Contextualise, Attend, Modulate and Tell: Visual Storytelling

Zainy M. Malakan

1,2 a

, Nayyer Aafaq

1 b

, Ghulam Mubashar Hassan

1 c

and Ajmal Mian

1 d

Department of Computer Science and Software Engineering, The University of Western Australia, Australia

Department of Information Science, Faculty of Computer Science and Information System, Umm Al-Qura University,

Saudi Arabia

Keywords:

Storytelling, Image Captioning, Visual Description.

Abstract:

Automatic natural language description of visual content is an emerging and fast-growing topic that has at-

tracted extensive research attention recently. However, different from typical ‘image captioning’ or ‘video

captioning’, coherent story generation from a sequence of images is a relatively less studied problem. Story

generation poses the challenges of diverse language style, context modeling, coherence and latent concepts

that are not even visible in the visual content. Contemporary methods fall short of modeling the context and

visual variance, and generate stories devoid of language coherence among multiple sentences. To this end, we

propose a novel framework Contextualize, Attend, Modulate and Tell (CAMT) that models the temporal rela-

tionship among the image sequence in forward as well as backward direction. The contextual information and

the regional image features are then projected into a joint space and then subjected to an attention mechanism

that captures the spatio-temporal relationships among the images. Before feeding the attentive representations

of the input images into a language model, gated modulation between the attentive representation and the in-

put word embeddings is performed to capture the interaction between the inputs and their context. To the best

of our knowledge, this is the ﬁrst method that exploits such a modulation technique for story generation. We

evaluate our model on the Visual Storytelling Dataset (VIST) employing both automatic and human evaluation

measures and demonstrate that our CAMT model achieves better performance than existing baselines.

1 INTRODUCTION

Describing a story from a sequence of images, a.k.a.

visual storytelling (Huang et al., 2016), is a trivial

task for humans but a challenging one for machines

as it requires understanding of each image in isola-

tion as well as in the wider context of the image se-

quence. Furthermore, the story must be described

in a coherent and grammatically correct natural lan-

guage. Closely related research areas to visual story-

telling are image captioning (Pan et al., 2020; Feng

et al., 2019; Yang et al., 2019; Donahue et al., 2015)

and video captioning (Zhang and Peng, 2020; Aafaq

et al., 2019a; Yan et al., 2019; Liu et al., 2020; Yao

et al., 2015; Gan et al., 2017; Pan et al., 2017; Aafaq

et al., 2019b). Figure 1 demonstrates the difference

between descriptions of images in isolation and sto-

ries for images in a sequence. Similarly we compare

https://orcid.org/0000-0002-6980-0992

https://orcid.org/0000-0003-2763-2094

https://orcid.org/0000-0002-6636-8807

https://orcid.org/0000-0002-5206-3842

Figure 1: An example highlighting the differences between

image captioning and storytelling. First block (top) depicts

that each image is captioned with one sentence in isolation.

The second block (bottom) indicates the narrative descrip-

tion for the same images stream.

the example of two captions: “stand in front of a ﬂag”

and “time to honor the ﬂag”. The ﬁrst caption cap-

tures the image content which is literal and concrete.

196

Malakan, Z., Aafaq, N., Hassan, G. and Mian, A.

Contextualise, Attend, Modulate and Tell: Visual Storytelling.

DOI: 10.5220/0010314301960205

In Proceedings of the 16th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2021) - Volume 5: VISAPP, pages

196-205

ISBN: 978-989-758-488-6

However, the second caption requires further infer-

ence about what it means to honor a ﬂag.

In contrast to conventional image captioning

where a static input image is presented devoid of con-

text, visual storytelling is more challenging as it must

capture the contextual relationship among the events

as depicted by the sequence of images. Moreover,

in comparison to video captioning, visual storytelling

poses challenges due to large visual variation at the

input (Wang et al., 2018a). On the language side,

it requires narrative generation rather than literal de-

scription. To achieve the narrative, it requires to en-

hance long term image consistency among multiple

sentences. The task becomes even more challeng-

ing as some stories involve description of human sub-

cognitive concepts that do not appear in the visual

content.

To address the aforementioned challenges, we

propose a novel framework that starts by modeling the

visual variance as a temporal relationship among the

stream of images. We capture the temporal relation-

ship in two directions i.e, forward as well as backward

using Bi-LSTM. To maintain the image speciﬁc rele-

vance and context of images, we project the image

information and the context vectors from Bi-LSTM

into a joint latent space. The spatio-temporal atten-

tion mechanism learns to relate the corresponding

information by focusing on image features (spatial-

attention) and context vectors (temporal attention).

The attentive representation (i.e, encoder output) is

then modulated with the input word embeddings be-

fore it is fed into the language model. We used the

Mogriﬁer-LSTM (Melis et al., 2020) architecture to

achieve this task. During the gated modulation in the

ﬁrst layer, the ﬁrst gating step scales the input em-

bedding, depending on the actual context, resulting in

a contextualized representation of the input. In ad-

dition, the input token itself is a contextual represen-

tation in which it occurs. This results in the LSTM

input highly context dependent and enabling the lan-

guage model to generate more relevant and contex-

tual descriptions of the images. Furthermore, intra-

sentence coherence is improved by feeding the last

hidden state of the ﬁrst sentence generator to the next

sentence generator.

