Few-shot Linguistic Grounding of Visual Attributes and Relations using

Gaussian Kernels

Daniel Koudouna and Kasim Terzi

School of Computer Science, University of St Andrews, U.K.

Keywords:

Few-shot Learning, Learning Models, Attribute Learning, Relation Learning, Scene Understanding.

Abstract:

Understanding complex visual scenes is one of fundamental problems in computer vision, but learning in this

domain is challenging due to the inherent richness of the visual world and the vast number of possible scene

conﬁgurations. Current state of the art approaches to scene understanding often employ deep networks which

require large and densely annotated datasets. This goes against the seemingly intuitive learning abilities of

humans and our ability to generalise from few examples to unseen situations. In this paper, we propose a

uniﬁed framework for learning visual representation of words denoting attributes such as “blue” and relations

such as “left of” based on Gaussian models operating in a simple, uniﬁed feature space. The strength of our

model is that it only requires a small number of weak annotations and is able to generalize easily to unseen

situations such as recognizing object relations in unusual conﬁgurations. We demonstrate the effectiveness of

our model on the predicate detection task. Our model is able to outperform the state of the art on this task in

both the normal and zero-shot scenarios, while training on a dataset an order of magnitude smaller.

1 INTRODUCTION

The task of scene understanding is typically under-

stood to involve reasoning beyond the level of objects,

and the ability to express complex attributes and re-

lations between objects. This paves the way for an

automatic, natural language description of a scene, or

answering questions about it. In a world where we

increasingly use language to communicate with arti-

ﬁcial agents (such as cars, assistive robots and smart

homes), it is essential for such agents to develop a rich

understanding of everyday visual scenes in order to

effectively communicate with users. Furthermore, it

is crucial that such agents can update their represen-

tations easily in order to adapt to changing circum-

stances and environments. For example, an assistive

robot helping a patient in their home is operating in an

environment where meaning of words such as “fast”

or “close to” can change over time, and will need to

adapt to such changes based on few examples.

The past decade has seen huge improvements

in terms of object detection performance, but the

wider task of scene understanding remains difﬁcult.

Datasets such as GQA (Hudson and Manning, 2019)

have attempted to further the ﬁeld of visual reason-

ing, but the need for meticulously annotated datasets

goes against the seemingly intuitive learning model

used by children when acquiring language, with their

ability to generalize learned concepts to unseen sit-

uations. Even with the emergence of large annotated

datasets, there still exists the problem of the vast num-

ber of possible conﬁgurations of objects, attributes

and relations in a natural scene. This leads to a com-

binatorial explosion for which it may be infeasible to

collect sufﬁcient examples for each sample. Novel al-

gorithms and models are needed that can generalize,

like humans do, from observed scenes to new unseen

conﬁgurations and recent work has been shifting back

to parsing language as a way to achieve this (Johnson

et al., 2017).

Many recent approaches do not attempt to ground

each word individually but focus on learning combi-

nations of words, typically formulated as a joint fea-

ture learning problem on triples of the type (subject-

object-predicate). This allows them to build on

powerful feature extraction abilities of modern deep

networks, but requires large annotated datasets and

makes it harder to transfer knowledge between predi-

cates (Peyre et al., 2017).

We propose a novel approach which parses state-

ments in a formal language and attempts to sequen-

tially ground each word separately onto a common

feature space. This formalism allows us to express

objects (such as “cat”), attributes (such as “red”) and

146

Koudouna, D. and Terzi

c, K.

Few-shot Linguistic Grounding of Visual Attributes and Relations using Gaussian Kernels.

DOI: 10.5220/0010261301460156

In Proceedings of the 16th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2021) - Volume 5: VISAPP, pages

146-156

ISBN: 978-989-758-488-6

 2021 by SCITEPRESS – Science and Technology Publications, Lda. All r ights reserved

Annotations Predictions

“blue” “red” “blue” “red”

Figure 1: High-level overview of the model. Representing each pixel in the region of interest of the image as a feature vector,

we estimate the probability distribution of the annotated attribute or relation in the embedding space . The model is then able

to predict the degree of each attribute at each pixel.

relations (such as “left of”) as functions operating on

the same feature space. Although our model is far

simpler than existing methods, we demonstrate that it

can learn attributes (such as “red”) and relations (such

as “above”) from a very small number of images and

that they can easily transfer to unseen examples (zero-

shot learning).

This paper presents the following contributions:

1. a process for mapping attributes and relations from

language onto functions in a single, simple and inter-

pretable feature space, using Gaussian models, 2. a

formalism based on lambda calculus which ties both

natural language descriptions into a series of such that

are executed sequentially on a scene, and 3. a self-

guided learning approach that can learn these map-

pings from very few examples.

