CAR-DCGAN: A Deep Convolutional Generative Adversarial Network

for Compression Artifact Removal in Video Surveillance Systems

Miloud Aqqa and Shishir K. Shah

Quantitative Imaging Laboratory, Department of Computer Science, University of Houston, U.S.A.

Keywords:

Compression Artifacts, Video Quality Enhancement, Deep Learning, Visual Surveillance.

Abstract:

Video compression algorithms result in a degradation of frame quality due to their lossy approach to decrease

the required bandwidth, thereby reducing the quality of video available for automatic video analysis. These

artifacts may introduce undesired noise and complex structures, which remove textures and high-frequency

details in video frames. Moreover, they may lead to decreased performance of some core applications in video

surveillance systems such as object detectors. To remedy these quality distortions, it is required to restore high-

quality videos from their low-quality counterparts without any changes to the existing compression pipelines

through a complicated nonlinear 2D transformation. To this end, we devise a fully convolutional residual

network for compression artifact removal (CAR-DCGAN) optimized in a patch-based generative adversarial

approach (GAN). We show that our model is capable of restoring frames corrupted with complex and unknown

distortions with more realistic details than existing methods. Furthermore, we show that CAR-DCGAN can

be applied as a pre-processing step for the object detection task in video surveillance systems.

1 INTRODUCTION

In automated video surveillance systems, two key

aspects impact video analytics algorithms: the

compression parameters that facilitate the acquisition

of video stream and the network characteristics that

facilitate data transmission. In the current deploy-

ment of these systems, cameras are often backhauled

via wireless links, where signal jitter and packet loss

affect video quality. Oftentimes, these transmission

channels have limited bandwidth and are allowed a

certain quota per camera. Therefore, it is necessary

to use lossy compression algorithms to encode videos

before transmission to central storage and processing

sites in order to reduce as much as possible the re-

quired bandwidth and lower communication latency.

Unfortunately, whenever a lossy algorithm is used,

undesired complex distortions will manifest. These

distortions stemming from both spatial artifacts (i.e.,

blocking, blurring, color bleeding, and ringing) and

temporal artifacts (i.e., edge ﬂoating, texture ﬂoating,

and mosquito noise) remove textures and high-

frequency details in video frames, as shown in Figure

1. There are two drawbacks to these artifacts. First,

they make video frames appear unpleasant to the

human eye. Second, they adversely impact the perfor-

mance of various vision algorithms, such as ob-

ject detectors (Aqqa et al., 2019).

Typically, lossy compression algorithms come

with a factor to control the trade-off between the

video’s ﬁle size and quality. The larger this factor,

the stronger is the video degradation stemming from

these artifacts. However, opting for low compression

rates is not always a practical solution due to band-

width constraints in video surveillance systems. This

constraint is often guaranteed by strong compression.

Most surveillance cameras use the H.264/AVC

standard (Wiegand et al., 2003) for video compres-

sion, which is a lossy compression algorithm. H.264

exploits spatial redundancy within video frames and

temporal redundancy in videos to achieve appealing

compression ratios, making it the most widely ac-

cepted standard for video encoding. A video is a

sequence of frames; a frame is divided into blocks

of square sizes (16×16, 8×8 and 4×4). H.264 is

a block-based coder/decoder that applies a series of

mathematical functions to achieve compression and

decompression (Juurlink et al., 2012).

Compression artifact removal aims to recover

high-quality videos from their low-quality com-

pressed counterparts. In the past, it has been ad-

dressed mainly without learning the denoising func-

tion from a large dataset. These techniques range

Aqqa, M. and Shah, S.

CAR-DCGAN: A Deep Convolutional Generative Adversarial Network for Compression Artifact Removal in Video Surveillance Systems.

DOI: 10.5220/0010312304550464

In Proceedings of the 16th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2021) - Volume 4: VISAPP, pages

455-464

ISBN: 978-989-758-488-6

455

Figure 1: Examples of compression artifacts encountered in video surveillance systems. Top row: patches cropped from

original video frames. Bottom row: patches cropped from compressed video frames. Different types of artifacts can appear

in the same region. Best viewed in color on a computer screen.

from optimizing discrete cosine transform (DCT) co-

efﬁcients (Zhang et al., 2013) to adding additional

knowledge about images or patches based on adap-

tive distribution modeling (Liu et al., 2015). Follow-

ing the success of deep convolutional neural networks

(CNNs), few approaches have been proposed recently

to address the artifact removal problem (Aqqa and

Shah, 2020; Galteri et al., 2017; Svoboda et al., 2016;

Yu et al., 2015). These techniques leverage the repre-

sentational power of CNNs to accurately estimate the

image manifold by learning a function that performs

an image transformation from a compressed input im-

age to a restored output.

