S*ReLU: Learning Piecewise Linear Activation Functions

via Particle Swarm Optimization

Mina Basirat

1 a

and Peter M. Roth

1,2 b

Institute of Computer Graphics and Vision, Graz University of Technology, Austria

Data Science in Earth Observation, Technical University of Munich, Germany

Keywords:

Visual Categorization, Activation Functions, Particle Swarm Optimization.

Abstract:

Recently, it was shown that using a properly parametrized Leaky ReLU (LReLU) as activation function yields

signiﬁcantly better results for a variety of image classiﬁcation tasks. However, such methods are not feasible

in practice. Either the only parameter (i.e., the slope of the negative part) needs to be set manually (L*ReLU),

or the approach is vulnerable due to the gradient-based optimization and, thus, highly dependent on a proper

initialization (PReLU). In this paper, we exploit the beneﬁts of piecewise linear functions, avoiding these

problems. To this end, we propose a fully automatic approach to estimate the slope parameter for LReLU from

the data. We realize this via Stochastic Optimization, namely Particle Swarm Optimization (PSO): S*ReLU. In

this way, we can show that, compared to widely-used activation functions (including PReLU), we can obtain

better results on seven different benchmark datasets, however, also drastically reducing the computational

effort.

1 INTRODUCTION

In the recent years, there has been a large scien-

tiﬁc interest in manually designing (Klambauer et al.,

2017; Clevert et al., 2016; Elfwing et al., 2018; Glo-

rot et al., 2011; Gulcehre et al., 2016)) and learn-

ing (Ramachandran et al., 2018; Basirat and Roth,

2019; Hayou et al., 2018; Li et al., 2018) new activa-

tion functions (AFs). Even though these works could

show that using more sophisticated non-linearities is

beneﬁcial in terms of convergency and training stabil-

ity, for many tasks—including image classiﬁcation—

those are not reﬂected by the ﬁnal performance. The

reported improvements, if any, are often only very

small. Thus, for many practical applications, ReLU is

still used as non-linearity. This, however, is only true

if the data is well separable. In contrast, if we have to

deal with hard-to-distinguish classes, and even subtle

differences are of relevance, using more sophisticated

activation functions gives signiﬁcantly better results

(Basirat and Roth, 2020). In particular, using a prop-

erly initialized Leaky ReLU (L*ReLU) enforces the

class separability and, ﬁnally, gives signiﬁcantly bet-

ter results.

https://orcid.org/0000-0001-5902-3045

https://orcid.org/0000-0001-9566-1298

(a) ReLU. (b) L*ReLU.

Figure 1: Nonlinear classiﬁcation problem solved using

different activation functions: (a) ReLU, (b) L*ReLU, (c)

PReLU, and (d) S*ReLU (proposed).

To illustrate this, in Fig. 1, we show the decision

boundaries for a simple nonlinear two-class classiﬁ-

cation problem, deﬁned as separating the red points

within a circle from the blue points outside the cir-

cle. Therefore, we apply a shallow fully connected

network with three layers (2,4,2), using different acti-

vation functions. From Fig. 1(a) we can see that using

ReLU even this simple problem cannot be solved. In

contrast, Fig. 1(b) shows that L*ReLU using a prop-

Basirat, M. and Roth, P.

S*ReLU: Learning Piecewise Linear Activation Functions via Particle Swarm Optimization.

DOI: 10.5220/0010338506450652

In Proceedings of the 16th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2021) - Volume 5: VISAPP, pages

645-652

ISBN: 978-989-758-488-6

645

erly set negative slope allows for perfectly separating

the two classes. However, in this case, the optimal

parameter needs to be searched by a time-consuming

grid-search, which is not feasible in practice.

To reduce the effort and the computational costs,

an automatic approach preserving the positive proper-

ties of linear piecewise activation functions would be

desirable. For instance, Parametric ReLU (PReLU)

(He et al., 2015) learns the slope parameter from the

training data. However, the approach is based on

gradient-based optimization. Thus, the optimization

likely gets stuck into a local optimum, and the suc-

cess of the approach strongly depends on the initial-

ization. This is illustrated in Fig. 1(c), showing that,

in the expected case, the classiﬁcation problem cannot

be solved properly.

To summarize, it is neither desirable to estimate

the necessary parameter manually (L*ReLU), nor to

rely on a gradient-based approach, which highly de-

pends on a proper initialization (PReLU). To avoid

both shortcomings, we propose to automatically learn

the slope parameter from the data, adopting ideas

from Stochastic Optimization (Spall, 2003). In con-

trast to gradient-based approaches, we avoid getting

stuck into local optima, and can ensure a globally op-

timal solution. Thus, as can be seen in Fig. 1(d), we

can estimate the decision boundary very well, even

though no prior knowledge was used. In favor of

other stochastic optimization methods, we ﬁnally se-

lected Particle Swarm Optimization (PSO) (Eberhart

and Kennedy, 1995) due to its simplicity and efﬁ-

ciency.