We purposefully keep both image features and our

model very simple to show that the power of the sys-

tem does not come from deeply learned features or

complex mathematical models, but from the mod-

elling of each visual attribute and relation indepen-

dently, and from the integration with language which

allows for sequential parsing of the scene. Our feature

space and functions used to represent concepts can

both be extended in the future but we want to show

that even at its simplest, this new model can match

the state of the art on some speciﬁc tasks and thus

presents a promising research direction. We demon-

strate this on the predicate detection task on the VRD

dataset, where we outperform the state of the art while

using a vastly smaller number of training examples

than other models. In addition, we present some qual-

itative results on learning attributes from random im-

ages queried from a search engine.

2 RELATED WORK

The relation between metric spaces and learned fea-

tures has been explored in the context of metric

learning and applied to the detection of attributes

in the context of image classiﬁcation (Zhang et al.,

2019), object detection (Karlinsky et al., 2019; Sohn,

2016), and intra-class comparison (Kovashka et al.,

2015). Our approach to attribute and relation learning

is compatible with learned feature spaces but in this

paper we use a simple hand-crafted feature space to

demonstrate general applicability of our model.

Few-shot learning requires vision systems to

learn novel categories from a small number of ex-

amples, inspired by the learning capabilities that hu-

mans, especially children, exhibit in language learn-

ing (Carey and Bartlett, 1978; Xu and Tenenbaum,

2000). Few-shot learning has been successful in the

context of classiﬁcation, which focuses on models

trained on traditional dataset which can then learn

new classes from one or few examples (Chen et al.,

2019; He et al., 2019; Karlinsky et al., 2019; Zhang

et al., 2019). We show that our model can learn gener-

alizable attributes and relations with very few exam-

ples without requiring a pre-existing learned model,

which more closely resembles human learning.

Relation learning is the task of learning and de-

tecting the relation between two objects in an im-

age. Some traditional AI approaches combined hand-

modelled spatial relations with probabilistic scene

models (Neumann and Terzi

c, 2010; Kreutzmann

et al., 2009) or constraints (Hotz et al., 2007) but did

not learn relations from annotated examples. Many

recent approaches have used a combination of visual

and language models to jointly learn triples in the

Few-shot Linguistic Grounding of Visual Attributes and Relations using Gaussian Kernels

147

form (subject-object-predicate). However, due to the

number of possible object classes and relations, there

has been a recent focus on learning relations more in-

dependently of the participating objects, such as de-

tecting unusual or previously unseen relations (Peyre

et al., 2017; Peyre et al., 2019), by driving attention

to regions of an image (Krishna et al., 2018; Luo and

Shakhnarovich, 2017), or by the explicit modelling

of executing functions (Andreas et al., 2016; Johnson

et al., 2017). Our approach is aligned with this direc-

tion of research, but we show that many relations can

be successfully learnt using a simple language model

and without powerful deep networks.

Language grounding and top-down processing

in visual tasks are long-standing topics in cognitive

science. We adopt an approach similar to classical

models such as BISHOP (Gorniak and Roy, 2004),

where a formal grammar deﬁnes a series of functions

executed on the scene. Unlike BISHOP, our model is

able to adopt a growing lexicon of learned words rep-

resenting attributes and relations using a grammar, ex-

tending the idea of scene description using a series of

interpretable feature maps (Richter et al., 2014). This

is in contrast with many modern approaches, which

often rely on word vectors (Lu et al., 2016; Peyre

et al., 2019) or generic embedding spaces (Krishna

et al., 2018; Sur

ıs et al., 2019) to disambiguate lan-

guage in relationship detection. Our work follows the

recent interest in learning individual words or phrases

from visual stimulus (Bisk et al., 2020; Jin et al.,

2020). In addition, our model is able to learn in a con-

tinual manner, expanding its vocabulary as new words

are introduced in a series of scenes.

3 MODEL

Our model operates on a common feature space for

evaluating both attributes and relations. We deﬁne

,...D

as the dimensions of features extracted

from a scene. We represent each pixel in a h × w im-

age as a vector corresponding to its value in each fea-

ture dimension D

as p

p. We also deﬁne a ﬁeld F as a

h×w matrix which stores a scalar value for each pixel

in a scene. In our model, ﬁelds represent results of op-

erations, similar to retinotopic maps in neural models.

3.1 Language

We adopt a language model in which each word of

a sentence is mapped into a function which is ex-

ecuted on the feature space representing the image.

We model the sentences as expressions in ﬁrst order

logic. Objects in the scene are modelled as terms

in the logic. Object classes and attributes are mod-

elled as unary predicates, e.g Cat(x) indicates ob-

ject x is a cat. Combination of attributes is possi-

ble through conjunction of predicates. For example,

“there is a red cat” is parsed as

∃x Cat(x) ∧ Red(x) (1)

Relations in the scene are modelled in terms of

event semantics (Parsons, 1991). A relation is mod-

elled as an existence of an event e with a landmark lm

representing the object of the event, and a trajector tr

representing the subject. We denote the relation and

the landmark as a single predicate, e.g Left of(e, x)

indicates a relation “left of” with object x as the land-

mark. We denote the trajector of a relation as tr(e,y).