Our contributions are summarised as follows:

• We propose a novel framework Contextualise, At-

tend, Modulate and Tell (CAMT) to generate a

story from a sequence of input images. We ﬁrst

model the bidirectional context vectors capturing

the temporal relationship among the input images

from the same stream and then project the regional

image features and the contextual vectors to a

joint latent space and employ the spatio-temporal

attention.

• We perform gated modulation on attentive repre-

sentation and the input token before feeding it into

the language model i.e, LSTM to model the in-

teraction between the two inputs. The modulated

transition function results in a highly context-

dependent input to the LSTM.

• To demonstrate the effectiveness of proposed

technique for visual storytelling, we perform

experiments on the popular Visual Storytelling

Dataset (VIST) with both automatic and human

evaluation measures. The superior performance

of our model over the current state-of-the-art in

both automatic and human evaluations shows the

efﬁcacy of our technique.

2 RELATED WORK

Below we discuss the literature related to image cap-

tioning and video captioning which are closely asso-

ciated to visual storytelling, followed by literature re-

view of visual storytelling.

2.1 Image Captioning

Image captioning can be categorised as a single frame

(i.e, image) described by a single sentence. The meth-

ods can further be sub-categorised into rule based

methods (do Carmo Nogueira et al., 2020; Mo-

gadala et al., 2020) and deep learning based methods

(Phukan and Panda, 2020; Huang et al., 2019a). The

rule based methods employ the classical approach of

detecting pre-deﬁned and limited number of subjects,

actions and scenes in an image and describe them

in natural language using template based techniques.

Due to advancements in deep learning and introduc-

tion of larger datasets (Krizhevsky et al., 2012), most

recent methods normally rely on deep learning and

advanced techniques such as attention (Wang et al.,

2020), reinforcement learning (Shen et al., 2020), se-

mantic attributes integration (Li et al., 2019a) and,

subjects and objects modeling (Ding et al., 2019).

However, all these techniques do not perform well in

generating narrative for a sequence of images.

2.2 Video Captioning

Video captioning can be treated as multi-frame (i.e,

video) described by a single sentence. This in-

volves capturing the variable length sequence of video

frames and mapping them to variable length of words

in a sentence. Like image captioning, classical video

Contextualise, Attend, Modulate and Tell: Visual Storytelling

197

Figure 2: Our model is based on encoder-decoder architecture. The encoder part consists of pre-trained ResNet 152 to extract

the visual features from each image. The feature vectors are then fed to a bidirectional Long Short-term Memory (LSTM)

network sequentially, which allows the context of all images to be reﬂected in the entire story. The decoder is a Mogriﬁer

LSTM comprising ﬁve rounds which improve the generated story.

captioning methods (Kojima et al., 2002; Das et al.,

2013; Krishnamoorthy et al., 2013; Nayyer et al.,

2019) follow template based approaches. Most recent

methods rely on the neural networks based frame-

work with encoder-decoder architecture being most

widely employed. The encoder i.e, 2D/3D-CNN, ﬁrst

encodes the video frames and the decoder i.e, Recur-

rent Neural Network (RNN), decodes the visual infor-

mation into natural language sentences. More recent

video captioning methods employ e.g reinforcement

learning (Wang et al., 2018d), objects and actions

modeling (Pan et al., 2020; Zheng et al., 2020; Zhang

et al., 2020), Fourier transform (Aafaq et al., 2019a),

attention mechanism (Yan et al., 2019; Yao et al.,

2015), semantic attribute learning (Gan et al., 2017;

Pan et al., 2017), multimodal memory (Wang et al.,

2018b; Pei et al., 2019) and audio integration (Hao

et al., 2018; Xu et al., 2017) for improved perfor-

mance. Few video captioning methods attempt to de-

scribe the video frames into multiple sentences (Yu

et al., 2016; Xiong et al., 2018). However, describing

a short video by a single or rarely by multiple sen-

tences, the challenges of storytelling are multi-fold,

as discussed in Section 1. Hence, most of the afore-

mentioned video captioning techniques are ineffective

for the task of storytelling in their original form.

2.3 Visual Storytelling

Storytelling is one of the oldest activities of mankind

and has attracted extensive research recently due to

improvement in computation and machine learning.

Visual storytelling provides a strategy to understand

activities within stream of images and summarise

these images in one paragraph (Wiessner, 2014). It

started with ranking and retrieval approach which is

used to retrieve a paragraph rather than a sentence

from multiple images rather than one image (Kim

et al., 2015). Later, Coherent Recurrent Convolu-

tional Network (CRCN) was introduced which en-

hanced the smooth ﬂow of various sentences in a

photostream (Park et al., 2017). This deep learn-

ing network encompasses entity-based local coher-

ence model, bidirectional Long Short Term Mem-

ory (LSTM) networks, and convolutional neural net-

works. A multiple reward functions approach dur-

ing training is used to understand the essential re-

ward role from human demonstrations (Wang et al.,

2018c). LSTM based model and transformer-decoder

was introduced to improve coherence in stories (Hsu

et al., 2019). Encoder-decoder based deep learning

models are deployed to improve image features and

generating sequence of sentences (Al Nahian et al.,

2019; Huang et al., 2019b). Recurrent neural Net-

work (RNNs) are introduced to improve the modula-

tion which enhanced the relevance, coherence and ex-

pressiveness of the generated story (Hu et al., 2020).

