Evaluating Synthetic Speech Workload with Oculo-motor Indices:

Preliminary Observations for Japanese Speech

Mateusz Dubiel

, Minoru Nakayama

and Xin Wang

Dept. Computer and Information Sciences, The University of Strathclyde, U.K.

Dept. Information and Communications Engineering, Tokyo Institute of Technology, Japan

National Institute of Informatics, Japan

Keywords:

Speech Processing, Synthetic Speech Evaluation, Pupillometry, Cognitive Workload.

Abstract:

Pupillometry has recently been introduced as a method to evaluate cognitive workload of synthetic speech.

Prior research conducted on English speech indicates that in noisy listening conditions, pupil dilation is sig-

niﬁcantly higher for synthetic speech as compared to natural speech. In a lab-based listening experiment, we

evaluated participants’ (n=16) pupil responses to Japanese speech (natural vs. synthetic) at three different

signal-to-noise levels (-1dB, -3dB and -5dB). Our research expands on previous work by evaluating pupil-

lary responses both in terms of temporal changes in pupil size and degree of pupil oscillations. We observe

statistically signiﬁcant differences in pupil sizes at the recall stage between each type of speech. For pupil

oscillations, we register statistically signiﬁcant differences in frequency power spectrum densities (PSDs).

Our investigation proposes an expansion of the current synthetic speech evaluation methods that are based on

pupillary responses and outlines possible avenues for future research that arise from the ﬁndings of this work.

1 INTRODUCTION

Although pupillometry has been used to measure cog-

nitive load for a long time (cf. Kahneman and Beatty

(1966); Beatty (1982); Kursawe and Zimmer (2015)),

it is only recently that it has been applied to the eval-

uation of text-to-speech (TTS) systems. The use of

the method for TTS cognitive workload evaluation

was pioneered by Govender and King Govender and

King (2018b). In their recent study, Govender et

al. Govender et al. (2019) found that in quiet listen-

ing conditions increased pupil dilation indicates at-

tention and engagement, while in noisy conditions,

increased pupil dilation indicates increased listening

effort. The results of recent evaluation studies Goven-

der and King (2018b); Govender et al. (2019); Siman-

tiraki et al. (2018) are promising and indicate that

pupil dilation can be used as an index of cognitive

listening effort for TTS systems.

However, since the ﬁndings of previous research

Govender and King (2018b); Govender et al. (2019);

Simantiraki et al. (2018) are limited only to the En-

glish language, it raises questions over their applica-

bility to other languages. For instance, English and

Japanese vary in terms of their phonemic invento-

ries (larger for English) and syllable structures (more

complex for English) (cf. (Ohata, 2004)). While there

are 15 different vowels (including diphthongs) in En-

glish, Japanese has only 5 vowels (ibid.). The larger

phonemic inventory potentially makes a language less

robust to noise, as the potential for confusing differ-

ent phonemes increases. Therefore, evaluations of

TTS systems may vary between different languages.

With this premise in mind, we analyse pupil dilation

and pupil oscillations to measure the listening effort

required by Japanese speech in noise conditions and

compare our ﬁndings to the similar study conducted

for English speech Govender et al. (2019).

Our experiment contributes to the current body of

TTS evaluation research by providing preliminary ob-

servations of using pupil dilation to evaluate Japanese

TTS. Additionally, we expand the current method by

also analysing pupil oscillations. Firstly, our investi-

gation aims to address the following questions.

• RQ1: How does the listening effort vary between

natural and synthetic speech at 3 different signal-

to-noise levels, i.e. -1dB, -3dB and -5dB?

• RQ2: What insights do pupil oscillations provide

into measuring the cognitive workload of syn-

thetic speech in noisy listening conditions?

Secondly, we reﬂect on the possible future directions

Dubiel, M., Nakayama, M. and Wang, X.

Evaluating Synthetic Speech Workload with Oculo-motor Indices: Preliminary Observations for Japanese Speech.

DOI: 10.5220/0010341303350342

In Proceedings of the 14th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2021) - Volume 4: BIOSIGNALS, pages 335-342

ISBN: 978-989-758-490-9

335

of research and make suggestions on how to make

the evaluation procedure of synthetic speech more

roboust.