For example, “a dog left of a cat” is parsed as

∃e∃x∃y Left of(e,x) ∧ Cat(x)

∧tr(e,y) ∧ Dog(y)

(2)

First-order logic allows us to use conjunctions

(“and”) and disjunctions (“or”) to parse arbitrar-

ily complex sentences. This includes conjunc-

tion of attributes (“the dog is big and black”) and re-

lations (“the dog is next to the cat and the person”).

We omit the logical representations of these examples

for brevity.

We explicitly model response maps of particu-

lar queries as partial applications of expressions in

lambda calculus. Formally, existence of an object of a

particular class is represented by an object-class func-

tion O:

λ Q ∃z O(z) ∧ Q(z) (3)

In the case of a subject of a relation, we add the tr

predicate as explained above:

λ Q ∃z ∃e O(z) ∧tr(e,z) ∧ Q(z) (4)

This allows response maps for attributes and rela-

tions to be modelled as lambda expressions. An at-

tribute is represented by an attribute function A:

λ y A(y) (5)

and a relation by a relation function R:

λ x λ y ∃ e R(e,x) (6)

where x and y represent objects, and e represents a

particular event, which is used to group together the

landmark and the trajector of a particular relation.

Each word in the vocabulary of the model will

take the form of an expression in Equations 3, 4, 5

and 6. In this logic, we use terms to represent either

objects or events. Therefore, the model only requires

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

148

Figure 2: Example of evaluating relation queries on an image. Left: An image from the COCO dataset. Centre: Evaluating

“left of the cat” Right: Evaluating “left of the dog”. Response maps are overlaid with the original image for clarity.

deﬁnitions for all O, A and R predicates, which can

be supplied either a priori, or learned by the model.

For this paper, we consider O as supplied a priori, and

focus on the learning of attributes and relations.

3.2 Objects

We model a term o in ﬁrst-order logic by a point

in our feature space p

. Conceptually, an object o,

represented as a term in the logic, is obtained by

a ﬁeld in our model, where the response value for

each pixel p indicates the conﬁdence for the partic-

ipation of the pixel to the particular object. Common

representations for obtaining such ﬁelds are bound-

ing boxes and segmentation masks obtained from an

appropriate detector. This allows us to describe not

only object classes obtained from an object detector,

e.g “cat”, but arbitrarily complex noun phrases, i.e

“the red cat”, “the red cat under the clock”.

In order to tie the object representation to lan-

guage, we collapse an object to a single point p

, by

considering the object ﬁeld F

. For each feature di-

mension D

, the value of the object point is the mean

value of D

weighted by the object ﬁeld. This rep-

resents that object regions of lower conﬁdence should

not contribute to the value, and non-object regions (i.e

zero-valued pixels in F

) should not contribute at all.

This operation is equivalent to taking the matrix

inner product between F

and D

. Therefore, p

is a

vector containing the matrix inner product between F

and each feature dimension:

= (< F

>,< F

>,... < F

>) (7)

This product then represents the weighted mean

feature of the object – mean position, mean colour,

mean texture, etc. which form the basis for calculating

attributes and relations as described previously. Here

we note that this mean representation of an object is

not used to detect or classify objects, but to provide a

reference in our feature space to identify a particular

object in the scene. This reference is then used as

input to other functions operating on the space.

3.3 Attributes

An attribute is deﬁned by an attribute function A

which operates on a point in the feature space:

A : R

→ R , (8)

where n is the dimensionality of the feature space. As

shown in Equation 5, this conveniently allows eval-

uation of an attribute on a single object represented

by mean value p

. Note that we can also apply the

attribute function to the entire h × w image at once,

which will produce a ﬁeld F ∈ R

h×w

A : R

n×h×w

→ R

h×w

. (9)

Importantly, this means that evaluating an attribute on

an image produces a ﬁeld in the space. Figure 1 shows

application of different attributes on entire images.

This formalism leads to, a ﬂexible model which

allows for attributes originating either from external

knowledge, or from any employed learning technique.

We describe a simple learning model for attributes in

Section 4.3.

In addition, this formalism allows for two differ-

ent types of evaluation of an attribute; the application

of an attribute on an object p

, as above, and the par-

tial evaluation of the attribute, without a participating

object, on a particular scene. Extracting features from

an image maps each pixel to a feature vector p

p, which

allows the evaluation of an attribute function on an

image to create a response map, as shown in Figure 1.

The partial application of an attribute allows

for top-down processing of a scene, enabling the

model to drive its attention to a particular region

of an image (e.g. “dark” or “smooth” regions).

It also allows evaluating vague statements such as

“red left of green” without having to detect objects

and process them in turn, which is done in a bottom-

up manner. In these cases, we convert the ﬁeld repre-

sentation of the attributes (i.e “red”) into an object as

described in Section 3.2.

Finally, to determine whether a particular object

has attribute A, we use the decision function:

Few-shot Linguistic Grounding of Visual Attributes and Relations using Gaussian Kernels

149

t(p

;A) =



true, if A(p

) > T

false, otherwise.