In this work, we address the problem of compres-

sion artifact removal in H.264/AVC encoded videos.

We propose a solution based on convolutional neural

networks trained on large sets of video frame patches

encoded at different bitrates, thus at different quali-

ties. In contrast to (Aqqa and Shah, 2020), our gener-

ator network is optimized in an adversarial framework

where there is no need to specify a loss function mod-

eling the quality of frame patches. We show that our

GAN can learn the conditional distribution of com-

pressed and uncompressed video frames at any com-

pression level, resulting in a better restoration. Fur-

thermore, our experiments show that it can be applied

as a reliable post-processing step for the object detec-

tion task in video surveillance systems.

In section 2, we review some of the related work.

In section 3, we detail the architecture of CAR-

DCGAN and the training approach. We describe in

section 4 the dataset, performance metrics, and im-

plementation details. Section 5 reports the results ob-

tained from our experiments. In section 6, we con-

clude our work.

2 RELATED WORK

In the past, compression artifact removal has been ad-

dressed mainly by designing hand-crafted ﬁlters re-

lying on information in the DCT domain. Recently,

few approaches have been proposed to learn the de-

noising function using deep convolutional neural net-

works (CNNs) following their success in other ma-

chine vision tasks. In the following, we will review

both kinds of methods.

Many software for handling images, videos, and

other multimedia ﬁles come with simple artifact re-

moval ﬁlters. For example, the FFmpeg framework

includes the simple post-processing (ssp) ﬁlter (Nos-

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

456

ratinia, 1999), which applies JPEG compression to

the shifted versions of the already-compressed im-

ages, and averages the results. Foi et al. proposed the

Pointwise Shape-Adaptive DCT (SA-DCT) method

(Foi et al., 2006), in which the thresholded transform

coefﬁcients are used to reconstruct a local estimate

of the image signal within the adaptive-shape sup-

port.Yang et al. have proposed to remove the arti-

facts introduced by quantization through a different

approach (Yang et al., 2000), which consists of apply-

ing DCT-based lapped transform on the signal already

in the DCT domain. The authors in (Li et al., 2014)

decompose images into texture and structure compo-

nents, then eliminate artifacts that are part of the tex-

ture component due to contrast enhancement. Chang

et al. (Chang et al., 2014) developed a method to re-

move blocking artifacts from JPEG compression im-

ages by ﬁnding a sparse representation over a learned

dictionary from a training set of images. While these

algorithms have shown promising results, they ex-

plicitly attempt to reverse the effect of DCT-domain

quantization optimally, and thus they are very speciﬁc

to the applied compressor. Furthermore, they tend

to overly smooth texture regions without reproducing

sharp edges and shapes of objects that machine vision

algorithms such as object detectors may be looking

for to classify an object.

A few recent approaches tackle the problem from

a different angle by learning the denoising function

using deep convolutional neural networks (DCNNs).

These methods learn a 2D transformation function

that can produce a restored version of the given de-

graded input image. Dong et al. (Dong et al., 2015)

have proposed artifact reduction CNN (AR-CNN),

which extends their super-resolution CNN (SRCNN)

architecture with feature enhancement layers follow-

ing sparse coding pipelines. They trained AR-CNN

in two stages - a shallow network is trained ﬁrst, then

it is used as an initialization for a ﬁnal 4 layer CNN

due to training difﬁculties encountered when training

the latter from scratch. Differently from AR-CNN,

Svoboda et al. (Svoboda et al., 2016) developed a

method with better results by training a feed-forward

CNN that combines residual learning and skip archi-

tecture to get a sharper reconstruction. The authors in

(Aqqa and Shah, 2020) have proposed a 34-layer fully

convolutional residual neural network (CAR-CNN) to

remove compression artifacts from H.264/AVC en-

coded videos. They trained their model by opti-

mizing a loss function that combines MSE loss and

SSIM based loss to capture both losses’ characteris-

tics, thus recovering high-frequency details without

over-smoothing the restored frame. These methods

have shown their ability to accurately estimate the im-

age manifold with more image details and semantics

thanks to not relying on local properties or DCT co-

efﬁcient statistics.

Convolutional neural networks have successfully

shown their ability in different image transformation

problems, such as image denoising (Zhang et al.,

2017), super-resolution (Kim et al., 2016; Dong et al.,

2014), and style-transfer (Gatys et al., 2016). Zhang

et al. (Zhang et al., 2017) have presented a denoising

convolutional neural network (DnCNN) to eliminate

Gaussian noise, showing that residual learning and

batch normalization are beneﬁcial for this task. Kim

et al. (Kim et al., 2016) addressed the problem of im-

age super-resolution using a deep architecture trained

on residual images. Ledig et al. (Ledig et al., 2017)

propose a deep residual convolutional network trained

in an adversarial fashion by optimizing a perceptual

loss that combines an adversarial loss and a content

loss. The authors state that their model can recover

photorealistic textures from heavily downsampled im-

ages. A style-transfer method of Gatys et al. (Gatys

et al., 2016) uses image representations from convo-

lutional neural network optimized for object recog-

nition while optimizing a loss that accounts for both

image content and style to keep the content of an ar-

bitrary photograph with the appearance of numerous

well-known artworks.