The experimental results on seven different

datasets show that, in this way, the optimal slope can

be estimated, even though no prior knowledge was

used, and that even the accuracy level of L*ReLU can

be matched. In addition, we compare our results with

those obtained by well-known and widely-used acti-

vation functions as well as to PReLU, which also es-

timates the slopes automatically from the data.

Thus, the main contributions of this paper can be

summarized as follows:

• We introduce a Particle Swarm Optimization

(PSO) based approach to automatically estimate

the optimal slope of the negative part of Leaky

ReLU (LReLU). Thus, also building on the ideas

of L*ReLU, we would like to refer to it as

S*ReLU.

• We demonstrate that our fully automatic approach

ﬁnally matches the accuracy level of L*ReLU,

which uses the manually-set optimal parameter

and, thus, yields the best possible solution (esti-

mated via a thorough parameter search).

2 RELATED WORK

In the following, we, ﬁrst, give a summary of ﬁxed

(Sec. 2.1) and learned (Sec. 2.2) activation functions.

Then, we revise Leaky ReLU in more detail (Sec. 2.3).

Finally, we give a short introduction to metaheuristic

stochastic optimization (Sec. 2.4).

2.1 Fixed Activation Functions

Inspired by simple thresholding functions, in the ﬁrst

place, squashing functions such as Sigmoid and Tanh

(Hornik, 1991) were of interest. In particular, as they

are continuous, bounded, and monotonically increas-

ing, they fulﬁll the required properties of the univer-

sal approximation theorem (Hornik, 1991), making

them a valid choice when learning continuous non-

linear functions. However, such functions often suf-

fer from the vanishing gradient problem (Hochreiter,

1998), which is, in particular, a problem when net-

works are getting deeper.

To overcome this problem, Rectiﬁed Linear Units

(ReLU) (Nair and Hinton, 2010) have been intro-

duced. As the derivative of any positive input is one,

the gradient cannot vanish, whereas all negative val-

ues are mapped to zero. On the one hand, this makes

ReLU easily and efﬁciently applicable; on the other

hand, we are facing two main problems: (a) There

is no information ﬂow for negative values, which is

known as dying ReLU. (b) The statistical mean of the

activation values is larger than zero, leading to a bias

shift in successive layers.

Both shortcomings can be alleviated by using Ex-

ponential Linear Unit (ELU) (Clevert et al., 2016).

By pushing the mean activation value towards zero,

ELU is more robust to noise and eliminates the bias

shift in the succeeding layers. This idea was later

extended by introducing a self-normalizing network:

Scaled Exponential Linear Unit (SELU) (Klambauer

et al., 2017). In this way, convergence towards a nor-

mal distribution with zero mean and unit variance can

be ensured.

2.2 Learned Activation Functions

More efﬁcient activation functions can be obtained by

learning the parameters from the data. In this way,

Parametric ELU (Trottier et al., 2017) overcomes the

vanishing gradient problem and allows for controlling

the bias shift. More complex functions (also non-

convex ones) can be learned using Multiple Paramet-

ric Exponential Linear Units (Li et al., 2018). In this

way, better convergence properties can be ensured, ﬁ-

nally, leading to a better classiﬁcation performance.

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

646

Similar results can also be achieved by adopting ideas

from reinforcement learning (Ramachandran et al.,

2018) and genetic programming (Basirat and Roth,

2019) by exploring complex search spaces, allow-

ing to construct new, more complex AFs. In this

way, Swish (Ramachandran et al., 2018), a combina-

tion of a squashing and a linear function, was found,

which has been demonstrated to work very well for

many problems. As an extension, Parametric Swish

(PSwish) additionally allows to train a scaling param-

eter. Similar functions, also yielding slightly better re-

sults in the same application domains, were found by

(Basirat and Roth, 2019). Recently, a theoretic jus-

tiﬁcation for these results has been given in (Hayou

et al., 2018), demonstrating that Swish-like functions

propagate information better than ReLU.

Even though competitive results have been shown

for many problems, the beneﬁcial theoretical proper-

ties did not allow to (signiﬁcantly) outperform neural

networks using ReLU. Thus, for most applications,

ReLU is used as nonlinearity, and other activation

functions are not considered at all.

2.3 Leaky ReLU

Nevertheless, it was shown that using Leaky ReLU

(LReLU) (Maas et al., 2013), just introducing a small

slope (α = 0.01) for the negative part of ReLU, gives

better results for many tasks. Even though we can

overcome the dying-ReLU-problem, we are still suf-

fering from the bias shift. In this way, Random-

ized Leaky Rectiﬁed Linear Unit (RReLU) (Xu et al.,

2015) sets the slope for the negative part randomly.