(10)

where T is a variable detection threshold.

3.4 Relations

Following Equation 6, a relation naturally extends an

attribute by producing a ﬁeld given two points instead

of one. In order to describe relations, we augment the

feature space with respect to a ﬁxed point lm

lm repre-

senting the landmark of the relation. For each dimen-

sion D, we consider a additional dimensions. For this

paper, we use:

∆

(lm

lm; D) = D −lm

∆

(lm

lm; D) = (D −lm

)

(11)

Formally, for a additional dimensions for each di-

mension, a relation can be represented as:

R : R

a·n

× R

→ R (12)

A property shared with attributes is the ability to

partially apply relations. Provided two objects, the

relation function can provide a value representing the

intensity of the relation. With only a single object, the

relation can be applied to give a value for each pixel in

the scene, creating response maps such as in Figures 2

and 4.

This concept can be illustrated in Figure 2. If one

of the feature dimensions is the x coordinate of the

object represented by p

, then the two relative dimen-

sions in Eq.11 will be the horizontal offset of p

from

the landmark and the square of the horizontal offset,

respectively. The horizontal offset makes it trivial to

learn the relation “left-of” with respect to the dog

and the cat as landmarks. Adding the y coordinate

to the features would also add the corresponding ver-

tical offset and its square, allowing us to easily learn

“above”, “below”, as well as distance-based concepts

such as “near” or “far”.

3.5 Learning Approach

In this paper, we model each attribute and relation

function as a Gaussian distribution in a shared feature

space. This follows the idea of representing concepts

as convex regions in a conceptual space (G

ardenfors,

2000). We use this model instead of a deep network

to demonstrate that the power of our model lies in the

formalism used to sequentially parse the scene, and

not the complexity of the architecture. However, there

is nothing preventing the use of powerful learned fea-

tures in the future. We use a set of domains, each of

which containing a number of dimensions. The set of

domains used in this paper are as follows:

• the pixel colour in the CIELAB colour space,

• horizontal and vertical offset (in pixels) from im-

age centre,

• the magnitude and angle of optical ﬂow, and

• the responses of oriented Gabor ﬁlters covering a

range of sizes and orientations.

In addition, we use the difference and square differ-

ence from a particular landmark as augmented fea-

tures when considering relations, as described in Sec-

tion 3.4.

The features we use are well-established in the

ﬁeld of computer vision and all map reasonably well

to semantic concepts describing colours, spatial rela-

tions, motion, and texture. When operating on still

images, the dimensions of optical ﬂow are ﬁxed at

zero. Our learning approach described below will

learn to ignore dimensions that are not useful for rep-

resenting speciﬁc attributes and relations.

In all cases, we model both the word W and en-

vironment E as two multivariate normal distributions

over the feature space:

W ∼ N (µ

,Σ

)

E ∼ N (µ

,Σ

)

(13)

In this paper we assume independence of the features

in the space, meaning Σ is diagonal, but this is not

required by the model.

For a training example, we split the image into

two sets of points by considering the participating ob-

ject. For example, objects obtained by a set of pixels

B from a bounding box produce a ﬁeld using the func-

tion:

F(p; B) =



1, if p ∈ B

0, otherwise.

(14)

We assign the points of the object to W and the re-

mainder to E. The environment samples are taken

from any annotation that does not deﬁne the word and

allows us to learn without annotating negative exam-

ples.

We then construct a ﬁeld function F which accepts

a single point p

F(p

p;W, E) =

exp





∑

−µ

)





(15)

where D

represents the KL-divergence between

two normal distributions W

and E

representing the

distributions for feature dimension i as:

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

150

Feature Extraction

“the frisbee right of the dog”

Landmark localization

“the frisbee right of the dog”

Relation application

“the frisbee right of the dog”

Trajector localization

“ the frisbee right of the dog”

Figure 3: Example of the evaluation process for a single relation “”the frisbee right of the dog”. First, the model detects

the appropriate landmark “dog”, and generates the response map for the relation “right of” using the detected object as the

landmark. Finally, the model detects the trajector “frisbee” and calculates the mean value of the response map of the bounding

box.

Figure 4: Examples of attention maps from the VRD dataset. Left: “on the bus” . Right: “wears the pants”. The maps show

the partial application of the relation, i.e “on” to the landmark, i.e “the bus” on the left. Calculation of the relation uses the

mean response of the bounding box of the trajector, i.e “wheel”.

(P,Q) = log

+ (µ

− µ

)

2σ

−

(16)

and k normalizes the value in the range [0,1).

3.5.1 Learning Attributes

A training example for an attribute consists of a set

of points obtained either from a bounding box of an

object or a segmentation mask, and a label represent-

ing the name of the attribute. The model then updates

its knowledge base and calculates the new Gaussian

A for the attribute, as discussed in Section 3.3. The

process is shown in Algorithm 1. Line 1 extracts the

image features to assign a feature vector to each pixel

in the image, collectively deﬁned as P. Lines 2 and 3

split these vectors into the feature vectors of the ob-

ject and the environment respectively. Finally, lines 4

to 7 add the data to the model and retrain any words

with the updated data.