To the best of our knowledge, the only method

restoring compressed video frames is proposed by

Aqqa et al. (Aqqa and Shah, 2020). Differently from

their work, we propose an improved generator trained

in a generative adversarial setup. We refer to the pro-

posed method as CAR-DCGAN. We summarize our

contributions as follows:

1) We present a new attempt to address compres-

sion artifact removal in H.264/AVC encoded videos.

Unlike existing methods that directly optimize deep

CNNs using hand-crafted loss functions, we train our

generator in a generative adversarial setup using in-

put patches encoded at different compression levels.

Thus, learning a model that is quality-agnostic and

can handle videos encoded at different bitrates.

2) Motivated by the fact that H.264/AVC is a block-

based encoder, we propose a novel strategy to learn

both the generator and the discriminator over patches

of a single frame in a conditional setting to better es-

timate the frame manifold, leading to sharper recon-

struction and more realistic images.

3) We demonstrate that our conditional GAN can pro-

duce better quality than other deep learning-based

methods and can be used as a reliable pre-processing

step for object detectors in video surveillance sys-

tems.

CAR-DCGAN: A Deep Convolutional Generative Adversarial Network for Compression Artifact Removal in Video Surveillance Systems

457

3 CAR-DCGAN

In the H.264/AVC compression artifact removal task,

the aim is to restore a video frame F

from a com-

pressed frame F

distorted by a lossy compression

algorithm. In R

W ×H×L

, we deﬁne F

, F

, and F

real valued tensors with width W , height H and num-

ber of image channels C. During H.264/AVC video

encoding process, an uncompressed image F

is en-

coded by:

= E(F

, QP) (1)

using H.264 encoder E with some quantization pa-

rameter QP. We would like to learn an inverse func-

tion Φ ≈ E

−1

to remove compression artifacts intro-

duced by E, thus restoring F

from F

≈ F

= Φ(F

) (2)

To this end, we deﬁne Φ(.) as a fully convo-

lutional residual network Φ(F

;θ) with parameters

θ that are learned using a Generative Adversarial

Framework. We follow the assumption ”deeper is

better,” and we propose a 34-layer fully convolu-

tional residual neural network (FCN) and is, there-

fore, able to restore images of any resolution. Further-

more, FCN architectures are suitable for performing

local nonlinear image transformations, which allows

us to train the network over smaller frame patches.

Indeed, H.264/AVC encoder/decoder operates over

smaller blocks of square sizes (32×32, 16×16, 8×8

and 4×4); thus, the artifacts we are interested in re-

moving appear at scales close to the patch size.

The GAN framework establishes two distinct

players, a generator and a discriminator, and poses

the two in an adversarial game. The generator (G)

is fed some noisy input and tasked to create “fake”

images that lay on the manifold of the real data

with maximally confusing the discriminator; simul-

taneously, the discriminator (D) is tasked with dis-

tinguishing between samples from the generator and

samples from the training data. In this work, we are

not aiming to generate new unseen frames sampled

from a distribution, but our task regards the output of

an improved version of a degraded frame, thus learn-

ing a Φ(.) function able to process compressed frames

and remove artifacts. This task can be achieved with

GANs by conditioning the training. To condition

the generative network, we feed as positive samples

and as negative samples F

, where .|. indi-

cates channel-wise concatenation. Details of the pro-

posed networks are presented in the following.

3.1 Generative Network

Inspired by (Aqqa and Shah, 2020), our generator

(G) contains only blocks of convolutional layers and

LeakyReLU non-linearities. We use layers with 32

feature maps with a 3 × 3 support. All convolutional

layers are followed by a LeakyReLU activation with

a slope of 0.2 for negative inputs. After the ﬁrst two

convolutional layers, we apply a chain of 16 residual

blocks using a 1 pixel padding to keep the same frame

size across all convolution layers after every convolu-

tion. Finally, to generate the enhanced frame, we use

a single kernel convolutional layer with a tanh activa-

tion to keep the output values in the [−1, 1] range. An

overview of the network is depicted in Figure 2.