2 RELATED WORK

2.1 Experiments with Natural Speech

Prior research shows that listening to natural speech

in noisy conditions is a cognitively demanding task,

especially if the speech samples presented are not in

listeners’ native language. Nakamura and Gordon-

Salant Nakamura and Gordon-Salant (2011) evalu-

ated the ﬁrst and the second language perception abil-

ities in quiet and noisy conditions of Japanese speak-

ers who moved to the USA in their mid-twenties.

Nakamura and Gordon-Salant used speech recogni-

tion thresholds to measure comprehension and found

that Japanese speakers who had excellent English

word recognition ability in quiet conditions failed to

reach native-like standard in noisy conditions. The

study illustrated the impact of noise on the compre-

hension of ﬁrst and second language speech stimuli.

In our study, to reduce potential contribution of sec-

ond language to cognitive load we only use native-

Japanese speakers.

Zekveld et al. Zekveld et al. (2010) evaluated the

inﬂuence of speech intelligibility on pupil dilation

during listening tests. The authors found that peak

dilation amplitude, peak latency, and mean pupil di-

lation systematically increase with decreasing speech

intelligibility. In other words, pupil response sys-

tematically varied as a function of speech intelligi-

bility. As highlighted by Zekveld et al. (ibid.), ap-

plying pupillometry to measuring listening effort can

yield valuable insights into the processing resources

required across listening conditions.

2.2 Experiments with Synthetic Speech

More recent research focused on applying pupilom-

etry to evaluate the contribution of synthetic speech

to cognitive workload. Govender and King Goven-

der and King (2018a) used the dual-task paradigm to

measure the impact of synthetic speech on cognitive

load. The authors conducted a series of experiments

where participants had to perform an additional task

(numerical and lexical reasoning) while listening to

speech stimuli. They observed that participants’ re-

action time increased with the decrease in the quality

of synthetic speech. Interestingly, the reaction times

were not the fastest for natural speech which indi-

cated that the dual-task paradigm might be measuring

a listener’s attention rather than their listening effort.

Based on this premise, Govender and King discontin-

ued using the dual-task paradigm in their follow-up

experiments.

In the followup studies, Govender et al. Goven-

der et al. (2019) evaluated the contribution of speech

to cognitive workload at different signal-to-noise lev-

els (i.e. -1dB, -3dB and -5dB). Their results indicated

that listening effort increased as signal-to-noise ration

decreased. The authors observed that for lower qual-

ity TTS systems (i.e. Hidden Markov Model (HMM)

systems) the attention ceiling was reached at lower

signal-to-noise levels. In our experiments, to estab-

lish a strong baseline we did not use HMM systems

but instead developed a state-of-the-art TTS system

using neural-network-based models (see Section 3.1

for details).

3 EXPERIMENTAL DESIGN

To address our research questions RQ1 and RQ2

(outlined in Section 1), we conducted a listening ex-

periment. 16 native Japanese speakers (M = 14, F =

2) with no self-reported hearing problems took part in

the experiment. The age of participants was between

21 and 25 years (Mean = 22.5).

3.1 Speech Stimuli

The Japanese speech corpus of Saruwatari-lab., Uni-

versity of Tokyo (JSUT)

was used to select speech

samples. The corpus consists of voice recordings of

a native Japanese female speaker, recorded in an an-

echoic room and sampled at 48kHz. We selected 40

sentences from the travel-domain subset of the corpus

(travel1000) as the natural speech stimuli. We then

used a Japanese state-of-the art text-to-speech (TTS)

system to synthesize speech wave-forms from the text

transcription of the selected natural stimuli.

The TTS system was built on the basis of the

classical neural-network-based statistical parametric

speech synthesis framework (Zen et al., 2013). It

uses an OpenTalk-based text analyzer (HTS Working

Group, 2015) to convert the text string into phonetic

labels, an RNN acoustic model to convert the labels

into acoustic features (i.e., Mel-cepstral coefﬁcients,

F0 trajectory, and aperiodicity parameters), and the

WORLD vocoder (HTS Working Group, 2015) to

produce the 48 kHz waveform with acoustic fea-

tures. For this experiment, the duration of phones was

https://tinyurl.com/jsutcorpus

BIOSIGNALS 2021 - 14th International Conference on Bio-inspired Systems and Signal Processing

336

aligned against the natural stimuli using a HMM (Ra-

biner, 1989).