Recently, it has been shown that not only using a

non-zero negative part is essential, but that also the

slope of the negative part is of importance. In par-

ticular, the goal of L*ReLU (Basirat and Roth, 2020)

was to demonstrate two points: First, piecewise linear

activation functions can deal with more complex data

very well, i.e., if the data is not well separable. This

is, in particular, the case when classes are very simi-

lar and small subtle differences need to be modeled.

Therefore, also the absence of features needs to be

covered. To this end, an activation function needs to

be uniform-continuous and strictly increasing, which

can be ensured by a probably initialized LReLU. Sec-

ond, the optimal slope is highly data-dependent and

related to the Lipschitz constant (c.f., (Sokoli

c et al.,

2017; Anil et al., 2019; Tsuzuku et al., 2018)). Thus,

for different tasks also different parameters for the

negative slope are needed. Even though these are in-

teresting insights, the slope for L*ReLU needs to be

set manually, which is infeasible in practice.

Parametric ReLU (PReLU) (He et al., 2015) over-

comes this problem by learning the slopes for the neg-

ative part based on the training data. Moreover, there

are two main differences to L*ReLU: (a) a separate

activation function is learned for each layer, and (b)

the activation functions are not kept ﬁxed but are up-

dated during neural network training. Even though

this sounds reasonable, the main drawback of PReLU

is—building on a gradient-based optimization—that

the solver often gets stuck into a local optimum, mak-

ing the approach very sensitive to a proper initializa-

tion. To allow to generate complex functions, SReLU

(Jin et al., 2016) is deﬁned via three piecewise linear

functions ﬁnally forming a crude S shape.

Overall, neither manually setting the slope param-

eter nor a high sensitivity to the initialization are de-

sirable in practice. Thus, in the following, we intro-

duce an approach for learning piecewise linear func-

tions from the data, overcoming the problems dis-

cussed above by building on ideas from metaheuristic

stochastic optimization.

2.4 Metaheuristic Stochastic

Optimizations

During the last decades, various metaheuristic

stochastic optimization approaches (Osman and La-

porte, 1996) such as Evolutionary Algorithms (EA)

(e.g., (Koza et al., 1999; Schwefel, 1987; Goldberg,

1989; Holland, 1992)) or Particle Swarm Optimiza-

tion (PSO) (Eberhart and Kennedy, 1995) have been

introduced. The key idea of such approaches is that

a population of candidate solutions competes and/or

collaborates to ﬁnd the optimal solution through eval-

uating the ﬁtness of each candidate solution. Then,

each candidate solution is tweaked over several iter-

ations in the direction of the ﬁttest solution. Indeed,

Evolutionary Algorithms (EA), including Genetic Al-

gorithms (GA) (Goldberg, 1989; Holland, 1992), Ge-

netic Programming (GP) (Koza et al., 1999), and Evo-

lution Strategies (ES) (Schwefel, 1987), are inspired

from biology. In contrast, PSO is a swarm intelli-

gence algorithm inspired by the social behaviors of

a swarm. Therefore, candidate solutions are referred

to as a swarm of particles, not as a population of indi-

viduals. In contrast to EAs, PSO does not re-sample

particles to generate new ones. PSO has been widely

used for hyper-parameter tuning and designing the

topology of deep neural networks (Sinha et al., 2018;

Lorenzo et al., 2017; Wang et al., 2018). Due to its

simplicity and the ability also to deal with rather com-

plex problems, for our problem, we ﬁnally decided to

build on PSO in favor of other metaheuristic stochas-

tic optimization approaches.

S*ReLU: Learning Piecewise Linear Activation Functions via Particle Swarm Optimization

647

3 LEARNING PIECEWISE

LINEAR ACTIVATION

FUNCTIONS

In the following, in Sec. 3.1, we ﬁrst review the main

concepts and motivation of piecewise linear activa-

tion functions, in particular of Rectiﬁed Linear Unit

(ReLU) and Leaky Rectiﬁed Linear Unit (LReLU).

Then, in Sec. 3.2, we introduce our new, more robust

automatic approach to estimate the optimal slope for

the negative part of LReLU.