3.5.2 Learning Relations

For a relation, two sets of points are needed, for the

landmark and the trajector. The model then calculates

the augmented features relative to the landmark, as

discussed in Section 3.4, and updates its knowledge

base, as shown in Algorithm 2. In this case, the di-

Algorithm 1: Training an attribute.

Input: Labelled image I with object o

Input: Word w (attribute name)

1 P ← extract features(I)

2 P

← get object points(P, o)

3 P

← P − P

4 add samples(w, P

)

5 add environment samples(P

)

6 for w in lexicon do

7 recalculate distribution(w)

mensionality of the feature space used is a × n, where

a is the number of feature augmentations and n is

the size of the original feature space. As shown, this

method allows for the insertion of an arbitrary num-

bers of words in the lexicon, without affecting the

existing words. In addition, it allows attributes and

relations to be stored with different dimensionalities,

while being derived from the same base feature space.

4 EVALUATION

We evaluate our model on the predicate detection task

of the Visual Relationship Dataset (VRD) (Lu et al.,

2016). Contrary to most modern approaches which

Few-shot Linguistic Grounding of Visual Attributes and Relations using Gaussian Kernels

151

Algorithm 2: Training a relation.

Input: Labelled image I with landmark lm

and trajector tr

Input: Word w (relation name)

1 P ← extract features(I, lm)

// P contains augmented features

2 P

← get object points(P, tr)

3 P

← P − P

4 add samples(w, P

)

5 add environment samples(P

)

6 for w in lexicon do

7 recalculate distribution(w)

use the entire training set, we randomly select a num-

ber of examples for each predicate. We demonstrate

that our model can still outperform the state-of-the-

art in the predicate detection task. In addition, we are

able to also outperform in the zero-shot portion of the

test set, which means a relation was observed before,

but the subject-predicate-object triple it is being tested

on was not. We also show qualitative querying on the

COCO dataset to demonstrate the generalizability of

the model. Finally, we demonstrate learning of simple

attributes by querying images from a search engine.

4.1 Relationship Detection on VRD

The VRD predicate detection task tries to learn and

predict the predicate between two annotated objects in

a scene (represented by ground truth bounding boxes).

We focus on this task as our model is not tied to a par-

ticular object detection model, as explained in Sec-

tion 3.2. Most approaches use a train/test split of

4000/1000 images, which roughly translates to 30000

triples in the training set, and 7000 in the test set. We

compare our model to a number of methods: 1. LP

introduces the dataset, and uses a language module

utilizing word embeddings along with visual features.

LP-V is a diagnostic using only visual features (Lu

et al., 2016) 2. DR-Net utilizes spatial conﬁgurations,

as well as a probabilistic model for each triplet (Dai

et al., 2017) 3. LK uses external linguistic knowledge

to better predict probabilities of each predicate given

the subject and object (Yu et al., 2017). 4. SR fuses all

features and uses structural ranking loss (Liang et al.,

2017). 5. NL uses a bi-directional RNN and relative

spatial features of the subject-object pair to predict

predicates (Liao et al., 2019).

Following standard procedure for the predicate

detection task, we use the ground-truth bounding

boxes of the subject and object without the use of an

object detector.

Table 1 shows the results. We signiﬁcantly outper-

form traditional approaches using a training set an or-

0.7

0.8

0.9

Number of samples (n)

Recall@50

10 20 30 40

0.2

0.4

0.6

0.8

Recall@N

n = 5

n = 20

Figure 5: Left: Graph of increasing sample size n against

mean Recall@50 on the VRD test set, with error bars.

Right: Graph of the effect of increasing sample size n

against mean Recall@N, with error bars.

der of magnitude smaller (n = 8 examples for each re-

lation, with some relations having fewer annotated ex-

amples in the training set). In addition, we are able to

achieve state-of-the-art on the subset of unseen triples

in the VRD test set. This demonstrates that our model

generalizes well, since we learn on very few examples

yet achieve excellent results in the zero-shot subset.

Figure 5 shows the effect of increasing sample size

for each relation on the VRD test set. Notably, the

number of samples represents the maximum number,

as some relations have ≤ 20 training examples. As

expected, lower sample sizes show very high variance

due to the random nature of the selection, as well as

the fact that the model might not be able to learn some

relations from a single example, such as symmetric

relations. However, the variance is quickly reduced at

higher sample sizes. In addition, Recall@N is shown

for sample sizes n = 5 and n = 20. The model ex-

hibits much higher variance at a lower number of sam-

ples, with a signiﬁcant increase in performance as n

increases.

We attribute the success of the model to two fac-

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

152

Table 1: Results on predicate and relationship detection in the VRD (Lu et al., 2016). We compare our model with similar

results discussed in Section 4.1. Results are compared, where applicable, to the zero-shot learning scenario.