Overall, the listed studies are mostly computationally

expensive due to their complexity level. In this pa-

per, our focus is to propose a computationally efﬁcient

method that can generate human-like story.

3 METHODOLOGY

Figure 2 shows the architecture of the proposed

model. It comprises of three modules: Bi-Encoder,

Attention and Decoder. Our Bi-Encoder module ﬁrst

encodes the image features and then it also encodes

the temporal context of the l images. The Attention

module captures the relationship at two levels: image

and image-sequence. Finally, the Decoder module

generates sequence of sentences by exploiting the mo-

griﬁer LSTM architecture. Details of the three mod-

ules are discussed below.

3.1 Bi-Encoder

Given a stream of l images i.e, I = (I

, I

, ..., I

), we

extract their high level feature vectors by employing a

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

198

pre-trained convolutional neural network ResNet152

(He et al., 2016). We denote the extracted features by

f = [ f

, f

, ..., f

]. To further capture the context in-

formation, we employ a sequence-encoder. A naive

method is to simply concatenate the image features

with the same sequence length, however, this loses

the temporal relationship amongst the images. Alter-

natively, a recurrent neural network can be employed

to capture the sequential information that aggregates

the temporal information over time. To capture this

relationship, we employ a Bi-LSTM, that summarises

the sequential information of l images in both direc-

tions i.e, forward as well as backward. At each time

step ‘t’, our sequence encoder takes an input of image

feature vector f

where i ∈ {1, 2, 3, 4, 5}. At last time

step i.e, t = 5, the sequence encoder has encoded the

whole stream of images and provides the contextual

information through the last hidden state denoted as

= [

−→

;

←−

3.2 Attention Module

The task of visual storytelling from a sequence of im-

ages involves describing the image(s) content in the

context of the other images. Here, the description of

images in isolation is undesired. To capture the image

features in the context of all the images, we incor-

porate an attention mechanism on image features and

the output of the sequence encoder that includes the

overall context of visual stream. Formally,

= W

·tanh(W

[ f

, h

] + b) (3.1)

where f

is the feature vector of i

image with hidden

state h

of sequence encoder after i

image has been

fed.

exp(ϕ

)

∑

k=1

exp(ϕ

)

(3.2)

where k is the length of the visual stream. Finally, the

attentive representation becomes;

∑

i=1

· [ f

, h

] (3.3)

The ﬁnal representations serve as the decoder inputs

which attends both image speciﬁc (low level) and

stream speciﬁc (high level) information.

3.3 Decoder

Recurrent networks, while successful, still lack in

generalisation while modeling the sequential inputs

especially for the problems where coherence and rel-

evance are vital. In visual storytelling, the problem

Figure 3: Illustrates how Mogriﬁer modulation is concate-

nating with LSTM unit. Before the input to LSTM, two

inputs x and h

modulate each other alternatively. Af-

ter ﬁve mutual gating rounds, the highest indexed updated x

and h

are then fed into normal LSTM unit.

depends on how model inputs interact with the con-

text in which they occur. To address these problems,

we exploit the modulating mechanism of the Mogri-

ﬁer LSTM (Melis et al., 2020) and employ as de-

coder in our framework. We ﬁrst describe how the

standard LSTM (Hochreiter and Schmidhuber, 1997)

generates the current hidden state i.e, h

hti

, given the

previous hidden state h

, and updates its memory

state c

hti

. For that matter, LSTM uses input gates Γ

forget gates Γ

, and output gates Γ

that are computed

as follows:

hti

= σ(W

, x

] + b

), (3.4)

hti

= σ(W

, x

] + b

), (3.5)

˜c

hti

= tanh(W

, x

] + b

), (3.6)

hti

= Γ

hti

 c

ht−1i

+ Γ

hti

 ˜c

hti

, (3.7)

hti

= σ(W

, x

] + b

), (3.8)

hti

= Γ

hti

tanh(c

hti

) (3.9)

where x is the input word embedding vector at time

step ‘t’ (we suppress t at all places for readability),

∗

represents the transformation matrix to be learned

in all cases, b

∗

represent the biases, σ is the logis-

tic sigmoid function, and  represent the hadamard

product of the vectors. In our decoder network, the

LSTM hidden state h is initialized by attentive vector

from the encoder output.