3.2 Discriminative Network

The architecture of the discriminator network D is

based mainly on a series of convolutional layers fol-

lowed by LeakyReLU activation. We double the num-

ber of feature maps every two layers except the last

one. The feature map’s size is decreased solely be-

cause of the effect of convolutions reaching the uni-

tary dimension in the last layer, in which we use a

sigmoid as the activation function. The discrimina-

tor is fed with frame patches rather than the whole

frame, as indicated in Figure 2, this is motivated by

the fact that the H.264/AVC encoder operates at the

block level, and those artifacts we aim to remove are

typically generated inside them. The weights ϕ of the

discriminator D are learned by minimizing:

= − log(D

)) − log(1 − D

)) (3)

where D(z) is taken from the sigmoid activation of

the discriminator network, with z indicating channel-

wise concatenation between the compressed input F

and the correspondent uncompressed version F

restored one F

3.3 Adversarial Training

Differently from CAR-CNN (Aqqa et al., 2019) that

is trained using a direct supervision approach, we

exploit to train our CAR-DCGAN in an adversarial

framework given the ability of GANs to model com-

plex multi-modal distributions, thus accurately esti-

mate the image manifold. We train conditional GANs

(Mirza and Osindero, 2014) to engage the generator

to better capture the image transformation task. The

training process for our model is as follows:

1. The generator processes the given degraded frame

patch and produces an enhanced version of it.

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

458

Conv 3x3 n32 s1

…

Residual Block

Conv 3x3 n32 s1

Conv 3x3 n3 s1

Tanh

Distorted Frame

Enhanced Frame

Generator

Discriminator

𝐶ℎ𝑎𝑛𝑛𝑒𝑙 − 𝑤𝑖𝑠𝑒

𝑐𝑜𝑛𝑐𝑎𝑡𝑒𝑛𝑎𝑡𝑖𝑜𝑛

Conv 3x3 n32

Conv 3x3 n64

Conv 3x3 n128

Conv 3x3 n256

Conv 3x3 n1

Sigmoid

𝑃(𝐼𝑛𝑝𝑢𝑡 ~ 𝑝

!"#"

)

Figure 2: An overview of the proposed method. Top: Architecture of the generative network. It contains 16 residual blocks,

and in each convolutional layer, we indicate by n the number of ﬁlters and s the stride. Bottom: Architecture of the discrim-

initive network. The input is created by performing the channel-wise concatenation between patches of the compressed frame

and the correspondent uncompressed version F

or restored one F

2. The discriminator learns basic convolutional ﬁl-

ters in order to distinguish between “real” frame

patches and “fake” ones.

3. The generator learns the correct bias and basic ﬁl-

ters to remove artifacts induced by the compres-

sion process, thus confusing the discriminator.

4. The discriminator becomes more accustomed to

“real” frame patches and is able to use signals in

the conditional data to look for particular triggers

in patches.

In the following, we describe the adversarial loss used

to train the generator network.

3.3.1 Pixel-wise MSE Loss

Mean Squared Error loss (MSE) is deﬁned as:

MSE

W H

∑

i=1

∑

j=1

i, j

− F

i, j

)

(4)

MSE

has shown improved performance in JPEG arti-

fact removal task (Svoboda et al., 2016). However,

it doesn’t recover most of the high-frequency details

from a distorted input.

3.3.2 Perceptual Loss

Perceptual loss has been employed successfully in

many image transformation tasks such as super-

resolution and image restoration (Dosovitskiy and

Brox, 2016; Gatys et al., 2016; Galteri et al., 2017).

The main idea is to optimize the network in a feature

space rather than the pixel space, encouraging uncom-

pressed video frames and restored ones to have simi-

lar feature representations. The distance between two

video frames is computed by projecting F

and F

a pre-trained network feature space, hence extracting

some meaningful latent representations. The percep-

tual loss is deﬁned as:

∑

i=1

∑

j=1

(φ

)

i, j

− φ

)

i, j

)

(5)

where H

and W

are the height and the width of the

feature maps respectively, and φ

(F) represents the

feature maps of some k-th layer of the pre-trained net-

work for an input video frame F. In this work, we use

the outputs of the pool4 layer of the VGG-19 model

(Simonyan and Zisserman, 2015) as the feature ex-

tractor.

CAR-DCGAN: A Deep Convolutional Generative Adversarial Network for Compression Artifact Removal in Video Surveillance Systems

459

!"#$%#&'()*+,-./01'(2 !"#$%#&'()*+,-./01'34 !"#$%#&'()*+,-./01'56

!"#$%#&'()*+,-./01'57

!"#$%#&'684)*+,-./01'(2 !"#$%#&'684)*+,-./01'34

!"#$%#&'684)*+,-./01'56

!"#$%#&'684)*+,-./01'57

!"#$%#&'6)*+,-./01'(2 !"#$%#&'6)*+,-./01'34 !"#$%#&'6)*+,-./01'56 !"#$%#&'6)*+,-./01'57

Uncompressed+frame

Uncompressed+patch

Figure 3: An uncompressed patch taken from a video frame and its 12 compressed versions. The compression artifacts can

be visually perceived as CRF value increases and bitrate decreases. The combination of CRF=29 and maximum bitrate of

2Mb/s results in the lowest compressed version, thus better image quality. The combination of CRF=47 and maximum bitrate

of 1Mb/s results in highest compressed version, thus worst image quality. Best viewed in color on a computer screen.