3.1 Piecewise Linear Activation

Functions

Piecewise functions, in general, are deﬁned via dif-

ferent functions for different parts of the domain. In

our case, we are interested in piecewise linear func-

tion f (x) deﬁned for the negative, f (x ≤ 0), and the

positive, f (x > 0), domain of R. The most promi-

nent function of this family is Rectiﬁed Linear Unit

(ReLU) deﬁned as

f (x) = max(x, 0). (1)

In practice, for most applications, including im-

age classiﬁcation, ReLU is used due to its simplicity

and efﬁciency. Moreover, for a wide range of appli-

cations, good results can be obtained. However, due

to the constantly zero negative part, we are suffering

from the dying ReLU problem and a bias shift in sub-

sequent layers. To this end, it has been shown that in-

troducing a small negative slope (i.e., α = 0.01) gives

better results for many applications:

f (x) = max(x, 0) + min(αx, 0), (2)

where α ≥ 0 deﬁnes the slope of the linear function

for the negative part. The function f (x) deﬁned in

Eq. (2) is referred to as Leaky ReLU (LReLU). As can

be seen from Fig. 2, the main difference compared

to ReLU is that not all negative values are mapped

to zero but are mapped using a linear function with a

small slope α.

−4 −2 2

−1

−4 −2 2

−1

(a) f (x) = ReLU. (b) f (x) = LReLU.

Figure 2: Piecewise linear functions: (a) ReLU and

(b) Leaky ReLU (LReLU), consisting of two linear parts:

f (x ≤ 0) and f (x > 0).

More recently, in (Basirat and Roth, 2020) it has

been demonstrated that not only using a non-zero neg-

ative part is of importance, but that also the selected

slope is of relevance. Moreover, it has been revealed

that the optimal slope is data-dependent. In other

words, for different tasks a different parametrization

is necessary. In general, as long as the data is well-

separable in the latent space, the choice of the activa-

tion function is not critical. This is also illustrated

in Table 3, where it can be seen that for different

choices of activation functions very similar results are

obtained for the CIFAR-datasets.

If this is not ensured, it has been shown (Basirat

and Roth, 2020; Clevert et al., 2016) that also

modeling the absence of features is of importance,

which can be achieved via using strictly monotoni-

cally increasing non-linear functions that are uniform-

continuous. In practice, this means that the negative

values should neither be mapped to zero nor satu-

rating, and that similar inputs should produce simi-

lar outputs. Both properties are fulﬁlled by LReLU,

where, additionally, also the desirable properties of

ReLU are inherited.

Even though this is an important and interesting

insight, it is not convenient to set the necessary pa-

rameter manually. To overcome this problem, PReLU

(He et al., 2015) can be used, which automatically

estimates the optimal slopes (i.e., separately for each

layer) from the data. However, as also can be seen

from Tables 3 and 4, the success of the approach is

highly dependent on an initialization close to the op-

timal solution. Building on a gradient-decent-based

optimization scheme, the approach gets often stuck

into a local minimum.

Since neither manually setting the parameter α nor

depending on a critical initialization are meaningful

for practical applications, in Sec. 3.2, we introduce an

automatic approach for optimally selecting the nega-

tive slope of LReLU not depending on a proper ini-

tialization, building on ideas of Particle Swarm Opti-

mization (Eberhart and Kennedy, 1995).

3.2 Learning Negative Slopes via

Particle Swarm Optimization

To overcome the problems of gradient-based optimiz-

ers, we propose to build on ideas from metaheuristic

stochastic algorithms. In particular, we apply Particle

Swarm Optimization (PSO) (Eberhart and Kennedy,

1995) to compute the optimal negative slope for

LReLU.

Given a swarm S = {x

, . . . ,x

}, n ≥ 1, of can-

didate solutions x

, the key idea of PSO is to move

the individual candidate solutions in the search space

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

648

towards an optimal solution, while sharing their ex-

periences. In general, a candidate solution x

, · · · , x

i, also referred to as “particle”, is a d-tuple,

representing a location in a d-dimensional search

space. Being interested in computing the slope of the

negative part of a piecewise linear function, we set

d = 1, i.e., a particle

is a scalar value x ∈ R

In this way, also each particle x is assigned a ve-

locity v(x), steering the current update:

x ← x + εv(x), (3)

where ε deﬁnes the jump size of the particles. To com-

pute the current estimate of v(x), we need to deﬁne

three optimal values, estimated via a so-called ﬁtness

function, for each particle x: (a) x

∗

, the best solution

for particle x (personal best), (b) x

, the best solution

among all neighbors of x (local best), and (c) x

, the

best solution of all particles x ∈ S (global best).

Given the current location of particle x, the update

for v(x) is computed by

v(x) ← wv(x)+a(x

∗

−x)+b(x

−x)+c(x

−x), (4)

where w ∈ [0, 1] is called inertia weight and controls

to which extend a particle’s velocity is steered by its

history of locations; a ∈ [0, β] is called the cogni-

tive parameter and controls exploitation; b ∈ [0, γ] and

c ∈ [0, δ] are called the social parameters and control

the local and the global exploration of the feasible

search space, respectively. Please note, the parame-

ters a, b, and c are randomly chosen from their respec-

tive ranges in each iteration. Starting from a random

initialization for x and v(x), in each iteration x and

v(x) are updated according to Eqs. (3) and (4) until a

predetermined stopping criterion is met. Even though

starting from a random initialization, ﬁnally, the opti-

mal slope for the negative part of the piecewise linear

activation function can be estimated.

