the GLCM features

are applicable descriptor for textures.

3.2 Image Pyramid Structured Network

In order to enhance multi-resolution information and

employ global and local features at the same time, we

used a pyramid-structured CNN in our work. Image

pyramid (Adelson et al., 1984) is a powerful but con-

ceptually simple structure that can interpret images at

multiple resolutions. Originally designed for machine

vision and image compression applications. By multi-

sampling the original image, images of different res-

olutions can be generated as a sequence.

Place the highest resolution images at the bottom

and arrange them in a pyramid shape. Since the base

level M is size 2

×2

or N ×N, where J = log

the intermediate level m is size 2

×2

, where 0 ≤

m ≤ M. Fully populated pyramids are composed of

M + 1 resolution levels from 2

×2

to 2

×2

That is, in general, the general limitation of P will

reduce the resolution approximation of the original

image; for example, the single-pixel approximation

of the 1 ×1 or 512 ×512 image has little value. The

total number of elements in a P + 1 level pyramid for

P > 0 is

(1 +

(4)

+ ···+

(4)

) ≤

. (3)

The Laplacian pyramid (Burt and Adelson, 1983)

retains the blurred version of the difference image be-

tween each level. Only the minimum level is not a

differential image, so that a higher-level differential

image can be used to reconstruct a high-resolution im-

age.

(x, y) = G

(x, y) −EXPAND(G

j+1

(x, y)), (4)

where L

(x, y) denotes the j-th level of Laplacian

pyramids and G

(x, y) and G

j+1

(x, y) denotes the j-th

level of Gaussian pyramid, the EXPAND is the up-

sampling operation.

3.3 Hybrid Feature based Network

Structure

Backbone. We use the ResNet-101 ( S1 to S4 in

Figure. 2) pretrained over the ImageNet(Krizhevsky

et al., 2012) dataset as the backbone to get 4 , 8 , 16

and 32 down-sampled feature maps.

GLCM Feature Map. As introduced in Section 3.1,

GLCM features form a 9×s ×s feature map, and this

global feature map is then sent into a 1 ×1 convolu-

tional layer to expand channels as the same as CNN

feature maps, thus we got ﬁnal GLCM feature map g.

In other words, GLCM Feature Maps g are extracted

by compressing the input images into different-bits

grayscale images.

GLCM Fusion Layer. To learn where are the texture-

lost regions, we introduce the GLCM fusion layer

G to augment GLCM features which contain com-

pensated information from nearby pixels. This layer

forces our model to learn the effective combination of

GLCM features that help predict the correct label and

guide the segmentation task towards an optimal per-

formance. Semantic segmentation requires both large

region context information and rich spatial informa-

tion. The former is mostly obtained through deep

hierarchies. For a single layer level, after we obtain

fused feature from image pyramid feature maps and

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

324

Figure 4: Class distribution in CSN dataset.

Laplacian pyramid feature maps mentioned above,

this feature map and GLCM feature map g are sent

into 1×1 convolutional layers separately followed by

a sum operation.

Image Pyramid Structure in Encoder. The Pyramid

structure enable a network consider both global infor-

mation and local detailed features, which respectively

corresponds to context information and spatial infor-

mation for semantic segmentation.

Fusion Block. Fusion blocks are used in each hierar-

chy to fuse high-resolution feature map f

i+1

obtained

from image pyramid network and the feature map

obtained from GLCM Fusion Layer G. Inside the fu-

sion block, each path is convolved with 3 ×3 convolu-

tion to determine the weight between two sets of fea-

ture maps and then upsampled to the same resolution

as f

i+1

. Two paths are summed up, and analagoulosly

further propagated through next fusion blocks until

the desired resolution is reached.

4 NIGHTCAMPUS AND CSN

DATASETS

As annotating large trainable nighttime dataset re-

quires extensive time and human effort, we elabo-

rately generate 10072 synthesis campus-like night-

time images based on Carla instead. Carla is an open

source simulator that can simulate real-world road

scenes. The Carla dataset is pixel-wise annotated by

Table 1: Distribution on different maps.

Geographical

environment

Maps vehicles pedestrian

Urban town01 [0,50,100] [0,100,200]

Urban town02 [0,50,100] [0,100,200]

Half-Urban

Half-Suburbs

town03 [0,80,160] [0,160,320]

Half-Urban

Half-Suburbs

town05 [0,80,160] [0,160,320]

Suburbs town04 [0,100,200] [0,200,400]

Figure 5: Sample images in CSN and corresponding

ground-truth label maps.

Figure 6: Sample images in NightCampus and correspond-

ing ground-truth label maps.

computer and has no annotation errors undoubtedly.