3.3.3 Adversarial Loss

We train the generator using a weighted combination

of the MSE loss, the perceptual loss and the standard

adversarial loss:

CAR

= l

MSE

+ αl

+ βl

adv

(6)

where l

adv

is deﬁned as:

adv

= − log(D

)) (7)

that rewards maximal confusion to the discriminator.

4 EXPERIMENTAL SETUP

4.1 Dataset

Previous work for JPEG compression artifact removal

were tested on BSDS500 (Martin et al., 2001) and

LIVE1 (Sheikh et al., 2014) datasets. These datasets

contain still images with distinctly different character-

istics compared to video frames encountered in video

surveillance systems. For this reason, Aqqa et al.

(Aqqa et al., 2019) have presented a new dataset of

uncompressed videos that represent common scenar-

ios where video surveillance cameras are deployed.

The videos are 5 minutes long movie clips and were

acquired using AXIS P3227-LVE network camera

and recorded in 1080p high deﬁnition (1920 × 1080)

at 30fps. To the best of our knowledge, it’s the only

dataset available with original uncompressed video

stream for video surveillance systems, and therefore,

we conduct experiments on this dataset.

H.264/AVC encoding uses Constant Rate Factor

(CRF) as the default quality (and rate control) setting.

CRF achieves constant quality by compressing dif-

ferent frames by different amounts, thus varying the

Quantization Parameter (QP) as necessary to main-

tain a certain level of perceived quality. It does this

by taking motion into account similar to the encoder

on a surveillance camera. CRF ranges between 0 and

51, where lower values would result in better quality

and higher values lead to more compression. To sim-

ulate the trade-off between quality and bitrate, CRF is

used in conjunction with Video Buffer Veriﬁer (VBV)

mode to ensure that the bitrate is constrained to a cer-

tain maximum as in real-world settings. An exhaus-

tive combination of CRF values (29, 35, 41, and 47)

and maximum bitrate values (2Mb/s, 1.5Mb/s, and

1Mb/s) are selected to create a total of 12 data variants

in this dataset. An uncompressed video frame and its

12 compressed versions available in this dataset are

shown in Figure 3.

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

460

Table 1: Restoration Quality Comparison. Results reported for average PSNR (dB).

Method

Bitrate = 2 Mb/s Bitrate = 1.5 Mb/s Bitrate = 1 Mb/s

CRF-29 CRF-35 CRF-41 CRF-47 CRF-29 CRF-35 CRF-41 CRF-47 CRF-29 CRF-35 CRF-41 CRF-47

H.264 29.65 28.09 25.93 24.53 29.25 28.07 25.90 24.53 28.58 27.70 25.85 24.53

CAR-CNN (MSE) 30.07 28.36 26.65 25.27 29.61 28.36 26.64 25.17 28.88 27.98 26.62 25.05

CAR-CNN (SSIM) 29.69 28.12 26.02 24.78 29.32 28.12 25.91 24.78 28.54 27.72 25.88 24.78

CAR-CNN (SSIM+MSE) 29.76 28.19 26.07 24.81 29.38 28.18 25.96 24.81 28.60 27.78 25.93 24.81

CAR-DCGAN 28.94 27.84 25.79 24.49 28.82 28.18 25.49 24.38 27.90 27.55 25.64 24.40

Table 2: Restoration Quality Comparison. Results reported for average SSIM.

Method

Bitrate = 2 Mb/s Bitrate = 1.5 Mb/s Bitrate = 1 Mb/s

CRF-29 CRF-35 CRF-41 CRF-47 CRF-29 CRF-35 CRF-41 CRF-47 CRF-29 CRF-35 CRF-41 CRF-47

H.264 0.817 0.789 0.725 0.604 0.807 0.788 0.723 0.604 0.787 0.774 0.720 0.604

CAR-CNN (MSE) 0.827 0.805 0.758 0.681 0.822 0.801 0.757 0.681 0.794 0.784 0.756 0.681

CAR-CNN (SSIM) 0.845 0.829 0.777 0.689 0.837 0.819 0.763 0.689 0.817 0.794 0.761 0.687

CAR-CNN (SSIM+MSE) 0.873 0.867 0.786 0.695 0.858 0.826 0.762 0.693 0.835 0.796 0.765 0.693

CAR-DCGAN 0.791 0.784 0.729 0.603 0.782 0.771 0.707 0.591 0.770 0.767 0.713 0.588

4.2 Similarity Measures

The most wide-spread evaluation metrics for qual-

ity assessment in compression artifact removal task

are MSE and the peak signal-to-noise ratio (PSNR),

which is the MSE normalized to the maximum pos-

sible signal values expressed in decibel (dB). An-

other alternative is to use the structure similarity in-

dex (SSIM) (Wang et al., 2004), which is the mean

of the product of three terms assessing similarity in

luminance, contrast and structure over multiple local-

ized windows. For a fair comparison with CAR-CNN

(Aqqa et al., 2019), we report evaluation of PSNR and

SSIM measures across all 12 data variants.