Algorithm 1 summarizes the overall procedure.

Starting from a swarm of random particles x assigned

a random velocity v(x) (lines 2–6), we randomly tag

a particle x

∈ S as the ideal solution φ (line 7). Then,

the following steps are iterated until the optimal solu-

tion is obtained or a stopping criterion is met (lines 8–

15): (a) evaluate the ﬁtness of all particles x and up-

date the optimal values; (b) update the velocity v(x)

based on the own experience (personal best), the ex-

perience discovered from its neighbors (local best),

and the best experience of all particles in the swarm

(global best); (c) update particle x.

In general, there are two main PSO strategies,

namely Global PSO (GPSO) and Local PSO (LPSO).

The difference between them lies in the neighborhood

For sake of readability, in the following discussion, we

also leave out the index i.

Algorithm 1: Particle Swarm Optimization.

Require:

n ← desired swarm size

w ← proportion of velocity to be retained

β ← proportion of personal best to be retained

γ ← proportion of the neighbors’ best to be retained

δ ← proportion of global best to be retained

ε ← jump size of a particle

Ensure:

φ ← the ﬁttest particle so far

1: procedure PARTICLESWARMOPTIMIZATION

2: S ←

3: for n times do

4: x ← RANDOM-PARTICLE(d)

5: v(x) ← RANDOM-VELOCITY(d)

6: S ← S ∪ {x}

7: φ ← x

8: repeat

9: for x ∈ S do

10: if FITNESS(x) < FITNESS(φ) then

11: φ ← x

12: UPDATE v(x): Eq. (4)

13: UPDATE x: Eq. (3)

14: until φ is optimal solution or stopping criterion is met

15: return φ

structure of the particles. In GPSO, the neighborhood

of a particle, for which information is shared, is de-

ﬁned by all particles in the entire swarm. On the con-

trary, in LPSO, the neighborhood of a particle is de-

ﬁned by a ﬁxed number of particles.

In this way, for GPSO, the parameter γ is set to 0,

enforcing b = 0; thus the term (x

− x

) is omitted.

More speciﬁcally, given the location of particle x, the

update of v(x

) is reduced to

v(x

) ← wv(x

) + a(x

∗

− x

) + c(x

− x

). (5)

In contrast, for LPSO, the parameter δ is set to 0,

enforcing c = 0; thus the term (x

∗

− x

) is omitted.

More speciﬁcally, given the location of particle x, the

update of v(x

) is reduced to

v(x

) ← wv(x

) + a(x

∗

− x

) + b(x

− x

). (6)

4 EXPERIMENTAL RESULTS

To demonstrate our approach, we run it for seven dif-

ferent image classiﬁcation benchmarks, two coarse-

grained visual categorization (CGVC) and ﬁve ﬁne-

grained visual categorization (FGVC) problems. To

this end, in the ﬁrst step, we run Local and Global

PSO to estimate the optimal slopes for LReLU for

each dataset, which are then used to train a neural net-

work in the second step. The benchmarks and details

about the experimental setups are given in Sec. 4.1

and Sec. 4.2, respectively.

S*ReLU: Learning Piecewise Linear Activation Functions via Particle Swarm Optimization

649

We split our evaluations into two different exper-

iments. First, in Sec. 4.3, we compare the slopes es-

timated via our PSO-approach to the optimal slopes

estimated for L*ReLU (Basirat and Roth, 2020). Sec-

ond, in Sec. 4.4, we compare the ﬁnally obtained

classiﬁcation results to L*ReLU, deﬁning the ”upper

bound”, to well-known and widely used activation

functions, and to PReLU (He et al., 2015). Finally,

in Sec. 4.5, we discuss the computational effort of

S*ReLU compared to L*ReLU.

4.1 Benchmark Datasets

To demonstrate the generality of our approach, we

demonstrate it for benchmarks of different charac-

teristics: (a) Coarse-grained Visual Categorization

(CGVC): CIFAR-10 and CIFAR-100 (Krizhevsky,

2009); and (b) Fine-grained Visual Categorization

(FGVC): Caltech-UCSD Birds-200-2011 (Wah et al.,

2011), Car Stanford (Krause et al., 2013), Dog Stan-

ford (Khosla et al., 2011), Aircrafts (Maji et al.,

2013), and iFood

In contrast to CGVC, where the classes are well

separable, in FGCV the single classes are more simi-

lar. Demonstrating CGVC and FGVC results side by

side should also show that the choice of the activation

function has a different impact on the two problems.

However, we can also see that PSO performs well on

both tasks.