To check whether the network trained on synthesized

images is effective in the real world, we collect a

real-world dataset called NightCampus with 500 real-

world nighttime images with pixel-level label annota-

tions used as test dataset. We prove that the network

trained on synthetic dataset is able to perform well in

real-world scenes.

4.1 The CSN Dataset and Label

Annotation

The Carla simulator is in a town environment, with

roads, buildings, streets, trafﬁc lights and so on. How-

ever, pedestrians or vehicles are added by running

python script. We generate 10072 images which are

similar to real scenes lighting effect, 6000 of which

are used for training, 4072 of which are used for val-

idation. Size of those images is 1280 ×720. We set

different densities of pedestrians and vehicles, diver-

sity of geographical environment, as listed in Table. 1.

The class information is same as Cityscapes dataset,

as shown in Figure. 4,the class distribution in each im-

age is quite balanced. Figure. 5 shows sample images

and corresponding ground-truth label maps.

4.2 The NightCampus Dataset

Images in our dataset are from real world night-

time road scene captured in a campus. These im-

ages are captured by Logitech c270 size of images is

1280 ×960. Compared to urban road scenes, Night-

Campus has more pedestrians, vegetation, and fewer

vehicles, and darker scenes which means the contrast

of images is greater and the problem of over-exposure

and under-exposure is more serious. And in campus

Hybrid Feature based Pyramid Network for Nighttime Semantic Segmentation

325

scenes there are fewer types of vehicles, for example,

there is no train in campus, truck and bus seldom ap-

pear, so we merge all types of cars into one ’vehicle’

class. Similarly, terrain is in no need. Finally we get

9 classes in total, that is ’vehicle’ ’road’ ’sidewalk’

’sky’ ’pole’ ’vegetation’ ’person’ ’trafﬁc sign’. Some

regions that are too difﬁcult to deﬁne even by humans

are labeled as ’uncertain’ so that they are ignored dur-

ing training and evaluation. Figure. 6 shows sample

images and corresponding ground-truth label maps.

5 EXPERIMENTS

5.1 Implementation Details

All experiments are on a workstation with Tesla V100

GPU under CUDA 9.0 and CuDNN 7.0. The ex-

periments are conducted based on pyTorch. The

network use mini-batch stochastic gradient descent

(SGD) (Krizhevsky et al., 2012) with batch size 20,

momentum 0.9 and weight decay 1e

−5

in training.

The initial learning rate is different with encoder and

decoder, for encoder is 5e

−4

and for decoder is 5e

−3

Training is divided into three stages with different

learning rate, at the beginning of each training stage,

initial learning rate is reduced by half.

5.2 D Parameter Selection in GLCM

We tried different distance parameter d = 1, 2, 3,4 set-

tings, to ﬁnd the best performance for GLCM feature

extraction on our CSN dataset. The experiment result

is shown in Table 2. We use mean Intersection over

Union (mIoU) to evaluate the semantic segmentation

performance in our experiments.

When d = 1, 2 pixel of interest (POI) cannot get

enough texture information from nearby pixels, and

when d = 4, POI may learn feature which is not from

instrumental classes. The following experiments were

all taken under d = 3.

5.3 Ablation Study

We have tried to add GLCM guidence layers to sev-

eral different layers combinations. We number the

layer level from the shallowest to deepest from 1 to

4. Experiments on CSN vilidation set are shown in

Table 2: Experiments on CSN Validation Dataset with Dif-

ferent d.

GLCM para d = 1 d = 2 d = 3 d = 4

mIoU(%) 92.1 93.4 94.2 92.8

Table 3. For single layer cases, the deeper layer did

not achieve good results because for global features,

context information is more important. The following

experiments were all taken under 1 + 2 situation.

And to verify the effectiveness of the pyramid

structure, we conduct experiments on CSN valida-

tion dataset. when GLCM are excluded, performance

drops signiﬁcantly to 87.8% mIoU, which conﬁrms

the importance of GLCM focusing on the missing tex-

ture information. And pyramid structure also can help

learn useful features at both w&w/o GLCM situation.

5.4 Experiment on Nighttime Datasets

We trained HFPNet on the training set of CSN, and

compare it with other real-time networks on the CSN

validation set and NightCampus dataset.

Experiment on CSN and NightCampus. As shown

in Table 4, our work substantially improved perfor-

mance on nighttime scenes as we obtained nearly 5%

mIoU improvement comparing to the other dattime

methods on CSN validation dataset and 88.3% mIoU

on NightCampus test dataset. Due to the difference

between synthetic and real pictures, the performance

is reduced in NightCampus dataset, but not much se-

vere. We prove that our HFPNet trained on synthetic

dataset is able to perform well on real-world scenes.