LSTM has proven to be a good solution for the

vanishing gradient problem. However, its input gate

also scales the rows of the weight matrices W

(ig-

nore the non-linearity in c). To this end, in the Mo-

griﬁer LSTM instead, the columns of all its weight

Contextualise, Attend, Modulate and Tell: Visual Storytelling

199

matrices W

∗

are scaled by gated modulation. Before

the input to the LSTM, two inputs x and h

mod-

ulate each other alternatively. Formally, x is gated

conditioned on the output of the previous step h

Likewise, the gated input is utilised in a similar fash-

ion to gate previous time step output. After a few

mutual gating rounds, the highest indexed updated

x and h

are then fed into LSTM as presented in

Figure 3. Thus, it can be expressed as: Mogrify

(x, c

, h

) = LSTM(x

↑

, c

, h

↑

) where x

↑

and

↑

are the modulated inputs being the highest in-

dexed x

and h

respectively. Formally,

= 2σ(W

i−1

)  x

i−2

, for odd i ∈ [1, 2, ..., r]

(3.10)

= 2σ(W

i−1

)  h

i−2

, for even i ∈ [1, 2, ..., r]

(3.11)

where  is the Hadamard product, x

−1

= x,

= h

= ζ

and r denotes the number of mod-

ulation rounds treated as a hyperparameter. Setting

r = 0 represents the standard LSTM without any gated

modulation at the input. Multiplication with a con-

stant 2 ensures that the matrices W

and W

result

in transformations close to identity.

3.4 Architecture Details

Our proposed architecture is based on deep learn-

ing model, which is combined in central two-parts,

as shown in Figure 2. The ﬁrst part is the encoder

which is utilized a pre-trained Resnet-152 (He et al.,

2016) as a CNN. The CNN is responsible for extract-

ing the image features and feed all extracted features

to bidirectional-LSTM. The bi-LSTM is utilized to

reﬂect all context of the streaming images as story-

like. Simultaneously, the bi-LSTM made up the vec-

tors which are fed directly through a fully connected

layer as word token into the decoder part. The de-

coder part is contained the Mogriﬁer LSTM with ﬁve

steps. Then all decoded vectors are fed to LSTM tok-

enizer to generate visual stories. In the <start> sign,

the tokenizer will start to receive the feature vectors

from Mogriﬁer, and it tokenizes the sentence word un-

til the LSTM meets the < end > which is a complete

sentence of the ﬁrst image and so on for the whole

story.

3.5 Model Training

All input images were resized to 256X256 pixels and

their intensities were normalized to [0,1]. All the im-

portant words from the VIST dataset were extracted

Figure 4: VIST dataset is composed of two types of image

sequences: Description In Isolation (DII), which is a collec-

tion of ﬁve images described in isolation, and Description

In Sequence (SIS), which is a collection of ﬁve images cap-

tioned in sequence (Huang et al., 2016).

and used as words embedded with a diminution of

256 vectors. For the encoder part, we used the param-

eters settings suggested by the GLACNet model (Kim

et al., 2018). The learning rate was set to 0.001 with

weight decay equals to 1e-5, and used the Adam op-

timizer. We applied teacher-forcing algorithm for our

LSTM training. To prevent overﬁtting and enhance

the performance of the training, we set the batch size

to 64.

4 EVALUATION

Below are the details about the dataset and metrics

which we used to evaluate our proposed model.

4.1 Visual Storytelling Dataset (VIST)

We evaluated our model on VIST dataset (Huang

et al., 2016). It was the ﬁrst dataset which was

created for the problem of visual storytelling. The

dataset contains 209,651 images creating 50,200 sto-

ries. There are two different types of sequence im-

ages: Description-in-Isolation (DII) and Story-in-

Sequence (SIS). Both these types consist of the same

photos, but the differences are in the description text.

In DII, all sequence images are described as an im-

age captioning, and they are not related to each other.

In SIS, the images are described as a narrative story-

like. Figure 4 demonstrate an example of DII and SIS

description.

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

200

Table 1: Comparison of the efﬁciency of our proposed model with variants of GLAC Net (Kim et al., 2018) in terms of

perplexity score, number of epochs and METEOR score. “-” means that the scores are not provided by the authors of the

respective method. Results inside brackets represent best scores.

Model Perplexity Score METEOR Number of

with Attention Validation Testing Score Epoch

LSTM Seq2Seq 21.89 % 22.18 % 0.2721 -

GLAC Net (-Cascading) 20.24 % 20.54 % 0.3063 -

GLAC Net (-Global) 18.32 % 18.47 % 0.2913 -

GLAC Net (-Local) 18.21 % 18.33 % 0.2996 -

GLAC Net (-Count) 18.13 % 18.28 % 0.2823 -

GLAC Net 18.13 % 18.28 % 0.3014 69

Ours (Encoder and Decoder Mogriﬁer) 17.11 % 16.77 % 0.3238 23

Ours - (Decoder Mogriﬁer only) (16.67 %) (15.89 %) (0.335) (22)

4.2 Evaluation Metrics

In the area of image description, researchers gener-

ally use several evaluation metrics to measure the

quality of their proposed techniques. The ﬁrst eval-

uation metric used in our study is Bilingual Evalua-

tion Understudy (BLEU) which compares set of ref-

erence texts with the generated-text using n-grams.