4.2 Experimental Setup

To allow for a fair comparison on these rather het-

erogeneous datasets, we used the same experimental

setup for all experiments:

For neural networks training, we used an architec-

ture consisting of eight convolutional plus two fully

connected layers with 400 and 900 units, respectively.

For training, we applied an Adam optimizer with

batch normalization, using a batch size of 70 and a

maximum pooling size of seven. To avoid random ef-

fects and to keep the results traceable, we abstained

from using dropout regularization. Using a random

initialization, we ran all experiments ﬁve times, where

the mean results are reported, respectively.

For the PSO-step (Miranda, 2018), we initialized

the particles in the expected range, i.e., x ∈ [0, 1], how-

ever, during optimization the search space was given

by [0, ∞). The parameters ε, w, β, γ, and δ were set

to 1, 0.5, 0.5, 0.3, and 0.3, respectively. We used a

swarm-size of 10 and run the optimization using the

loss on an independent test set as the ﬁtness function

https://sites.google.com/view/fgvc5/competitions/

fgvcx/ifood (last accessed: October 31, 2020)

for 15 epochs. The number of iterations in PSO was

set to 5, and for Local PSO 4 neighbors have been

considered. Please note that the estimated slopes are

kept ﬁxed and are not changed during neural network

training. That is, in particular, a signiﬁcant difference

to PReLU, where the slope is adapted during the neu-

ral network training.

4.3 PSO vs. Optimal Slope

In the ﬁrst experiment, we compare the slopes es-

timated using Global PSO (GPSO) and Local PSO

(LPSO) to the optimal slopes identiﬁed in (Basirat

and Roth, 2020). The corresponding results for

CGVC and FGVC are summarized in Tables 1 and 2,

respectively.

It can be seen that for the simpler CGVC both ap-

proaches, GPSO and LPSO, yield similar results close

to the optimal slope. In contrast, for the FGVC bench-

marks, GPSO yields consistently better results, i.e.,

the estimated slopes are closer to the optimal ones.

Thus, from the practical (data-agnostic) point of view,

we would recommend using GPSO, which would give

better results in the expected case. The ambiguity* for

Aircraft can be explained by the fact that in (Basirat

and Roth, 2020) for this dataset two optimality peaks

(i.e., α = 0.2 and α = 0.35) have been reported. Over-

all, these results clearly show that our fully automatic

approach, in particular the GPSO variant, allows us

to recover the optimal slope parameter even without

having any prior knowledge.

Table 1: Comparison of the best slope of L*ReLU and

slopes found via GPSO and LPSO for the CGVC bench-

marks.

Dataset

Best slope

(L*ReLU)

Slope

(GPSO)

Slope

(LPSO)

CIFAR-10 0.10 0.12 0.11

CIFAR-100 0.10 0.11 0.11

Table 2: Comparison of the best slope of L*ReLU and

slopes found via GPSO and LPSO for the FGVC bench-

marks.

Dataset

Best slope

(L*ReLU)

Slope

(GPSO)

Slope

(LPSO)

Birds 0.35 0.36 0.01

Cars 0.25 0.30 0.41

Dogs 0.05 0.06 0.01

iFood 0.35 0.35 0.43

Aircraft* 0.35 0.17 0.22

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

650

4.4 Comparison to the State-of-the-Art

Next, we compare the classiﬁcation accuracy of

S*ReLU (GPSO and LPSO) to (a) L*ReLU (deﬁn-

ing the ”upper bound”), (b) well-known and widely

used AFs and known to yield good results in practice,

namely ReLU (Nair and Hinton, 2010), ELU (Clev-

ert et al., 2016), SELU (Klambauer et al., 2017), and

Swish (Ramachandran et al., 2018), and (c) to Para-

metric ReLU (PReLU) (the most related approach.)

The thus obtained mean accuracies for CGVC and

FGVC are shown in Tables 3 and 4, respectively.

Table 3 shows that for CGVC all activation func-

tions perform more or less on par. In addition, we

see that both GPSO and LPSO match the optimal re-

sults of L*ReLU, where—as expected from the es-

timated slopes—LPSO gives slightly better results.

In contrast, for FGVC, as can be seen in Table 4,

LPSO provides—as was expected from the estimated

slopes—worse results compared to GPSO. However,

again S*ReLU matches the optimal results of L*ReLU

very well. The other activation functions give worse

results, as was also shown in (Basirat and Roth, 2020).

In particular, this applies for PReLU, which also es-

timates the slope parameter automatically. However,

the approach tends to get stuck into a local minimum,

whereas S*ReLU ensures a globally optimal solution

in any case.

4.5 Computational Effort

In Secs. 4.3 and 4.4, we demonstrated that, compared

to other widely-used activation functions, S*ReLU

gives better results, even matching those of L*ReLU,

where the optimal parameter was estimated via a

brute-force grid search. The main advantage of

S*ReLU is that this parameter is estimated automat-

ically, drastically reducing the computational effort.