4.3 Implementation Details

For training our networks, we use 90k video frames as

the training set and 12k for the validation set. Testing

is performed on 17k video frames for each of the 12

data variants. We have used the PyTorch framework

(Paszke et al., 2017) for our evaluations. The training

process was distributed over two Nvidia Tesla v100

GPUs with a mini-batch of 64 video frames and have

been carried on for 360 epochs. For each image, we

ﬁrst rescale it to (910 × 512) and then we randomly

crop a 32 × 32 patch with horizontal ﬂipping. At the

training stage, we have optimized the networks pa-

rameters with Adam (Kingma and Ba, 2015) starting

with a learning rate of 10

−4

and momentum of 0.9.

5 RESULTS

The evaluation results of the mean PSNR and SSIM

across different data variants are shown in Table 1

and Table 2, respectively. The performance of our

generator CAR-DCGAN is compared with the stan-

dard H.264/AVC compression and CAR-CNN (Aqqa

and Shah, 2020), which was trained using three dif-

ferent loss functions: MSE loss, SSIM loss, and a

weighted combination of MSE and SSIM. As can be

seen in Table 1 and Table 2, the performance of our

generator is much lower than all the three variants of

CAR-CNN across all data variants from a quality in-

dex point of view. In fact, CAR-CNN was trained to

optimize MSE and SSIM hence achieving better re-

sults in PSNR and SSIM measures. Moreover, these

measures are known for better evaluating blurry re-

gions over more realistic ones, as reported in other

image transformation tasks such as super-resolution.

However, the restored video frames by our generator

are perceptually more realistic and have more ﬁner

consistent details, as shown in Figure 4. This can be

explained by the fact that the combination of adver-

sarial loss and perceptual loss tends to generate real-

istic textures rather than the smooth and poor detailed

patches of the MSE/SSIM based generators.

5.1 Object Detection

In video surveillance systems, we are more inter-

ested in understanding how video quality affects ma-

chine vision algorithms. During video compression,

quality distortions stemmed from spatial and tempo-

ral artifacts are introduced to the video frames lead-

ing to decreased performance of object detectors,

as shown in (Aqqa et al., 2019). This degradation

in performance can be explained because compres-

sion artifacts remove textures and details in these

video frames. These high-frequency features repre-

sent edges and shapes of objects that the detector may

CAR-DCGAN: A Deep Convolutional Generative Adversarial Network for Compression Artifact Removal in Video Surveillance Systems

461

CAR-CNN&(MSE) CAR-CNN&(SSIM)

CAR-CNN&(SSIM+MSE) Ground&TruthCAR-DCGAN

Compressed

Figure 4: Example of a video frame compressed at the highest compression rate (i.e., CRF=47 and Bitrate=1Mb/s) and

reconstruction results from different methods. Best viewed in color and zoomed in on a computer screen.

be looking for to classify an object.

In this experiment and for a fair comparison

with CAR-CNN, we use YOLO as the object de-

tector (Redmon et al., 2016). We adopt the same

evaluation procedure as in (Aqqa and Shah, 2020).

More speciﬁcally, the detections of YOLO on uncom-

pressed videos are considered ground-truth bound-

ing boxes and compared to its detections on recon-

structed versions of the 12 compressed variants. As

a lower bound, we also report performance on video

frames restored using H.264; results are reported in

Table 3. As we can expect, the more a video frame is

compressed by the H.264/AVC encoder, the highest

the drop in the performance of YOLO, especially at

higher CRFs, as shown in Figure 5. Even at moder-

ate compression levels (i.e., CRF=29), the detection

performance drops by at least 15.7% after restora-

tion. CAR-CNN generators are able to recover part

of the object characteristics, but the improvements

compared to the lower bound are not impressive, as

they gain around 0.08% (MSE-based), 1.7% (SSIM-

based), and 2.3% (SSIM+MSE) at the lowest com-

pression level (i.e., CRF=29 and Bitrate=2MB/s). In

fact, the over-smoothed and blurry patches recov-

ered by MSE/SSIM generators lack sharp textures

and high-frequency details that represent edges and

shapes of objects. Compared to CAR-CNN, our GAN

approach is able to restore the distorted frames in a

more effective manner yielding the best result, in-

creasing the performance by 7.7% in mAP from 0.766

to 0.843. At higher compression levels (i.e., CRF=41

and CRF=47), the variation in mAP across different

restoration methods is minimal as it becomes difﬁcult

to recover missing details due to heavy compression.