The average duration of the selected sentences

was 3 seconds. In line with previous research (Goven-

der et al., 2019), we decided to select samples of

this length to facilitate sentence repetition for the par-

ticipants. The selected samples were mixed with a

speech-shaped noise at three levels of signal-to-noise:

-1dB,-3dB and -5dB. Speech stimuli were divided

into two blocks of natural and synthetic speech. There

were 10 sentences in each block. We alternated the se-

quence of blocks for each participant in order to pre-

vent a sequencing effect. The participants were di-

vided into 3 groups, and each group listened to the

stimuli at a different level of noise, i.e. -1dB, -3dB

and -5dB.

3.2 Procedure

The experiment took place at Tokyo Institute of Tech-

nology Lab. All participants attended a brieﬁng ses-

sion before the experiment and provided their written

consent in order to participate. Pupil data was col-

lected using an ACTUS Eye-tracker using 60Hz sam-

pling rate for both eyes. Participants listened to audio

samples via Sony WH-CH700N On-Ear headphones.

In preparation of the experimental setup we followed

the procedure explained in Winn et al. (2018).

3s Speech sound

Recall (4s)

With

Noise

Phase 1 (2s)

Phase 2

Phase 3 (2s)

Phase 4

Phase 5 (4s)

Figure 1: Experimental Procedure.

The experimental procedure is presented in Fig-

ure 1. Participants were asked to look at the black

cross on a grey background, listen to speech samples

and to respond by repeating the words that they had

heard when the cross changed its colour to red. Mask-

ing speech-shaped noise was present while the black

cross was displayed and it was turned off when the

cross changed its colour to red.

The experimental procedure consisted of ﬁve

phases. Phase 1 (0-2 seconds) immediately preceded

the onset of the sentence and was used for pupil cali-

bration. In phase 2 (2-5 seconds), participants had to

listen to and memorise the speech stimulus . Next, in

phase 3 (5-7 seconds) participants retained informa-

tion and then repeated it in the recall phase 4 (8-12

seconds). The ﬁnal phase 5 - was ”relax and refresh”

(12-16 seconds). The recall attempt was considered

as successful only if the whole utterance was repeated

correctly.

At the end of each block (10 sentences), the partic-

ipants were asked to ﬁll in a questionnaire regarding

their listening effort, perceived naturalness of speech,

and motivation to listen to the samples. All of the

items were measured on a 5-point Likert scale and ap-

plied as in Govender et al. (2019). For listening effort

- 1 signiﬁed the least effort and 5 signiﬁed the most

effort; for naturalness - 1 signiﬁed the least natural

voice and 5 the most natural voice; and for motivation

- 1 signiﬁed the lowest motivation and 5 signiﬁed the

highest motivation. We used questionnaires as com-

plimentary subjective evaluation measures in addition

to objective measures (pupil responses).

3.3 Pre-processing

The mean and standard deviations (SD) of the pupil

size, from 1 second before the sentence onset (base-

line) up until the start of the verbal response were cal-

culated. Pupil diameters for both eyes were measured

at 60Hz. Since the eye-tracker can detect measuring

errors such as blinks, they were replaced with the pre-

vious ‘normal’ size. Pupil sizes were standardised us-

ing the mean pupil size before the stimulus onset as

a baseline. Relative pupil size was calculated by di-

viding the observed pupil size by the baseline. In the

following analysis, pupillary changes on both eyes are

processed as independent data such as repeated mea-

sures on a trial.

4 RESULTS

Recall accuracy is presented in Table 1. There are

signiﬁcant differences in recall rates between natu-

ral and synthetic speech except -3dB condition (-

1dB:t(4) = 5.1, p < 0.01, -3dB:t(8) = 2.2, p = 0.06,

-5dB:t(7) = 4.1, p < 0.01) The result of the two-way

Anova shows that the natural/synthetic factor is sig-

niﬁcant (F(1, 23) = 34.0, p < 0.01) while the signal-

to-noise level factor is not signiﬁcant (F(2, 23) =

2.01, p = 0.16).

4.1 Self-reported Measures

The self-reported measures are presented in Figure 2.

As expected, natural speech is rated as more natural

than synthetic speech. However, the scores go down

Evaluating Synthetic Speech Workload with Oculo-motor Indices: Preliminary Observations for Japanese Speech

337

Figure 2: Comparison of participants’ ratings for Naturalness, Cognitive Load and Motivation.