It is considered to be optimal for measuring the ef-

ﬁciency of techniques with short sentences and have

different versions. We selected BLEU-1, BLEU-

2, BLEU-3, and BLEU-4 in our study (Papineni

et al., 2002). The second evaluation metric used

is Recall-Oriented Understudy for Gisting Evaluation

(ROUGE) which is used to compare three different

types of text summaries such as n-grams, word se-

quences and word pairs. ROUGE has various sub-

types, such as ROUGE-1, ROUGE-2, ROUGE-W.

ROUGE-L and ROUGE-SU4, and we use ROUGE-

L as it is suitable for measuring efﬁciency for sin-

gle text document evaluation and short summaries

(Lin, 2004). The third evaluation metric used is Met-

ric for Evaluation of Translation with Explicit OR-

dering (METEOR) which considers the words’ syn-

onyms with its matching with the text reference. It is

optimal in measuring efﬁciency at the sentence level

(Banerjee and Lavie, 2005). The ﬁnal evaluation met-

ric used is Consensus-based Image Description Eval-

uation (CIDEr) which is designed for image caption-

ing evaluation. It compares generated-text with vari-

ous human captions (Vedantam et al., 2015). All of

these selected evaluation metrics thoroughly evaluate

our proposed methodology and help us to compare

with state-of-the-art techniques.

Table 2: Human evaluation survey results for 10 ground

truth stories and also 10 generated stories by our proposed

model.

Story Rank 1-5 (worst-best)

Type Relevance Coherence

Ground Truth 3.45 3.44

Proposed model (CAMT) (3.66) (3.65)

5 RESULTS AND DISCUSSION

In this section, we compare the results of our pro-

posed approach with state-of-the-art methods. We

also discuss the human evaluation of our technique

and performance of the model during training.

5.1 Quantitative Result

5.1.1 Perplexity Score Comparison

During training, we compare the proposed model’s

perplexity score with the model proposed by (Kim

et al., 2018) which has different variants. We used

two variants of our proposed model: using Mogri-

ﬁer LSTM in both encoder and decoder parts, and us-

ing Mogriﬁer LSTM in decoder part only. Table 1

shows the perplexity scores, METEOR scores and

number of epochs for all the selected models. Table 1

shows that using Mogriﬁer LSTM only in the decoder

part improves the perplexity score to 16.67 and 15.89

for validation and test data respectively in only 22

epochs which is the best among the compared mod-

els. Similarly, we also found that our proposed model

with Mogriﬁer LSTM in only the decoder part out-

performs other models by achieving best METEOR

score of 0.335. Therefore, we selected this variant of

our model for comparison with other state-of-the-art

techniques.

Contextualise, Attend, Modulate and Tell: Visual Storytelling

201

Table 3: Comparison of performance of our proposed model with state-of-the-art techniques using six automatic evaluation

metrics. “-” means that the scores are not provided by the authors of the respective method. Results enclosed in brackets

represent scores.

Models BLEU-1 BLEU-2 BLEU-3 BLEU-4 CIDEr ROUGE-L

Show, Reward and Tell(Wang et al., 2018a) 0.434 0.213 0.104 0.516 (0.113) -

AREL(baseline) (Wang et al., 2018c) 0.536 0.315 0.173 0.099 0.038 0.286

GLACNet(baseline) (Kim et al., 2018) 0.568 0.321 0.171 0.091 0.041 0.264

HCBNet (Al Nahian et al., 2019) 0.593 0.348 0.191 0.105 0.051 0.274

HCBNet(without prev. sent. attention) (Al Nahian et al., 2019) 0.598 0.338 0.180 0.097 0.057 0.271

HCBNet(without description attention) (Al Nahian et al., 2019) 0.584 0.345 0.194 0.108 0.043 0.271

HCBNet(VGG19) (Al Nahian et al., 2019) 0.591 0.34 0.186 0.104 0.051 0.269

VSCMR (Li et al., 2019b) 0.638 - - 0.143 0.090 0.302

MLE (Hu et al., 2020) - - - 0.143 0.072 0.300

BLEU-RL (Hu et al., 2020) - - - 0.144 0.067 0.301

ReCo-RL (Hu et al., 2020) - - - 0.124 0.086 0.299

Proposed model (CAMT) (0.641) (0.361) (0.2011) (0.1845) 0.042 (0.303)

Figure 5: Comparison of stories generated by our proposed model and GLAC Net model with ground truth for a sequence of

ﬁve images. The text in red represents repetition while text in blue represents relevance to the information in its subsequent

image.

5.1.2 Comparison with State-of-the-Art

Methods

We compare our proposed model with the follow-

ing state-of-the-art models: Show, Reward and Tell

method (Wang et al., 2018a); AREL

, a method for an

implicit reward with imitation learning (Wang et al.,

2018c); GLACNet

, an approach to learn attention

cascading network (Kim et al., 2018); HCBNet, an

approach of using image description as a hierarchy

https://github.com/eric-xw/AREL.git

https://github.com/tkim-snu/GLACNet

for the sequence of images (Al Nahian et al., 2019);

VSCMR, a method of cross-modal rule mining (Li

et al., 2019b); and ReCo-RL, an approach of de-

signing composite rewards (Hu et al., 2020). All

these methods achieve high scores on VIST visual

storytelling dataset. The performance of all models

are compared using the selected automatic evaluation

metrics which include BLEU-1, BLEU-2, BLEU-

3, BLEU-4, CIDEr, METEOR, and ROUGE-L. The

evaluation metric script was published by (Hu et al.,

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

202

2020)

. Table 3 presents the results for all the men-

tioned models, which clearly shows that our proposed

model outperform other models on all the selected

evaluation metrics except CIDEr score.