In fact, for L*ReLU the search space was deﬁned by

16 slopes equidistantly sampled in the range [0,1]. To

reduce the impact of random effects, each experiment,

running 90 epochs, was repeated 5 times. In contrast,

for S*ReLU, using a swarm size of 10 and 5 PSO it-

erations, we need to run only 15 epochs. In this way,

the computational effort can be reduced by a factor of

10, still preserving the same classiﬁcation accuracy.

5 CONCLUSION

For many classiﬁcation problems, Leaky ReLU

(LReLU) provides better results compared to other

widely-used activation functions. However, the nec-

essary parameter, i.e., the slope of the negative part,

has to be estimated empirically from the data, or the

approaches are very sensitive to proper initialization.

In this paper, we propose an automatic approach, not

suffering from these problems. In particular, we learn

the negative slope of LReLU via Particle Swarm Opti-

mization (PSO): S*ReLU. This metaheuristic stochas-

tic optimization method ensures a globally optimal

solution, where we applied two different approaches:

LPSO and GPSO. The experimental results revealed

that we match the (optimal) accuracy of L*ReLU, but

at a signiﬁcantly reduced computational effort. Since,

in the expected case, GPSO gives better results than

LPSO, we would recommend using GPSO.

ACKNOWLEDGEMENTS

This work is (in part) supported by the German Fed-

eral Ministry of Education and Research (BMBF)

in the framework of the international future AI lab

AI4EO (Grant number: 01DD20001).

Table 3: Mean accuracies for different activation functions for CGVC, where the proposed approaches are in color.

Dataset ELU Swish ReLU SeLU PReLU L*ReLU GPSO LPSO

CIFAR-10 90.81% 91.23% 90.83% 89.72% 87.83% 90.98% 91.02% 91.06%

CIFAR-100 63.64% 64.36% 65.32% 63.29% 60.28% 66.44% 65.90% 66.19%

Table 4: Mean accuracies for different activation functions for FGVC, where the proposed approaches are in color.

Dataset ELU Swish ReLU SeLU PReLU L*ReLU GPSO LPSO

Birds 39.12% 38.89% 38.18% 36.86% 37.69% 44.30% 43.81% 36.93%

Cars 41.86% 44.72% 33.08% 39.17 % 40.07% 47.20% 47.88% 45.83%

Dogs 35.67% 37.04% 35.17% 33.65% 35.14% 37.63% 37.58% 35.65%

iFood 38.12% 41.14% 37.67% 34.67% 39.27% 42.81% 42.06% 40.86%

Aircraft 38.97% 39.63% 38.49% 30.54% 37.03% 40.42% 39.35% 39.89%

S*ReLU: Learning Piecewise Linear Activation Functions via Particle Swarm Optimization

651

REFERENCES

Anil, C., Lucas, J., and Grosse, R. B. (2019). Sorting out

Lipschitz function approximation. In ICML.

Basirat, M. and Roth, P. M. (2019). Learning task-speciﬁc

activation functions using genetic programming. In

VisApp.

Basirat, M. and Roth, P. M. (2020). L*ReLU: Piece-wise

linear activation functions for deep ﬁne-grained visual

categorization. In WACV.

Clevert, D., Unterthiner, T., and Hochreiter, S. (2016). Fast

and accurate deep network learning by exponential

linear units (ELUs). In ICLR.

Eberhart, R. and Kennedy, J. S. (1995). A new optimizer

using particle swarm theory. In Pro. Int’l Symposium

on Micro Machine and Human Science, pages 39–43.

Elfwing, S., Uchibe, E., and Doya, K. (2018). Sigmoid-

weighted linear units for neural network function ap-

proximation in reinforcement learning. Neural Net-

works, 107:3–11.

Glorot, X., Bordes, A., and Bengio, Y. (2011). Deep sparse

rectiﬁer neural networks. In Proc. Int’l Conf. on Arti-

ﬁcial Intelligence and Statistics.

Goldberg, D. E. (1989). Genetic Algorithms in Search, Op-

timization and Machine Learning. Addison-Wesley.

Gulcehre, C., Moczulski, M., Denil, M., and Bengio, Y.

(2016). Noisy activation functions. In ICML.

Hayou, S., Doucet, A., and Rousseau, J. (2018). On the

selection of initialization and activation function for

deep neural networks. arXiv:1805.08266.

He, K., Zhang, X., Ren, S., and Sun, J. (2015). Delving deep

into rectiﬁers: Surpassing human-level performance

on imagenet classiﬁcation. In ICCV.