Table 1: Recall accuracy.

Level S/N Mean STD

-1dB** N 1.00 -

S 0.74 0.11

-3dB N 0.96 0.09

S 0.78 0.16

-5dB** N 0.90 0.10

S 0.68 0.05

Correct:

Incorrect:

-1dB

-3dB

-5dB

Figure 3: Change in pupil size when reference material was

correctly and incorrectly repeated.

as the level of noise increases. Natural speech is also

perceived as less cognitively taxing than synthetic

speech. Interestingly, synthetic speech was rated as

easier to listen to at higher levels of noise. Finally,

for motivation we can see that participants were less

motivated to listen to the stimuli at the highest level

of noise which is potentially reﬂective of the task dif-

ﬁculty.

4.2 Pupil Dilation

Mean relative pupil sizes for natural and synthetic

speech at 3 levels of signal-to-noise, for all listening

phases (1-5) are summarised in Table 2. As the re-

call accuracy varies between different signal-to-noise

levels the pupil sizes are summarised for the correct

responses (see Table 1 for details). For the correct

recall attempts, we observe an increase in pupil size

until phase 3 and from thereon there is a decrease un-

til phase 5. Since pupil response has a time-delay

(Beatty, 1982), the size for phase-4 is also the high-

est in some conditions. This phenomenon coincides

with the ﬁndings of previous studies (Kahneman and

Beatty (1966); Beatty (1982)).

At phase 5 (after the recall phase), the pupil size

for synthetic speech is higher than for the natural

speech except for the -5dB condition. We conducted

a two-way Anova to determine the impact of speech

type (natural vs. synthetic) at three levels of signal-

to-noise (-1 ∼ -5dB) on pupil dilation. The results are

summarised in Table 3. In phase 5, we observed sta-

tistically signiﬁcant differences in pupil sizes for both

factors (speech sound: F(1, 348) = 5.91, p < 0.05 and

sound level: F(2, 348) = 3.14, p < 0.05). The inter-

action is not signiﬁcant. Mean pupil size for synthetic

speech is larger than for natural sound, and also pupil

size increases with the level of signal-to-noise ratio (-

1dB to -5dB).

In the next step, we compared the pupil sizes for

correct and incorrect responses. Figure 3 presents par-

ticipants’ relative pupil size for experimental phases

1-5. The ﬁgure compares pupillary changes between

correct and incorrect recall attempts. For the correct

recall attempts, pupil size increases until phase 3 and

from there decreases until phase-5. In particular, the

peak is most prominent for the -5dB condition, which

indicates that this condition requires the most mental

effort. For the incorrect recall attempts, we observe

a downward trend with the exception of -5dB condi-

tion, where there is an increase in phase 3, however

the peak is ﬂatter as compared to correct recall at-

tempts. The trajectory of changes in pupil size for

incorrect responses seems to indicate that the subjects

gave up on their recall attempts after the phase 2.

4.3 Pupil Oscillations

When the pupil size changes, some pupillary os-

cillations in the lower frequency band are observed

BIOSIGNALS 2021 - 14th International Conference on Bio-inspired Systems and Signal Processing

338

Table 2: Mean pupil sizes during 5 phases.

Phase

Level N/S N 1 2 3 4 5

-1dB N 76 1.02 1.05 1.07 1.07 1.01

S 54 1.02 1.07 1.10 1.10 1.07

-3dB N 66 1.02 1.07 1.10 1.10 1.05

S 50 1.02 1.07 1.09 1.11 1.08

-5dB N 64 1.02 1.10 1.15 1.13 1.08

S 44 1.02 1.09 1.12 1.12 1.08

Table 3: Two-way ANOVA for pupil sizes at pahse 5.

Source df SS V F Pr

Nat/Syn* 1 0.076 0.076 5.91 0.02

Level* 2 0.081 0.040 3.14 0.04

Interaction 2 0.057 0.028 2.22 0.11

Error 348 4.444 0.013

as a low-pass ﬁlter due to the biological signal

(Duchowski et al., 2018). As presented in previous

work, these frequency powers of pupillary changes

can sometimes be used as an index of mental activity

(Nakayama and Shimizu, 2004; Peysakhovich et al.,

2015).