These results assess the beneﬁts of our patch-

based generative approach compared to traditional

methods for the H.264/AVC compression artifact re-

moval task. Although MSE/SSIM trained generators

yield better restoration performance from a quality in-

dex point of view, they are still simplistic and insuf-

ﬁcient to capture the complexity of the image man-

ifold. On the other hand, our adversarial approach

allows the generator to accurately estimate the im-

age manifold, thus better model the artifact removal

task. Moreover, our experiments show that machine

vision algorithms can suffer heavily from artifacts in-

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

462

Table 3: Detection performance of YOLO measured as mean average precision (mAP) at IoU=0.50 on the 12 data variants

for different reconstruction methods.

Method

Bitrate = 2 Mb/s Bitrate = 1.5 Mb/s Bitrate = 1 Mb/s

CRF-29 CRF-35 CRF-41 CRF-47 CRF-29 CRF-35 CRF-41 CRF-47 CRF-29 CRF-35 CRF-41 CRF-47

H.264 0.766 0.736 0.661 0.522 0.756 0.735 0.661 0.519 0.745 0.733 0.557 0.519

CAR-CNN (MSE) 0.774 0.759 0.698 0.577 0.768 0.761 0.697 0.577 0.758 0.753 0.669 0.577

CAR-CNN (SSIM) 0.783 0.772 0.703 0.587 0.779 0.773 0.706 0.587 0.764 0.759 0.675 0.587

CAR-CNN (SSIM+MSE) 0.789 0.781 0.723 0.589 0.783 0.776 0.727 0.589 0.769 0.763 0.676 0.588

CAR-DCGAN 0.843 0.831 0.743 0.597 0.838 0.815 0.738 0.594 0.811 0.804 0.680 0.589

Figure 5: Mean Average Precision (mAP) of different re-

construction methods in regards to different CRFs. CAN-

DCGAN outperforms other methods accross all CRFs. The

variation is minimal for CRFs higher than 41.

troduced during the compression process due to an

inability to generalize from their sharp training sets.

6 CONCLUSION

We have presented a fully convolutional residual neu-

ral network for the H.264/AVC compression arti-

fact removal task in video surveillance systems. We

trained our model in a patch-based generative ad-

versarial approach to accurately learn the conditional

distribution of compressed and uncompressed video

frames, leading to better restoration than MSE/SSIM

trained networks. Our experiments show that condi-

tional GANs produce higher video frames with ﬁner

and sharper details relevant to both human view-

ers and machine vision algorithms. Moreover, we

have shown that our approach can be used as a pre-

processing step for computer vision tasks such as ob-

ject detection in applications where quality distortions

may be present.

ACKNOWLEDGMENT

This work was performed in part through the ﬁnan-

cial assistance award, Multi-tiered Video Analytics

for Abnormality Detection and Alerting to Improve

Response Time for First Responder Communications

and Operations (Grant No. 60NANB17D178), from

U.S. Department of Commerce, National Institute of

Standards and Technology.

REFERENCES

Aqqa, M., Mantini, P., and Shah, S. K. (2019). Understand-

ing how video quality affects object detection algo-

rithms. In 14th International Conference on Computer

Vision Theory and Application.

Aqqa, M. and Shah, S. K. (2020). CAR-CNN: A deep resid-

ual convolutional neural network for compression ar-

tifact removal in video surveillance systems. In 15th

International Conference on Computer Vision Theory

and Application.

Chang, H., Ng, M. K., and Zeng, T. (2014). Reducing ar-

tifacts in jpeg decompression via a learned dictionary.

IEEE Transactions on Image Processing, 62:718–728.

Dong, C., Deng, Y., Loy, C. C., and Tang, X. (2015). Com-

pression artifacts reduction by a deep convolutional

network. In IEEE International Conference on Com-

puter Vision (ICCV).

Dong, C., Loy, C. C., He, K., and Tang, X. (2014). Learn-

ing a deep convolutional network for image super-

resolution. In European Conference on Computer Vi-

sion (ECCV).

Dosovitskiy, A. and Brox, T. (2016). Generating images

with perceptual similarity metrics based on deep net-

works. In International Conference on Neural Infor-

mation Processing Systems (NIPS).

Foi, A., Katkovnik, V., and Egiazarian, K. (2006). Point-

wise shape-adaptive dct for high-quality deblocking

of compressed color images. In 14th European Signal

Processing Conference.

Galteri, L., Seidenari, L., Bertini, M., and Bimbo, A. D.

(2017). Deep generative adversarial compression ar-

tifact removal. In IEEE International Conference on

Computer Vision (ICCV).