5.1.3 Human Evaluation

To evaluate the performance of our model in real

world scenarios, we conducted a survey where par-

ticipants were asked to rank the stories generated by

our model in terms of relevance and coherence. We

selected 10 stories generated by our model and 10

ground truth stories. All with their associated images

and asked the participants to rank them on a scale of

1 to 5 (worst to best) in terms of relevance and coher-

ence. Table 2 presents the results which shows that the

participants found the stories generated by our model

to be more coherent and relevant than the provided

ground truth with the dataset.

5.2 Qualitative Analysis

Due to the nature of the visual storytelling problem,

we thoroughly analysed the stories generated by our

model. We also compared our stories with ground

truth and stories generated by GLAC Net model (Kim

et al., 2018). Figure 5 presents two sets of ﬁve images

from VIST dataset along with the provided ground

truth stories followed by stories generated by GLAC

Net and our proposed model. The text in red mentions

the repetition of the story while the text in blue men-

tions the relevance of the story with the images. In

both stories generated by GLAC Net, we can observe

the repetition of the information and non-relevance to

the images while stories generated by our proposed

model were more coherent and relevant to the gener-

ated images. For instance, the last three sentences in

the story generated by GLAC Net for the lower set

of images are “We had a great time”, “It was a lot of

fun”, and “I can’t wait to go back”. All the three sen-

tences do not contribute in the story and repeating the

information. On the other hand, our proposed model

generated story which is more coherent and relevant

to the images.

5.3 Discussion

The main purpose of our study was to build a simple

and computationally efﬁcient model which can gen-

erate stories form images that are more relevant to the

images and coherent in structure. From the results,

it can be observed that our proposed model achieves

https://github.com/JunjieHu/ReCo-RL

both objectives in addition to achieving better per-

formance than the existing state-of-the-art techniques.

As mentioned in Table 1, our proposed model is time-

efﬁcient in training as it is trained over 22 epochs

only. In addition, our proposed model is much sim-

pler than existing models such as (Hu et al., 2020)

which uses more complex architectures involving two

RNNs. Whereas, our proposed model is designed on a

simple encoder-decoder methodology achieving com-

petitive results with state-of-art techniques.

6 CONCLUSION

In this paper, we introduced a novel encoder-decoder

technique for visual description as storytelling. Our

framework is straightforward and comprises a ResNet

152 and Bi-LSTM as an encoder, and Mogriﬁer

LSTM with ﬁve steps as a decoder. In between,

we utilize an attention mechanism which allows the

model to generate a novel sentence according to a spe-

ciﬁc image region while maintaining the overall story

context. Our proposed model outperforms state-of-

the-art methods on automatic evaluation metrics. In

future work, we aim to extend our model to gener-

ate different types of stories such as ﬁction. In addi-

tion, we aim to to extend our model to be able to track

objects that re-appear in subsequent images and in-

corporate their re-appearance and movement into the

story.

REFERENCES

Aafaq, N., Akhtar, N., Liu, W., Gilani, S. Z., and Mian, A.

(2019a). Spatio-temporal dynamics and semantic at-

tribute enriched visual encoding for video captioning.

In Proceedings of IEEE CVPR, pages 12487–12496.

Aafaq, N., Akhtar, N., Liu, W., and Mian, A. (2019b). Em-

pirical autopsy of deep video captioning frameworks.

preprint arXiv:1911.09345.

Al Nahian, M. S., Tasrin, T., Gandhi, S., Gaines, R., and

Harrison, B. (2019). A hierarchical approach for vi-

sual storytelling using image description. In Interna-

tional Conference on Interactive Digital Storytelling,

pages 304–317. Springer.

Banerjee, S. and Lavie, A. (2005). Meteor: An automatic

metric for mt evaluation with improved correlation

with human judgments. In Proceedings of the acl

workshop on intrinsic and extrinsic evaluation mea-

sures for machine translation and/or summarization,

pages 65–72.

Das, P., Xu, C., Doell, R. F., and Corso, J. J. (2013). A

thousand frames in just a few words: Lingual descrip-

tion of videos through latent topics and sparse object

Contextualise, Attend, Modulate and Tell: Visual Storytelling

203

stitching. In Proceedings of the IEEE CVPR, pages

2634–2641.

Ding, S., Qu, S., Xi, Y., Sangaiah, A. K., and Wan, S.

(2019). Image caption generation with high-level im-

age features. Pattern Recognition Letters, 123:89–95.

do Carmo Nogueira, T., Vinhal, C. D. N., da Cruz J

unior,

G., and Ullmann, M. R. D. (2020). Reference-based

model using multimodal gated recurrent units for im-

age captioning. Multimedia Tools and Applications,

pages 1–21.