Predicate Detection

Comparison Entire set R@50 Zero-shot R@50 Training size

LP-V (Lu et al., 2016) 7.11 - 30000

LP (Lu et al., 2016) 47.87 8.45 30000

DR-Net (Dai et al., 2017) 80.87 - 30000

LK (Yu et al., 2017) 85.64 54.20 30000

SR (Liang et al., 2018) 86.01 60.90 30000

NL (Liao et al., 2019) 84.39 80.75 30000

Ours 93.67 89.55 560

tors. First, the model only considers objects as points

in the feature space, as described in Section 3.2, and

so is able to easily generalize spatial relations be-

tween triples, either seen or unseen. As described, we

use the feature vector of the object p

to effectively

translate the feature space. This allows us to easily

adapt to symmetric and anti-symmetric relations, as

we learn the average translation of the space by con-

sidering the objects in our knowledge base. This also

helps to explain why our model achieves a very high

recall at only a small number of examples, as shown

in 5.

Secondly, we are able to keep the predicates inde-

pendent of each other, since we learn a different dis-

tribution for each. This allows us to extend the model

to an arbitrary number of predicates without affecting

the performance of other predicates, which is particu-

larly helpful when considering learning with very few

examples.

4.2 Image Retrieval

In order to further demonstrate the generalizability

of our model, we use the COCO dataset to carry

out content-based image retrieval. We use the same

model trained on the VRD dataset as described in

Section 4.1. In addition, we use an off-the-shelf pre-

trained YOLO object detector (Redmon and Farhadi,

2018) to provide bounding boxes. We are able to

query the COCO dataset for images containing a par-

ticular relation, as shown in Figure 6. As shown, the

model then ranks images in the dataset according to

the conﬁdence in the existence of the relation. We

demonstrate the strength of the model to handle com-

plex language by combining two queries with “and”.

As discussed in Section 3.1, we use a simple gram-

mar to parse a sentence in natural language and con-

vert it into a series of operations on the feature space,

as shown in Figure 3.

4.3 Online Attribute Learning

In order to demonstrate the learning of attributes, we

use the Flickr API to obtain a small set of weakly-

annotated training images for a variety of attributes.

Some examples are shown in Figures 1 and 7. We

treat the centre of the image as an object possessing

the desired property, by treating the whole image as

an object o using a Gaussian centered on the image as

a response ﬁeld. This bypasses the need for an object

detector, and leverages the fact that, on average, an

attribute will be most represented in the centre of the

image.

Figure 8 shows the rate of convergence of our

model, by considering the shift in the centre of

the attribute distribution that each additional sample

causes. As expected, our model shows the high-

est change and variance at the ﬁrst additional sam-

ple, while converging at a very low sample number

(n > 10).

We also experimented with learning the same at-

tributes by scaling down original images before train-

ing. Figure 8 shows the average resolution of the

training data. We scale the input data by a factor

of 4 and 16. As shown, the model is able to con-

verge just as fast with orders of magnitude fewer data

points, suggesting that the model learns not from an

abundance of similar points, but by slowly differenti-

ating the features of the centre of the images possess-

ing the attribute, from the rest of the environment, as

discussed in Section 3.5.

Few-shot Linguistic Grounding of Visual Attributes and Relations using Gaussian Kernels

153

“dog near frisbee and near person”

“person right of cat and left of dog”

“person on bed and below clock”

Figure 6: Examples of content-based image retrieval on the COCO dataset. The model trained on VRD is presented a textual

query, and ranks the images in the dataset by the conﬁdence of the statement being true in the image. The top 5 results for

each query are shown, sorted by conﬁdence from left to right.

Figure 7: Examples of attention maps from the Flickr API.

Top: “purple” Bottom: “green”.

5 DISCUSSION

5.1 Learning approach Advantages

One of the main advantages of our model is its ﬂex-

ibility in the vocabulary employed. Since the model

does not have a ﬁxed lexicon, it can learn either from a

large annotated dataset or in an online manner. When-

ever it encounters a word with no model (i.e. no

Gaussian function to link it to the feature space), it

can look for annotated examples which include that

word. When using a dataset, unlike neural network

approaches, our model does not iterate over the data

in training epochs, but obtains new vocabulary or re-

ﬁnes its existing knowledge base by considering each

data point in the training set in sequence.

Another major beneﬁt of this approach is the lack

of explicit feature selection. Traditional neural net-

work models rely on back-propagation to emphasize

the importance of a particular feature. In contrast, our

model will naturally learn that only a few of the fea-

ture dimensions will be important for a particular at-

tribute (e.g colour for ’green’, but position for ’left’)

by considering the variance of the strength of the fea-

ture in the training data, as discussed in Section 3.5.

This property will exhibit a lower variance (i.e higher

concentration of data points) in the salient feature di-

mensions, and a higher variance in the non-salient

features, relative to the environment.