The visualization examples are shown in Fig-

ure. 7. Compared to BiseNet, our HFPNet can seg-

ment over- and under-exposure regions more credi-

bly. Particularly, our model can produce more ac-

curate and clear boundaries in the segmentation of

buildings and vegetation. In addition, it makes the

sidewalk clearer and more complete. BiseNet ignores

some poles, but our street lights have been success-

fully identiﬁed in those cases.

Experiment on WildDash 2. WildDash 2 has 325

nighttime images, we test with WildDash 2 using HF-

PNet pretrained on Carla and got 56.7% mIoU, per-

formance declined much than on NightCampus be-

cause of severe motion blur and mirror reﬂection. No-

tice that classes of datasets are different so we set

those not corresponded as ignore label thus we do not

compare with others whose classes are inconsistent

with ours.

5.5 Experiment on CityScapes Dataset

CityScapes (Cordts et al., 2016) is a urban street

scene dataset from cars perspective, including 5000

high-resolution images as large as 1024 × 2048.

CityScapes has 19 semantic classes not counting ig-

nore label 255. We uploaded our semantic segmenta-

tion predictions to CityScapes organizers evaluation

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

326

Table 3: Experiments on Differenet Combination of Layers.

Layer Selection/single layer 1 2 3 4

mIoU(%) on CSN 89.2 91.5 88.2 83.8

Layer Selection/combination 1+2 1+2+3 1+2+3+4

mIoU(%) on CSN 94.7 90.1 85.4

Table 4: Results on CSN and NightCampus Dataset.

Method CSN validation set NightCampus test set

SegNet (Badrinarayanan et al., 2017) 51.3 45.6

BiSeNet (Yu et al., 2018) 89.6 84.3

ICNet (Zhao et al., 2018) 80.1 74.8

CCNet (Huang et al., 2018) 85.2 80.6

PSPNet (Zhao et al., 2017) 72.7 68.3

ReﬁneNet-LW101 (Nekrasov et al., 2018) 85.9 82.8

HFPNet 94.7 88.3

Table 5: Results on Test Set of Cityscapes.

Method Backbone Coarse Mean IoU(%) FPS

Deeplab (Chen et al., 2017) VGG16 × 63.1 0.25

FCN-8s (Long et al., 2015) VGG16 × 65.3 2

Dilation10 (Yu and Koltun, 2015) VGG16 × 67.1 0.25

LRR (Ghiasi and Fowlkes, 2016) VGG16 × 69.7 -

LRR (Ghiasi and Fowlkes, 2016) VGG16

√

71.8 -

ICNet* (Zhao et al., 2018) Res101 × 69.5 30.3

GUN* (Mazzini, 2018) DRN-D-22 × 70.4 33.3

PSPNet (Zhao et al., 2017) Res101

√

81.2 0.78

ReﬁneNet-LW101* (Nekrasov et al., 2018) Res101 × 72.1 36.8

HFPNet* Res101 × 73.9 32

*real-time semantic segmentation method.

Figure 7: Visualization examples of our results on Night-

Campus.

server and obtained feedback scores In our experi-

ments, we use ﬁne annotated images only. In Table 5,

Mean IoU and Frames Per Second(fps) are reported.

HFPNet only slightly superior to other real-time algo-

rithms in this daytime dataset as the visualization re-

sults shown in Figure. 8. That is because there are few

overexposed and underexposed areas so the weights

of GLCM features are approaching 0.

Figure 8: Visualization results on Cityscapes dataset.

6 CONCLUSION

In this paper, we tackled the problem of nighttime se-

mantic segmentation task, mainly focus on the miss-

ing texture information problem in over- and under-

exposure region. We achieved that by introducing

GLCM in our well-designed exposure-awareness de-

Hybrid Feature based Pyramid Network for Nighttime Semantic Segmentation

327

coder network to compensate the missing texture in-

formation. To tackled the lack of large trainable

dataset in this ﬁeld and to evaluate our HFPNet quan-

titatively, we presented a synthetic CSN dataset and

a real-world NightCampus dataset. We demonstrated

that HFPNet, which is trained on synthetic dataset,

yielding top performances on real-world scenes.

ACKNOWLEDGEMENTS

This work was supported in part by the NSFC under

Grants 62073215, 61873166, and 61673275.

REFERENCES

Adelson, E. H., Anderson, C. H., Bergen, J. R., Burt, P. J.,

and Ogden, J. M. (1984). Pyramid methods in image

processing. RCA engineer, 29(6):33–41.

Badrinarayanan, V., Kendall, A., and Cipolla, R. (2017).