CAR-DCGAN: A Deep Convolutional Generative Adversarial Network for Compression Artifact Removal in Video Surveillance Systems

463

Gatys, L. A., Ecker, A. S., and Bethge, M. (2016). Im-

age style transfer using convolutional neural networks.

In IEEE Conference on Computer Vision and Pattern

Recognition (CVPR).

Juurlink, B., Alvarez-Mesa, M., Chi, C. C., Azevedo, A.,

Meenderinck, C., and Ramirez, A. (2012). Under-

standing the application: An overview of the h.264

standard. Scalable Parallel Programming Applied to

H.264/AVC Decoding, pages 5–15.

Kim, J., Lee, J. K., and Lee, K. M. (2016). Accurate image

super-resolution using very deep convolutional net-

works. In IEEE Conference on Computer Vision and

Pattern Recognition (CVPR).

Kingma, D. P. and Ba, J. (2015). Adam: A method for

stochastic optimization. In the 3rd International Con-

ference for Learning Representations.

Ledig, C., Theis, L., Husz

ar, F., Caballero, J., Cunning-

ham, A., Acosta, A., Aitken, A., Tejani, A., Totz, J.,

Wang, Z., and Shi, W. (2017). Photo-realistic single

image super-resolution using a generative adversarial

network. In IEEE Conference on Computer Vision and

Pattern Recognition (CVPR).

Li, Y., Guo, F., Tan, R. T., and Brown, M. S. (2014). A

contrast enhancement framework with jpeg artifacts

suppression. In European Conference on Computer

Vision (ECCV).

Liu, H., Xiong, R., Zhang, J., and Gao, W. (2015). Im-

age denoising via adaptive soft-thresholding based on

nonlocal samples. In IEEE Conference on Computer

Vision and Pattern Recognition (CVPR).

Martin, D. R., Fowlkes, C., Tal, D., and Malik, J. (2001). A

database of human segmented natural images and its

application to evaluating segmentation algorithms and

measuring ecological statistics. In IEEE International

Conference on Computer Vision (ICCV).

Mirza, M. and Osindero, S. (2014). Conditional generative

adversarial nets. In arXiv preprint arXiv:1411.1784.

Nosratinia, A. (1999). Embedded post-processing for en-

hancement of compressed images. In Proceedings

DCC’99 Data Compression Conference.

Paszke, A., Gross, S., Chintala, S., Chanan, G., Yang, E.,

DeVito, Z., Lin, Z., Desmaison, A., Antiga, L., and

Lerer, A. (2017). Automatic differentiation in Py-

Torch. In NeurIPS Autodiff Workshop.

Redmon, J., Divvala, S., Girshick, R., and Farhadi, A.

(2016). You only look once: Uniﬁed, real-time object

detection. In IEEE Conference on Computer Vision

and Pattern Recognition (CVPR).

Sheikh, H. R., Wang, Z., Cormack, L., , and Bovik, A. C.

(2014). Live image quality assessment database re-

lease 2.

Simonyan, K. and Zisserman, A. (2015). Very deep con-

volutional networks for large-scale image recognition.

In International Conference on Learning Representa-

tions (ICLR).

Svoboda, P., Hradis, M., Ba

rina, D., and Zemc

ık, P. (2016).

Compression artifacts removal using convolutional

neural networks. Journal of WSCG, 24:63–72.

Wang, Z., Bovik, A., Sheikh, H., and Simoncelli, E. (2004).

Image quality assessment: from error visibility to

structural similarity. IEEE Transactions on Image

Processing, 13:600–612.

Wiegand, T., Sullivan, G. J., Bjontegaard, G., and Luthra,

A. (2003). Overview of the h.264/avc video coding

standard. IEEE Transactions on Circuits and Systems

for Video Technology, 13:560–576.

Yang, S., Kittitornkun, S., Hu, Y.-H., Nguyen, T., and Tull,

D. (2000). Blocking artifact free inverse discrete co-

sine transform. In Proceedings 2000 International

Conference on Image Processing.

Yu, K., Dong, C., Deng, Y., Loy, C. C., and Tang, X. (2015).

Compression artifacts reduction by a deep convolu-

tional network. In IEEE International Conference on

Computer Vision (ICCV).

Zhang, K., Zuo, W., Chen, Y., Meng, D., and Zhang, L.

(2017). Beyond a gaussian denoiser: Residual learn-

ing of deep cnn for image denoising. IEEE Transac-

tions on Image Processing, 26:3142–3155.

Zhang, X., Xiong, R., Fan, X., and Gao, W. (2013).

Compression artifact reduction by overlapped-block

transform coefﬁcient estimation with block similarity.

IEEE Transactions on Image Processing, 22:4613–

4626.

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

464