Our approach can also distinguish between sym-

metric and anti-symmetric relations. Most visual re-

lations between objects can be described as sym-

metric “A close to B” =⇒ “B close to A” or anti-

symmetric “A left of B” =⇒ ¬“B left of A”. For

example, the symmetric relation “close to” exhibits

a spread of values across the regular horizontal and

vertical dimensions, as objects may be close on both

sides, but a higher concentration of values in the re-

spective squared dimensions, since objects close to

each other are usually a ﬁxed distance apart.

5.2 Introspection and Meta-querying

Due to the statistical nature of our model, and the fact

that our feature dimensions are relatively simple, we

are able to answer questions about learned linguistic

terms. As mentioned in Section 3.3, we use the KL-

Divergence in order to select the features in our space

which exhibit the most information gain relative to

the environment. This, combined with the fact that

each predicate is learned independently, naturally al-

lows the model to describe which dimension is most

salient for each predicate, as shown in Figure 9. This

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

154

0 2 4

8 10 12 14

18 20

0.1

0.2

0.3

Sample number (#)

∆~µ

469 × 376

118 × 95

30 × 24

Figure 8: Graph of average deviation in the attribute distribution mean~µ against sample number for n = 5 attributes, for various

image resolutions. Attributes are learned as described in Section 4.3. The graph shows the convergence of the (averaged) mean

of the distributions as more data is added to the model’s knowledge base.

red is related to ’dim_2’ :

{’dim_1’: 0.117, ’dim_2’: 0.861,

’dim_3’: 0.378}

purple is related to ’dim_3’ :

{’dim_1’: 0.0679, ’dim_2’: 0.365,

’dim_3’: 0.534}

yellow is related to ’dim_3’ :

{’dim_1’: 0.335, ’dim_2’: 0.387,

’dim_3’: 1.008}

Figure 9: Example output from learned concepts from im-

ages queried from a search engine, discussed in Section 4.3.

Dimensions 1 to 3 represent the components of LAB space,

in order.

is particularly powerful when feature dimensions cor-

relate well with semantic concepts as they do in our

case: e.g. the L dimension of the CIELAB space cor-

responds to intensity/lightness. This allows the eval-

uation of simple queries related to learned attributes

such as ’what is dark?’ with generated answers such

as ’dark is related to lightness’. This can be evalu-

ated at any time, using the accumulated knowledge of

the model. This can either be a collection of images,

when applied to a general task such as a dataset, or

a changing environment over time, when applied to a

real-world scenario such as a surveillance camera.

6 CONCLUSION

We have presented a framework for grounding of at-

tributes and visual relations and a model built on this

framework. Our model allows the learning of at-

tributes and relations in the same way, using Gaussian

distributions in a feature space of common image fea-

tures. Importantly, we use a single model for learn-

ing both attributes and relations. The novelty of our

contribution does not come from the use of Gaussian

models, but from our approach to parsing queries and

sequentially processing the scene. We use the same

formalism for grounding objects, attributes, and rela-

tions, in contrast to most current work on relation and

attribute learning.

Our system outperforms the state-of-the-art on the

task of predicate detection on the VRD dataset, and

generalizes well in a zero-shot learning task. In ad-

dition, we show that our approach is able to learn

attributes in an online manner, by using images re-

trieved by a search engine. We feel that these are

promising early results for our formalism and plan to

explore deep learning of conceptual spaces to improve

performance in the future.

ACKNOWLEDGEMENTS

The Titan Xp GPU used for this research was donated

by the NVIDIA Corporation.

REFERENCES

Andreas, J., Rohrbach, M., Darrell, T., and Klein, D.

(2016). Learning to compose neural networks for

question answering. In NAACL HLT 2016, The 2016

Conference of the North American Chapter of the As-

sociation for Computational Linguistics: Human Lan-

guage Technologies, pages 1545–1554.

Bisk, Y., Holtzman, A., Thomason, J., Andreas, J., Ben-

gio, Y., Chai, J., Lapata, M., Lazaridou, A., May, J.,

Nisnevich, A., Pinto, N., and Turian, J. P. (2020). Ex-

perience grounds language. ArXiv, abs/2004.10151.

Carey, S. and Bartlett, E. (1978). Acquiring a single new

word.

Few-shot Linguistic Grounding of Visual Attributes and Relations using Gaussian Kernels

155

Chen, Z., Fu, Y., Zhang, Y., Jiang, Y., Xue, X., and Sigal,

L. (2019). Multi-level semantic feature augmentation

for one-shot learning. IEEE Transactions on Image

Processing, pages 1–1.

Dai, B., Zhang, Y., and Lin, D. (2017). Detecting visual

relationships with deep relational networks. In Pro-

ceedings of the IEEE Conference on Computer Vision

and Pattern Recognition (CVPR).

Gorniak, P. and Roy, D. (2004). Grounded semantic com-

position for visual scenes. The Journal of Artiﬁcial

Intelligence Research, 21:429–470.

ardenfors, P. (2000). Conceptual Spaces: The Geometry

of Thought. MIT Press, Cambridge, MA, USA.