We calculated power spectrum densities (PSD) for

each phase in a trial at frequency powers of 1.88Hz

and 3.75Hz.

PSDs at 1.88Hz are compared for both types of

speech at 3 noise-to-signal ratios across 5 phases.

We observe signiﬁcant differences in PSDs between

sound sources except for the -1dB condition. The

maximum powers are marked at phase 3 for the -5dB

condition, and at phase-4 for -1dB and -3dB condi-

tions. The sound levels seem to inﬂuence pupil oscil-

lations.

PSDs at 3.75Hz are compared and summarised in

Figure 4. All PSDs are minimised during the memo-

rising phase (phase 2), this suggests that participants

were focused while the speech stimuli were being

played. The maximised PSDs are different between

different noise-to-signal levels; at phase 3 for -5dB,

phase-4 for -3dB, and phase-5 for -1dB. However, no

statistically signiﬁcant differences were detected. For

most conditions the powers are the minimum level at

phase 2, the memorising stage. After phase 2, pupil

oscillation in higher frequency increased with the ex-

perimental phases. The maximum phases are phase

5 for -1dB condition, phase 4 for -3dB condition, and

phase 3 for -5dB. The levels of noise inﬂuenced pupil-

lary oscillation for a longer amount of time.

Frequency power spectrum densities (PSDs =

1.88Hz) - presented in Figure 7 - are summarised

as two a dimensional category: natural (N) and syn-

thetic (S) at three signal-to-noise levels (-1dB, -3dB,

and -5dB). There are statistically signiﬁcant differ-

Natural:

Synthetic:

-1dB

-3dB

-5dB

3.75Hz

Figure 4: Frequency power of pupil oscillation (f=3.75Hz).

Correct:

Incorrect:

-1dB

-3dB

-5dB

1.88Hz

Figure 5: Correct and incorrect recall responses for f =

1.88Hz).

ences (p<0.05) in PSDs between natural and syn-

thetic sounds for level -3dB and -5dB. However, the

orders are different between two conditions. At -

3dB, oscillations are higher for natural than synthetic

speech and for -5dB the reverse is the case. On the

other hand, the maximum powers are marked at phase

4 for the condition -1dB and -3dB, and at phase 3

for the condition -5dB. The highest levels of mental

workload were observed at the recall phase (phase 4)

for -1dB and -3dB, and at retention phase (phase 3)

for -5dB. This may indicate that a higher level of noise

makes retention more difﬁcult for natural speech.

PSDs are compared between correct and failed re-

sponses for PSDs = 1.88Hz (Figure 5) and PSDs =

3.75 (Figure 6). For correct responses the pupil os-

Evaluating Synthetic Speech Workload with Oculo-motor Indices: Preliminary Observations for Japanese Speech

339

Correct:

Incorrect:

-1dB

-3dB

-5dB

3.75Hz

Figure 6: Correct and incorrect recall responses for f =

3.75Hz).

Natural:

Synthetic:

-1dB

-3dB

-5dB

1.88Hz

Figure 7: Frequency power of pupil oscillation (f=1.88Hz).

cillations reach a maximum at phase 3 or 4 (PSDs =

1.88Hz). However, in incorrect responses our data

shows that the maximum occurs at the memorising

phase (phase 2); when subjects failed the memorisa-

tion, the power monotonically decreases. Frequency

power spectrum densities (PSDs = 3.75Hz) are com-

pared between correct and failed responses. When the

recall failed, the maximums for pupil oscillation were

observed in phase 5 for -1dB, and phase 4 for -3dB

and -5dB.

5 DISCUSSION

Our analysis of pupillary responses for natural and

synthetic Japanese speech at three different signal-to-

noise levels leads us to the following observations.

Pupil Dilation: We observed statistically signiﬁ-

cant differences between natural and synthetic speech

at the ﬁnal experimental stage - phase 5 (relax and

refresh) for all signal-to-noise levels except -5dB.

This may indicate that at this level, for the syn-

thetic speech, participants’ attention threshold was

exceeded. There is a rapid increase of pupil size in

phase 4 and subsequently it takes longer for pupils to

stabilise. It is possible that participants may have been

reﬂecting whether their response was correct. For cor-

rect responses we observed peaks at phase 3, with

the exception of condition -3dB where pupil dilation

peaks in phase 4. This may indicate that higher lev-

els of noise trigger quicker pupillary responses (faster

rate of increase). With regards to the RQ1, our ﬁnd-

ings are in line with previous research Govender et al.

