factors should be taken into consideration when using
the Moverio BT-35E binocular Optical See-Through
device. Although somewhat capable, this device is
not the best suited for AR purposes, due to the lack
of specific System Development Kits for their setup
and usage. That said, this paper focus on techniques
and procedures on how to get this device setup for AR
usage, trying to circumvent the mishaps that currently
exist.
Some obstacles were raised during the develop-
ment, like the lack of System Development Kits that
provide device display calibration for free and/or
weren’t fully compatible with each other. This cre-
ated the need for developing a solution for that, where
performance was also an obstacle to take into account
and discussed in the paper.
In the future it is expected that the concepts and
processes discussed here in this article will be applied
in the project under development, more precisely us-
ing the device with an AR software in support for
warehouse order picking processes. This way, it is
possible to help a warehouse operator to perform his
tasks in a simpler and faster way, without great com-
plexity or previous knowledge required. This aid may
be provided using the information and visual instruc-
tions on the Epson BT-35E device, thus informing the
user of the current status of a task, which must be
taken inside a warehouse when executing a route con-
sisting in the picking of products, among others.
ACKNOWLEDGMENTS
This work is co-financed by the ERDF - European Re-
gional Development Fund under the Operational Pro-
gram for Competitiveness and Internationalization -
COMPETE 2020 of Portugal 2020 through ANI - Na-
tional Innovation Agency - Project ”AR WARE: Aug-
mented Reality for intelligent WAREhouse manage-
ment: POCI- 01-0247-FEDER-033432”.