He, X., Qiao, P., Dou, Y., and Niu, X. (2019). Spatial atten-

tion network for few-shot learning. In ICANN 2019:

Deep Learning, pages 567–578, Cham. Springer In-

ternational Publishing.

Hotz, L., Neumann, B., Terzi

c, K., and

Sochman, J.

(2007). Feedback between low-level and high-level

image processing. Technical Report Report FBI-HH-

B-278/07, University of Hamburg, Hamburg.

Hudson, D. A. and Manning, C. D. (2019). Gqa: A new

dataset for real-world visual reasoning and composi-

tional question answering. Conference on Computer

Vision and Pattern Recognition (CVPR).

Jin, X., Du, J., Sadhu, A., Nevatia, R., and Ren, X.

(2020). Visually grounded continual learning of com-

positional phrases.

Johnson, J., Hariharan, B., Van Der Maaten, L., Hoffman,

J., Fei-Fei, L., Zitnick, C. L., and Girshick, R. (2017).

Inferring and executing programs for visual reasoning.

In 2017 IEEE International Conference on Computer

Vision (ICCV), pages 3008–3017.

Karlinsky, L., Shtok, J., Harary, S., Schwartz, E., Aides, A.,

Feris, R., Giryes, R., and Bronstein, A. M. (2019).

Repmet: Representative-based metric learning for

classiﬁcation and few-shot object detection. In Pro-

ceedings of the IEEE/CVF Conference on Computer

Vision and Pattern Recognition (CVPR).

Kovashka, A., Parikh, D., and Grauman, K. (2015). Whit-

tlesearch: Interactive image search with relative at-

tribute feedback. In International Journal of Com-

puter Vision (IJCV).

Kreutzmann, A., Terzi

c, K., and Neumann, B. (2009).

Context-aware classiﬁcation for incremental scene in-

terpretation. In Workshop on Use of Context in Vision

Processing, Boston.

Krishna, R., Chami, I., Bernstein, M., and Fei-Fei, L.

(2018). Referring relationships. In IEEE Conference

on Computer Vision and Pattern Recognition.

Liang, K., Guo, Y., Chang, H., and Chen, X. (2018). Visual

relationship detection with deep structural ranking. In

AAAI.

Liang, X., Lee, L., and Xing, E. P. (2017). Deep variation-

structured reinforcement learning for visual relation-

ship and attribute detection. In CVPR, pages 4408–

4417.

Liao, W., Rosenhahn, B., Shuai, L., and Ying Yang, M.

(2019). Natural language guided visual relationship

detection. In Proceedings of the IEEE/CVF Con-

ference on Computer Vision and Pattern Recognition

(CVPR) Workshops.

Lu, C., Krishna, R., Bernstein, M., and Fei-Fei, L. (2016).

Visual relationship detection with language priors. In

ECCV.

Luo, R. and Shakhnarovich, G. (2017). Comprehension-

guided referring expressions. In Proceedings of the

IEEE Conference on Computer Vision and Pattern

Recognition (CVPR).

Neumann, B. and Terzi

c, K. (2010). Context-based proba-

bilistic scene interpretation. In Proc. Third IFIP Int.

Conf. on Artiﬁcial Intelligence in Theory and Prac-

tice, pages 155–164, Brisbane.

Parsons, T. (1991). Events in the Semantics of English.

Peyre, J., Laptev, I., Schmid, C., and Sivic, J. (2017).

Weakly-supervised learning of visual relations. In

ICCV.

Peyre, J., Laptev, I., Schmid, C., and Sivic, J. (2019). De-

tecting unseen visual relations using analogies. In The

IEEE International Conference on Computer Vision

(ICCV).

Redmon, J. and Farhadi, A. (2018). Yolov3: An incremental

improvement. arXiv.

Richter, M., Lins, J., Schneegans, S., and Sch

oner, G.

(2014). A neural dynamic architecture resolves

phrases about spatial relations in visual scenes. In

Artiﬁcial Neural Networks and Machine Learning –

ICANN 2014, pages 201–208.

Sohn, K. (2016). Improved deep metric learning with multi-

class n-pair loss objective. In NIPS.

Sur

ıs, D., Epstein, D., Ji, H., Chang, S.-F., and Vondrick, C.

(2019). Learning to learn words from visual scenes.

arXiv preprint arXiv:1911.11237.

Xu, F. and Tenenbaum, J. B. (2000). Word learning as

bayesian inference. In In Proceedings of the 22nd

Annual Conference of the Cognitive Science Society,

pages 517–522. Erlbaum.

Yu, R., Li, A., Morariu, V. I., and Davis, L. S. (2017). Vi-

sual relationship detection with internal and external

linguistic knowledge distillation. In 2017 IEEE In-

ternational Conference on Computer Vision (ICCV),

pages 1068–1076.

Zhang, J., Zhao, C., Ni, B., Xu, M., and Yang, X. (2019).

Variational few-shot learning. In The IEEE Interna-

tional Conference on Computer Vision (ICCV).

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

156