Hochreiter, S. (1998). The vanishing gradient problem dur-

ing learning recurrent neural nets and problem solu-

tions. Int’l Journal of Uncertainty, Fuzziness and

Knowledge-Based System, 6(2):107–116.

Holland, J. H. (1992). Adaptation in Natural and Artiﬁcial

Systems: An Introductory Analysis with Applications

to Biology, Control and Artiﬁcial Intelligence. MIT

Press.

Hornik, K. (1991). Approximation capabilities of mul-

tilayer feedforward networks. Neural Networks,

4(2):251–257.

Jin, X., Xu, C., Feng, J., Wei, Y., Xiong, J., and Yan, S.

(2016). Deep learning with S-shaped rectiﬁed linear

activation units. In AAAI, pages 1737–1743.

Khosla, A., Jayadevaprakash, N., Yao, B., and Fei-Fei, L.

(2011). Novel dataset for ﬁne-grained image catego-

rization. In Workshop on Fine-Grained Visual Cate-

gorization (CVPRW).

Klambauer, G., Unterthiner, T., Mayr, A., and Hochre-

iter, S. (2017). Self-normalizing neural networks. In

NeurIPS.

Koza, J. R., Bennett, F. H., and Stiffelman, O. (1999). Ge-

netic programming as a darwinian invention machine.

In European Conf. on Genetic Programming.

Krause, J., Stark, M., Deng, J., and Fei-Fei, L. (2013). 3D

object representations for ﬁne-grained categorization.

In Int’l Workshop on 3D Representation and Recogni-

tion.

Krizhevsky, A. (2009). Learning multiple layers of features

from tiny images. Technical Report 1 (4), 7, Univer-

sity of Toronto.

Li, Y., Fan, C., Li, Y., Wu, Q., and Ming, Y. (2018). Im-

proving deep neural network with multiple parametric

exponential linear units. Neurocomputing, 301:11–24.

Lorenzo, P. R., Nalepa, J., Kawulok, M., Ramos, L. S., and

Ranilla, J. (2017). Particle swarm optimization for

hyper-parameter selection in deep neural networks. In

Genetic and Evolutionary Computation Conf.

Maas, A. L., Hannun, A. Y., and Ng, A. Y. (2013). Rectiﬁer

nonlinearities improve neural network acoustic mod-

els. In Workshop on Deep Learning for Audio, Speech

and Language Processing (ICML).

Maji, S., Rahtu, E., Kannala, J., Blaschko, M., and Vedaldi,

A. (2013). Fine-grained visual classiﬁcation of air-

craft. arXiv:1306.5151.

Miranda, L. J. V. (2018). PySwarms, a research-toolkit for

Particle Swarm Optimization in Python. Journal of

Open Source Software, 3(21):433.

Nair, V. and Hinton, G. E. (2010). Rectiﬁed linear units

improve restricted boltzmann machines. In ICML.

Osman, I. H. and Laporte, G. (1996). Metaheuristics: A bib-

liography. Annals of Operations Research, 63:511–

623.

Ramachandran, P., Zoph, B., and Le, Q. V. (2018). Search-

ing for activation functions. In ICLRW.

Schwefel, H.-P. (1987). Collective phenomena in evolu-

tionary systems. In Annual Meeting Problems of Con-

stancy and Change.

Sinha, T., Haidar, A., and Verma, B. (2018). Particle swarm

optimization based approach for ﬁnding optimal val-

ues of convolutional neural network parameters. In

IEEE Congress on Evolutionary Computation.

Sokoli

c, J., Giryes, R., Sapiro, G., and Rodrigues, M.

(2017). Robust large margin deep neural net-

works. IEEE Transactions on Signal Processing,

65(16):4265–4280.

Spall, J. C. (2003). Introduction to Stochastic Search and

Optimization. John Wiley & Sons, 1 edition.

Trottier, L., Gigu

ere, P., and Chaib-draa, B. (2017). Para-

metric exponential linear unit for deep convolutional

neural networks. In Int’l Conf. on Machine Learning

and Applications.

Tsuzuku, Y., Sato, I., and Sugiyama, M. (2018). Lipschitz-

margin training: Scalable certiﬁcation of perturbation

invariance for deep neural networks. In NeurIPS.

Wah, C., Branson, S., Welinder, P., Perona, P., and Belongie

(2011). The Caltech-UCSD Birds-200-2011 Dataset.

Technical Report CNS-TR-2011-001, California In-

stitute of Technology.

Wang, B., Sun, Y., Xue, B., and Zhang, M. (2018). Evolving

deep convolutional neural networks by variable-length

particle swarm optimization for image classiﬁcation.

In IEEE Congress on Evolutionary Computation.

Xu, B., Wang, N., Chen, T., and Li, M. (2015). Empirical

evaluation of rectiﬁed activations in convolution net-

work. arXiv:1505.00853.

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

652