Donahue, J., Anne Hendricks, L., Guadarrama, S.,

Rohrbach, M., Venugopalan, S., Saenko, K., and Dar-

rell, T. (2015). Long-term recurrent convolutional net-

works for visual recognition and description. In Pro-

ceedings of the IEEE CVPR, pages 2625–2634.

Feng, Y., Ma, L., Liu, W., and Luo, J. (2019). Unsupervised

image captioning. In Proceedings of the IEEE CVPR.

Gan, Z., Gan, C., He, X., Pu, Y., Tran, K., Gao, J., Carin,

L., and Deng, L. (2017). Semantic compositional net-

works for visual captioning. In Proceedings of the

IEEE CVPR, pages 5630–5639.

Hao, W., Zhang, Z., and Guan, H. (2018). Integrating both

visual and audio cues for enhanced video caption. In

Proceedings of the AAAI.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In Proceedings of

the IEEE conference on computer vision and pattern

recognition, pages 770–778.

Hochreiter, S. and Schmidhuber, J. (1997). Long short-term

memory. Neural computation, 9(8):1735–1780.

Hsu, C.-C., Chen, Y.-H., Chen, Z.-Y., Lin, H.-Y., Huang,

T.-H., and Ku, L.-W. (2019). Dixit: Interactive visual

storytelling via term manipulation. In The World Wide

Web Conference, pages 3531–3535.

Hu, J., Cheng, Y., Gan, Z., Liu, J., Gao, J., and Neubig, G.

(2020). What makes a good story? designing com-

posite rewards for visual storytelling. In AAAI, pages

7969–7976.

Huang, L., Wang, W., Chen, J., and Wei, X.-Y. (2019a). At-

tention on attention for image captioning. In Proceed-

ings of the IEEE International Conference on Com-

puter Vision, pages 4634–4643.

Huang, Q., Gan, Z., Celikyilmaz, A., Wu, D., Wang, J., and

He, X. (2019b). Hierarchically structured reinforce-

ment learning for topically coherent visual story gen-

eration. In Proceedings of the AAAI Conference on

Artiﬁcial Intelligence, volume 33, pages 8465–8472.

Huang, T.-H., Ferraro, F., Mostafazadeh, N., Misra, I.,

Agrawal, A., Devlin, J., Girshick, R., He, X., Kohli,

P., Batra, D., et al. (2016). Visual storytelling. In Pro-

ceedings of the 2016 Conference of the North Amer-

ican Chapter of the Association for Computational

Linguistics: Human Language Technologies, pages

1233–1239.

Kim, G., Moon, S., and Sigal, L. (2015). Ranking and re-

trieval of image sequences from multiple paragraph

queries. In Proceedings of the IEEE Conference

on Computer Vision and Pattern Recognition, pages

1993–2001.

Kim, T., Heo, M.-O., Son, S., Park, K.-W., and Zhang, B.-T.

(2018). Glac net: Glocal attention cascading networks

for multi-image cued story generation. arXiv preprint

arXiv:1805.10973.

Kojima, A., Tamura, T., and Fukunaga, K. (2002). Natural

language description of human activities from video

images based on concept hierarchy of actions. IJCV,

50(2):171–184.

Krishnamoorthy, N., Malkarnenkar, G., Mooney, R. J.,

Saenko, K., and Guadarrama, S. (2013). Generating

natural-language video descriptions using text-mined

knowledge. In Proceddings of the AAAI, volume 1,

page 2.

Krizhevsky, A., Sutskever, I., and Hinton, G. E. (2012). Im-

agenet classiﬁcation with deep convolutional neural

networks. In Advances in neural information process-

ing systems, pages 1097–1105.

Li, G., Zhu, L., Liu, P., and Yang, Y. (2019a). Entangled

transformer for image captioning. In Proceedings of

the IEEE International Conference on Computer Vi-

sion, pages 8928–8937.

Li, J., Shi, H., Tang, S., Wu, F., and Zhuang, Y. (2019b). In-

formative visual storytelling with cross-modal rules.

In Proceedings of the 27th ACM International Con-

ference on Multimedia, pages 2314–2322.

Lin, C.-Y. (2004). Rouge: A package for automatic evalu-

ation of summaries. In Text summarization branches

out, pages 74–81.

Liu, S., Ren, Z., and Yuan, J. (2020). Sibnet: Sibling con-

volutional encoder for video captioning. IEEE Trans.

on Pattern Analysis and Machine Intelligence, pages

1–1.

Melis, G., Ko

cisk

y, T., and Blunsom, P. (2020). Mogriﬁer

lstm. In Proceedings of the ICLR.

Mogadala, A., Shen, X., and Klakow, D. (2020). Integrat-

ing image captioning with rule-based entity masking.

arXiv preprint arXiv:2007.11690.

Nayyer, A., Mian, A., Liu, W., Gilani, S. Z., and Shah,

M. (2019). Video description: A survey of meth-

ods, datasets, and evaluation metrics. ACM Comput-

ing Surveys (CSUR), 52(6):1–37.