Segnet: A deep convolutional encoder-decoder ar-

chitecture for image segmentation. IEEE transac-

tions on pattern analysis and machine intelligence,

39(12):2481–2495.

Burt, P. and Adelson, E. (1983). The laplacian pyramid as a

compact image code. IEEE Transactions on commu-

nications, 31(4):532–540.

Chen, L.-C., Papandreou, G., Kokkinos, I., Murphy, K., and

Yuille, A. L. (2017). Deeplab: Semantic image seg-

mentation with deep convolutional nets, atrous convo-

lution, and fully connected crfs. IEEE transactions on

pattern analysis and machine intelligence, 40(4):834–

848.

Cordts, M., Omran, M., Ramos, S., Rehfeld, T., Enzweiler,

M., Benenson, R., Franke, U., Roth, S., and Schiele,

B. (2016). The cityscapes dataset for semantic urban

scene understanding. In Proceedings of the IEEE con-

ference on computer vision and pattern recognition,

pages 3213–3223.

Ge, J., Luo, Y., and Tei, G. (2009). Real-time pedes-

trian detection and tracking at nighttime for driver-

assistance systems. IEEE Transactions on Intelligent

Transportation Systems, 10(2):p.283–298.

Ghiasi, G. and Fowlkes, C. C. (2016). Laplacian pyramid

reconstruction and reﬁnement for semantic segmenta-

tion. In European Conference on Computer Vision,

pages 519–534. Springer.

Huang, Z., Wang, X., Huang, L., Huang, C., Wei, Y., and

Liu, W. (2018). Ccnet: Criss-cross attention for se-

mantic segmentation.

Krizhevsky, A., Sutskever, I., and Hinton, G. E. (2012). Im-

agenet classiﬁcation with deep convolutional neural

networks. In Advances in neural information process-

ing systems, pages 1097–1105.

Lin, T. Y., Dollar, P., Girshick, R., He, K., Hariharan, B.,

and Belongie, S. (2017). Feature pyramid networks

for object detection. In 2017 IEEE Conference on

Computer Vision and Pattern Recognition (CVPR).

Long, J., Shelhamer, E., and Darrell, T. (2015). Fully con-

volutional networks for semantic segmentation. In

Proceedings of the IEEE conference on computer vi-

sion and pattern recognition, pages 3431–3440.

Mazzini, D. (2018). Guided upsampling network for

real-time semantic segmentation. arXiv preprint

arXiv:1807.07466.

Nekrasov, V., Shen, C., and Reid, I. (2018). Light-weight

reﬁnenet for real-time semantic segmentation. arXiv

preprint arXiv:1810.03272.

c, M. and Segvic, S. (2020). Efﬁcient semantic seg-

mentation with pyramidal fusion. Pattern Recogni-

tion, page 107611.

Sakaridis, C., Dai, D., and Van Gool, L. (2019). Guided cur-

riculum model adaptation and uncertainty-aware eval-

uation for semantic nighttime image segmentation.

Sun, L., Wang, K., Yang, K., and Xiang, K. (2019). See

clearer at night: Towards robust nighttime semantic

segmentation through day-night image conversion.

Wang, C. Research on Infrared Image Semantic Segmenta-

tion Technology Based on Deep Learning. PhD thesis,

University of Chinese Academy of Sciences (Shang-

hai Institute of Technical Physics, Chinese Academy

of Sciences).

Xu, F. and Fujimura, K. (2002). Pedestrian detection and

tracking with night vision. In Intelligent Vehicle Sym-

posium, 2002. IEEE.

Yu, C., Wang, J., Peng, C., Gao, C., Yu, G., and Sang,

N. (2018). Bisenet: Bilateral segmentation network

for real-time semantic segmentation. In Proceed-

ings of the European Conference on Computer Vision

(ECCV), pages 325–341.

Yu, F. and Koltun, V. (2015). Multi-scale context ag-

gregation by dilated convolutions. arXiv preprint

arXiv:1511.07122.

Zhao, H., Qi, X., Shen, X., Shi, J., and Jia, J. (2018).

Icnet for real-time semantic segmentation on high-

resolution images. In Proceedings of the European

Conference on Computer Vision (ECCV), pages 405–

420.

Zhao, H., Shi, J., Qi, X., Wang, X., and Jia, J. (2017).

Pyramid scene parsing network. In Proceedings of

the IEEE conference on computer vision and pattern

recognition, pages 2881–2890.

Zhiyi Liu, Shaoyuan Sun, Z. R. (2020). Infrared image se-

mantic segmentation of unmanned vehicles at night

based on improved deeplabv3+. Journal of Applied

Optics, 41(1).

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

328