(2019) - indicating that synthetic speech imposes a

higher cognitive load as compared to natural speech.

Pupil Oscillations: At 1.88Hz, maximum power

spectrum densities were observed at the retention

phase (phase 3) for condition -5dB, and the recall

phase (phase 4) for conditions -1dB and -3dB. It

seems that the high level of noise led to an increased

cognitive load at the retention stage that was higher

than in the recall phase. We, therefore, hypothesise

that high levels of noise led to stronger pupil oscil-

lations and low recall accuracy as observed in Table

1. Following the failed attempt to retain information,

the oscillations decrease (less cognitive resources are

involved in recall). There is similarity between dila-

tion and oscillations as both tend to peak at the reten-

tion stage for -5dB and for the recall phase for -1dB

and -3dB which indicates that using oscillations also

provides empirical insights for assessing the cognitive

workload of TTS systems (RQ2).

Self-reported Measures: reﬂect the ﬁndings of

the study by Govender et al. Govender et al. (2019)

- with synthetic speech being ranked as more cogni-

tively taxing than natural speech at all levels of signal-

to-noise. Interestingly, however, while for natural

speech, cognitive load ratings remain relatively sta-

ble, synthetic speech is ranked as less taxing at higher

levels of noise (see Figure 2 for details). Partici-

pants have retained high levels of listening motivation

throughout the experiment with the exception of the -

5dB condition for synthetic speech where we can see

a drop in motivation. This trend could be attributed to

excessive level of noise, making the listening task too

difﬁcult in this condition.

BIOSIGNALS 2021 - 14th International Conference on Bio-inspired Systems and Signal Processing

340

6 LIMITATIONS AND FUTURE

WORK

While our study provides insights into using a com-

bination of oculo-motor indices to evaluate Japanese

TTS, we are mindful of its limitations. Firstly, the

study was conducted on a relatively small sample (n

= 16) of predominantly male participants. Secondly,

the study was conducted in a lab environment using

computer generated speech-shaped noise. Thus eval-

uation results can vary in other environments, such as

real-life noisy listening conditions or an-echoic cham-

ber. Thirdly, self-reported measures are subject to

inter-rater variability which could affect the objec-

tive assessment of speech. Finally, it should also be

noted that other factors beyond our control, such as

stress, could have affected the experimental outcome

as some participants were more concerned about pro-

viding correct responses.

Although the above limitations may affect the

generalisability of our research results, they also high-

light the variables that should be taken into account

in order to make evaluation of TTS more robust and

standardised. In future research, the issues of gender

and experimental design should be given more atten-

tion in order to ensure higher ecological validity of

evaluations. Firstly, whenever possible, participant

samples should be gender- and age-balanced, with

ﬁndings investigated separately for each gender and

age group. Secondly, similar consideration should be

given to the types of voices that are selected for syn-

thesis. Thirdly, calibration of sound pressure should

also be considered in evaluation - while the volume

of sound can have an impact of participants’ cogni-

tive workload, to the best of our knowledge, there are

currently no ofﬁcial guidelines on volume calibration.

Finally, it should be ensured that differences in par-

ticipants’ cognitive abilities are accounted for - this

could be addressed by administering a listening test

at the pre-experiment stage.

7 CONCLUSIONS

This paper presented the results of an in-lab evalu-

ation experiment in which participants listened to a

series of Japanese speech stimuli mixed with noise.

In line with the ﬁndings of previous research on En-

glish speech Govender et al. (2019), we found that

synthetic speech led to a faster increase in pupil size

(sharper curve) indicating more cognitive load. This

result was supported by participants’ perceptions who

rated synthetic speech as more cognitively taxing as

compared with natural speech. On the other hand,

we found that participants’ pupil oscillations were

stronger at higher levels of noise for natural speech

at the retention phase, but lower at the recall state in-

dicating the impact of external factors such as stress

or excessive level of noise (ceiling effect).