Pan, B., Cai, H., Huang, D.-A., Lee, K.-H., Gaidon, A.,

Adeli, E., and Niebles, J. C. (2020). Spatio-temporal

graph for video captioning with knowledge distilla-

tion. In IEEE CVPR.

Pan, Y., Yao, T., Li, H., and Mei, T. (2017). Video cap-

tioning with transferred semantic attributes. In IEEE

CVPR.

Papineni, K., Roukos, S., Ward, T., and Zhu, W.-J. (2002).

Bleu: a method for automatic evaluation of machine

translation. In Proceedings of the 40th annual meet-

ing of the Association for Computational Linguistics,

pages 311–318.

Park, C. C., Kim, Y., and Kim, G. (2017). Retrieval of sen-

tence sequences for an image stream via coherence re-

current convolutional networks. IEEE transactions on

pattern analysis and machine intelligence, 40(4):945–

957.

Pei, W., Zhang, J., Wang, X., Ke, L., Shen, X., and Tai, Y.-

W. (2019). Memory-attended recurrent network for

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

204

video captioning. In Proceedings of the IEEE CVPR,

pages 8347–8356.

Phukan, B. B. and Panda, A. R. (2020). An efﬁcient tech-

nique for image captioning using deep neural network.

arXiv preprint arXiv:2009.02565.

Shen, X., Liu, B., Zhou, Y., Zhao, J., and Liu, M. (2020).

Remote sensing image captioning via variational au-

toencoder and reinforcement learning. Knowledge-

Based Systems, page 105920.

Vedantam, R., Lawrence Zitnick, C., and Parikh, D. (2015).

Cider: Consensus-based image description evalua-

tion. In Proceedings of the IEEE conference on com-

puter vision and pattern recognition, pages 4566–

4575.

Wang, J., Fu, J., Tang, J., Li, Z., and Mei, T. (2018a).

Show, reward and tell: Automatic generation of narra-

tive paragraph from photo stream by adversarial train-

ing. In Thirty-Second AAAI Conference on Artiﬁcial

Intelligence.

Wang, J., Wang, W., Huang, Y., Wang, L., and Tan, T.

(2018b). M3: Multimodal memory modelling for

video captioning. In Proceedings of the IEEE CVPR,

pages 7512–7520.

Wang, J., Wang, W., Wang, L., Wang, Z., Feng, D. D.,

and Tan, T. (2020). Learning visual relationship and

context-aware attention for image captioning. Pattern

Recognition, 98:107075.

Wang, X., Chen, W., Wang, Y.-F., and Wang, W. Y.

(2018c). No metrics are perfect: Adversarial re-

ward learning for visual storytelling. arXiv preprint

arXiv:1804.09160.

Wang, X., Chen, W., Wu, J., Wang, Y.-F., and Yang Wang,

W. (2018d). Video captioning via hierarchical re-

inforcement learning. In Proceedings of the IEEE

CVPR, pages 4213–4222.

Wiessner, P. W. (2014). Embers of society: Firelight

talk among the ju/’hoansi bushmen. Proceedings of

the National Academy of Sciences, 111(39):14027–

14035.

Xiong, Y., Dai, B., and Lin, D. (2018). Move forward and

tell: A progressive generator of video descriptions. In

Proceedings of the ECCV, pages 468–483.

Xu, J., Yao, T., Zhang, Y., and Mei, T. (2017). Learning

multimodal attention lstm networks for video caption-

ing. In Proceedings of the 25th ACM international

conference on Multimedia, pages 537–545.

Yan, C., Tu, Y., Wang, X., Zhang, Y., Hao, X., Zhang, Y.,

and Dai, Q. (2019). Stat: spatial-temporal attention

mechanism for video captioning. IEEE Trans. on Mul-

timedia, 22:229–241.

Yang, X., Tang, K., Zhang, H., and Cai, J. (2019). Auto-

encoding scene graphs for image captioning. In Pro-

ceedings of IEEE CVPR.

Yao, L., Torabi, A., Cho, K., Ballas, N., Pal, C., Larochelle,

H., and Courville, A. (2015). Describing videos by

exploiting temporal structure. In Proceedings of the

IEEE ICCV, pages 4507–4515.

Yu, H., Wang, J., Huang, Z., Yang, Y., and Xu, W. (2016).

Video paragraph captioning using hierarchical recur-

rent neural networks. In Proceedings of the IEEE

CVPR, pages 4584–4593.

Zhang, J. and Peng, Y. (2020). Video captioning with

object-aware spatio-temporal correlation and aggre-

gation. IEEE Trans. on Image Processing, 29:6209–

6222.

Zhang, Z., Shi, Y., Yuan, C., Li, B., Wang, P., Hu, W.,

and Zha, Z.-J. (2020). Object relational graph with

teacher-recommended learning for video captioning.

In Proceedings of the IEEE/CVF CVPR.

Zheng, Q., Wang, C., and Tao, D. (2020). Syntax-aware

action targeting for video captioning. In Proceedings

of the IEEE/CVF CVPR.

Contextualise, Attend, Modulate and Tell: Visual Storytelling

205