Although our results are preliminary, we have

shown that pupil oscillations can provide additional

measurements for cognitive workload of synthetic

speech in noisy listening conditions, and established

a baseline for future experiments. In order to fur-

ther validate the accuracy of our ﬁndings, future work

should investigate if our result can be replicated us-

ing diverse participant samples - to account for gen-

der speciﬁc hearing sensitivity (cf.McFadden (1998)).

We hope that our study will encourage discussion on

how other biological signals such as pupil oscillations

could expand TTS evaluation methods in future.

ACKNOWLEDGEMENTS

We would like to express our gratitude to Professor

Takao Kobayashi for his advice with selecting the

speech corpus for our study. We would also like to

thank all participants who took part in the experiment.

REFERENCES

Beatty, J. (1982). Task-evoked pupillary responses, process-

ing load, and the structure of processing resources.

Psychological bulletin, 91(2):276.

Duchowski, A. T., Krejtz, K., Krejtz, I., Biele, C., Niedziel-

ska, A., Kiefer, P., Raubal, M., and Giannopoulos, I.

(2018). The index of pupillary activity: Measuring

cognitive load vis-

a-vis task difﬁculty with pupil os-

cillation. In Proceedings of the 2018 CHI Conference

on Human Factors in Computing Systems, pages 1–13.

Govender, A. and King, S. (2018a). Measuring the cog-

nitive load of synthetic speech using a dual task

paradigm. In Interspeech, pages 2843–2847.

Govender, A. and King, S. (2018b). Using pupillometry to

measure the cognitive load of synthetic speech. Sys-

tem, 50:100.

Govender, A., Wagner, A. E., and King, S. (2019). Using

pupil dilation to measure cognitive load when listen-

ing to text-to-speech in quiet and in noise. In INTER-

SPEECH, pages 1551–1555.

HTS Working Group (2015). The Japanese TTS System

Open JTalk.

Kahneman, D. and Beatty, J. (1966). Pupil diameter and

load on memory. Science, 154(3756):1583–1585.

Kursawe, M. A. and Zimmer, H. D. (2015). Costs of storing

colour and complex shape in visual working memory:

Insights from pupil size and slow waves. Acta Psy-

chologica, 158:67–77.

Evaluating Synthetic Speech Workload with Oculo-motor Indices: Preliminary Observations for Japanese Speech

341

McFadden, D. (1998). Sex differences in the auditory sys-

tem. Developmental Neuropsychology, 14(2-3):261–

298.

Nakamura, K. and Gordon-Salant, S. (2011). Speech per-

ception in quiet and noise using the hearing in noise

test and the japanese hearing in noise test by japanese

listeners. Ear and Hearing, 32(1):121–131.

Nakayama, M. and Shimizu, Y. (2004). Frequency analysis

of task evoked pupillary response and eye-movement.

In Spencer, S. N., editor, Eye-Tracking Research and

Applications Symposium 2002, pages 71–76, New

York, USA. ACM, ACM Press.

Ohata, K. (2004). Phonological differences between

japanese and english: Several potentially problematic.

Language learning, 22:29–41.

Peysakhovich, V., Causse, M., Scannella, S., and Dehais, F.

(2015). Frequency analysis of a task-evoked pupillary

response: Luminance-independent measure of men-

tal effort. International Journal of Psychophysiology,

97:30–37.

Rabiner, L. R. (1989). A tutorial on hidden Markov models

and selected applications in speech recognition. Pro-

ceedings of the IEEE, 77(2):257–286.

Simantiraki, O., Cooke, M., and King, S. (2018). Impact of

different speech types on listening effort. In INTER-

SPEECH, pages 2267–2271.

Winn, M. B., Wendt, D., Koelewijn, T., and Kuchinsky,

S. E. (2018). Best practices and advice for using pupil-

lometry to measure listening effort: An introduction

for those who want to get started. Trends in hearing,

22:2331216518800869.

Zekveld, A. A., Kramer, S. E., and Festen, J. M. (2010).

Pupil response as an indication of effortful listening:

The inﬂuence of sentence intelligibility. Ear and hear-

ing, 31(4):480–490.

Zen, H., Senior, A., and Schuster, M. (2013). Statistical

parametric speech synthesis using deep neural net-

works. In Proc. ICASSP, pages 7962–7966.

BIOSIGNALS 2021 - 14th International Conference on Bio-inspired Systems and Signal Processing

342
